Table of Contents
Connections and Setup
Things to consider before you connect ................... 2
Illustrations contained in this document are for representation only.
RTD2052/28/05, 10:45 AM1
1
Connections and Setup
Things to consider before you connect
• Ensure that the mains supply in your house complies with that indicated on the identification
sticker located on the back of your unit.
• Install your unit horizontally, away from any source of heat (fireplace) or appliances creating
st
rong magnetic or electric fields. The components of this unit are sensitive to heat. The
maximum ambient tempe
• Leave enough space around the unit to allow adequate ventilation: 10 cm on either side and
above the top, and 5 cm at the
• The humidity of the room should not exceed 75%. If you have to use the unit outdoors, do
not expose it to
rain or splashing water. The apparatus should not be exposed to dripping or
splashing and no objects filled with liquids, such as vases, should be placed on the appa
• Moving the unit from a cold place to a warm one can cause condensation on some
components inside the unit. Let the condensation disappear on its own befo
unit on again.
• Before moving the player, make sure the disc tray is empty.
Other important use and cleaning information at the end of the booklet.
Accessories provided
Remote control and 2
F
F
O
N
O
D
C
•
D
V
D
U
T
L
O
V
non-
H
C
N
U
N
E
M
E
K
E
F
O
O
W
B
U
S
E
D
I
U
G
•
E
L
T
I
T
L
E
O
F
N
I
2
5
4
G
I
N
8
E
7
L
-
/
0
T
U
P
Y
A
L
P
E
S
R
E
V
E
R
O
T
S
M
O
O
Z
D
R
O
C
E
R
E
D
O
M
Y
A
E
L
K
P
A
W
•
K
C
O
L
C
rechargeable AAA
batteries
R
3
6
D
9
V
D
T
H
O
I
D
U
A
D
R
A
W
R
O
F
E
S
U
AP
P
1
X
U
A
E
L
B
A
C
•
T
2
A
X
S
U
A
R
C
V
+
-
V
T
R
E
N
K
C
A
B
O
G
R
U
T
E
R
E
T
U
M
V
A
S
R
A
E
OKO
L
C
D
N
U
O
R
R
U
S
V
E
L
.
Q
E
1
C
S
I
D
G
N
A
N
I
rature should not exceed 35° Celsius.
rear.
-
+
Left
and right
front speakers
Center
ratus.
re turning the
speaker
Subwoofer
Left and right
rear speakers
Caution!
Invisible laser radiation when open. Avoid exposure to beam. Class 1 laser product. This system
must be opened only by qualified technicians to p
DVD copy protection
In accordance with the DVD standard, your DVD player is equipped with a Copy Protection system,
which can be switched on and off by the DVD disc itself, in o
relevant DVD disc onto a videotape of very poor picture quality, or even impossible. This product
rates copyright protection technology that is protected by method claims of certain U.S.
incorpo
patents and other intellectual p
rs. Use of this copyright protection technology must be authorized by Macrovision
owne
ration, and is intended for home use only unless otherwise authorized by Macrovision
Corpo
Corpo
ration. Reverse engineering or disassembly is prohibited.
2
RTD2052/28/05, 10:45 AM2
Illustrations contained in this document are for representation only.
roperty rights owned by Macrovision Corporation and other rights
revent accidents caused by the laser beam.
rder to make any recording of the
Connections and Setup
Front panel controls
FRONT PANEL ILLUSTRATION TO COME
Open and close the disc tray.
Start playing a disc. Pause.
Stop disc playback.
DISC SKIP – Goes to the next slot in the disc tray. Above the disc skip
button indicator lights that show which disc is being played.
SOURCE - Select the input source. Above the source button are indicator
lights that show which source is active.
SUBWOOFER - Toggle between different subwoofer output levels.
SURROUND - Changes the surround sound settings. The LED lights when
Surround mode is active.
ON/STANDBY - Switch the unit on and off.
RTD2052/28/05, 10:35 AM3
3
Connections and Setup
Pr
VIDEO
Pb
Y
S-VIDEO
COMPONENT VIDEO
REGULAR AND PROG SCAN
Composite
video cable
S-VIDEO cable
Component
video cable
Connecting to audiovisual equipment
AUDIO IN
AUX 1 AUX 2
Video cables
Composite video cable (included)
The basic Video jack (usually color-coded yellow) is also referred to as composite
video. Usually the video cable is bundled with the audio cables (white and red).
S-VIDEO cable (not included)
The S-VIDEO(separate video) jack provides better picture quality than composite
video (the VIDEO jack) because the color is kept separate from the black and
white part of the video signal. If you are using S-video, you must connect the
audio jacks to get sound. If you use S-video to connect to another component,
you must choose the S-Video option in the Video menu (see page 20).
Component video cables Pr, Pb, Y) (not included)
The Pr, Pb, Y jacks provide optimum picture quality by separating the video signal
into three parts. To ensure maximum picture quality, use three video-grade cables
(yellow) for the connection. You can also buy bundled component video cables
that are color-coded to match the Y, Pb, Pr inputs (green, blue and red). If you
use component video to connect to another component, you must choose the
Component option in the Video menu (see page 20).
