RCA RCD152 User Manual

v1.0 (EN/E)

user manual

manual de usuario

RCD152

P

EN/E

It is important to read this instruction prior to using your new product for the first time.
Es importante leer este manual antes de usar por vez primera su euipo.

FCC information

This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device
must accept any interference received,
including interference that may cause
undesired operation.

This device generates and uses radio
frequency (RF) energy, and if not installed
and used properly, this equipment may
cause interference to radio and television
reception.

If this equipment does cause interference to
radio or television reception (which you can
determine by unplugging the unit), try to
correct the interference by one or more of
the following measures:

• Re-orient the receiving antenna (that is,
the antenna for the radio or television
that is “receiving” the interference).

•Move the unit away from the equipment
that is receiving interference.

• Plug the unit into a different wall outlet
so that the unit and the equipment
receiving interference are on different
branch circuits.

In accordance with FCC requirements,
changes or modifications not expressly
approved by Thomson Inc. could void the
user’s authority to operate this product.

This product complies with DHHS Rules 21
CFR subchapter J. Applicable at the date of
manufacture.

For your records

In the event that service should be required,
you may need the model number and the
serial number. In the space below, record the
date and place of purchase and the serial
number:
Model No.:
Date of Purchase:
Place of Purchase:
Serial No.:

CAUTION

RISK OF ELECTRIC SHOCK

THE LIGHTNING
FLASH AND ARROW­HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
"DANGEROUS
VOLTAGE" INSIDE
THE PRODUCT.

WARNING:

SHOCK HAZARD,

TO RAIN OR MOISTURE.

DO NOT OPEN

CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USER­SERVICEABLE PARTS IN­SIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.

SEE MARKING ON BOTTOM / BACK OF PRODUCT

TO PREVENT FIRE

DO NOT EXPOSE THIS PR ODUCT

THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.

OR ELECTRICAL

AUDIO AND COMMUNICATIONS DIVISION PLEASE READ AND SAVE THIS FOR FUTURE REFERENCE

IMPORTANT SAFETY INSTRUCTIONS

Some of the following information may not
apply to your particular product; however, as
with any electronic product, precautions
should be observed during handling and
use.

• Before using the product, please follow
and adhere to all warnings, safety and
operating instructions located on the
product and in the user book. Save all
instructions for future reference.

• Do not expose product to rain and do
not use near water; such as, sink, wet
basement, swimming pools, etc.

• Always leave sufficient space around the
product for ventilation. Do not place
product in or on a bed, rug, bookcase or
cabinet that may prevent air flow
through vent openings.

• Do not expose product to extreme
temperatures such as found near a hot
radiator or stove, or in a car parked in
the Summer sun.

• Connect power cord only to AC power
source as marked on the product.

• Some products employ a polarized AC
line plug (one blade is wider). This is a
safety feature. The plug will go in the
power outlet only one way. If the plug
doesn’t go into the outlet completely,
turn the plug over and put it in the other
way. If it still doesn’t fit, contact a
qualified electrician to change the outlet.
Do not defeat the safety purpose of the
polarized plug.

• Route power cord to prevent it from
being pinched, or walked on, or melted
by a hot stove or radiator.

•To clean cabinet, unplug AC power cord,
then use a soft cloth dampened only
with water.

• Do not place lighted candles, cigarettes,
cigars, etc. on the product.

• Unplug AC power cord from outlet
during a lightning storm or when
product is left unused for a long period
of time to prevent damage due to
lightning or power line surges.

• Care should be taken so that objects do
not fall and liquids do not spill into the
product.

• Never add accessories that the product
has not been designed to accommodate.

• Use only the manufacturer’s approved
mounting instructions and hardware
when installing product.

• Do not attempt to disassemble the
cabinet. This product does not contain
customer serviceable components.

• Do not handle the unit or power cord
when your hands are wet or damp.

• Carts and Stands — The
appliance should be used
only with a cart or stand
that is recommended by
the manufacturer.

• An appliance and cart combination
should be moved with care. Quick stops,
excessive force, and uneven surfaces may
cause the appliance and cart
combination to overturn.

