Remington XR1550AU User Manual

WETech
CLOSE SHAVE

USE & CARE

MANUAL

PLEASE READ

PRIOR TO USE

To register your product go to

remington-products.com.au

remington.co.nz

2 YEAR WARRANTY

XR1550AU

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances, basic precautions should
always be observed, including the following.

READ ALL INSTRUCTIONS BEFORE USING

For additional protection, the installation of a residual current
device (rcd) having a rated residual operating current not
exceeding 30 mA is advisable in the electrical circuit supplying
the bathroom. Ask your installer for advice.

WARNING: TO REDUCE THE RISK OF BURNS, ELECTROCUTION
AND FIRE OR INJURY TO PERSONS

DANGER: As with most electrical appliances, electrical parts are
electrically live even when the switch is off.

• The appliance should never be left unattended when plugged into
a power outlet, except when charging the appliance.

• This appliance should not be used by children or other persons
with reduced physical, sensory or mental capabilities or lack
of experience and knowledge unless they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.

• Never operate this appliance if it has a damaged cord or plug,
if it is not working correctly, if it has been dropped or damaged,
or dropped into water. If the supply cord or plug of the appliance
is damaged it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard. It
cannot be repaired. Keep the cord away from heated surfaces.

• Charge, use and store the product at a temperature between 0°C
and 32°C.

• Do not use outdoors or where aerosol (spray) products are being
used, or where oxygen is being administered.

• Do not use this appliance with damaged or broken tracks, foils or
cutters, as injury may occur.

2

• For use on facial hair only. Not intended for shaving the hair on
your head.

• Do not plug or unplug the appliance with wet hands.

• For household use only.

• Do not place or store the appliance or charging adaptor where it
can fall or be knocked into a sink or bath.

• Do not place in or drop into water or any other liquid for extended
periods of time.

• If an appliance falls into water, “unplug it” immediately. Do not
reach into the water.

• Unplug the charging adaptor from the electrical outlet immediately
after fully charging.

• Unplug and switch off this appliance before cleaning it.

• Use this appliance only for its intended use as described in this
manual.

• Do not use attachments not recommended by Remington.

• Never drop or insert any object into any opening of this appliance.

• Always store the charging adaptor in a moisture-free location.

• Do not use on people who are asleep.

• Do not use an extension cord or a voltage converter with this
appliance.

• Do not wrap the cord around the appliance.

Remington strongly recommends that an approved Safety Switch
(residual current device) be installed to protect all bathroom power
outlets. Ask an electrical contractor for advice.

SAVE THESE INSTRUCTIONS

3

XR1550AU WETech CLOSE SHAVE

USE & CARE INSTRUCTION MANUAL

Thank you for purchasing your new Remington® WE Tech CLOSE SHAVE rotary

shaver. Inside this manual you will find tips on using and caring for your shaver.

2

1

6

KEY PARTS

1. On/Off Button

2. Shaving Head

3. Hairpocket

4. Neck Assembly

5. Pop Up Trimmer (not shown)

6. LED Fuel Gauge

7. Charging Pins (not shown)

3

4

5

7

Also Includes:

• Travel Friendly Charging Stand

• Head Guard

• Cleaning Brush

• Power Adaptor

4

FEATURE XR155 0AU

Power System Cordless

Initial Charge Time 24 Hours

Full Charge Time 90 Minutes

Cordless Shave Time 60 Minutes

Quick Charge Yes

Indicators LED

Voltage Type Worldwide

Charging Stand Yes

Replacement Head & Cutters Part No. SPR-XR1550AU

Power System: Cordless – shaver can only be used without the power cord. The
shaver will not run while it is charging on its charging stand.

Quick Charge: 5 minute charge supplies enough power for one shave.

Indicator: LED Fuel Gauge – indicates the amount of remaining battery power.

Voltage Type: Worldwide Voltage – shaver automatically adapts to an outlet

voltage between 100V and 240V.

