Revo Mondo Wi-Fi Operating Instruction

WI-FI INTERNET RADIO

INTERNET RADIO ADAPTOR

mode d’emploi

Operating Guide

Bedienungsanleitung

Mode demploi

Bruksanvisning

www.revo.co.uk

Contents

Welcome to Mondo Wi-Fi 3

Benefits of Internet Radio 3

Mondo Wi-Fi Overview 3

Warranty 3

Warranty Registration 3

Before Getting Started 3

Wi-Fi Internet Requirements 3

Connecting Mondo 3

Controls and Connections 4

Remote Control 4

Powering Mondo 4

Reciva Radio Portal 4

Connecting To Your Network 5

Choosing a Station 6

Station Updates 6

On-Demand Broadcasts 7

General Operation 7

Resetting Mondo 7

Alarm + Clock Functions 8

Setting Mondo’s Clock 8

Setting An Alarm 8

Configure Menu 9

Network Configuration 9

Version + Firmware Updates 9

Languages 9

Factory Reset 9

Register 9

Clock 9

Sleep Mode 9

Backlight 9

Wi-Fi Strength 9

Media Player Operation 10

Windows + Apple Mac Set-Up 10

Accessing Shared Music 10

General Media Player Operation 10

Windows PC UPnP Set-Up 11

Troubleshooting 12

Spare and Accessories 12

Preface

Copyright and
Acknowledgements

Copyright © 2007 Revo Technologies Ltd.
All rights reserved.

Revo Technologies Ltd
The Inox Building
Caldwellside
Lanark
Scotland
United Kingdom
ML11 7SR

Tel. [phone]
Int. Tel. [phone]
Fax. [phone]
Int. Fax. [phone]
Email. [e-mail]
Website: www.revo.co.uk

The information in this guide is believed to
be correct at the time of publication.
However, our policy is one of continuous
development and so the information is
subject to change without notice.

Revo, Mondo and M-Port are trademarks or
registered trademarks of Revo Technologies
Limited.

® is a registered trademark of Apple

iPod
Computer, Inc.

Safety Warnings

Do not operate this radio near water.
Avoid small objects and liquids from getting
into this product.
Do not remove screws or casing parts.
Use only the power supply unit supplied.

EEC: This product has been designed and
type-tested to comply with EU requirements
and carries a CE mark.

Technical Support

Should you encounter any difficulties with
the operation of your Revo Mondo Wi-Fi, or
should you suspect that it may be faulty in
some way, please call our technical support
department on the number below:

01555 66 61 61

Alternatively, email [e-mail] or
visit the troubleshooting section of our
website at: www.revo.co.uk/support

2

Welcome to Mondo Wi-Fi

Thank you for buying our Mondo Wi-Fi internet radio, we feel sure that it will
provide you with years of enjoyment and reliable service.

This guide has been designed to quickly get you up-and-running and listening
to internet radio, offer guidance on the more complex features of this
product and provide information on safety, warranty and registration.

Benefits of Internet Radio

Access to 7,000+ internet radio stations
Search by genre or country
Access ‘Listen Again’ services
Station list updates automatically
No subscription charges

Mondo Wi-Fi Overview

The Mondo Wi-Fi Internet Radio Adaptor is
capable of accessing thousands of internet
radio stations from all over the world, giving
the user an unprecedented choice of radio
content.

Mondo Wi-Fi connects to any sound system
that has RCA inputs, be it a hi-fi system or
boombox type product. It then links to any
broadband Wi-Fi connection to stream both
live and “Listen Again" internet radio
broadcasts.

Mondo has the added benefit of providing
full electronic alarm clock functionality.

Warranty

Revo Technologies Ltd warrants to the
purchaser that this product will be free
from parts and manufacturing defects in
the course of normal use for a period of
one year from the date of purchase.

This warranty does not apply in cases of
accidental damage, where the case has
been removed, wear and tear, negligence,
modification or inappropriate use.

Should you encounter problems with this
product, please contact your supplier or
alternatively see page 2 of this guide for
technical support contact details.

Warranty Registration

It is a warranty condition that you register
your purchase by either completing the
warranty card enclosed with your radio or
alternatively registering online at

www.revo.co.uk/register

Before Getting Started

Wi-Fi Internet Requirements

In order to use your Mondo Wi-Fi internet
radio adaptor you will require a wireless
(Wi-Fi) broadband Internet connection.

