Page 1
POWER
SERIES
USE & CARE
MANUAL
PLEASE READ
PRIOR TO USE
2 YEAR WARRANTY
PR124 5AU
Page 2
IMPORTANT SAFETY INSTRUCTIONS - READ ALL INSTRUCTIONS BEFORE USING
When using electrical appliances, basic precautions should always be observed, including
the following. For additional protection, the installation of a residual current device (rcd )
having a rated residual operating current not exceeding 3 0 mA is advisable in the electrical circuit supplying the bathroom. Ask your installer for advice.
WARNING - TO REDUCE THE RISK OF BURNS, ELECTROCUTION AND FIRE OR
INJURY TO PERSONS
DANGER - As with most electrical appliances, electrical parts are electrically
live even when the switch is off.
• The appliance should never be left unattended when plugged into a power outlet, except
when charging the appliance.
• This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and k nowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
underst and the hazards involved. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without supervision.
• Never operate this appliance if it has a damaged cord or plug, if it is not working correctly,
if it has been dropped or damaged, or dropped into water. If the supply cord or plug of the
appliance is damaged it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard. I t cannot be repaired. Keep the cord away from
heated surfaces.
• Charge, use and store the product at a temperature bet ween 0°C and 32°C.
• Do not use outdoors or where aerosol (spray) products are being used, or where oxygen is
being administered.
• Do not use this appliance with damaged or broken tracks or cu tters, as injury may occur.
• Do not plug or unplug the appliance with wet hands.
• For household use only.
• Do not place or store the appliance or charging adaptor where it can fall or be knocked into a
sink or bath.
• Unplug the charging adaptor from the electrical outlet immediately after fully charging.
• Unplug and switch of f this appliance before cleaning it.
• Use this appliance only for its intended use as described in this manual.
• Do not use attachments not recommended by Remington.
• Never drop or insert any object into any opening of this appliance.
• Always store the charging adaptor in a moisture-free location.
• Do not use on people who are asleep.
• Do not charge the shaver in the shower, where water is present, or where it can be pulled
into a shower or bath while charging.
• Do not use an extension cord or a voltage converter with this appliance.
• Do not wrap the cord around the appliance.
SAVE THESE INSTRUCTIONS
2
Page 3
PR1245AU POWER SERIES WETECH
USE AND CARE MANUAL
Thank you for purchasing your new Remington® Power Series WETech Shaver. Inside this
manual you will find tips on using and caring for your shaver.
KEY PARTS
1 Pivoting head & cut ter
assembly
2 Hair pocket release
button
3 Pop-up trimmer (rear)
4 On/Off switch
5 Charging indicator light
6 Power Port (not shown)
ALSO INCLUDES
• Head Guard
• Cleaning Brush
• Storage Pouch
• Power Adaptor
1
2
3
4
5
6
ABOUT YOUR SHAVER
PR1245AU SPECIFICATIONS
Power System Cordless (Rechargeable)
Initial Charge Time 24 Hours
Full Char ge Time 4 Hours
Runtime 60 Minut es
Indicators LED Charging Indicator
Voltage Typ e (adaptor v oltage t ype) Worldwide 100-240V
Waterproof Wet/Dry
Replacement Part No. SPR-PR4AU
CHARGING
• Before using your shaver for the first time, charge it for 24 hours. Note during this charge
ignore the electronic indicators as they are in “start-up cycle”.
• Plug the adaptor into your shaver and then plug the charging adaptor unit into a domestic
power outlet. Check to ensure that the shaver is OFF. The Charging Indicator Light will glow
to indicate that it is charging and turn off when it is full.
• The batteries cannot be overcharged, bu t it is recommend that charging be discontinued and
the shaver stored away if it will not be used for an extended period of time (2-3 months).
• The shaver will be fully charged in 4 hours.
• To preserve the life of the batteries, discharge them by running the shaver until the shaver
turns of f. Do this ever y 6 months.
• Use the shaver only with the charging adaptor supplied.
3
Page 4
TIPS FOR BEST RESULTS
• Your Remington Power Series WETech shaver is waterproof. You may use shaving foam or
cream with your shaver. You may also shave in the shower.
• Always hold the shaver at a right angle to the skin so that all three heads are touching the
skin with equal pressure.
• Stretch skin with the free hand so hairs stand upright, making it easier for them to enter the
cutting chamber.
• Use moderate to slow, circular stroking movement. The use of short, circular motions in
stubborn areas may obtain a closer shave, especially along the neck and chin line.
• Do not pres s hard against the skin to avoid skin irritation and/or damage to the rotar y heads.
