Raymarine H6 System Installation Manual

D7579_1

System Installation

Manual

Document number: 87035_1
Date: November 2004

2 Raymarine H6 - System Installation Manual

Trademarks and registered trademarks

Autohelm, HSB, Raymarine, RayTech Navigator, Sail Pilot, SeaTalk and Sportpilot are
registered trademarks of Raymarine Limited. Apelco is a registered trademark of
Raymarine Holdings Limited.(Registered in all Major marketing territories.

AST, Autoadapt, Auto GST, Autoseastate, Autotrim, Bidata, Marine Intelligence,
Maxiview, On Board, Raychart, Raynav, Raypilot, Raystar, ST40, ST60, Seaclutter,
Smart Route, Tridata and Waypoint Navigation are trademarks of Raymarine Limited.

Windows, Word and Excel are trademarks of Microsoft Inc.

Firewire is a trademark of Apple Computer.

iLink is a trademark of the Sony Corporation.

All other product names are trademarks or registered trademarks of their respective
owners.

Software in this product is based in part on the work of the Independent JPEG Group.

©Raymarine 2004

1

Contents

Important Information ............................................................................................ ..1

Purpose ...............................................................................................................1

Handbook information ........................................................................................1

Safety notices .....................................................................................................2

EMC conformance ..............................................................................................3

EMC installation guidelines ................................................................................3

System cables and connectors ............................................................................4

System integration .................................................................................................. ..5

Introduction ........................................................................................................5

System integration ..............................................................................................5

System overview ...................................................................................................... ..7

Introduction ........................................................................................................7

System overview .................................................................................................7

Planning the installation ....................................................................................... ..13

Introduction ......................................................................................................13

Installation sites ................................................................................................13

Safety of operation ...........................................................................................14

Off-vessel communications ...............................................................................14

Navtex ..............................................................................................................15

Television reception ..........................................................................................15

Cable runs .........................................................................................................16

Computer, interface units and core components ..............................................16

Display units .....................................................................................................17

Lifeline ..............................................................................................................17

Power amplifier and speakers ...........................................................................18

Base sensors, transducers and 3rd party equipment .........................................18

Cables ....................................................................................................................... ..19

Introduction ......................................................................................................19

Cable runs .........................................................................................................19

2 Raymarine H6 - System Istalation Manual

System cables ...................................................................................................19

Installation .............................................................................................................. ..23

Introduction ......................................................................................................23

Safety notices ...................................................................................................23

Computer and interface installation .................................................................25

System control ..................................................................................................27

Display unit installation ....................................................................................28

Trackball installation ........................................................................................31

Lifeline installation ...........................................................................................33

Audio visual control unit ...................................................................................36

Power amplifier ................................................................................................38

Speaker units ....................................................................................................39

System set up .......................................................................................................... ..43

Introduction ......................................................................................................43

Initial system startup ........................................................................................43

Adjusting the display screen .............................................................................44

H6 software setup .............................................................................................46

Online setup .....................................................................................................47

Television setup ................................................................................................49

3rd Party software setup ...................................................................................50

Chart installation ..............................................................................................50

Instrument calibration ......................................................................................55

Maintenance and troubleshooting ...................................................................... ..57

Introduction ......................................................................................................57

EMC Servicing and Safety Guidelines ................................................................57

Troubleshooting ................................................................................................58

Maintenance .....................................................................................................61

Technical support ..............................................................................................65

3

Appendix A: *.ini file details ........................................................................................67

Installation checklist .............................................................................................. ..91

Raymarine H6 World Wide Warranty ................................................................... ..93

System component dimensions ........................................................................... ..99

Display unit connections ..................................................................................... ..105

Inter-unit connections ......................................................................................... ..107

Installation templates ......................................................................................... ..118

4 Raymarine H6 - System Istalation Manual

Important Information 1

Important Information

Purpose

This handbook contains very important information on the installation and setting up
of Raymarine H6. In order to obtain the best results in operation and performance,
please read this handbook thoroughly.

As a Certified Installer for Raymarine H6, you will have many years experience in the
installation of Raymarine products. This handbook therefore deals with the installation
of the core components of H6, and covers:

•System overview.

• System installation.

• System set up.

• Maintenance and troubleshooting.

Installation of the Raymarine base sensors and transducers should be carried out in
accordance with the installation instructions contained in the relevant handbooks
supplied with the equipment.

Installation of system options and accessories should be carried out in accordance with
the relevant Manufacturer’s instructions as supplied with the equipment.

Raymarine’s Technical Services representatives are available to answer any questions
that you may have arising from this installation.

Handbook information

The technical and graphical information contained in this handbook, to the best of our
knowledge, was correct as it went to press.

However, our policy of continuous improvement and updating may change product
specifications without prior notice. As a result, unavoidable differences between the
product and handbook may occur from time to time, for which liability cannot be
accepted by Raymarine.

2 Raymarine H6 - System Installation Manual

Safety notices

WARNING:High Voltage

This system contains high voltages. Adjustments require specialized
service procedures and tools only available to qualified technicians ­there are no user serviceable parts or adjustments. The operator should
never remove the display unit covers or attempt to service the
equipment.

WARNING:Electrical safety

Make sure the power supply is switched off before you start installing
this system.

WARNING: Product installation

This equipment must be installed and operated in accordance with the
Raymarine instructions provided. Failure to do so could result in poor
product performance, personal injury, and/or damage to your boat.

WARNING:Lithium batteries

The navigation and entertainment computer main boards and lifeline
transmitters have lithium batteries fitted.

Do not attempt to re-charge these batteries.

Do not incinerate these batteries.

Check local regulations when disposing of used batteries.

Ensure that they are replaced with a battery of the same type.

WARNING:Navigation aid

This system is only an aid to navigation. Its accuracy can be affected by
many factors, including equipment failure or defects, environmental
conditions, and improper handling or use. It is the users’ responsibility
to exercise common prudence and navigational judgements. This
system should not e relied upon as a substitute for such prudence and
judgement. Always maintain a permanent watch so that you can
respond to situations as they develop.

CAUTION: Display units

To provide protection against the damaging effects of UV light, it is
advisable to replace the sun covers provided when the color LCD
displays are not in use.

Important Information 3

EMC conformance

All Raymarine equipment and accessories are designed to the best industry standards
for use in the recreational marine environment. The design and manufacture of
Raymarine equipment and accessories conforms to the appropriate Electromagnetic
Compatibility (EMC) standards, but correct installation is required to ensure that
performance is not compromised.

EMC installation guidelines

All Raymarine equipment and accessories are designed to the best industry standards for use in the
recreational marine environment.

Their design and manufacture conforms to the appropriate Electromagnetic Compatibility (EMC)
standards, but correct installation is required to ensure that performance is not compromised. Although
every effort has been taken to ensure that they will perform under all conditions, it is important to
understand what factors could affect the operation of the product.

The guidelines given here de scribe the conditions for optimum EM C performance, but it is recognized that
it may not be possible to meet all of these conditions in all situations. To ensure the best possible
conditions for EMC performance within the constraints imposed by any location, always ensure the
maximum separation possible between different items of electrical equipment.

For optimum EMC performance, it is recommended that wherever possible:

• Raymarine equipment and cables connected to it are:

• At least 3 ft. (1 m) from any equipment transmitting or cables carrying radio signals e.g. VHF
radios, cables and antennas. In the case of SSB radios, the distance should be increased to 7 ft.
(2 m).

• More than 7 ft. (2 m) from the path of a radar beam. A radar beam can normally be assumed to
spread 20 degrees above and below the radiating element.

• The equipment is supplied from a separate battery from that used for engine start. Voltage drops
below 10 V, and starter motor transients, can cause the equipment to reset. This will not damage the
equipment, but may cause the loss of some information and may change the operating mode.

• Raymarine specified cables are used. Cutting and rejoining these cables can compromise EMC
performance and must be avoided unless doing so is detailed in the installation manual.

• If a suppression ferrite is attached to a cable, this ferrite should not be removed. If the ferrite needs to
be removed during installation it must be reassembled in the same position.

Suppression Ferrites

The illustration shows typical cable suppression ferrites used with Raymarine
equipment. Always use the ferrites supplied by Raymarine.

Connections to Other Equipment

If your Raymarine equipment is to be connected to other equipment using a cable
not supplied by Raymarine, a suppression ferrite MUST always be attached to the

D3548-3

cable near to the Raymarine unit.

4 Raymarine H6 - System Installation Manual

System cables and connectors

Cables and connectors used in Raymarine H6 form an integral part of the system. It is a
contractual requirement of the installation to ensure that the correct quality of cable is
used, and that maximum lengths as specified in this handbook are not exceeded. Valid
proof of purchase of the correct cable type will be required for Raymarine to validate
the Warranty for the system.

For full details of approved cable types, maximum permitted lengths and connector
types, refer to “Cables” on page 19.

System integration 5

System integration

Introduction

This chapter contains general information concerning system integration of
Raymarine products.

System integration

System integration enables various instruments and displays to communicate with
each other and use the collected data to increase the functionality of the system.

Integration can simply be creating a master display and repeating it on a screen
located in another part of the boat, or taking information from one set of instruments
and showing that information on the display of another instrument.

This data exchange is only possible if the data gathering is accurate, and transfer
between instruments is fast and accurate.

Fast and accurate data transfer for navigation functions is achieved by using a

®

combination of two different data protocols, SeaTalk
Electronics Association (NMEA) Data Interface Standard.

and National Marine

Data transfer for the entertainment functions is achieved using composite video, RGB,
RS232 and 5.1 Audio protocols.

Navigation protocols

SeaTalk

The SeaTalk protocol was originally developed by Autohelm (part of Raymarine) and
enables compatible instruments to be connected by a single cable carrying power and
data in/out, without a central processor, creating a simple network.

Additional instruments and functions can be added to a SeaTalk system, simply by
plugging them into the network. SeaTalk equipment can also communicate with other
non-SeaTalk equipment via the NMEA 0183 standard.

2

hsb

The high speed bus 2 (hsb2) protocol was developed by Raymarine to enable up to ten
multiple displays to be linked together. This enables all of the screens to display data
from any unit connected the bus to any other unit which is connected to the bus. This
data can be displayed in full, split and overlay screen modes

6 Raymarine H6 - System Installation Manual

NMEA 0183

The NMEA 0183 Data Interface Standard was developed by the National Marine
Electronics Association of America. It is an international standard to enable equipment
from many different manufacturers to be connected together and share information.

The NMEA 0183 standard carries similar information to SeaTalk. However, it has one
important difference in that one cable will only carry information in one direction. For
this reason NMEA 0183 is generally used to connect a data receiver and a transmitter
together, e.g. a compass sensor transmitting heading to a radar.

This information is passed in ‘sentences’, each of which has a three-letter sentence
identifier. It is therefore important when checking compatibility between items that
the same sentence identifiers are used, e.g. VTG carries Course and Speed Over
Ground data, GLL carries latitude and longitude, DBT carries water depth and MWV
carries relative wind angle and wind speed data.

Entertainment protocols

Composite video

Composite video is an analogue form of video representation in which video and
synchronization signals are mixed together.

RGB

RGB supplies a separate signal for each of the three colors; red, blue and green.

IEEE 1394

IEEE 1394 also known as ‘Firewire’ or ‘iLink’ was developed by Apple and adopted in
1995 as an official industry standard. It is a connectivity standard that allows the
transfer of data at lightning speed between such devices as a hard drive and digital
camera. It is a similar protocol to USB and Ethernet.

