usermanual
RS2520/RS2521/RS2522/RS2550
RS3520/RS3522
VTCD550
A3000/A3005/A3200/A3205/A3400
FCC Information
RCA Information
This device generates and uses radio frequency (RF)
energy, and if not installed and used properly, this
equipment may cause interference to radio and television reception.
This product complies with DHHS Rules 21 CFR
Subchapter J. Applicable at the date of manufacture.
This equipment has been type tested and found to
comply with the specifications in Subpart J of Part 15
of FCC Rules. These rules are designed to provide reasonable protection against radio and television interference in a residential installation. However , there is
no guarantee that interference will not occur in particular installations.
If this equipment does cause interference to radio or
television reception (which you can determine by
turning the equipment off and on), try to correct the
interference by one or more of the following measures:
• Reorient the receiving antenna (that is,
the antenna for the radio or television
that is "receiving" the interference).
• Move the unit away from the equipment
that is receiving interference.
• Plug the unit into a different wall outlet
so that the unit and the equipment
receiving interference are on different
branch circuits.
If these measures do not eliminate the interference,
please consult your dealer or an experienced
radio/television technician for additional suggestions.
Also, the Federal Communications Commission has
prepared a helpful booklet, "How To Identify and
Resolve Radio TV Interference Problems." This booklet is available from the U.S. Government Printing
Office, Washington, DC 20402. Please specify stock
number 004-000-00345-4 when ordering copies.
For Your Safety
The AC power plug is polarized (one blade is wider
than the other) and only fits
into AC power outlets one
way. If the plug won’ t go
into the outlet completely,
turn the plug over and try to insert it the other way.
If it still won’t fit, contact a qualified electrician to
change the outlet, or use a different one. Do not
attempt to bypass this safety feature.
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE
SLOT , FULLY INSERT.
For Your Records
In the event that service should be required, you may
need both the model number and the serial number .
In the space below, record the date and place of purchase, and the serial number:
Model No.
Remote Control No.
Date of Purchase
Place of Purchase
Serial No.
Service Information
This product should be serviced only by those specially trained in appropriate servicing techniques. For
instructions on how to obtain service, refer to the
warranty included in this Guide.
EN
Have a Blast- Just Not in Your Eardrums
Make sure you turn down the volume
on the unit before you put on headphones. Increase the volume to the
desired level only after headphone are
in place.
WARNING: TO PREVENT FIRE
OR ELECTRICAL SHOCK HAZARD,
DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
THE LIGHTNING
FLASH AND ARROWHEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
"DANGEROUS
VOLTAGE" INSIDE
THE PRODUCT.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
DO NOT OPEN
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
Contents
FCC/ Safety Information
Installation . . . . . . . . . .2
Controls & Indicators
CD Player . . . . . . . . . . . . . . . .3
Tape Player . . . . . . . . . . . . . .4
Remote Control . . . . . . . . . .4
Display
Showing the Demonstration
. . . . . . . . . . . . . . . . . . . . . . . .5
Display Alarm/Clock . . . . . . .5
Setting the Time . . . . . . . . .5
Setting the Timer . . . . . . . . .5
Activating the Timer . . . . . .5
Adjusting the Display
Brightness . . . . . . . . . . . . . . .5
Sleep Mode . . . . . . . . . . . . . .5
Sound Features
Using Preset Equalizer Curves
. . . . . . . . . . . . . . . . . . . . . . . .6
Creating a Custom Curve
. . . . . . . . . . . . . . . . . . . . . . . .6
Activating Surround Sound .