If your wireless network is configured to use
Wired Equivalent Privacy (WEP) or Wi-Fi
Protected Access (WPA) data encryption,
you need to know the WEP or WPA code
(Web Key) in order allow Mondo Wi-Fi to

communicate with the network.
Mondo Wi-Fi should be able to operate
anywhere within 35 metres of the wireless
base station – depending on the operating
environment and the specification of your
wireless base station.

Please ensure that your wireless network is
powered-up and connected to your
broadband Internet connection.

Connecting Mondo

Mondo can be connected to any audio
system that has stereo RCA connectors.

Using the connection leads supplied, simply
connect to the corresponding red and black
RCA connectors on Mondo’s rear panel.

3

Controls and Connectors

2. 3.

1.

1.

back select

2.

A

3. 4.

4. 5.

A

Remote Control

12.

11.

1.

2.

3.

4.

5. 6.

10.

9.

8.

7.

1. Power

2. Back

3. Scroll Left

4. Scroll Right

5. Select

1. Wi-Fi Antenna

2. Stereo RCA Line-Out

3. DC Power Socket

4. Headphone Socket

1. Scroll Left

2. Select

3. Reply

4. Back

5. Presets

6. Media Player

7. Browse

8. Volume Down

9. Scroll Right

10. Volume Up

11. Alarm 0n/Off

12. Standby

Media Player

Stop

Skip Back Skip Forward

Play / Pause

Powering Mondo Wi-Fi

Your Mondo Wi-Fi internet radio adaptor can be powered from the mains using the power
adaptor supplied.

To power from the mains, insert the power adaptor plug into the DC power socket on the
rear of Mondo Wi-Fi. Pressing the button will switch Mondo Wi-Fi on.

Only use the power adaptor supplied. Replacements can be purchased from our website
www.revo.co.uk, or alternatively call us on 01555 66 61 61.

Reciva Radio Portal

The station list used by Mondo Wi-Fi’ is
compiled and managed by Reciva Limited,
they also provide the internet radio
technology used in Mondo Wi-Fi.

Mondo Wi-Fi users are able to access
additional internet radio services by visiting
the Reciva Radio Portal at - www.reciva.com
and registering their radio.

4

Connecting To Your Network

87.50MHz

Clock not set...

Revo Mondo

Wi-Fi

Initialising

Network

Revo Pico Wi-Fi

Internet Radio

< Scan for

network >

Connecting to

Network

Initialising

Network

Revo Pico Wi-Fi

Internet Radio

< Scan for

network >

Connecting to

Network

Initialising

Network

Revo Pico Wi-Fi

Internet Radio

No Wireless
Networks Found

< Scan for

network >

My Home Network

Connecting to

Network

Initialising

Network

Revo Pico Wi-Fi

Internet Radio

No Wireless
Networks Found

< Scan for

network >

My Home Network

Network Ok

Connecting to

Network

Initialising

Network

Revo Pico Wi-Fi

Internet Radio

No Wireless
Networks Found

< Scan for

network >

My Home Network

Network Ok

Connecting to

Network

Initialising

Network

Revo Pico Wi-Fi

Internet Radio

No Wireless
Networks Found

Connecting to

Network

Initialising

Network

Revo Pico Wi-Fi

Internet Radio

< Scan for

network >

My Home Network

Network Ok

Enter WEP key

<END<> 0 1234>

<END<> 0 1234>

Using saved key

Connecting to

Network

Initialising

Network

Revo Pico Wi-Fi

Internet Radio

No Wireless
Networks Found

< Scan for

network >

My Home Network

Network Ok

Enter WEP key

Connecting to

Network

Initialising

Network

Revo Pico Wi-Fi

Internet Radio

No Wireless
Networks Found

< Scan for

network >

My Home Network

Network Ok

Enter WEP key

<END<> 0 1234>

Connecting to

Network

Initialising

Network

Revo Pico Wi-Fi

Internet Radio

No Wireless
Networks Found

Press the ON/OFF button to power-up
Mondo Wi-Fi. Mondo’s LCD screen will
display a welcome message.

After a few seconds this message will
change to ‘Initialising Network’

You will then be given the option to scan
for available networks. Press the
button to action this request.

NOTE: If you make a mistake at any point,

BACK to return to previous screen.

press

If Mondo can’t find a wireless network it
will display the following message.

If this happens please check that your
wireless router is switched on, refer to
the manufacturer if problem persists.

If Mondo does find your wireless network,
it will display the network name, for
example:

In some cases Mondo Wi-Fi may find
more than one network. Use the
buttons to see the names of each one –
and press the
name of your own network is displayed.

