Revo Blik Operating Instruction

H Y B R I D D I G I T A L R A D I O
mode d’emploi
Operating Guide
Bedienungsanleitung
Mode d emploi
Bruksanvisning
w w w . r e v o . c o . u k
Contents
Welcome to BLIK RadioStation 3
BLIK Overview 3
Warranty + Warranty Registration 3
Before Getting Started 3
Wi-Fi Internet Connection 3
Registering Your Radio 3
Controls and Connections 4
Remote Control 4
Powering BLIK 4
Remote Control Operation 4
Setting The Time and Date 4
Getting Started 5
BLIK’s Control Method 5
BLIK’s Menus Explained 5
Internet Radio Mode 6
Connecting To Wi-Fi network 6
Using Internet Radio Features 7
Choosing A Station 7
Choosing A Podcast 7
My Favourites 8
My Added Stations 8
Help 8
Internet Radio Portal 8
Access Additional Features 8
Registering Your Radio 8
Music Player Mode 9
Windows PC Set-UP 9
Apple Mac Set-Up 10
DAB Mode 11
DAB Mode Menu Options 12
FM Mode 13
MPort Mode 13
Alarms Mode 14
Sleep Mode 15
System Setup 15
Info 15
Troubleshooting 16
Preface
Copyright and Acknowledgements
Copyright © 2007 Revo Technologies Ltd. All rights reserved.
Revo Technologies Ltd The Inox Building Caldwellside Lanark Scotland United Kingdom ML11 7SR
Tel. 01555 66 61 61 Int. Tel. +44 1555 66 61 61 Fax. 01555 66 33 44 Int. Fax. +44 1555 66 33 44 Email. enquiries@revo.co.uk Website: www.revo.co.uk
The information in this guide is believed to be correct at the time of publication. However, our policy is one of continuous development and so the information is subject to change without notice.
Revo, BLIK and M-Port are trademarks or registered trademarks of Revo Technologies Limited.
iPod® is a registered trademark of Apple Computer, Inc.
Safety Warnings
Do not operate this radio near water. Avoid small objects and liquids from getting into this product. Do not remove screws or casing parts. Use only the power supply unit supplied.
EEC: This product has been designed and type-tested to comply with EU requirements and carries a CE mark.
Technical Support
Should you encounter any difficulties with the operation of your Revo BLIK Wi-Fi, or should you suspect that it may be faulty in some way, please call our technical support department on the number below:
01555 66 61 61
Alternatively, email or visit the troubleshooting section of our website at: www.revo.co.uk/support
2
Welcome to BLIK RadioStation
Thank you for buying our BLIK RadioStation digital radio, we feel sure that it will provide you with years of enjoyment and reliable service.
This guide has been designed to quickly get you up-and-running and listening to internet radio, offer guidance on the more complex features of this product and provide information on safety, warranty and registration.
BLIK RadioStation Overview
BLIK RadioStation is the ultimate ‘one box’ digital radio, providing an unprecedented choice of over 9,000 stations from around the globe.
Whether your preferred station is broadcasting from your own country on DAB or DAB+ digital radio, or on the other side of the world via the internet radio platform ... BLIK RadioStation is ready to deliver.
BLIK also provides coverage of traditional FM radio, comprehensive electronic alarm clock functionality and the added benefit of doubling as an iPod ® speaker system.
Throw-in class-leading audio performance and the ability to stream music from your PC or Mac, and BLIK RadioStation becomes the radio of choice for the digital generation.
Warranty
Revo Technologies Ltd warrants to the purchaser that this product will be free from parts and manufacturing defects in the course of normal use for a period of one year from the date of purchase.
This warranty does not apply in cases of accidental damage, where the case has been removed, wear and tear, negligence, modification or inappropriate use.
Should you encounter problems with this product, please contact your supplier or alternatively see page 2 of this guide for technical support contact details.
Warranty Registration
It is a warranty condition that you register your purchase by either completing the warranty card enclosed with your radio or alternatively registering online at
www.revo.co.uk/register
Before Getting Started
IMPORTANT
To ensure that your BLIK RadioStation is running the latest software release (and therefore has access to the latest software
I
features), we advise you to perform a software update. Please see page 16 of this operating guide for full details.
Wi-Fi Internet Connection
In order to use the internet radio functions of your BLIK RadioStation, you will require a wireless (Wi-Fi) broadband internet connection.
