HOW TO MEASURE FOR A CLOSET DOOR
MKTD4074 ENG REV 2021
1 RENIN.COMRENIN 2020
INTERIOR DOORS & HARDWARE | HOW TO ORDER
MEASURING THE FINISHED OPENING
It is important to measure a nished opening in the following places to the nearest 1/8"
BYPASS DOORS
For bypass doors, use the shortest height
measurement and largest width measurement
when selecting your door.
A
Width at Top
A
A
Width at Top
A
B
Width at Bottom
C
Height (Left Side)
C
Height (Right Side)
D
D
B
BIFOLD & PIVOT DOORS
For bifold and pivot doors, use the smallest height measurement and smallest width measurement when
selecting your door. NOTE: If the diagonal measurements are more than a 1/2" dierence, the doors will
not slide open or closed completely and the opening should be xed so the opening is straighter.
B
Width at Bottom
C
Height (Left Side)
Height (Right Side)
D
E
E
Diagonal
E F
B
F
Diagonal
C
D
F
2 RENIN.COM
INTERIOR DOORS & HARDWARE | HOW TO ORDER
GENERAL SIZING INFORMATION
STANDARD SIZES FOR
81" SLIDING BYPASS DOORS
(INCLUDES MODELS: EU2010,
EU2030, EU2450, EU2460, EU2470,
EU3210, EU3220, EU3265, EU3290
AND EU3295)
FINISHED
OPENING SIZE
# OF PANELS
48" x 80¼" - 80⅞" 2
60" x 80¼" - 80⅞" 2
72" x 80¼" - 80⅞" 2
No custom sizing available on
these models.
STANDARD SIZES FOR 80
TOP ROLL SLIDING BYPASS DOORS
(INCLUDES MODELS: BY0100,
BY0106, BY0108, BY0109
AND BY0120)
FINISHED
OPENING SIZE
# OF PANELS
1
/
"
2
48" x 80" - 81" 2
60" x 80" - 81" 2
72" x 80" - 81" 2
84" x 80" - 81" 2
96" x 80" - 81" 2
108" x 80" - 81" 3
120" x 80" - 81" 3
144" x 80" - 81" 3
192" x 80" - 81" 4
STANDARD SIZES FOR 96"
TOP ROLL SLIDING BYPASS DOORS
(INCLUDES MODELS: BY0100)
FINISHED
OPENING SIZE
# OF PANELS
48" x 95½" - 96½" 2
60" x 95½" - 96½" 2
72" x 95½" - 96½" 2
84" x 95½" - 96½" 2
96" x 95½" - 96½" 2
108" x 95½" - 96½" 3
120" x 95½" - 96½" 3
144" x 95½" - 96½" 3
192" x 95½" - 96½" 4
STANDARD SIZES FOR
BOTTOM ROLL SLIDING BYPASS DOORS
(INCLUDES MODELS: BY0220, BY0230,
BY0250, BY320B AND BY320P)
FINISHED
OPENING SIZE
# OF PANELS
80
1
/
"
2
48" x 80" - 80¾" 2
60" x 80" - 80¾" 2
72" x 80" - 80¾" 2
84" x 80" - 80¾" 2
96" x 80" - 80¾" 2
108" x 80" - 80¾" 3
120" x 80" - 80¾" 3
144" x 80" - 80¾" 3
192" x 80" - 80¾" 4
STANDARD SIZES FOR 96"
BOTTOM ROLL SLIDING BYPASS DOORS
(INCLUDES MODELS: BY0220, BY0230,
BY0250, BY320B AND BY320P)
FINISHED
OPENING SIZE
# OF PANELS
48" x 95½" - 96¼" 2
60" x 95½" - 96¼" 2
72" x 95½" - 96¼" 2
84" x 95½" - 96¼" 2
96" x 95½" - 96¼" 2
108" x 95½" - 96¼" 3
120" x 95½" - 96¼" 3
144" x 95½" - 96¼" 3
192" x 95½" - 96¼" 4
STANDARD SIZES FOR
1
80
/
" BIFOLD DOORS
2
(INCLUDES MODELS: EU3010,
EU3080, EU3110, AND EU3150)
FINISHED
OPENING SIZE
# OF PANELS
24" x 80¼" - 80⅝" 2
30" x 80¼" - 80⅝" 2
36" x 80¼" - 80⅝" 2
No custom sizing available on
these models.
3 RENIN.COM
INTERIOR DOORS & HARDWARE | HOW TO ORDER
GENERAL SIZING INFORMATION
STANDARD SIZES FOR
1
80
/
" BIFOLD DOORS
2
(INCLUDES MODELS: BI0221,
BI321B AND BI321P)
FINISHED
OPENING SIZE
# OF PANELS
24" x 80⅜" - 80⅞" 2
30" x 80⅜" - 80⅞" 2
36" x 80⅜" - 80⅞" 2
48" x 80⅜" - 80⅞" 4
60" x 80⅜" - 80⅞" 4
72" x 80⅜" - 80⅞" 4
STANDARD SIZES FOR
96" BIFOLD DOORS
(INCLUDES MODELS: BI321B
AND BI321P)
FINISHED
OPENING SIZE
# OF PANELS
24" x 95 ⅞" - 96 ⅜" 2
30" x 95 ⅞" - 96 ⅜" 2
36" x 95 ⅞" - 96 ⅜" 2
48" x 95 ⅞" - 96 ⅜" 4
60" x 95 ⅞" - 96 ⅜" 4
72" x 95 ⅞" - 96 ⅜" 4
STANDARD SIZES FOR
1
80
/
" PIVOT DOORS
2
(INCLUDES MODELS: PV3330,
PV3340, PV5401 AND PV5402)
FINISHED
OPENING SIZE
# OF PANELS
24" x 80¼" - 80⅝" 2
30" x 80¼" - 80⅝" 2
36" x 80¼" - 80⅝" 2
No custom sizing available on
these models.
