Many aircraft were shot down in
Vietnam, but were not destroyed. The
U.S. airforce created the giant HH-53C
Super Jolly Green Giant to rescue
downed pilots and to hoist any sal­vagable aircraft. This huge machine
owes it's loading capability to the great
Skycrane helicopter. The Super Jolly
contained armor protection and extra
fuel for a six man crew on a rescue
mission. The Super Jolly was used by
the U.S. Navy, Marines, and Airforce.
Your Revell model features rotat­ing main and tail rotors, auxiliary fuel
tanks, rescue hoist, detailed cock­pit, opening cargo door, optional
U.S. Army vehicle, 105mm Howitzer,
removable engine covers and authen­tic decal markings for two versions.

KIT 4542 85454200200

HH-53C

SUPER JOLLY GREEN GIANT

* REPEAT SEVERAL TIMES

* A REPETER PLUSIEURS FOIS

READ THIS BEFORE YOU BEGIN LIRE CE QUI SUIT AVANT DE COMMENCER

* Study the assembly drawings.
* Each plastic part is identified by a number.
* In the assembly drawings, some parts will be

marked by a star (★) to indicate chrome
plated plastic.

* For better paint and decal adhesion, wash

the plastic parts in a mild detergent solution.
Rinse and let air dry.

* Check the fit of each piece before

cementing in place.
* Use only cement for polystyrene plastic.
* Scrape plating and paint from areas

to be cemented.
* Allow paint to dry thoroughly before

handling parts.
* Any unused parts may be discarded.

DECAL APPLICATION INSTRUCTIONS

1. Cut desired decal from sheet.

2. Dip decal in water for a few seconds.

3. Place wet decal on paper towel.

4. Wait until decal is movable on paper backing.

5. Place decal in position on model, face up and

slide backing away.

6. Press out air bubbles with a soft damp cloth.

7. Milkiness that may appear is for better decal

adhesion and will dry clear. Wipe away any

excess adhesive.

8. Do not touch decal until fully dry.

9. Allow the decals 48 hours to dry before

applying clear coat.

NOTE: Decals are compatible with

setting solutions or solvents.

* REPEAT PROCEDURE

* R E P E T E Z L E P R O C E D E

* OPTIONAL PARTS

`` ` ` `

* PIECES EN OPTION

* Etudier les schémas de montage.
* Chaque pièce en plastique est identifiée par un numéro.
* Sur les schémas de montage, certaines pièces sont

marquées d'une étoile (★) pour indiquer qu'elles sont en
plastique chromé.

* Pour une meilleure prise de la peinture et des autocollants,

laver les pièces en plastique avec une solution détergente peu
concentrée. Les rincer et les laisser sécher à l'air.

* Vérifier que chaque pièce s'ajuste bien avant

de la coller en place.
* N'utiliser que de la colle pour polystyrène.
* Gratter les parties à coller pour enlever le chrome et la peinture.
* Laisser la peinture bien sécher avant de manipuler les pièces.
* Toute pièce inutilisée peut être jetée.

DIRECTIVES D'APPLICATION DES AUTOCOLLANTS

1. Découper l'autocollant désiré de la feuille.

2. Tremper l'autocollant dans de l'eau pendant quelques secondes.

3. Placer l'autocollant mouillé sur une serviette en papier.

4. Attendez que l'autocollant puisse être déplacé sur son

support en papier.

5. Mettre l'autocollant en position sur le modèle face sur

le dessus et faire glisser le support pour l'enlever.

6. Appuyer avec un chiffon doux humide pour éliminer les bulles d'air.

7. La substance laiteuse qui peut apparaître est destinée à

améliorer l'adhésion de l'autocollant et devient incolore au

séchage. Essuyer pour enlever tout excédent d'adhésif.

8. Ne pas toucher l'autocollant tant qu'il n'est pas bien sec.

9. Laisser l'autocollant sécher pendant 48 heures avant

d'appliquer une couche transparente.

REMARQUE: Les autocollants sont compatibles avec

* DECAL

* DECAL COMANIE

les solutions de fixage ou les solvants.

* ASSEMBLY CAUTION

*ATTENTION D ASSEMBLEE

* CEMENT TOGETHER

* A COLLER

This paint guide is provided to complete this kit

Ce guide de peintures est fourni pour reproduire le modèle

Semi Gloss Black

Red

White

Silver

Olive Drab

Dark green

Field Green

Gray

Dark Tan

Steel

* REMOVE AND THROW AWAY

* A RETIRER ET JETER

as shown on the box.

réduit qui apparaît sur la boîte.