. . . . . . . . . . . . . . . . . . . . . . . .6
Boosting the Bass . . . . . . . . .6
Muting Audio . . . . . . . . . . . .6
X- Surround . . . . . . . . . . . . . .6
CD Player
Loading Discs . . . . . . . . . . . .6
Playing Discs . . . . . . . . . . . . .6
Shuffling the Play Order . . .6
Sampling Tracks . . . . . . . . . .6
Repeating the Play Order . .6
Setting Up a CD program . .7
Playing a Program List . . . . .7
Displaying the Program list
. . . . . . . . . . . . . . . . . . . . . . . .7
Deleting a Track from a
Program List . . . . . . . . . . . . .7
Automatically Skipping
Tracks (ATS) . . . . . . . . . . . . . .7
Creating an ATS Program . .7
Editing an ATS Program . . .7
Skipping a Disk . . . . . . . . . . .7
Searching through a CD . . .7
T uner
Tuning to a Station . . . . . . .8
Using Presets . . . . . . . . . . . .8
Auto Preset Program (for FM
only) . . . . . . . . . . . . . . . . . . . .8
Setting Presets . . . . . . . . . . .8
Suppressing Stereo Signal
. . . . . . . . . . . . . . . . . . . . . . . .8
Tuning to an RDS Station
. . . . . . . . . . . . . . . . . . . . . . . .8
Displaying RDS Station
Information . . . . . . . . . . . . .8
Searching by Program
Type (PTY) . . . . . . . . . . . . . . .9
Tape Player
Playing a Tape . . . . . . . . . . .9
Continuous Play . . . . . . . . . .9
Recording . . . . . . . . . . . . . . .9
From Tuner . . . . . . . . . . . . . .9
From CD . . . . . . . . . . . . . . . .9
Tape to Tape . . . . . . . . . . . . .9
From an Auxiliary Input . . .9
Troubleshooting Tips
. . . . . . . . . . . . . . . . . . .10
Maintenance
Cleaning . . . . . . . . . . . . . . .10
CD Player . . . . . . . . . . . . . . .10
Tape Player . . . . . . . . . . . . .10
More Information . . . .11
US Warranty . . . . . . . .12
Canadian Warranty . . .13
RS2520/ RS2521/ RS2522
RS2550
RS3520/ RS3522
VTCD550
A3000/A3005/A3200/
A3205/A3400
EN
1
Installation
RS2550/
VTCD550
RS2520/
RS3520/A3000/
A3005
To ensure sufficient ventilation, keep the spacings shown below
free from other surfaces:
1
10 cm 10 cm
10 cm
5 cm
10 cm
EN
RS2522/ RS3522/
A3400
2
3
4
2
5
6
RS2521/ A3200/
A3205
1
2
3
4
5
6
1
2
3
4
6
1
2
3
4
5
6
1. AM Loop Antenna Connector
2. Auxillary Connector
3. Surround Speaker Jacks
4. Main Speaker Jacks
5. Subwoofer Speaker Jacks
6. Optical Output
(only available for Thomson Models)
7. FM Antenna Jack (for A3400 only)
7
~
- -
~
~
- -
+ +
POWER
DIMMER/DEMO
PHONES
DECK 1 DECK 2
RECORD/PLAYBACK
DIRECT DISC ACCESS
2
3
1
DISC
DISC
DISC
SIMULTANEOUS PLAY AND LOAD SYSTEM
5 DISC CHANGER
DIGITAL PLL
SYNTHESIZED TUNER
X-SURR.
X-S
URROUND
D
I
G
I
T
A
L
M
U
L
T
I
F
U
N
C
N
O
T
I
P
L
A
Y
/
P
A
U
S
E
G
S
O
J
I
T
L
U
M
S
O
U
R
C
E
-
S
T
O
P
E
Q
/
C
U
S
T
U
M
E
Q
S
H
U
F
F
L
E
I
N
T
R
O
R
E
P
E
A
T
A
T
S
S
T
E
A
U
T
O
M
A
T
I
C
R
E
C
O
R
D
L
E
V
E
L
/
A
U
T
O
S
T
O
P
OPEN/CLOSE
DISC SKIP
4
5
DISC
DISC
CLOCK
B. BOOST
TIMER
BAND
Y
A
L
P
S
I
D
T
N
E
C
E
R
O
U
L
F
E
M
U
L
O
V
FM ST/SCAN
T
A
T
I
O
N
+
S
S
A
B
T
S
O
O
B
KEVLAR
SOUND SYSTEM
/
E
D
O
M
P
L
E
H
D
N
U
O
R
R
U
S
-
X
PLAYBACK
1
-
2
G
N
I
B
B
U
D
E
P
A
T
/
Y
A
L
P
S
U
O
U
N
I
T
N
O
C
3
Controls and Indicators
EN
CD Player
OPEN/CLOSE —Opens or closes
the disc tray.
DISC 1 - DISC 5 — Selects disc 1, 2,
3, 4, or 5
DISC SKIP — Skips to the next CD
in the tray
STANDBY/POWER (RCA models)
— Turns power on or off (ST ANDBY mode). ST ANDBY/ POWER/
ECO (Thomson models) — keep
pressing briefly STANDBY mode
to enter ECO (power saving, without clock display) mode.
PHONES — Jack for connecting
headphones
SOURCE— Selects the CD player/
tuner/ tape player/ external source
SET — Sets tuner or CD presets
mode
DEMO/DIMMER — Turns the feature demonstration on or off
STOP — Stops CD track
(stops tape on digital
tape drives)
SKIP FORWARD —
Increments radio frequency or CD tracks
SKIP BACKWARD —
Decrements radio frequency or CD tracks
PLA Y/PAUSE — Plays or
pauses CD
CLOCK — Shows clock time and
enters clock setting mode.
TIMER — Enters timer setting
mode and turns the mode on/off.
