Ricoh eQuill Quick Start Manual

eWriter Solutions

TM

Designed for the way your work flows.

Ricoh eQuill

TM

Quick Start Guide

Release 1.0.0

© 2011 Ricoh Company, Ltd.

Getting Started

Step 1 — Charge the eQuill

a. Connect the small end of your Micro-

USB cable into the Ricoh eQuill Clip­board.

b. Connect the larger end into a USB port,

or the proper port on the AC adapter.
If using USB, the USB port must have
adequate current for charging. Note:
You can also place your eQuill in a multi­unit charger.

c. When the Ricoh eQuill Clipboard is fully

charged, the LED light is solid blue.

Step 2 — Turn It On

a. Slide the On/Off button to the left. The

On/Off button is located at the top of the
eQuill.

b. The LED light will blink blue while the

Ricoh eQuill Clipboard is starting up.
Note: If the LED blinks red three times,
or there is no blinking, charge the unit.

c. When the Ricoh eQuill Clipboard is

ready for use, the light will stop blinking.

d. Log in using the password supplied by

your administrator (if appropriate).

Step 3 — Go to your Inbox

a. Use the stylus (specialized pen) to tap

the Inbox icon.

b. Once you tap the Inbox icon, this takes

you to the Inbox page.

User Interface

The following figure shows the Inbox and
eQuill icons. Refer to “User Interface” in the
eQuill User’s Guide.

Step 4 — Open a Document

a. Tap on any document name to open it.
b. If there are no documents, see the eQuill

User’s Guide or your administrator to
add.

Step 5 — Write On It

The stylus is custom manufactured for the
Ricoh eQuill and is made to produce high
resolution markings. The stylus is used just
like a pen on paper — it writes and erases.

Step 6 — Submit (One-Button Routing)

When you press the Submit button, the doc­ument is routed to the next step of your
workflow, no matter how many different
workflows and servers your business sup­ports. The typical places it would be routed
to are an email address or backend system.
See the eWriter Workflow Services Adminis-
trator’s Guide to learn how to set the routing
destination.

Battery Indicator

You can determine that your Ricoh eQuill
Clipboard needs to be charged by checking
the power indicator at the top right of the
screen. If it is down to one bar, you should
charge your eQuill. If your eQuill is out of
power, you will not be able to turn it on, mark
on it, and in some cases, even see the
power indicator. If you try to power on the

device when it is out of power, the LED indi­cator will flash three times.

Turning Off the eQuill

Slide the On/Off button (top of eQuill), and
hold for seven seconds. The light will blink
blue when you first press the button.

LED Lights

In normal use, LEDs will only be used during
booting and shutting down. When in use,
blinking LEDs indicate eQuill status. When
off, you only get solid LEDs indicating charg­ing status.

eQuill Layout

Inbox Icon

Inbox

Temp l at e

Settings

Wireless Signal

Battery

Delete Refresh

Doc

Blank Forms

LED Light Description

No lights Unit is not charging; no

external power.

Red light blinks Unit tried to perform an unsuc-

cessful operation. Get help.

Blue light blinks Unit is performing an opera-

tion. Wait until completion.
Red light blinks 3x
only while charging

Power is critically low. Charge

the unit.
Solid blue Unit is fully charged.
Solid purple Unit is partially charged, but

may still be used.
Solid red Insufficient battery power.

Charge before use.

No Description No Description No Description

1 eQuill display 5 Backward Page

Flip Button

9 On/Off Button

2 Camera Display 6 Forward Page

Flip Button

10 Charging Contact

3 Shutter Button 7 Power Connector 11 Accessory Plug

4 Submit Button 8 LED Indicator 12 Camera Lens

— 2 ——3 ——4 ——5 ——6 —

Blank Forms and Documents

When you open a blank form by clicking
on it, it's like tearing off the top form of the
pad and making it a unique form that you
can then write on using the stylus.
Blank forms are assigned to a specific
Ricoh eQuill inbox (user account) for use.
A Ricoh eQuill Clipboard can support as
many as 500 active blank forms.

Important Settings

Settings Home Screen

Tapping the Settings icon allows the user
to view tablet information and allows
modifications to be made to the Tablet.

The following pages are accessed from
the General Settings page:

• Network Settings

• User Settings

• Tools Settings

• Software Settings

• About Settings

General

The General section of the page contains
the Airplane Mode settings. WiFi and cellular
service is disabled and enabled with the Air­plane Mode.

Other Settings

Each of the topics listed under Other Set­tings can be accessed by pressing the back­ward and forward page buttons, or by
tapping the arrow icon to the right of the
topic.

Network Settings

The Network Settings page displays Net­works, 3G and Connection information.

WiFi/MiFi

Network names are displayed in the box.
Only known networks are displayed and rec­ognized. Available networks are indicated by
a small circles to the right of the wireless
icon. Enter the network password at the
prompt to gain access. The wireless signal
strength is indicated by the wireless icon.
The refresh icon, when tapped, performs a
scan of local networks.

3G Radio

This section displays the 3G status of the
Tablet. The options are enabled or disabled.

Connection

This section contains the WiFi address, 3G
address, and other network information.

User Settings

The User Settings page displays the User ID
and Server information.

Tools Settings

The Tools Settings page displays Provision­ing, 3G Account, and Pen Calibration infor­mation.

Software Update Settings

The Software Settings page displays the cur­rent version of the software. The software is
updated by the Over the Air update process.

About Settings

The About Settings page displays hardware
information, 3G module information, and the
Legal information. The 3G information is
only displayed on those tablets that are
authorized for 3G service. The information in

this block is the information required for 3G
service.

Instructions For Care

The eQuill is not waterproof. If your device
does get wet, unplug all cables. Wait for the
device to dry completely before powering it
on. Do not attempt to dry your eQuill with an
external heat source, such as a hair dryer.
Clean the screen with a soft cloth; be careful
not to wipe it with anything abrasive.

Storage Requirements

When storing your eQuill, do not expose it to
extreme heat or cold.

Below are the storage requirements for your
eQuill.

• Temperature: -25° to +50° Celsius or -13°

to +122° Fahrenheit

• Humidity: < 80% non-condensing

How to Reach Us

Ricoh Innovations, Inc. EWS
2077 Gateway Place
San Jose, CA 95110 USA
Fax: [phone]
E-mail: [e-mail]
Website: www.ricoh-ews.com

© 2011 Ricoh Innovations, Inc.

Release 1.0.0

August 26, 2011
