Service part catalogue
SelfCookingCenter® whitefficiency® Line
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
4/30/2012
3 AC480V (440V) 60Hz UL
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
SelfCookingCenter® whitefficiency®
4/30/2012
3 AC480V (440V) 60Hz UL
2
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
SelfCookingCenter® whitefficiency®
Pos.
Part No.
Description
Qty.
1
Control panel
1
2
Electrical installation
1
3
ClimaPlus
1
4
Steam generator
1
5
Hot air heating
1
6
Motor and fan wheel
1
7
Interior cabinet
1
8
Door
1
9
Exterior cabinet
1
10
Water
1
11
CleanJet + Care
1
13
Standard accessory
1
4/30/2012
3 AC480V (440V) 60Hz UL
3
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Control panel
4/30/2012
3 AC480V (440V) 60Hz UL
4
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Control panel
Pos.
Part No.
Description
Qty.
1
87.01.005
Control panel insert with overlay
1
2
42.00.112
Control pcb *TFT*
1
3
42.00.081
MMI pcb
1
4
40.03.467
Cable On-Off switch MMI
1
5
40.03.515
Cable MMI - TFT
1
6
40.03.516
Cable MMI - CPU
1
7
16.02.062
Dial f. pulse generator
1
9
40.00.404
Pulse generator
1
12
16.01.910
Cover f. control pcb w. gasket
1
13
16.01.908
Sealing f. panel insert
1
4/30/2012
3 AC480V (440V) 60Hz UL
5
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Electrical installation
4/30/2012
3 AC480V (440V) 60Hz UL
6
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Electrical installation
Pos.
Part No.
Description
Qty.
1
40.00.453
Solid state relais
2
2
10.00.061
Pan head screw Torx T20 M4x12
4
3
10.00.061
Pan head screw Torx T20 M4x12
1
4
1204.0120
Tooth lock washer A4,3
1
5
40.03.932
Heat sink big 2 SSR
1
6
40.03.372
Mounting device heat sink SSR
1
7
10.00.507
Pan head screw Torx 5/16" T20
6
8
40.03.499
Fan housing *UL*
1
9
40.03.428
Cooling fan
1
10
40.03.257
Converter 230VAC 24VDC
1
16
42.00.080
Control pcb *Sicotronic*
1
17
42.00.128
SD-memory card 4GB
1
18
40.04.000
Mounting base for control pcb
1
19
10.00.989
Rivet with screw
2
20
10.00.243
Spacer M4x8
1
21
1104.0121
Hex nut M4 self locking
2
22
40.03.756
Fixing clip f. pcb
1
23
40.03.533
Fixing clip f. pcb
4
24
40.03.998
Bus cable 1.15m
1
27
40.00.283
Power transformer
1
29
1008.0761
Hex screw M8x25
1
35
40.04.034
Loudspeaker K 64 WPT
1
A
Electrical installation
1
4/30/2012
3 AC480V (440V) 60Hz UL
7
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Electrical installation
4/30/2012
3 AC480V (440V) 60Hz UL
8
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Electrical installation
Pos.
Part No.
Description
Qty.
1
40.03.360
Contactor assembly
1
2
40.03.981
Cable clock switch USA
1
6
40.03.612
Cable control harness
1
8
40.01.329
Dry up protector 183°
1
9
3014.0302
Hex nut M10 for dry-up protector
1
10
40.01.482
Safety temperature limiter 365°C
1
11
3014.0327
Hex nut M10x1,0
1
12
40.03.668
Contactor B&J K3-24B00 190 R
1
13
40.02.641
Auxilliary contact B&J HN10 N/O
1
17
40.03.348
Control transformer T1
1
18
10.01.065
Hex nut M5
1
19
40.03.404
Mounting support transformer
1
20
10.01.065
Hex nut M5
1
21
40.02.426
Varistor
1
25
4001.0224
Fuse 6.35x32mm
2
25
40.01.588
Fuse SC-8A 10x38
2
26
40.01.487
Fuse holder 2pol
1
26
40.02.512
Fuse holder 2x6.3A
1
27
40.01.486
Fuse holder 3pol KTK-R
1
28
4001.0206
Fuse
3
29
10.00.365
Pan head screw Torx M3x20
2
37
40.03.955
Terminal block grey WKN 10/U
3
39
40.03.731
Earth terminal WKN 35SL/U
1
40
40.03.955
Terminal block grey WKN 10/U
1
44
4001.1203
End plate for mounting rail
1
47
40.03.282
Drip protection for air inlet filter 1 UL
1
48
10.00.709
Hex nut M6 w. locking
1
49
10.01.218
Edge protection profile
1
50
40.03.755
Cover behind 2 UL
1
51
10.00.365
Pan head screw Torx M3x20
2
54
40.04.122
Cover for Fuse *UL*
5
4/30/2012
3 AC480V (440V) 60Hz UL
9
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
ClimaPlus
4/30/2012
3 AC480V (440V) 60Hz UL
10
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
ClimaPlus
Pos.
Part No.
Description
Qty.
