Page 1

digital video disc player

the ultimate movie experience!

user's manual

RC5210P

RC5200P

Page 2

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates “dangerous voltage” inside the product that presents a risk of electric shock or personal injury.

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USERSERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol indicates important instructions accompanying the product.

WARNING

To reduce the risk of fire or shock hazard, do not expose this DVD player to rain or moisture.

CAUTION

CAUTION: DVD PLAYERS USE A VISIBLE LASER BEAM WHICH COULD

CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE PLAYER CORRECTLY AS INSTRUCTED.

CAUTIONS

Caution: To prevent electric shock, match wide blade of plug to wide

slot, fully insert. Attention: Pour éviter les chocs électriques, introduire la lame la

plus large de la fiche dans la borne correspondante de la prise et pousser jusqú au fond.

This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To prevent electromagnetic interference with electric appliances, such as radios and televisions, use shielded cables and connectors for connections.

FCC NOTE (for U.S.A.):

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures.

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect this equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This class B digital apparatus meets all requirements of the Canadian Interference--Causing Equipment Regulations.

THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

Note:

This unit can be used only where the power supply is AC 120 V, 50-60Hz. It cannot be used elsewhere.

Note:

This DVD player is designed and manufactured to respond to the Region Management Information. If the Region number of a DVD disc does not correspond to the Region number of this DVD player, this DVD player cannot play the disc. The Region number for this DVD player is Region No 1.

Note:

This device is protected by U.S. patent numbers 4,631,603 and 4,577,216 and 4,819,098 and other intellectual property rights. The use of Macrovision’s copy protection technology in the device must be authorized by Macrovision and is intended for home and other limited pay-per-view uses only, unless otherwise authorized in writing by Macrovision. Reverse engineering or disassembly is prohibited.

Product Registration

Please fill out the product registration card and return it immediately. Returning this card allows us to contact you if needed.

Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model numbers in case you need them. The numbers are located on the back of the player.

Model No.____________________________________________________ Serial No. ____________________________________________________ Purchase Date: ______________________________________________ Dealer/Address/Phone: _________________________________________

_____________________________________________________

RC5210P

CLASS 1 LASER PRODUCT

Page 3

Setup and Connections ....................................................................3

Unpack the Box ...............................................................................................................4

Types of Discs That the Player Can Play ..................................................................5

Prepare to Connect the DVD Player..........................................................................5

Types of Jacks and Cables ........................................................................................ 6

Choosing a Connection ................................................................................................7

DVD Player + TV without A/V Input Jacks ..........................................................8

DVD Player + TV with A/V Input Jacks.................................................................9

DVD Player + TV + Dolby Digital Receiver ...................................................... 10

DVD Player + TV + VCR...........................................................................................11

Setting Up the Menu Language.............................................................................. 12

Playing DVDs .................................................................................... 13

Loading and Playing a DVD ...................................................................................... 14

Using a DVD’s Disc Menu .......................................................................................... 15

DVD Playback Features .............................................................................................. 16

Chapter Skip ............................................................................................................. 16

Fast Motion Playback (Picture Scan) ................................................................ 16

Freeze Frame and Frame Advance ..................................................................... 16

Slow Motion Playback (In Freeze Frame Mode) ............................................ 16

Selecting Specific Scenes on a DVD .................................................................. 17

Selecting a Title Number .................................................................................. 17

Selecting a Chapter Number ........................................................................... 17

Using Elapsed Time............................................................................................. 18

Selecting a Title Using the GUIDE button................................................... 18

Using the Subtitle Feature ................................................................................... 19

Changing the Audio Language ........................................................................... 20

Changing the Camera Angle ............................................................................... 21

Using the Marker Feature..................................................................................... 22

Other Features in the Player Information Display........................................ 24

Table of Contents

Using the Setup Menu................................................................... 25

Selecting Default Audio Languages ...................................................................... 26

Setting the Rating Limit............................................................................................ 28

Locking the Rating Limit .................................................................................. 29

Unlocking the Rating Limit ............................................................................. 30

Changing the Password .................................................................................... 31

Changing the Menu Language ................................................................................ 32

Turning the On-Screen Display ON/OFF ............................................................... 33

Dimming the Front Panel Display........................................................................... 34

Selecting the TV Screen Setting.............................................................................. 35

Selecting Digital Output Type ................................................................................. 36

Advanced Options ....................................................................................................... 37

Dolby Digital is a trademark of Dolby Laboratories Licensing Corporation

Table of Contents 1

Page 4

Table of Contents

Playing Audio CDs .......................................................................... 39

Loading and Playing an Audio CD ......................................................................... 40

CD Information Display ............................................................................................. 40

Audio CD Playback Features .................................................................................... 41

Skipping Tracks ........................................................................................................ 41

Scanning Tracks ....................................................................................................... 41

Selecting a Specific Track..................................................................................... 41

Program Playback ................................................................................................... 42

Deleting Programmed Tracks .......................................................................... 43

Random Playback.................................................................................................... 43

Additional Features in the Player Information Display ................................... 44

Playing Video␣ CDs ........................................................................... 45

Loading and Playing a Video CD............................................................................. 46

Video CD Information Display ................................................................................. 46

If the Video CD Has Playback Control................................................................... 47

Video CD Playback Features ..................................................................................... 48

Skipping Tracks ........................................................................................................ 48

Selecting a Specific Track..................................................................................... 48

Changing the Audio Channel Output............................................................... 49

Program Playback ................................................................................................... 49

Deleting Programmed Tracks .......................................................................... 50

Random Playback.................................................................................................... 51

Features in the Player Information Display......................................................... 51

Reference .......................................................................................... 53

A Tour of the Remote................................................................................................. 54

A Short Glossary of DVD Terminology .................................................................. 55

Front Panel Controls ................................................................................................... 56

Front Panel Display ..................................................................................................... 57

Back Panel......................................................................................................................58

Handling Cautions....................................................................................................... 59

Maintenance of Cabinet ........................................................................................... 59

Formation of Condensation ..................................................................................... 59

Troubleshooting ........................................................................................................... 60

Limited Warranty......................................................................................................... 62

Index ................................................................................................................................ 64

2 Table of Contents

Page 5

There’s Always a Catch

Setup and

Because DVD is a new technology, we recommend that you take some time right now to read through this manual and familiarize yourself with the player.

I Know, You Really Want to Get Going

I know that you’d rather use your DVD player than read about it, so I’ve divided this manual up into sections that address how to use each type of disc that you can play on your player: DVDs, Audio CDs, and Video CDs. So, you don’t have to read all of the book at once.

Please Read This Section First

This section includes key information to get you started in the right direction. You’ll get your DVD player set up and connected, then you can go back to the sections that discuss specific features as you want to use them.

Connections

A Note about the Illustrations

The illustrations in this book are representational, and in some instances may not exactly match the item represented.

Setup and Connections 3

Page 6

Unpacking the Box

Unpack the Box

Carefully unpack the items in the box:

• DVD player

• Remote control and batteries

• Audio/Video cables

• S-Video cable

• Power cord

Install Batteries in the Remote

1. Open the battery door on the back of the remote.

2. Insert fresh batteries. Make sure that the polarities (+ and –) are aligned correctly.

3. Replace the battery door.

Important Battery Information

• If you’re not going to use the remote for a month or more, be sure to remove the batteries because they can leak and cause damage.

• Dispose of batteries in the proper manner, according to federal, state, and local regulations.

• Any battery may leak electrolyte if mixed with a different battery type, if inserted incorrectly, if all batteries are not replaced at the same time, if disposed of in fire, or if an attempt is made to charge a battery not intended to be recharged.

• Discard leaky batteries immediately. Leaking batteries can cause skin burns or other personal injury.

4 Setup and Connections

Page 7

Prepare to Connect the DVD Player

Types of Discs That the Player Can Play

This DVD player is capable of playing the following types of discs, having the corresponding logos:

• DVDs

• Audio CDs

• Video CDs

DIGITAL VIDEO

Prepare to Connect the DVD Player

Before you connect your DVD player, there are a few things that you need to know.

Protect Your Components from Power Surges

• Connect all components before plugging any power cords into the wall outlet.

• Always turn off the DVD player, TV, and other components before you connect or disconnect any cables.

Position Cables Correctly to Avoid Audio Hum or Interference

• Insert all cable plugs firmly into their jacks.

• Place the audio/video cables to the sides of the TV’s back panel instead of straight down the middle after you connect your components.

DO NOT Use CD-R Discs!

The wave length of the pickup of this DVD player may cause CD-R discs to be erased. DO NOT play CD-R discs in this player!

CAUTION

Protect your components from overheating.

• Do not stack electronic components or other objects on top of the DVD player.

• Do not block ventilation holes in any of the components. Arrange the components so that air can circulate freely.

• Try not to coil any twin-lead cables and keep them away from the audio/video cables as much as possible.

• Make sure all antennas and cables are properly grounded.

• Allow adequate ventilation when placing your components in a stand.

See Safety Information, inside front cover.

Setup and Connections 5

Page 8

Types of Jacks and Cables

Audio (L)

Video

Ant In

RF Out

A / B

CH3 CH4

RF Modulator

(Front)

(Back)

Types of Jacks and Cables

Before deciding which method to connect the DVD player, take a moment to familiarize yourself with the different types of jacks and cable.