5.1 audio

5.1 is an indicator of fie full bandwidth channels and one low bandwidth, bass or low

frequency effect (LFE) channel.

System overview 7

System overview

Introduction

This section gives an overview of the Raymarine H6 system. Information concerning
the installation of the various components will be found in the following chapters.

System overview

Raymarine H6 integrates navigation, entertainment and information technology into a
comprehensive system that can be fully customized to the user’s preferences. Data is
provided by a range of sensors and transducers and displayed on high-resolution, flat
panel displays located at the helm and other locations (e.g. saloon, cabins).

Functionality of the system is provided by two computers, one for navigation, one for
entertainment. The entertainment computer is able to act as an online spare in the
event of the failure of the navigation computer.

Base system sensors and transducers collect data and pass it to dedicated interface
units, which in turn pass it to the associated computer. The computer processes the
data which is then shown on the displays. The user can set these displays to show
information according to their preferred options.

The entertainment part of the system contains a DVD/CD player, terrestial and satellite
television. There is a choice of plasma or LCD main entertainment screen, with the
option for flat screen television in each cabin. The helm navigation display can also be
viewed on selected screens. The system also includes a 12 channel zoneable surround
sound system.

Core packages

The complete system consists of core packages to which user specified options and
accessories can be added. A typical system is shown in at the end of this chapter and
consists of:

• Navigation core package.

• Base sensors and transducers package.

• Entertainments core package.

• Options and accessories.

Navigation core package

The navigation core package consists of the following components:

• Navigation computer.

• Navigation interface unit.

8 Raymarine H6 - System Installation Manual

•Display screens.

• Lifeline Man Overboard (MOB) system.

• Trackball.

Base sensors and transducers

The base sensors and transducers are standard Raymarine products and for full system
functionality must include the following:

• Smartpilot Autopilot.

• DSM 250.

• Pathfinder radar.

• Pathfinder scanner.

• Data processing unit.

• Depth and speed instruments.

• Wind instrument.

• SeaTalk/NMEA junction box.

• Calibration instrument.

Entertainments core package

The entertainments core package consists of the following components:

• Entertainments computer.

• Entertainments interface unit.

• 12 channel audio amplifier.

• Speakers and sub woofer.

• Audio-visual control unit.

• Remote control.

Options and accessories

The options and accessories can consist of any of the following components:

Raymarine supply

• Additional displays and trackball for second helm.

• Weather.

• Additional speakers for second helm.

Third party supply

• Plasma or LCD screen.

• Flat screen televisions.

• CCTV cameras.

• GPRS system.

•Navtex.

System overview 9

Cabin televisions

In a standard H6 installation all of the cabin televisions and the saloon entertainments
screen will all show the same programme. If the option of individual channels being
available in individual cabins is required, it will be necessary to install LCD screens that
have a built-in tuner.

10 Raymarine H6 - System Installation Manual

11

This page should be replaced with the A3 sheet - System Schematic

12 Raymarine H6 - Installation Manual

Planning the installation 13

Planning the installation

Introduction

Consisting of core packages that join together to produce a fully integrated system, the
installation of Raymarine H6 requires careful planning to ensure that it can achieve its
full potential. Before installing Raymarine H6, plan the installation, considering:

• Installation sites

• Safety of operation.

•Navtex.

• Television reception.

• Cable runs.

• Location of computer and interface units.

• Location of the display units.

• Location of base sensors and transducers.

Project management

As can be seen from the above list, there are many facets to an installation. It is
recommended that the installation process is split into its various component parts
and managed to ensure that all of the different sections are available in the correct
sequence at the right time.

Installation sites

When planning installation sites for system components, consider the following:

• Ventilation - Electrical components generate heat; any installation site must
have adequate ventilation. This is particularly relevant for computers, interface
units, amplifiers and displays. In some locations it may require forced ventilation to
ensure adequate ventilation and airflow.

• Unit mounting - Whilst individual units incorporate shock mounting, it is vital
that the units themselves are securely mounted and adequately supported to avoid
unnecessary damage to the system or boat’s structure.

Because each installation of Raymarine H6 is unique, it is the responsibility of the
installer to ensure that adequate support and fixing is provided for system
components and in most cases will require local manufacture of mounting
brackets and straps.

14 Raymarine H6 - System Installation Manual

Safety of operation

An important part of planning the installation is ensuring the safe operation of the
system. Consider the following when planning the installation:

Trackball

The trackball(s) should be positioned so that the user’s wrist is supported during use.
This will avoid repetitive strain injury (RSI) to the user. The trackball(s) also need to be
adjacent to the display units.

Lifeline receiver

The Lifeline receiver should be installed in a horizontal position, adjacent to the main
helm trackball and displays for ease of operation.

Audio-visual control unit

The audio-visual control unit must be installed in the horizontal plane, adjacent to the
main entertainments screen, with direct line of sight from seating to the unit to ensure
that the remote control functions correctly.

Pathfinder radar unit

The Pathfinder radar unit should be installed at the main helm adjacent to the H6
displays. Alarms created in H6 can only be cancelled using the Pathfinder unit.

Autopilot head

An autopilot head should be installed at each helm adjacent to the H6 displays. Safety
procedures require that the autopilot be controlled from the autopilot head not H6.

Off-vessel communications

There are several ways in which off-vessel communications can be established for H6.
This must be discussed in detail with the customer before installation. Factors which
affect what equipment will be required are:

• What type of boat is H6 being installed in.

• What is its main area of operation.

Having ascertained this information, a decision needs to be made as to which method
of connection will be most suitable for the type of operation; this can be achieved via:

• General Packet Radio Service (GPRS).

This is an ‘always on’ higher capacity connection providing internet and packet
based data services.

Planning the installation 15

• Group Special Mobile (GSM).

This is an open, non-proprietary system with international roaming capability.

• Satellite

This method of connection provides high speed phone and internet connection
with world-wide coverage.

Navtex

Navtex sof tware is included in H6 as an option for the u ser. If N avtex is to b e availa ble
the following will be required for operation:

• License key - this will be required to activate the Navtex software. This is
available from www.marinecomputing.com

• Navtex 518 KHz antenna - this will receive international transmissions
worldwide. Raymarine recommend the Marine Computing International 518 KHz
antenna which is available from www.marinecomputing.com

Television reception

Consultation will be required with the customer whether terrestrial television or
satellite television reception is required. H6 is capable of receiving both, but with
certain limitations.

The system can only receive either terrestrial or satellite television not both. In each
case reception is controlled by H6 and the same channel will be shown on all system
entertainment screens, so if the Saloon television is tuned to show H6 navigation
information this will be shown on all screens. However if LCD screens with in-built
tuners are installed it is possible for channel selection to be available.

16 Raymarine H6 - System Installation Manual

Cable runs

CAUTION: Cable runs

Do not pull cables through a bulkhead or deckhead using a cord attached
to the connector. This could damage the connectors.

Cables and connectors used in Raymarine H6 form an integral part of the system. Some
cables are provided, others will have to be supplied.

Consider the following before installing the system cables:

• You need to attach power cables and scanner cables. Additional cables may be
required for long cable runs.

• If a cable needs to be longer, ensure that the cable being used is of the correct
quality and gauge. For example, longer power cable runs may require larger wire
gauges to minimize any voltage drop in a cable.

• All cables should be adequately secured, protected from physical damage and
exposure to heat. Avoid running cables through bilges or doorways, or close to
moving or hot objects.

• Acute cable bends must be avoided.

• Where a cable passes through an exposed bulkhead or deckhead, a watertight
feed-through should be used.

• Secure cables in place using tie-wraps or lacing twine. Coil any extra cable and tie
it out of the way.

Computer, interface units and core components

When planning the installation of the computer, interface units and core components,
the following should be considered to ensure safe and reliable operation:

• Position - The computer and interface units should be mounted as a pair, i.e
navigation computer and interface unit, with the following:

• Maximum cable distance permitted between units - 0.8 m.

• Maximum cable distance permitted distance between navigation and

entertainment pairs - 20 m.

• Remote control - If the computer and interface units are to be located some
distance from the main helm, a remote control power switch may be required from
the navigation computer to the helm to facilitate ease of operation.

• Convenience - The mounting locations should be easily accessible to allow
operation of the front panel controls and CD-ROM drive.

• Access - There must be sufficient space behind the units to allow cable
connections to the unit connectors, avoiding tight bends in the cables.

Planning the installation 17

• Ventilation - There must be sufficient space to allow an airflow around the units
to provide adequate ventilation. This airflow should be of a forced type if necessary.

Display units

When planning the installation of the display units, the following should be considered
to ensure safe, comfortable and reliable operation:

• Convenience - The mounting location should be easily accessible to allow
operation of the front panel controls and should enable easy viewing of the display.

• Access - There must be sufficient space behind the displays to allow cable
connections to the rear panel connectors, avoiding tight bends in the cables.

• Interference - The selected locations for display units should be far enough away
from devices that may cause interference, such as motors, generators and radio
transmitter/receivers (see EMC guidelines in Important Information).

• Environment - Do not restrict airflow at the rear of the display units and sensor
modules; ensure there is adequate ventilation and protect units from physical
damage and excessive vibration. It is good practice to mount system components
in protected areas away from prolonged and direct exposure to rain and salt spray.

Lifeline

• Ventilation - To prevent any dimming of the displays by the in-built active
thermal management, it will be necessary to provide adequate ventilation.
Wherever possible this should be ambient cabin or fresh air. If the units are to be
installed in a binnacle (on a flybridge) or other enclosed space consideration should
be given to mechanical ventilation to ensure sufficient airflow.

When planning the installation of the Lifeline receiver, the following should be
considered to ensure safe, comfortable and reliable operation:

• Lifeline receiver - it is recommended that the Lifeline receiver is installed in a
suitable position as near horizontal as possible at the main helm.

• System antennas - these should be positioned to give maximum coverage of the
boat. To achieve this it is necessary to mount one vertical and the other horizontal.

For example, on a flybridge cruiser, one could be installed in a horizontal position
in the radar arch, and one in a vertical position in either the engine room or a
forward cabin. On a sail boat, one could be installed in the sail locker and one in
the main accommodation.

• Identification - there can be up to eight Lifeline transmitter tags active at any
one time, each identified by a number. Consider the installation of a ‘white’ type
board near to the main helm for recording which crew member is assigned to
which tag.

18 Raymarine H6 - System Installation Manual

Power amplifier and speakers

Power amplifier

• Position - The amplifier can be installed in a horizontal or vertical plane, which
can be enclosed and insulated for sound as necessary.

• Access - There must be sufficient space behind the unit to allow cable connections
to the unit connectors, avoiding tight bends in the cables.

• Ventilation - There must be sufficient space to allow an airflow around the unit to
provide adequate ventilation. This airflow should be of a forced type if necessary.

Speaker units

• Position - The speaker units should be installed giving consideration to the effects
of surround sound in an enclosure packed with a suitable acoustic wadding.
Consideration should also be given to ensuring safe distances between speakers
and equipment such as a fluxgate compass, remember, this may be above or below
the area in which the speakers have to be installed.

Base sensors, transducers and 3rd party equipment

When planning the installation of base sensors, transducers and third party equipment
(e.g. GPRS) follow the instructions given in the relevant Product Handbook concerning
installation and cables.

Cables 19

Cables

Introduction

This section lists the cables and their associated connectors that will be required to
complete the installation of Raymarine H6.