If your wireless network is configured to use Wired Equivalent Privacy (WEP) or Wi-Fi Protected Access (WPA) data encryption, you need to know the WEP or WPA code (Web Key) in order to allow BLIK
Registering Your Radio and Accessing Additional Services
Some of BLIK RadioStation’s more advanced internet radio features can only be accessed by visiting the Frontier Internet Radio Portal (www.wifiradio-frontier.com).
BLIK RadioStation and DAB+
At the time of writing, BLIK RadioStation is the first and only digital radio product that is capable of receiving broadcasts on the new DAB+ digital radio platform - without the
RadioStation to connect to the network. BLIK RadioStation should be able to operate anywhere within 35 metres of the wireless base station – depending on the operating environment and the specification of your wireless base station.
Please ensure that your wireless network is powered-up and connected to your broadband Internet connection
These features include the ability to create a “Favourites” list and add unlisted radio stations and podcasts. See page 8 for instructions on how to register your radio.
need for modification or additional software. Meaning that BLIK is ready for future developments. This facility is in addition to BLIK’s reception of standard DAB signals.
3
Controls and Connectors
16.17.
1.
2.
3.
4.
5.
15.
14.
13.
12.
11.
6.
7.
8.
18.
10.
9.
1. Power On / Off
2. Volume Up
3. Scroll Back
4. Volume Down
5. Alarm
6. Presets 1-8
Media Player Controls
Stop
Play / Pause
7. Play
8. Preset 9 / Skip Back
9. Snooze / Sleep
10. Preset 10 / Skip Forward
11. Scroll Down
12. Info
Skip Back Skip Forward
13. Select
14. Scroll Forward
15. Mode
16. Scroll Up
17. Menu
18. Pause
Remote Control
14.15.
1. Scroll Back
2. Select
3. Menu
4. Scroll Down
5. Media Player
6. Presets 1-10
7. Alarm / Clock
8. Snooze / Sleep
9. Info
10. Volume Down
11. Scroll Forward
12. Volume Up
13. Power On / Off
14. Mode
15. Scroll Up
1. 2
3.
4.
5.
6.
1.
3.
2. 4. 5. 6.
13.
12.
11.
10.
9.
5. Media Player Controls
8.
7.
Stop
Skip Back Skip Forward
1. M-Port
2. Telescopic Antenna
3. DC Power Socket
4. 3.5mm Headphone Socket
5. Audio Right
6. Audio Left
Play / Pause
Powering BLIK RadioStation
Your BLIK RadioStation can be powered from the mains using the power adaptor supplied.
To power from the mains, insert the power adaptor plug into the DC power socket on the rear of BLIK RadioStation. Pressing the button will switch BLIK RadioStation on.
Only use the power adaptor supplied. Replacements can be purchased from our website
www.revo.co.uk
, or alternatively call us on 01555 66 61 61.
Setting the Time and Date
The time can be set in one of two ways, either manually via the System Setup option on the Main Menu, or alternatively simply press the MODE key until BLIK RadioStation enters DAB Mode. In DAB mode, BLIK will automatically set the correct time and date from the DAB transmitter.
4
Getting Started
BLIK RadioStation is a sophisticated digital radio device, with several modes of operation and many advanced features.
In order for you to get the most out of BLIK’s functions, it is important that you learn how to use the cursor based control system, and also understand how BLIK’s menus work.
BLIK RadioStation’s Control Method
BLIK RadioStation’s control method is based around seven main keys as identified below.
Diagram of the four cursor keys and the select, menu and mode button
Label each of the keys as follows:
Scroll Up:
Press to scroll through menu options
Scroll Back: Press to return to the previously selected menu entry. Repeatedly pressing will return you to the top level of the Mode menu (for the mode you are in).
Scroll Forward: When in text entry screens, this key can be used to navigate through the characters. It can also be used to move through to the next menu level.
Scroll Down: Press to scroll through menu options
SELECT – Press to select the current menu entry. In FM mode, pressing SELECT will initiate an FM scan.
Menu:
Press to enter (or return to) the Mode menu for the mode of operation you are currently in. Pressing for a second time will return you to the ‘playing’ screen.
Mode:
Sequentially cycles through each of the modes of operation.