Note: If your television is a high definition television, use the DVD player’s progressive scan
output to get the highest possible video resolution. Set the Progressive Scan option in the
Display menu to On (see page 20).
Note: If one of the devices is not working, check that all the cables have been inserted
properly into the jacks.
Explanation of jacks and cables
The jacks on the back of your receiver (pictured left) and the
cables shown below are used to connect to other components.
The video jacks are OUT jacks, which need to be connected to
IN jacks on the TV or monitor you’re connecting to (so the
video content goes from the receiver to the screen). The audio
jacks are IN jacks, which need to be connected to OUT jacks on
the component you’re connecting to, so the sound from the
component comes into the receiver (and out through the
speakers).
Audio cables (not included)
AUDIO L (left) and R (right)
These jacks and cables are often color-coded (red for right audio, and white for
left audio). You must connect audio cables to the AUDIO L and R jacks if you are
using S-video.
Audio cables
(red and white)
Note: If your component has only one input for audio (mono), connect it to the left (white L/
Mono) audio jack on the TV and don’t connect the right audio part of the cable.
4
RTD2052/28/05, 10:35 AM4
Connections and Setup
Connecting the speakers
Six speakers are provided with the unit (2 front, 1
cente
r, 2 rear, 1 subwoofer). To achieve good
round effects, all six speakers need to be
sur
connected
One speaker
Speaker wi
FR FLSR SLCENSUB
terminals.
Connect the speaker wi
speaker
back of the unit. P
terminal
lock wi
speake
to the receiver.
wire is attached with each speaker.
res are color-coded to match the
re from the back of each
to the corresponding color terminal at the
ress down the tab to open the
and insert the wire (1). Release the tab to
re in the terminal (2). Do the same for center
r, rear speakers and the subwoofer.
Note: When connecting the speakers, make sure the
polarities (“+” speaker wire to “+” on the receiver) of
speaker wires and terminals match. If the cords are
reversed, the sound will be distorted. Do not ground the
output line, it will damage the speaker.
(1)
3
(2)
Positioning speakers
1
1
Left, Right (Front Speakers)
Front speakers carry primarily music and sound effects.
2
2
1
3
Courtesy Dolby Laboratories
Center
In sur
round mode, the center speaker carries most of the
dialog as well as music and effects. It should be set
the left and right speake
3
round (Rear Speakers)
Sur
rear speakers’ overall sound balance should be as close
The
as possible
to the front speakers. Proper placement is vital to
rs.
between
establish an evenly distributed sound field.
Subwoofer
A subwoofer is designed to reproduce powerful low bass
effects (explosions, the rumble of spaceships, etc.) which
dramatically heighten the action on the screen.
RTD2052/28/05, 10:35 AM5
5
Connections and Setup
Magnetic shielding
Speakers placed less than two feet from the TV set must be magnetically shielded in order to
prevent picture distortion. Front and center speakers provided with this unit are magnetically
shielded to protect your TV set.
Note: It is not recommended to place the rear speakers and subwoofer near the TV set.
Front speaker placement
Follow the suggestions for speaker placement below to get the
best results.
Alignment
Align the center speaker evenly with (A) or slightly behind (B) (the
Courtesy Dolby Laboratories
Courtesy Dolby Laboratories
left and right speakers), but not ahead of them.
Angle
Place the left and right speakers to form a 45-degree angle with
your favorite viewing position to duplicate the soundtrack mixer’s
perspective.
Height
The mid- and high-frequency drivers of the three front speakers
should be as close as possible to the same height. This often
requires placing the center speaker directly on top (A) or beneath
(B) the TV set.
Preferred surround placement
Location
If possible, place surround speakers to either side of the
listening area, not behind it.
Height
If space permits, install surround speakers 2-3 feet above
viewers. This helps to minimize localization effects.
Aiming
Aim surround speakers straight across the room, not down
at viewers, to help create a more open, spacious surround
sound field.
Alternative Surround Placement
Rear wall
If rear wall mounting is the only choice, aim the speakers
at each other (A), towards the front (B) or towards the
sidewalls (C, D). Experiment with placement until sounds
seem to surround you, rather than come from behind you.
6
RTD2052/28/05, 10:35 AM6
Connections and Setup
No adjacent walls
Surround speakers can go on stands facing each other to
approximate sidewall mounting (A), or to the sides or rear of
the viewing area, aimed upwards; they can go right on the
floor, or preferably, a few feet off the floor such as on end
tables (B).
Test tone/Channel balance
Channel balance
Your receiver is equipped with a test signal generator for
balancing the channels. As the signal “travels” from channel
to channel, adjust the level controls until each channel plays
at the same loudness level (see page 21).
Level adjustment and surround channel level expectation
Even though you adjust the surround channel to be as loud
as the others on the test signal, on actual program material
the surround channel is usually much lower than the front.
Don’t re-adjust the surround level; program producers use
surround for subtle atmospherics and ambience, and only
rarely for special effects.
RTD2052/28/05, 10:35 AM7
7
Loading...
+ 21 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