Cables and connectors used in Raymarine H6 form an integral part of the system. It is a
contractual requirement of the installation to ensure that the correct quality of cable is
used, and that maximum lengths as specified are not exceeded. Valid proof of
purchase of the correct cable type will be required for Raymarine to validate the
Warranty for the system.

Cable runs

CAUTION: Cable runs

Do not pull cables through a bulkhead or deckhead using a cord attached
to the connector. This could damage the connectors.

Consider the following before installing the system cables:

• You need to attach power cables and scanner cables. Additional cables may be
required for long cable runs.

• All cables should be adequately secured, protected from physical damage and
exposure to heat. Avoid running cables through bilges or doorways, or close to
moving or hot objects.

• Acute cable bends must be avoided.

• Where a cable passes through an exposed bulkhead or deckhead, a watertight
feed-through should be used.

• Secure cables in place using tie-wraps or lacing twine. Coil any extra cable and tie
it out of the way.

Strain relief

It is important that all cables and connections are fitted with adequate and suitable
strain relief.

System cables

The following pages give a detailed listing of cables required to complete the
installation of H6 and cover:

•Cable names.

•Cable type.

• Maximum permitted lengths.

• Connector types and pin out details.

20 Raymarine H6- System Installation Manual

21

This page should be replaced with the A3 sheets - Cables

22 Raymarine H6 - Installation Manual

Installation 23

Installation

Introduction

This section deals with the installation of the core components of Raymarine H6 and
covers:

• Computer and interface units.

• System control.

• Display units.

• Trackball.

• Lifeline system.

• Audio visual control unit.

• Power amplifier.

•Speakers.

Base sensors and transducers - should be installed in accordance with the
instructions contained in the relevant Raymarine handbooks.

Third party equipment - should be installed in accordance with the instructions
contained in the relevant Manufacturer’s handbook accompanying the product.

Safety notices

WARNING: High Voltage

This system contains high voltages. Adjustments require
specialized service procedures and tools only available to
qualified technicians - there are no user serviceable parts or
adjustments. The operator should never remove the display
unit covers or attempt to service the equipment.

WARNING: Electrical safety

Make sure the power supply is switched off before you start
installing this system.

WARNING: Product installation

This equipment must be installed and operated in accordance
with the Raymarine instructions provided. Failure to do so
could result in poor product performance, personal injury, and/
or damage to the boat.

24 Raymarine H6 - System Installation Manual

WARNING: Lithium batteries

The navigation and entertainment computer main boards and
lifeline transmitters have lithium batteries fitted.

Do not attempt to re-charge these batteries.

Do not incinerate these batteries.

Check local regulations when disposing of used batteries.

Ensure that they are replaced with a battery of the same type.

CAUTION: Transit securing clips

Before installation the transit securing clips must be removed
from the hard drive shock mounts of both the avigation and
Entertainments computers.

Installation 25

Computer and interface installation

Introduction

D7406_1

Computer

Interface

This section deals with the installation of the navigation and entertainment computer
and interface units.

Installation sites

When selecting installation sites for the computer and interface units the following
points must be considered:

Position

D7407_1

The computer and interface units must be installed so that the unit is square to the
bulkhead.

The computer must be installed in a horizontal position. Failure to do this will result in
incorrect operation of the CD-ROM drive.

Access and ventilation

D7408_1

26 Raymarine H6 - System Installation Manual

Adequate space should be left behind the units for cable connections and access.

The computer and interface units must have adequate airspace around them to allow
free airflow for cooling purposes. In some instances it may be necessary to provide a
forced airflow to achieve this.

Installing the units

CAUTION: Transit securing clips

Before installation the transit securing clips must be removed from the
hard drive shock mounts of both the avigation and Entertainments
computers.

AB

'L' shaped channel Shelf

C D

D7409_1

Secure

The computer and interface units must be supported behind the bulkhead when
installed. This can be achieved using suitable ‘L’ section channel or a shelf (A and B
above).

DO NOT use the front bezel of the unit for support.(C above).

Every endeavour should be made to secure the computer and interface units to their
mounting supports, along their entire length or at a minimum the rear, in order to
prevent movement and provide correct shock and vibration support (D above).

Adequate room must be left at the front of the navigation computer to allow operation
of the CD-ROM drive.

Installation 27

To remove thetransit securing clips:

1. Remove the top cover of the computer.

Transit

securing clip

D7660_1

2. Locate the transit securing clip which is located to the right of the CD drive when
the computer is viewed from the front.

3. Remove the transit securing clip by pulling it upwards and awayf rom the shock
mounting.

System control

The normal operating sequence for H6 requires power to be applied to the system by
pressing the on/off button on the front of the navigation computer. If the computer and
interface units are installed some way from the helm (e.g. on another deck) this is not
always easy or practical. Consideration should therefore be given to installing a
remote power switch at the main helm which can be used as an alternative to the
computer button.

Installation of this will require a cable to be run from the navigation interface unit ­CON 29 and terminate in a suitable ON/OFF switch at the helm. This switch must be
clearly annotated as to its purpose.

Main helm

Remote ON/OFF

D7597_1

switch

Navigation computer

28 Raymarine H6 - System Installation Manual

Display unit installation

Power requirements

CAUTION:

The display units are not intended for use on ‘positive’ ground boats. The
power input cable earth screen connections must be connected directly
to the boat’s ground.

The display units are designed to run on a DC power system rated at either 12 V or 24 V.

A 2.5 m length cable is supplied for connecting the display to the boat’s DC power
system.

The DC system should be either:

• Negative grounded, with the negative battery terminal connected to the boat’s
ground, or,

• Floating, with neither battery terminal connected to the boat’s ground.

Grounding the displays

It is important that an effective RF ground is connected to each display. The displays
must be grounded by connecting the drain wire (screen) of the power input cable to the
nearest ground point of the boat’s RF ground system.

Installation

Each display should be installed as follows, using the templates supplied:

To install the display units:

1. Tape the templates into the required positions.

2. Using the template, drill a mounting hole 4.1 mm (0.16in) diameter in the 4 marked
positions for each template.

3. Cut the aperture in the surface, checking that there is nothing behind that the saw
might damage.

Installation 29

-35.027˚-35.027˚

20.024˚20.024˚

1

3

15" LC

D Panel tem

plate

To ensure correct dimensions,

use the template provided.

4

6

302.2 mm (11.9 in)

Remove

shaded areas

only

Drill mou

4.1 mm diameter
(4 positions)

nting hole

2

center line

391.6 mm (15.4 in)

Instrument edg

e

Sun cover edge

D7410_-1

7

5

8

11

-35.027˚

20.024˚

4. Place the display into the aperture, push a M4 screw through each hole.

10

9

6 mm (0.24 in) min.
18 mm (0.71 in) max.

D7411_1

30 Raymarine H6 - System Installation Manual

5. Assemble 2 off, side plates onto M4 screws and secure using a plain and a spring
washer, affix nuts and tighten.

6. To each side of the display loosely attach in the following order:
i. Metal washer.
ii. Bracket.
iii. Plastic washer.
iv. Cam.
v. Pen ny wa sher.
vi. Spring washer.
vii. M8 bolt.

7. Operate the cams to clamp the display into position.

8. Tighten the M8 bolts.

9. Secure the front bezel in place using 4 x TBA bolts.

Installation 31

Trackball installation

CAUTION: Water ingress

To avoid water ingress ensure that the sealing gasket is correctly located
before fixing the trackball into position.

Installation

2

Hole A

Fas

edge

cia

Cover

edge

Hole

A

from shaded areas only

1

Remove material

4

H6 Trackball

Mounting Template

Unit

UP

in 8 positions

3

6 mm (

Drill hole,

diameter

1

/

4

in)

Hole A

Check

Hole A
If you are using the Button-Head screws supplied, drill 4 mm (

Hole A

1

­6
2

3
7

D

5

/32 in) holes.

If you are using Self-Tapping screws, then drill holes of a suitable size to ensure secure fixing.

D7412_1

D7413_1

32 Raymarine H6 - System Installation Manual

To install the trackball:

1. Tape the template into the required position.

2. Using the template drill a suitable size hole at each of the positions marked A for
the securing screws.

3. Using the template, drill the eight 6 mm (1/4 in) holes marked in the shaded area.

4. Cut the aperture in the surface, checking that there is nothing behind that the saw
might damage.

5. Ensure that the sealing gasket is correctly located in the groove on the underside of
the trackball plate.

6. Connect the drain tube to the underside of the trackball housing.

7. Connect the trackball cable to the trackball connector.

8. Place the trackball into position and secure using suitable screws.

Installation 33

Lifeline installation

CAUTION: Water ingress

To avoid water ingress ensure that the sealing gasket is correctly located
before fixing the Lifeline receiver into position.

Receiver installation

Hole A

2

Hole A

UP

-1

3
2
3

7

D

5

/32 in) holes.

Hole

A

3

D7414_1

H6 Lifeline Unit

Hole A

1

4

Fascia

edge

Mounting Template

from shaded areas only

Remove material

Cover

edge

Check

Hole A
If you are using the Butt Head screws supplied, drill 4 mm (
If you are using Self-Tapping screws, then drill holes of a suitable size to ensure secure fixing.

34 Raymarine H6 - System Installation Manual

D7415_1

To install the Lifeline receiver:

1. Tape the template into the required position.

2. Using the template drill a suitable size hole at each of the positions marked A for
the securing screws.

3. Using the template, drill the eight 6 mm (1/4 in) holes marked in the shaded area.

4. Cut the aperture in the surface, checking that there is nothing behind that the saw
might damage.

5. Ensure that the sealing gasket is correctly located in the groove on the underside of
the Lifeline receiver plate.

6. Connect the Lifeline cable to the Lifeline receiver connector.

7. Place the Lifeline receiver into position and secure using suitable screws.

Installation 35

Aerial installation

Chain locker - vertical

Flybridge - horizontal

D7529_1

The system antenna should be positioned to give maximum coverage of the boat. To
achieve this it is necessary to mount one vertical and the other horizontal.

For example, on a flybridge cruiser, one could be installed in a horizontal position in the
radar arch, and one in a vertical position in either the engine room or a forward cabin.
On a sail boat, one could be installed in the sail locker and one in the main
accommodation.

To mount an antenna:

Lock nut

Antenna mount

D7530_1

1. Mount the antenna bracket in a suitable position.

2. Insert the antenna into the antenna bracket.

3. Tighten the lock nut to secure the antenna into position.

Antenna

36 Raymarine H6 - System Installation Manual

Audio visual control unit

H

o

2

le

A

F

a

s

cia
e

d

g

e

H

o

le

A

1

Check

Hole A
If you are using the Button-Head screws supplied, drill 6 mm (
If you are using Self-Tapping screws, then drill holes of a suitable size to ensure secure fixing.

U

P

H6 AVC Unit

Mounting Tem

Remove material

from shaded areas only

1

/4 in) holes.

plate

H

o

le

A

H

o

le

A

3

D7416_1

D7417_-1

Installation 37

Installation

To install the AV control unit:

1. Tape the template into the required position.

2. Using the template drill a suitable size hole at each of the positions marked A for
the securing screws.

3. Using the template, drill the eight 6 mm (1/4 in) holes marked in the shaded area.

4. Cut the aperture in the surface, checking that there is nothing behind that the saw
might damage.

5. Connect the cables to the correct connectors.

38 Raymarine H6 - System Installation Manual

Power amplifier

H
o

le

A

2

F
a

scia

e

d
g
e

H
o

le

A

1

UP

H6 Amplifier Unit

Mounting Template

Rem

from sh

ove m
aded areas only

aterial

Check

Hole A
If you are using the Button-Head screws supplied, drill 7 mm (

9

/32 in) holes.