If your network is not configured to
request a password (WEP/WPA), Mondo
will connect to the network and display:

If a WEP/WPA key (password) is
required, Mondo will display the following:

After a few seconds, Mondo will ask you
to input the WEP/WPA code and will
display the password entry screen:

SELECT

<>

SELECT button when the

<>buttons to cycle back and

Use the
forward through the alpha-numeric
character list. Press the
to select a character.

Please note, WEP/WPA pass codes are
case-sensitive.

If you make a mistake while entering your
password, press the
delete a character.

After selecting the final character of your
password, scroll to the word ‘END’ and
press the
code. Mondo Wi-Fi should now
successfully connect to your network.

Mondo Wi-Fi will automatically remember
the WEP/WPA code for your network,
and other networks you have used
previously. You will not need to re-enter
these codes in the future.

SELECT button to enter your

SELECT button

BACK button to

5

Choosing a Station

87.50MHz

Clock not set...

<Stations >

<Location >

6537 Stations

<Stations >

<Genre >

6537 Stations

<Location >

6537 Stations

<Stations >

<Albania >
16 Stations

<Genre >

6537 Stations

<Location >

6537 Stations

<Stations >

<Albania >
16 Stations

<Genre >

6537 Stations

<Location >

6537 Stations

<Stations >

<[All Station] >
323 Stations

<Albania >
16 Stations

< Dance >
323 Stations

<Genre >

6537 Stations

<Location >

6537 Stations

<Stations >

<[All Station] >
323 Stations

<Albania >
16 Stations

Loading 323
Stations

< Dance >
323 Stations

<Genre >

6537 Stations

<Location >

6537 Stations

<Stations >

<[All Station] >
323 Stations

<Albania >
16 Stations

Loading 323
Stations

<Cool FM >
96 kbps WMA

< Dance >
323 Stations

<Genre >

6537 Stations

<Location >

6537 Stations

<Stations >

<[All Station] >
323 Stations

<Albania >
16 Stations

Loading 323
Stations

<Cool FM >
96 kbps WMA

< Genre >
6537 Stations

< Dance >
323 Stations

<Genre >

6537 Stations

<Location >

6537 Stations

<Stations >

<[All Station] >
323 Stations

<Albania >
16 Stations

Loading 323
Stations

<Cool FM >
96 kbps WMA

< Genre >
6537 Stations

< Dance >
323 Stations

< Dance >
323 Stations

<Genre >

6537 Stations

<Location >

6537 Stations

<Stations >

<[All Station] >
323 Stations

<Albania >
16 Stations

Loading 323
Stations

<Cool FM >
96 kbps WMA

< Genre >
6537 Stations

< Dance >
323 Stations

< Dance >
323 Stations

<[All Station] >
323 Stations

<Genre >

6537 Stations

<Location >

6537 Stations

<Stations >

<[All Station] >
323 Stations

<Albania >
16 Stations

Loading 323
Stations

Loading 323
Stations

<Cool FM >
96 kbps WMA

<Cool FM>
96 kbps WMA

< Genre >
6537 Stations

< Dance >
323 Stations

< Dance >
323 Stations

<[All Station] >
323 Stations

<Genre >

6537 Stations

<Location >

6537 Stations

<Stations >

<[All Station] >
323 Stations

<Albania >
16 Stations

Loading 323
Stations

Loading 323
Stations

<Cool FM >
96 kbps WMA

<Cool FM>
96 kbps WMA

Station Update

from Reciva

< Genre >
6537 Stations

< Dance >
323 Stations

< Dance >
323 Stations

<[All Station] >
323 Stations

<Genre >

6537 Stations

<Location >

6537 Stations

<Stations >

<[All Station] >
323 Stations

When Mondo Wi-Fi has connected to your
wireless network, you are now ready to
select a station.

Please Note: You can move back to the
previous screen at any time by pressing

BACK button.

the

Mondo Wi-Fi has three main menu
headings Stations, Configure and Media
Player.To select a radio station, use the
<>buttons until the word STATIONS
appears, then press the

SELECT button.

You now have the option of selecting a
station by
Use the <>buttons to pick your search
method, then press

Choosing
alphabetical list of countries broadcasting
internet radio. Use the <>buttons to
scroll through the country list. Press
SELECT to select your desired location.
For example:

You will then be given the choice of listing
all station types in this country, or listing
them by genre eg. Pop, Dance... etc.

<>keys and press SELECT to

Use the
make your selection, Mondo Wi-Fi will now
download the station list for your choice.