S-Video Jack and Cable (S-VHS)

The S-Video jack provides excellent picture quality for your DVD player. This jack is available on many TVs. Because the S-Video jack carries only the picture signal, and not the sound, you’ll also need to connect the left and right audio cables.

Audio/Video Jacks and Cables (RCA-type)

S-Video Jack

The audio/video jacks provide very good picture and stereo sound quality, and should be used if your TV has no S-Video jack. Each jack is color coded (yellow for video, red for right audio, and white for left audio). If your TV has only one input for audio (mono), you may need a Y-adaptor (not included) to combine sound from both channels.

RF Jacks and Coaxial Cables (F-type)

You may not need coaxial cables to connect the DVD player to your TV, but you may need to use coaxial cables to carry the cable, satellite, or off-air signal to your television.

Digital Cable

If you own a Dolby Digital receiver with a digital coaxial input, you can use that cable to connect the DVD player to that receiver to get the best sound quality.

Audio/Video Jack

RF Jack

Coaxial

Jack

RF Modulator

If your television has only an RF input jack, you will need to use an RF modulator (not included) to convert the line output signal to an RF signal.

6 Setup and Connections

Page 9

Choosing a Connection

The following pages show examples of connections commonly used to connect the DVD player with a TV and other components. Refer to your TV, VCR, or Dolby Digital Receiver owner’s manual for more information on hooking up your specific components.

DVD Player + TV without A/V Input Jacks .................................. 8

If your television only has antenna (RF) inputs, you will need to get an RF modulator and A/V cable “Y” adapter (not included) in order to connect the DVD player.

DVD Player + TV with A/V Input Jacks (and/or S-Video) .......... 9

Choosing a Connection

If your television has A/V input jacks use them to connect your DVD for better quality picture and sound. (For the best quality picture, use the S-Video input if your television has one.)

DVD Player + Stereo Amplifier/Receiver + TV ..........................10

If your television has an S-Video input, and you have a Dolby Digital Receiver (with a digital coaxial-type input jack), use this connection to get the best quality picture and sound.

DVD Player + TV + VCR .............................................................. 11

If you want to include a VCR in your connection scheme, this shows you one possible connection.

Finishing the Connection

After you have connected all of the components, you will need to attach the power cord, and set the on-screen menu language.

Don’t Forget to Plug It In

After you’ve connected the components, don’t forget to plug in the DVD player. Details at the end of this section.

Setup and Connections 7

Page 10

DVD Player + TV without A/V Input Jacks

(Good Picture and Mono Sound Quality)

ANT IN

CABLE

RF MODULATOR (not included)

"Y" ADAPTER (not included)

Video

Audio (L)

RF Out

Ant In

OFF-AIR SIGNAL

DVD PLAYER

COAXIAL

DIGITAL

AUDIO OUT

VIDEO

OUT

S-VIDEO

OUT

To Connect the DVD Player

If you do not have audio/video input jacks on your television, you need to use an RF modulator and A/V cable “Y” adapter (not included).

1. Connect the “Y” adapter to the DVD player’s AUDIO OUT L & R

jacks, and a standard A/V cable to the VIDEO OUT jack.

2. Connect the other ends of the cable and adapter to the corresponding inputs on the RF modulator.

3. Connect the off-air antenna or your cable signal to the antenna input on the RF modulator (if it has one).

4. Connect the output from the modulator to the antenna input on your television.

CAUTION

Do not stack electronic components or other objects on top of the DVD player. See Safety Information, inside front cover.

To Watch DVD

Tune your television to RF modulator output channel (the modulator should have a CH 3/4 switch to indicate the output channel).

NOTE:

• You may need to adjust the A/B switch on the RF modulator to watch television programming.

8 Setup and Connections

Consult the owner’s manuals of the additional components you are connecting for more detailed connection information for those particular components.

Page 11

DVD Player + TV with A/V Input Jacks

(Better Picture and Sound Quality)

CABLE

OFF-AIR SIGNAL

AUDIO

DVD PLAYER

COAXIAL

DIGITAL

AUDIO OUT

L R

VIDEO

AUDIO OUT

VIDEO

OUT

S-VIDEO

OUT

ANT IN

To Connect the DVD Player

1. Using A/V cables, connect the AUDIO OUT L & R jacks to the corresponding audio inputs on the TV.

2. With a third A/V cable, connect the VIDEO OUT jack to the corresponding video input on the TV (or the S-Video cable if your television has an S-Video input).

Note:

• Your cable or off-air connection to the television should not be affected by this connection. Connect as you normally would to your television. (You may need to consult your television manual for details.)

To Watch DVD

Tune your television to either the Video or S-Video input channel. Consult your television manual for specific details.

CAUTION

Do not stack electronic components or other objects on top of the DVD player. See Safety Information, inside front cover.

Consult the owner’s manuals of the additional components you are connecting for more detailed connection information for those particular components.

Setup and Connections 9

Page 12

DVD Player + TV + Dolby Digital Receiver

(Best Picture and Sound Quality)

AUDIO

VIDEO

DVD PLAYER

DOLBY DIGITAL RECEIVER

COAXIAL

DIGITAL

AUDIO OUT

DIGITAL

S-VIDEO

L R

AUDIO OUT

S-VIDEO

VIDEO

OUT

AUDIO IN

ANT IN

To Connect the DVD Player

1. Connect the left and right A/V cables to the A/V receiver,

Connect a coaxial digital cable to the DIGITAL OUT jack on the DVD player and to the digital input on a Dolby Digital receiver.

2. Connect the video cable (or the S-Video cable if your television has an S-Video input).

Dolby Digital

This format is used when 5.1-channel audio signals are recorded onto the digital track of film. It provides six separate channels: left, right, center, left rear, right rear, and common subwoofer.

To Watch DVD

Tune your television to either the Video or S-Video input channel for the video output. Use your Dolby Digital receiver for audio output.

CABLE

OFF-AIR SIGNAL

PLEASE READ BEFORE USING THE DIGITAL OUT JACK!

This player’s coaxial digital output jack is designed for connection to a Dolby Digital receiver or decoder.

Older digital equipment may not be compatible with the Dolby Digital bitstream. Such a connection can create a high level of noise that may be harmful to your ears, and could damage headphones or speakers.

If you have this problem, try changing the Dolby Digital output from bitstream to PCM using the Digital Output feature in the Setup menu. See “Using the Setup Menu” for more details.

CAUTION

Do not stack electronic components or other objects on top of the DVD player. See Safety Information, inside front cover.

Consult the owner’s manuals of the additional components you are connecting for more detailed connection information for those particular components.

10 Setup and Connections

Page 13

DVD Player + TV + VCR

The following is one possible connection if you want to include a VCR in your connection scheme.

AUDIO

VIDEO

DVD PLAYER

COAXIAL

DIGITAL

AUDIO OUT

L R

AUDIO OUT

VIDEO

S-VIDEO

OUT

ANT IN

DVD Player + TV + VCR

VCR

L R

OUT

AUDIO

VIDEO

L R

OUT TO TV

IN FROM ANT

CABLE

OFF-AIR SIGNAL

To Connect the DVD Player

1. Use audio/video cables to connect the player’s left and right AUDIO OUT jacks to the TV.

2. Use a video cable to connect the player’s VIDEO OUT jack to a TV (or the S-video cable to connect the S-VIDEO OUT jack, if your television has an S-Video input).

To Connect the VCR

1. Connect the off-air antenna or cable to the antenna input on the VCR.

2. Use a coaxial cable to connect the antenna output on the VCR to the antenna input on the television.

DVD Copy Protection

Many DVD discs are encoded with copy protection. Because of this, you should only connect your DVD player directly to your TV, not to a VCR. Connecting to a VCR results in a distorted picture from copy-protected DVD discs.

CAUTION

Do not stack electronic components or other objects on top of the DVD player. See Safety Information, inside front cover.

To Watch DVD

Tune your television to either the Video or S-Video input channel. Consult your television manual for specific details.

To Watch VCR

Tune your television to channel 3 or 4 depending on how you set the CH3/4 switch on the back of the VCR.

Consult the owner’s manuals of the additional components you are connecting for more detailed connection information for those particular components.

Setup and Connections 11

Page 14

2nd

1st

Setting Up the Menu Languages

Connect the AC Power Cord

After you have connected the components, you need to connect the AC power cord. Connect the AC power cord to the back of the DVD player and to an AC power outlet (AC120 V, 50-60 Hz).

Setting Up the Menu Language

By default, the player’s menu language is set to English. If you want to change the language, press MENU on the remote. After plugging in the player, the first time you press the button, this screen comes up:

Press the number on the remote corresponding to the language of your choice.

Other Language Options

The Menu Language feature changes the language only for the text on the menu screens. There are other language options available for subtitling and audio.

NOTE: Make sure that the plug is fully seated in the DVD player.

For more information on these language options, see “Using the Setup Menu” later in this manual.

12 Setup and Connections

Page 15

A New Way of Looking At Things

In this section you learn how to use your DVD player to play DVD discs (DVDs for short).

As a little up-front information, you should know that although some of the remote buttons look the same as those you would use with a VCR or CD player, the functions work somewhat differently. So, take some time now to find out how to play DVDs, and then you can sit back and enjoy all of the features it has to offer you.

Also Keep In Mind...

In order for some of the player’s features to work, the DVDs that you use must be encoded with specific information. For example, a disc must contain subtitles in order for the player to show them to you.