Using these keys, you will be able to perform most functions and navigate through BLIK RadioStation’s various menus
BLIK RadioStation’s Menus Explained
BLIK RadioStation has three types of menu as follows:
Main Menu
This is BLIK RadioStation’s principle (top level) menu, and allows you to enter different operating modes, setup the radio, and view information such as software version and your radio’s ID number.
Mode Menus
The Mode menus are so called because they show the functions available within the context of each of the operating modes (internet radio mode, DAB mode, FM mode etc. etc.).
Pressing the MENU button at any time will take you to the Mode menu of the operating mode your radio is currently in. Each Mode menu includes a listing for Main Menu – selecting this option will return you to the top level Main Menu (as described above).
Main Menu
The Main menu provides access to the following modes and sub-menus:
Internet Radio Music Player DAB FM Mport Sleep Alarms System Setup Info
On powering-up BLIK RadioStation for the first time, you will be presented with this menu. To select an option from the menu, simply use the or keys to move through the menu options, and press SELECT or to make a selection or move to the next menu level.
5
Internet Radio Mode
Connecting to the Wi-Fi Network
In order to access BLIK RadioStation’s internet radio features, first you must connect to your Wi-Fi broadband connection.
Firstly, select ‘Internet Radio’ from BLIK’s main menu, or press the MODE key until ‘Internet Radio Mode’ appears on BLIK’s display.
BLIK RadioStation will now ask you to select a ‘Wlan region’. To do so, use the and cursor keys to scroll through the selections. Press the SELECT or key to make your selection.
BLIK RadioStation will ask you to choose the Wi-Fi network you’d like to use. If there are more than one available, all will be listed. To make your selection use the and cursor keys to scroll through the options. Press the SELECT or key to make your choice.
If the Wi-Fi network you have chosen doesn’t require a password, BLIK RadioStation will automatically connect.
If your chosen network has security enabled, you will be asked to input the relevant key or password. Remember, the password will be case-sensitive.
Use the and cursor keys to scroll through the banks of characters. Use the
and keys to move the flashing cursor
along the row of characters, and press SELECT when your chosen character is flashing. When the password has been entered, move the flashing cursor to the
symbol at the end of the line and press
SELECT. BLIK RadioStation will now connect to the network.
Internet Radio
Music Player
>Most of Europe USA
>My Home Network
>Connected>Connected
Key: 0123456789< C
Please wait Connecting...
BLIK RadioStation will remember the security key or password, you will not be required to enter it again, even after BLIK has been disconnected from main power.
BLIK can also remember keys and passwords for multiple Wi-Fi networks.
If at some time you would like to connect to another Wi-Fi network, you can do so by selecting ‘Wizard’ from the ‘Internet Setup’ option on the main menu, and entering the required key/password.
Advanced users can edit their Wi-Fi settings by accessing the ‘System Setup’ option from the Main menu.
6
>Internet setup Time setup
Using Internet Radio Features
The internet radio mode allows you to choose from a number of services, including listening to live radio or Podcasts. There are five options on the internet radio menu as follows:
My Favourites: Used to navigate to your favourite stations. This list is compiled using
your PC/Mac via the internet radio portal. See page 8 for details.
Stations: Find stations by location, genre, most popular, new station or by
alphabetical search.
Podcast: Find Podcasts or ‘Listen-Again’ services by location, genre or search.
My Added Stations: Shows stations which you have personally added to BLIK RadioStation’s
list through the vTuner internet radio portal. See page 8 for details.
Help: Find your Access Code here, see page 8.
Choosing A Station
To select a station, enter ‘Internet Radio
Mode’ from the Main Menu or by pressing
the MODE key until ‘Internet Radio Mode’ is
displayed on BLIK’s LCD display.
Using the and cursor keys, scroll to
the ‘Stations’ option and press SELECT or
the key.
You now have the option of selecting a
station by location (country), genre,
alphabetical search, most popular
stations or new stations. Using the
and cursor keys, scroll through the list
and press SELECT or the key to choose
your search criteria.
Internet Radio
Mode
My Favourites >Stations
Location >Genre
Choosing location will give you an
alphabetical list of continents/regions and
then a list of countries. Use the and
cursor keys, scroll through the list and
press SELECT or the key to choose your
country. You will then be given the option of
choosing a genre, to further refine your
search.
After selecting your search criteria, you will
be presented with a list of stations that
meet your requirements. Simply select a
station from the list to begin listening.