You can now scroll through the station list
and make your selection by pressing the
SELECT button.

Choosing
alphabetical list of station types. Use the
<>keys to view these.

Press the
desired genre.

You will now be given the choice of viewing
all stations in this genre, or further
sorting them by location (country)

Now select your chosen station from the
alphabetical list.

Station Updates

Occasionally, Mondo Wi-Fi will tell you that it
is receiving an updated station list. It does
this automatically and periodically, ensuring
that Mondo Wi-Fi always has the latest
station directory on-board.

6

location (country) or by genre.

SELECT.

location will give you an

Genre will give you an

SELECT button to choose your

OR

OR

OR

On-Demand Broadcasts

< Live (Real

Audio) >

< On Demand >

< Live (Real

Audio) >

< On Demand >

< Chart Show >

< Live (Real

Audio) >

< On Demand >

< Chart Show >

Start Time
<00:03:03 >

< Live (Real

Audio) >

Some radio stations provide a number of
additional ways to listen to content; for
example being able to listen to radio
shows that have already been broadcast,
know as On-Demand or ‘Listen-Again’.

To choose between a ‘Live’ broadcast or
an On-Demand one, simply use the
buttons to select your option and press
SELECT to choose.

If you select On-Demand, you will be
presented with a list of shows that are
available to ‘Listen Again’.

<>buttons until your choice is

Use the
displayed on the LCD, then press the
SELECT button to confirm.

Some stations may allow you to fast­forward through an On-Demand
broadcast. Do so by pressing
on the remote control and using the <>
buttons to forward and rewind through
the broadcast. Press
from your selected point.

SELECT to play

<>

BROWSE

OR

OR

General Operation

Changing Volume

To change Mondo Wi-Fi’s volume, press the
VOLUME UP and DOWN buttons on
Mondo’s remote control, the volume level
will be displayed on Mondo’s LCD screen.
Mondo Wi-Fi will remember its previous
volume level after shutdown and power-up.

Internet Radio Presets

Mondo Wi-Fi can store five presets on its
remote control. To store the current
station, press and hold one of the preset
keys for a period of two seconds. To select
a stored station, simply press the
corresponding preset key.

Returning To Main Menu

You may return to Mondo’s top-line main

Resetting Mondo Wi-Fi

In the unlikely even that Mondo Wi-Fi should
‘crash’, ‘freeze’ or stop responding to key
presses, it is possible to perform a reset
and bring it ‘back to life’.

A ‘Factory Reset’ can be activated from
Mondo’s ‘Configure’ menu. Performing a

menu at anytime by pressing the
button and working back through previous
menus.

BACK

LCD Backlight

Under standard factory settings, Mondo will
dim its LCD backlight after approximately
30 seconds. Pressing any button on Mondo
or the remote control will temporarily return
the LCD brightness to full. To change these
factory settings see the ‘Backlight’
instructions on page 9 .

Requesting a Station

If you want to listen to a radio station that
is not listed in Mondo’s station list, you can
visit the Reciva website at
http://www.reciva.com/ and make a
request to add the station to the list.

factory reset will completely reset Mondo’s
memory, clearing all WEP/WPA codes and
user settings. This will effectively return
Mondo to its default factory settings.

7

Alarm + Clock Functions

<Alarm1 >

<Set alarm >

<Set clock >

Set alarm

Set minutes
<08:05 >

Set Alarm

00:00

Set Clock

08:10

¯ Clock ˘

Alarm Set:

07:10

Set Alarm

00:00

Set Clock

08:10

¯ Clock ˘

22:35

(07:10 )

Alarm Set:

07:10

Set Alarm

00:00

Set Clock

08:10

¯ Clock ˘

¯ Clock ˘

Set Clock

08:10

¯ Clock ˘

Setting Mondo’s Clock

Turn Mondo Wi-Fi on and from the
Configure menu locate the Clock option.
Press SELECT and Mondo will give you
two options; ‘Set Clock’ or ‘Set Alarm’.
Choose ‘Set Clock’ and press
now use the <>keys to change the hour,
then press

SELECT to set. Mondo Wi-Fi

will now ask you to set the minutes in the
same way, press

SELECT to set the time.

Setting An Alarm

Press the button to switch on your
radio, then press the button on the
Mondo Wi-Fi remote control. Use the <>
keys to change the hour, then press
SELECT to set. Mondo Wi-Fi will now ask
you to set the minutes in the same way,

SELECT to set the alarm time.

press

Press the button to put Mondo into
standby mode. Mondo will now display the
current time on the top row of its display,
with the alarm time shown in brackets on
the second line of the display.