Playing DVDs

Regional Coding

Both the DVD player and the discs are coded by region. These regional codes must match in order for the disc to play. If the codes do not match, the disc will not play. This player’s code is Region No. 1.

Playing DVDs 13

Page 16

Loading and Playing a DVD

Before you load a disc, make sure that it is compatible with the player. Note that the following discs CANNOT be used with this player:

• Laserdisc

• CD-I, CD-ROM, CD-R, DVD-ROM

• MiniDisc



• Discs recorded using other broadcast standards (i.e. PAL or SECAM)

• CD-G discs play audio only, not graphics

To Load and Play a DVD

Make sure the DVD player is properly connected (see “Setup and Connections”) and turned on before you begin.

1. Press the OPEN•CLOSE button on the front of the DVD player.

2. Place a disc gently into the tray with the disc’s label facing up (double-sided discs have a small label on both sides near the center).

3. Press the OPEN•CLOSE or PLAY button to close the disc tray.

The DVD player reads the disc’s table of contents, and then begins playback, or displays the disc menu (if the DVD has one). A DVD’s behavior is determined by how it’s been “authored”—or programmed.

Single-sided disc (label side up)

(

)



Double-sided disc

Accessing the Disc Menu

Many DVDs will skip the disc menu and begin playback automatically. During playback, press the MENU button on the remote to access the disc menu.

Label

An example of a disc menu.

4. Press STOP to stop playback.

14 Playing DVDs

Resume Feature

When you stop disc play, the player remembers where you stopped, so when you press PLAY again to begin play, it will pick up where you left off (unless the disc is removed, the STOP button is pressed twice, or the player is unplugged). Because this feature uses elapsed time as a marker, this feature does not work with discs that do not keep elapsed time (for example, interactive DVDs).

Page 17

Using a DVD’s Disc Menu

A DVD is capable of having a disc menu—its own on-screen menu system separate from the player’s displays. This menu may allow you to change features such as language and playback settings.

Although disc menus’ content and operation differ from DVD to DVD, the following example should give you a pretty good idea of what to expect.

1. When the disc is playing, press MENU to bring up the disc menu.

2. Use the up and down MOVE arrows to highlight the setting or feature you want to change and press OK.

Using a DVD’s Disc Menu

POWER

PLAY FORWARDREVERSE

PAUSE

SKIP

OK button

GO BACK

Menu button

Move Arrow buttons

SKIP

STOP

MENU GUIDE

INFO

The Language setting is selected

3. Use the up and down MOVE arrows to select a language and press OK.

English is selected

Notes:

• Because the disc menu is DVD-dependent, operation may vary from disc to disc.

• If the DVD is removed from the disc tray, or the player is turned off, these settings are returned to the initialized settings.

Initialized Settings

“Initialized settings” are the setting to which the player will default each time it is turned on.

Any settings you change with the disc menu only temporarily override the initialized settings.

Use the Setup Menu of the DVD player to change the initialized settings. (See “Using the Setup Menu” for more details.)

Playing DVDs 15

Page 18

DVD Playback Features

Several options are available during DVD playback.

Chapter Skip

Because program content on a DVD can be divided into Chapters, you can skip through a disc’s contents one chapter at a time.

• Press and release SKIP– on the remote (SKIP REV on the player) to go to the beginning of the Chapter that is playing. Press again to go to the beginning of the preceding Chapter.

• Press and release SKIP+ on the remote (SKIP FWD on the player) to go to the beginning of the next Chapter.

Fast Motion Playback (Picture Scan)

To scan through a section of the disc during playback, use the Picture Scan feature:

1. Press the REVERSE or FORWARD button on the remote during playback to search through a disc.

2. Press the button again on the remote to search at a faster speed.

Playback buttons

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

3. Press the PLAY button on the remote to resume normal playback.

Freeze Frame and Frame Advance

1. Press PAUSE once to freeze playback.

2. Each subsequent press of the PAUSE button advances the picture one frame at a time.

3. Press PLAY to resume normal playback.

Slow Motion Playback (In Freeze Frame Mode)

While the disc is in freeze frame mode, you can invoke either forward or backward slow motion playback.

• Press REVERSE on the remote for backward slow motion playback. Press the button again to increase the speed.

Playback features are disc-dependent, and may not work with all discs.

Slow Motion Backward

Because of the nature of MPEG2 video, searching backward does not provide as clear a picture as searching forward, and the picture may appear “jumpy.”

16 Playing DVDs

Page 19

• Press FORWARD on the remote for forward slow motion playback. Press the button again to increase the speed.

• Press PLAY to resume normal playback.

Selecting Specific Scenes on a DVD

Use the on-screen disc information display to access a specific scene on a DVD.

Selecting Specific Scenes on a DVD

POWER

PLAY FORWARDREVERSE

Move Arrow buttons

SKIP

STOP

MENU GUIDE

PAUSE

SKIP

OK button

Selecting a Title Number

1. During disc playback, press INFO on the remote.

Title

Enter the title number and press OK.

2. Use the up and down MOVE arrows or number buttons to enter a different title number.

3. Press OK to begin playing the selected title.

Selecting a Chapter Number

1. During disc playback, press INFO on the remote.

Chapter

GO BACK

Info button

INFO

Information Displays

Press the INFO button on the remote to display the disc information display on-screen.

Press INFO a second time to display the player information display.

Pressing INFO a third time clears the display from the screen.

Number buttons

Enter the chapter number and press OK.

2. Use the right MOVE arrow to highlight the current chapter number.

What’s a Scene?

Because DVD is a digital format, the information can be separated in many different ways. One way that a DVD might be separated is by scenes (as in a movie). Each scene might be a title or chapter, so rather than watching the whole movie to get to a scene, you can just go straight to it.

Playing DVDs 17

Page 20

Selecting Specific Scenes on a DVD

3. Use the up and down MOVE arrows or number buttons to enter a different chapter number.

4. Press OK to begin playing the selected chapter.

Notes for Title/Chapter Select:

• These features do not function when using a DVD without title and chapter numbers.

• You can also use the SKIP+ and SKIP– buttons on the remote to skip chapters.

Using Elapsed Time

1. During disc playback, press INFO on the remote.

Elapsed Time

Move Arrow buttons

Info button

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

Guide button

OK button

Number buttons

Enter playing time and press OK

2. Use the right MOVE arrow to highlight the time.

3. Use the number buttons to enter the time from which you want to start.

4. Press OK to begin playback starting at the elapsed time indicated.

Note:

• Some DVDs cannot be searched using this feature.

Selecting a Title Using the GUIDE button

You can use the GUIDE button on the remote to access a list of titles available on a DVD.

1. Press GUIDE on the remote.

2. Use the up and down MOVE arrows to highlight a title and press OK. The selected title begins play.

18 Playing DVDs

Page 21

Notes:

• This feature may not work with all DVDs because not all DVDs contain multiple titles.

• Depending on the type of DVD, another menu may be displayed.

Using the Subtitle Feature

POWER

PLAY FORWARDREVERSE

SKIP

STOP

PAUSE

SKIP

Using the Subtitle Feature

When a DVD is recorded with subtitles, you can use the Subtitle feature to view the subtitles on-screen.

Changing the Subtitle Language (On the Player)

You can temporarily change the initialized subtitle language (provided additional languages are included on the DVD) from the disc information display.

1. During disc playback, press INFO on the remote.

Subtitle Language

Select a subtitle language and press OK.

Move Arrow buttons

Info button

MENU GUIDE

INFO

GO BACK

OK button

2. Use the right MOVE arrow to highlight the subtitle stream number. (Each language is assigned a stream number.)

3. Use the up and down MOVE arrows or number buttons to select a subtitle language.

4. Press the right MOVE arrow to highlight the subtitle on/off checkbox. Use the up and down MOVE arrows to turn the subtitle feature on or off. A check appears in the box when subtitles are turned on.

5. Press INFO twice to turn off the information display.

Note:

• When the player is turned on, the initialized subtitle language is selected. If the disc does not contain this language, the “default” language is automatically selected.

Make sure that the player’s subtitle feature is turned on, or the subtitling will not appear on-screen.

Playing DVDs 19

Page 22

Changing the Audio Language

When a DVD is recorded with multiple language tracks, you can use the Audio Language feature to temporarily change the initialized audio language.

1. During disc playback, press INFO on the remote.

Audio Soundtrack Language

Move Arrow buttons

POWER

PLAY FORWARDREVERSE

PAUSE

SKIP

STOP

MENU GUIDE

Select an audio language and press OK.

2. Use the right MOVE arrow to highlight the audio stream number. (Each language is assigned a stream number.)

3. Use the up and down MOVE arrows or number buttons to select a language.

4. Press INFO twice to turn off the information display.

Notes:

• When the player is turned on, the initialized audio language is selected. If the disc does not contain this language, the “default” language is automatically selected.

• This feature is disc-dependent, and may not work with all DVDs.

Info button

INFO

GO BACK

20 Playing DVDs

Page 23

Changing the Camera Angle

Some DVDs contain multiple angles of a particular scene or sequence.

Changing the Camera Angle

POWER

1. During disc playback, press INFO on the remote.

Angle Number

Select a camera angle and press OK

2. Use the right MOVE arrow to highlight the angle number.

3. Use the up and down MOVE arrows or number buttons to select a camera angle.

4. Press INFO twice to turn off the information display.

Note:

• This feature does not work when a DVD has not been recorded with a multi-camera angle system.