If you are using Self-Tapping screws, then drill holes of a suitable size to ensure secure fixing.

H
o
le

A

H
o
le

3

A

D7319-1

D7418_1

Installation

To install the power amplifier:

1. Tape the template into the required position.

2. Using the template drill a suitable size hole at each of the positions marked A for
the securing screws.

D7419_1

Installation 39

3. Using the template, drill the eight 6 mm (1/4 in) holes marked in the shaded area.

4. Cut the aperture in the surface, checking that there is nothing behind that the saw
might damage.

5. Connect the cables to the rear of the unit ensuring correct polarity.

Speaker units

To ensure correct 5.1 surround sound quality, it is necessary to install the speakers in
certain positions and ensure that they are acoustically insulated.

5.1 surround sound

To enjoy the full effect of 5.1 surround sound the speakers should be installed to reflect
the diagram below.

Front left

Front centre

Surround left

Front right

AV control unit

Subwoofer

Surround right

D7420_1

Acoustic insulation

To ensure sound quality the speakers should be installed in an enclosure of the
following volume:

• Sub woofer units - 60 liters (2 cu.ft).

• Speakers - 7 liters (0.25 cu.ft).

40 Raymarine H6 - System Installation Manual

Each enclosure should be loosely filled with a suitable acoustic wadding.

Speaker installation

PLEASE CHECK M

Hole A

3

EASUREM

ENTS ON

TEM

PLATE BEFORE USE.

UP

H6 Speaker Unit

Mounting Template

114 mm

Cut hole,

Fascia edge

Hole A

2

(4

1

/

2

in) diameter

Remove material

from shaded area

97.58 mm (3

2

7

/

s only

3

2

in)

1

Hole A

in)

32

/

27

97.58 mm (3

Hole A

-1
4
32
7
D

Check

Hole A
If you are using the Button-Head screws supplied,
drill 6 mm (

1

/4 in) holes.
If you are using Self-Tapping screws, then drill holes
of a suitable size to ensure secure fixing.

D7421_1

Note: Speaker grille material is local supply
to suit interior.

D7422_1

Installation 41

Sub woofer installation

1

2

UP

H6 Sub Woofer Unit
Mounting Template

189 mm

Cut hole,

(7

2

9

/

6

4

in)

diameter

Rem

from

ove

shaded areas only

Drill hole

5.2 m

d

iam

eter.

m

m

7

(

(4 positions)

aterial

/

3

,

2

in)

3

D7325-1

D7423_1

D7424_1

42 Raymarine H6 - System Installation Manual

System set up 43

System set up

Introduction

This chapter deals with the set up of Raymarine H6 after installation of the system and
covers the following:

• Initial system startup.

• H6 software setup.

•Online setup.

• Television setup.

rd

•3

Party software setup.

• Chart installation.

• Instrument calibration.

Initial system startup

To start H6:

1. Ensure that all peripheral instruments within the system are powered ON.

2. Press the button on the front of the Navigation computer to start running H6*.

3. Press the power button on both displays to ON.
The H6 disclaimer is displayed on the left screen.

4. If you agree to the terms of the disclaimer, click I Agree. The H6 Welcome screen is
displayed. If you do not click I Agree H6 will not start.

5. Click OK.The Welcome screen closes and H6 starts. The button bar and databoxes are
displayed.

Note:

* If a remote control switch has been fitted to the system, this should be used to power

H6.

44 Raymarine H6 - System Installation Manual

Adjusting the display screen

Each H6 display unit is shipped with factory default settings, however there may be a
need to adjust these. This is done via on-screen menus using the buttons on the unit
fascia.

Adjustment
controls

Power button

D7661_1

The set up menus of the displays allow you to adjust how the image is displayed and
contain the following options:

Brightness, volume and input source

Setting the Brightness, Volume and Input Source

the mode

Press

+

Press

Press

Note:

Raymarine H6 monitors do not have in-built speakers, monitor volume adjustment is

What you see

Brightness

--

--

Video source

Analogue (RGB)
DV1
Composite-S

43

Volume

29

D7531_1

To adjust/selectSelecting

+

+

Press

Press

+

+

Press

Press

+

Press

Press

To finish ­or wait 10 secs

Press (do not hold)

Press (do not hold)

Press (do not hold)

part of the software setup. Therefore adjusting the volume of the monitor will have no effect on
the H6 system.

System set up 45

Set up menu

Set up menu item Function Purpose

Image Adjust Menu Contrast Adjust the display contrast (this has no effect in composite

Tint Select cool, neutral or warm color temperature.

Aspect ratio Select the aspect ratio; this is useful if you choose a

Horizontal position They can be used for VGA inputs to adjust the horizontal

Vertical position

Advanced menu options

Image enhancement

Phase adjust

Clock adjust

Gamma correction

RGB adjust

Black level adjust

Restore defaults

video or s-video mode).

resolution that has a different aspect ratio to the display (4
x 3 at its standard resolution of 1024 x 768)

and vertical position of the image on the screen.
Once commissioning is complete these controls do not
normally need to be adjusted

The following controls do not normally need adjusting

Select video or text enhancement mode
Video enhancement may improve moving images. Text
enhancement is suitable for static images

To adjust the pixel position on the LCD to match the VGA
input, thus ensuring a clear image.

To adjust the pixel timing to mach the VGA input, thus
ensuring a clear image.

Select the LCD or CRT gamma correction.

Adjust the Red, Green or Blue color intensity.

Adjust the black level.

Restore the factory default settings.

Auto set up Automatically adjusts the image size, contrast, focus and

Language option list Select the language for the OSD menus.

About M1500 Shows the display software version.

stability.

To adjust the display settings:

1. Press and hold either of the adjustment buttons at the top right of the display. An

on-screen menu appears.

2. Press either of the adjustment buttons to scroll through the menu to the required

option.

3. Press and hold the adjustment button. The selected menu appears.

4. Use the adjustment buttons to scroll and select your option.

5. Select the adjustment by pressing the Power button.

46 Raymarine H6 - System Installation Manual

H6 software setup

.ini files

CAUTION: *.ini files

Changes to files other than those detailed below may result in H6failing
to operate correctly. It is strongly recommended that a copy of these
files is made and placed on the hard drive before any modifications are
implemented.

H6 is shipped with software installed to factory default settings, these may require
adjustment for the particular installation to display data accurately and in the correct
format.

These adjustments are carried out within the .ini files contained within the H6 software
program.It is necessary to modify three software files to ensure that accurate data is
displayed.

These files are found in the Setup directory and are named:

•cam.ini.

• datasources.ini.

• setup.ini.

It is strongly recommended that you make a copy of these files and place them in the
Setup directory. They should be suitably renamed e.g ‘cam.example.ini’ and saved. If
during setup an unrecoverable error is made this file can then be amended to its
original name and use to restore that section of H6 to its original settings.

For details of the text contained in these files see “ *.ini file details” on page 67.

Permitted changes

cam.ini

Changes in this file are limited to:

• Camera type - NTSC or PAL.

•Camera names.

datasouces.ini

Changes in this file are limited to those which ensure data is received fom the correct
source to avoid conflict within H6 and the resultant display of incorrect information.

setup.ini

Changes in this file are limited to:

• Entertainment - show on button bar.

System set up 47

• Rudder - if maximum rudder angle is different to default.

•Windforce.

•Speed.

• Alarms - set beeper.

• Startup - change totem pole displays.

To modify the files:

1. Connect a keyboard and mouse to the rear of the navigation computer using the

Trackball MUX connection and keyboard connection below this.

2. Power up the system as described in

3. Press the Windows key on the keyboard. The Windows task bar is displayed.

4. Select Start/Programs/Accessories/Notepad. The Notepad is displayed.

5. Select File/Open/C:/H6. The H6 directory is displayed.

6. Double-click ‘setup’. The file directory is displayed.

7. At the bottom of the dialog box locate the field named ‘Files of type’.

i. Click the arrow to the right of the field. A drop-down menu is displayed.

Initial system startup

above. H6 will load.

ii. Select

8. Double-click ‘cam.ini.’ The contents of the file open in Notepad.

9. Modify the file script as necessary, making sure that it is done correctly as described

in the instructions at the start of the file.

10.Save any changes that are made to the file.

11. Repeat steps 8 through 10 for the files named ‘datasources.ini’ and ‘setup.ini’.

12. Turn H6 off and restart the system.

13. Check all expected data is displayed.

Online setup

With H6 connected to the off-boat communication, On-line can be setup so that
connection to the Internet is made by simply pressing the GPRS or GSM button on the
browser screen.

To create an internet connection:

With the off -boat communication modem connected to the serial port COM 2,the
system operating and a keyboard connected:

1. In Windows click Start.

2. From the pop-up tool bar select Settings.

3. From the drop-down menu select Network and Dial-up connections.

All Files

. All files in the directory are displayed.

48 Raymarine H6 - System Installation Manual

4. Click

5. Click

6. When you are asked to name the modem, type in either

Make new connection

Next

and follow the on screen instructions.

. The Internet connectionwizard is displayed.

D7662_1

GPRS

or

GSM

. The

association is then made between the modem and the On-line browser softkey.

7. Complete installation as instructed by the wizard.

This procedure associates the modem with the on-screen softkey. When the selected
softkey is pressed the modem will make the connection to the internet.

GPRS GSM

buttons

D7398_1a

System set up 49

Television setup

H6 can receive either terrestrial or satellite television, not both. Set up for reception is
as follows:

Terrestrial television

Line out

Short link

Entertaiments computer

D7598_1

Audio input

To receive terrestrial television it is necessary to construct a short link with a jack plug
at each end which is then installed between the Audio input and Line Out ports on the
rear of the Entertainments computer as illustrated above.

Satellite television

Satellite TV

Antenna

Entertainments computer

Satellite
receiver

Audio

VGA

Suitable

signal splitter

Entertainments interface

D7599_1

50 Raymarine H6 - System Installation Manual

For satellite television a suitable signal splitter must be sourced and installed between
the satellite receiver and the Entertainments computer and interface. The signal
splitter should split the satellite signal into VGA and audio channels and be connected
as follows:.

• Audio - Signal splitter to Audio Input - rear of Entertainments computer.

• VGA - Signal splitter to ENT 2 - ear of Entertainments interface.

3rd Party software setup

It will be necessary to register and setup 3rd party software to ensure that the
information is displayed correctly.

Navtex

With the Navtex antenna installed and connected to the modem serial port of the
Navigation computer and H6 running:

1. As H6 opens the MCI Navtex registration screen is displayed.

2. Enter the Navtex license key.

3. Press O.K. Navtex is now registered and available for use. The registration screen

will no longer appear at system power up.

If N av te x i s n ot re qu ired th e s of tw ar e m us t b e d is ab le d by a me nd in g t he set up. in i fil e -
See “ *.ini file details” on page 67.

Chart installation

WARNING: Chart datum

Ensure that all cartography used in the H6 system is based on WGS84. Failure
to do so could create an error in the boats position.

This section describes how to install charts using the C-Map Chart Selector and the
Chart Manager.

C-Map NT+/PC charts from CD-ROM

C-Map charts are installed using C-Map’s chart selector. You select the charts you
require, purchase the relevant chart licences and then register the charts. Once C­Map charts have been purchased and installed they are automatically detected by H6
on start-up and made available through the C-Map layer of the chart application.

