Re:control M207
Touch Screen Remote Control
User’s Manual
Preface
Preface
About this manual
This manual is designed to make using the Re:control M207 Remote Control as
easy as possible. Information in this document has been carefully checked for
accuracy and is subject to change without notice.
Copyright
© Copyright 2004/8
This document is protected by the international copyright law. No part of this
publication may be reproduced by any means without the permission of REVOX
GmbH in Germany.
The information provided from REVOX GmbH is believed to be accurate. Any
changes and enhancements to the product and to the information thereof will be
documented and issued as a new release to this manual.
i
Table of Contents
PREFACE ....................................................................................................... I
TABLE OF CONTENTS ...............................................................................1
CHAPTER 1 INTRODUCING RE:CONTROL M207............................... 3
1.1 RE:CONTROL M207 FEATURES ...................................................................... 4
1.2 UNPACKING THE RE:CONTROL M207............................................................... 4
1.3 INSTALLING BATTERY....................................................................................5
1.3.1 Precautions for using battery............................................................... 6
1.4 TURNING THE TOUCH SCREEN ON ................................................................... 6
1.5 IDENTIFYING COMPONENTS ...........................................................................7
1.5.1 The front side of the re:control M207.................................................... 7
1.5.2 The rear side of the Re:control M207 ................................................... 8
1.5.3 Direct Access Buttons (Rubber Buttons)............................................... 9
1.5.4 LCD Touch Screen........................................................................... 10
1.5.5 Precautions of using touch screen ..................................................... 10
1.5.6 Touch screen keys ........................................................................... 11
CHAPTER 2 QUICK START..................................................................... 16
2.1 RE-CALIBRATE THE SCREEN......................................................................... 16
2.2 DATE / TIME SETTING ................................................................................. 17
2.3 DEVICE SETTING ....................................................................................... 18
CHAPTER 3 HOW TO SET YOUR RE:CONTROL M207 .................... 20
3.1 ADD A DEVICE ...........................................................................................20
3.1.1 Create a new device ........................................................................20
3.1.2 Load the codes for the newly-added device........................................ 22
A. Pre-code ....................................................................................................22
B. Learning .....................................................................................................24
3.2 ADD A SOFT KEY ....................................................................................... 26
3.3 ADD A TEXT ..............................................................................................28
3.4 RE-LABEL A DEVICE, KEY OR TEXT................................................................ 29
3.5 RE-SIZE A DEVICE, KEY OR TEXT ..................................................................31
3.6 DELETE A DEVICE, KEY OR TEXT .................................................................. 33
1
Re:control M207 User’s Manual
3.7 PRE-CODE ............................................................................................... 34
3.8 LEARNING................................................................................................ 37
3.9 LEARN A CYCLE KEY................................................................................... 39
3.10 DELETE DEVICE/KEY CODES...................................................................... 41
3.11 CREATE A MACRO .................................................................................... 42
3.11.1 Macro ........................................................................................... 42
3.11.2 Timer Macro .................................................................................. 45
A. Create a Timer Macro .............................................................................. 45
B. Delete Your Timer Macro .......................................................................... 47
C. Re-label Your Timer Macro ....................................................................... 48
D. View Your Timer Macro ............................................................................ 49
3.12 CREATE YOUR FAVOR ITE CHANNELS ........................................................... 50
3.12.1 Add the favorite channel keys.......................................................... 50
3.12.2 Set these Macros as your favorite channels...................................... 51
CHAPTER 4 MENUS.................................................................................. 52
4.1 SETTING.................................................................................................. 52
4.2 KEY LAYO UT .............................................................................................56
4.3 CODE SETTING ......................................................................................... 57
4.4 TIMER MACRO .......................................................................................... 58
4.5 DUPLICATE............................................................................................... 59
4.6 CALIBRATE............................................................................................... 61
CHAPTER 5 INSTALL USB CABLE AND SOFTWARE ....................... 62
5.1 INSTALL RE:CONNECT USB CABLE................................................................ 62
5.1.1 INSTALL THE DRIVER ............................................................................... 62
5.2 INSTALL UPGRADE TOOLS ........................................................................... 64
5.3 UPGRADE VMCU FIRMWARE AND VMCF PRE-PROGRAMMED CODES ................. 66
APPENDIX A ............................................................................................... 69
FEATURES..................................................................................................... 69
SPECIFICATIONS............................................................................................. 70
APPENDIX B ...............................................................................................71
OPTIONAL ACCESSORIES ................................................................................. 71
APPENDIX C ............................................................................................... 72
TROUBLESHOOTING TABLES ............................................................................. 72
2
Chapter 1 Introducing
Re:control M207
Congratulations on your purchasing Re:control M207 Remote
Control. The Re:control M207 is a digital Universal Remote Control
with smart function design that is easy to configure and use, enabling
you to control all your IR equipped electronic devices.
One of the main features is the touch screen control panel, which
could integrate the number of remote controls in one and reduce the
number of buttons for each device. The design makes it easy for you
to find the function you want. You can control up to 64 devices but
under 8 default categories such as TV, Satellite, VCR, DVD/VCD,
Amplifier/Receiver, CD/MD, Tuner/Tape and AUX.
There are more features for users to setup the Re:control M207 easily.
Combined with preprogrammed codes and Learning functions,
Re:control M207 enables you to easily configure each device at home
or office. Approximately 95% success rate in integration for all brands
of remotes verifies Re:control M207 with high compatibility.
Furthermore, you can also easily edit devices, change the LCD
appearance, and customize other settings.
Macro and Timer functions enable you to initiate a chain of 60
commands just by tapping a key. Besides, the Macro combined with
timer can operate automatically at specific times.
Although most of Universal Remote Controls have a code list for
various brands and static controlling functions, they can not provide
you with a lot of flexibility. With Re:control M207, you are able to add
or delete devices, to re-label devices or keys, and to change the size
and shape of the LCD soft keys. You can control all your devices with
one remote control. No longer will you have to search for several
different remotes!
3
Re:control M207 User’s Manual
1.1 Re:control M207 Features
This following list identifies Re:control M207 key features. For more
information on getting the most, please refer to the following
chapters.
1. Control up to 64 devices including VCD/DVD, TV, Satellite,
VCR, CD/MD, Receiver/Tuner, Tape, etc.
2. Large LCD touch-screen display with automatic backlighting for
visibility in dim environment.
3. Direct access buttons for accessing frequently used functions
such as volume, channel, play, mute and stop.
4. Excellent learning ability with auto learning guide
5. Huge preprogrammed codes database.
6. Motion detector enables users to power up remotes
automatically.
7. Fully customizable keys, devices, icons and layouts.
8. Each macro can store up to 60 commands with time delays.
9. Timer design enables macro to operate automatically.
10. With the optional Docking Station, users can charge Ni-MH
rechargeable batteries.
11. On-line upgradeable by the Upgrade Tools and editable by the
RemoteComm software.
1.2 Unpacking the Re:control M207
After unpacking the package, please make sure the following items
are included.
Re:control M207 Remote Control x 1 set
User’s Manual x 1 set
If any of above items is missing or appears damaged, please
contact your local dealer immediately. Do not throw the shipping
package away in case you need to ship your Re:control M207.
For the following optional accessories, you can contact local
retailers directly or attend to our web-site: www.revox.de
4
.
Chapter 1 Introducing Re:control M207
1.3 Installing Battery
Please refer to the following illustration and instructions for inserting
the batteries
1. Remove
battery
cover.
2. Insert batteries.
Ensure
that you
insert
the batteries
according to
the marking
inside the
battery case.
Figure 2-1: Inserting the batteries
The battery compartment is located at the back of Re:control M207.