BAND
— Changes among tuner
bands. FM/AM for RCA and
FM/MW/LW for Thomson.
Enters autopreset program in
FM mode.
FM ST/ SCAN — Toggles between
FM stereo and mono. Enters tuner
scan mode.
SHUFFLE—Turns SHUFFLE mode
on or off to play CDs randomly .
(PTY/MIX for Thomson series)
INTRO—Turns INTRO mode on or
off to play the first 10 seconds of
each track. (RDSTIME/INTRO on
Thomson models)
REPEAT
(for RCA models) —
Turns REPEAT mode on or off to
repeat a track, a disc, or all discs.
REPEAT/ RDS (for Thomson models)
— also shows RDS informa-
tion in Tuner mode (FM).
ATS —Sets up an automatic track
skip program
BASS BOOST — Turns bass boost
on or off
EQ/ CUSTOM EQ — Toggles
among FLAT, ROCK, JAZZ, POP,
CLASSICAL & CUSTOM modes.
X-SOUND/ HELP MODE —
Press once to activate X-SURROUND
(only for RS2521, RS2522,
RS3520, RS3522, A3200, A3205,
A3400)
. Keep pressing briefly to
turn
HELP mode on or off to dis-
play useful information about sys-
tem keys and features.
VOLUME—Increases/ decreases
volume.
JOG WHEEL —
Turn (+) to
increase or (-)
to decrease
numeric values
on display/
select tuner
preset stations/
select CD tracks
Multi-function JOG
DIRECT DISC ACCESS
2
3
4
1
DISC
DISC
DISC
SIMULTANEOUS PLAY AND LOAD SYSTEM
5
DISC
DISC
5 DISC CHANGER
DIGITAL PLL
SYNTHESIZED TUNER
POWER
DIMMER/DEMO
PHONES
DECK 1 DECK 2
RECORD/PLAYBACK
X-SURR.
D
I
P
L
A
Y
/
P
A
U
S
E
S
O
U
S
T
O
P
S
H
U
F
F
L
E
I
N
T
R
O
R
E
P
E
A
T
A
U
T
O
M
A
T
I
C
R
E
C
O
R
D
L
E
X-S
URROUND
G
I
T
A
L
M
U
L
T
I
F
U
N
C
N
O
T
I
G
O
J
I
T
L
U
M
R
C
E
-
E
Q
/
C
U
S
T
U
M
E
Q
A
T
S
S
T
E
V
E
L
/
A
U
T
O
S
T
O
P
Y
A
L
P
S
I
D
T
N
E
C
E
R
O
U
L
F
E
M
U
L
O
V
S
T
A
T
I
O
N
+
S
S
A
B
T
S
O
O
B
D
O
M
P
L
E
H
U
O
R
R
U
S
-
X
/
Y
A
L
P
S
U
O
U
N
I
T
N
O
C
DISC SKIP
B. BOOST
/
E
D
N
G
N
I
B
B
U
D
E
P
A
T
OPEN/CLOSE
CLOCK
TIMER
BAND
FM ST/SCAN
KEVLAR
SOUND SYSTEM
PLAYBACK
1
-
2
G
S
O
T
J
A
I
T
T
I
L
O
U
M
N
-
S
T
E
+
Controls and Indicators
Remote Control
POWER — (RCA models) —
Turns power on or of f
(STANDBY mode). (Thomson
models) — keep pressing
briefly STANDBY mode to
enter ECO (power saving,
without clock display) mode.
TUNER — Selects tuner
CD — Selects CD player
TAPE— Selects tape player
AUX — Selects an external
input.
MUTE — Mutes volume
VOL+ or VOL- — Increases/
decreases volume
EQ PRESET — Selects equalizer presets
HELP — Turns HELP mode
on/off
PLA Y— Plays current CD
STOP — Stops playing CD
TRACK FWD — Increments CD track; searches
through CD
TRACK REV — Decrements CD track; searches
through CD
(Press TRACK FWD/ REV to tune up/ down tuner
frequency)
DISC SKIP — Skips to next CD
REPEAT —(REPEAT/RDS — Thomson models)
Repeats a track, CD, or all CDs. When the radio is
active, displays RDS information
PAUSE— Pauses the CD
SHUFFLE (MIX/PTY SEARCH — Thomson models)
— Turns on/off random listening
BASS B. — Turns on or off Bass Boost
SLEEP — Press to select the time interval in
minute before the unit turns off.
PRESET UP/DOWN — Selects next/ previous preset
station
SURROUND — Activates X- SURROUND (only for
RS2521, RS2522, RS3520, RS3522, A3200, A3205,
A3400). Otherwise, does not function in this unit.
