Revo Domino Operating Instruction

Version 1.0

Owner’s Manual
Bedienungsanleitung
Manuale D’Uso
Manuale dell’utente

TECHNICAL SUPPORT

WARRANTY

Should you encounter problems using this product, please refer to the
troubleshooting section on page 39 of this owner’s guide.
Alternatively, call Revo technical support on :

UK 01555 666161

From outside the UK + 44 1555 666161

Alternatively, e-mail [e-mail] or visit the troubleshooting
section of our website at: www.revo.co.uk/support

ENVIRONMENTAL INFO

PRODUCT DISPOSAL INSTRUCTIONS (WEEE DIRECTIVE)

The symbol shown here and on the product means that it is classed
as Electrical or Electronic Equipment and should not be disposed with
other household or commercial waste at the end of its working life.

The Waste of Electrical and Electronic Equipment (WEEE) Directive
(2002/96/EC) has been put in place to recycle products using best
available recovery and recycling techniques to minimise the impact
on the environment, treat any hazardous substances and avoid the
increasing landfill.

For more information please contact your local authority or the retailer
where the product was purchased.

RoHS COMPLIANT & CE MARK

This product has been designed to comply with international
directives on the Restriction of Hazardous Substances (RoHS) and has
been designed and type-tested to comply with EU
requirements and carries a CE mark.

SAFETY WARNINGS

• Do not operate this radio near water

• Do not remove screws or casing parts

• Use only the power supply unit supplied

• Avoid small objects and liquids from entering the product

Revo Technologies Ltd warrants to the end user that this product will
be free from defects in materials and workmanship in the course of
normal use for a period of one year from the date of purchase.
This guarantee covers breakdowns due to manufacturing faults and
does not apply in cases such as accidental damage, general wear
and tear, user negligence, modification or repair not authorised by
Revo Technologies Ltd.

To register your purchase please visit www.revo.co.uk/register

COPYRIGHTS AND
ACKNOWLEDGEMENTS

Copyright 2009 Revo technologies Ltd. All rights reserved.

No part of this publication may be copied, distributed, transmitted
or transcribed in any form or by any means, electronic, mechanical,
magnetic, manual or otherwise, without the permission of Revo
Technologies Limited.

REVO and DOMINO and are trademarks or registered trademarks
of Revo Technologies Ltd. iPod and iPhone are trademarks of Apple
Inc., registered in the U.S. and other countries.

Revo Technologies Ltd
The Inox Building, Caldwellside, Lanark,
Scotland, United Kingdom, ML11 7SR

Tel: [phone] Int. Tel: [phone]
Fax: [phone] Int. Fax: [phone]

Email: [e-mail] Website: www.revo.co.uk

DISCLAIMER

Revo Technologies Limited makes no representation or
warranties with respect to the content of this publication, and
specifically disclaims any implied warranties of merchantability or
fitness for any particular purpose. Further, Revo Technologies Limited
reserves the right to make changes to this publication from time to
time, without notification to any person or organisation.

02

CONTENTS

02 Technical Support

02 Environmental information

02 Warranty

02 Copyright and Acknowledgements

02 Disclaimer

03 Welcome / Unpacking

04 Anatomy

05 Remote Control

06 Power Supply

06 Set Up

07 Controlling Domino / Menu Structure

08/09 DAB Mode

10/11 DAB Mode Menu Options

12 FM Mode

13 FM Mode / AUX IN Mode

14/16 iPod Mode

17/18 Internet Setup

19/22 Internet Radio Mode

23 Internet Radio Portal

24/25 Setting up a Music Server

26/28 Music Player Mode

29/31 Last.fm Mode

32/33 Alarm Clock

34/38 System Settings

39/40 Troubleshooting

41 Error Messages

WELCOME

Thank you for purchasing our Domino radio, we are sure that it will
provide you years of enjoyment and reliable service.

This guide has been designed to quickly get you up-and-running with
your radio, and explain the more complex features of this product,
as well as providing information on safety, warranty details and
troubleshooting.

There are three models in the Domino range ( and ),
each with its own set of features and benefits. This owner’s manual
offers guidance on all three versions.

Please note: Not all features are available on all models.

At the top of each page you will see the three model logos
displayed. If this particular section of the manual is not applicable
to your model, the model logo will be crossed-out., as shown below.

This denotes that INTERNET RADIO Mode is not available on Domino D1.

UNPACKING DOMINO

Carefully remove Domino from its packaging before removing the
other items from the box.

The box should contain the following:

• Domino radio

• Remote control

• iPod dock adaptor kit

• Power supply with multi - country adaptors (UK, Euro, USA)

• Owner’s Manual

Should any item be missing or damaged, please contact your point
of purchase or call Revo directly on [phone]

NOTE: Domino’s packaging should be retained for possible future use,
it is the safest way to transport Domino should it be necessary.