1
22.00.882
Mounting device f. pressure sensor
1
2
3017.1011
Pressure sensor for humidity control Huba 401
1
4
22.00.850
Outer humidity meas. Piece
1
5
22.00.881
Gasket f. hum. meas. Pipe
1
6
1104.0122
Hex combination nut M4 galv
3
7
22.00.525
Hose set f. humidity control
1
8
22.00.725
Humidity control cpl.
1
9
22.00.914
Air inlet pipe
1
10
22.00.961
Drain hose for humidity control
1
11
2066.0527
Hose clamp ø14mm
2
12
22.00.767
Vent cover
1
13
22.00.837
O-ring for humidity control
2
15
10.00.111
Cable clip long
2
4/30/2012
3 AC480V (440V) 60Hz UL
11
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Steam generator
4/30/2012
3 AC480V (440V) 60Hz UL
12
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Steam generator
Pos.
Part No.
Description
Qty.
1
44.00.939
Steam generator insolated
1
2
10.00.709
Hex nut M6 w. locking
1
14
44.01.343
Heating element
1
17
44.00.279
Gasket f. heating element
1
18
10.00.709
Hex nut M6 w. locking
9
19
2066.0519
Hose clamp 35,6mm
1
20
2066.0526
Hose clamp ø46mm
1
21
44.00.207
Emptying pump
1
22
1006.0762
Hex screw M6x10
2
23
1306.0222
Washer A6,4x15x1,5
2
24
44.01.201
Fixing device f. pump steam generator
1
25
10.00.709
Hex nut M6 w. locking
2
26
44.01.220
Drain hose steam generator
1
27
40.04.106
Thermocouple steam generator *B5*
1
29
10.00.414
Cable strap black 120°
1
30
1104.0122
Hex combination nut M4 galv
1
31
2112.1006
Steam hose 50x7mm
1
32
2066.0504
Hose clamp 40-60mm
2
34
44.00.280
Gasket f. heating element+Level elektrode insert
1
35
2920.1300
Level elektrode insert
1
36
10.00.709
Hex nut M6 w. locking
4371
38
44.01.168
Fixing angle steam generator
1
43
2066.0518
Hose clamp 30mm
2
A
8354.1320
Pump connection spout cpl.
1
4/30/2012
3 AC480V (440V) 60Hz UL
13
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Pump connection spout
4/30/2012
3 AC480V (440V) 60Hz UL
14
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Pump connection spout
Pos.
Part No.
Description
Qty.
1
2118.1000
Pump connection spout
1
2
2120.1259
Stop plug 10mm
1
3
2110.1008
Silicon hose ø10x2mm
1
4
2066.0527
Hose clamp ø14mm
2
5
2066.0530
Hose clamp ø16.4mm
1
6
2062.0331
Junction pressure hose GS 10
1
7
4005.0101
Tie rap 145 mm
1
4/30/2012
3 AC480V (440V) 60Hz UL
15
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Hot air heating
4/30/2012
3 AC480V (440V) 60Hz UL
16
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Hot air heating
Pos.
Part No.
Description
Qty.
1
40.03.410
Mating flange f. heating assembly
1
2
40.03.641
Heating assembly
1
4
10.00.109
Hex screw M5x23
6
5
10.01.076
Cap nut M5*A2
1
6
40.03.415
Gasket f. heating assembly
1
7
1107.0103
Star lock ø3
2
17
50.00.844
Nozzle f. moistening
1
18
50.00.846
Union nut M12x13.2 N
1
4/30/2012
3 AC480V (440V) 60Hz UL
17
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Motor and fan wheel
4/30/2012
3 AC480V (440V) 60Hz UL
18
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Motor and fan wheel
Pos.
Part No.
Description
Qty.
1
40.03.514
Fan motor
1
3
10.01.049
Square necked mushroom head bolt 6x30
4
4
10.00.709
Hex nut M6 w. locking
2
5
22.00.721
Flange f. motor shaft gasket
1
6
22.00.722
Mounting support f. gasket flange
1
7
22.00.083
Motor shaft gasket
1
8
20.01.755
Isolation for mounting plate for motor
1
9
10.01.065
Hex nut M5
3
10
22.00.829
Fan wheel
1
11
10.00.565
Hex screw M8x20
1
12
1308.0162
Washer A8,4
1
13
10.00.111
Cable clip long
3
14
20.01.411
Bushing for motor mounting bar
4
4/30/2012
3 AC480V (440V) 60Hz UL
19
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Interior cabinet
4/30/2012
3 AC480V (440V) 60Hz UL
20
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Interior cabinet
Pos.
Part No.
Description
Qty.