**We recommend that you use your new shaver daily for up to four weeks to allow time for your
hair and skin to become accustomed to the new shaving system* *
CLEANING
DA ILY
1. Open the shaver head by pressing the release button on the front of the shaver (Fig. A) and
flipping open the head away from the body of the shaver (Fig. B).
2. Tap out excess hair shavings.
3. Rinse the head of the shaver in running water.
4. Close the head assembly.
MONTHLY
• Perform cleaning steps 1 and 2.
• Hold the shaver upside down so that the open cut ter assembly is facing towards you. Slide
the blue cut ter support frame upwards towards the shaver to release it from the assembly
(Fig. C).
• Pull the cut ter support frame away from the inner cut ters ( Fig. D).
• Thoroughly brush hairs from the inner and outer cutters. Rinse out remaining debris ( Fig. E).
• Place the cutter support frame back into position and lock into place (Fig. F-G).
• Align the spring hinge into the slot at the back
WARNING
• Detach the hand-held part from the supply cord before cleaning in water.
• Shaver heads are suitable for cleaning under an open water tap.
CAUTION
• Shaver heads can be rinsed with water. The water temperature should not exceed 70
degrees. U nplug the shaver before cleaning wit h water.
• Keep the adaptor and cable dry.
TRIMMER
• Lubricate the teet h of the trimmer every six months with a drop of sewing machine oil.
4
Page 5
8 Place the trimmer at desired trim line for a quick, easy, professional trim.
9 To retract the trimmer, push down until it locks into position.
E Tips for best results
• Ensureyourskinisdry.Alwaysholdtheshaveratrightanglestotheskinso
that all three heads are touching the skin with equal pressure.
• Usemoderatetoslowstrokingmovements.Theuseofshortcircular
motions in stubborn areas may obtain a closer shave, especially along the
neck and chin line.
• DONOTpresshardagainsttheskininordertoavoiddamagetotherotary
heads.
C CARE FOR YOUR SHAVER
Care for your appliance to ensure a long lasting performance. We recommend
you clean your product after each use. The easiest and most hygienic way to
clean the appliance is by rinsing the appliance head after use with warm water.
A
B
D
E
F
I J
K
ENVIRONMENTAL PROTECTION
To avoid environmental and health problems due to hazardous substances in electrical
and electronic goods, appliances marked with this symbol must not be disposed of
with unsorted municipal waste, but recovered, reused or recycled.
BATTERY REMOVAL
DANG ER: Once the shaver has been dismantled for disposal, do not attempt to reassemble and/
or use.
• The battery mus t be removed from the appliance before it is scraped.
• The appliance must be disconnected from the supply mains when removing the battery.
• Unplug shaver from the outlet to avoid risk of elec trical shock.
• Remove the head from the shaver (Press release button and pull head straight away from the
shaver body).
• Using a small screwdriver, pry the front cover from the shaver.
• Remove the 4 screws located on the front of the shaver. (Fig. H)
• Remove rear cover from inner housing to expose batteries (Fig. I )
• Pry bat teries free from circuit board and cut wires (Fig. J – K)
• Dispose of battery properly.
H
5
Page 6
SUITABLE FOR USE IN BATH OR SHOWER.
This product conforms to radio frequency interference requirements
Any product purchased and used commercially carries a limited 90 Day Warranty.
REPLACING YOUR HEADS & CUTTERS
It is very important to replace your head and cutters when necessar y to ensure a close,
comfor table shave without irritation. We recommend they be replaced every 12 months. Here
are some signs of head and cutter wear, indicating that replacement is needed:
• Irritation: As t he heads get excessively worn you may experience some skin irritation. This
would be especially noticeable when you apply moisturizing lotion.
• Pulling: When the cutters wear you may feel a sense of pulling and a loss of closeness when
you shave. This is an indication that it is time to replace your heads and cutters.
Replacement heads & cut ters may be obtained from your local retailer, or directly from
Remington®. Simply fill out the enclosed accessory order form or alternatively your order can
be proces sed over the phone via the Remington® Service Hotline - refer to page 8.
MONEY BACK OFFER – AUSTRALIA / NEW ZEALAND ONLY
If within 6 0 days you are not fully satisfied with your Remington® shaver, just return the shaver
with this completed coupon and a copy of your Australian/New Zealand purchase receipt to
Remington®. In return, we will send you a cheque for the full purcha se price of the shaver.
Please allow 6-8 weeks for your cheque to arrive.
Name:
Address:
City:
State: Postcode:
Contact No: Area Code: Ph:
Product Model number:
Is this the first Remington shaver you have owned /purchased? Yes No
What is the reason you are returning this product?