Mondo Wi-Fi wake you up to an audible
tone, to stop the alarm simly press any
button on Mondo or its remote control.
When the alarm has been deactivated,
Mondo will switch to the radio station that
was playing before Mondo went into
standby mode.

SELECT,

8

Configure Menu

Network Configuration

Enables you to scan again for connection to
another wireless network, or to manually
configure the network parameters. You can
also choose to enable the ‘Low Signal
Warning’ prompt when your wireless
network signal is low.

Version

This will display such information as your
device s serial number and
hardware/software version numbers.
This information may be requested when
dealing with technical support issues.

Update Firmware

Use this to check whether there are any
firmware updates available for your Mondo
Wi-Fi radio adaptor. Mondo will check, and
prompt you if there is. You can then make
the decision whether to start a firmware
download or not. A firmware update can
take several minutes, do not switch Mondo
Wi-Fi off until this procedure has been
completed. Doing so my cause permanent
damage.

Language

This allows you to change Mondo’s display
language. Languages supported include
English, French, German, Italian,
Norwegian, Danish, Dutch, Portuguese,
Spanish, Swedish and Finnish.

Factory Reset

See page 7 for details.

Register

This will display a key code that can be used
to register your radio on the Reciva
customer portal: http://www.reciva.com/

Clock

Set Mondo Wi-Fi’s on-board clock via this

menu. It is also possible to access the
alarm clock features of Mondo Wi-Fi
through this menu, as an alternative to
using the remote control.

Sleep Mode

Select Sleep Mode from the congigure
menua to programme Mondo to turn itself
off after a pre-defined period of time. Sleep
Mode operates in 15 minute incraments,
from 15 minutes to 90 minutes. Simply use

<>keys to define the sleep period and

the
press
automatically put itself into standby mode
after the time has elapsed.

Backlight

It is possible to change the brightness of
Mondo Wi-Fi’s LCD screen via the Configure
menu. There are three brightness settings
as follows:

Normal: This setting defines Mondo’s
normal LCD brightness level. Use the <>
keys to select the required brightness level
and press SELECT to set.

Auto-Bright: When switched on, pressing
any button on Mondo or its remote control
will activate ‘Auto-Bright’ mode for a period
of 30 seconds. The actual brightness level
for ‘Auto-Bright’ is defined by this setting.

Standby: This sets the LCD brighness level
for when Mondo Wi-Fi is in ‘Standby’ mode.
Use the
brightness level and press

Wi-Fi Strength

This will display the strength of your Wi-Fi
signal and will range between 0% - 100%.
The further Mondo Wi-Fi is away from your
Wi-Fi base-station, the weaker the signal
strength will be.

SELECT. Mondo Wi-Fi will now

<>keys to select the required

SELECT to set.

9

Media Player Operation

Mondo Wi-Fi’s media player functionality
allows you to play audio files (AAC, AIFF, AU,
MP3, RM, WAV and WMA) and playlists
(M3U) stored on a networked PC or Apple
Mac. The media player functions have been
tested and certified to operate with
Windows 2000, Windows XP, Windows
Vista and Mac OSX 10.2 or a later version.

Windows PC Set-Up

Ensure that your PC is available on the
network, then using Windows Explorer,
locate the folder where your audio files are
stored...then

Right click on the folder.
Select ‘Properties’
Click on ‘Sharing’
Select “Share this folder on the network’
and ‘Allow network users to change my
files’. Please note, do not try to make your
‘My Documents’ or any of its sub-folders
(e.g. ‘My Music’) shareable.

Apple Mac Set-Up

Setup Windows File Sharing on the MAC:

From the ‘Dock’, click ‘System Preferences’.
From the ‘System Preferences’ window
(under the ‘Internet & Network’ section)
click ‘Sharing’.

From the ‘Sharing’ window, do the following:

Under the ‘Services’ section, enable
‘Personal File Sharing’ and ‘Windows
Sharing’. Also, click ‘Start’ for each of these
services.

Under the ‘Firewall’ section, keep firewall off.

Under the ‘Internet’ section, keep ‘Internet
Sharing’ off.

Setup an Account:

From the ‘System Preferences’ window,
under the ‘System’ section, click ‘Accounts’.
Select an account and remember its ‘Short
Name’ and password. This information will
be used by Mondo Wi-Fi when connecting to
your Mac.