1
40.00.290
Thermocouple humidity
1
2
10.00.087
Clamp strap f. sensor
1
3
10.00.100
Hex nut M4, self-locking
1
7
40.04.114
Wiring interior light
1
8
40.00.098
Reflector f. interior light
1
9
40.00.091
Gasket frame w. glass a. gaskets
1
10
3024.0201
Halogen bulb 300°C
1
11
20.01.801
Door gasket
1
12
40.04.098
Meat probe sensor
1
13
10.00.612
Hex nut M16 flat
1
14
1315.0104
Copper washer 16x20x1,5
1
16
40.01.317
Screen core temperature sensor
1
17
10.01.076
Cap nut M5*A2
2
20
40.04.096
Thermocouple interior cabinet B1
1
21
40.03.782
Screen interior cabinet sensor
1
22
10.01.076
Cap nut M5*A2
2
23
54.01.117
Outlet sieve
1
24
40.01.482
Safety temperature limiter 365°C
1
25
3014.0327
Hex nut M10x1,0
1
A
22.00.742
Air baffle
1
4/30/2012
3 AC480V (440V) 60Hz UL
21
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Air baffle
4/30/2012
3 AC480V (440V) 60Hz UL
22
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Air baffle
Pos.
Part No.
Description
Qty.
4
22.00.730
Hand protection
1
6
10.00.515
Rivet 3,2x5 A4
4
7
40.03.780
Fixing clip core temp. cable
1
8
22.00.491
Surge guard for Meat probe sensor
1
9
2760.1370
Latch hook for air baffle
2
10
1604.0167
Rivet 4x10
3
11
22.00.361
Deep-draw f. air baffle
1
12
10.00.515
Rivet 3,2x5 A4
4
13
10.00.744
Washer A4,3 *A4
1
4/30/2012
3 AC480V (440V) 60Hz UL
23
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Door
4/30/2012
3 AC480V (440V) 60Hz UL
24
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Door
Pos.
Part No.
Description
Qty.
1
24.00.152
Door handle
1
2
24.00.176
Door lock
1
6
24.00.504
Lock cover
1
8
24.00.133
Door mounting support top
1
9
1008.0768
Ornamental screw M8x16
3
11
24.00.223
Door mounting support bottom
1
12
1006.1962
Countersunk screw Torx M6x16
2
14
24.00.137
Door bolt
1
15
10.01.162
1
17
24.00.048
Door bolt
1
18
1008.0769
Ornamental screw M8x30
1
20
2001.0109
Compression spring
1
21
24.00.141
Holding bracket f. door catch
1
22
1006.0760
Hex screw M6x16
2
24
24.00.142
Door catch
1
25
1005.2000
Interlocking tooth screw M5x8
1
27
24.01.100
Spring clip f. door lock
1
A
24.00.105
Door
1
4/30/2012
3 AC480V (440V) 60Hz UL
25
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Door
4/30/2012
3 AC480V (440V) 60Hz UL
26
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Door
Pos.
Part No.
Description
Qty.
1
24.00.198
Inner glass pane
1
2
24.00.147
Sleeve for door bolt top
1
3
24.00.146
Door setting bolt
1
4
24.00.502
Fixing device f. magnet with magnet
1
5
24.01.188
Drain door drip collector
1
6
24.01.801
Door drip collector
1
9
24.00.171
Silicone buffer 7mm for door
1
10
1005.1966
Countersunk screw Torx M5x16
2
11
10.00.041
Rivet nut M5 hexagon closed
2
4/30/2012
3 AC480V (440V) 60Hz UL
27
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Exterior cabinet
4/30/2012
3 AC480V (440V) 60Hz UL
28
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Exterior cabinet
Pos.
Part No.
Description
Qty.
1
1104.0820
Snap nut 4,2mm
3
2
1110.0800
Cage nut M10
3
3
12.00.205
Upper part of pedestal
4
4
12.01.133
Lower part of pedestal
4
6
10.00.975
Hex screw M10x35
4
7
12.00.516
Turning lock f. lower part of pedestal
4
8
10.00.745
Cap nut M6*A2
1
9
1206.0120
Tooth lock washer A6,4
1
10
16.01.146
Bracket for door contact switch
1
12
10.01.214
Interlocking tooth screw M5x10
1
13
22.00.767
Vent cover
1
14
16.01.965
Opening mechanism for panel insert
1
18
40.00.335
Door switch
1
A
Exterior cabinet
1
4/30/2012
3 AC480V (440V) 60Hz UL
29
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Exterior cabinet
4/30/2012
3 AC480V (440V) 60Hz UL
30
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Exterior cabinet
Pos.
Part No.
Description
Qty.
1
16.02.153
Top cover
1
2
1003.2265
Countersunk self tapping screw 4,2x16
10
3
1104.0820
Snap nut 4,2mm
10
5
16.00.146
Side panel right
1
6
1603.0166
Rivet 3,2x7,9 CNS closed
4
7
16.00.147
Side panel left
1
8
10.00.992
Hex self tapping screw B4,2x32
2
9
1104.0820
Snap nut 4,2mm
2
10
16.02.343
Back panel
1
11
16.01.856
Front panel
1
12
1603.0166
Rivet 3,2x7,9 CNS closed
4
15
16.01.511
Crossbar below
1
16
1004.2160
Hex self tapping screw 4,2x16
3
17
1107.0100
Star lock ø4
5
18
50.00.751
Tulip for handshower with tape
1
19
16.00.186
Crossbar top
1
20
1603.0166
Rivet 3,2x7,9 CNS closed
4
22
16.01.748
Gasket f. breather tube d=63mm
1
24
40.02.684
Air inlet filter cpl.