To purchase and install C-Map charts:

1. Insert the C-Map Chart Selector CD-ROM into the Navigation computer CD drive.

2. Select Chart from the button bar. The chart application is displayed.

System set up 51

3. Select Controls/Charts/C-Map Selector. The C-Map Selector and H6 on-

screen keyboard are displayed.

D7425_1

4. Drag the on-screen keyboard to the right-hand screen.

5. From the Chart Catalog, select and double-click the area that you require charts for.

An expanded list of charts appears.

6. Select the area that you require charts for. Placing the cursor over a chart number

will cause a pop-up of the area name to appear and the area will be highlighted on
the main chart.

D7426_1

7. Click the highlighted area. A list of available charts is displayed in the

selected from map

box. Placing the cursor over a chart number will cause a pop-up

Charts

of the area covered to appear.

8. Click

displayed.

Buy selected chart

in the tool bar at the top of the screen. The shopping cart is

52 Raymarine H6 - System Installation Manual

D7427_1

9. Details of the selected chart are displayed in the lower window.

10. Take note of the Chart licence request number (highlighted in the illustration

above).

11. Repeat steps 5 through 9 for each chart you want to purchase.

12.Click

Call Center

in the toolbar at the top of the screen. Contact details for C-Map

will be displayed.

13. Contact C-Map at the relevant center shown in the Call Center list and purchase

license keys for each chart you want to install. Take a careful note of these numbers
as they will be required to register the charts.

14. Click Insert Chart Licence in the toolbar at the top of the screen. The screen updates

to allow chart registration.

D7428_1

System set up 53

15. Using the on-screen keyboard type in the license key for each chart that you have

purchased.

Note:

Make sure that the license key is entered correctly. Mistakes are not brought to your at-

tention, the chart will install, but not operate until the correct number is entered.

16.Click

Register

.The chart details will be transferred to the Purchased NT+/PC Charts

list.

17. The chart is now copied to the hard drive of the Navigation computer and will

automatically be available through the C-Map chart layer.

18. Remove the CD-ROM from the Navigation computer.

Maptech charts

Installation of Maptech charts requires a keyboard, they must therefore be puchased
and installed onto the system during the initial installation of H6.

To install Maptech charts:

1. 1. Purchase the relevant chart license key. This can be obtained from

www.maptech.com.

2. Connect the keyboard to the Navigation computer.

3. Insert the CD-ROM into the drive on the front of the Navigation computer. The

installation wizard will appear.

4. Check

5. Click

On this computer

Next

. The registration screen appears.

.

D7663_1

D7664_1

54 Raymarine H6 - System Installation Manual

6. Enter

7. Enter

8. Enter

9. Clik

Name

details.

Product ID
Activation code

Next

. This is on the registration card in the CD cover.

. This is the license key number purchased from Maptech.

and follow the on-screen instructions.

10. When installation is complete, remove the keyboard connection from the

Navigation computer.

Chart manager

With the installation of charts completed as detailed in
above, the H6 chart manager will search and locate Maptech charts that are installed
on your system. You then select which charts you require and install them using the
chart manager.

To install charts using the chart manager:

With a chart window open:

1. Select Controls/Install Charts. The following dialog box will appear:

To install Maptech charts:

D7429_1

2. Click OK. H6 will now search for charts on your system. After searching the

following dialog box will appear:

D7430_1

3. Click OK. The chart installer screen will be displayed.

All of the installed charts are highlighted by default. If you do not want to install all
of the charts, deselect them by clicking in the black area to the right hand side of
the chart installer.

4. If necessary, highlight the charts you want to install.

System set up 55

D7431_1

5. Click

Install

, when you have highlighted all of the required charts. The progress of

the installation of each chart will be shown.

6. The chart manager will update the chart list.

7. Click

OK

. The dialog box closes.

Instrument calibration

CAUTION: Chart and GPS datum

The GPS must be set for WGS84 datum.

Base sensors and transducers should be calibrated in accordance with the instructions
contained in the relevant handbooks.

56 Raymarine H6 - System Installation Manual

Maintenance and troubleshooting 57

Maintenance and troubleshooting

Introduction

This chapter covers the recommended maintenance and troubleshooting procedures
for Raymarine H6 and covers the following:

• Navigation core system.

• Base sensors and transducers.

• Entertainments core system.

• Options and accessories.

EMC Servicing and Safety Guidelines

• Raymarine equipment should be serviced only by authorized Raymarine service

technicians. They will ensure that service procedures and replacement parts used
will not affect performance. There are no user serviceable parts in any Raymarine
product.

• Some products generate high voltages, so never handle the cables/ connectors

when power is being supplied to the equipment.

• When powered up, all electrical equipment produces electromagnetic fields. These

can cause adjacent pieces of electrical equipment to interact with one another,
with a consequent adverse effect on operation. In order to minimize these effects
and enable the user to get the best possible performance from their Raymarine
equipment, guidelines are given in the installation instructions, to enable the user
to ensure minimum interaction between different items of equipment, i.e. ensure
optimum Electromagnetic Compatibility (EMC).

• Always report any EMC-related problem to the nearest Raymarine dealer. We use

such information to improve our quality standards.

• In some installations, it may not be possible to prevent the equipment from being

affected by external influences. In general this will not damage the equipment but
it can lead to spurious resetting action, or momentarily may result in faulty
operation.

58 Raymarine H6 - System Installation Manual

Troubleshooting

As with all powerful systems, sometimes everything does not go as it should with H6.
This section will help you to spot and solve some of the problems.

H6 software

Problem Possible solution

Route not being followed, even though Follow Route
softkey is set to On

Expanded data box is not shown on screen Possibly hidden behind another window - reselect the display

In a split chart/radar window - Range in/out does not
work

Radar overlay is not clear on the chart Change the overlay color in the Layers folder of Set-up. Many

Navtex does not operate This is 3rd party software that must be registered prior to use.

On-line does not work You will need to have a modem connection outside of H6 with the

On-line - an added site from an authorized site is not
displayed correctly in the site list.

Check that the autopilot is in track following mode.

mode. The data box will be returned to its original position.

Click the edge of th e section you want to change range in to make
it the active application. Range controls will now work.

users find a purple color works well in bright sunlight.

Check that the registration screen does not appear when H6 is
started. If it does you will need a license key to register the
software.

appropriate Windows drivers.

The URL is too long to be displayed. Rename the site with a
suitable name, the URL will remain unchanged.

Display units

Problem Possible solution

You have pressed the power button, but the display
does not function

1. Make sure that the power supply cable is sound and that all
connections are tight and free from corrosion.

2. Check the system fuse.

The display shows the message ‘CHECK INPUT’ Check that H6 is powered and that the cables are correctly

The display is very dim Adjust the display brightness. If this has no effect then the display

The display switches off unexpectedly The display powers off completely in no input signal is received or

connected.

has overheated; when the display cools, brightness will return.

30 seconds. Reapply power to the display by switching it on using
the power button.

Maintenance and troubleshooting 59

Navigation system

Problem Possble solution

Data is missing from an H6 databox 1. Use diagnostics window to check data is entering computer. If

it is not check cable connections.

2. Check settings in setup.ini file are correct.

Le ft o r ri ght hand Na vig ation s cre en i s not v isi ble. 1. Che ck N avi gat ion co mpu ter is t urned O N.

2. Check cable connections between Display units, Navigation
computerand interface units.

3. Press and hold display power button.

4. Check power to monitor.

5.Active thermal management working. Wait for monitor to coll,
check ventilation and restart.

Navtex licensing creen appears at start up. If Navtex is not required, disable it in setup.ini file.

H6 time is ncorre ct when computer has been swi tched

Replace battery on Navigation computer motherboard.

off and on.

Only one screen appears and cu rsor does not move off

In Windows display properties, check two screen mode.

the screen.

Warning ‘Num boards = 0’ appears on screen. Open Navigation computer and try to re-seat CCTV PCI card.

Radar

Problem Possible solution

No radar display 1. Check Radar transmit softkey is set to ON.

2. Check that Pathfinder display has been powered ON.

‘Scanner not responding’ message Check that the cable connecting the scanner to the Pathfinder

display is firmly attached and undamaged.

The bearing displayed on the radar is not the same as
the actual bearing

Perform the bearing alignment procedure as described in
the Scanner handbook.

Sonar

Problem Possible solution

Display’ freezes’ 1.Check the scrolling speed is not set to zero.

2.Check the transducer cable for damage.
If damaged, the cable and transducer must be replaced as a unit.

Sonar doe s not display fish 1. Fish arches are not displ ayed if the boat is stopped - fish appear

Sonar does not see the bottom or fish 1. Check that the gain is not set too low.

Sonar display is unreliable at high speeds Turbulence around the transducer may be confusing the unit.

Sonar displays a lot of background noise 1. Check that the gain is not set too high.

Sounder speed or log readings are wrong 1. Check that the transducer paddle wheel is clean.

on the display as a straight line.

2. Check that the gain is not set too low.

2. Check that the transducer face is not covered or fouled. If
necessary clean the transducer.

2. Check tat the transducer is clean.

2. If necessary add a speed offset.

60 Raymarine H6 - System Installation Manual

Lifeline

Problem Possible solution

Cannot regi ster a specific L ifeline tag Replace the tag battery See “Replacing a transmi tter battery” on

page 63.

Cannot activate any Lifeline tag 1. Check antenna are correctly installed and connections are

correct.

2. Make sure tags are correctly seated in the Lifeline receiver.

Lifeline data box shows ‘ Lifeline Offline’ message Check cable connections between computer and interface units.

Lifeline MOB alarm activates as tags are carried
around boat

Incorrect Lifeline antenna coverage. Check antenna locations,
orientation and connections are correct.

Cannot register a tag after a system reboot Lifeline needs to detect activated tags. Click ‘Reset Lifeline’, a

message asking if you want to register detected tags will be

OK

, you will now be able to register a new tag.

All tags show 24 hours to expiry even though this is
not correct

displayed. Click

This usually occurs after a system reboot. De-activate all tags and
re-activate them.

Lifeline shows ‘Man Overboard’ alarm on opening Computer, not H6 system has been shut down. Click ‘Reset

Lifeline’. Alarm will be cancelled and Lifeline system will reset.

Trackball

Problem Possible solution

Cursor stops following the trackball Move the trackball more slowly. The cursor will then follow.

Entertainments system

Problem Possible solution

Audio-visual control unit will not accept a disk. 1. Check tha t the unit is turned on.

Power amplifier (not the speakers) makes a
continuous clicking noise.

Cannot view navgation screen on entertainments
screens.

Etertainment screen does not change from Nav 1 to
Nav 2

Entertainments do not respond to remote control 1. Make sure the remote is pointed towards the AV control unit.

Message ‘ Audio system not responding’ appears on
screen.

No sou nd f rom a ce nte r or re ar s pea ker Chec k DV D/C D disk is 5 .1 a udi o.

No sound from a speaker 1. Check volume settings.

Remote control unit screen is blank Change the batteries.

2. Press the eject button in case there is already a disk in the unit.

Check amplifier input voltage and power requirements are being
met.

Check cable computer and interface connections.

Check nav interface to ents interface comms cable connections.

2. Check batteries in the remote control unit do not require
replacing.

Check all computer and interface connections.

2. Check 5.1 audio cable and connections

.

Maintenance and troubleshooting 61

Entertainments system

Sound plays from DVD but not a CD In Windows set-up enable Digital audio on DVD drive.