• Damage Requiring Service–This product
should be serviced by qualified service
personnel when:
A. The power supply cord or the plug has
been damaged; or

B. Objects have fallen, or liquid has been
spilled into the product; or
C. The product has been exposed to rain;
or
D. The product does not appear to
operate normally or exhibits a marked
change in performance; or
E. The product has been dropped, or the
cabinet damaged.

• When service or repairs are completed,
ask the service technician to perform the
safety check described in the service
manual and to confirm that replacement
parts have the same safety characteristics
as the original parts.

• Overloading – Do not overload the wall
outlets, extension cords or integral
convenience receptacles as this can result
in a risk of fire or electric shock.

• IF YOUR PRODUCT OPERATES ON
BATTERIES, adhere to the following
precautions:
A. Any battery may leak electrolyte if
mixed with a different battery type, if
inserted incorrectly, or if all batteries are
not replaced at the same time.
B. Any battery may leak electrolyte or
explode if disposed of in fire or an
attempt is made to charge a battery not
intended to be recharged.
C. Discard leaky batteries immediately.
Leaking batteries can cause skin burns or
other personal injury.When discarding
batteries, be sure to dispose of them in
the proper manner, according to
provincial and local regulations.

• IF YOUR PRODUCT IS EQUIPPED WITH
ANTENNA TERMINALS, and if an
outdoor antenna is connected, be sure
the system is grounded so as to provide
some protection against voltage surge
and built-up static charges. An outdoor
antenna should be locate away from
power lines.

• IF PRODUCT IS TO BE CONNECTED TO
A CATV SYSTEM, call the CATV system
installer’s attention to Article 820-40 of
the NEC that provides guidelines for
proper grounding and, in particular,
specifies that the cable ground shall be
connected to the grounding system of
the building, as close to the point of
cable entry as practical.

Important information

Service information

This product should be serviced only by those
specially trained in appropriate servicing
techniques. For instructions on how to obtain
service, refer to the warranty included in this
Guide.

Technical information

Product: Portable CD radio
Brand: RCA
Model: RCD152
Power Supply: 120V ~ 60Hz
Power Consumption: 15 Watts

IMPORTER
Comercializadora Thomson de México, S.A.
de C.V.
Álvaro Obregón No. 151. Piso 13.
Col. Roma. Delegación Cuauhtémoc
C.P. 06700. México, D.F.
Telefono: 52-55-11-020360
RFC: CTM-980723-KS5

EXPORTER
Thomson Inc.
P.O. Box 1976
Indianapolis, IN 46206 - 1976
©2007 Thomson Inc.
Trademark(s) ® Registered
Marque(s) ® Deposée(s)
Marca(s) ® Registrada(s)
www.rcaaudiovideo.com
Printed in China / Impreso en China

Precautions

• This compact disc player uses a laser to
read the music on the disc. The laser
mechanism corresponds to the cartridge
and stylus of a record player. Although
this product incorporates a laser pick-up
lens, it is completely safe when operated
according to directions.

• Discs rotate at high speed inside the
player. Do not use damaged, warped, or
cracked discs.

• Do not touch the pick-up lens which is
located inside the disc compartment. To
keep dust from collecting on the pick-up
lens, do not leave the compartment door
open for an extended period of time. If
the lens becomes dirty, clean it with a
soft brush, or use an air blower brush
designed for camera lenses.

Don’t infringe

This product should only be used for the
purposes for which it is sold, that is,
entertainment, violating no copyright law.
Any attempts to use this product for
unintended purposes are unlawful and
therefore not condoned by Thomson.

Before you begin

AC power

Plug the power supply cord into the AC
power jack on the back of the unit, and into
an AC power supply outlet that accepts the
plug supplied with your unit.

Battery power

You can insert 6 D-sized alkaline batteries
(not supplied) and you can take your stereo
just about anywhere. Open the battery
compartment door on the back of the unit
by pressing down on the arrow and pulling
out the cover. Insert batteries in the battery
compartment. Three AA-sized batteries (not
supplied) are needed to keep radio station
memory.