1
25
16.00.329
Cover f. USB interface
1
26
10.00.103
EJOT PT-screw KA 3.5x10
1
27
40.04.046
Interface cable USB 1.0m
1
28
10.00.460
EJOT PT-Screw Torx 3,5x14
2
29
50.00.300
Drip collector
1
30
50.00.303
Bushing drip collector
2
31
50.01.192
Drain pipe
1
32
50.00.296
Clip f. drip collector
4
33
1107.0100
Star lock ø4
6
34
56.00.445
Frame for drawer CareControl
1
4/30/2012
3 AC480V (440V) 60Hz UL
31
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Water
4/30/2012
3 AC480V (440V) 60Hz UL
32
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Water
Pos.
Part No.
Description
Qty.
1
54.00.739
Ventilation pipe
1
2
54.01.141
Rubber form piece venting pipe
1
3
2066.0516
Hose clamp 60-80 mm
2
4
50.00.086
Locking plate f. water distribution
1
6
2066.0205
Hose clamp 8-16x9 mm SW 7mm
2
8
50.00.313
T-fitting water connection
1
9
50.01.238
Hand shower roll guide *lead free*
1
10
50.01.213
Connect. pipe f. hand shower roll guide
1
11
50.00.085
Plug-in spring f. hand shower roll guide
1
12
50.00.130
Hand shower
1
13
50.00.156
Clamp f. hand shower roll guide
1
15
1105.0121
Hex combination nut M5 galv
1
25
54.00.357
Ball valve drain SCC cpl.
1
27
10.00.449
Pan head screw M6x16
2
28
10.00.511
O-ring for ball valve drain 46x3.5
1
29
10.00.512
O-ring for ball valve drain 26x3.5
1
30
54.01.169
Inspection lid, quenching nozzle, B2
1
31
54.01.168
Gasket f. inspection lid quenching
1
32
54.01.191
Collecting pan
1
33
10.00.745
Cap nut M6*A2
1
34
50.01.050
Triple solenoid valve
1
35
50.00.071
Water distribution hor. w/o roll guide con.
1
38
2067.0050
Pressure hose d10mm
1.1
39
2067.0050
Pressure hose d10mm
.41
41
50.01.523
Water volume sensor
1
42
2067.0050
Pressure hose d10mm
.53
47
50.01.146
Single solenoid valve
1
48
50.00.070
Water distribution hor roll guide con.
1
49
2067.0050
Pressure hose d10mm
.4
50
50.00.078
Non return valve DW16/DN12
2
51
8354.1304
Venting valve for steam generator
1
52
1900.0202
Water filter
3
55
2022.0101
Grommet d8mm
1
4/30/2012
3 AC480V (440V) 60Hz UL
33
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
CleanJet + Care
4/30/2012
3 AC480V (440V) 60Hz UL
34
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
CleanJet + Care
Pos.
Part No.
Description
Qty.
1
56.00.185
Pump f. cleaning UP30
1
2
12.00.898
Housing f. Cleaning pump
1
3
1004.0666
Hex screw M4x10
1
4
56.00.166
Pressure hose f. cleaning
1
5
2066.0518
Hose clamp 30mm
1
6
2066.0521
Hose clamp 27mm
1
7
56.00.607
Suction hose f. cleaning
1
8
2066.0518
Hose clamp 30mm
2
11
10.00.980
EJOT PT-Screw K30x10
4
12
56.00.492
Care container table unit
1
13
56.00.462
Bushing care container/pump
1
14
10.00.984
Hose clamp CLIC d=27.5mm
2
15
56.00.451
Pump f. CareControl DPS 35
1
16
56.00.540
Care hose 1
1
17
2066.0518
Hose clamp 30mm
1
18
40.02.965
Cable harness solenoid valve / SC-pump
1
19
2067.0164
Pressure hose ø10mm 650mm long
1
20
10.00.873
Hose clamp CLIC d=15.5mm
1
21
56.00.537
Pipe f. Care hose
1
22
10.00.983
Hose clamp CLIC d=23mm
1
23
56.00.457
Care hose 2
1
24
10.00.605
Hose clamp ø25.3
1
25
10.00.979
Cable clamp D=22
1
26
1005.2000
Interlocking tooth screw M5x8
1
29
56.00.488
Drawer Care container
1
32
56.00.375
Cover for pump
1
33
10.01.214
Interlocking tooth screw M5x10
2
35
2067.0050
Pressure hose d10mm
.65
4/30/2012
3 AC480V (440V) 60Hz UL
35
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Standard accessory
4/30/2012
3 AC480V (440V) 60Hz UL
36
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Standard accessory
Pos.
Part No.
Description
Qty.
1
60.62.100
Hinging rack left
1
2
60.62.101
Hinging rack right
1
3
60.71.022
Positioning support f. core sensor
1
8
10.01.193
Sticker set
1
10
60.71.379
Water connection kit, table unit E/USA
1
A
Internal fat drain
1
4/30/2012
3 AC480V (440V) 60Hz UL
37
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Internal fat drain
4/30/2012
3 AC480V (440V) 60Hz UL
38
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Internal fat drain
Pos.
Part No.