RECORD — does not function in this unit
Tape Player
6+2 RS2520, RS2521, RS2550, RS3520, RS3522
VTCD550, A3000, A3005
6+5 A3200, A3205, A3400
6+2 and 6+5 tape controls include:
RECORD
PLAY
REWIND
FAST -FORW ARD
STOP/EJECT
PAUSE
Tip: In STANDBY mode (press
POWER off), the system displays
the time. Press POWER to turn
the system on in the previously
used mode. Press CD, TAPE,
TUNER, or A U X to select the corresponding
mode. Look at the display icons to identify
the current mode.
EN
4
Tip: Depending on your system model, your
tape drive is
either controlled
by 6+2 or 6+5
mechanical buttons located
below the decks.
POWER
CDTUNER
R
E
P
S
E
T
Q
E
--
M
E
U
T
TRACK REV
STOP
REPEAT DISC SKIP SHUFFLE
RECORD
PRESET
SLEEP
AUX
TAPE
PLAYPAUSEHELP
TRACK FWD
SURROUND
BASS B.
VOLVOL
+
5
EN
Display
Showing the Demonstration
Not operational in CD mode. Press DEMO/DIMMER
to turn on/off demonstration mode. The demonstration scrolls through all display operations.
DISPLA Y ALARM/CLOCK
Setting the Time
1. Press CLOCK until the time flashes on the display
(12-hour clock for RCA, 24-hour clock for Thomson).
2. Rotate MUL TI JOG to set the hour and then press
SKIP FORWARD to shift to minute digits.
3. Rotate MUL TI JOG to set the minute.
4. Press SET to save settings and STOP to quit setting.
Note: When system is ON, you can press CLOCK to
display the current time for about 2 seconds.
Setting the Timer
1. Press TIMER until the ON and clock time flash on
the display ( ON - timer on time ) (12-hour clock for
RCA, 24-hour clock for Thomson).
2. For setting time, rotate MUL TI JOG to set the
hour and then press SKIP FORWARD to shift to
minute digits.
3. Rotate MUL TI JOG to set the minute.
4. Press SKIP FORWARD to change to OF (timer off
time) with clock time flashes. Repeat steps 2 & 3 for
timer off time setting.
5. Press SET to save settings and STOP to quit setting.
Activating the Timer
Press and release TIMER to turn on/off
the alarm. The alarm is active when the
clock icon indicator is lit.
Adjusting the Display Brightness
1. Press and hold DEMO/DIMMER for more than 2
seconds.
2. While the dimmer is displayed, rotate MUL TI JOG to
select the desired level (DIMM
0 - 3).
Sleep Mode
Y ou can select the time interval in minute before the
unit turn off automatically . Press SLEEP on the
remote to select among 5,15, 30, 45, 60, 90 & 120
minutes.
DIM 2
Tip: DEMO
Mode does
not affect the
current system
operation. When the
system is initially plugged
in, DEMO mode is activated.
BASS
SURROUND
CD PLAYER
Loading Discs
1. Press SOURCE repeatedly to select CD mode.
2. Press OPEN/CLOSE to open the drawer.
3. Insert up to five discs with label face up. (Press DISC
SKIP to rotate the disc carrier.)
4. Press OPEN/CLOSE to close the drawer. Loaded disc
position icon lights.
Playing Discs
Press PLA Y/PAUSE to begin or pause play, and STOP
to stop play.
Select a specific disc by pressing DISC 1 - DISC 5.
Press SKIP FORWARD/ BACKWARDto select a specific track.
Play and load simultaneously by:
1. Press OPEN/CLOSE to open the tray while a
CD is playing
2. Load/change discs for available trays by pressing
DISC SKIP.
3. Press OPEN/CLOSE to close the tray.
Shuffling the Play Order
Press SHUFFLE to turn on/off the playing of tracks in
random order . (PTY/MIXfor Thomson models.)
Sampling Tracks
Press INTRO to play the first 10 seconds of each track
on the current disc, all discs in the tray, or turn INTRO
mode off.
(Note: Y ou may also press REPEAT to select 1 disc or
all discs before activating INTRO & SHUFFLE functions)
Repeating the Play Order
Press REPEATto repeat the current track, current disc,
all discs, or turn REPEATmode off.
Using Preset Equalizer Curves
Press PRESET EQ to toggle among
FLAT, ROCK, JAZZ, POP, CLASSICAL
& CUSTOM. The display shows
briefly the selection.
Creating a Custom Curve
1. Press PRESET EQ to select CUSTOM
mode.
2. While "CUSTOM" is displayed, rotate MUL TI JOG
to cycle among displayed bass-, mid-, and treble range levels.
3. While BAS, MID, or TRE is displayed, adjust VOLUME to set
the associated gain between -10
- +10.