Entertainment computer does not start 1. Check cable connections.

2. Tur n AV u nit con tro l sw itc h to ON.

• These tables are not exhaustive, if having tried the possible solutions you are still

experiencing difficulties, contact Raymarine as detailed in “Technical support” on
page 65.

Maintenance

Display screens

Routine checks

The displays are sealed units. Maintenance procedures are therefore limited to the
following periodic checks:

• Examine the cables for signs of damage, such as chafing, cuts or nicks.

• Check that the cable connectors are firmly attached.

Cleaning the display

CAUTION: Take care when cleaning the displays. Do not wipe a display
screen with a dry cloth - this could scratch the screen coating. Do not
use acid, ammonia based or abrasive products.

1. Ensure the display is switched off.

2. Wipe the display with a clean, damp cloth.

3. If necessary use iso-propyl alcohol (IPA) or a mild detergent solution to remove

grease marks.

Base sensors

Pathfinder radar

Routine checks

The displays are sealed units. Maintenance procedures are therefore limited to the
following periodic checks:

• Examine the cables for signs of damage, such as chafing, cuts or nicks.

• Check that the cable connectors are firmly attached.

62 Raymarine H6 - System Installation Manual

Cleaning the display
CAUTION: Take care when cleaning the displays. Do not wipe a display
screen with a dry cloth - this could scratch the screen coating. Do not
use acid, ammonia based or abrasive products.

1. Ensure the display is switched off.

2. Wipe the display with a clean, damp cloth.

3. If necessary use iso-propyl alcohol (IPA) or a mild detergent solution to remove

grease marks.

Sounder module

Routine checks

The sounder module is a sealed unit. Maintenance procedures are therefore limited to
the following periodic checks:

• Examine the cables for signs of damage, such as chafing, cuts or nicks.

• Check that the cable connectors are firmly attached.

Cleaning the module

The sounder module is a sealed unit and does not require regular cleaning. However, if
it is found to be necessary to clean the unit:

1. Ensure the display is switched off.

2. Wipe the display with a clean, damp cloth.

3. If necessary use iso-propyl alcohol (IPA) or a mild detergent solution to remove

grease marks.

Transducer

CAUTION: Harsh cleaning solvents such as acetone may damage the
transducer.

Sea growth can collect quickly on the bottom of the transducer, this can reduce
performance in just a few weeks. To prevent the build-up of sea growth, coat the
transducer with a thin layer of paint.

Use only water-based antifouling paint, or a water- based paint specifically designed
for transducers. Apply the paint with a brush.

If the transducer becomes fouled or stops working because of sand or sea growth, use
a stiff brush to clean it. The surface can be sanded with a fine-grit wet or dry sandpaper
(#320 grade or finer), but this will affect the performance of the unit when the boat is
moving at higher speeds.

Maintenance and troubleshooting 63

The paddle wheel mechanism may become jammed by dirt, grit or barnacles. Work the
contaminant out of the mechanism, then clean the unit with soap and water or
alcohol.

Instruments and keypads

Certain atmospheric conditions may cause a small amount of condensation to form on
instrument windows. This will not harm the instruments and will clear after they have
been switched on for a short period.

Wind transducer

If the windvane is removed from its mounting block for any reason, fit the blanking
cover (supplied) to the windvane mounting block connector.

Lifeline transmitters

WARNING: Lithium batteries

The Lifeline transmitter tags have a lithium battery fitted. Do
not attempt to recharge these batteries.

Do not incinerate these batteries.

Ensure that they are replaced with a battery of the same type.

Check local regulations when disposing of spent batteries.

CAUTION: Transmitter screws

Do not overtighten the transmitter tag screws when replacing
the unit battery as this may result in irreparable damage to the
unit.

Replacing a transmitter battery

The battery of each transmitter tag should be replaced at regular intervals to ensure
that the unit functions correctly.

The battery required is:

3 V, Lithium cell, Part No. CR2430 - these are obtainable from any reputable electronics
or photographic store:

To replace a transmitter battery:

64 Raymarine H6 - System Installation Manual

a

a

1.Carefully remove the three screws (a) holding the two parts of
the transmitter unit together.

a

2.Carefully remove the battery and replace with a new one, ensuring
correct polarity.

c

b

3.Ensure that the sealing gasket (c), is correctly located in the groove
around the edge of the unit.

4.Re-assemble the unit, and replace the screws (a), making sure that
they are not over-tightened.

D7303_1

Maintenance and troubleshooting 65

Technical support

To get Technical Support....

www.raymarine.com

United States

Raymarine Technical Services

1-800-539-5539 extension 2333, or
(603)-881-5200

Raymarine Technical Support

1-800-539-5539 extension 2444, or
(603) -881-5200

Product Repair and Service

Raymarine Product Repair Center
22 Cotton Road, Unit D,
Nashua, NH03603 - 4219
1-800-539-5539

Opening hours:
Monday through Friday 0815 - 1700
Eastern Standard or Eastern Daylight
Savings Time.

Europe

Technical Support
Services
Accessories

Raymarine Limited
Anchorage Park
Portsmouth
PO3 5TD
England

Tel:
[phone]

Fax:
[phone]

D7600_1

66 Raymarine H6 - System Installation Manual

67

Appendix A: *.ini file details

Introduction

This appendix gives details of the *.ini files that have to be modified during post
installation set up as detailed in

cam.ini

;Brightness and Contrast are from 0-511

;Camera names must be enclosed in inverted commas.

;Gamma is either 1 or 0

;For NTSC Cameras set PAL=0

;Cycle speed is the time (in Milliseconds) before the camera is
switched to the next one.

;The minimum setting for this value is 200

System set up

on

page 43

.

[General]

PAL=1

CycleSpeed=5000

[Camera0]

Active=1

Name=”Docking”

Brightness=133

Contrast=300

Gamma=0

[Camera1]

Active=0

Name=”Eng 1”

Brightness=106

Contrast=206

68 Raymarine H6 - System Installation Manual

Gamma=0

[Camera2]

Active=0

Name=”Aft Deck”

Brightness=164

Contrast=279

Gamma=0

[Camera3]

Active=0

Name=”Eng2”

Brightness=193

Contrast=232

Gamma=0

69

datasources.ini

; Caption = The name of the Field

;

; IDString = Regular expression for sentence that we’re getting
data from

; a full stop matches any character. An example is GPS which

; which matches $GPRMC with ...RMC, this would also match
$IIRMC.

; It is best to make this pattern as specific as possible.

;

; Element = the element within a sentence that the data is coming
from. For example:

;

;

; $SDDPT,10.3,0.0

; | | |

; | | +----------Element 2

; | +---------------Element 1

; +--------------------Element 0

;

;

; Depth’s Field0 gets it’s data from Element 1. Which is

10.3.

; If element is -1, this means that that particular is

; ignored and H6

; deals with the sentence as a whole.

;

;

; --== Frank Jackson ==--

; --== dB Research ==--

70 Raymarine H6 - System Installation Manual

; Magnetic Variation is calculated internally so the datasources
for

; true should be the same as magnetic.

[Course]

Field0-Caption=Heading Magnetic

Field0-IDString=.APHDM

Field0-Element=1

Field1-Caption=COG Magnetic

Field1-IDString=...VTG

Field1-Element=3

Field2-Caption=Heading True

Field2-IDString=.IIHDM

Field2-Element=1

Field3-Caption=COG True

Field3-IDString=...VTG

Field3-Element=3

[Depth]

Field0-Caption=Depth

Field0-IDString=...DBT

Field0-Element=3

[GPS]

Field0-Caption=Latitude and Longitude

Field0-IDString=...RMC

Field0-Element=-1

Field1-Caption=Max Error

Field1-IDString=...GGA

Field1-Element=8

71

[Speed]

Field0-Caption=SOG

Field0-IdString=...RMC

Field0-Element=7

Field1-Caption=STW

Field1-IDString=...VHW

Field1-Element=5

[Rudder]

Field0-Caption=Rudder Angle

Field0-IDString=.IIRSA

Field0-Element=1

[Wind]

Field0-Caption=Wind Direction

Field0-IDString=...MWV

Field0-Element=1

Field1-Caption=Wind Speed

Field1-IDString=...MWV

Field1-Element=3

Field2-Caption=True Wind Direction

Field2-IDString=...MWD

Field2-Element=1

Field3-Caption=True Wind Speed

Field3-IDString=...MWD

Field3-Element=5

Field4-Caption=Heading

Field4-IDString=...HDM

Field4-Element=1

72 Raymarine H6 - System Installation Manual

Field5-Caption=True Magnetic Wind Direction

Field5-IDString=...MWD

Field5-Element=3

[Leeway]

Field0-Caption=Wind Direction

Field0-IDString=.IIMWD

Field0-Element=1

Field1-Caption=Wind Speed

Field1-IDString=.IIMWD

Field1-Element=5

Field2-Caption=Heading

Field2-IDString=.IIHDM

Field2-Element=1

Field3-Caption=Heading True

Field3-IDString=.IIHDT

Field3-Element=1

Field4-Caption=Magnetic Wind Direction

Field4-IDString=.IIMWD

Field4-Element=3

[Stanguard]

Field0-Caption=EPIRB

Field0-IDString=.PEGR

Field0-Element=-1

73

[Ents]

Field0-Caption=SOG

Field0-IdString=.GPVTG

Field0-Element=5

[XTE]

Field0-Caption=UTC

Field0-IdString=.IIRMC

Field0-Element=1

[LL]

Field0-Caption=Latitude and Longitude

Field0-IDString=...GGA

Field0-Element=-1

Field1-Caption=COG True

Field1-IDString=...VTG

Field1-Element=1

Field2-Caption=SOG

Field2-IdString=.GPRMC

Field2-Element=7

Field3-Caption=COG Magnetic

Field3-IDString=...VTG

Field3-Element=3

[Pipe]

Field0-Caption=Anything

Field0-IDString=.

Field0-Element=-1

74 Raymarine H6 - System Installation Manual

setup.ini

; 12/08/2004

; Specifies which comport the MUXed data is coming in on. There
should be no reason to change

; this.

[DMX]

ComPort=1

; The settings in DataServer are all internal and have nothing to
do with the hardware. These ; values should never be changed.

[DataServer]

SensorPorts=19

SensorBaud=4800

SensorPorts9600=

Channel0Baud=9600

Channel1Baud=9600

Channel2Baud=9600

Channel3Baud=9600

Channel4Baud=9600

Channel5Baud=9600

Channel6Baud=9600

Channel7Baud=9600

Channel8Baud=9600

Channel9Baud=9600

Channel10Baud=9600

Channel11Baud=9600

Channel12Baud=9600

Channel13Baud=9600

Channel14Baud=9600

Channel15Baud=9600

75

OutputPorts=22

H6Port=17

Simulate=0

; Sets the internal comport for the Autopilot (virtual
serialport).

[Autopilot]

Comport=8

; These extra sentences are supplied for compatability with non­Raymarine products.

; Adding a 1 next to the required sentence will include it in H6s
output to the autopilot.

OutputRMC=1

OutputBWC=0

OutputAPB=0

OutputRMB=1

OutputAAM=0

;Screen settings used internally and should not be changed.

[Screen]

Width=1024

Height=768

Refresh=60

Depth=32

76 Raymarine H6 - System Installation Manual

; There should be no need to change LifeLine settings

; TagExpiry is managed by lifeline.