Description
Qty.
1
60.72.619
Jerry can 10l (2,64USGAL)
1
2
60.72.608
Drain pipe with bajonett
1
3
60.72.729
Ball valve DN32 (1 1/4")
1
4
60.72.432
Sealing ring
1
5
60.72.594
End cap for Internal fat drain
1
6
60.72.617
Grease collector 2/1
1
4/30/2012
3 AC480V (440V) 60Hz UL
39
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Index
Part-no.
Description
Page
10.01.162
.........................................................................
.25...................
.
22.00.742
Air baffle
...............................................................21...................
.
40.02.684
Air inlet filter cpl.
.......................................................31...................
.
22.00.914
Air inlet pipe
...........................................................11...................
.
40.02.641
Auxilliary contact B&J HN10 N/O
.....................................
.9.....................
16.02.343
Back panel
.............................................................31...................
.
60.72.729
Ball valve DN32 (1 1/4")
...............................................39....................54.00.357
Ball valve drain SCC cpl.
.............................................
.33...................
.
16.01.146
Bracket for door contact switch
.......................................
.29...................
.
40.03.998
Bus cable 1.15m
.......................................................7.....................
56.00.462
Bushing care container/pump
.........................................35...................
.
50.00.303
Bushing drip collector
.................................................
.31...................
.
20.01.411
Bushing for motor mounting bar
.......................................19...................
.
10.00.979
Cable clamp D=22
.....................................................35...................
.
10.00.111
Cable clip long
.........................................................
11, 19
................40.03.981
Cable clock switch USA
...............................................9.....................
40.03.612
Cable control harness
.................................................9.....................
40.02.965
Cable harness solenoid valve / SC-pump
.............................35...................
.
40.03.516
Cable MMI - CPU
.....................................................
.5.....................
40.03.515
Cable MMI - TFT
.....................................................
.5.....................
40.03.467
Cable On-Off switch MMI
.............................................
.5.....................
10.00.414
Cable strap black 120°
...............................................
.13...................
.
1110.0800
Cage nut M10
.........................................................29....................10.01.076
Cap nut M5*A2
.......................................................
.
17, 21
...............
.
10.00.745
Cap nut M6*A2
.......................................................
.
29, 33
...............
.
56.00.492
Care container table unit
.............................................
.35...................
.
56.00.540
Care hose 1
...........................................................35...................
.
56.00.457
Care hose 2
...........................................................35...................
.
50.00.156
Clamp f. hand shower roll guide
.......................................33...................
.
10.00.087
Clamp strap f. sensor
.................................................
.21...................
.
50.00.296
Clip f. drip collector
...................................................
.31...................
.
54.01.191
Collecting pan
.........................................................33...................
.
4/30/2012
3 AC480V (440V) 60Hz UL
40
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Index
Part-no.
Description
Page
2001.0109
Compression spring
...................................................25...................
.
50.01.213
Connect. pipe f. hand shower roll guide
...............................33...................
.
40.03.360
Contactor assembly
...................................................9.....................
.
40.03.668
Contactor B&J K3-24B00 190 R
.......................................9.....................
.
87.01.005
Control panel insert with overlay
.....................................
.5.....................
.
42.00.080
Control pcb *Sicotronic*
...............................................7.....................
.
42.00.112
Control pcb *TFT*
.....................................................5......................40.03.348
Control transformer T1
...............................................
.9.....................
.
40.03.257
Converter 230VAC 24VDC
...........................................
.7.....................
.
40.03.428
Cooling fan
...........................................................
.7.....................
.
1315.0104
Copper washer 16x20x1,5
...........................................
.21...................
.
1005.1966
Countersunk screw Torx M5x16
.......................................27...................
.
1006.1962
Countersunk screw Torx M6x16
.......................................25...................
.
1003.2265
Countersunk self tapping screw 4,2x16
...............................31...................
.
40.03.755
Cover behind 2 UL
...................................................
.9......................16.01.910
Cover f. control pcb w. gasket
.........................................5.....................
.
16.00.329
Cover f. USB interface
.................................................31...................
.
40.04.122
Cover for Fuse *UL*
...................................................9.....................
.
56.00.375
Cover for pump
.......................................................
.35...................
.
16.01.511
Crossbar below
.......................................................
.31...................
.
16.00.186
Crossbar top
...........................................................31...................
.
22.00.361
Deep-draw f. air baffle
.................................................23...................
.
16.02.062
Dial f. pulse generator
.................................................5......................24.00.105
Door..................................................................
.25...................
.
24.00.137
Door bolt
...............................................................25...................
.
24.00.048
Door bolt
...............................................................25...................
.
24.00.142
Door catch
.............................................................25...................
.
24.01.801
Door drip collector
.....................................................27...................
.
20.01.801
Door gasket
...........................................................
.21...................
.
24.00.152
Door handle
...........................................................25...................
.
24.00.176
Door lock
.............................................................
.25...................
.
24.00.223
Door mounting support bottom
.......................................
.25...................
.
4/30/2012
3 AC480V (440V) 60Hz UL
41
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Index
Part-no.
Description
Page
24.00.133
Door mounting support top
...........................................