03

ANATOMY OF DOMINO

04

REMOTE CONTROL

01 - Mode
02 - Scroll up
03 - Power
04 - Menu
05 - Back
06 - Select
07 - Forward
08 - Volume increase
09 - Alarm
10 - Scroll Down
11 - Info
12 - Volume Decrease
13 - Presets 1- 10
14 - Sleep
15 - Snooze
16 - Skip Back (Fast Rewind)
17 - Play/Pause
18 - Skip Forward (Fast Forward)
19 - Feedback (Love/Ban)

BATTERY REPLACEMENT

1

The Domino remote control is powered by a single 3V lithium
battery. Depending on usage, the battery should happily run for
between 1 and 2 years.

Replace the battery when button presses seem sluggish, or when the
operating range appears to have reduced significantly.

Replace the old battery with a new CR2025 lithium cell.

2

05

POWER SUPPLY (PSU)

Your Domino radio is supplied with a multi-region power supply,
meaning that it can be operated in a number of countries around
the world.

Simply choose the correct adaptor for your country from the
selection supplied, then follow the instructions below.

SET-UP

Using the PSU supplied, connect one end to the DC power socket found on the

1

rear of Domino, then plug the opposite end into the mains socket on the wall.

UK EURO U.S.A

2

Fully extend the antenna for DAB or FM operation

06

3

Press the POWER button once to start the initialization process.

CONTROLLING DOMINO

Despite it’s sophisticated range of features, Domino is surprisingly
simple to use. By utilising a joystick control method, minimising the
number of buttons and switches, and employing a multi-line graphical
OLED display, we have created an extremely user-friendly radio.

To get the best from your radio, it’s important that you fully
understand how Domino’s controls and menu systems work.

POWER / VOLUME

To power-up Domino, press the VOLUME knob. To send Domino back
into STANDBY mode, press the VOLUME knob again.

MODE SELECTION

Turning the MODE knob in either direction will switch between

Domino’s modes of operation.

JOYSTICK CONTROL

The joystick controller has five functions (see illustration 4), as follows:

UP Scrolls Up
DOWN Scrolls Down
LEFT Scrolls Left and moves back through menus
RIGHT Scrolls Right and moves forward through menus
PRESS SELECT

FUNCTION BUTTONS

Positioned around Domino’s joystick you will find the ALARM, MENU,
INFO and PRESET buttons.

MEDIA KEYS

On Domino’s top face you will find a selection of MEDIA keys (see
illustration 5). These are used in a number of modes including iPod,
Media Player and Last.fm.

4

MENU STRUCTURE
EXPLAINED

MAIN MENU

This is Domino’s principle (top level) menu, and offers entry to all
modes, as well as access to your radio’s various settings.

The MAIN MENU provides access to the following modes and
sub-menus (depending on your model).

• Internet Radio • Music Player • Last.fm

• DAB Radio • AUX-IN • iPod

• FM Radio • System Settings • Alarms

MODE MENUS

The Mode Menus are so called because they show the functions
available within the currently selected mode.

5

Pressing the at any time will take you to the Mode Menu for the
mode of operation your radio is currently in.

Each of the Mode Menus also includes a listing for MAIN MENU,
allowing you to return to the top level MAIN MENU.

07

DAB RADIO MODE

GETTING READY FOR DAB OPERATION

Please ensure that the radio’s antenna is extended before operation
in DAB Mode.

To enter DAB MODE, turn the knob until the DAB MODE intro
screen is displayed, alternatively press then select MAIN MENU,
then DAB from menu option list.

On power-up, Domino will automatically perform a full scan to see
what stations are being broadcast in your area, before storing them
alphabetically in the radio’s memory.

It may be necessary to perform a manual scan from time to time, in
order to update your radio’s station list. This may be required for any
one of the following reasons:

1. Station availability can change from time to time as new stations
appear, or existing stations cease broadcasting.

2. If reception was poor during the initial automatic scan, for
example the radio’s antenna was not completely extended,
it may be that the station list is incomplete or even empty.

3. If you have poor reception on some of the stations (resulting in
broken or poor quality audio), you may wish to list only stations that
have a strong signal strength.

To start a manual scan, press the button then select FULL SCAN
from the menu list.

To scan for only stations that have a strong signal strength, press
then select LOCAL SCAN from the menu list.

When the scan is complete, your radio will list all available stations.

To remove stations that are listed but unavailable, press then
choose PRUNE INVALID. When asked whether you wish to remove all
invalid stations”, select YES.