NOTE: Some countries will require the use of a plug adaptor that is not included
with your shaver.

Travel Lock: To engage travel lock, press and hold the On/Off button for 3
seconds. To disengage travel lock, press and hold the On/Off button for 3 seconds.

5

CHARGING

1. Plug the power adaptor into the charging stand. (Diagram A)

2. Plug the power adaptor into wall outlet. (Diagram B)

3. Charge shaver for 24 hours before its first use. This first charge is important

to the shaver’s battery life. (Diagram C)

NOTE: During initial charge ignore the electronic indicators as they are in
“start up cycle”.

4. Use shaver until recharge is required.

A B C

CAUTION:

• Make sure the shaver and your hands are dry when charging the shaver.

• Always charge the shaver in a cool, dry place.

SHAVING

1. Press power button to turn on. (Diagram D)

2. Shave face and neck using short, circular strokes. (Diagram E)

D

3. After shaving, turn the shaver off. (Diagram D)

B

E

6

SHAVING TIPS

• The Remington® WE Tech CLOSE SHAVE is waterproof. You may use shaving

foam or gel with your shaver. You may also shave in the shower.

• Wait at least 15 minutes after getting up before shaving, to ensure your face

is free of puffiness that may be present from sleeping.

• Always hold the shaver at a right angle to the skin so that all three heads are

touching the skin with equal pressure.

• Stretch skin with the free hand so hairs stand upright, making it easier for

them to enter the cutting chamber.

• Use moderate to slow, circular stroking movement.

• The use of short, circular motions in stubborn areas may obtain a closer

shave, especially along the neck and chin line.

• Do not press hard against the skin to avoid skin irritation and/or damage to

the rotary heads.

• As with every shaver, your shave will improve over time. Allow up to four

weeks of daily shaving to develop an effective shaving style and for your skin
to adjust to the new shaver. The adaptation period my take a little longer if
your skin is sensitive, if you are switching from a different method of shaving,
or if you alternate between shaving methods.

TRIMMING

F G

Pop- up Trimmer:

1. Push trimmer release button to engage trimmer. (Diagram F )

2. Trim long, difficult hairs and side burns.

3. Close trimmer by pressing down. (Diagram G)

NOTE: Lubricate teeth with oil every 6 months.

7

Shaver Saver: Aerosol Spray Cleaner

Face Saver: Pre-shave Powder Stick

7.50

Shaving Head & Cutters for XR1550AU

$

$

Qty Amount

NZD

Price each

AUD

Price each

$11.95 AUD $14.95 NZD

SP4

SP5 $$11.95 AUD $14.95 NZD

$

$

Sub Total

$

TOTAL

handling

Postage &

Spectrum Brands Australia Pty Ltd

Locked Bag 3004

Braeside, VIC 3195

Australia

SPR-XR1550AU $49.95 AUD $54.95 NZD

Article

Replacement

Remington is a Registered Trademark

of Spectrum Brands, Inc., or one

of its subsidiaries.

CLEANING & MAINTENANCE

The shaver is a washable appliance. The head and body may be cleaned
under warm water.

NOTE: When cleaning your shaver, make sure the shaver is turned off and

disconnected from the power cord.

CAUTION:

• When cleaning the external surfaces of the shaver, do not use strong

detergents or other chemicals.

• To dry, wipe the surface of the shaver with a dry towel. Do not use a hair dryer

or heater to dry the shaver.

NOTE: The shaver head and neck assembly is designed to be detachable from the
shaver body. Simply pull upwards from the neck of the shaver for easy release.
To reattach neck, align it with the neck attachment cavity so that it clips back into
position.