.25...................
.
24.00.146
Door setting bolt
.......................................................27...................
.
40.00.335
Door switch
...........................................................
.29...................
.
24.01.188
Drain door drip collector
...............................................27...................
.
22.00.961
Drain hose for humidity control
.......................................
.11...................
.
44.01.220
Drain hose steam generator
...........................................13...................
.
50.01.192
Drain pipe
.............................................................
.31....................60.72.608
Drain pipe with bajonett
...............................................39...................
.
56.00.488
Drawer Care container
...............................................
.35...................
.
50.00.300
Drip collector
.........................................................
.31...................
.
40.03.282
Drip protection for air inlet filter 1 UL
.................................
.9.....................
40.01.329
Dry up protector 183°
.................................................
.9.....................
40.03.731
Earth terminal WKN 35SL/U
...........................................9.....................
10.01.218
Edge protection profile
...............................................
.9.....................
10.00.980
EJOT PT-Screw K30x10
.............................................
.35....................10.00.103
EJOT PT-screw KA 3.5x10
...........................................
.31...................
.
10.00.460
EJOT PT-Screw Torx 3,5x14
.........................................
.31...................
.
44.00.207
Emptying pump
.......................................................
.13...................
.
60.72.594
End cap for Internal fat drain
.........................................
.39...................
.
4001.1203
End plate for mounting rail
...........................................
.9.....................
40.03.499
Fan housing *UL*
.....................................................
.7.....................
40.03.514
Fan motor
.............................................................
.19...................
.
22.00.829
Fan wheel
.............................................................19....................44.01.168
Fixing angle steam generator
.........................................13...................
.
40.03.780
Fixing clip core temp. cable
...........................................23...................
.
40.03.756
Fixing clip f. pcb
.......................................................7.....................
40.03.533
Fixing clip f. pcb
.......................................................7.....................
24.00.502
Fixing device f. magnet with magnet
.................................
.27...................
.
44.01.201
Fixing device f. pump steam generator
...............................
.13...................
.
22.00.721
Flange f. motor shaft gasket
...........................................19...................
.
56.00.445
Frame for drawer CareControl
.......................................
.31...................
.
16.01.856
Front panel
...........................................................
.31...................
.
4/30/2012
3 AC480V (440V) 60Hz UL
42
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Index
Part-no.
Description
Page
4001.0206
Fuse..................................................................
.9.....................
.
4001.0224
Fuse 6.35x32mm
.....................................................
.9.....................
.
40.01.487
Fuse holder 2pol
.......................................................9.....................
.
40.02.512
Fuse holder 2x6.3A
...................................................
.9.....................
.
40.01.486
Fuse holder 3pol KTK-R
...............................................9.....................
.
40.01.588
Fuse SC-8A 10x38
...................................................
.9.....................
.
16.01.748
Gasket f. breather tube d=63mm
.....................................
.31....................40.03.415
Gasket f. heating assembly
...........................................
.17...................
.
44.00.279
Gasket f. heating element
.............................................13...................
.
44.00.280
Gasket f. heating element+Level elektrode insert
.....................13...................
.
22.00.881
Gasket f. hum. meas. Pipe
...........................................
.11...................
.
54.01.168
Gasket f. inspection lid quenching
.....................................33...................
.
40.00.091
Gasket frame w. glass a. gaskets
.....................................21...................
.
60.72.617
Grease collector 2/1
...................................................39...................
.
2022.0101
Grommet d8mm
.......................................................33....................3024.0201
Halogen bulb 300°C
...................................................21...................
.
22.00.730
Hand protection
.......................................................
.23...................
.
50.00.130
Hand shower
.........................................................
.33...................
.
50.01.238
Hand shower roll guide *lead free*
...................................
.33...................
.
40.03.932
Heat sink big 2 SSR
...................................................7.....................
.
40.03.641
Heating assembly
.....................................................17...................
.
44.01.343
Heating element
.......................................................13...................
.
1104.0122
Hex combination nut M4 galv
.........................................
.
11, 13
................1105.0121
Hex combination nut M5 galv
.........................................
.33...................
.
1104.0121
Hex nut M4 self locking
...............................................
.7.....................
.
10.00.100
Hex nut M4, self-locking
...............................................21...................
.
10.01.065
Hex nut M5
...........................................................
.
9, 19
.................
.
10.00.709
Hex nut M6 w. locking
.................................................
9, 13, 19
.............
.
3014.0302
Hex nut M10 for dry-up protector
.....................................
.9.....................
.
3014.0327
Hex nut M10x1,0
.....................................................
.
9, 21
.................
.
10.00.612
Hex nut M16 flat
.......................................................21...................
.
1004.0666
Hex screw M4x10
.....................................................35...................
.
4/30/2012
3 AC480V (440V) 60Hz UL
43
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Index
Part-no.
Description
Page
10.00.109
Hex screw M5x23
.....................................................17...................
.
1006.0762
Hex screw M6x10
.....................................................13...................
.
1006.0760
Hex screw M6x16
.....................................................25...................
.
10.00.565
Hex screw M8x20
.....................................................19...................
.