Note that the AC line cord must be
unplugged from the jack on the back of
the unit to operate on batteries.

Important battery
information

• Remove the batteries to avoid leakage if
you do not use your system for more
than one month.

• Discard leaky batteries immediately as
leaking batteries may cause skin burns or
other personal injuries. Dispose of
batteries in the proper manner,
according to provincial and local
regulations.

• Any battery may leak electrolyte under
the following circumstances:

- if mixed with a different battery type,

- if inserted incorrectly,

- if all batteries are not replaced at the
same time,

CD player

CD-R / RW

Notes on CD-R/RW

• Do not affix any type of

•To avoid damages to the CD-R/RW

• Do not load an unrecorded CD-R/RW

• Playback capability for CD-RW discs

Selecting CD mode

When the unit is turned off, press
ON/STANDBY (or FUNCTION/STANDBY on
the remote control) three times to enter CD
mode.

This unit is compatible
with audio CD-R/RW
discs.

labels to either side
(recordable or labeled side) of a CD-R/
RW disc as this may result in the unit
malfunctioning.

disc, do not open the disc
compartment door while the disc is
being read.

disc into the unit. This may take a
longer time to read the disc.

may vary due to variations in the
quality of the CD-RW disc and the
recorder used to create the disc.

- if disposed of in fire, or

- if an attempt is made to charge a
battery not intended to be recharged

• Be sure to remove batteries when storing
the set for more than 30 days. Leaky
batteries can badly damage the system.
Be sure to dispose of leaky, weak or dead
batteries properly according to federal,
state, and local regulations. To prevent
injury or damage, do not reverse
batteries and do not mix battery type.

Headset safety

• Have a Blast – Just Not in
your eardrums!
Make sure you turn down
the volume on the unit
before you put on headphones. Increase
the volume to the desired level only after
headphone are in place.

• Do not play your headset at high volume.
Hearing experts warn against extended
high-volume play.

• If you experience ringing in your ears,
reduce volume or discontinue use.

•You should use with extreme caution or
temporarily discontinue use in
potentially hazardous situations.

• Even if your headset is an open-air
designed to let you to hear outside
sounds, do not turn up the volume so
high that you are unable to hear what is
around you.

Loading disc

1. Press the CD OPEN button to slide disc
tray out.

2. Place a disc on the disc tray with the
label side facing up.

3. Push the disc tray back in.

The total number of tracks on the disc can
be read from display.

Play and pause

1. In stop mode, press PLAY/PAUSE to
begin CD playback.

2. During CD playback, press PLAY/PAUSE

to pause playback. Press again to

resume.

Skip and search

1. Press TRACK/TUNE / to skip to the
previous or next track respectively.

2. Press and hold TRACK/TUNE / to
search quickly current track backward or
forward respectively.

Stop playback

Press STOP to stop playback.

CD remain

Press REMAIN to select between showing
disc remain time and track elapse time. This
function is not available during CD program
playback.

General controls

Main unit

P

ON/STANDBY (RADIO/TAPE/CD) To turn
the unit on/ off, to select among radio, tape
and CD mode.

STANDBY (OFF) > RADIO > TAPE > CD

BAND To select the radio band.
EQ To select among sound effects (Flat /

Rock / Jazz / Pop / Classic).
DBBS To turn the digital bass boost system
on and off.
VOLUME + / – To increase or decrease the
output volume.

To connect the headphone.
PLAY MODE / P In radio mode, to access

the preset radio channels.
In CD mode, to select among the playback
modes (repeat 1 / repeat all / random ).
SET In radio mode, to set the radio preset
channels.
In CD mode, to enter the program mode.

Programming

1. In stop mode, press SET to enter
program setting mode.
The program location shows briefly and
then the track number and program icon
flash on the display.

2. Press TRACK/TUNE / to select the
track you want to program.

3. Press SET again to confirm your selection
and access the next program location.

4. Repeat steps 2 to 3 to program to a
maximum of 20 tracks.

5. Press PLAY/PAUSE in program mode
to start program playback (PROGRAM
indicator lights on the display).
Press STOP to return to normal
playback mode and the program will not
be saved.