Boosting the Bass
Press BASS BOOST to turn on/off boosting the bass
frequency.
Muting Audio
Press MUTE on the remote to
cut the sound.
X- Surround
Press X- SURROUND to enjoy enriched sound quality.
This feature gives you:
1. Better width and depth for vocal and instrumental
sound.
2. More powerful presence for studio recording.
3. Enhanced surround effects with greater flexibility
in positioning speakers.
FLAT
Tip: While playing a CD, press
and hold SKIP-FORWARD or
BACKWARD for more than 2 sec-
onds to search through the CD.
EN
MID+08
POP
JAZZ
ROCK
CUSTOM
MUTE
Sound Features
6
CLASS
DIRECT DISC ACCESS
2
3
4
1
DISC
DISC
SIMULTANEOUS PLAY AND LOAD SYSTEM
5 DISC CHANGER
5
DISC
DISC
DISC
OPEN/CLOSE
DISC SKIP
7
EN
CD Player
Setting Up a CD Program
Y ou can program the CD player to play up to any 32
tracks on the CDs in the tray.
1. While the CD player is stopped, press SET to enter
program mode. The system displays the next available program number: “- - P:01,” with “- -” flashing,
prompts you for the first track in the program list.
2. Rotate MUL TI JOGto select a track (press DISC
SKIP or DISK 1 - DISK 5
to select a track from a
different disc).
3. Immediately press SET
to assign the selected
track to the program number . After 3 seconds, you
are prompted for the next track in the program list.
(In CD program mode, PROG icon will be lit.)
Playing a Program List
While in PROGRAM mode, press PLAY.
Displaying the Program List
1. While the CD player is stopped, press SET to enter
PROGRAM mode.
2. Press SET repeatedly to list each track assignment
in the program list.
Deleting a T rack fr om
a Program List
While in PROGRAM mode, display the programmed
track to be deleted (press SET if
necessary to cycle through the
list) and immediately press
STOP. To clear the whole
programmed list, press
and hold STOP for 5
seconds. The system
displays the message
CLEAR.
Automatically Skipping Tracks
(ATS)
Creating an ATS Program
1. Press STOP.
2. Press ATS to display “- - P:01"
3. Press DISC SKIP or DISC (1-5) to specify a disc.
4. Rotate the jog to specify the first track to skip, and
press SET.
5. Repeat the previous step to add more tracks to the
ATS program.
6. Press PLA Yto play the ATS program.
Editing an A TS Pr ogram
1. Press STOP.
2. Press ATS.
3. Press SET repeatedly until the display shows the
track you want to change.
4. Press DISC SKIP or DISC (1-5) to specify a disc.
5. Rotate the jog to specify the replacement track to
be skipped, and press SET.
6. Repeat the previous step to change other previously programmed tracks.
7. Press PLA Yto play the program.
Note: During ATS mode, ATS icon will be lit.
Skipping a Disk
Press DISC SKIP.
Searching Through a CD
Press and hold SKIP FORWARD/ BACKWARD
to search through a CD as it is playing.
Tip: You can create a
program of up to 32 tracks
Caution: Do not push to force clos-
ing of the tray during CD playback or
tray opening.
5 P:01
DISC
DIRECT DISC ACCESS
DISC
2
1
DISC
3
DISC
4
DISC
5
8
1. Press SOURCE to select TUNER.
2. Press BAND to select the next radio band.
Choices are:
AM/FM (RCA models)
FM/MW/LW (Thomson models)
The tuner can be either TUNE or PRESET mode.
When in PRESET mode, the PROG light is on.
Tuning to a Station
Press SKIP FORWARD/
BACKWARD to select fre-
quencies.
Using Presets
Rotate MUL TI JOGto access the previous or next preset station. The display first shows the preset program
number and after a few seconds, the frequency and
then the preset program number again. (FMPR:01 is
FM preset 1)
Auto Preset Programming (for FM
only)
Press and hold BAND
button for 2 second to
scan stations in the selected band. The stations will
then be stored as preset
channels. Maximum 32 stations can be stored. Beware
of your preset channels being erased accidentally
because the scanning and storing process is automatic
upon pressing the button.
Y ou can stop the automatic scan by pressing anybutton, but the erased stations cannot be recovered.
Setting Presets
1. Press SKIP FORWARD/ BACKWARD to access the
desired frequency.
2. Press the SET button once.
3. The most recently accessed program location will
be displayed.
4. If a different program location is preferred, rotate
MUL TI JOG to move to the desired preset number (1-
32).
5. Press SET to store the selected frequency at that
preset.
Suppressing Stereo Signal
Press FM ST/SCAN to toggle between FM mono and
stereo for stereo FM stations.