1008.0761
Hex screw M8x25
.....................................................7.....................
10.00.975
Hex screw M10x35
...................................................
.29...................
.
1004.2160
Hex self tapping screw 4,2x16
.......................................
.31....................10.00.992
Hex self tapping screw B4,2x32
.......................................31...................
.
60.62.100
Hinging rack left
.......................................................37...................
.
60.62.101
Hinging rack right
.....................................................
.37...................
.
24.00.141
Holding bracket f. door catch
.........................................
.25...................
.
2066.0205
Hose clamp 8-16x9 mm SW 7mm
.....................................33...................
.
2066.0521
Hose clamp 27mm
...................................................
.35...................
.
2066.0518
Hose clamp 30mm
...................................................
.
13, 35
...............
.
2066.0519
Hose clamp 35,6mm
.................................................
.13....................2066.0504
Hose clamp 40-60mm
.................................................13...................
.
2066.0516
Hose clamp 60-80 mm
...............................................
.33...................
.
10.00.873
Hose clamp CLIC d=15.5mm
.........................................
.35...................
.
10.00.983
Hose clamp CLIC d=23mm
...........................................
.35...................
.
10.00.984
Hose clamp CLIC d=27.5mm
.........................................
.35...................
.
2066.0527
Hose clamp ø14mm
...................................................
11, 15
...............
.
2066.0530
Hose clamp ø16.4mm
.................................................15...................
.
10.00.605
Hose clamp ø25.3
.....................................................35....................2066.0526
Hose clamp ø46mm
...................................................13...................
.
22.00.525
Hose set f. humidity control
...........................................
.11...................
.
12.00.898
Housing f. Cleaning pump
.............................................35...................
.
22.00.725
Humidity control cpl.
...................................................11...................
.
24.00.198
Inner glass pane
.......................................................27...................
.
54.01.169
Inspection lid, quenching nozzle, B2
.................................
.33...................
.
40.04.046
Interface cable USB 1.0m
.............................................31...................
.
1005.2000
Interlocking tooth screw M5x8
.........................................
25, 35
...............
.
10.01.214
Interlocking tooth screw M5x10
.......................................
29, 35
...............
.
4/30/2012
3 AC480V (440V) 60Hz UL
44
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Index
Part-no.
Description
Page
20.01.755
Isolation for mounting plate for motor
.................................19...................
.
60.72.619
Jerry can 10l (2,64USGAL)
...........................................
.39...................
.
2062.0331
Junction pressure hose GS 10
.......................................
.15...................
.
2760.1370
Latch hook for air baffle
...............................................23...................
.
2920.1300
Level elektrode insert
.................................................
.13...................
.
24.00.504
Lock cover
.............................................................25...................
.
50.00.086
Locking plate f. water distribution
.....................................
.33....................40.04.034
Loudspeaker K 64 WPT
...............................................7.....................
.
12.01.133
Lower part of pedestal
.................................................29...................
.
40.03.410
Mating flange f. heating assembly
.....................................17...................
.
40.04.098
Meat probe sensor
...................................................
.21...................
.
42.00.081
MMI pcb
...............................................................5.....................
.
22.00.083
Motor shaft gasket
.....................................................19...................
.
40.04.000
Mounting base for control pcb
.........................................7.....................
.
22.00.882
Mounting device f. pressure sensor
...................................11....................40.03.372
Mounting device heat sink SSR
.......................................7.....................
.
22.00.722
Mounting support f. gasket flange
.....................................19...................
.
40.03.404
Mounting support transformer
.........................................9.....................
.
50.00.078
Non return valve DW16/DN12
.........................................33...................
.
50.00.844
Nozzle f. moistening
...................................................17...................
.
10.00.512
O-ring for ball valve drain 26x3.5
.....................................
.33...................
.
10.00.511
O-ring for ball valve drain 46x3.5
.....................................
.33...................
.
22.00.837
O-ring for humidity control
.............................................11....................16.01.965
Opening mechanism for panel insert
.................................
.29...................
.
1008.0768
Ornamental screw M8x16
.............................................25...................
.
1008.0769
Ornamental screw M8x30
.............................................25...................
.
22.00.850
Outer humidity meas. Piece
...........................................11...................
.
54.01.117
Outlet sieve
...........................................................
.21...................
.
10.00.449
Pan head screw M6x16
...............................................33...................
.
10.00.507
Pan head screw Torx 5/16" T20
.......................................7.....................
.
10.00.365
Pan head screw Torx M3x20
.........................................
.9.....................
.
10.00.061
Pan head screw Torx T20 M4x12
.....................................7.....................
.
4/30/2012
3 AC480V (440V) 60Hz UL
45
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Index
Part-no.
Description
Page
56.00.537
Pipe f. Care hose
.....................................................
.35...................
.
50.00.085
Plug-in spring f. hand shower roll guide
...............................33...................
.
60.71.022
Positioning support f. core sensor
.....................................37...................
.
40.00.283
Power transformer
.....................................................7.....................
2067.0050
Pressure hose d10mm
...............................................
.
33, 35
...............
.
56.00.166
Pressure hose f. cleaning
.............................................35...................
