Rice Lake INT300 Operation Manual

INT300

Waterproof Scale

Operation Manual

165215

Contents i

Contents

1.0 Introduction............................................................................... 1

1.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.2 Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.3 Weight Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

2.0 Operation................................................................................... 3

2.1 Power On/Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2.2 Zero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2.3 Tare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2.4 Set Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2.5 Checkweighing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

3.0 References ................................................................................ 5

INT300 Limited Warranty ...................................................................... 6

Technical training seminars are available through Rice Lake Weighing Systems.

Course descriptions and dates can be viewed at www.ricelake.com/training

or obtained by calling 715-234-9171 and asking for the training department.

© Rice Lake Weighing Systems. All rights reserved. Printed in the United States of America.

Specifications subject to change without notice.

Rice Lake Weighing Systems is an ISO 9001 registered company.

November 20, 2014

ii INT300

Rice Lake continually offers web-based video training on a growing selection

of product-related topics at no cost. Visit www.ricelake.com/webinars.

Introduction 1

1.0 Introduction

The INT300 is a waterproof scale, suitable for sanitary applications and general
weighing. It uses IP65 waterproof technology and ABS housing. The INT300 has low
power consumption with a rechargeable battery that provides 40 hou rs of continuous
use (when the back light is not in use). The INT300 sports a large 25mm LCD with
orange LED back light display.

1. 1 S af e ty

Safety Symbol Definitions:

Indicates a potentially hazardous situation that, if not avoided,
could result in serious injury or death and includes hazards that
are exposed when guards are removed.

Indicates a potentially hazardous situation that, if not avoided,
may result in minor or moderate injury.

Indicates information about procedures that, if not observed,
could result in damage to equipment or corruption of and loss of
data.

General Safety

Do not operate or work on this equipment unless you have read
and understand the instructions and warnings in this manual.
Failure to follow the instructions or heed the warnings could
result in injury or death. Contact Rice Lake Weighing Systems
for replacement manuals. Proper care is your responsibility.

Failure to heed may result in serious injury or death.

Disconnect all power to this unit before installing, cleaning, or servicing. Failure to
do so could result in bodily harm or damage the unit.

Permit only qualified persons to service the instrument.

Remove power before connecting or disconnecting any components.

DO NOT place the scale in direct sunlight.

Verify the local voltage and receptacle type are correct for the scale.

Only use the original adapter others could cause damage to the scale.

Pluggable equipment must be installed near an easily accessible socket outlet.

Avoid unstable power sources.

DO NOT use near large power equipment or large motors.

Avoid sudden temperature changes, vibration, wind and water.

Avoid heavy RF noise.

WARNING

CAUTION

Important

WARNING

2 INT300 Waterproof Scale

1. 2 Ke ys

1.3 Weight Display

Figure 1-1. Weight Display

Key Description

Turns the scale power on/off.

Subtracts weight of container.

Sets display to zero.

Table 1-1. Key Descriptions

Display Description

ZERO Zeroing display

STABLE Stable display

NET Net weight display

Low battery

HI High limits

LOW Low limits

CHARGING Recharging display

Table 1-2. Weight Display

POWER

TARE

ZERO

Operation 3

2.0 Operation

2.1 Power On/Off

T o power the scale on or of f, press . The display is switched on and the self test
starts. The scale takes 15 minutes to warm up and stabilize the measured values after

being turned on.

2.2 Zero

To zero the scale, press .

2.3 Tare

1. Place container on the pan.

1. Press . Zero is displayed and weight of container is subtracted.

1. Remove the container. Tared weight is displayed as a negative weight.

1. Press . Zero is displayed, tare weight is cleared.

2.4 Set Backlight

1. In weighing mode, press and hold . The display will show:

2. Press to change the display:

•

BK-AU – sets the backlight to turn on automatically

•

BK-oF – sets the backlight to turn off when not using the scale.

3. When set, press to confirm and return to weighing mode.

Backlight Color

•Red: High

•Green: OK

•Orange: Low

POWER

ZERO

TARE

TARE

ZERO

Bk-au

TARE

ZERO

4 INT300 Waterproof Scale

2.5 Checkweighing

1. In weighing mode, press and hold . Display will show:

(Hi limits set) and red backlight.

• Press to change the value.

• Press to change location.

2. When set, press . Display will show

(Low limits

set) and orange backlight.

• Press the key to change the value.

• Press to change location.

3. When set, press to confirm and return to weighing mode.

TARE

TARE

ZERO

ZERO

TARE

ZERO

ZERO

References 5

3.0 References

To set the following, see Section 5.0 Calibration in the INT300
Technical Manual, PN 165216.

• Enter Setting Mode

• Calibrate

•Set Resolution

• Change Capacity

• Check Internal Counts

• Automatic Sleep

Important

6 INT300 Waterproof Scale

INT300 Limited Warranty

Rice Lake Weighing Systems (RLWS) warrants that all RLWS equipment and
systems manufactured and sold by RLWS and properly installed by an authorized
RLWS Distributor or Original Equipment Manufacturer (OEM) will operate per
written specifications as confirmed by the Distributor/OEM and accepted by RLWS.
All systems and components are warranted against defects in ma terials and
workmanship for one year.

RLWS warrants that the equipment sold hereunder will conform to the current written
specifications authorized by RLWS. RLWS warrants the equipment against faulty
workmanship and defective materials. If any equipment fails to conform to these
warranties, RLWS will, at its option, repair or replace such goods returned within the
warranty period subject to the following conditions:

• Upon discovery by Buyer of such nonconformity, RLWS will be given prompt
written notice with a detailed explanation of the alleged deficiencies.

• Individual electronic components returned to RLWS for warranty purposes must
be packaged to prevent electrostatic discharge (ESD) damage in shipment.
Packaging requirements are listed in a publication, Protecting Your Components
From Static Damage in Shipment, available from RLWS Equipment Return
Department.

• Examination of such equipment by RLWS confirms that the nonconformity
actually exists, and was not caused by accident, misuse, neglect, alteration,
improper installation, improper repair or improper testing; RLWS shall be the sole
judge of all alleged non-conformities.

• Such equipment has not been modified, altered , or changed by any person other
than RLWS or its duly authorized repair agents.

• RLWS will have a reasonable time to repair or replace the defective equipment.
Buyer is responsible for shipping charges both ways.

• In no event will RLWS be responsible for travel time or on-location repairs,
including assembly or disassembly of equip ment, nor will RLWS be liable for the
cost of any repairs made by others.

THESE WARRANTIES EXCLUDE ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,
INCLUDING WITHOUT LIMITATION WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. NEITHER RLWS NOR DISTRIBUTOR WILL, IN ANY
EVENT, BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.

RLWS AND BUYER AGREE THA T RLWS’ SOLE AND EXCLUSIVE LIABILITY HEREUNDER
IS LIMITED TO REPAIR OR REPLACEMENT OF SUCH GOODS. IN ACCEPTING THIS
WARRANTY, THE BUYER WAIVES ANY AND ALL OTHER CLAIMS TO W ARRANTY.

SHOULD THE SELLER BE OTHER THAN RLWS, THE BUYER AGREES TO LOOK ONLY TO
THE SELLER FOR WARRANTY CLAIMS.

NO TERMS, CONDITIONS, UNDERSTANDING, OR AGREEMENTS PURPORTING TO
MODIFY THE TERMS OF THIS WARRANTY SHALL HAVE ANY LEGAL EFFECT UNLESS
MADE IN WRITING AND SIGNED BY A CORPORATE OFFICER OF RLWS AND THE
BUYER.