1. Put your thumb in the battery cover slot and pull to remove the
cover.
2. Insert new batteries into the bay in the direction indicated in
the battery compartment.
3. Replace the battery bay cover. You will hear it click into place.
5
Re:control M207 User’s Manual
1.3.1 Precautions for using battery
Please pay attention to the following instructions:
1. Be sure that the positive (+) and negative (-) polarities of each
battery match the polarities indicated in the compartment.
2. Do not expose the batteries to excessive heat or flame.
3. Keep the batteries away from children.
4. Low power batteries will reduce the effective distance of the
unit.
5. Do not mix different type of batteries or mix new and used
batteries to use at the same time.
If you use Ni-MH rechargeable batteries, please pay
more attention to the followings.
a. Before the first use, please charge the batteries for
10 hours.
b. Do not recharge the batteries with an unqualified
charger.
c. When the battery low power warning icon appears,
please recharge batteries right away.
d. Please renew the batteries immediately when its
running time left is lower than half of preliminary after
they are fully recharged.
Warning:
When the battery low power warning icon
appears, you may not enter the Setup Menu to
operate the functions such as using learning function,
adding a Macro, or deleting devices.
1.4 Turning the touch screen on
There are three ways to turn on
Re:control M207:
1. Picking up the Smart Remote:
The motion detector design will
turns the Re:control M207 on.
2. Pressing any rubber key.
Figure 2-2: Turning the LCD on
6
3. Taping the LCD touch screen.
Chapter 1 Introducing Re:control M207
1.5 Identifying Components
Please refer to the following illustrations to identify the components
of the Re:control M207. This section provides you an overview of
the Re:control M207. For the detailed description on operation,
please refer to Chapter 3.
1.5.1 The front side of the re:control M207
1. Light Sensor (P.53)
The Light Sensor will detect the
ambient brightness or dimness
to control the backlight whether
turn on or not.
2. LCD (P.11)
The LCD screen enables you to
configure and control your
devices on it by taping the
screen. In addition, you can tap
the screen to power on the
Re:control M207.
3. Hard key (P.9)
You can operate the most
frequently-used functions by
pressing these hard keys.
4. Transmission port (P.71)
Figure 1-1: Front view
With the port, you can connect
your PC and the Re:control
M207 with the Re:connect USB
cable.
7
Re:control M207 User’s Manual
1.5.2 The rear side of the Re:control M207
Figure 1-2: Rear view
1. IR Port
You can point the IR port at the IR
receiver of targeted device to
control the unit.
2. Reset switch
You can reset the Re:control M207
while the Re:control M207 can’t
work properly or hang on.
3. Back label
Back label marks the model
number and the briefly
specifications.
4. Buzzer hole
Beeps signal are released from
here.
5. Battery compartment
You can remove the cover to
replace the 3xAAA alkaline
batteries or Ni-MH rechargeable
batteries.
6. Learning eye (P.37)
The Re:control M207 receives the
IR codes from here and saves the
corresponding codes. Makes the
original remote control point at the
Learning eye of the Re:control
M207 and press the corresponding
buttons to send out the IR signals.
In this way, the Re:control M207
will learn the IR codes from your
original device.
8
Chapter 1 Introducing Re:control M207
1.5.3 Direct Access Buttons (Rubber Buttons)
The Direct Access Buttons provide you with easy access to
often-used functions such as volume and channel control, fast
forward and fast reverse, play and stop, etc. Before use, you have
to set up the Re:control M207 first. (Refer to Chapter 3 How to Set
Your Re:control M207, Page20.)
Figure 1-3: Direct access buttons
Setup mode function Device normal function
● Enter the setup menu by press it for
n
about 1 second.
● Exit the setup item and back to last setup
mode.
● Enter the submenu
o
● Confirm the setup item
● Select the items ● Channel up or channel down button.
p
● Change the degree of the selected item. ● Volume up or volume down.
q
● No function ● Device power button: Press the button to
r
● No function ● Mute function.
s
● Back to the Main menu.
● Turns on the backlight.
● Play or Stop function.
● Forward or back function.
turns on the selected device.
● Open the disk/ tape
9
Re:control M207 User’s Manual
* These buttons function differently according
to the currently selected device.
1.5.4 LCD Touch Screen
The LCD (Liquid Crystal Display) touch screen enables you to
configure and operate your Re:control M207 with the touch of a
finger.
1.5.5 Precautions of using touch screen
Please pay attention to the following instructions:
1. Do not tap the LCD touch screen fiercely. Tap the LCD Touch
Screen gently.
2. Do not use a pen or any sharp object to tap the screen. You
might damage the surface. You can use a blunt object such as a
pencil eraser or the cap of a pen.
3. Do not immerse it in liquid. Keep the Remote dry. Wipe off any
spills immediately because the Re:control M207 is not
waterproof.
4. Do not expose the Re:control M207 to extreme temperatures.
Keep it away from heat sources.
5. Do not drop the Re:control M207.
6. Do not put anything on the touch screen.
7. Do not use abrasives or cleaning solutions to clean the
Re:control M207. If needed, dampen the clean soft cloth slightly
with clean water before cleaning.
10
Chapter 1 Introducing Re:control M207
1.5.6 Touch screen keys
The touch screen keys enable you to control your devices as you
would do with your original remote control. Besides, you can set up
macros, program timers and cycle key and configure the LCD screen
as many as you want.
Figure 1-4: Touch screen buttons
It is very easy to use the touch screen. You just need to tap the soft
buttons to active the specific function. As Figure 2-3, each button with
functionality is stated as below. Before use, you have to set up the
Re:control M207 first. (Refer to Chapter 3 How to Set Your Re:control
M207, Page 20.)
Introducing the frequently used LCD Layout as followed:
11
Re:control M207 User’s Manual
y Main Menu
Press the Menu button to call out the Main
Menu.
n The access to Timer Macro.
o The access to the basic information
about the remote.
p Device key
q Tap the right or left icon to
change the pages.
r Page indicator. It means that there
are totally 2 pages and you are in the first
one. There are totally 8 pages in Main
Menu.
y Device Layout
Tap the device key directly to enter the device
page.
12
n TV Device name (P.20 )
o Soft key in the device (P.26)
p Cycle key (P.39)
q Macro key (P.42)
Chapter 1 Introducing Re:control M207
y Basic Information Layout
After pressing the icon, you can get
the basic information as follow:
n Date information (P.52)
o Time information (P.52)
p Buzzer information (P.52)
q Batteries power indicator ( P.52)
r Program version
s Pre-programmed code version
y Timer Macro Layout
After pressing the icon, you can get
the Timer Macro layout as follow:
n Tap the Timer Macro key
directly to start the macro function.
(P.45)
o If the Macro has been set, the
symbol will been shown next to the
Macro key. (P.45)
p If the Timer has been set, the
symbol will been shown next to the
Macro key. (P45)
q Page indicator. It means that
there are totally 8 pages in Timer
Macro function and you are in the first
page. There are totally 32 Timer
Macros for your use.( P.45)
13
Re:control M207 User’s Manual
y Setup Menu Layout
When you are under the setup status you will see the icons as
followed:
n Help Guide. Tap this icon to get the setup process
information.
You can press or to read the information pages.
After reading the tips, press “ Enter” button to exit.
o Under the setup mode you will see the icons show on the
top right of the screen. The fast way to edit the Re:control
M207 is tapping the icon directly to exchange the edit
functions directly. You don’t need to exit back to the setup
menu for exchange the edit function. Every icon’s function
is introduced as follow.
Key Layout Setup Mode
o Tap the icon directly to exchange the
functions in Key layout.