.
2067.0164
Pressure hose ø10mm 650mm long
.................................
.35....................3017.1011
Pressure sensor for humidity control Huba 401
.......................11...................
.
40.00.404
Pulse generator
.......................................................
.5.....................
2118.1000
Pump connection spout
...............................................15...................
.
8354.1320
Pump connection spout cpl.
...........................................13...................
.
56.00.451
Pump f. CareControl DPS 35
.........................................
.35...................
.
56.00.185
Pump f. cleaning UP30
...............................................
.35...................
.
40.00.098
Reflector f. interior light
...............................................
.21...................
.
10.00.515
Rivet 3,2x5 A4
.........................................................23....................1603.0166
Rivet 3,2x7,9 CNS closed
.............................................31...................
.
1604.0167
Rivet 4x10
.............................................................23...................
.
10.00.041
Rivet nut M5 hexagon closed
.........................................
.27...................
.
10.00.989
Rivet with screw
.......................................................7.....................
54.01.141
Rubber form piece venting pipe
.......................................33...................
.
40.01.482
Safety temperature limiter 365°C
.....................................
.
9, 21
.................
40.01.317
Screen core temperature sensor
.....................................
.21...................
.
40.03.782
Screen interior cabinet sensor
.........................................21....................42.00.128
SD-memory card 4GB
.................................................7.....................
16.01.908
Sealing f. panel insert
.................................................5.....................
60.72.432
Sealing ring
...........................................................
.39...................
.
16.00.147
Side panel left
.........................................................31...................
.
16.00.146
Side panel right
.......................................................
.31...................
.
2110.1008
Silicon hose ø10x2mm
...............................................
.15...................
.
24.00.171
Silicone buffer 7mm for door
.........................................
.27...................
.
50.01.146
Single solenoid valve
.................................................
.33...................
.
24.00.147
Sleeve for door bolt top
...............................................
.27...................
.
4/30/2012
3 AC480V (440V) 60Hz UL
46
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Index
Part-no.
Description
Page
1104.0820
Snap nut 4,2mm
.......................................................
29, 31
...............
.
40.00.453
Solid state relais
.......................................................7.....................
.
10.00.243
Spacer M4x8
.........................................................
.7.....................
.
24.01.100
Spring clip f. door lock
.................................................25...................
.
10.01.049
Square necked mushroom head bolt 6x30
...........................
.19...................
.
1107.0103
Star lock ø3
...........................................................
.17...................
.
1107.0100
Star lock ø4
...........................................................
.31....................44.00.939
Steam generator insolated
...........................................
.13...................
.
2112.1006
Steam hose 50x7mm
.................................................
.13...................
.
10.01.193
Sticker set
.............................................................37...................
.
2120.1259
Stop plug 10mm
.......................................................15...................
.
56.00.607
Suction hose f. cleaning
...............................................35...................
.
22.00.491
Surge guard for Meat probe sensor
...................................23...................
.
50.00.313
T-fitting water connection
.............................................
.33...................
.
40.03.955
Terminal block grey WKN 10/U
.......................................
.9......................40.00.290
Thermocouple humidity
...............................................
.21...................
.
40.04.096
Thermocouple interior cabinet B1
.....................................21...................
.
40.04.106
Thermocouple steam generator *B5*
.................................
.13...................
.
4005.0101
Tie rap 145 mm
.......................................................
.15...................
.
1204.0120
Tooth lock washer A4,3
...............................................7.....................
.
1206.0120
Tooth lock washer A6,4
...............................................29...................
.
16.02.153
Top cover
.............................................................
.31...................
.
50.01.050
Triple solenoid valve
...................................................33....................50.00.751
Tulip for handshower with tape
.......................................
.31...................
.
12.00.516
Turning lock f. lower part of pedestal
.................................
.29...................
.
50.00.846
Union nut M12x13.2 N
.................................................17...................
.
12.00.205
Upper part of pedestal
.................................................29...................
.
40.02.426
Varistor
...............................................................
.9.....................
.
22.00.767
Vent cover
.............................................................
11, 29
...............
.
54.00.739
Ventilation pipe
.......................................................
.33...................
.
8354.1304
Venting valve for steam generator
...................................
.33...................
.
10.00.744
Washer A4,3 *A4
.....................................................
.23...................
.
4/30/2012
3 AC480V (440V) 60Hz UL
47
SelfCooking Center 62 - 6 x 2/1 GastronormE
E62SH11122284870
Index
Part-no.
Description
Page
1306.0222
Washer A6,4x15x1,5
.................................................
.13...................
.
1308.0162
Washer A8,4
...........................................................19...................
.
60.71.379
Water connection kit, table unit E/USA
...............................
.37...................
.
50.00.070
Water distribution hor roll guide con.
.................................
.33...................
.
50.00.071
Water distribution hor. w/o roll guide con.
.............................33...................
.
1900.0202
Water filter
.............................................................33...................
.
50.01.523
Water volume sensor
.................................................
.33....................40.04.114
Wiring interior light
.....................................................21...................
.
4/30/2012
3 AC480V (440V) 60Hz UL
48
Loading...