Choosing A Podcast
Podcasts (also referred to as ‘Listen Again’)
are selected in the same way as a regular
station.
Select ‘Podcast’ from the ‘Internet Radio’
menu, you can search for a station by
location, genre or a combination of both.
The main difference is that when you have
selected a station, you will then be
presented with a list of ‘shows’ or Podcasts
available from that station.
Select your choice by using the and
cursor keys, scroll through the list and
press SELECT or the key to make your
selection.
Location >Genre
Finland >France
BBC Radio 1 >BBc 1Xtra
BBC Radio 1 Playing
>Podcast My Added Stations
>Podcast My Added Stations
>BBC 6 Music BBC Radio 7
7
My Favourites
It is possible to compile a list (or lists) of your favourite stations, allowing quick and easy access to a number of varied stations. To do this you must first register your radio and then choose your favourites by visiting the Frontier Internet Radio Portal - see ‘Internet Radio Portal’ section below for details.
When in ‘Internet Radio Mode’, choose ‘Station List’ from the options, then select ‘My Favourites’.
If you have set up a ‘My Favourites’ list via the Frontier Portal, your list will appear on BLIK’s screen.
My Added Stations
If you have added any of your own stations to BLIK’s already huge station list (via the Frontier Portal - see section below), they will be listed here. The ‘My Added Stations’ option can be found under ‘Station List’ in ‘Internet Radio Mode’.
Help
The ‘Help’ option is where you can find the Access Code that you require to register your radio on the Frontier Portal (see below for full instructions). A helpful FAQ audio track can also be found under this heading.
>My Favourite
Stations
>Station List Main Menu
>Get Access Code FAQ
Internet Radio Portal
Access Additional Features
Some of BLIK RadioStation’s more advanced internet radio features can only be accessed by visiting the Frontier Internet Radio Portal.
In order to access these features you must first register your radio.
Registering Your Radio
Firstly, open your web browser on your PC or Mac and go to the Frontier Portal at
http://www.wifiradio-frontier.com
Click on the Register link, (located on the left hand panel) to begin the registration process.
You will now be asked for an Access Code.
To find your Access Code enter ‘Internet Radio Mode’, select ‘Station List’ from the options, then select ‘Help’. From the ‘Help’ menu now select “Get Access Code”.
Now fill-in the rest of the from to complete the registration process. You will now be able to login and take advantage of the various additional features and services offered by the Frontier Internet Radio Portal.
>Get Access Code ABCD1EF
8
Music Player Mode
Music Player Operation
BLIK RadioStation’s media player functionality allows you to play audio files (ACC, AIFF, AU, MP3, RM, WAV and WMA) and playlists (M3U) stored on a networked PC or Apple Mac. The media player functions have been tested and certified to operate with Windows 2000, Windows XP, Windows Vista and Mac OSX 10.2 –
10.4.9 (currently Mac OSX ‘Leopard’ is not supported).
Windows PC Set-Up
There are two Music Player modes available. Each of them requires different settings, and either one can be used to playback music from a media server.
Shared Folders (CIFS)
In order to set up the device to playback music stored on shared network drives, user name, password and domain settings must be configured to work with the PC share settings. This is only required if the user has set a password on his/her shared folders.
PC: Domain/Workgroup configuration
The Domain configuration item can be found on a Windows XP machine as follows:
1. From the start menu, select Control Panel > System then select the Computer Name tab.
2. The Domain or Workgroup that this Computer is a member of is displayed in this tab.
3. Select the user just created, select ‘Create Password ...’ and enter a password for this user.
4. Note the User Name and Password.
Note for Windows VISTA : Users have to turn on the Guest account via manage user accounts in the control panel in VISTA, then add access to either ‘Everyone’ or ‘Guest’ on the shared drive. They could create a new account for the internet radio, with a password, if they are concerned about security. The Guest account has no password by default, so the Wi-Fi radio will connect to it from its factory default settings.
PC: Configuring A Shared Drive
From the Start menu select My Computer and navigate to the directory you wish to share. Right click on the directory and select Sharing and Security. Configure the shared drive as read only, and ensure that the User Name created above has read access to the share.
Wi-Fi Radio: Storing The Username And Password
Before the radio can stream music from a PC, you need to ensure you have shared folder available on the PC, and set up the radio so that it knows the username and password (if one has been set) for the shared folder on the PC. This can be set up using the PC settings menu.