08

DAB RADIO MODE

SELECTING A STATION

To access your radio’s station list, press UP, DOWN or LEFT on the
joystick controller at any time, alternatively press then select
STATION LIST.

Scroll through the available stations using UP and DOWN on the
joystick controller, then either press the joystick to select your station
choice, or tap RIGHT.

FAVOURITE STATION PRESETS

Domino allows you to store your favourite stations as presets, either
via its button or 10 preset buttons located on the Domino
remote control.

To store the station you are currently listening to as a preset, simply
press the then select an empty preset number from the 10
available in the list. Now press and hold the joystick to store your
selection. “Preset Stored” will be displayed on your radio’s screen.
The preset number that has been assigned to the station will be
displayed at the bottom of the screen.

If you want to change a particular preset in the future, repeat the
process and the previously stored preset will be automatically
overwritten.

09

DAB MODE MENU OPTIONS

STATION INFO

In DAB MODE, Domino is capable of displaying various pieces of information on
its screen. By pressing the button, you can sequentially cycle through the
following types of information.

STANDARD DAB SCREEN Shows scrolling text info from broadcaster

PROGRAMME TYPE For example News, Rock Music, Classical etc.

MULTIPLEX AND FREQUENCY Multiplex owner and station frequency

SIGNAL STRENGTH Station’s current signal strength

BIT RATE AND CODEC Audio format, sample rate, mono or stereo

DATE Today’s date

10

DAB MODE MENU OPTIONS

DYNAMIC RANGE COMPRESSION (DRC)

If you are listening to music with a high dynamic range in a noisy
environment (for example, classical music while cooking), you may
wish to compress the audio’s dynamic range. This has the effect of
making quiet sounds louder, and loud sounds quieter.

To change the DRC setting, press then choose the DRC option,
before selecting OFF, LOW or HIGH.

STATION ORDER

It is possible to choose the order of the DAB station list to be either
ALPHANUMERIC, ENSEMBLE or VALID.

As the name implies, ALPHANUMERIC lists stations in alphanumeric
order.

ENSEMBLE lists groups of stations that are broadcast together on the
same ensemble, for example BBC or Central Scotland Local.

VALID lists valid stations first, alphanumerical, then off-air stations.

To change the station order, press then select STATION ORDER,
before choosing either ALPHANUMERIC, ENSEMBLE or VALID.

STATION ORDER DESCRIPTION

ALPHANUMERIC Display all stations in alphanumeric order.

ENSEMBLE List active stations [ones that are currently broadcasting] before inactive ones.

VALID Remove inactive stations from the station list.

11

FM RADIO MODE

FM OPERATION

Please ensure that the radio’s antenna is extended before operation
in FM MODE.

To enter FM MODE, turn the knob until the FM MODE intro screen
is displayed, alternatively press then select MAIN MENU, then FM
from menu option list.

If this is the first time that Domino has been used in FM MODE,
scanning will start at the beginning of the frequency range ­otherwise Domino will default to the station you were listening to last.

Pressing the joystick controller will start the radio scanning for the next
available station. Domino will automatically stop scanning when a
station is found.

To fine tune, use UP or DOWN on the joystick controller to
incrementally change the frequency.

When on an FM station that has a strong signal and is broadcasting
RDS information, Domino will display the station name and other
pieces of text information on-screen.

FAVOURITE STATION PRESETS

Domino allows you to store your favourite stations as presets, either
via its button or 10 preset buttons located on the Domino
remote control.

To store the station you are currently listening to as a preset, simply
press the then select an empty preset number from the 10
available in the list. Now press and hold the joystick to store your
selection. “Preset Stored” will be displayed on your radio’s screen.
The preset number that has been assigned to the station will be
displayed at the bottom of the screen.

If you want to change a particular preset in the future, repeat the
process and the previously stored preset will be automatically
overwritten.

12

FM RADIO MODE

FM SETTINGS

Press the button to access the FM MODE MENU. From here

you can set some FM preferences such as SCAN SETTING and AUDIO
SETTING.

SCAN SETTING allows you to decide whether the radio should stop
scanning only when it finds a station with a strong signal.

AUDIO SETTING gives you the option of listening to a station in mono,
should the signal strength not be sufficiently strong to allow stereo
reception.

AUX IN MODE

AUX IN MODE allows you to play audio from an external source (such
as an MP3 player) through your radio.

To do so, connect your external audio source to the 3.5mm AUX IN
connector on the rear of Domino.

Turn the volume down low on both Domino and, if adjustable, the
external device.

Now turn the knob until the AUX IN screen is displayed,
alternatively press then select MAIN MENU, then AUX IN.

Adjust the volume of Domino and, if necessary, the external audio
device as required.

13