Thomson models
Tuning to an RDS Station
1. Rotate MUL TI JOG to preset station or press SKIP
FORWARD/ BACKWARD to desired frequency.
2. If RDS station found, RDS lights on display with station name shown.
PR:01
87.50 MHz
Tip: Your audio system has 32 preset stations.
Tip: Press F M ST/ SCAN for more than 1
second to automatically tune up/down the
band for the next station. When a station
is detected, it will stop for 5 seconds to let
you save the station. After 5 seconds (if no
keys is pressed), it will continue to search for
next station.
EN
Tuner
Tip: RDS stations broadcast on FM
only. When the tuner detects an
RDS signal, the RDS icons turns
on.
BBC No...
SCIENC...12:05
DIGITAL PLL
SYNTHESIZED TUNER
POWER
X-SURR.
DIMMER/DEMO
P
L
PHONES
S
H
U
F
F
L
E
I
X-S
URROUND
D
I
G
I
T
A
L
M
U
A
Y
/
P
A
U
S
E
S
O
U
R
C
E
S
T
O
P
E
Q
/
C
U
S
T
U
M
E
Q
N
T
R
O
R
E
P
E
A
T
A
T
S
Y
A
L
P
S
I
D
T
N
L
E
T
C
I
E
F
R
U
O
N
U
C
N
O
L
T
I
F
E
M
U
L
O
V
G
S
O
T
J
A
I
T
T
I
L
O
U
N
M
+
-
S
S
A
B
T
S
O
O
B
/
E
D
O
M
P
L
E
H
D
N
U
O
R
R
U
S
-
X
S
T
E
CLOCK
B. BOOST
TIMER
BAND
FM ST/SCAN
KEVLAR
SOUND SYSTEM
9
EN
Tuner
Displaying RDS Station
Information
Toggle REPEAT/ RDS to display the frequency, station
name (PS), station type (PTY), clock time (CT), or radio
text (RT). In CT mode, press CT/INTRO key to replace
the displayed time by RDS station time. If clock
time is not yet set, this information will
be shown as clock time automatically.
Searching by Program Type (PTY)
1. Press PTY/MIX to enter PTY selection
2. Toggle PTY/MIXor rotate the jog to select a PTY
mode.
3. Within 5 seconds, press PRESET SKIP FORWARD/
BACKWARD to search for a station broadcasting the
selected type of program.
Tape Player
Playing a Tape
Tip: You can play a tape from either deck.
1. Press SOURCE repeatedly to select TAPE.
2. Press STOP/EJECT to open the cassette door.
3. Insert a tape into the door and push the door
closed.
4. Press REWIND/FAST FORWARDto position the
tape to the desired starting position.
5. Press PLA Y.
Continuous Play
1. Insert a tape into deck 2 and start playback.
2. Insert a tape into deck 1 and press PLA Y and
PAUSEtogether.
3. When the tape in deck 2 finishes playback, PAUSE
at deck 1 will be released automatically and start
playback.
Recording
From Tuner
1. Insert a tape into deck 1.
2. Press SOURCE repeatedly to select TUNER and to
access the desired radio band.
3. Tune to the station to be recorded.
4. Press RECORD to begin recording.
5. Press STOP to end recording.
From CD
1. Insert a tape into deck 1.
2. Press SOURCE repeatedly to select CD.
3. Insert the disc(s) to be recorded.
4. Select the track, CD, or program to be recorded.
5. Press RECORD to begin recording.
6. CD begins to play.
7. Press STOP to end recording.
Tape to T ape
1. Insert the destination tape in deck 1.
2. Insert the source tape into deck 2.
3. Press PAUSEand then RECORD on deck 1.
4. Press PLA Yon deck 2. The playback and recording
start simultaneously.
From an Auxiliary Input
1. Insert the cassette in deck 1.
2. Check that the auxiliary device has been connected
correctly to the AUX connector on the back of the
audio system.
3. Start playback on the auxiliary device.
4. Press RECORD on deck 1 to begin recording.
5.. Press STOP to end recording.
Tip: You can search for stations using one of the
following program types: R D S NEWS(news),
AFFAIR ( news and documentaries), INFO (weather,
medical), SPORT (sports), EDUCAT (education), DRAMA
(series and plays), CULTUR (religion), SCIENC (science
and technology), VARIED (miscellaneous), POP M (pop
music), ROCK M (rock music), MOR M (middle-of-the
road music), LIGHTM (light music), CLASSI (classical
music), OTHERM (unclassified music), ALARM (alarm).