Shared Media (UPnP)
3. If the PC is not a member of any Domain or Workgroup then one must be joined. To do this click on the change button on the computer name tab and enter the name of the domain (default on Windows XP is MSHOME).
4. A reboot of the PC may be prompted if the Domain or Workgroup has been changed.
PC: Setting up a new user account (Windows XP)
BLIK RadioStation may require you to set-up a user account on each PC that you wish to browse. By default most PCs have at least one user account associated with it. The user name and password (optional) needs to be the same on each PC as the Internet Radio only stores one user name and one password. For windows XP this can be set up as follows:
1. From the start menu, select Control Panel -> User accounts
2. From this screen left click the ‘Add ...’, and enter the new user name and the Domain/Workgroup setting noted above. Select the type of user (limited) and then select ‘create account’.
Media sharing uses Windows Media Player (WMP) 11 and above as media server. This mode does not require any setting in the radio, but the PC needs to be configured to allow the radio access to the media. You will only have to do it once, following the next steps.
1. The PC must be connected to network (wired or wireless) that will be used to share media with the radio.
2. Ensure that the radio is powered on and connected to the same network as the PC.
3. In WMP, add to the media library the audio files and folders you want to share with your internet radio (in Library > Add to library).
4. In the WMP main window, click on Library, then Media sharing.
The Internet radio is presented as an “Unknown Device”. Make sure that the device has access to the shared media by selecting it and clicking <Allow>. Then click <OK>.
The PC is now ready to stream the music to the radio.
9
Music Player Mode
Apple Mac Set-Up
Set-Up for OSX 10.2.1 --> 10.4.9
Setup Windows File Sharing on the MAC:
From the ‘Dock’, click ‘System Preferences’. From the ‘System Preferences’ window (under the ‘Internet & Network’ section) click ‘Sharing’.
From the ‘Sharing’ window, do the following:
Under the ‘Services’ section, enable ‘Personal File Sharing’ and ‘Windows Sharing’. Also, click ‘Start’ for each of these services. Under Windows file sharing you will also need to 'enable' the account you wish to share from (This needs your administrator password).
Under the ‘Firewall’ section, keep firewall off.
Under the ‘Internet’ section, keep ‘Internet Sharing’ off.
Setup an Account:
From the ‘System Preferences’ window, under the ‘System’ section, click ‘Accounts’. Select an account and remember its ‘Short Name’ and password. This information will be used by BLIK RadioStation when connecting to your Mac.
Directory Setup:
From the ‘Dock’, click ‘Finder’. From the ‘Finder’ window, click ‘Applications > Utilities’. Holding Ctrl click on ‘Directory Access’ then select ‘Get Info’ and ensure that read / write enabled. Next double click on ‘Directory Access’ and enable the following:
AppleTalk LDAPv3
SLP SMB/CIFS
Also, for the ‘SMB/CIFS’ item, click ‘Configure’ and select an appropriate workgroup.
To allow your BLIK RadioStation you need to add your login details, by following the path Main Menu -> System Setup -> Internet Setup -> PC Settings. You should input your short username and administrator password here. Ensure that your Mac is successfully connected to the wireless network. Note, you may need to wait for few minutes for the changes to take effect. You should now be able to access the audio files on your Mac by selecting Browse -> Shared Folders on BLIK, then selecting the workgroup chosen in the step above. On selecting your Mac scroll through the available folders until you find the one which contains your music files.
Apple Mac Set-Up
Set-Up for OSX Leopard 10.5.1-->
Setup Windows File Sharing on the MAC:
From the ‘Dock’, click ‘System Preferences’. From the ‘System Preferences’ window (under the ‘Internet & Network’ section) click ‘Sharing’.
From the ‘Sharing’ window, do the following:
Under the ‘Services’ section, enable ‘File Sharing’ click ‘Start’ for this service. Then under the shared folders click the "+" and select the folder which contains your music files. Then Select the music folder from the shared folders area, in the users area make sure "Everyone" is set to read and write. Finally click on "Options" and make sure "Share files and folders using AFP" is checked and "Share files and folders using SMB" (This will require your admin password to activate) lastly make sure your account is also checked as active.