Displaying the Program List
Press SET repeatedly to show program list.

Exit Program Mode

Program mode will be deactivated once you
press STOP to end program playback.

Clearing program list

Your program will be erased once you open
the disc compartment door or change to
another source mode (e.g. radio).

If you are in normal playback
mode but want to play the
saved program, press STOP,
then SET and then PLAY/PAUSE.

II

TRACK / TUNE / In radio mode, to
tune up or down the radio frequency.
In CD mode, to search/skip CD track
backward or forward.

STOP To stop CD playback.
REMAIN In CD mode, to select between

displaying track elapse time and CD remain
time.
PLAY / PAUSE To start or pause CD
playback.

CD OPEN To open the CD door.
CLOSE Push to close the CD door.

Cassette Player

REC To start the tape recording.
PLAY To start the tape playback.
REW To rewind the tape.
FWD To fast forward the tape.
STOP/EJECT To stop the tape playback,

winding or recording, to open the cassette
door.
PAUSE To pause the tape playback.

Play mode

Press PLAY MODE to select among
playback mode (repeat 1 / repeat all /
random ). Selection made is indicated
by icons on the display.

General controls

Remote control

REMAIN In CD mode - Selects between
displaying track elapse time and CD remain
time.
SET In radio mode, to set the radio preset
channels.
In CD mode, to enter the program mode.
VOL + / – To increase or decrease the output
volume.

MUTE To mute the audio output.
BAND To select the radio band.
DBBS To turn the digital bass boost system

on and off.
EQUALIZER SOUND To select among the
sound effects (Flat / Rock / Jazz / Pop /
Classic).
PLAY MODE / PRESET UP In radio mode,
to access the preset radio stations.
In CD mode, to select among the playback
modes (repeat 1 / repeat all / random ).

FUNCTION/
STANDBY To turn

the unit on/ off, to
select among radio,
tape and CD mode.

CD TRACK/TUNE
BACK /FWD

In radio mode, to
tune up or down the
radio frequency.
In CD mode, to
search/skip CD track
backward or forward.
PLAY / PAUSE To
start or pause the CD
playback.
CD STOP To stop
the CD playback.

Troubleshooting tipsCD player

System doesn’t turn on

• Unplug the unit for a moment, and then
plug it back in.

• Check the outlet by plugging in another
device

No sound

• Adjust volume setting.

• Make sure you’ve selected the correct
function

• Make sure headphones are not plugged
in.

Poor radio reception

• Adjust the antenna for better reception

•Try turning off electrical appliances near
the unit, such as hair dryers, vacuum
cleaners, or fluorescent lights

Maintenance

Cleaning the exterior

• Disconnect the system from AC power
before cleaning the exterior of the unit
with a soft dust cloth.

• Clean the exterior with a soft clean cloth
or slightly moistened chamois leather.
DO NOT use solvents as it may cause
damage to the unit.

• Cassette functions cannot be operated
with the remote control.

• The remote control must be inserted
with 2 “AAA” or “UM-4” or “R03”
batteries prior to use.

Display

34

2

1

78

1. Selected sound effect

2. Sound is muted

3. Program mode activated

4. Playback modes

5. Digital bass boost system activated

6. Radio frequency unit

7. Shows volume level, track number,
playback time, program location or radio
frequency

8. Radio band

CD doesn’t play

• Make sure you’ve put a CD in the tray

• Make sure the CD’s label is facing up

•Try another CD

• Make sure that Pause mode is not
activated

• Make sure CD function is selected

CD sound skips

• Clean the CD (as explained in
“Maintenance”)

• Check CD for warping, scratches, or other
damage

ESD remark:

In case of misfunction due to electrostatic
discharge just reset the product (disconnect
and reconnect of the power source may be
required) to resume normal operation.

Handling CDs

• Do not touch the signal surfaces. Hold
CDs by the edges, or by one edge and the
hole.

• Do not affix labels or adhesive tapes to
the label surfaces. Do not scratch or
damage the label.

• CDs rotate at high speeds inside the

5

6

Radio Tape player

Select radio mode

When the unit is turned off, press
ON/STANDBY (or FUNCTION/STANDBY on
the remote control) once to select radio
mode.