Move Arrow buttons

Info button

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

Playing DVDs 21

Page 24

Using the Marker Feature

Use the Marker feature to select (or mark) parts of a DVD so that you can quickly find the section at a later time.

Storing a Marker During DVD Playback

1. During disc playback, press INFO on the remote twice to bring up the player information display.

Marker

Player Information Display

2. Use the right MOVE arrow to highlight the marker.

3. Press OK to activate the marker.

4. When you reach the scene you want to mark, press OK. Markers in use display a number (1–5). Up to five scenes may be marked at the same time.

Move Arrow buttons

Info button

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

5. Press INFO to turn off the information display.

•

Unused Marker

Selected Marker

Markers are also cleard when the tray is opened and when the power is turned off.

22 Playing DVDs

Page 25

Recalling a Marked Scene

Using the Marker Feature

1. During disc playback, press INFO on the remote twice to bring up the player information display.

2. Use the right MOVE arrow to highlight the marker.

3. Press OK to activate the marker.

4. Use the right and left MOVE arrows to select a marked scene.

5. Press the up MOVE arrow to skip to the marked scene.

Clearing a Marker

The marker is cleared each time a disc is removed from the player, or when the power is turned off.

If all five markers are in use, you can still mark new scenes. However, the previous marker will be erased. Use the instructions on the previous page to add additional markers.

Move Arrow buttons

Info button

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

Playing DVDs 23

Page 26

Other Features in the Player Information Display

Along with the marker, several other features are available in the player information display.

To access any feature:

1. Press INFO on the remote twice to access the display.

2. Use the right and left MOVE arrows to highlight a feature.

3. Use the up and down MOVE arrows to change a feature’s settings (except A-B Repeat).

4. Press INFO to turn off the information display.

(From the display’s left)

A-B Repeat lets you mark a segment. Press OK at the beginning (A) and again at the end (B) of the segment you want to review. The segment will repeat until you press OK to clear the feature.

Repeat Mode lets you select between disc (shown at left), title, or chapter repeat, and standard play.

Move Arrow buttons

Info button

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

Title Repeat

Chapter Repeat

Standard Playback

Virtual Surround Sound uses a Dolby Digital soundtrack (required) to create a surround sound effect without rear speakers. Two modes are available. Choose the mode that best suits your taste.

24 Playing DVDs

Page 27

Putting You In Control

Using the

The Setup menu lets you customize your DVD player by allowing you to set up a rating level, select various language preferences, and even adjust the player to the type of television screen you have (i.e. wide-screen).

To access the Setup menu, press the MENU button on the remote control while the DVD player is in the stop mode. Use the up and down MOVE arrows on the remote to access the different features.

Setup Menu

Using the Setup Menu 25

Page 28

Selecting Default Audio Languages

Use the Disc Languages menu to set default languages for a DVD’s disc menu, soundtrack, and subtitles.

1. In stop mode, press MENU on the remote.

2. Use the up and down MOVE arrows to navigate the menu. Highlight “Disc Languages” and press OK.

Menu button

Move Arrow buttons

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

Disc Languages Menu

Selecting the Audio Preference

Use the Audio Preference menu to select the soundtrack language.

1. In the Disc Languages menu, press OK on the remote to select “Audio.”

2. Use the up and down MOVE arrows to highlight a language and press OK.

Audio Preference Menu

Using the Number Buttons

You can also select an option in the Setup Menu by pressing its number on the remote.

26 Using the Setup Menu

Page 29

Selecting Default Audio Languages

• Select “Original” if you want the default soundtrack language to be the original language the disc is recorded in.

• Select “Other” if the language you want is not listed. Enter the appropriate code from the list at the end of this chapter and press OK.

Notes:

• Not all discs provide multiple languages for the soundtrack.

• Some discs may not contain the language you select as your initial language; in that case the disc will use its toppriority language setting.

Selecting the Subtitle Preference

Use the Subtitle Preference menu to select the language the disc’s subtitles are to be displayed in.

Menu button

Move Arrow buttons

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

1. In the Disc Languages menu, use the up and down MOVE arrows on the remote to highlight “Subtitles” and press OK.

2. Use the up and down MOVE arrows to highlight a language and press OK.

Subtitle Preference Menu

• Select “Automatic” if you want the subtitle language to be the same as the language selected as audio preference.

• Select “Other” if the language you want is not listed. Enter the appropriate code from the list at the end of this chapter and press OK.

Note:

• Not all discs provide multiple languages for the subtitles.

Using the Setup Menu 27

Page 30

Setting the Rating Limit

Selecting the Menu Preference

Use the Menu Preference menu to select the language you want a DVD’s disc menu to be displayed in.

POWER

1. In the Disc Languages menu, use the up and down MOVE arrows on the remote to highlight “Menu” and press OK.

2. Use the up and down MOVE arrows to highlight a language and press OK.

Menu Preference Menu

• Select “Other” if the language you want is not listed. Enter the appropriate code from the list at the end of this chapter and press OK.

Note:

• Not all discs provide multiple languages for the disc menu.

Menu button

Move Arrow buttons

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

Setting the Rating Limit

The Rating Limit feature works in conjunction with DVDs that have been assigned a rating—which helps you control the types of DVDs that your family watches.

1. In stop mode, press MENU on the remote.

Current Rating Limit

Player’s Menu Language

Setting the default menu language in the Menu Preference menu affects DVD disc menus only.

To change the language of your player’s menu system, see “Changing the Menu Language” later in this section.

28 Using the Setup Menu

Page 31

2. Use the up and down MOVE arrows to highlight “Rating Limit” and press OK.

Set Rating Menu (if rating level is unlocked)

3. To set the rating, use the up and down MOVE arrows to highlight your preferred level and press OK.

Locking the Rating Limit

POWER

PLAY FORWARDREVERSE

PAUSE

SKIP

OK button

GO BACK

Menu button

Move Arrow buttons

Number buttons

SKIP

STOP

MENU GUIDE

INFO

After selecting a rating limit, you will need to lock it to prevent it from being changed. The new rating limit will reset to its default if it is not locked.

Enter a 4-digit password to lock the rating level.

1. Use the number buttons on the remote to enter a new 4-digit password and press OK.

If the Rating Limit Feature Doesn’t Work

The rating level is locked.

In order for the Rating level feature to work, the disc must be encoded with the proper rating information. If the maker of the disc did not encode rating information, then this feature will not work for that disc.

Using the Setup Menu 29

Page 32

Unlocking the Rating Limit

You can unlock the player completely, or temporarily. Temporarily unlocking the player unlocks the player for the current disc only.

To completely unlock the player:

1. In the Setup menu, use the up and down MOVE arrows on the remote to highlight “Rating Limit” and press OK.

2. Enter your 4-digit password and press OK.

Rating Limit Menu (if rating limit is locked)

3. Use the up and down MOVE arrows to highlight “Unlock Player” and press OK.

Menu button

Move Arrow buttons

Number buttons

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

Unlock Player Screen

4. Press OK to continue.

To temporarily unlock the player:

1. In the Setup menu, use the up and down MOVE arrows to highlight “Rating Limit” and press OK.

2. Enter your 4-digit password and press OK.

What if a DVD’s rating exceeds the player’s rating limit?

The player alerts you when you try to play a DVD with a rating that exceeds the limit you’ve set. The message, “Your selection exceeds the rating limit for this player.” appears on screen.

Some discs are authored with a rating override feature included. When you play a disc with this feature, the message, “Your selection exceeds the rating limit for this player. Override the limit?” is displayed. Select “Override” or “Cancel.” If you choose to override the rating limit, you will need to enter your 4-digit password to begin playback.

30 Using the Setup Menu

Page 33

3. In the Rating Limit menu, use the up and down MOVE arrows to highlight “Unlock Temporarily” and press OK.

4. Press OK to continue. The player is unlocked for this disc only.

Changing the Password

You can change the password at your convenience.

1. In the Setup menu, use the up and down MOVE arrows on the remote to highlight “Rating Limit” and press OK.

Changing the Password

POWER

PLAY FORWARDREVERSE

PAUSE

SKIP

OK button

GO BACK

Menu button

Move Arrow buttons

Number buttons

SKIP

STOP

MENU GUIDE

INFO

2. Enter your 4-digit password and press OK.

3. In the Rating Limit menu, use the up and down MOVE arrows to highlight “Change Password” and press OK.

4. Use the number buttons to enter a new 4-digit password and press OK.

5. Press OK to continue.

Pro-tect PlusTM Locking Feature

The DVD player’s disc tray can be locked shut. You can still play a disc as long as it was inserted in the player before locking the tray. The disc cannot be removed from the player until the tray is unlocked.

You can lock the disc tray when the DVD player is turned on or off.

1. Press and hold STOP on the player.

2. Press POWER on the remote.

If the player is turned on, “LOCKED” appears in the front panel display.

The player cannot be turned off when locked.

To unlock the disc tray, repeat the steps above. “UNLOCKED” appears in the front panel display if the player is turned on.

Using the Setup Menu 31

Page 34

Changing the Menu Language

Use this feature to change the language for the player’s on-screen menu system.