Directory Setup:

From the ‘Dock’, click ‘Finder’. From the
‘Finder’ window, click ‘Applications >
Utilities’. Holding Ctrl click on ‘Directory
Access’ then select ‘Get Info’ and ensure
that read / write enabled. Next double click
on ‘Directory Access’ and enable the
following:

✓

AppleTalk LDAPv3

✓✓

SLP SMB/CIFS

Also, for the ‘SMB/CIFS’ item, click
‘Configure’ and select an appropriate
workgroup.

Copy and paste the audio files to
‘Documents’ in the ‘Finder’ window. Ensure
that your Mac is successfully connected to
the wireless network. Note, you may need
to wait for few minutes for the changes to
take effect.

✓

You should now be able to access the audio
files on your Mac by selecting ‘Media Player
> Windows Shares’ on Mondo Wi-Fi, then
selecting your Mac from the list of devices.
On selecting your Mac, if no shared folders
are found, press the
select user - at this point you can enter in
the ‘Short Name’ and password for your
Mac account.

SELECT button and

Accessing ‘Shared’ Music

When Mondo has connected to your
wireless network, press the BACK button
until ‘Stations’ is displayed. Use the <>
keys to find the ‘Media Player’ menu on­screen, then press the SELECT button.

Using the <>keys, find and select
“Windows Shares’, then ‘Scan for PCs’.
Mondo will now display ‘Finding PCs’. When
the scan is complete, use the
find your PC and select, Mondo will now
search for shared folders. Using the
keys to highlight the correct folder and
press SELECT.

Mondo will display ‘File Scan...’ as it scans
through all the files on your Mac or PC.

PLEASE NOTE If you have a large number
of files, this operation could take several
minutes.

When Mondo has finished scanning, it will
display ‘By Album’. You can now browse
through the scanned media files, which will
be organised ‘By Album’, ‘By Artist’, and
‘Playlist’ - if available.

IMPORTANT The first time Mondo Wi-Fi
completes a file scan, a file called
“reciva_media_cache” is written to the folder
where the audio files are stored. This will
speed-up subsequent file scans.

<>keys to

<>

Listening To A Single Track

Scroll until ‘By Artist’ is on-screen then
press SELECT. Now use the <>keys to
scroll until your artist choice is displayed,
then press
desired album is displayed, and select it.
The prompt ‘Add To Queue’ will appear at
this point. Scroll until your chosen track
name is on-screen and press
choice will now start to play.

SELECT. Now scroll until your

SELECT. Your

Listening To A Complete Album

Using the <>keys, locate and select
‘By Artist’, then select your choice of artist.
Now use the
album choice is displayed, then press
SELECT. The prompt ‘Add To Queue’ will
appear at this point, press SELECT and
your chosen album will start to play.

<>keys to scroll until your

Queuing Tracks For Playback

Highlight your chosen track then press
SELECT. ‘Track Added To Queue’ will now
be displayed.

Queuing Albums For Playback

Highlight your chosen album then press

SELECT. Scroll to ’Add To Queue’ then
SELECT. ‘Tracks Added To Queue’ will now

be displayed.

10

Controlling Playback

Use the STOP button on Mondo’s

remote control to stop playback.

PLAY/PAUSE button to start

Use the
a track, pause a track, or restart a paused
track.

SKIP TO PREVIOUS TRACK to

Use
start playback of the previous track in the
queue.

SKIP TO NEXT TRACK to

Use the
start playback of the next track in the
queue.

Browsing A Queue

Press the BROWSE button - the currently
playing track name will be displayed. Use
the <>keys to see the tracks that are
queued for playback. To jump ahead and
play a track from the queue, use the
keys and SELECT.

<>

Removing Tracks From A Queue

Press the BROWSE button - the currently
playing track name will be displayed.

Use the <>keys to scroll to the track
that you would like to remove from the
queue. Press and hold the
seconds. Mondo will display ‘Delete Track?’.

Use the <>keys to to highlight either
‘Yes’ or ‘No’. Press
selection. ‘Removed From Queue’ will be
displayed if you decided to delete a track.

To clear the entire contents of a queue,
select ‘Clear Queue’ from the the main
Media Player menu.

STOP key for 2

SELECT to make your

Playing Tracks Randomly

Select and add the individual tracks to the
queue as described previously.

Return to the main top-line Media Player
menu and select ‘Playback Mode’.

<>keys to display ‘Shuffle’, then

Use the
select

SELECT.

Confirm that ‘Shuffle’ mode should be
enabled, by selecting YES or NO.