Add Device (P.20)
Add Key (P.26)
Add Text (P.28)
Re-label (P.29)
Re-size (P.31)
Delete Key (P.33)
14
Code Setting Setup Mode
o Tap the icon directly to exchange the
functions in Code Setting.
Pre-code (P.34)
Learning (P.37)
Macro (P.42)
Cycle key (P.39)
Delete code (P.41)
Enter code number (P.34)
Chapter 1 Introducing Re:control M207
o Tap the icon directly to exchange the
* When you are adding or editing the macro
Timer Macro Setup Mode
functions in Timer Macro.
Add / Edit the Timer Macro
Re-label the Timer Macro
Delete Timer or Macro
View Macro processes
processes two icons shows as below:
n When setting the Macro processes
tap this icon to goes back to last
Macro step. (Please refer to Page )
o Set delay between two commends
15
Chapter 2 Quick Start
In this chapter, you are able to know how to set up the Re:control M207
quickly without through complicate procedure.
When turn on the Re:control M207, at first you will see the welcome
greeting message shown on the screen. From now on, you formally
enter the setup procedure. Please operate by the following instructions
step by step.
2.1 Re-calibrate the screen
1. Press button for 1 second for entering Setup Menu.
2. Scroll the
press
3. Scroll the
press
screen calibration.
4. Tap the 5
When finished, the screen will go back to previous “Setting” menu
automatically.
or buttons to choose Setting item and
button for entering “Setting” menu.
or buttons to select Calibrate item and
button for entering “Calibrate Panel” operation screen for
places following up screen indication step by step.
If you want to exit from the current display, please press
button until back to the main menu.
16
Chapter 2 Quick Start
2.2 Date / Time setting
1. Press button for 1 second for entering Setup Menu.
2. Scroll the
and press
3. Scroll the
and press
the year column with underline and means it is ready to be
input current date by pressing
you are able to move the underline forward and backward to
target any column by pressing
4. Set up actual date and date format as you want. When
everything is done, press
or buttons to choose Setting item
button for entering “Setting” menu.
or buttons to select Date item
button for confirmation. After that, you will find
and button, and
and button.
button to confirm and exit.
5. Continuously to setup time, scroll the cursor and choose
Time item and press
will find the hour column with underline and means it is ready
to be input current time by pressing
and you are able to move the underline forward and backward
to target any column by press
6. Input actual time and choose suitable time format as you want.
When everything is done, press
exit.
If you want to exit from the current display, please press
button until back to the main menu.
button for confirmation. Also, you
and button,
and button.
button to confirm and
17
Re:control M207 User’s Manual
2.3 Device setting
1. Turn on the targeted device for the Re:control M207 to setting the
device.
2. The Re:control M207 will directly get throw the setup mode when
you operate the Re:control M207 at first time. Please tap the
target device key in the Main Menu to enter “Setup device” menu.
(ex. “TV” device)
* Pre-code: load pre-programmed IR code from the factory
default (no guarantee being able to control all brand
devices).
3. Pressing the
press
4. Choose the first letter of targeted device brand (ex. n “S” on
behalf of Sony, Samsung…etc ), and point the Re:control
M207 at the targeted device, and then tap
to start auto searching.
5. As you see the targeted device has been turned off, please tap
or press any buttons to stop auto searching right away. Tap
or p gently to figure out the correct remote code
(Code number as shown on the top middle position of the
LCD.) till the targeted device has been turned on again. Press
the power key or the hard key to test the codes to confirm the
code. If the codes aren’t correct please continue repeat step
4-5 again to search the proper code for your target device.
6. Finally, press
or buttons to choose “Yes” item and
button for entering the operation mode.
button to load the code and exit.
o soft button
18
Chapter 2 Quick Start
If you didn’t get completely correct remote codes from
“Pre-programmed code list” item, or you did wrong steps,
please try the other ways to re-setup or supplement.
a. Use Pre-code function to load current remote codes.
(Please refer to 3.1.2 A. Pre-code page22.)
b. Use Learning function to learn all or part of correct
remote codes. (Please refer to 3.1.2 B. Learning
page24.)
Since now, you are able to control your devices by the Re:control
M207. For more information about advanced operation functions,
please go toward next chapter.
19
Chapter 3 How to Set Your
Re:control M207
In this chapter, you can find all the topics about how to setup the Smart
Remote. Each topic has its detailed instruction. You can easily customize
the Smart Remote by the procedures.
3.1 Add a Device
With the function, you are able to create a new device for the Smart
Remote. There are two main stages for you to add a device
successfully. The first one is to create a new device in the main menu.
The second one is to load the specific codes for your newly-added
device.
3.1.1 Create a new device
1. Please press the button for 1 second to enter Setup Menu.
And then press the
2. Select the
submenu.
3. On taping the soft button, you will see the indication for the
function. After reading the tips, please press the
to the next step.
to enter “Key Layout” menu.
Add Device item by press the to enter the
button to go
20
Chapter 3 How to Set Your Re:control M207
4. Please choose two points within the desired block on LCD. A “v”
symbol will appear where you tapped. After you determine the
second point, the key frame will show up on the screen
automatically. Tap the frame to confirm the location.
If you want to relocate the points, you can press the
button
to quit.
a. The size of the key will depend on the points you choose.
b. You cannot setup a device that will overlap the adjacent
keys.
5. After deciding the location, please name the device by taping the
keypad on the screen.
Select letters Tapping the
key to select the
capital letters, lower case letters or special
text for your selection.
Select Icons Tapping the
key to select more
symbols.
Delete letters/icon Tapping the
key if you want to delete
the letters or symbols.
Next row: Tapping the
And then press the
button to confirm your decision.
key to enter the next row.
6. Please decide the “Device Category” for your device by pressing
the
or buttons. Press the to confirm and enter
next step.
21
Re:control M207 User’s Manual
7. Finally, please decide how you will load the IR remote codes for
the device. There are three choices for you: “Pre-code”,
“Learning” and “Done”. More detail please refer to the following
sections to get further understanding.
3.1.2 Load the codes for the newly-added device
When adding a new device successfully, you will be asked if you
will load the codes for your device. There are two ways to load IR
remote codes for your newly-added device: “
“
Learning”. Please choose one of these two ways to load the
codes. If you don’t want to load any codes for the device, just select
“Done” to finish the setting process.
A. Pre-code
The Re:control M207 is equipped with a mass pre-programmed
code database. With the function, you are able to load the remote
codes for your device. It also enables you to control the device
even if you lose your original remote.
1. When you successfully add a new device, please decide if you
continue to load the codes for the device. If you want to use
“pre-code” to load the codes, please choose this item.
2. Please select the brand of your device. You just need to select
the first letter of your brand. For example,n if your device
belongs to Sony, please select “S” as your brand.
Pre-code” and
22
Chapter 3 How to Set Your Re:control M207
When you are in this page, you will find out an icon
located on the top-right position. It is “Key Pad Entry”
function. You can key in the number for your codes
directly by searching from the “Pre-programmed code list”.
In this way, you can save some time than using the auto
searching function. However, each brand may have
several codes. You may need to load the codes to test the
correct codes for your device.
3. After selecting “Brand” item, please make sure that the targeted
device is turned on.
4. Please have the Re:control M207 pointed to your device and tap
“GO
” o to start auto searching.
5. When the Re:control M207 finds out the correct remote code for
your device, your device will be turned off. Please tap or press
any button on the Re:control M207 to stop auto searching.
6. Please press or p key to ascertain that the remote
codes are suitable for your device. Press the power key or the
hard key to test the codes to confirm the code. If the codes
aren’t correct please continue repeat step 4-5 again to search
the proper code for your target device.