[LifeLine]

ComPort=5

Tag2Expiry=26/06/2004 11:11:41

[Entertainment]

RecvPort=3

Comport=11

Screen=1

; RecvPort,Comport and Screen should be left as is.

ShowOnButtonBar=1

; ShowOnButtonBar, 0 Removes Ents button from ButtonBar, 1 Puts
ents button on the buttonbar.

MouseSwitch=0

;MouseSwitch, switches the video if the mouse changes screen. 1
to activate, 0 to deactivate.

;Misc settings are used internally and should not be changed.

[Misc]

Host=0

DebugDisplayServer=0

WantDisplayServer=1

77

; These settings allow control of what data is passed onto
Raytech.

; There should be no need to change the

[RayTech]

LaunchRaytech=0

SendCOG=1

SendHDT=1

SendSOG=1

SendSTW=1

SendPosition=1

SendMaxErr=1

;Depth settings are managed by the Depth program itself and are
used to rememeber

;alarm settings between each H6 session. There is no need to
change the settings here.

[Depth]

LowAlarm=20.9

HighAlarm=19.69008

LowOn=0

HighOn=0

BtnSpeed=80

[Rudder]

MaxAngle=40

;Allows the maximum angle on the rudder display to be altered.

78 Raymarine H6 - System Installation Manual

[WindForce]

Adjustment=30.0

Length=70

Beam=5

Airdraft=3.5

Draft=1.5

; Used internally, do not change.

[SeaTalk]

UseSeaTalk=0

SeaTalkInterval=500

[Speed]

; Best Values are 40,60,80 these give properly rounded dial
markings

TopSpeed=40

[Alarms]

AlarmsOn=0

ComPort=12

79

; Alarm

; OnInterval = Time in centiseconds to make a noise

; OffInterval = Time in centiseconds to silence alarm

; PreferredBeeper = 0 = use beeper 0, 1=use beeper 1, 2=Use any
available beeper

[AlarmBeeps]

[A1]

Name=”Depth”

OnInterval=8

OffInterval=2

PreferredBeeper=0

[A2]

Name=”Lifeline”

OnInterval=5

OffInterval=5

PreferredBeeper=2

; GMH not used in full Nav system

; Channel refers to the channel on the Interface and is NOT the
comport.

; These settings should remain as is in a full Nav System.

[GMH]

GMHOn=0

NMEAChannel=6

IRChannel=0

80 Raymarine H6 - System Installation Manual

; Setting a value to 1 runs the application at startup.

; Settings a value to 0 excludes the application from H6 startup.

[Startup]

HideTaskBar=1

Entertainment=1

;Important! Entertainment should always be on to setup the
screen switching at bootup.

;If you need to remove Entertainment from the button bar use the
ShowOnButtonBar setting

;in Entertainment

Raytech=1

Course=1

Speed=1

CCTV=1

Depth=1

Lifeline=1

Online=1

Rudder=1

GPS=1

WeatherChannel=0

NavTex=1

Wind=1

WindForce=1

Rudder=1

XTE=1

Stanguard=0

Waypoint=1

Alarms=1

Appendix B: Technical specification 81

Appendix B: Technical specification

Navigation computer

Approvals:
complies with EMC Directive 89/336/EEC

Size:
Fro nt pa nel
Enclosure

Weight 7 kgs (15.43 lbs)

Mounting Panel mounting

by meeting the relevant parts of EN60945:2002

355 x 105 x 10 mm (13.98 x 4.13 x 0.39 ins)
305 x 93 x 385 mm (12.0 x 3.66 x 15.15 ins)

Power 14 V to 19 V DC supplied from Navigation interface unit

9A maximum consumption at 19 V DC

Environmental:
Operating/Storage temperature ranges
Humidity limit

0

-20

C to + 550 C

up to 90% at 35

0

C non-condensing

Controls Power On/Off button

Connectors:
Input

18 V DC power

2

hsb
PAL/NTSC
RGB

Output

RGB

Ethernet
PS/2

Navigation interface unit

Approvals:
complies with EMC Directive 89/336/EEC

Size:
Fro nt pa nel
Enclosure

Weight 7.5 kgs (16.53 lbs)

by meeting the relevant parts of EN 60945:2002

355 x 105 x 10 mm (13.98 x 4.13 x 0.39 ins)
305 x 93 x 385 mm (12.0 x 3.66 x 15.15 ins)

Mounting Panel mounting

Power 24 V DC (10.8 V to 31.2 V DC absolute)

10 A maximum consumption at 24 V DC

Fuses 15 Amp

Environmental:
Operating/Storage temperature ranges
Humidity limit

0

-20

C to +550 C

up to 90% at 35

0

C non-condensing

82 Raymarine H6 - System Installation Manual

Navigation interface unit

Controls None

Connectors:
Input

24 V DC power
NMEA
RS232
RGB
PS/2

Output

18 V, 10 A supply to Navigation computer
5 x 12 V DC supplies to peripheral instrumentation
RGB
Sync 1 V Resolution 1024 x 768
PS/2
Alarms

Entertainments computer

Approvals:
complies with EMC Directive 89/336/EEC

Size:
Fro nt pa nel
Enclosure

Weight 7 kgs (15.43 lbs)

Mounting Panel mounting

Power 14 V to 19 V DC supplied from Navigation interface unit

Environmental:
Operating/Storage temperature ranges
Humidity limit

Controls Power On/Off button

Connectors:
Input

by meeting the relevant parts of EN60945:2002

355 x 105 x 10 mm (13.98 x 4.13 x 0.39 ins)
305 x 93 x 385 mm (12.0 x 3.66 x 15.15 ins)

9A maximum consumption at 19 V DC

0

-20

C to + 550 C

up to 90% at 35

0

C non-condensing

18 V DC power
75 Ohm antenna
IEEE1394

Output

RGB
RS232
Sync 1 V Resolution 1024 x 768

5.1 surround sound
PS/2

Entertainments interface unit

Approvals:
complies with EMC Directive 89/336/EEC

Size:
Fro nt pa nel
Enclosure

Weight 7.5 kgs (16.53 lbs)

by meeting the relevant parts of EN 60945:2002

355 x 105 x 10 mm (13.98 x 4.13 x 0.39 ins)
305 x 93 x 385 mm (12.0 x 3.66 x 15.15 ins)

Appendix B: Technical specification 83

Entertainments interface unit

Mounting Panel mounting

Power 24 V DC (10.8 V to 31.2 V DC absolute)

10 A maximum consumption at 24 V DC

Fuses !5 Amp

Environmental:
Operating/Storage temperature ranges
Humidity limit

0

-20

C to +550 C

up to 90% at 35

0

C non-condensing

Controls None

Connectors:
Input

NMEA
RS232
RGB
PS/2

Output

18 V, 10 A supply to Entertainment computer
5 x 12 V DC supplies to peripheral instrumentation
RGB
Sync 1 V Resolution 1024 x 768
PS/2

Audio visual control unit

Approvals:
complies with EMC Directive 89/336/EEC

Size:
Fro nt pa nel
Enclosure

by meeting the relevant parts of EN 60945:2002

220 x 105 x 10 mm (8.66 x 4.13 x 0.39 ins)
150 x 87 x 335 mm (5.90 x 3.42 x 13.18 ins)

Weight 3 kgs (6.61 lbs)

Mounting Panel mounting

Power 24 V DC (21.6 V to 31.2 V DC absolute)

Fuses 5 Amp (internal)

Environmental:
Operating/Storage temperature ranges
Humidity limit

0

-5

C to +550 C

up to 90% at 35

0

C non-condensing

Controls Off/Standby/On

Volume

Connectors:
Input

Output

24 V DC power

IEEE1394
Amplifier volume and power switch port
IR to Entertainment interface unit port

84 Raymarine H6 - System Installation Manual

Amplifier unit

Approvals:
complies with EMC Directive 89/336/EEC

Size:
Fro nt pa nel
Enclosure

Weight 10 kgs (22 lbs)

Mounting Panel mounting

Power 24 V DC (21.6 V to 31.2 V DC absolute)

Fuses 30 Amp (internal)

Environmental:
Operating/Storage temperature ranges
Humidity limit

Controls None (software controlled)

Connectors:
Input

Output

Input/output

by meeting the relevant parts of EN60945:2002

482 x 105 x 10 mm (18.97 x 4.13 x 0.39 ins)
434 x 88 x 350 mm (17.9 x 3.46 x 13.78 ins)

30 A maximum consumption at 24 V DC

0

-5

C to +550 C

up to 90% at 35

0

C non-condensing

24 V DC power
Volume and power switch port

5.1 surround sound
Aux (stereo)
12 x 4 Ohm loudspeaker outputs
RS232 interface to entertainments interface unit

Speaker(s)

Approvals:
complies with EMC Directive 89/336/EEC

Size:
Fro nt be zel
Speaker
Enclosure

Weight 1.3 kgs (2.86 lbs)

Mounting Panel mounting

Power 50 Watts (audio)

Environmental:
Operating/Storage temperature ranges
Humidity limit

Connectors:
Input Push on/solder tags

by meeting the relevant parts of EN 60945:2002

136 x 136 x 16 mm (5.35 x 5.35 x 0.62 ins)
130 mm diameter x 70 mm depth (5.11 x 2.75 ins)
Recommended volume of 7 liters (0.24 cu.ft) loosely filled with suitable
acoustic wadding.

0

-20

C to +550 C

up to 90% at 35

0

C non-condensing

Appendix B: Technical specification 85

Sub woofer unit

Approvals:
complies with EMC Directive 89/336/EEC

by meeting the relevant parts of EN60945:2002

Size:
Fro nt be zel
Speaker
Enclosure

None
216 mm diameter x 100 mm depth (8.50 x 3.93 ins)
Recommended volume of 60 liters (2.11 cu.ft) loosely filled with suitable
acoustic wadding.

Weight 1.4 kgs (3.08 lbs)

Mounting Internal

Power 50 Watts (Audio)

Environmental:
Operating/Storage temperature ranges
Humidity limit

0

-20

C to +550 C

up to 90% at 35

0

C non-condensing

Connectors:
Input Push on/solder tags

Remote control unit

Approvals:
complies with EMC Directive 89/336/EEC

by meeting the relevant parts of EN60945:2002

Size: 177 x 74 x 33 mm (7.8 x 3.0 x 1.3 ins)

Weight 0.25 kgs (0.55 lbs)

Power 3 x 1.5 V (AA size) batteries (primary or rechargeable)

Environmental:
Operating temperature range

0

+ 5

C to + 450 C

Display Monochrome touch screen LCD with 4 gray levels and digital contrast

control
Resolution 160 x 100 pixels
Blue EL backlighting for LCD and hard buttons

Infrared (IR) Infrared sending LED and learning eye

Operating distance - 10 m (33 ft.)
Learning distance - 2 cm (1 in) to maximum 10 cm (4ins)

Lifeline receiver

Approvals:
complies with R&TTE DIrective 1999/5/EC

Size:
Fro nt pa nel
Enclosure

by meeting the relevant parts of:

EN 60945:2002
EN 301 489-9
EN 300 220-1
EN 300 220-3

119 x 105 x 10 mm(4.68 x 4.13 x 0.39 ins)
95x 57 x 132 mm (3.74 x 2.24 x 5.19 ins)

86 Raymarine H6 - System Installation Manual

Lifeline receiver

Weight 0.75 kgs (1.65 lbs)

Mounting Panel mounting

Power 12 V DC (10.8 V to 15.6 V DC absolute)