Ensure that your Mac is successfully connected to the wireless network. Note, you may need to wait for few minutes for the changes to take effect. You should now be able to access the audio files on your Mac by selecting ‘Browse > Shared Folders’ on BLIK, then selecting your Mac from the list of devices. On selecting your Mac, you should see your folder that you selected above.
10
DAB Mode
BBC Radio 1 calls cost max
BBC Radio 1 Pop Music
BBC Radio 1 BBC National DAB
BBC Radio 1 12B 225.64MHz
BBC Radio 1 128kbps Stereo
BBC Radio 6Music 11:48:03
BBC Radio 6Music 18/12/2007
BBC Radio 1 Sig strength 96
Choosing a Station
Extend the telescopic antenna found on the rear of BLIK RadioStation.
Enter ‘DAB Mode’ from the Main Menu or by pressing the MODE key until ‘DAB Mode’ is displayed on BLIK’s LCD display.
If this is the first time BLIK RadioStation has been used in DAB Mode, it will scan for DAB stations in your area and store them in memory. BLIK will also set its clock at this point.
When the station scan has been completed, stations will be displayed in numeric then alphabetic order. The first station in the list will be selected.
If no DAB signal is found, it may be necessary for you to relocate your radio.
www.ukdigitalradio.com/coverage
Or visit to check that DAB coverage is available in your area.
Select your station choice by using the and cursor keys, scroll through the station list and press SELECT or the key to make your selection.
To Change the Display Mode
BLIK has nine different display modes.
Simply press the INFO button to cycle through each mode. These display modes are explained in the table opposite:
MODE
Display option Example
DAB Mode
Scanning... 10
•••••
>ArrwRock
BBCAsian
BBC 6Music
Service not ava
BBC 6Music
Playing
Normal display with scrolling text
Signal level, indicator on bar shows minimum
tlkSPORT
acceptable level
Type of broadcast
Broadcaster
Station name and frequency
Signal strength
Data rate and stereo/mono
Time
Date
11
DAB Mode Menu Options
BLIK RadioStation has a number of additional functions that are accessed through the DAB
Mode menu, as follows:
Station Order
Press the MENU key in DAB Mode then press select Station order.
To specify the order in which stations are displayed
Select the Station order option.
Use the and cursor keys to scroll through the options, and press SELECT or the key to make your selection.
Manual Tune
Choose the Manual Tune option from the DAB Mode menu.
The Manual Tune selection screen allows you to select a particular frequency to tune to. The list of frequencies displayed is dependant on the currently-set frequency band and contains all of the frequencies within that band. It starts with the short name of the frequency, for example 12B, and is followed by the actual frequency in MHz.
If there is a station corresponding to this station number and frequency, the display will show the name, frequency, and a tuning meter will show the signal strength.
DRC - Dynamic Range Control
BLIK RadioStation includes a dynamic range control that automatically boosts the volume of quieter sounds for listening in noisy environments.
The DRC control is found in the DAB Mode menu under ‘DRC’. There are three pre-defined settings as follows:
DRC Description
DRC Low Dynamic Range Control is
DRC High The recommended setting
DRC Off Dynamic Range Control is
set to half
for noisy environments
switched off
The following table describes the options available under the ‘Station Order’ menu:
Station order Description
Alphanumeric Lists stations in alphabetical
Ensemble Lists stations by multiplex.
Valid Lists only active stations.
order.
Local and Full Scan
As time passes, new stations will become available in your area. To find them and add them to your station list it is necessary to perform either a ‘Local’ or ‘Full’ scan. Both operations can be accessed via the DAB Mode menu.
A Local Scan performs a shorter scan of only the ‘local’ ensemble range.
A Full Scan will take longer, but will cover the complete DAB ensemble range.
Favourite Station Presets
BLIK RadioStation allows you to store 10 favourite station presets, either via the 10 preset keys on BLIK itself, or on the BLIK remote control.
To save the station you are currently listening to as a preset, simply press and hold a preset key (from 1 - 10) for 2 seconds. BLIK will confirm that the key has been programmed by displaying ‘Preset Stored’ on BLIK’s LCD screen.
Please note, if you store a preset on a key that was already holding a favourite station, the previous station will automatically be erased.
12
FM Mode
87.50Mhz FM
87.50Mhz FM
BBC Radio 1 Preset Stored
FM Mode
M-Port
MPort Mode
FM Operation
Extend the telescopic antenna found on the rear of BLIK RadioStation.