7. If they work, it means that you have already found the correct
remote codes. Please press
button to confirm your
decision.
23
Re:control M207 User’s Manual
B. Learning
With the function, the Re:control M207 is able to learn IR remote
codes directly from your original remote. You can also control your
device if you fail to get the right remote codes in the
pre-programmed code database.
When using the learning function, please have your original remote pointed
to the “Learning Eye” at the bottom of the Re:control M207 as the Figure
3-1.
24
Figure 3-1: Using the Learning eye
Chapter 3 How to Set Your Re:control M207
1. When you successfully add a new device, please decide if you
continue to load the codes for the device. Choose the
“
Learning” item, to get the remote codes.
2. The specific key needs to be learned will be shown in black on
LCD. The Re:control M207 will automatically guide you to
learn the remote code for each key one by one. However, you
can also change the sequence as you like by taping any key
you want to learn.
=
3. At the moment, please have your original remote pointed to
“Learning Eye” (P.8) at the bottom of the Re:control M207.
And then press the corresponding key on your original remote
for about 2-3 seconds “UNTIL” the symbol
LCD to make sure the Re:control M207 learn the code
completely.
The first page will guide you to learn the rubber keys on the
Re:control M207 step by step.
shows up on
25
Re:control M207 User’s Manual
4. The symbol will show up when the Re:control M207
learns remote codes successfully. However, the symbol
will show up when the Re:control M207 fails to learn the
remote codes. If the Re:control M207 fails to copy the remote
code please repeat step3.
5. Please press the
button when you finish learning all keys.
learning
successfully
Learning fail
The preset layout for your device
may not match your original remote
completely. Please use “Add Key”
(Page 26) and “Delete” (Page 33)
functions to adjust the layout.
3.2 Add a Soft Key
With the function, you are able to create a new soft key in your devices.
There are two main stages for you to add a soft key successfully. The
first one is to create a new soft key in your target device. The second
one is to load the specific code for your newly-added soft key.
1. Please press the
Menu. And then enter “Key Layout” menu.
2. Please choose the “
submenu.
3. On tapping the soft key, you will see the indication for the function.
After reading the tips, please press the
step.
button for about 3 seconds to enter Setup
Add Key” item and then you will enter the
button to go to next
26
Chapter 3 How to Set Your Re:control M207
4. Please choose two points from the blocks on LCD. A “v” sign will
appear where you tapped. After you determine the second point, the
key frame will show up on the screen automatically. Tap the frame to
confirm the location.
If you want to relocate the points, you can press the
button to
quit.
a. The size of the key will depend on the points you choose.
b. You cannot setup a soft key that will overlap the adjacent
keys.
5. Please select the shape for the new soft key. There are two choices
for you: Rectangle and Ellipse. You can confirm your selection by
tapping the soft key or pressing the
6. After deciding the location, please name the key. (Please refer to
page 22 for name the key.) And then press the
confirm your decision.
You can add new keys in every device together then input the
IR codes at the same time. You can use “ Learning” function
to get the corresponding remote code for your newly-added soft
key at one time. Please refer to Chapter 3.8 Learning (P.37) for
more information.
button.
button to
27
Re:control M207 User’s Manual
3.3 Add a Text
With the function, you are able to add a description for a specific
device or soft key.
1. Please press the
And then enter “Key Layout” menu.
2. Please choose the “
the submenu.
3. On tapping the soft key, you will see the indication for the function.
After reading the tips, please press the
step.
button for 1 second to enter Setup Menu.
Add Text” item and then you will enter
button to go to next
28
4. Please choose two points from the blocks on LCD. A “v” sign will
appear where you tapped. After you determine the second point,
the key frame will show up on the screen automatically. Tap the
frame to confirm the location.
If you want to relocate the points, you can press the
to quit.
5. Please add your description to the text and press the
to confirm your words.
button
button
Chapter 3 How to Set Your Re:control M207
a. The words you can add to the description will
depend on the points you choose.
b. You can add a text to not only for a specific device
but a soft key. To add a description to a soft key,
you just need to choose the specific device in
advance and follow the former steps.
3.4 Re-label a Device, Key or Text
With the function, you are able to rename a device, soft key or text.
1. Please press the
And then enter “Key Layout” menu.
2. Please choose the “
submenu.
3. On tapping the soft key, you will see the indication for the function.
After reading the tips, please press the
step.
4. Please select the device you want to rename.
button for 1 second to enter Setup Menu.
Re-label” item and then you will enter the
button to go to next
5. And then you need to make a decision: to re-label the device itself
or to go into device to re-label its soft keys.
Re-label device: If you decide to re-label the device, please key
in the new name. And then press the
decision.
Into device: If you decide to re-label the soft key in the device,
please choose the key you want to rename and key in the new
name.
button to confirm your
29
Re:control M207 User’s Manual
Select letters Tapping the
key to select the
capital letters, lower case letters or special
text for your selection.
Select Icons Tapping the key to select more
symbols.
Delete letters/icon Tapping the
key if you want to delete
the letters or symbols.
Next row: Tapping the
And then press the
button to confirm your decision.
key to enter the next row.
6. If you want to re-label the text, please select the text you want to
change and follow step 4.
You can continue to select other keys to rename until
you finish renaming all keys.
30
Chapter 3 How to Set Your Re:control M207
3.5 Re-size a Device, Key or Text
With the function, you are able to re-size a device, soft key or text. You
can also use the function to change the locations for them.
1. Please press the
And then enter “Key Layout” menu.
2. Please choose the “
submenu.
3. On tapping the soft key, you will see the indication for the function.
After reading the tips, please press the
step.
button for 1 second to enter Setup Menu.
Re-size” item and then you will enter the
button to go to next
4. Please select the device you want to resize.
5. Making a decision to re-size the device itself or to go into device
to re-size its soft keys.
Re-size Device: To re-size the device.
Into Device: To re-size the soft key in the device.
6. Choose two points from the blocks on LCD. A “v” sign will appear
where you tapped. After you determine the second point, the key
31
Re:control M207 User’s Manual
frame will show up on the screen automatically. Tap the frame to
confirm the location.
If you want to relocate the points, you can press the
quit.
The way to re-size a soft key is similar to the way
to add a soft key.
You cannot revise a soft key device that will
overlap the adjacent keys.
button to
32
Chapter 3 How to Set Your Re:control M207
3.6 Delete a Device, Key or Text
With the function, you are able to delete a device, soft key or text.
1. Please press the button for 1 second to enter Setup Menu. And
then enter “Key Layout” menu.
2. Please choose the “
submenu.
3. On tapping the soft key, you will see the indication for the function.
After reading the tips, please press the
Delete” item and then you will enter the
button to go to next step.
4. Please select the device you want to delete. And then you need to
make a decision: to delete the device itself or to go into device to
delete its soft keys.
5. If you select a device to delete, you will see a message to confirm
your decision. Please choose “Yes” or “No” to confirm your decision.
6. If you go into device to delete its soft keys, you will delete the key
directly by tapping the soft key.
7. If you want to delete a text, please touch the text directly.
33
Re:control M207 User’s Manual
8. Please press the button to exit after you finish the delete
function.
If you have saved the remote codes in the device or the soft
key, “Delete” function will erase not only the icons but also
the remote codes. You will see a message to confirm your
decision, when the Re:control some codes are saved in your
target.
3.7 Pre-code
The Re:control M207 is equipped with a mass pre-programmed code
database. With the function, you are able to load the code for your
device. It also enables you to control your device even if you lose your
original remote.
1. Please press the button for 1 second to enter Setup Menu. And
then enter “Code Setting” menu.