Select Radio Band

Press BAND to select between FM and AM
band.

Tuning to a station

• Press TRACK/TUNE to tune down the
radio frequency.

• Press TRACK/TUNE to tune up the
radio frequency.

• Press and hold TRACK/TUNE or

for 2 seconds and then release the
button to automatically tune to the next
station.

Extend or reposition the
antenna for better FM
reception. Rotate the unit for
better AM reception.

Maintenance

player. Do not use damaged (cracked or
warped) CDs.

• Make sure CDs are stored in their
original case after use. Keep them away
from damp, humid or abnormally heated
places.

Cleaning CDs

• Dirty CDs can cause poor sound quality.
Always keep CDs clean by wiping them
gently with a soft cloth from the inner
edge toward the outer perimeter.

• If a CD becomes dirty, wet a soft cloth in
water, wring it out well, wipe the dirt
away gently, and then remove any water
drops with a dry cloth.

• Do not use record cleaning sprays or
antistatic agents on CDs. Also, never
clean CDs with benzene, thinner, or
other volatile solvents which may cause
damage to disc surface.

CD Lens Care

• When your CD lens gets dirty it can also
cause the system to output poor sound
quality. To clean the lens you will need to
purchase a CD lens cleaner which can
maintain the output sound quality of
your system. For instructions on cleaning
the CD lens, refer to the ones
accompanying the lens cleaner.

Cassettes

•To protect your recordings from
accidental erasure on one or both sides
of your cassette, snap out the tab at the

Setting preset stations
manually

There are 10 preset locations for FM band
and 10 preset location for AM band on this
unit.

1. In radio mode, press BAND to select the
radio band.

2. Press TRACK/TUNE or to select the
station to save as a preset station.

3. Press SET. The Program icon flashes.

4. Press P repeatedly to assign the preset
station number.

5. Press SET to confirm. Program icon stops
flashing.

6. Repeat steps 2 to 5 to set additional
preset stations.

Using presets

1. Press BAND to select between bands.

2. Press P repeatedly to access the
desired preset stations.

top of the cassette. If you decide later to
record on the tape, seal the hole with a
piece of adhesive tape. (Refer to
diagram)

• Quit Slacking - A little bit of
slack in your tapes can cause
scratches on the tape, or
worse yet, the tape could
break. If you notice some
slack in the tape, use a pencil to tighten
it up before you insert it.

Technical Specification

Power supply: 120V~60Hz
Dimensions ( H x W x D inches):
Unit size - 6.8 x 15 x 10.2
Weight: 7.5 lb
CD player: Response curve (+/- 2dB):
60Hz to 20 kHz
Rating Plate: Look for it at the bottom of the
set.

The descriptions and characteristics in this owner’s
manual are for the purpose of general reference only
and not as a guarantee. In order to provide you with
the highest quality product, we may make changes or
modifications without prior notice. The English
version serves as the final reference on all product
and operational details should any discrepancies arise
in other languages.

A

A

A

6
0

A

A

Playing a tape

1. When the unit is off, press ON/STANDBY
(or FUNCTION/STANDBY on the remote
control) twice until TAPE mode is
selected. The tape indicator “tAPE” lights
on the display.

2. Press STOP/EJECT to open the tape deck
door.

3. Insert a tape into the door and push the
door closed.

• Be sure to slide the cassette into the tape
slot on the door. Do not place the tape
directly onto the tape mechanism.

4. Press REW or FWD to wind the tape to
the desired starting position. Press STOP/
EJECT to stop winding.

5. Press PLAY to start playback.
Press PAUSE to pause playback (press
again to release the button to resume
playback).
Press STOP/EJECT to stop playback.

U.S. Limited Warranty

What your warranty covers:

• Defects in materials or workmanship.

For how long after your purchase:

• One year from date of purchase.
The warranty period for rental units begins
with the first rental or 45 days from date of
shipment to the rental firm, whichever
comes first.

What we will do:

•Provide you with a new, or at our option, a
refurbished unit. The exchange unit is under
warranty for the remainder of the original
product’s warranty period.