1

2

3

4

1. Head & cutter (hair pocket) assembly

2. Detachment grooves

3. Neck assembly

4. Neck attachment cavity

Daily Cleaning:

1. Locate the detachment grooves on the head & cutter assembly. Gently pull to

detach the hair pocket from the neck assembly. (Diagram L)

2. Tap out excess hair shavings.

3. Rinse the head of the shaver in running water.

4. Gently reattach the hair pocket to the neck assembly until it locks in place on

all three sides. The hair pocket may be reattached in any configuration.

10

Weekly Cleaning:

Q

1. Locate the detachment grooves on the head & cutter assembly. Gently pull to

detach the hair pocket from the neck assembly. (Diagram L)

2. Tap out excess hair shavings

3. Slide the blue cutter support frame upwards towards the direction of the two

cutters to release it from the assembly. (Diagram M)

4. Lift and remove the cutter support frame away from the cutters.

5. Remove the cutters. (Diagram N)

6. Thoroughly rinse away any debris from inner and outer cutters with warm

water.

7. Replace the inner cutters. (Diagram O) The inner and outer cutters are colour

coded (grey, blue and black) to ensure each cutter is returned to its original
and most effective position on the cutter assembly.

8. Hold the cutter support frame with the raised center section facing upwards.

Place it over the cutters so that the centre mouth opening is facing the blue
cutter. Slide the cutter carrier towards the blue cutter until the locking tab
locks under the centre triangle. (Diagram P)

9. Lubricate each cutter with Remington Shaver Saver (SP4).

10. Gently reattach the hair pocket to the neck assembly until it locks in place

on all three sides. The hair pocket may be reattached in any configuration.
(Diagram Q)

L

M

N

O

P

Suitable for use in bath and shower.

This product conforms to radio frequency interference requirements.

Any product purchased and used commercially carries a limited 90 Day Warranty.

11

REPLACING THE HEAD & CUTTERS

Please refer to the FEATURE table on page 5 of this manual that lists the correct
replacement part number for your shaver.

It is very important to replace your head and cutters when necessary to ensure
a close, comfortable shave without irritation. We recommend they be replaced
every 12 months. Here are some signs of head and cutter wear, indicating that
replacement is needed:

• Irritation: As the heads get excessively worn you may experience some skin

irritation. This would be especially noticeable when you apply moisturizing
lotion.

• Pulling: When the cutters wear you may feel a sense of pulling and a loss of

closeness when you shave. This is an indication that it is time to replace your
heads and cutters.

Replacement heads & cutters may be obtained from your local retailer, or directly
from Remington
page 8 & 9, or alternatively your order can be processed over the phone via the
Remington

MONEY BACK OFFER – AUSTRALIA / NEW ZEALAND ONLY

If within 6 0 days you are not fully satisfied with your Remington® shaver, just return the shaver
with this completed coupon and a copy of your Aus tralian/New Zealand purchase receipt to
Remington
Please allow 6-8 weeks for your cheque to arrive.

Name:

Address:

City:

State: Postcode: DO B: / /

Contact No: Area Code: Ph:

Product Model number:

Is this the first Remington shaver you have owned /purchased? Yes No

Why are you returning this shaver?

Skin Irritation Shave is not close enough Prefer a rotary/foil shaver

Other:

®

. Simply fill out the enclosed accessory order form - refer to

®

Service Hotline - refer to page 14.

®

. In return, we will send you a cheque for the full purchase price of the shaver.

12

Spectrum Brands Aust ralia Pty Ltd and Spectrum Brands New Zealand Limited

WARRANTY AGAINST DEFECTS

In this warranty:

Australian Consumer Law means the Australian consumer law set out in Schedule 2 to the
Competition and C onsumer Act 2010;

CGA means the New Zealand C onsumer Guarantees Act 1993;

Goods means the product or equipment which was accompanied by this warranty and

purchased in Australia or New Zealand, as the case may be;

Manufacturer, We or us means:

1. for Goods purchased in Australia, Spectrum Brands Australia Pt y Ltd

ACN, 007 070 573; or

2. for Goods purchased in New Zealand, Spectrum Brands New Zealand Limited,

as the case may be, contact details as set out at the end of this warranty;

Supplier means the authorised distributor or retailer of the Goods that sold you the Goods
in Australia or in New Zealand; and

You means you, the original end-user purchaser of the G oods.

1. Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law, or the CGA. You are entitled to a replacement or refund for a major failure and
compensation for any other reasonably foreseeable loss or damage. You are also entitled
to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.

2. The benefits provided by this Warranty are in addition to all other rights and remedies in

respect of the Goods which the consumer has under either the Australian Consumer Law
or the CG A. The original purchaser of t he Goods is provided with the following Warranty
subject to the Warranty Conditions:

3. We warrant the Goods for all parts defective in workmanship or materials for the period of

two (2) years from the date of purchase (Warranty Period). If the Goods prove defective
within the Warrant y Period by reason of improper workmanship or material, we may, at our
own discretion, repair or replace t he Goods without charge.

Warranty Conditions

4. The G oods must be used in accordance with the manu facturer’s instructions. This Warranty

does not apply should the defect in or failure of the Goods be attributable to misuse, abuse,
accident or non-observance of manufacturer’s instructions on the part of the user. As far as
the law permits, the manufacturer does not accept liability for any direct or consequential
loss, damage or other expense caused by or arising out of any failure to use t he Goods in
accordance with the manufacturer’s instructions.

5. Exhaustible components (such as shaver heads, cutters and foils) of the Goods are included

under this Warranty only where there is a defect in workmanship or materials used.

6. The warrant y granted under clause 3 is limited to repair or replacement only.

7. Any parts of the Goods replaced during repairs or any produc t replaced remain the propert y

of the manufacturer. In the event of the Goods being replaced during the Warranty Period,
the warranty on the replacement Goods will expire on the same date as for the Warranty
Period on the original Goods which are replaced.

13

8. In order to claim under the warranty granted under clause 3 you must:

(a) Retain this warranty with your receipt/proof of purchase; and
(b) Return the Goods to us at the relevant address below or to the Supplier by prepaid
freight within the War ranty Period accompanied with (i) the legible and unmodified original
proof of purchase, which clearly indicates the name and address of the Supplier, the
date and place of purchase, the product name or other product serial number and (ii) this
warranty.

9. This warrant y is immediately void if:

(a) Any serial number or appliance plate is removed or defaced;
(b) The Go ods have been serviced or other wise repaired by a pers on not authorised to do so
by us or where non approved replaced parts are used.

10. The Goods are designed for domestic use only. A limited 90-day Warr anty applies to any

industrial or commercial use of the Goods. T he Goods must be connected to the electrical
voltage requirement s as specified in the ratings label located on the Goods.

11. This warranty does not cover the cost of claiming under the warrant y or transport of the

Goods to and from the Supplier or us.

12. This warrant y is only valid and enforceable in Australia against Spectrum Brands Australia

Pty Ltd and in New Zealand against Spectrum Brands New Zealand Limited.

Contact us or the Supplier for further details.

Spectrum Brands Australia Pty Ltd

Locked Bag 3004
Braeside, VIC 3195
AUSTRALIA
Customer service in Australia: 1800 623 118
E-mail: [e-mail]
Website: www.remington-products.com.au

Spectrum Brands New Zealand Limited

PO Box 9817
Newmarket, Auckland 1149
NEW ZEALAND
Customer service in New Zealand: 0800 736 776
E-mail: [e-mail]
Website: www.remington.co.nz

REMINGTON SERVICE HOTLINE

Aust ralia 1800 623 118 (toll free)
New Zealand 0800 736 7 76 (toll free)

®

Registered Trade Mark of Spectrum Brands, Inc., or one of its subsidiaries

Made in China to the Specifications of Spectrum Brands, Inc.

©

2018 Spectrum Brands Inc.
RE V: 03/18
PART NO: T22-700 0158
TYPE: R03A

14