2. Please choose the “
enter the submenu.
3. You will see the indication for the function. After reading the tips by
press the
the tips, press
4. Please select the device which you want to load the remote codes.
5. After pressing the soft key, you will see the help guide for the
function. After reading the tips, please press the
the next step.
or to read the information pages. After reading
Pre-code” item and press the button to
button to exit and enter the next step.
button to go to
34
Chapter 3 How to Set Your Re:control M207
6. Please select the brand of your device. You just need to select the
first letter of your brand. For example, if your device belongs to Sony,
please select “S” as your brand n.
In this page, you will find out an icon
“Key Pad Entry” function. You can key in the
code number for your device directly. In this way,
you are able to save the time to load the
corresponding codes. However, each brand may
have several remote codes. You may need to
load the remote codes for some times to find out
the correct codes for your device.
or
. It is
7. After selecting “Brand” itemn, please make sure that the device is
turned on.
8. Please have the Re:control M207 pointed at your device and tap
osoft button to start auto searching.
9. When the Re:control M207 finds out the correct remote code for your
device, your device will be turned off. Please tap or press any button
on the Re:control M207 to stop auto searching.
10. Please press
or p key to ascertain that the remote
codes are suitable for your device. Press the power key or the hard
key to test the codes to confirm the code. If the codes aren’t correct
please continue repeat step 4-5 again to search the proper code for
your target device.
11. If they work, it means that you have already found the correct remote
codes. Please press
button to confirm your decision.
If they don’t work, please continuing the auto search by repeat the
step 8 ~ step10. After the Pre-code auto search are finished the LCD
will shows up the “Search completely” message and the “OK” icon.
Tap the “OK” to exit the auto search. This means this IR codes
35
Re:control M207 User’s Manual
doesn’t included in the Re:control M207 pre-code database. If you
can’t use Pre-code to load correct code for your device please try by
“Learning Function” at next chapter
36
Chapter 3 How to Set Your Re:control M207
3.8 Learning
With the function, you are able to use the Re:control M207 to learn IR
remote codes directly from your original remote. You are able to control
your devices with the Re:control M207, even if the code for your device
is not included in the database.
a. Although the learning function is able to copy almost all the IR
remote codes. There are still very few special codes that the
Re:control M207 cannot learn directly.
b. When using the learning function, please have your original
remote pointed to the “Learning Eye” port at the bottom of the
Re:control M207.
Using the Learning eye
37
Re:control M207 User’s Manual
1. Please press the button for 1 second to enter Setup Menu. And
then enter “Code Setting” menu.
2. Please choose the “
button to enter the submenu.
3. You will see the help guide for the learning function. After reading the
tips, please press the
4. Please select the device which you want to catch the remote codes.
5. After pressing the device key, the specific key needs to be learned
will be shown in black on LCD. The Re:control M207 will
automatically guide you to learn the remote code for each key one by
one. However, you can also change the sequence as your will by
taping any key you want to learn.
Learning” item and then please press the
button to go to the next step.
38
=
6. At the moment, please have your original remote pointed to the
“Learning Eye” port at the bottom of the Re:control M207. And then
The first page you see will guide you to learn each remote code
for the rubber keys on the Re:control M207.
Chapter 3 How to Set Your Re:control M207
press the specific key on your original remotes for about 2-3 seconds
until the symbol
7. The symbol
remote codes successfully. However, the symbol
shows up on LCD.
will show up when the Re:control M207 learns
will show up
when the Re:control M207 fails to learn the remote codes. Please
repeat step 5. to learn the remote code if the Re:control M207 fails to
copy it.
8. Please press the
button when you finish learning all keys.
learning successfully Learning fail
The preset layout for your device may not match
your original remote completely. Please use
Add Key” (Page 26) and “Delete” (Page
“
33) functions to adjust the layout.
3.9 Learn a Cycle key
Some devices save a circle of commands in one button. For the special
design, the Re:control M207 is equipped the Cycle function. With the
function, you are able to send the circle of commands.
1. Please press the
then enter “Code Setting” menu.
2. Please choose the “
to enter the submenu.
button for 1 second to enter Setup Menu. And
Cycle” item and then press the button
39
Re:control M207 User’s Manual
3. On pressing the soft key, you will see the direction for the function.
After reading the tips, please press the
step.
button to go to the next
4. Please choose any of keys (except Device key) you will use as Cycle
keys.
5. Please have your original remote pointed to the ”Learning Eye” at the
bottom of the Re:control M207. And then press the corresponding
key on your original remotes for about 2-3 seconds until the symbol
shows up on LCD.
You can save 6 cycle commands at most in the Cycle key.
6. Please press the
button when you finish learning all the circle of
commands.
When you have saved some commands in a
Cycle keys, a specific sign will be marked on
the Cycle key.
40
Chapter 3 How to Set Your Re:control M207
3.10 Delete Device/Key codes
With the function, you can delete the codes in the keys.
1. Please press the
then enter “Code Setting” menu.
2. Please choose the “
3. On pressing the soft key, you will see the direction for the function. After
reading the tips, please press the
button for 1 second to enter Setup Menu. And
Del.Code” item and then enter the submenu.
button to go to the next step.
4. Please select the device you want to delete. And then you need to
make a decision: to delete all the codes for the device or to go into
device to delete the codes for its keys.
5. If you select a device to delete, you will see a message to confirm
your decision. Please choose “Yes” or “No” to confirm your decision.
6. If you go into device to delete the codes for its keys, you will delete
the codes directly by taping the soft keys.
The “Del.Code.” function is similar to “Delete” (P33)
function. However, “Del.Code” just deletes the codes
for the keys. “Delete” will delete both the keys and
codes.
41
Re:control M207 User’s Manual
3.11 Create a Macro
The “Macro” function enables you to send a series of commands with
just one key. The features for Macro function are as follows:
1. You can save up to 60 commands with in one Macro key. You can
use any keys except Device key as your Macro.
2. You are able to setup some delays between two commands.
3. You can go to the Main Menu and press the top-left icon
access “ Timer Macro” function.
4. During the Macro transmission, all commands will be shown on the
LCD while they are sending.
5. The Re:control M207 is equipped with two types of Macros: “ Macro”
and “Timer Macro”
3.11.1 Macro
With the function, you can use all the keys (except for device key, Macro
key and Cycle keys.) as Macros. The Macro enables you to send a
series of commands just with one key.
1. Please press the
then enter “Code Setting” menu.
2. Please choose the “
3. On pressing the soft key, you will see the direction for the function.
After reading the tips, please press the
step.
button for 1 second to enter Setup Menu. And
Macro” item and then enter the submenu.
to
button to go to the next
42
4. Please select any key in devices as the commands (except for
Chapter 3 How to Set Your Re:control M207
device key, Macro key and Cycle keys.) for the Macro key. You can
save 60 commands at most in a Macro.
a. You can press the icon n to go back the former
command you select.
b. You can press the icon o to setup the delay
between two commands from 0 to 30 seconds.
5. Please press the
button to confirm your decision.
When you have set a soft key as a Macro
key, a specific sign will be marked a black
triangle on the key.
43
Re:control M207 User’s Manual
An Example to Add a Macro
The basic devices in operation:
1. Turn the TV on.
2. Switch the TV to video mode.
3. Turn the DVD on.
4. Create a two-second delay.
5. Instruct the DVD to play a disc.
The commands for the Macro key.
1. Press the TV device button.
2. Press the Power buttons.
3. Press the TV/Video button.
4. Press the DVD device button.
5. Press the Power button
6. Press the Time Delay icon.
7. Use the Up and Down arrows to select a time delay.
8. And, press
9. Press the Play button.
10. Press
11. Press
The correlation table could be shown as below:
The Basic Device Operation The Required Macro Sequence
Turn the TV on.