•Proof of purchase in the form of a bill of
sale or receipted invoice which is evidence
that the product is within the warranty
period must be presented to obtain
warranty service. For rental firms, proof of
first rental is also required.

How to make a warranty claim:

•Properly pack your unit. Include any cables,
etc., which were originally provided with
the product. We recommend using the
original carton and packing materials.

•Include evidence of purchase date such as
the bill of sale. Also print your name and
address and a description of the defect.
Send via standard UPS or its equivalent to:
Thomson Inc.

Product Exchange Center, 11721 B
Alameda Avenue, Socorro, Texas 79927

•Insure your shipment for loss or damage.
Thomson accepts no liability in case of
damage or loss en route to Thomson.

• Pay any charges billed to you by the
Exchange Center for service not covered by
the warranty.

•A new or refurbished unit will be shipped to
you freight prepaid.

What your warranty does not cover:

• Customer instruction. (Your Owner’s Manual
provides information regarding operating
Instructions and user controls. For
additional information, ask your dealer.)

•Installation and set-up service adjustments.

• Batteries.

• Damage from misuse or neglect.

•Products which have been modified or
incorporated into other products.

•Products purchased or serviced outside the
USA.

• Acts of nature, such as but not limited to
lightning damage.

Recording to tape

From radio

1. Insert a tape into the deck.

2. Press ON/STANDBY (or FUNCTION/
STANDBY on the remote control) until
RADIO mode is selected.

3. Press BAND to access the desired radio
band.

4. Press TRACK/TUNE or to tune to
the station to be recorded.

5. Press REC and PLAY together to begin
recording.

6. Press PAUSE or STOP to pause or stop
the recording respectively.

From CD

1. Insert a tape into the deck.

2. Press ON/STANDBY (or FUNCTION/
STANDBY on the remote control) until
CD mode is selected.

3. Insert the disc to be recorded.

4. Select the track or program to be
recorded.

5. Press REC and PLAY together to begin
recording.

6. Play the track or program to be recorded.

7. Press PAUSE or STOP to pause or stop
recording respectively.

For better recording quality,
use normal bias tape (Type I)
only.

Product Registration:

•Please complete and mail the Product
registration Card packed with your unit. It
will make it easier to contact you should it
ever be necessary. The return of the card is
not required for warranty coverage.

Limitation of Warranty:

• THE WARRANTY STATED ABOVE IS THE ONLY
WARRANTY APPLICABLE TO THIS PRODUCT.
ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED (INCLUDING ALL IMPLIED
WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE) ARE
HEREBY DISCLAIMED. NO VERBAL OR
WRITTEN INFORMATION GIVEN BY
THOMSON INC., ITS AGENTS OR EMPLOYEES
SHALL CREATE A GUARANTY OR IN ANY
WAY INCREASE THE SCOPE OF THIS
WARRANTY.

• REPAIR OR REPLACEMENT AS PROVIDED
UNDER THIS WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CONSUMER. THOMSON
INC. SHALL NOT BE LIABLE FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES RESULTING
FROM THE USE OF THIS PRODUCT OR
ARISING OUT OF ANY BREACH OF ANY
EXPRESS OR IMPLIED WARRANTY ON THIS
PRODUCT. THIS DISCLAIMER OF
WARRANTIES AND LIMITED WARRANTY ARE
GOVERNED BY THE LAWS OF THE STATE OF
INDIANA. EXCEPT TO THE EXTENT
PROHIBITED BY APPLICABLE LAW, ANY
IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE ON
THIS PRODUCT IS LIMITED TO THE
APPLICABLE WARRANTY PERIOD SET FORTH
ABOVE.

How state law relates to this warranty:

• Some states do not allow the exclusion nor
limitation of incidental or consequential
damages, or limitations on how long an
implied warranty lasts, so the above
limitations or exclusions may not apply to
you.

• This warranty gives you specific legal rights,
and you also may have other rights that vary
from state to state.

If you purchased your product outside the
USA:

• This warranty does not apply. Contact your

dealer for warranty information.