Noir satiné

Rouge

Blanc

Argent

Gris vert

Vert fonce

Vert champétre

Gris

Havane foncé

Acier

* DO NOT CEMENT

* NE PAS COLLER

If you have any questions or comments, call our hotline at: [phone]

or, please write to:

Revell Inc Consumer Service Department, 1850 Howard Street Unit A, Elk Grove Village, Illinois 60007

Be sure to include the plan number (85454200200), part number, description, your return address and phone number.

Visit our website: www.revell.com

Revell Inc Elk Grove Village, IL. Copyright © 2010. All rights reserved.

1

COCKPIT ASSEMBLY

8

CONTROL

PEDAL BULKHEAD

GRAY

5

SEAT

GRAY

7

YAW

CONTROL PEDALS

GRAY

10

CYCLIC PITCH

CONTROL COLUMN

GRAY

SEMI GLOSS

BLACK

SILVER

SEMI

GLOSS-

BLACK

INSTRUMENT PANEL

SEMI GLOSS BLACK WITH

11

SILVER DIALS

DECAL

1

6

PITCH CONTROL

LEVER

SEMI GLOSS

BLACK

OLIVE DRAB

WHITE

SILVER

COCKPIT BULKHEAD

SHADED AREAS - SEMI GLOSS

12

GRAY

BLACK

Kit 4542 - Page 2

10

CYCLIC PITCH

CONTROL COLUMN

GRAY

SEMI GLOSS

BLACK

COCKPIT AND CARGO FLOOR

9

GRAY

2

FUSELAGE / WINDOW ASSEMBLY

19

SIDE WINDOWS

CLEAR

(INTERIOR ONLY)

18

RIGHT

FUSELAGE

GRAY

EMERGENCY EXIT WINDOW

17

CLEAR

MAIN ROTOR SHAFT

22

FUSELAGE

(INTERIOR ONLY)

20

NOSE GEAR WELL

WHITE

21

LEFT

GRAY

EMERGENCY EXIT WINDOW

17

CLEAR

19

SIDE WINDOWS

CLEAR

3

UPPER CARGO DOOR

16

GRAY (INSIDE)

RAMP ASSEMBLY

CARGO DOOR WINDOW

17

CLEAR

CARGO RAMP OUTSIDE

CARGO RAMP INSIDE

15

GRAY

14

CARGO RAMP

EXTENSIONS

GRAY

13

GRAY

4

RAMP / FUSELAGE ASSEMBLY

FIRST

5

25

RIGHT

MAIN OUTER WHEEL

SEMI GLOSS

BLACK

RAMP

23

TAIL ROTOR SHAFT

DOOR

24

TAIL ROTOR

SEMI GLOSS BLACK

SECOND

CARGO RAMP

THIRD

CARGO

DOOR

MAIN WHEEL / SPONSON ASSEMBLY

27

MAIN GEAR STRUT

WHITE

28

LEFT

SILVER

MAIN OUTER WHEEL

SEMI GLOSS BLACK

30

RIGHT

OUTSIDE SPONSON

(INTERIOR ONLY) WHITE

CANOPY

(FRAME FUSELAGE COLOR)