Enter ‘FM Mode’ from the Main Menu or by pressing the MODE key until ‘FM Mode’ is displayed on BLIK’s LCD display.
If this is the first time BLIK has been in FM mode, it will start at the beginning of the FM frequency range. Otherwise, the last FM station you were listening to will be selected.
To scan through the FM frequency range press the and buttons.
To ‘SEEK’ the next active station, press the
SELECT button.
Favourite Station Presets
BLIK RadioStation allows you to store 10 favourite station presets, either via the 10 preset keys on BLIK itself, or on the BLIK remote control.
To save the station you are currently listening to as a preset, simply press and hold a preset key (from 1 - 10) for 2 seconds. BLIK will confirm that the key has been programmed by displaying ‘Preset Stored’ on BLIK’s LCD screen.
Please note, if you store a preset on a key that was already holding a favourite station, the previous station will automatically be erased.
MODE
MPort Mode
Using MPort
Revo’s MPort connector allows for quick and easy connection of an iPod®, similar MP3 player or sound source.
Using the connection lead supplied, BLIK is transformed into a high quality digital audio speaker system.
Connect one end of the supplied audio lead to the headphone (or auxiliary out) socket of your source device, then connect the other end to the MPort on the side of BLIK.
Now press the MODE key and cycle through the options until ‘MPort Mode’ is displayed.
BLIK’s LCD screen will now display the word ‘MPort’ on its screen.
You should adjust the output volume level on both the source device and on BLIK itself to gain optimal volume levels and sound performance.
13
Alarms Mode
BLIK RadioStation must have its clock and date set to use the alarm functionality.
To automatically set the time and date, tune to a DAB service and BLIK will extract the correct time and date from the DAB broadcast stream. Alternatively, the time and date can be manually set via the ‘Time Setup’ option, this can be found under the ‘System Setup’ menu, which is located in the ‘Main Menu.”
Setting An Alarm
BLIK allows you to store up to four different alarm programmes in memory.
To set an alarm, press the ALARM button.
BLIK will now ask you to choose which of the four alarm memories you’d like to use. Use the and keys too choose an alarm and press SELECT.
To set the wake-up time, press SELECT and use the and keys to set the wake up hour, then press SELECT or the button to move onto the minute setting. When your wake-up time has been set, press SELECT.
You can now decide whether you would like to be woken up by Internet Radio, DAB, FM or Buzzer. To choose the wake­up mode press the key to view the ‘Mode’ option and press SELECT.
You can now decide whether you would like to be woken-up by the last played station, or by a specific preset (if none are set, BLIK will wake you up using the default Buzzer).
You will now have the option to set the wake-up volume for your alarm. Use the
and keys to adjust the volume and
press SELECT to set.
Finally, you should select ‘Save’ from the menu to complete your alarm programme.
When BLIK has an active alarm in its memory, the alarm icon will appear on the top line of BLIK’s display at all times.
ALARM
Alarm1: Off Alarm2: Off
Set Alarm Time 07:15
>Internet Radio DAB Mode
>Mode: DAB Mode Last Listened
Alarm Volume
•••••••••••
Alarm Volume
•••••••••••
To halt an alarm, press any button on BLIK’s keypad. Alternatively, tap the SNOOZE button to mute the alarm for a period of 5 minutes. When BLIK is in Snooze mode, the Snooze icon will be displayed on the LCD screen, together with the current time and remaining Snooze time.
To cancel a preset alarm, go back into the ALARM programming mode and change ‘ON’ to ‘OFF. The details of the alarm will continue to be retained in memory, and the alarm programme can be switched back on again at a later date.
14
07:15 >off
07:20:01
5:00
Sleep Mode
Setting A Sleep Period
It is possible to programme BLIK RadioStation to turn off after a pre­defined period of time. To do so, select the ‘Sleep’ option from the Main Menu.
Now, using the and keys, you can select a sleep time period of 15, 30, 45, 60, 75 or 90 minutes.
BLIK will now automatically put itself into standby mode after the time has elapsed.
System Setup
Set sleep time
Sleep time off
Set sleep time
Sleep time off
Internet Setup
Advanced users can find and edit their Wi-Fi settings in this section, these include MAC address, DHCP status, PC Settings, SSID, IP Settings etc.