1. In stop mode, press MENU on the remote.

Menu Language

2. Use the up and down MOVE arrows to highlight “Menu Language” and press OK.

Menu button

Move Arrow buttons

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

Menu Language Preference Menu

3. Use the up and down MOVE arrows to highlight the desired language for the on-screen menu system and press OK.

Disc Menu Language

To change the default language for DVD disc menus, see “Selecting Default Audio Languages” earlier in this section.

32 Using the Setup Menu

Page 35

Turning the On-Screen Display ON/OFF

Use this feature to turn on or off the on-screen displays that appear in the upper right corner of the screen (Play, Pause, etc.).

1. In stop mode, press MENU on the remote.

On-Screen Display

2. Use the up and down MOVE arrows to highlight “On-Screen Display” and press OK.

Menu button

Move Arrow buttons

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

On-Screen Display Menu

3. Use the up and down MOVE arrows to highlight “ON” or “OFF” and press OK.

Using the Setup Menu 33

Page 36

Dimming the Front Panel Display

Use this feature to adjust the brightness of the player’s front panel display.

1. In stop mode, press MENU on the remote.

Display Dimming

2. Use the up and down MOVE arrows to highlight “Display Dimming” and press OK.

Menu button

Move Arrow buttons

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

Display Dimming Menu

3. Use the up and down MOVE arrows to highlight a display option.

Always Bright Default setting. Always Dim Dims display.

4. Press OK.

34 Using the Setup Menu

Page 37

Selecting the TV Screen Setting

Depending on the type of television you have, you may want to adjust the screen setting (aspect ratio).

1. In stop mode, press MENU on the remote.

TV Screen

2. Use the up and down MOVE arrows to highlight “TV Screen” and press OK.

Menu button

Move Arrow buttons

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

Select a screen setting that matches your TV

3. Use the up and down MOVE arrows to highlight a screen setting.

(Standard TV)

Select this for conventional size TVs. The aspect ratio is selected according to the disc played. If the DVD is recorded in letterbox mode (widescreen) , black bars will appear at the top and bottom of the screen.

(Widescreen TV)

Select this for wide-screen televisions. If the DVD is recorded in 4:3, the left and right side of the screen will appear black.

4. Press OK.

Using the Setup Menu 35

Page 38

Selecting Digital Output Type

If you have a receiver with a digital signal input, use this feature to select your player’s type of digital output.

1. In stop mode, press MENU on the remote.

Digital Output

2. Use the up and down MOVE arrows to highlight “Digital Output” and press OK.

Menu button

Move Arrow buttons

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

Digital Output Menu

3. Use the MOVE arrows to highlight an output option and press OK.

LPCM Allows downsampling of 96kHz/24-bit digital recordings so that 48kHz/16-bit digital recordings can be made directly via digital cable. Unless you plan to make recordings of this type (e.g., with a MiniDisc or DAT recorder), leave the setting turned off.

Dolby Digital Some older digital components are not compatible with the default “Bitstream” setting. If you experience noise and distortion during Dolby Digital playback, select “PCM” instead.

36 Using the Setup Menu

Page 39

Advanced Options

The Advanced Options menu contains several additional features that you can control.

1. In stop mode, press MENU on the remote.

Advanced Features

2. Use the up and down MOVE arrows to highlight “Advanced Options” and press OK.

Menu button

Move Arrow buttons

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

Advanced Options Menu

3. Use the up and down MOVE arrows to highlight an option.

When an option is selected, use the MOVE arrows to change the setting.

Pause Scanning Helps eliminate “flicker” that sometimes appears in still-frame mode. Auto, the default setting, advances to the next frame. The Field setting eliminates flicker by displaying only one of the frame’s fields.

Audio for 2x Playback Turns audio off or on when a disc is in 2x playback mode.

4x3 Preference For playing DVD discs authored in 16x9 widescreen on a conventional TV. Pan/Scan crops the edges of the image. Letterbox displays black bars at the top and bottom of the screen.

Dynamic Range Compression Compresses the dynamic range (quietest to loudest sound) of a disc’s soundtrack. Useful for latenight listening when you want to hear a movie’s dialogue without having to turn the volume up.

4. Press OK.

Using the Setup Menu 37

Page 40

Language Codes

Don’t forget to press the OK button after you enter the code.

Code Language CodeLanguage Code Language

Abkhazian 6566 Afar 6565 Afrikaans 6570 Albanian 8381 Ameharic 6577 Arabic 6582 Armenian 7289 Assamese 6583 Aymara 6588 Azerbaijani 6590 Bashkir 6665 Basque 6985 Bengali; Bangla 6678 Bhutani 6890 Bihari 6672 Bislama 6673 Breton 6682 Bulgarian 6671 Burmese 7789 Byelorussian 6669 Cambodian 7577 Catalan 6765 Chinese 9072 Corsican 6779 Croatian 7282 Czech 6783 Danish 6865 Dutch 7876 English 6978 Esperanto 6979 Estonian 6984 Faroese 7079 Fiji 7074 Finnish 7073 French 7082 Frisian 7089 Galician 7176 Georgian 7565 German 6869 Greek 6976 Greenlandic 7576 Guarani 7178 Gujarati 7185 Hausa 7265 Hebrew 7387 Hindi 7273

Hungarian 7285 Icelandic 7383 Indonesian 7378 Interlingua 7365 Interlingue 7369 Inupiak 7375 Irish 7165 Italian 7384 Japanese 7465 Javanese 7487 Kannada 7578 Kashmiri 7583 Kazakh 7575 Kinyarwanda 8287 Kirghiz 7589 Kirundi 8278 Korean 7579 Kurdish 7585 Laothian 7679 Latin 7665 Latvian, Lettish 7686 Lingala 7678 Lithuanian 7684 Macedonian 7775 Malagsy 7771 Malay 7783 Malayalam 7776 Maltese 7784 Maori 7773 Marathi 7782 Moldavian 7779 Mongolian 7778 Naru 7865 Nepali 7869 Norwegian 7879 Occitan 7967 Oriya 7982 Oromo (Afan) 7977 Panjabi 8065 Pashto, Pushto 8083 Persian 7065 Polish 8076 Portuguese 8084 Quechua 8185 Rhaero-Romance 8277 Romanian 8279

Russian 8285 Samoan 8377 Sangho 8371 Sanskrit 8365 Scots Gaelic 7168 Serbian 8382 Servo-Croatian 8372 Sesotho 8384 Setswana 8478 Shona 8378 Sindhi 8368 Singhalese 8373 Siswati 8383 Slovak 8375 Slovenian 8376 Somali 8379 Spanish 6983 Sundanese 8385 Swahili 8387 Swedish 8386 Tagalog 8476 Tajik 8471 Tamil 8465 Tatar 8484 Telugu 8469 Thai 8472 Tibetan 6679 Tigrinya 8473 Tonga 8479 Tsonga 8483 Turkish 8482 Turkmen 8475 Twi 8487 Ukrainian 8575 Urdu 8582 Uzbek 8590 Vietnamese 8673 Volapük 8679 Welsh 6789 Wolof 8779 Xhosa 8872 Yiddish 7473 Yoruba 8979 Zulu 9085

38 Using the Setup Menu

Page 41

Just Like Your CD Player

Playing

Your DVD player can play Audio Compact Discs, as well as DVDs. If you’ve used a CD player before, you will probably notice that your DVD player has a lot of the same features as a CD player.

This section gives you all the information you need to know to play Audio CDs on your DVD player.

Audio CDs

Playing Audio CDs 39

Page 42

Loading and Playing an Audio CD

Before you load a disc, make sure that it is compatible with the player. Note that the following discs CANNOT be used with this player:

• Laserdisc

• CD-I, CD-ROM, CD-R, DVD-ROM

• MiniDisc

To Load and Play an Audio CD

Make sure that you have properly connected the DVD player (see “Setup and Connections”) before you begin.

1. Press OPEN•CLOSE or PLAY on the front of the DVD player.

2. Place a disc gently into the tray with the disc’s label facing up.

1. Wavin' Good Day

2. surfin' in the rain

3. Born on Thursday

4. Smarter than y

5.Dadio's dreams

ou



3. Press the PLAY button to close the disc tray. The DVD player reads the disc’s table of contents, and

then begins disc playback.

4. Press STOP to stop playback.

CD Information Display

1. Press INFO on the remote to bring up the CD information display.

Time Counter

Track Number

2. Press INFO a second time to show the player information display, and then a third to turn it off.

Insert with the label facing up.

You can find additional details on the player information display later in this section.

40 Playing Audio CDs

Page 43

Audio CD Playback Features

When playing audio CDs, your DVD player has many of the same features that your CD player has, including track skip, repeat play, and programmed playback.

Skipping Tracks

• To skip forward to the beginning of the next track on a CD, press SKIP+ on the remote (SKIP FWD on the player).

• To skip backward to the beginning of the track that is playing on a CD, press SKIP– on the remote (SKIP REV on the player). Press the button again to go to the beginning of the preceding track.

Scanning Tracks

• Press FORWARD or REVERSE on the remote. Pressing either button additional times increases the speed of the scan.

Selecting a Specific Track

Playback buttons

Info button

Number buttons

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

1. Use the number buttons to enter your desired track number.

2. Press PLAY or OK to begin playback.

Note

• Entering a two-digit number automatically starts playback without having to press PLAY or OK. For this to work with tracks 1–9 of a CD, press “0” and then the track number.

