Rca W1162 User Manual

W1162

Windows 10

2-in-1 Tablet with detachable keyboard

User Manual

Need Help? Visit support.rcatablets.com

Safety Precautions

Equipment tested for compliance as a

W1162

complete unit

FCC Information

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be deter mined by tur ning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

EN - 1

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

• Cons u lt the deale r o r a n exp e r i enced radio/ T V

technician for help.

Warning: Changes or modifications not expressly

approved by the party responsible for compliance (MLB International Inc., PO Box 1214, Lockport, NY, 14095, Tel: 716-240-0902) could void the user’s authority to operate the equipment.

CAN ICES-3(B) / NMB-3(B)

Caution: Use of controls or adjustments or performance

of procedures other than those specified may result in hazardous radiation exposure.

Warning: the AC adapter is used as disconnect device

and it should remain readily operable during intended use. In order to disconnect the mains plug from mains completely, the AC adapter should be disconnected from the mains socket outlet completely.

Service Information

This product should be serviced only by those specially trained in appropriate servicing techniques. For instructions on how to obtain service, refer to the warranty included in this guide.

EN - 2

IMPORTANT SAFETY INSTRUCTIONS

PLEASE READ AND

SAVE THIS FOR FUTURE REFERENCE

Some of the following information may not apply to your particular product; however, as with any electronic product, precautions should be observed during handling and use.

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

• Do n o t i n s tall n ear a ny h e at s o u rces such as

radiators, heat registers, stoves, or other apparatus (including ampliﬁers) that produce heat.

• Protect the p o w e r c o r d fro m being w alked o n

or pinched p a r t i c u l a r l y at p l u g s , convenience receptacles, and the point where they exit from the apparatus.

• Only use attachments / accessories specified by the

manufacturer.

• Unplug this apparatus during lightning storms or

when unused for long periods of time.

EN - 3

• Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

ADDITIONAL SAFETY INFORMATION

• The AC adapter and apparatus shall not be exposed

to dripping or splashing and no objects filled with liquids, s u c h as vases, shall b e placed on t h e apparatus.

• Always leave sufficient space around the product for

ventilation. Do not place product in or on a bed, rug, in a bookcase or cabinet that may prevent air flow through vent openings.

• Do not place lighted candles, cigarettes, cigars, etc.

on the product.

• Care should be taken so that objects do not fall into the

product.

• Do not attempt to disassemble the cabinet. This product

does not contain customer serviceable components.

• To prevent the risk of fire or electric shock, do not

expose this apparatus to rain or moisture.

• Do not play your headset at high volume. Hearing

experts warn against extended high-volume play.

EN - 4

Contents

Safety Precautions .....................................................1

Important Safety Instructions ................................... 3

Startup ..................................................................... 6

Overview of Controls ........................................................ 6

Buttons ........................................................................ 7

Keyboard ................................................................ 8

Accessory ................................................................... 9

Connections ............................................................. 10

Battery Management and Charging ............................... 10

USB ..............................................................................12

Micro SD ........................................................................12

HDMI .............................................................................. 13

Headphone ..................................................................... 13

Using your Tablet ....................................................... 14

Turning your Tablet on ....................................................... 14

Turning your Tablet off ...................................................... 15

Using the Touchscreen...................................................... 16

Windows Start Screen ............................................... 19

Action Center .................................................................. 22

Tablet Mode Screen .......................................................... 25

Customizing Apps ............................................................ 27

Connecting to a Wi-Fi Network ............................... 28

Bluetooth ............................................................ 29

Synchronizing your Tablet .................................................. 29

Recovery your Tablet ......................................................... 30

Additional Information ............................................ 31

Trouble Shooting .............................................................. 31

Specifications .................................................................. 33

Limited Warranty ..................................................... 34

EN - 5

Startup

Overview of Controls

Front camera

MIC (microphone)

HDMI port

DC jack

Micro-USB port

Headphone jack

Power button

USB port

Windows button

Connector

RESET button

Micro SD card slot

Rear camera

EN - 6

Volume+/- button

Item Description

Microphone For voice input.

HDMI port Connect to a TV or a display device.

DC jack Connect with 5V DC charger.

Micro-USB port Use to charge the tablet's battery.

Headphone jack Headphone connection for personal

listening.

Power button Press to enter standby/wake up mode,

press and hold to switch On/Off the unit.

USB port Connect to a USB storage device or a

mouse or a wired keyboard.

Connector Use to connect the keyboard.

Reset button Press to reset the tablet.

Micro SD card slot Accepts micro SD card (up to 32G).

Volume +/- button Press to increase/decrease the volume.

Windows

button Press to open/close the Windows Start

screen.

EN - 7

Keyboard

Overview

Connector

Use to connect the tablet to keyboard.

Keys

Windows key

Press to open/close the Wi ndows Sta r t

Remove tablet from keyboard

screen.

Touch pad

EN - 8

Tablet docking

There are two ways to dock the tablet onto the keyboard.

NOTE

The keyboard connects to the tablet via the Connector. When the connection is successful:

• If the tablet is in PC mode, it will automatically adjust its

settings to use the keyboard.

• If the tablet is in Tablet mode, the message box "Do you

want to exit tablet mode?" will display on the bottom of

the screen. Choose "Yes" or "No" to proceed.

Accessory

The following accessory is included.

AC Adapter ....................................................................................................x1

EN - 9

Connections

Battery Management and Charging

The tablet has a built-in rechargeable battery.

Battery Icon

The battery icon displays in the taskbar and the Settings charm.

Battery icon

Description

Full battery

Your tablet is running on battery power and the battery is discharging.

Low battery and need to charge

Battery is charging.

Battery is fully charged and AC adapter is connected.

EN - 10

Charging the Battery

Use the AC Adapter or the Micro-USB port to charge the battery.

To USB

charger

USB cable

(not included)

To Wall Outlet

To DC jack

AC Adapter

(included)

(Micro USB port)

Note: In order to keep the battery working in best condition, please pay attention to the following:

• The included AC adapter is for use with this unit only.

Do not use it with other equipment.

• Please do not charge the battery in high temperatures.

• Do not wait for the battery to be fully depleted before

charging again. Keep the battery charged as needed.

• If tablet has not been used for a long period of time, the

battery might be in over discharge protection mode and may take longer to charge.

IMPORTANT! If your tablet’s battery contains less than 5% charge, it will not power on. Charge your tablet with the provided AC adapter for several minutes before attempting to power on again.

EN - 11