Time Setup
The time can be set in one of two ways, either manually via the System Setup option on the Main Menu, or alternatively simply press the MODE key until BLIK RadioStation enters DAB Mode. In DAB mode, BLIK will automatically set the correct time and date from the DAB transmitter. BLIK will remember its time setting even when in standby mode, and will only lose the time/date when power is removed.
Under the ‘Time Setup’ menu, you can also switch between 12 an 24 hour clock formats.
Lastly, the ‘Auto Update’ option in the ‘Time Setup’ menu allows you to select whether or not the time should be synchronised with the DAB broadcaster clock. If ‘No Update’ is selected, then the clock remains as manually set.
Info
Factory Reset
In the unlikely event that BLIK RadioStation should ‘crash’, ‘freeze’ or start behaving in a strange way, it is possible to perform a full software reset. This operation will completely reset BLIK’s memory, clearing all WEP/WPA codes and user settings. This will effectively return BLIK to its default factory settings.
Software Update
It is possible to remotely update BLIK RadioStation’s software via your Wi-Fi internet connection, to ensure that you have all the latest features, or to fix known bugs in the software. To check whether there are any updates available, simply go to the ‘System Setup’ option on the ‘Main Menu’ and select ‘Software Update’. BLIK will search to see if a software update is necessary, then report back. If an update is available and necessary, BLIK will start the download process and install its new software automatically.
Software Version and Radio ID
You may be asked for one or both of these pieces of information when dealing with a technical support issue.
Both can be found under the ‘Info’ heading, located in the ‘Main Menu’.
SW version
ir.dabp-mmi.rvo.ve
Radio ID
0013EOA11D25
15
Troubleshooting
Wi-Fi Internet Radio
If you are experiencing any problems with your BLIK RadioStation please read the following ‘troubleshooting’ guide. Alternatively you can visit the support section of the Revo website (www.revo.co.uk) or call our technical support staff on 01555 66 61 61.
If you have trouble connecting BLIK RadioStation to your wireless network, these steps may help to resolve the problem:
1. Confirm that a Wi-Fi connected PC can access the Internet (i.e. can browse the web) using the same network.
2. Check that a DHCP server is available, or that you have configured a static IP address on the radio.
3. Check that your network’s firewall is not blocking any outgoing ports.
As a minimum, BLIK RadioStation needs access to UDP and TCP ports 80, 554, 1755, 5000 and 7070.
4. Check your access point does not restrict connections to particular MAC addresses. You can view the radio’s MAC address under the ‘Internet Setup’ section, accessed via the ‘System Setup’ option on BLIK’s main menu.
5. If you have an encrypted network, check that you have entered the correct key or pass phrase into the radio. Remember that text-format keys are case sensitive. If, when attempting to connect to an encrypted network, your radio displays: ‘Wireless error’ followed by a 5-digit number, then please ensure that you enter the correct pass phrase for the network. If the problem persists, then you may need to consult your network configuration.
If BLIK RadioStation can connect to the network successfully, but is unable to play particular stations, it may be due to one of the following causes:
1. The station is not broadcasting at this time of the day (remember it may be located in a different time zone).
2. The station has reached the maximum allowed number of simultaneous listeners.
3. The station is not broadcasting anymore.
4. The link on the radio is out of date.
5. The Internet connection between the server (often located in a different country) and you is slow.
DAB Digital Radio
Q. I hear a ‘burbling’ noise on some
stations.
A. If the signal strength is too low, a break-
up in reception can occur. This sound is the result. Make sure that BLIK’s antenna is fully extended and in an upright position. If the problem persists, move BLIK to another location or check that you are in an area where reception of this station is possible. Visit: www.ukdigitalradio.com/coverage to check DAB coverage in your area.
Q. I get a ‘No stations available’ message?
A. Make sure that your antenna is fully
extended and vertical. Check the signal strength and move BLIK to another location if necessary.
Q. BLIK’s clock isn’t set.
A. BLIK needs to be able to pick-up a DAB
signal or have its clock set manually. If BLIK can find a DAB station, it can then set its clock.
16
Revo Technologies Ltd The Inox Building Caldwellside Lanark Scotland United Kingdom ML11 7SR
Telephone Support
Online Support
www.revo.co.uk/support support@revo.co.uk
01555 666 161
Loading...