Playing Audio CDs 41

Page 44

Program Playback

Program playback lets you set up a specific order for Audio CD playback.

1. With the player in stop mode, press INFO on the remote twice to bring up the player information display.

Playback Mode

Player Information Display

2. Use the right MOVE arrow to highlight Playback Mode.

3. Use the up and down MOVE arrows to scroll through the options:

Standard Playback

Program Playback

Play button

Move Arrow buttons

Info Button

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

Number buttons

Random Playback

4. When the Program Playback icon is displayed, press OK.

Selected Track(s)

Disc’s Track Numbers

Program Playback Screen

To Program Tracks:

1. Use the MOVE arrows or number buttons to highlight a track number and press OK to add it to the program list.

2. Repeat step 1 to add more tracks. Up to 24 tracks may be programmed at once.

3. Press PLAY to begin programmed playback.

42 Playing Audio CDs

Page 45

Notes:

Program Playback

• When the program is completed, the disc stops and the Program Playback menu is displayed again.

• To resume normal playback, press GO BACK and then press PLAY.

Deleting Programmed Tracks

There are two ways to delete tracks from a program list:

• Press the down MOVE arrow until “Clear last track” is highlighted, then press OK.

• Highlighting “Clear all tracks” and pressing OK deletes all tracks in the list. All programmed tracks are also deleted when the disc is removed or the DVD player is turned off.

Random Playback

A CD’s tracks can be set to play back in random order.

1. With the player in stop mode, press INFO on the remote twice to bring up the player information display.

Play button

Move Arrow buttons

Info Button

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

2. Use the right MOVE arrow to highlight Playback Mode.

3. Use the up and down MOVE arrows to scroll through the options. When the Random Playback icon is displayed, press OK. (See previous page for icons.)

4. Press PLAY to begin playback.

Playing Audio CDs 43

Page 46

Additional Features in the Player Information Display

When playing a CD, many features in the player information display work exactly the same as they do when playing DVDs. Differences are noted below.

To access any feature:

1. Press INFO on the remote twice to access the display.

2. Use the right and left MOVE arrows to highlight a feature.

3. Use the up and down MOVE arrows to change a feature’s settings (except A-B Repeat).

4. Press INFO to turn off the information display.

(From the display’s left)

A-B Repeat lets you mark a segment. Press OK at the beginning (A) and again at the end (B) of the segment you want to review. The segment will repeat until you press OK to clear the feature.

Repeat Mode lets you select between disc repeat (shown at left) track repeat, or standard play.

Move Arrow buttons

Info button

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

•

Track Repeat

Standard Playback

Marker lets you mark sections to let you find them quickly later on. See “Playing DVDs” for complete details.

44 Playing Audio CDs

Page 47

What’s a Video CD?

DIGITAL VIDEO

Playing

The Video CD format is similar to DVD in that Video CDs can contain movies. The big difference is in the amount of information that can be stored on a single Video CD.

This section gives you all the information you need to know to play Video CDs on your DVD player.

Video␣ CDs

Playing Video CDs 45

Page 48

Loading and Playing a Video CD

Before you load a disc, make sure that it is compatible with the player. Note that the following discs CANNOT be used with this player:

• Laserdisc

• CD-I CD-ROM, CD-R, DVD-ROM

• MiniDisc

• Discs recorded using other color TV systems (i.e. PAL or SECAM)

To Load and Play a Video CD

Make sure that you have properly connected the DVD player (see “Setup and Connections”) before you begin.

1. Press the OPEN•CLOSE button on the front of the DVD player.

2. Place a disc gently into the tray with the disc’s label facing up.

3. Press OPEN•CLOSE or PLAY to close the disc tray. The DVD player reads the disc’s table of contents, and

then displays the playback control menu or begins disc playback.

4. Press STOP to stop playback.

Video CD Information Display

1. Press INFO on the remote to bring up the Video CD’s information display.

Playback Control

Audio Channel Output

Time Counter

Track Number

The New Meaning of It All Library

Insert with the label facing up.

Volume One



2. Press INFO a second time to show the player’s information display, and then a third to turn it off.

46 Playing Video CDs

Page 49

If the Video CD Has Playback Control

Playback Control

If a disc is encoded with the playback control function, a menu screen appears after the disc is loaded into the player.

An example of a playback control menu.

1. Use the number buttons on the remote to select a title.

2. Press OK or PLAY to begin playback of the selected title.

3. Press SKIP+ or SKIP– on the remote (SKIP FWD or SKIP REV on the player) to scroll through the titles.

4. Press GO BACK to stop playback and return to the menu or press STOP to stop playback and remove the menu from the screen.

Playback Buttons

OK button

Number buttons

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

Go Back button

Bypassing Playback Control

If a Video CD has Playback Control, you can bypass the menu by following these steps when you first load the discs.

1. Press STOP to put the player in the stop mode.

2. Use the number buttons on the remote to enter the desired track number, and then press PLAY. When playback begins, the disc will respond as if it is not in the Playback Control mode.

Resuming Playback Control

• To resume the Playback Control mode, press STOP, and then press PLAY.

For More Information About Playback Control

Check the instructions that accompany the Video CD for more information on how to use the playback control function for that specific disc.

Playing Video CDs 47

Page 50

Video CD Playback Features

The DVD player gives you several options when playing Video CDs, including skipping tracks, repeat play, and programmed playback.

Skipping Tracks

• To skip forward to the beginning of the next track on a Video CD, press SKIP+ on the remote (SKIP FWD on the player).

• To skip backward to the beginning of the track that is playing on a video CD, press SKIP– on the remote (SKIP REV on the player). Press the button again to go to the beginning of the preceding track.

Note:

• For some Video CDs, the SKIP buttons may bring up the menu screen instead.

Selecting a Specific Track

Stop button

OK button

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

Play button

Skip+/Skip– buttons

Number buttons

1. Use the number buttons on the remote to enter your desired track number.

2. Press PLAY or OK to begin playback.

Notes:

• Entering a two-digit number automatically starts playback without having to press PLAY or OK. For this to work with tracks 1–9, press “0” and then the track number.

• This feature does not work in Playback Control mode.

• You can also use the digits on the remote to enter a track number directly. Press PLAY to begin playback

48 Playing Video CDs

Page 51

Changing the Audio Channel Output

Program Playback

If you are playing a stereo Video CD, you can change the channel output from the player.

1. During disc playback, press INFO on the remote.

2. Use the right MOVE arrow to highlight the audio channel output.

3. Use the up and down MOVE arrows to select an audio channel (left, right, or stereo).

4. Press INFO twice to turn off the information display.

Program Playback

Program playback lets you set up a specific order for the playback of tracks on a disc.

You must bypass Playback Control before you can program tracks (see “Bypassing Playback Control” earlier in this section).

1. With the player in stop mode, press INFO on the remote twice to bring up the player information display.

Move Arrow buttons

Info button

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

Number buttons

Playback Mode

Player Information Display

2. Use the right MOVE arrow to highlight Playback Mode.

3. Use the up and down MOVE arrows to scroll through the options:

Standard Playback

Program Playback

Random Playback

4. When the Program Playback icon is displayed, press OK.

Playing Video CDs 49

Page 52

Program Playback

Selected Track(s)

Disc’s Track Numbers

Program Playback Screen

To Program Tracks:

1. Use the MOVE arrows or number buttons to highlight a track number and press OK to add it to the program list.

2. Repeat step 1 to add more tracks. Up to 24 tracks may be programmed at once.

3. Press PLAY to begin programmed playback.

Notes:

• When the program is completed, the disc stops and the Program Playback menu is displayed again.

Play button

Move Arrow buttons

Number buttons

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

• To resume normal playback, press GO BACK and then press PLAY.

Deleting Programmed Tracks

There are two ways to delete tracks from a program list:

• Press the down MOVE arrow until “Clear last track” is highlighted, then press OK.

• Highlighting “Clear all tracks” and pressing OK deletes all tracks in the list. All programmed tracks are also deleted when the disc is removed or the DVD player is turned off.

50 Playing Video CDs

Page 53

Random Playback

Features in the Player Information Display

A Video CD’s tracks can be set to play back in random order.

1. With the player in stop mode, press INFO on the remote twice to bring up the player information display.

2. Use the right MOVE arrow to highlight Playback Mode.

3. Use the up and down MOVE arrows to scroll through the icons. When the Random Playback icon is displayed, and press OK.

4. Press PLAY to begin playback.

Features in the Player Information Display

Move Arrow buttons

Info button

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK button

When playing a Video CD, many features in the player information display work exactly the same as they do when playing audio CDs. Differences are noted on the next page.

To access any feature:

1. Press INFO on the remote twice to access the display.

2. Use the right and left MOVE arrows to highlight a feature.

3. Use the up and down MOVE arrows to change a feature’s settings (except A-B Repeat).

4. Press INFO to turn off the information display.

Playing Video CDs 51

Page 54

Features in the Player Information Display

(From the display’s left)

A-B Repeat lets you mark a segment. Press OK at the beginning (A) and again at the end (B) of the segment you want to review. The segment will repeat until you press OK to clear the feature.

Repeat Mode lets you select between disc repeat (shown at left), track repeat, or standard play. Playback Control must be turned off.

Track Repeat

Standard Playback

Marker lets you mark sections to let you

•

find them quickly later on. See “Playing DVDs” for complete details.

