REVEL PERFORMA F30
Owner’s Manual
2
Figure 1. The REVEL
PERFORMA F30
loudspeaker.
INTRODUCTION
Revel®leads the loudspeaker world in research, advanced
engineering techniques, and unique production processes. The
REVEL PERFORMA
™
F30 loudspeaker is the perfect demonstra-
tion of Revel’s unparalleled engineering capabilities.
The Revel Performa F30 loudspeaker utilizes much of the advanced
engineering found in Revel’s famed Ultima™ loudspeakers. Each one
has an inverted magnesium/aluminum-alloy dome woofer and
midrange and an aluminum dome tweeter that achieve fully pistonic
performance to yield extraordinary freedom from coloration. We also
use our groundbreaking measurement process to seamlessly integrate
the superb transducers with the high-order crossover network to achieve
a truly full-range sound with stunning realism and superb dynamics.
As a result, the REVEL PERFORMA F30 loudspeaker sets a whole
new standard in sound quality at anywhere near its price range. Its
superior performance, assured by our ongoing research, will greatly
contribute to the enjoyment of music or film sound in your home.
ABOUT THE MANUAL AND WARRANTY
To begin enjoying your new loudspeakers, first read and then perform
the instructions in this owner’s manual. Maximum performance
depends on following all instructions described here, as well as those
found in the owner’s manuals of associated components in your audio
system. Save these instructions for future reference.
REVEL PERFORMA F30 loudspeakers are covered by a limited
5-year warranty, so save the bill of sale to protect your purchase
and aid in any service-related questions.
REVEL PERFORMA F30
Owner’s Manual
3
,,,,,,,
Figure 2. Transducer and connection locations for the REVEL
PERFORMA F30 loudspeaker.
DESCRIPTION
The REVEL PERFORMA F30 loudspeaker features a transducer
complement (see Figure 2) of one 10-inch (250 mm) woofer, a
5.25-inch (133 mm) midrange driver, and a 1-inch (25 mm) tweeter.
Combined with an individually-optimized crossover network, this
transducer arrangement results in a superior off-axis response that
provides a large “listening window” and an uncolored in-room
response, even in the presence of strong wall reflections.
WOOFER
The 10-inch (250 mm) inverted aluminum-dome woofer features:
• True pistonic operation for increased freedom from coloration.
• Optimized and shielded magnetic circuits to minimize harmonic
distortion and prevent interference with video monitors.
• Butyl rubber surround for large, linear excursion capabilities.
• CCA (carbon composite aluminum) flat-wire voice coil on a
2–inch (50 mm) fiberglass bobbin for low mass with high
power handling.
• Vented center-pole piece for better cooling and low compression.
REVEL PERFORMA F30
Owner’s Manual
4
Install straps for
single-wire operation
Install straps for
single-wire operation
Low Frequency Input High Frequency Input
Remove straps
for bi-wire
or bi-amp
+1-1
0
+.5
-.5
Front Tweeter Level (dB)
Serial Number
Revel
Northridge, California
Made in U.S.A.
xxxx
REVEL PERFORMA F30 Front
(without grilles)
REVEL PERFORMA F30 Rear
Tweeter
Woofer Port
Tweeter
Level Control
Midrange
Woofer
Connectors (with
shorting straps)
MIDRANGE
The 5.25-inch (133 mm) inverted magnesium-dome midrange
transducer features:
• True pistonic operation for increased freedom from coloration.
• Optimized and shielded magnetic circuits to minimize harmonic
distortion and prevent interference with video monitors.
• Butyl rubber surround for large, linear excursion capabilities.
• Oversized 1.5-inch (38 mm) voice coil wire on a Kapton
®
bobbin for low mass with increased strength.
TWEETER
The 1-inch (25 mm) aluminum-alloy dome tweeter features:
• True pistonic operation for increased freedom from coloration.
• Underhung with copper-clad aluminum wire for low distortion.
• Ferrofluid for better power handling with reduced compression.
• Magnetically shielded to prevent interference with video monitors.
CROSSOVER NETWORK
Each REVEL PERFORMA F30 loudspeaker has an individuallyoptimized crossover network with:
• A high-order crossover at 220 Hz and 2.8 kHz to optimize the
on- and off-axis response of the system.
• Filter networks with carefully selected components for optimum
performance with low distortion across a wide dynamic range.
• Provision for bi-amplified applications via removable external
shorting straps on the gold-plated binding posts.
CABINET
The cabinet is constructed of 1-inch (25 mm) thick MDF walls
with extensive internal bracing for unshakable performance.
A rounded front baffle is sculpted to reduce diffraction, and four
cast aluminum feet adorn the cabinet for superior coupling to any
floor. The wood-veneer cabinet is available in finishes of Cherry,
Sycamore, Rose, or Black Ash.
REVEL PERFORMA F30
Owner’s Manual
5
WARNING
Figure 3. A REVEL
PERFORMA F30 loudspeaker
with its inner packing materials.
UNPACKING
IMPORTANT! Do not attempt to lift a REVEL PERFORMA F30
loudspeaker from its packing carton alone – use at least two strong
people to unpack the product properly. To avoid injury, use
extreme care during unpacking. Always stand as straight as possible and use your leg muscles to lift the REVEL PERFORMA F30
loudspeaker. Do not lift it while bending from the waist.
Each REVEL PERFORMA F30 loudspeaker is packed in its own
carton with a shipping weight of 102 pounds (46.3 kg). To avoid
personal injury and possible product damage, we strongly urge you
to enlist additional help before unpacking either carton.
To unpack a loudspeaker, perform the following steps:
1. Place a REVEL PERFORMA F30 loudspeaker onto its side.
2. Open the bottom flaps. Stand the unit in the up position.
3. Open the top flaps. Take out the spike foot kit and set it aside.
Remove the top pad.
4. Lift the carton off the loudspeaker and set it aside, being careful
not to damage the cabinet. Also, remove the middle pad.
5. Grasping the cabinet on the sides, lift it up and remove the bottom pad. Use caution to avoid touching any of the transducers.
REVEL PERFORMA F30
Owner’s Manual
6
Install straps for
single-wire operation
Install straps for
single-wire operation
Low Frequency Input
High Frequency Input
Remove straps
for bi-wire
or bi-amp
+1-1
0
+.5
-.5
Front Tweeter Level (dB)
Serial Number
Revel
Northridge, California
Made in U.S.A.
Spike Foot Kit
Middle Pad
Top Pad
Bottom Pad
Warranty Card and
Owner’s Manual