X
DECK 1 DECK 2
RECORD/PLAYBACK
A
U
T
O
M
A
T
I
C
R
E
C
O
R
D
L
E
V
E
L
/
A
U
T
O
1
-
2
G
N
I
B
B
U
D
E
P
A
T
/
Y
A
L
P
S
U
O
U
N
I
S
T
T
N
O
O
P
C
DECK 1 DECK 2
RECORD/PLAYBACK
PLAYBACK
PLAYBACK
10
EN
Solution
Check power cord for a secure connection.
Unplug the unit for a moment, and then
plug into power source again.
Check the outlet by plugging in another
device.
Increase the volume setting.
Check connection to speakers.
Check that you have selected the appropriate function: CD, TAPE, T uner.
Check antenna connection.
Move antenna.
Turn off nearby electrical appliances, such
as hair dryer, vacuum cleaner, microwave,
fluorescent lights.
Check that CD is in the tray.
Check that CD label is facing up.
Check that PAUSE mode is not on.
Check that CD function is selected.
Clean the disc.
Check disc for warping, scratches, or other
damage.
Check if something is causing the system to
vibrate. If so, move the system.
Problem
System will
not turn on
No sound
Poor radio
reception
CD does
not play
CD sound
skips
Problem
CD button
will not
respond, or
does not
change
discs when
you press
DISC SKIP
Distorted or
noisy tape
recordings
Remote
control
does not
work
Solution
Switch to another function (TAPE, T uner)
and then back to CD.
Inspect the tape heads and clean and
demagnetize.
Check that the batteries are properly
installed.
Replace weak batteries.
Check the system is plugged in to power
source.
Point the remote directly at the system’s
front panel.
Move closer to the system.
Remove any obstacles between the remote
and the system.
Disconnect the audio system from the power source
before performing any maintenance.
Cleaning
Clean the exterior of the system using a soft dust
cloth.
CD Player
CAUTION! This system operates with a laser. It must
be opened by only a qualified technician.
Tape Player
To prevent deterioration of sound quality, periodically open the door of each deck and clean the magnet-
ic heads, pinch roller , and capstan with a cotton bud
dipped in alcohol. Also, demagnetize the head by
playing a demagnetizing cassette (available through
an audio equipment store).
To protect recordings one or
both sides of a tape, remove
the corresponding tab. If you
later want to record on the
tape, affix a piece of adhesive tape over the hole.
Quit Slacking - A little bit of slack in
your tapes can cause scratches on
the tape, or worse yet, the tape
could break. If you notice some slack
in the tape, use a pencil to tighten it
up before you insert it.
Maintenance
Troubleshooting Tips
Side A ProtectionBSide B Protection
A
A
11
EN
More Information
Safety Precautions
• Never open the cabinet under any circumstances. Any
repairs or internal adjustments should be made only by a
trained technician.
• Never operate this product with the cabinet removed.
• Do not touch the player with wet hands. If any liquid
enters the player cabinet, take the player to a trained
technician for inspection.
• This compact disc player uses a laser to read the music
on the disc. The laser mechanism corresponds to the cartridge and stylus of a record player. Although this product incorporates a laser pick-up lens, it is completely safe
when operated according to directions.
• Discs rotate at high speed inside the player. Do not use
damaged, warped, or cracked discs.
Prevent damage to this product, set switch for proper
voltage.
• Do not touch the pick-up lens which is located inside
the disc compartment. Also, to keep dust from collecting
on the pick-up lens and do not leave the compartment
door open for an extended period of time. If the lens
becomes dirty, clean it with a soft brush, or use an air
blower brush designed for camera lenses.
Important Batteries Information
• Remove the batteries to avoid leakage if you do not
use your remote control for more than one month.
Discard leaky batteries immediately as leaking batteries
may cause skin burns or other personal injuries. Dispose
of batteries in the proper manner, according to provincial and local regulations. Any battery may leak electrolyte if mixed with a different battery type, if inserted
incorrectly, if all batteries are not replaced at the same
time, if disposed of in fire, or if an attempt is made to
charge a battery not intended to be recharged.
Headset Safety
• Do not play your headset at a high volume. Hearing
experts are against continuous extended play.
• If you experience a ringing in your ears, reduce volume
or discontinue use it.
• Y ou should use be extreme caution or temporarily discontinue use it in potentially hazardous situations.
Even if you headset is an open-air type designed to let
you hear outside sounds, don’t turn up the volume so
high that you are unable to hear what is around you.
Handling CDs
• Do not touch the signal surfaces. Hold CDs by the
edges, or by one edge and the hole. Do not affix labels or
adhesive tapes to the label surfaces. Do not scratch or
damage the label. CDs rotate at high speeds inside the
player. Do not use damaged (cracked or warped) CDs
Cleaning CDs
• Dirty CDs can cause poor sound quality. Always keep
CDs clean by wiping them gently with a soft cloth from
the inner edge toward the outer perimeter.