52 Playing Video CDs

Page 55

Tour of the Remote Control

This section briefly describes each of the remote buttons’ functions.

About the DVD Player

This section includes extra information about the DVD player, including a description of the front panel and front panel display, the back panel, some basic use and care guidelines, and a glossary of DVD terms.

Troubleshooting

This short troubleshooting section will hopefully solve any problems that you might encounter with your DVD player.

Reference

Limited Warranty

The Limited Warranty includes information on getting service for your DVD player.

Reference 53

Page 56

A Tour of the Remote

(buttons listed in alphabetical order)

FORWARD Allows you to search forward through a disc while it is in play mode (or slow speed search in pause mode).

GO BACK While using the on-screen menu system, takes you to the preceding menu screen.

GUIDE Allows you to see the titles that are available on the current DVD disc (if the disc contains a title menu).

INFO Displays information that is available about the disc, such as the current title, chapter, and playing time.

MENU Brings up the main menu of the DVD disc. The information you see will vary from disc to disc, and some discs may contain no menu at all. When in stop mode, use to access the Setup menu.

MOVE Arrows Use the arrows to navigate through the menu system of both the DVD player and the DVD discs. Use OK to choose a highlighted option.

Number Buttons Use the numbers to input information such as title/chapter numbers, track numbers, or to make selections on some menu screens.

POWER

PLAY FORWARDREVERSE

SKIP

MENU GUIDE

INFO

STOP

PAUSE

GO BACK

SKIP

OK Use to choose a highlighted option. PAUSE Pauses disc play. PLAY Begins disc play (and closes disc tray, if open). POWER Puts the player in standby mode when power is on. REVERSE Allows you to search backward through a disc

while it is in play mode (or slow speed search in pause mode).

SKIP+ Allows you to move to the beginning of the next chapter or track on a disc (in effect, “skipping” the chapter or track).

SKIP– Allows you to move to the beginning of the preceding chapter or track on a disc (in effect, “skipping” the chapter or track).

STOP Stops disc play.

54 Reference

Warning Icon

This icon indicates an invalid button press.

Page 57

A Short Glossary of DVD Terminology

Angles When making a DVD, the studio can incorporate various camera angles which you can select by using the ANGLE button on the remote. Note that not all DVDs contain multiple camera angles.

Chapter Each Title on a DVD can be divided into chapters (similar to tracks on an audio CD).

Disc Menu The Disc menu is an on-screen menu (or series of menus) included with the program content of a DVD. These menus vary from disc to disc, and should not be confused with the player’s own on-screen menus.

Dolby Digital A digital surround sound format that provides six separate (discrete) audio channels: left, right, center, left rear, right rear, and subwoofer.

To play back a Dolby Digital soundtrack, connect the DIGITAL AUDIO OUT jack to a compatible Dolby Digital receiver.

If you have a Dolby Pro Logic Surround decoder, you will obtain the full benefit of Pro Logic from the same DVD movies that provide full 5.1-channel Dolby Digital soundtracks, as well as from titles with the Dolby Surround mark.

LPCM Linear Pulse Code Modulation—a digital recording process. Turning LPCM on in the Setup menu converts 96KHz/24-bit digital audio to 48KHz/16-bit audio which is compatible with digital recording devices such as MiniDisc and DAT recorders.

Subtitling Because so much information can be stored on a DVD, many discs may contain foreign language subtitles.

Title A DVD may contain several different titles; for example, if a disc contains four different movies, each might be considered a title (and each may have several Chapters within it).

Reference 55

Page 58

Front Panel Controls

POWER

STANDBY

PHONES

–

VOLUME +

6 7 8 9

SKIP REV

OPEN•CLOSE

PLAY

STOP

SKIP FWD

PAUSE

1. POWER Button and STANDBY Indicator Light Use to turn the power on and off. The STANDBY indicator lights when the power is turned off and the player is connected to an AC power supply.

2. Disc Tray Press OPEN•CLOSE to open and close the disc tray.

3. SKIP REV Allows you to move to the beginning of the preceding title, chapter, or track on a disc (in effect, “skipping” the title, chapter, or track).

4. PLAY Begins disc play (and closes disc tray if open).

5. SKIP FWD Allows you to move to the beginning of the next title, chapter, or track on a disc (in effect, “skipping” the title, chapter, or track).

6. PHONES Headphone jack. You can attach headphones here for private listening.

7. VOLUME Use to adjust headphone volume level.

8. Front Panel Display (See following page for details.)

9. OPEN•CLOSE Press to open and close the disc tray.

10. STOP Stops disc play.

11 . PAUSE Pauses disc play (also use for frame advance).

56 Reference

Page 59

Front Panel Display

1 243

1. Indicates disc is loaded. Rotates when disc is playing or searching

2. Indicates still frame mode.

3. Indicates disc is playing.

4. Indicates repeat play mode.

5. Indicates disc is in pause mode.

6. Display. Some of the key messages displayed:

NO DISC No disc in player. NO PLAY Disc cannot be played (wrong Region Number, or rating is locked).

5 6 7

11 12

PBC Playback Control on a Video CD. P: # Program mode (P: track number). PAUSE Disc is in pause mode PLAY Disc is playing. READ Player is reading disc type and information. SEARCH Player is in search mode (forward or backward) SLOW Slow motion playback mode. STILL Still frame.

7. Indicates what type of audio is available on a DVD: mono, stereo, or surround.

8. Indicates a DVD disc is loaded in the player.

9. Indicates program play.

10. Indicates that the angle feature is available.

11. Indicates a disc is digitally recorded at 96KHz sampling rate.

12. Indicates a disc is digitally recorded at 24-bit resolution.

Reference 57

Page 60

Back Panel

COAXIAL

DIGITAL

AUDIO OUT

1 2 43

1. DIGITAL AUDIO OUT Use a coaxial digital cable to connect to a compatible Dolby Digital receiver. Dolby Digital offers theater-quality sound.

AUDIO OUT

VIDEO

OUT

S-VIDEO

OUT

2. AUDIO OUT R / L Jacks Connect to the R/L Audio input jacks of your television, audio/video receiver, or VCR.

3. VIDEO OUT Jack Use a video cable to connect this jack to the Video input on your television for a good quality picture.

4. S-VIDEO OUT Jack Use the S-Video cable to connect this jack to the S-Video jack on your television.

58 Reference

Page 61

Care and Maintenance

Handling Cautions

• Before connecting other components to this player, be sure to turn them all off.

• Do not move the player while a disc is being played, or the disc may be scratched or broken, and the player’s internal parts may be damaged.

• Do not put a flower vase filled with water or any small metal objects on the player.

• Be careful not to put your hand into the disc tray.

• Do not place anything other than the disc in the disc tray.

• Exterior influences such as lightning and static electricity can affect normal operation of this player. If this occurs, turn the player off and on again with the POWER button, or disconnect and then reconnect the AC power cord to the AC power outlet. The player will operate normally.

• Be sure to remove the disc and turn off the player after use.

• Disconnect the AC power cord from the AC outlet when you don’t intend to use the player for long periods of time.

Maintenance of Cabinet

For safety reasons, be sure to disconnect the AC power cord from the AC outlet.

• Do not use benzene, thinner, or other solvents for cleaning.

• Wipe the cabinet with a soft cloth.

Formation of Condensation

Due to sharp changes in temperature and humidity, condensation may form if warm air comes in contact with any cold parts inside the player.

• When condensation forms inside the player, the player may not operate correctly. If this occurs, leave the player at room temperature until the inside of the player becomes dry and operational.

• If condensation forms on a disc, wipe the disc with a soft and dry cloth by moving the cloth from the center hole toward the outer edge.

Reference 59

Page 62

Troubleshooting

Common Problem Solution

No Power Insert the power cord’s plug securely into the outlet and the cord’s AC IN plug to

the AC IN connector on the back of the player.

Power turns itself off The power is automatically turned off after approx 30 minutes have elapsed in

the stop mode (auto power-off feature). Turn power back on.

Play fails to start, even • Ensure that the disc is installed with the label side facing up. when PLAY is pressed • This player plays only DVD discs, Audio CDs and Video CDs.

Play commences but then • The disc is dirty. Clean it. stops immediately • Condensation has formed. Allow player to dry out.

No picture • Ensure that the equipment is connected properly.

• Turn on the TV’s power.

• Ensure that the input setting for the TV is correct.

Picture is distorted during • It is normal for some distortion to appear while scanning. forward and reverse scan

No sound or distorted sound • Ensure that the equipment is connected properly.

• Ensure that the input settings and the volume adjustment for the TV and/or receiver are correct.

• No sound is heard during still, frame advance, or slow-motion play.

No operations can be • Check the batteries in the remote. May need replacing. performed with remote • Operate the remote control at a distance of no more than 20 feet.

• Remove any obstacles between the remote and the DVD player or other component.

• Remove batteries and hold down one or more buttons for several minutes to drain the microprocessor inside the remote to reset it. Reinstall batteries and try remote again.

The icon appears on screen • The feature or action cannot be completed at this time because:

1. The DVD’s software restricts it.

2. The DVD software doesn’t support the feature (e.g., angles).

3. The feature is not available at the moment

4. You’ve requested a title or chapter number or search time that is out of range.

60 Reference

Page 63

Troubleshooting

DVD Problem Solution

Subtitle and/or audio If the subtitle and/or audio language does not exist on the disc, the language is not the one initial settings will not be seen/heard. The disc’s priority language is selected selected from the instead. Set the subtitle and or audio language initial setting manually. initial setting

No on-screen display The OFF setting is selected for OSD Display; select ON in the Setup menu.