6
Page 7
Spectrum Brands Aust ralia Pty Ltd and Spect rum Brands New Zealand Limited
WARRANTY AGAINST DEFECTS
In this warranty:
Australian Consumer Law means the Australian consumer law set out in Schedule 2 to the
Competition and C onsumer Act 2010;
CGA means the New Zealand C onsumer Guarantees Act 1993;
Goods means the product or equipment which was accompanied by this warrant y and
purchased in Austr alia or New Zealand, as the case may be;
Manufacturer, We or us means:
1. for Goods purchased in Australia, Spectrum Brands Australia P ty Ltd
ACN, 007 070 573; or
2. for Goods purchased in New Zealand, Spectrum Brands New Zealand Limited,
as the case may be, contact details as set out at the end of this warranty;
Supplier means the authorised distributor or retailer of the Goods that sold you the G oods
in Australia or in New Zealand; and
You means you, the original end-user purchaser of the Goods.
1. Our goods come with guarantees that cannot be excluded under the Aus tralian Consumer
Law, or the CGA. You are entitled to a replacement or refund for a major failure and
compensation for any other reasonably foreseeable loss or damage. You are also entitled
to have the goods repaired or replaced if the goods fail to be of acceptable qualit y and the
failure does not amount to a major failure.
2. The benefits provided by this Warranty are in addition to all other rights and remedies in
respect of the Goods which the consumer has under either the Australian Consumer Law
or the CG A. The original purchaser of the Goods is provided with the following Warranty
subject to the Warranty Conditions:
3. We warrant the Goods for all parts defective in workmanship or materials for the period of
two (2) years from the date of purchase (Warranty Period). If the Goods prove defective
within the Warrant y Period by reason of improper workmanship or material, we may, at our
own discretion, repair or replace the Goods without charge.
Warranty Conditions
4. The Goods must be used in accordance with the manufacturer’s instructions. This Warranty
does not apply should the defect in or failure of the Goods be attributable to misuse, abuse,
accident or non-observance of manufacturer’s instructions on the part of the user. As far as
the law permits, the manufacturer does not accept liability for any direct or consequential
loss, damage or other expense caused by or arising out of any failure to use the Goods in
accordance with the manufacturer’s instructions.
5. Exhaustible components (such as shaver heads, cutters and foils) of the Goods are included
under this Warrant y only where there is a defect in workmanship or materials used.
6. The warrant y granted under clause 3 is limited to repair or replacement only.
7. Any parts of the Goods replaced during repairs or any product replaced remain the proper ty
of the manufacturer. In the event of the Goods being replaced during the Warranty Period,
the warranty on the replacement Goods will expire on the same date as for the Warranty
Period on the original Goods which are replaced.
7
Page 8
8. In order to claim under the warranty granted under clause 3 you mus t:
(a) Retain this warranty with your receipt/proof of purchase; and
(b) Return the Goods to us at the relevant address below or to the Supplier by prepaid
freight within the Warranty Period accompanied with (i) t he legible and unmodified original
proof of purchase, which clearly indicates the name and address of the Supplier, the
date and place of purchase, the product name or other product serial number and (ii ) this
warranty.
9. This warrant y is immediately void if:
(a) Any serial number or appliance plate is removed or defaced;
(b) The Go ods have been serviced or other wise repaired by a person not authorised to do so
by us or where non approved replaced parts are used.
10. The Goods are designed for domestic use only. A limited 90 -day Warranty applies to any
industrial or commercial use of the Goods. The Goods must be connected to the electrical
voltage requirement s as specified in the ratings label located on the Goods.
11. This warranty does not cover the cost of claiming under the warranty or transport of the
Goods to and from the Supplier or us.
12. This warrant y is only valid and enforceable in Australia against Spectrum Brands Australia
Pty Ltd and in New Zealand against Spectrum Brands New Zealand Limited.
Contact us or the Supplier for further details.
Spectrum Brands Australia Pty Ltd
Locked Bag 3004
Braeside, VIC 3195
AUSTRALIA
Customer service in Austr alia: 1800 6 23 118
E-mail: [email protected]
Spectrum Brands New Zealand Limited
PO Box 9817
Newmarket, Auckland 1149
NEW ZEALAND
Customer service in New Zealand: 080 0 736 776
E-mail: [email protected]
Website: www.remington-products.com.au
REMINGTON SERVICE HOTLINE
Aust ralia 1800 623 118 (toll free)
New Zealand 0800 736 7 76 (toll free)
AUTHORISED REPAIR CENTRES
Visit www.remington-products.com.au for Authorised repair centre details.
® Registered Trade Mark of Spectrum Brands Inc.(SBI), or one of its subsidiaries
Made in China to the Specifications of Spectrum Brands, Inc.
© 2015 Spectrum Brands Inc.
Rev. 05 /15
Part No. T22-0003256
8
Loading...