Switch the TV to video mode.
Turn the DVD on.
Create a two-second delay.
Instruct the DVD to play a disc
to confirm time delay.
to save Macro
button 4 times to exit and return to main Menu.
1. Press the TV device key.
2. Press the Power key.
3. Press the TV/Video key.
4. Press the DVD device key.
5. Press the Power key
6. Press the Time Delay icon.
7. Use the Up and Down arrows to
select a time delay.
8. Press
9. Press the Play key.
to confirm time delay.
44
Completion
10. Press to save the Macro key
11. Press the
return to main Menu.
button 4 tim to
Chapter 3 How to Set Your Re:control M207
3.11.2 Timer Macro
A. Create a Timer Macro
The “Timer” function enables you to set up devices to turn on at
specified times. It can be used to operate a Macro function
automatically at a specific time. The function helps you to record
movies, turn on music, act as an alarm clock, or implement
Home Automation. You can enjoy the marvelous convenience
after setting the Timer Macro.
The Re:control M207 is quipped with 32 sets of Timer Macros.
1. Please press the
Menu. And then enter “Macro/Timer” menu.
2. Please choose the “
submenu.
3. There are totally 32 Macro keys for you to setup. Please
select one Timer Macro as your will.
button for 1 second to enter Setup
Add/Edit” item and then enter the
You can press the icon
corner to setup the delay between two
commands.
4. Please select any keys in devices as the commands for the
Timer Macro. You can save 60 commands at most in one
Timer Macro.
at the top-right
45
Re:control M207 User’s Manual
a. You can press the icon at the top-left
corner to go back the former command you
select.
b. You can press the icon
delay between two commands, if your
device needs time to responds from 0 to 30
seconds.
to setup the
5. Please press the
button to confirm your decision. And
then please decide if you will setup a Timer for the Timer
Macro.
6. If select “No”, you can confirm and exit the Macro setup
commands. You can repeat the step3-5 to setup more
Timer Macro.
If select “Yes”, you can press the
decide at what time by press the
hour or press the
and to change the items.
soft keys as n to
and to set the
Tap the date or weekday soft key as o to setup the
operate time for the Macro function. The section you
choose will be in black.
46
Chapter 3 How to Set Your Re:control M207
a. In setting the Timer, you need to make a choice between
date and weekday.
b. If a Timer Macro has been set, A tinny mark
been shown beside the Macro key
If the Macro has been set, the symbol will been
shown next to the Macro key.
If the Timer has been set, the symbol will been
shown next to the Macro key.
Example indicates as follows:
will
B. Delete Your Timer Macro
With the function, you are able to delete Timer Macros as your
will.
1. Please choose the “
submenu.
Delete” item and then enter the
2. Please select the Macro/Timer key you intend to delete
3. And then please decide if you want to delete the Macro or
the Timer.
47
Re:control M207 User’s Manual
If you delete the Timer Macro, you will erase the
Timer along with it at the same time.
C. Re-label Your Timer Macro
With the function, you can easily re-label your Timer Macros.
1. Please choose the “
submenu.
2. Please select the Timer Macro you intend to re-label
3. Please key in the new name for the Timer Macro. And then
press the
button to confirm your decision.
Re-label” item and then enter the
48
Chapter 3 How to Set Your Re:control M207
You can also press the” Icon” key to add different
icons to the Timer Macro.
D. View Your Timer Macro
With the function, you are able to view all the Macro commands and
the timer in the Timer Macro you selected.
1. Please choose the “ view” item and then your will enter
the submenu.
2. Please select the Time Macro you intend to
view.
3. Please press
and to view the
commands in turns.
4. Please tap the icon
at the top-right
corner to view the timer. If this Macro
doesn’t set the Timer in,
icon won’t
shows up.
5. Please press the
button to return the
former menu.
49
Re:control M207 User’s Manual
3.12 Create Your Favorite Channels
You can use Macros to save the channels you like. In this way, you are
able to get your favorite channels just by taping Macros. There two main
steps you need complete: Add some soft keys as Macros and Set these
Macros as your favorite channels.
3.12.1 Add the favorite channel keys
1. Please decide the place where your favorite channels will be
located. You can create these keys in any device or just in the
Main Menu.
2. Please refer to Section 3.2 to know how to add a soft key.
3. You can save similar types of channels in the same pages. For
example, you can save CNN and BBC in the 3rd page and
save HBO and Star Movies in the 4th page.
4. If you like, you can also add some texts for these favorite
channels. For example, you can add “News” to the 3rd page
and “Movies” to the 4th page.
50
Chapter 3 How to Set Your Re:control M207
3.12.2 Set these Macros as your favorite channels
1. It is the same as the way to set Macro. (Please refer to 3.11.1
Macro on page 42 )Please enter “Macro” in “Code Setting”.
And then choose one of the soft keys you just created as your
Macro key.
2. After selecting one soft key, please enter your TV device and
key in the number of your favorite channel for the new Macro.
3. In this way, you have successfully created one Macro as your
favorite channel.
4. Please follow the procedures to setup all your favorite
channels.
5. Press the
and input the channel number. (ex: CNN channel 97, HBO
channel 56)
6. After setting these Macros, press the
Macro and exit the setup procedures.
button goes back to MENU list to select “TV”
51
button to save the
Re:control M207 User’s Manual
Chapter 4 Menus
4.1 Setting
The steps to enter the setting menu for detailed settings are as follows:
1. Press
2. Scroll the cursor
then press
3. Select the items as follows to setup your the Re:control M207.
button for 1 second for entering Setup Menu.
or and choose “ setting” item,
button for entering “ Setting” menu.
52
4. Press
item you select will be marked in black.
5. You can press
6. Press the
setting information, please refer to the followings.
7. After finishing the setting, please press
settings.
, buttons or tap the screen to select the item. The
or to change the pages.
button to enter a setting item. To get the detailed
button to save your
Chapter 4 Menus
1. You can use the function to setup the date for your remote.
Date
Time
Buzzer
Power
Contrast
2. Please use
date.
3. Please use
4. Please press
without saving the setting.
1. You can use the function to setup the time for your remote.
2. Please use
time system. (24hr / 12hr )
3. Please use
4. Please press
without saving the setting.
1. You can use the function to setup the buzzer volume.
2. Please use
(Off / Small / Medium / Large)
3. Please press
without saving the setting.
1. This item indicates the power of the batteries.
2. When the batteries are almost depleted the
show on the top-right of the screen.
1. You can use the function to setup the LCD contrast.
2. Please use
3. Please press
without saving the setting.
or to choose the year, month and
or to change the numbers.
to save your setting or press to exit
or to choose the hour, minute and
or to change the numbers.
to save your setting or press to exit
or to change to the buzzer volume.
to save your setting or press to exit
icon will
or to change to the LCD contrast.
to save your setting or press to exit
53
Re:control M207 User’s Manual
g
g
g
g
1. You can use the function to chan
LCD.
2. Please use
LCD Off
Light
Sensitivity
Light Period
LCD.
3. LCD can last for 600 seconds at most.(Disable/10sec ~600sec)
4. You can use the function to change the consumption of
electricity.
5. Please press
without saving the setting.
1. You can use the function to chan
Re:control M207.
2. Please use
3. The more sensitive, the more easily for the Re:control M207
to turn on its backlight.
4. You can also use the function to chan
electricity.
5. Please press
without saving the setting.
1. You can use the function to change the light period for the
backlight.