• If a CD becomes dirty, wet a soft cloth in water , wring it
out well, wipe the dirt away gently, and then remove any
water drops with a dry cloth.
• Do not use record cleaning sprays or antistatic agents
on CDs. Also, never clean CDs with benzene, thinner, or
other volatile solvents which may cause damage to disc
surface
Don’t Infringe
This product should only be used for the purposes for
which it is sold, that is, entertainment, violating no copyright law. Any attempts to use this product for which it is
not intended is unlawful and therefore not condoned by
Thomson Consumer Electronics.
Technical Specification
Power supply: 230V~50Hz for Thomson models,
120V~60Hz for RCA models.
Dimensions ( H x W x D mm):
Unit size - 329 x 307 x 360 (For all)
Speaker ( for RS2520/ RS3520/ A3000/ A3005 )
- 329 x 250 x 232.5
Speaker ( for RS2521/ A3200/ A3205 )
- 329 x 250 x 252.5
Speaker ( for RS2550/ VTCD550 )
- 361/329 x 240 x 258
Speaker ( for RS2522/ RS3522/ A3400 )
- 361 x 250 x 265
Tape deck: Response curve: 125Hz-8kHz (-5dB)
CD player: Response curve (+/- 2dB): 20Hz to 20 kHz
Rating Plate: Look for it at the back of the set.
What your warranty covers:
• Any defect in materials or workmanship.
For how long after your purchase:
• One year .
(The warranty period for rental units begins with the first rental or 45 days from date of shipment
to the rental firm, whichever comes first.)
What we will do:
• Provide you with a new, or at our option, a refurbished unit.
• The exchange unit is under warranty for the remainder of the original product's warranty period.
How to make a warranty claim:
• Properly pack your unit. Include any cables, etc., which were originally provided with the product.
We recommend using the original carton and packing materials.
• Include in the package evidence of purchase date such as the bill of sale. Also print your name and
address and a description of the defect. Send standard UPS or its equivalent to:
Thomson Consumer Electronics, Inc.
Product Exchange Center
11721 B Alameda Ave.,
Socorro, Texas 79927
• Pay any charges billed to you by the Exchange Center for service not covered by the warranty.
• Insure your shipment in case of loss of damage. Thomson accepts no liability in case of damage orloss.
• A new or refurbished unit will be shipped to you prepaid freight.
What your warranty does not cover:
• Customer instruction. (Y our Owner's Manual provides information regarding operating instructions
and user controls. For additional information, ask your dealer .)
• Installation and set-up service adjustments.
• Batteries.
• Damage from misuse or neglect.
• Products which have been modified or incorporated into other products.
• Products purchased or serviced outside the USA.
• Acts of God, such as but not limited to lightning damage.
Product Registration:
• Please complete and mail the Product Registration Card packed with your unit. It will make it easier
to contact you should it ever be necessary. The return of the card is not required for warranty coverage.
How state law relates to this warranty:
• This warranty gives you specific legal rights, and you may have other rights which vary from
state to state.
If you purchased your product outside the USA:
• This warranty does not apply. Contact your dealer for warranty information.
12
US Warranty
EN
Canadian Warranty
13
EN
Thomson Consumer Electronics Canada, Inc. warrants to the purchaser or gift recipient that if any manufacturing defect becomes apparent in this product within 1 year from the original date of purchase, it will be
replaced free of charge, including return transportation.
This warranty does not include damage to the product resulting from accidents, misuse or leaking batteries.
Should your product not perform properly during the warranty period, either:
1. Return it to the selling dealer with proof of purchase for replacement,
OR
2. Remove the batteries (where applicable), and pack product complete with accessories in the original
carton (or equivalent).
— Mail prepaid (with proof of purchase) and insured to:
Thomson Consumer Electronics Canada, Inc.
Distribution Centre
7400 A Bramalea Road
Mississauga, Ontario L5S 1X1
The provisions of this written warranty are in addition to and not a modification of or subtraction from the
statutory warranties and other rights and remedies contained in any applicable legislation, and to the extent
that any such provisions purport to disclaim, exclude or limit any such statutory warranties and other rights and
remedies, such provisions shall be deemed to be amended to the extent necessary to comply therewith.
If you are unable to find a qualified servicer for out of warranty service, you may write to:
Thomson Consumer Electronics Canada, Inc.
P.O. Box 0944
Indianapolis, Indiana, U.S.A., 46206-0944
Attach your sales receipt to this booklet for future reference. This information is required if service is needed
during the warranty period.
PURCHASE DATE
NAME OF STORE
Model Number:
55051620
Rev. 0 EN/F/E
Loading...