Environmental:
Operating/Storage temperature ranges
Humidity limit

0

-20

C to + 550 C

up to 90% at 35

0

C non-condensing

Controls None (software controlled)

Connectors:
Input

12 V DC power
2 x 50 Ohm BNC antennas

Output

RS232

Lifeline transmitter

Approvals:
complies with R&TTE DIrective 1999/5/EC

Size: 70 x 45 x 25 mm (2.75 x 1.77 x 0.98 ins)

Weight 25 grms (0.05 lbs)

Mounting Clipped to crew member

Power CR2 430 lithium cell (internal)

Environmental:
Operating/Storage temperature ranges
Humidity limit

by meeting the relevant parts of:

0

-20

C to + 550 C

up to 90% at 35

0

C non-condensing

EN 60945:2002
EN 301 489-9
EN 300 220-1
EN 300 220-3

Trackball

Approvals:
complies with EMC Directive 89/336/EEC

Size:
Fro nt pa nel
Enclosure

Weight 0.5 kgs (1.10 lbs)

Mounting Panel mounting

Environmental:
Operating/Storage temperature ranges
Humidity limit

by meeting the relevant parts of EN 60945:2002

119 x 105 x 10 mm (4.68 x 4.13 x 0.39 ins)
75 x 65 x 35 mm (2.95 x 2.55 x 1.37 ins)

0

-20

C to + 550 C

up to 90% at 35

0

C non-condensing

Appendix B: Technical specification 87

Trackball

Controls Position control ball

2 x selection buttons

Connectors:
Input

Output

None

PS/2

Display units

Approvals:
CE - conforms to
FCC - conforms to

Size: 416.4 x 334.2 x 141.0 mm (16.4 x 13.16 x 5.55 ins)

Weight 10 kgs (22 lbs)

Mounting Console mount with bracket mount option

Power 12 V and 24 V system (10.7 V to 32 V DC absolute)

Fuses Minimum ratings for 12 V boat supply:

1999/5/EC, EN60945:2002
Part 80 (47CFR) and Part 2 (47CFR)

Floating earth/fully isolated
72 W maximum consumption with full brightness

Isolator switch - 15 A
Thermal breaker rating - 8 A
Fuse value - 12 A

Minimum ratings for 24 V boat supply:
Isolator switch - 8 A
Thermal breaker rating - 4 A
Fuse value - 6 A

Environmental:

Operating/Storage temperature ranges
Humidity limit

Waterproof to CFR46; suitable for external mounting

0

-10

C to + 500 C

up to 90% at 35

0

C non-condensing

The display(s) must be stored and installed away from strong magnetic fields

Controls Power On/Off button

OSD (On Screen Display) control switches

Display type color TFT LCD

Resolutions and refresh rates 640 x 480, 60 Hz

800 x 600, 72 Hz
1024 x 768, 60 Hz (recommended)
1024 x 768, 70 Hz
1280 x 1024, 60 Hz

Display size 304.1 x 228.1 mm active area

Connectors Power input

DVI Input
VGA Input
Audio Input

88 Raymarine H6 - System Installation Manual

Radar features

Range scales (Range rings) 1/8 (1/16) nm to 72(12) nm dependant on scanner Performance limited by

Range ring accuracy Better than +/- 1.5% of the max. range scale in use, or 22m (72ft) whichever

Bearing accuracy

Variable range markers 2 x VRM’s, readout nm, sm, km

Electronic bearing lines

Bearing scale

Minimum range 23m (25yds)

Range discrimination 23m (25yds)

Presentation modes Head up, Course up or North up (selectable True or Magnetic)

Scanner control Interference rejection, standby/transmit modes, pulse selection, Tune, Rain,

Magnetic sensor NMEA (required for fast heading data, suitable for MARPA), or SeaTalk

Waypoint display Target waypoint displayed.

MARPA Manual acquisition of 10 targets, automatic tracking, dangerous target

scanner type and position

is the greatest.

0

+/- 1

2 x EBL’s, floating if required, resolution 1

0

360

graduated at 100 intervals

FTC and Sea controls, with selection of manual or automatic cont rol of gain,
sea clutter and tune (Auto GST

TM

0

)

alarms TBA

Appendix C: List of Abbreviations 89

Appendix C: List of Abbreviations

Abbreviation Meaning

AV Audio/Visual

CCTV Closed Circuit Television

CD Compact Disk

dc Direct Current

DC Direct Current

DSM Digital Sounder Module

DVD Digital Versatile Disc

EMC Electromagnetic Compatibility

EPIRB Emergency Position Indicating Radio Beacon

ft feet

GPRS General Packet Radio Service

GPS Global Positioning System

GSM Group Special Mobile

Hz Hertz

in(s) Inch (es)

LCD Liquid Crystal Display

m metre

mm millimeters

MOB Man Overboard

nm Nautical Miles

NMEA National Marine Electronics Association

PCI Peripheral Component Interconnect

RAM Random Access Memory

RF Radio Frequency

RGB Red/ Green/ Blue

ROM Read-only Memory

90 Raymarine H6 - System Installation Manual

Abbreviation Meaning

ROM Read Only Memory

RSI Repetitive Strain Injury

SSB Single Side Band

TFT Thin Film Transistor

VVolts

VHF Very High Frequency

Installation checklist 91

Installation checklist

The following checklist must be completed by the Installer and signed by the Installer
and Boat Owner.

This document forms part of the warranty conditions for Raymarine H6.

No. Check Confirmed

Received H6 Restore disk

Received Windows restore disk

Off- vessel communication connection options discussed and agreed with Owner

System powered and demonstrated to Owner/Captain

System set up completed

92 Raymarine H6 - System Installation Manual

No. Check Confirmed

Raymarine H6 World Wide Warranty 93

Raymarine H6 World Wide Warranty

The Raymarine Warranty Terms and Conditions as described below do not affect the Customer’s legal rights and complies
with EU Directive 1999/44/EC.

In order to ensure that the product continues to operate efficiently and reliably, we recommend that, before using the
product, the customer carefully reads he Owner’s Handbook and follows the advice on safe and correct operation and use
of the product. We recommend that the Raymarine product, is installed by a Raymarine certified installer. Installation by
persons other than a Raymarine certified installer may invalidate the warranty.

1. Product warranty

1.1 Raymarine warrants each new product to be of good materials and workmanship. Raymarine, or its approved agents,
will repair or exchange under warranty any parts or product proven to be defective in material or workmanship under
normal use, for a period of 2 years (24 months) from date of sale to end user, subject to the limits contained in this warranty
document.

1.2 The Raymarine warranty covers the parts and labor associated with any warranty repair as described above, provided
that the product is returned to Raymarine or one of its approved agents.

1.3 Raymarine reserve the right to replace under warranty, not repair, certain Raymarine products subject to the limitations
below, provided that they are returned to the nearest Raymarine National Distributor. For details of such products refer to
the internet at www.raymarine.com or contact your nearest Raymarine National Distributor.

2. On-board warranty

2.1 In addition to the Product warranty cover as described above, Raymarine will, authorize on-board warranty service by
the nearest Raymarine approved service agent, subject to the maximum mileage and other limits referred to in paragraph

4.12 below, on products, where proof of installation, or commission by Raymarine certified installers, can be shown.

2.2 The warranty provides for on-board repair or exchange of the product, by Raymarine or its approved service agents, for
a period of 2 years (2 months), subject to the limits contained in this warranty document. In the case of a product installed,
by a Raymarine certified OEM installer, on a new boat prior to the sale of the boat to the customer. In the case of a product
installed, by a Raymarine certified installer, on a boat already in the possession of the customer, the 2 year period will begin
on the date of the commissioning of the installed product.

3. Obtaining warranty service

3.1 In the event of warranty service being required, the customer should contact Raymarine Technical Support or the
nearest Raymarine approved service agent - the contact details of Raymarine Technical Support and a full list of the names
and details of worldwide service agents are available on the internet at www.raymarine.com and in the Owner’s
Handbook.

3.2 The affected product must be returned to the customer’s local Raymarine approved service agent or direct to Raymarine
with: proof of purchase showing the date o f purchase and the name of the supplier of the product; and the serial number of
the affected product; or a warranty card completed by the product supplier (which will contain the information required).

3.3 In cases where the customer is making a warranty claim for on-board warranty, the nearest Raymarine approved service
agent should be contacted and on-board service requested (which will be subject to the limits referred to in paragraph 4.12
below). Before the on-board warranty service is performed, the customer must have available: proof of purchase showing
the date of purchase and the name of the supplier of the product; and the serial number of the affected product; and proof
of installation of the product by a Raymarine certified installer; or a warranty card completed and stamped by a Raymarine
certified installer (which will contain the information required).

4. Warranty limitations

4.1 Raymarine warranty policy does not apply to any product that has been subjected to accident, abuse or misuse,
shipping damage, alterations, corrosion, incorrect and/or non-authorized service, or products on which the serial number
has been altered, mutilated or removed. Raymarine warrants only the components supplied by Raymarine. Peripheral
devices interfaced to any Raymarine H6 system are warranted separately by the component manufacturer and are not
party to this agreement.

94 Raymarine H6 - System Installation Manual

4.2 Products purchased outside of the country of installation will not be covered by on-board warranty.

4.3 Raymarine assumes no responsibility for damage incurred during installation or as a result of improper installation.

4.4 This warranty does not cover routine system checkouts, alignment/calibration, sea-trials or commissioning, unless

required by replacement of part(s) in the area being aligned.

4.5 Raymarine a ssumes no responsibility for d amage caused by or to other equipment, systems or components occasioned
by improper or unauthorized connection, or use, of the product.

4.6 Consumable items, including, but not limited to: fuses, batteries, drive belts, radar mixer diodes, magnetrons, snap-in
impeller carriers, impellers, impeller bearings, and impeller shafts are specifically excluded from this warranty. A complete
list of the consumable items relating to each product can be found in the Owner’s Handbook and/or on the internet at

www.raymarine.com.

4.7 All costs associated with transducer replacement, other than the cost of the transducer itself, are specifically excluded

from this warranty.

4.8 Overtime/premium labor portion of services outside of normal working hours is not covered by this warranty.

4.9 If repairs are necessary under the warranty, the affected product must be forwarded to a Raymarine facility or a

Raymarine approved service agent, at the owner’s expense.

4.10 The Raymarine warranty does not cover any differences in material, coloring or size between those alluded to in
corporate advertising, literature or published on the internet, which are not specifically objected to at the time of delivery.

4.11Travel costs other than auto mileage, tolls and two (2) hours travel time, are specifically excluded from the warranty on
al products. Costs, which are excluded from the coverage of this warranty, include but are not limited to; taxi fares, launch
fees, aircraft rental, subsistence, customs, shipping and communication charges etc.

4.12 Neither Raymarine nor a Raymarine service agent shall be liable for any incidental, indirect, consequential or special
(including punitive or multiple) damages, nor shall Raymarine or a Raymarine service agent be liable for any loss of profit,
business, contracts, opportunity, goodwill or other similar loss. The liability of Raymarine or a Raymarine service agent to a
customer under this warranty, whether for breach of contract, tort, breach of statutory duty or otherwise, shall not exceed
US$1,000,000. Nothing in this paragraph 4.12 shall limit the liability of Raymarine or a Raymarine service agent in respect
of death or personal injury caused by its negligence, fraud or any other liability which by law, cannot be excluded or limited.

4.13 All Raymarine products sold or provided hereunder are merely aids to navigation. It is the responsibility of the user to
exercise discretion and proper navigational skill independent of any Raymarine product.