2. Please use
backlight. (Off / 1sec ~ 60sec)
3. Backlight can last for 60 seconds at most.
4. You can use the function to chan
electricity.
5. Please press
without saving the setting.
e the lasting time for the
or to change to lasting time for the
to save your setting or press to exit
e the light sensitivity of the
or to change to the light sensitivity.
e the consumption of
to save your setting or press to exit
or to change to light period for the
e the consumption of
to save your setting or press to exit
54
Chapter 4 Menus
y
g
y
g
j
y
g
Motion
Welcome Page
Calibrate
1. The Motion Detector will sense an
the LCD automatically.
2. You can use the function to chan
detector. (Off/ Slow / Medium / Fast).
3. Please use
Detector.
4. The more sensitive (eg:Fast), the more easil
Re:control M207 to turn on its LCD.
5. You can use the function to chan
electricity.
6. Please press
without saving the setting.
1. There will be a welcome page when you first time use the
Re:control M207 or reset it.
2. Please use
welcome page. (Enable/ Disable)
3. Please press
without saving the setting.
1. Please use “Calibrate” to ad
you find the Re:control M207 is not so sensitive as before.
2. When
3. Please refer to Chapter 5.5 for detailed information or press
ou are calibrating the LCD, please press the place
where a sigh “X” shows up.
or to change to sensitivity of Motion
to save your setting or press to exit
or to decide if you can see the
to save your setting or press to exit
movement and turn on
e the sensitivity of Motion
for the
e the consumption of
ust the accuracy of LCD when
to exit without saving the setting.
1. When you want to reset your Re:control M207, please use
Reset
the function. It will erase all your settings in your remote.
2. There will be a messa
really want to reset your remote, please tap “Yes”. Then you
will reset it right away.
e to confirm your decision. If you
55
Re:control M207 User’s Manual
g
4.2 Key Layout
1. To add your devices to the Re:control M207.
Add Device
Add Key
Add Text
Re-size
Delete
2. You can use “Pre-code” or “Learning” to load the codes for the
device by the way.
3. (Please refer to Chapter 3.1 Add a Device on page 20.)
1. To add new keys to your devices in the Re:control M207.
2. You can use “Pre-code” or “Learnin
device by the way. (Please refer to 3.2 Add a Device on page
26.)
1. To add a description for a specific device key or a key.
(See 3.3 Add a Text on page28.)
To resize a specific device key or a key or a text.
You can also change the location of keys with the function.
(See 3.5 Re-size a Device, Key or Text on page 31.)
To delete a specific device key or a key.
The function also deletes both the keys and codes at the same
time.
(See 3.6 Delete a Device, Key or Text on page33.)
” to load the codes for the
56
Chapter 4 Menus
4.3 Code Setting
Pre-code
Learning
Macro
Cycle
Del. Code
To load the pre-programmed codes for your devices.
(Please refer to 3.7 Pre-code on page 34.)
To use the function to learn the IR codes from your remotes.
(Please refer to 3.8 Learning on page37.)
To add Normal Macros to your Re:control M207.
You can use all the keys as your Normal Macros except
device keys.
*You cannot setup a timer for a Normal Macro.
(Please refer to 3.11.1 Macro on page 42.)
To add Cycle keys to your Re:control M207.
(Please refer to 3.9 Learn a Cycle key on page 39.)
To remove the coeds setup in the devices or keys.
You won’t erase the keys in using the function.
(Please refer to 3.10 Delete Device/Key codes on page41.)
57
Re:control M207 User’s Manual
4.4 Timer Macro
To add or edit your Timer Macros in your Re:control M207.
Add / Edit
Delete
Re-label
View
You can setup the Timer for the Macro at the same time.
There are 32 sets of Timer Macros you can use.
(Please refer to 3.11.2 A. Create a Timer macro on page
45.)
To delete your Timer Macros in your Re:control M207.
(Please refer to 3.11.2 B. Delete Your Timer Macro on
page47.)
To rename your Timer Macros in your Re:control M207.
(Please refer to 4.4 Re-label a Device, Key or Text on
page48.)
To view your Macro/Timer keys in your Re:control M207.
You can see all the commands and the timer saved in the
specific Timer Macro. (Please refer to D. View Your Timer
Macro on page49.)
58
Chapter 4 Menus
4.5 Duplicate
You can connect two Re:control M207s with
Duplicate
With the function, you are able to transfer your settings to the other
Re:control M207 with Transmit Wire.
1. Please connect two Re:control M207s A and B, by using Transmit
Wire.
2. If you intend to transfer the settings in A to the other one, please
select the “A” Re:control M207 to start the duplication.
3. Please press the
Menu”. And then enter
Transmit Wire. (Appendix B P. 71) And then you
duplicate the settings in one remote and transfer
then to the other one.
button for 1 second to enter the “Setup
Duplicate directly.
4. On pressing the soft key, you will see a message to confirm your
decision.
5. If you decide to duplicate these settings. Please tap “Yes” then
start the duplication.
If you have lots of settings in the original remote, it
will take more time to duplicate the settings for the
other remote.
59
Re:control M207 User’s Manual
6. A message will appear to show the process of the duplication.
7. If the duplication is completed successfully, a message will show
up to tell you the completion. If the duplication isn’t successfully
please repeat from the step 1 again.
If a message “Duplicate Fail” show up,
please check out the followings.
a. The cable does connect these two
remotes precisely.
b. The batteries in these remotes does
have enough energy.
60
Chapter 4 Menus
4.6 Calibrate
When you feel the Re:control M207’s touch panel is not so sensitive,
you can use the function to adjust the touch panel in your Re:control
M207 In this way. Besides, the Re:control M207 will also lead you to
complete the function when you reset your remote.
1. Please press the
And then enter “
2. Please select “
3. On taping the soft key, the Re:control M207 will lead you to
complete the calibration.
4. Please tap the place where the indicator shows up.
5. When you finish taping the indicator, you have successfully
calibrated your Re:control M207.
button for 1 second to enter Setup Menu.
Setting” menu..
Calibrate” in the 3rd page in Setting Menu.
61
Re:control M207 User’s Manual
Chapter 5 Install USB Cable
and Software
5.1 Install Re:connect USB cable
The Re:connect USB cable enables the Re:control M207 to connect with a
PC.
5.1.1 Install the Driver
1. Find the SLC-2080 USB_driver from the CD
enclosed with the package or download the driver
from
http://www.revox.de Double click the
icon “SLC-2080 USB_driver” to start installation.
When the InstallShield Wizard welcome window
shows up, please click “Next” to start installation.
62
Chapter 5 Install USB Cable and Software
2. The program is starting to install the driver. After few seconds, the window
shows as below. Please click “Finish” to complete the setup processes.
The SLC-2080 USB driver is installed completely.
63
Re:control M207 User’s Manual
5.2 Install Upgrade Tools
Upgrade Tools enables you to upgrade your firmware and
pre-programmed codes through the net.
1. Find the program from the CD enclosed with the package or download the
program from http://www.revox.de
2. Please double click the icon below to install Upgrade Tools.
When you are setting up the program, you will see the
window as below. Please click “Next” to go to the next step.
64
3. Please choose the location you will install the program.
4. Please determine the shortcut folder for your Upgrade Tools.
Chapter 5 Install USB Cable and Software
5. If everything is Ok, please click “Install” to setup the program.
6. At this time, you have successfully installed Upgrade Tools. Please
click “Finish” to exit the installation.
65
Re:control M207 User’s Manual
5.3 Upgrade VMCU Firmware and VMCF
Pre-programmed Codes
With the Re:connect USB cable and Upgrade Tools, you can easily
upgrade your Re:control M207 through the internet. There are two types
of file you can upgrade: VMCU Firmware and VMCF Pre-programmed
Codes.