The menu is displayed in a The Menu Language preference is set to that language. Go to the a foreign language Setup menu and select the language you prefer.

Play doesn’t begin when The rating limit has been set and the disc is subject to that restriction. a title is selected

No forward or reverse scan Some DVDs have sections that prohibit rapid scanning, or title and chapter skip.

Disc won’t play Both the player and the DVD is coded by region. If the regional codes don’t

match, the disc cannot be played. This player is Region No. 1.

Desired angle cannot be changed Some DVDs do not have the multi-camera angle system, and some discs have it

only on certain portions.

Picture is not displayed Make sure the TV SCREEN feature in the Setup menu is set correctly for your with correct aspect ratio television.

Forgot Rating Limit Password With the power on, press and hold the SKIP REV, PAUSE, and POWER buttons on

the player. This resets the password feature and all other settings to the initial factory settings. You may be required to select a menu language the next time you power up.

Cannot copy discs to video tape This player is equipped with anticopy protection.

Self-Diagnostic Message Solution

U 11 The disc is dirty. Wipe the discs with a soft cloth.

H When you see a code that begins with “H”, it means that the unit

is not functioning properly. Turn the unit off and on again by pressing POWER twice or unplug the AC power cord from the wall outlet, and then plug the unit back in. This will make the unit operate normally if external electrical influences such as lightning or static electricity have affected the operation of the unit.

Reference 61

Page 64

Limited Warranty

What your warranty covers:

• Any defect in materials or workmanship.

For how long after your purchase:

• 90 days - Unit exchange, which includes parts and labor.

• 91 days to 1 year - Unit exchange, which includes parts only; you pay the labor.

• The warranty for rental units begins with the first rental or 45 days from date of shipment to the rental firm, whichever comes first.

What we will do:

During the initial 90 days:

Exchange the DVD unit with a new or, at our option, refurbished unit.

After the 90 days and within one year:

Exchange the DVD unit with a new or, at our option, refurbished unit. We will bill you a flat exchange charge to replace a defective unit. This charge covers the labor cost for its repair.

How you get service:

• Call 1-800-311-9263 and have your unit’s date of purchase and model/serial number ready. The model/ serial number information is on the back of your unit.

• A representative will troubleshoot your problem over the phone.

• If the representative determines that you should receive a replacement unit you will be provided with a Return Authorization (RA) number and the location of a nearby exchange point if one exists. No returns will be accepted without the RA number.

To receive a replacement unit before you return yours:

If you are located near an exchange point:

1. We will send a replacement unit to our exchange point.

2. The exchange location will notify you of its arrival.

3. Take your unit and your evidence of purchase date, such as a bill of sale, to the exchange location and you will be provided the new or refurbished unit. Please retain all accessories such as the remote control hand unit.

4. If the repairs are covered by your warranty, you will not be billed.

If you are not located near an exchange point:

1. Provide your Discover, MasterCard or Visa account number and expiration date to your phone representative. This is for security purposes only and your account will not be charged at this time.

2. We will send you a replacement unit.

3. If you return the unit to us within 14 days from the date you were provided a Return Authorization number, only items not covered by warranty will be charged to your account. If your unit is not

received within 14 days, the suggested retail value of the unit will be charged to your credit card. This amount will be credited if the unit is subsequently received.

4. Ship your defective unit back to us, excluding all accessories, using the replacement unit’s carton. Shipping instructions will be included on the carton along with your RA number which will allow you to easily ship the unit back to us. Make sure you insure your shipment in case of damage or loss. Include with the shipment:

62 Reference

Page 65

Limited Warranty

• Evidence of purchase date such as a bill of sale, to verify your unit’s warranty eligibility.

• A brief note describing your unit’s problem.

• Your name, address and phone number.

Thomson assumes no responsibility of warranty shipments from the customer to the factory if not shipped in the manner prescribed by Thomson.

Return transportation, storage, handling and insurance costs are your responsibility. We accept no responsibility in case of damage or loss.

To receive a replacement unit after we have received your unit:

• Write the RA number on the outside of the carton used to return the unit. Make sure you insure your shipment in case of damage or loss.

• Carefully pack the unit using the original box and packing material if possible. Please retain all accessories that were included with your unit such as the remote control hand unit.

• Include with the shipment:

1. Evidence of purchase date such as a bill of sale, to verify your unit’s warranty eligibility.

2. A brief note describing your unit’s problem.

3. Your name, address and phone number.

• The representative will advise the address to mail a cashier’s check or money order for payment if there are any out of warranty labor or parts charges, and you elect not to use your credit card.

• After we receive your product, a new or refurbished unit will be shipped to you.

What Your Warranty Does Not Cover:

• Acts of God, such as but not limited to lightning damage.

• Adjustment of customer controls.

• Damage from misuse or neglect.

• A unit that has been modified or incorporated into other products or is used for institutional or other commercial purposes.

• Batteries.

• Units purchased or serviced outside the U.S.A.

• Shipping damage if the unit was not packed and shipped in the manner prescribed by Thomson.

• Storage fees may be charged by the exchange point if you fail to pickup the replacement unit in a timely manner.

Product Registration:

• Please complete and mail the Product Registration Card packed with your DVD product. It will make it easier to contact you should it ever be necessary. The return of the card is not required for warranty coverage.

How State Law Relates to Warranty:

• This warranty gives you specific legal rights and you may have other rights that vary from state to state.

If You Purchased Your Product Outside the United States:

• This warranty does not apply. See your dealer for warranty information.

Reference 63

Page 66

Index

A-B repeat 44, 52 AC IN connector 12 AC power cord

connecting 12

Advanced Options menu 37

4x3 Preference 37 Audio for 2x playback 37 Dynamic Range Compression 37

Pause Scanning 37 Angles, description of 55 Audio

Audio language 20

Dolby Digital 10, 36, 55

Dynamic Range Compression 37

for 2x playback 37

LPCM 36, 55 Audio CD

loading a disc 40

playback features 41 Audio channel output, changing 49 Audio language 20, 26

changing 20 AUDIO OUT MIXED FRONT L/R jacks 58 Audio Preference menu 26 Audio/video cables 6, 11

Digital cable 6 Digital output 36

Dolby Digital 36 LPCM 36

selecting type 36 Disc Languages menu 26 Disc menu 15, 55 Disc tray 56 Discs, types that can be played 5 Displays, front panel 57 Dolby Digital 10, 36, 55 DVD

playback features 16 Dynamic Range Compression 37

Elapsed time 18

Fast motion playback 16 Frame advance 16 Freeze frame (pause) 16 Front panel controls 56 Front panel display 34, 57

dimming 34

messages 56

Back panel controls 58 Batteries, remote 4

Camera angle 21

changing 21 Chapter, description of 55 Chapter scan search 16 Coaxial cable, F-type 6 Codes

language 38 Connections

DVD Player + TV + Dolby Digital Receiver 10

DVD player + TV + VCR 11

DVD player + TV with A/V input jacks 9

DVD player + TV without A/V input Jacks 8 Contents 1

64 Reference

Glossary 55

Indicators, front panel 57 Information display 24, 40, 44, 51

additional features (audio CD) 44 additional features (DVD) 24 additional features (video CD) 51

Language code list 38 Limited warranty 62 Loading a disc

audio CD 40 DVD 14 video CD 46

LPCM 36, 55

Page 67

Index

Maintenance 59 Marker 22, 44, 52

clearing 23 recalling 23

Menu language 32

changing 32 setting up 12

Menu Preference menu 28

On-screen display 33

turning on/off 33

Password 29 PHONES headphone jack 56 Picture scan 16 Playback control 47

bypassing 47

Playback features

audio CD 41 DVD 16

Program Playback

deleting programmed tracks 50

Program playback 42, 49

audio CD 42 Deleting programmed tracks 43 video CD 49

Random playback 43, 51

audio CD 43 video CD 51

Rating limit 28

changing password 31 locking 29

unlocking 30 Regional coding 13 Remote

installing batteries 4

tour of 54 Repeat mode 44, 52 Repeat play

DVD 17 RF modulator 6, 8

S-video cable 11 S-VIDEO OUT jack 6, 11, 58 Scanning tracks 41

audio CD 41

chapter scan 16 fast motion playback 16

Searching for scenes

by chapter 17 by title 17

Selecting a track

audio CD 41

video CD 48 Setup menu 25, 28 Skipping tracks

audio CD 41

video CD 48 Slow motion playback 16 STANDBY indicator light 56 Subtitle language 19

changing 19 Subtitle Preference menu 27 Subtitling, description of 55

Title, description of 55 Track selection

audio CD 41

video CD 48 Track skip

audio CD 41

video CD 48 Troubleshooting 60 TV screen setting 35

standard TV 35

widescreen TV 35

Video CD 45

loading 46 VIDEO OUT jacks 11, 58 VOLUME dial 56

Warranty, limited 62

Reference 65

Page 68

10330 North Meridian Street Indianapolis, IN 46290

Trademark(s)® Registered

Marca(s) Registrada(s)

Printed in Japan

TOCOM 15311080

RCA RC5210P User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