Repeating Tracks In A Queue

Select the individual tracks as previously
described.

Return to the main top-line Media Player
menu and select ‘Playback Mode’.

Scroll to display ‘Repeat’, then press
SELECT button.

Confirm that ‘Repeat’ mode should be
enabled, by selecting YES or NO.

Windows PC UPnP Set-Up

If your PC is running Microsoft Windows XP
or Vista, then you can use Window Media
Player 11 (WMP 11) to act as your UPnP
(Universal Plug and Play) media server 1.0.

WMP 11 can be downloaded from
Microsoft’s website and installed by following
the instructions detailed in its installation
wizard.

Once installed, Windows Media Player 11
will create a library from all the media files
available to it on your PC. To add new media
files to the library, select ‘File > Add to
Library… > Advanced Options’, click ‘Add’
and choose the files you wish to add and
click ‘OK’.

You will now need to connect Mondo Wi-Fi
to Windows Media Player 11 and configure
it to allow the radio to access your media
library. In order to this, you will need to do
the following:

Keep pressing
top-line menu and then scroll to ‘Media
Player’ and press SELECT.

Now use the
Servers’ and press
scan for all available UPnP servers. Note, it
may take a few seconds for Mondo to
complete its scan and before the scan has
been completed. Mondo will display
‘[Empty]’. Mondo will continue to display
‘[Empty]’ if no UPnP servers are found.

If “No PC Found” is displayed on Mondo’s
display, click the library tab in Windows
Media Player and select media sharing, now
select share my media and then click ‘OK’.

At this point you can scan for UPnP
servers on Mondo Wi-Fi again, Mondo will
now be listed as a unknown device in the
media sharing window click the ‘Allow’
button and then click ‘OK’. Mondo Wi-Fi
should now be accessing your Windows
Media Player Library.

PLEASE NOTE that only WMA files in
Windows Media Player are accessible using
UPnP.

BACK to get to Mondo’s

<>keys to scroll to ‘UPNP

SELECT. Mondo will

Playing Music Using UPnP

When the UPnP server is configured to
share media files with Mondo Wi-Fi, you can
begin playing music as follows:

Press the
displayed, then scroll to ‘Media Player’
option, now press the SELECT button.

Use the <>keys to highlight ‘UPNP
Servers’ and press
scan for all available UPnP servers. Please
note, it may take a few seconds for Mondo
to complete its scan. Before the scan has
been completed, Mondo will display ‘[Empty]’
and continue to do so if no UPnP servers
can be found.

After a successful scan, select your UPnP
server using the
than one UPnP server), and then pressing
the

Mondo will now list the media categories
available from the UPnP server, e.g. ‘Music’,
‘Playlists’ etc. Use the
which category you wish to browse, then
press
highlight a sub category and press
Scroll to highlight the media files that you
wish to play, then press
will display ‘[Add to Queue]’, press SELECT
again and Mondo will add the tracks to its
queue and begin playing them automatically.
added to the radio’s queue.

BACK button until ‘Stations’ is

SELECT. Mondo will

<>keys (if there is more

SELECT button.

<>keys to choose

SELECT. Use the <>keys to

SELECT.

SELECT. Mondo

11

Browsing A Queue

Press the BROWSE button - the currently

playing track name will be displayed. Use
the <>keys to scroll through the tracks
that are queued for playback. If you want to
jump to a particular place in the queue,
press the
required track is displayed. It is important to

SELECT button when the

note here that media files scanned from the
radio’s ‘Windows Shares’ function can also
be added to the radio’s queue.

Full instructions on queue management,
controlling music playback etc. under UPnP
can be found on page 11.

Troubleshooting

If you are experiencing any problems with
your Mondo Wi-Fi internet radio adaptor,
please read the following ‘troubleshooting’
guide. Alternatively can can visit the HELP
section of the Reciva website
(www.reciva.com) the support section of the
Revo website (www.revo.co.uk) or call our
technical support staff on 01555 66 61 61.

If you have trouble connecting Mondo Wi-Fi
to your wireless network, these steps may
help to resolve the problem:

1. Confirm that a Wi-Fi connected PC can
access the Internet (i.e. can browse the
web) using the same network.

2. Check that a DHCP server is available, or
that you have configured a static IP address
on the radio. You can configure a static IP
address on the radio using the menu item
‘Configure -> Network Config -> Edit Config’,
and then select ‘No’ for ‘Auto (DHCP)’.