A. VMCU Firmware: The file controls the operation of the Re:control
M207. You can load the renewed VMCU Firmware to make your
Re:control M207 works better.
B. VMUF Pre-programmed Codes: The file is the database of
pre-programmed codes. We keep on collecting the codes around
the world and revising the database for customers. You can
download the latest pre-programmed codes for your Re:control
M207.
1. Please load your Upgrade Tools. And then connect your
Re:control M207 and your PC with the Re:connect USB cable.
(Make sure the driver has bee install properly. Please refer to
P.61.)
2. Please select Re:control M207 from c the “model type” item.
66
Chapter 5 Install USB Cable and Software
3. Please select “Data Source” where you will load the files.
From Internet: You will download
the latest files from our database.
From File: If you want to load the
previous file, please select the item.
Backup Remote: If you want to
back up your settings, please select
the item.
4. Please click “Get data” button to
load the files. An “OK” message will
be shown when the process is
finished.
5. There are two choices in “Upgrade type”: “All (Reset to factory
default)” and “Pre-programmed code”
If you select “All (Reset to factory default)”, you will
upgrade your pre-programmed code database and erase all
your settings in the Re:control M207 at the same time.
If you select “Pre-programmed code”, you will just upgrade
your pre-programmed code database and keep your settings
in the Re:control M207.
67
Re:control M207 User’s Manual
6. After selecting the “Update type”, just click “Upgrade” button to
start the updating process.
68
Appendix A
Features
64 Devices in One: 64 in 1 remote control. No more running out of device
buttons.
Customization: Users can customize every the size, text, or icon for the button as
your will.
Pre-Programmed Code: Users can access to the specific codes for their devices
from pre-programmed codes.
Powerful Learning Function: The Re:control M207 is able to copy almost all the
IR codes by its powerful learning function.
Two Types of Buttons: Users can keep balance between the flexibility of soft keys
and the touch of rubber keys.
Smart Learning Guide: The Re:control M207 automatically guides you to learn all
the buttons one by one.
Macro Key: Each Macro key can store up to 60 commands, including time delays.
You can also customize Macro names if you want.
Cycle Key: Each Cycle key can store up to 6 IR codes.
Timer: Users can combine the Timers function with the Macro function to send
commands at specific time. In this way, you will never miss any thing you want to
record.
Brilliant Blue Backlight: It will automatically detect the environment brightness
and light up blue LED backlight auxiliary illumination.
Motion detector: The motion detector enables the LCD to turn on automatically by
sensing the motion.
Rechargeable Batteries: Optional docking station can recharge the batteries
easily. (Include Ni-MH AAA rechargeable batteries and desktop charger)
Flash Upgradeable Software: Users are capable of upgrading the latest
operation and application software for the Re:control M207.
Powerful RemoteComm Program: Free software “RemoteComm” can be
downloaded from www.revox.de
function, input icon or create own database simply through the RemoteComm
software.
for further customization. Users can edit any
69
Re:control M207 User’s Manual
Specifications
Model
Battery
Dimensions
Weight
Power Consumption
Keys
Display
LCD Resolution
Remote Capability
Display types
IR Range
Learning Frequency
Memory
Backlight
Re:control M207
Alkaline batteries 3 x AAA or Ni-MH rechargeable
batteries
210 (L) x 68 (W) x 24 (H) mm
170g (without batteries)
Operation current: 30 ~ 150mA (max)
LCD on current: 750µA
LCD off current: 20µA
64 Keys / 8 Pages
Touch liquid crystal display
160 x 105 black/white dot matrix LCD.
64 in 1 devices
TV, DSS, SAT, cable, VCR, DVD, AMP, Tape, Tuner,
CD, AUX
10 ~ 15 M, 35˚~45˚
20 KHz ~ 455 KHz & Pulse up to 256 bits long
1 M byte flash memory
Brilliant blue LED
Interface
Optional accessories
70
UART / 115,200bps (SLC-2080 USB Included)
Re:connect USB transmission cable
Docking Station
Appendix B
Optional Accessories
Re:connect USB cable
USB Cable Transmit Wire
The Re:connect USB cable enables transmission of system setup
between a PC and the Re:control M207. With Transmit Wire the
Re:control M207 also can duplicate the user setup data for one to
another.
RemoteComm: With the “RemoteComm” software enables user to
customize the remote control, create macros and timers.
Upgrade Tools: With the “Upgrade Tools” enables user to upgrade MCU
program and Pre-Programmed Code. (Please refer to 5.3 Upgrade
VMCU Firmware and VMCF Pre-programmed Codes P.65)
Duplicate: By connecting a “Transmit Wire” between two Re:control
M207s, you can duplicate settings and functions from one Re:control
M207 to another.
Free “RemoteComm” & “Upgrade Tools” software can be downloaded
from
www.revox.de for further customization.
Docking Station
Docking Station
Optional docking station can recharge the batteries easily. The package is
including Ni-MH AAA rechargeable batteries and desktop charger circuit.
71
•
Appendix C
Troubleshooting Tables
Problem Solution
LCD does not show
anything when you touch it.
• Batteries may be dead.
• Replace the batteries with three new AAA Alkaline batteries.
• Check the batteries are properly installed.
The Re:control M207
doesn’t operate a device.
You cannot operate a
device even after teaching
the device using the
learning function.
You see an “error” display
on the LCD screen during
the learning procedure.
You see an “error” display
during operation.
IR Learning is not
successful.
• Make sure that the desired device on the Re:control M207 LCD
panel has been selected.
• Move closer to the device. The maximum operating distance is
approximately 10 meters (30 feet).
• Ensure that you are aiming the Re:control M207 directly at the
device and that there are no obstructions between the
Re:control M207 and the device.
• Ensure that you have correctly used the learning function to
configure the device or the Pre-Programmed Code has been
properly done.
• Re-teach the malfunction key.
• Make sure that your Re:control M207 has correctly learning the
target device’s remote control code.
• Delete the device data from the Re:control M207 and carry out
the learning function again.
• Make sure you did not program more than one remote for a
given device.
• Make sure you hold the target remote’s key till the screen
displays OK or Error on the screen.
• Make sure the two remotes are not too close or too far apart –
keep them about 2~4 inches (5~10 cm) apart, and your device
remote control is aiming directly at the Re:control M207’s
learning eye.
• The key that you pressed has not been taught.
• Teach the key using the learning procedure.
Replace batteries in the Re:control M207 and the remote you
are trying to configure.
• Keep the learning distance between the remote control and the
Re:control M207’s learning eye to about 2~4 inches (5-10cm).
• Do not use the learn function near an incandescent lamp.
• Memory capacity is full (56 keys for each of eight models).
• The learning process has no errors, but you still can’t control
72
Troubleshooting Tables
Problem Solution
your AV devices:
- Repeat the learning procedure again.
- If you still can’t solve the problem, contact us for help.
- Original remote might not be compatible with learning
Macro does not work.
A key of your existing
remote performs two or
more functions
The LCD screen turns off.
• Be sure to aim the Re:control M207 at the devices while the
• Macro was not properly set up. Repeat macro set-up
• Some remotes issue multiple commands when a key is held
• Each key of the Re:control M207 can only learn one command.
• The Re:control M207 is preset automatically to switch the LCD
• Just tap the touch screen to turn the Re:control M207 back on
procedure.
macro commands are being sent.
procedure.
down. Please be sure to teach different keys of Re:control
M207 for these different commands.
E.g. Cycle key
off after 1 minute by default if left unused.
again.
73
Loading...