Kit 4542 - Page 4

33

CLEAR

26

INNER WHEEL

SEMI GLOSS BLACK

26

INNER WHEEL

SEMI GLOSS BLACK

INSIDE SPONSON

(INTERIOR ONLY) WHITE

INSIDE SPONSON

(INTERIOR ONLY) WHITE

29

RIGHT

31

LEFT

WHITE

32

LEFT

OUTSIDE SPONSON

(INTERIOR ONLY) WHITE

6

NOSE WHEEL ASSEMBLY

34

LEFT

NOSE OUTER WHEEL

SEMI GLOSS BLACK

35

NOSE GEAR STRUT

WHITE

NOSE GEAR DOOR

(INTERIOR ONLY) WHITE

26

INNER WHEEL

SEMI GLOSS BLACK

SILVER

36

SEMI GLOSS BLACK

SILVER

26

INNER WHEEL

28

RIGHT

NOSE OUTER WHEEL

SEMI GLOSS BLACK

WHITE

VENTRAL ANTENNA

37

38

CARGO HOOK

7

ENGINE COWLING TOP

SEMI GLOSS

BLACK

LEFT

(INTERIOR ONLY) WHITE

COWLING ASSEMBLY

43

RIGHT

(INTERIOR ONLY) WHITE

SEMI GLOSS

BLACK

RED

ENGINE COWLING BOTTOM

(INTERIOR ONLY) WHITE

44

RIGHT ENGINE

EXHAUST COVER

STEEL

RED

42

RIGHT

Kit 4542 - Page 5Kit 4542 - Page 8

RED

41

LEFT

STEEL

ENGINE COWLING TOP

SEMI
GLOSS
BLACK

39

ENGINE EXHAUST COVER

RED

40

ENGINE COWLING BOTTOM

LEFT

(INTERIOR ONLY) WHITE

8

ENGINE ASSEMBLY

45

RIGHT ENGINE

INTAKE OUTSIDE

SEMI
GLOSS
BLACK

46
RIGHT ENGINE
INTAKE INSIDE

47

INTAKE

SUPPORT BRACKET

HORIZONTAL STABILIZER

HORIZONTAL STABILIZER

50

TOP

51

BOTTOM

49

LEFT ENGINE

INTAKE INSIDE

SEMI
GLOSS
BLACK

48

LEFT ENGINE

INTAKE OUTSIDE

47

INTAKE

SUPPORT BRACKET

9

FUEL TANK PYLON TOP

Kit 4542 - Page 6 Kit 4542 - Page 7

FUEL TANK PYLON ASSEMBLY

52

LEFT

53

FUEL TANK PYLON BOTTOM

LEFT

FUEL TANK PYLON TOP

54

RIGHT

FUEL TANK PYLON BOTTOM

55

RIGHT

10

ANTENNA / TANK / BOOM ASSEMBLY

57

AUXILIARY FUEL TANK HALF

RIGHT

79

AFT

RIGHT

78

VOR / LOCALIZER AERIALS

FUSELAGE ANTENNA

FUEL TANK PYLON

80

FUSELAGE

ANTENNA

TACAN AERIAL

81
SPONSON
ANTENNA

56

AUXILIARY FUEL TANK HALF

82

LEFT

LEFT

FUEL TANK PYLON

83

UHF AERIAL

84

RESCUE

HOIST STRUTS

86

RESCUE HOIST

RESCUE CABLE / HOOK

85

STEEL

59

REFUELING BOOM HALF

RIGHT

OLIVE DRAB

58

REFUELING BOOM HALF

LEFT

OLIVE DRAB

STEEL

11

ROTATING SWASH

4

ROTOR HEAD

FAIRING

2

PLATE

STEEL

60

RIGHT

PITOT TUBE

(TIP) SILVER

ROTOR ASSEMBLY

1

ROTOR HEAD

MECHANISM

STEEL

3

ROTOR BLADES

WHITE

SEMI GLOSS BLACK

61

LEFT

PITOT TUBE

(TIP) SILVER

WHITE

WHITE

12

STEERING WHEEL

ARMY VEHICLE ASSEMBLY

64

WINDSHIELD

CLEAR

65

63

WINDSHIELD

FRAME

62

BODY

12

ARMY VEHIC LE ASSEMBLY CONTINUED

68

INNER WHEEL

SEMI GLOSS BLACK

69

GRILLE

(HEADLIGHTS) SILVER

67

OUTER WHEEL

SEMI GLOSS

BLACK

OLIVE DRAB

13

74

HOWITZER BARREL HALF

LEFT

OLIVE DRAB

66

CHASSIS

SEMI GLOSS BLACK

105MM HOWITZER ASSEMBLY

72

INNER WHEEL

SEMI GLOSS BLACK

73

HOWITZER BARREL HALF

RIGHT

OLIVE DRAB

71

OUTER WHEEL

SEMI GLOSS

BLACK

OLIVE DRAB

Kit 4542 - Page 9

13

HOWITZER ASSEMBLY CONTINUED

75

ARMOR PLATE

OLIVE DRAB

70

FRAME

OLIVE DRAB

14

HYDRAULIC JACK

76

TAIL BUMPER

STEEL

COMPLETED ASSEMBLY

FINAL ASSEMBLY

SHOWN ASSEMBLED

27

77

TAIL BUMPER

STEEL

27

Kit 4542 - Page 10 Kit 4542 - Page 3

15

DECAL PLACEMENT

Kit 4542 - Page 11

16

DECAL PLACEMENT

Kit 4542 - Page 12