3. Check that your network’s firewall is not
blocking any outgoing ports. As a
minimum, Mondo Wi-Fi needs access to
UDP and TCP ports 80, 554, 1755, 5000
and 7070.

4. Check your access point does not
restrict connections to particular MAC
addresses. You can view the radio’s MAC
address using the menu item ‘Configure ->
Network Config -> View Config -> MAC
address’.

5. If you have an encrypted network, check
that you have entered the correct key or
pass phrase into the radio. Remember that
text-format keys are case sensitive. If, when
attempting to connect to an encrypted
network, your radio displays: ‘Wireless
error’ followed by a 5-digit number, then
please ensure that you enter the correct
pass phrase for the network. If the problem
persists, then you may need to consult your
network configuration.

If Mondo Wi-Fi can connect to the network
successfully, but is unable to play particular
stations, it may be due to one of the
following causes:

1. The station is not broadcasting at this
time of the day (remember it may be
located in a different time zone).

2. The station has reached the maximum
allowed number of simultaneous listeners.

3. The station is not broadcasting anymore.

4. The link on the radio is out of date.

5. The Internet connection between the
server (often located in a different country)
and you is slow. Try using a PC to play back
the stream via the broadcaster’s web site.
If you can play back the station with a PC,
but not via Mondo Wi-Fi - use the form at
http://www.reciva.com/ to notify Reciva of
the problem - they can change the station
data that is used by the radio.

Accessories and Spares

The following optional accessories and spare parts are available for Mondo.
Please contact your local retailer or alternatively call us on 01555 666 161.
Accessories and spare parts can also be purchased online at www.revo.co.uk

Remote Control:

Replacement Mondo remote control.

Mains Power Supply Unit:

Replacement power supply for Mondo.

Stereo RCA Leads:

Replacement leads to connect Mondo to a hi-fi system or similar.

12

Safety Information

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK:
DO NOT REMOVE SCREWS, COVERS OR THE CABINENT.
NO USER SERVICING PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with
arrowhead symbol within an
equilateral triangle is intended
to alert the user to the
presence of uninsulated
"dangerous voltage" within the
product's enclosure that may
be of sufficient magnitude to
constitute a risk of electric
shock to persons.

The exclamation point within an
equilateral triangle is intended
to alert the user to the
presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.

WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.

IMPORTANT SAFETY INSTRUCTIONS

To reduce the risk of electrical shock, fire,
etc:

1. Read these instructions.

2. Keep these Instructions.

3. Heed all Warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth. For stubborn
stains, use a soft cloth dampened with a
weak solution of mild detergent and
water. Dry the apparatus immediately
afterwards with a clean cloth. Do not use
abrasive clothes, thinners, alcohol, or
other chemical solvents, because they
may damage the finish or remove the
panel lettering.

7. Do not block any ventilation openings. The
ventilation shall not be impeded by
covering the ventilation openings with
items, such as newspapers, table clothes,
curtains, etc.

8. Do not install near any heat source such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.

9. Do not defeat the safety purpose of the
polarized or grounding - type plug. A
polarized plug has two blades with one
wider than the other. A grounding type
plug has two blades and a third grounding

prong. The wide blade or the third prong
are provided for your safety. If the
provided plug does not fit into your outlet,
consult an electrician for replacement of
the obsolete outlet.

10. Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.
If the power cord is damaged, it must be
repaired by a qualified repairer.

11. Only use attachments/accessories
specified by the manufacturer.

12. Use only with the cart, stand, tripod,
bracket or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.

PORTABLE CART WARNING

13. Unplug this apparatus during lightning
storms or when unused for long periods
of time.

14. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.

15. The apparatus shall not be exposed to
dripping or splashing and no objects filled
with liquids, such as vases, shall be
placed on the apparatus.

16. The mains plug or an appliance coupler is
used as the disconnect device, the
disconnect device shall remain readily
operable.

17. Please read Rating Labels at the bottom
of the Sender and Receiver for power
input and other safety information.

FCC

This device complies with Part 15 of the FCC
Rules Operation that is subject to following
two conditions:

(1) This device may not cause harmful

interference and,

(2) This device must accept any

interference received, including
interference that may cause undesired
operation.

WARNING: Changes or modifications to this
unit not expressly approved by the party
responsible for compliance could void the
user authority to operate the equipment.

13

Revo Technologies Ltd The Inox Building Caldwellside Lanark Scotland United Kingdom ML11 7SR

Telephone Support 01555 666 161

Online Support www.revo.co.uk/support [e-mail]
