Service part catalogue
SelfCooking Center® Linie
SelfCooking Center 62G
validity: 10/2008
03.03.2009
1NAC230V 50/60Hz
SelfCooking Center 62G
validity: 10/2008
Overview
03.03.2009
1NAC230V 50/60Hz
2
SelfCooking Center 62G
validity: 10/2008
Overview
Pos.
Module
Page
1
Control panel
............................................................................2
Electrical installation
.....................................................................3ClimaPlus
................................................................................4
Steam generator
.........................................................................5Hot air heating
...........................................................................6Motor and fan wheel
.....................................................................7Interior cabinet
...........................................................................8Door.....................................................................................9
Exterior cabinet
..........................................................................10
Water
....................................................................................11
CleanJet + Care
.........................................................................12Gas parts
................................................................................13
Miscellaneous
...........................................................................
03.03.2009
1NAC230V 50/60Hz
4
...........
.6...........
.10.........
.12.........
.18.........
.22.........
.24.........
.28.........
.32.........
.36.........
.40.........
.42.........
.48.........
.
3
SelfCooking Center 62G
validity: 10/2008
Control panel
03.03.2009
1NAC230V 50/60Hz
4
SelfCooking Center 62G
validity: 10/2008
Control panel
Pos.
Part No.
Description
Qty.
1
87.00.000
Control panel insert with overlay
1
2
42.00.002
Control pcb
1
3
10.00.916
Hex nut M4 w. locking
6
4
10.00.355
Spacer black
6
5
2020.0400
Fixing device for cable harness
2
6
16.00.232
Dial f. pulse generator blue
1
7
40.00.404
Pulse generator
1
9
40.02.087
Buzzer
1
10
1104.0121
Hex nut M4 self locking
1
11
5110.1029
Gasket mode switch
1
14
16.00.387
Mounting device f.sealing + sealing lip
1
03.03.2009
1NAC230V 50/60Hz
5
SelfCooking Center 62G
validity: 10/2008
Electrical installation
03.03.2009
1NAC230V 50/60Hz
6
SelfCooking Center 62G
validity: 10/2008
Electrical installation
Pos.
Part No.
Description
Qty.
1
10.00.709
Hex nut M6 w. locking
2
2
10.00.239
EJOT PT-Screw Torx 4x10
3
16
42.00.065
Relay-I/O pcb
1
17
40.00.417
Fixing clip f. pcb
2
18
1104.0801
Cage nut M4
1
19
10.00.243
Spacer M4x8
1
20
1104.0120
Hex nut M4
1
21
40.01.579
Fixing clip f. pcb
3
22
40.00.471
Bus cable 0.8m
1
22
40.00.471
Bus cable 0.8m
1
25
10.00.112
Cable clip short
4
27
10.00.421
Cable clip
8
28
10.00.111
Cable clip long
4
28
10.00.111
Cable clip long
1
29
10.00.112
Cable clip short
2
31
10.00.471
Cable clip d10-12mm
3
32
10.00.471
Cable clip d10-12mm
3
43
1106.0160
Hex nut M6
1
44
1206.0120
Tooth lock washer A6,4
1
45
4002.0110
Cable connector, junction
2
57
40.01.596
Power supply cable 3x2,5mm² 3m
1
59
40.00.320
Cable connection M20x1.5
1
A
Electrical installation
1
03.03.2009
1NAC230V 50/60Hz
7
SelfCooking Center 62G
validity: 10/2008
Electrical installation
03.03.2009
1NAC230V 50/60Hz
8
SelfCooking Center 62G
validity: 10/2008
Electrical installation
Pos.
Part No.
Description
Qty.
2
10.00.111
Cable clip long
4
3
40.02.515
Dry up protector 315°F/157°C
1
4
3014.0302
Hex nut M10 for dry-up protector
1
5
40.01.482
Safety temperature limiter 365°C
1
6
3014.0327
Hex nut M10x1,0
1
7
40.02.917
Contactor 3TG1010-2AK2
1
10
3101.1008
Cooling fan
1
11
10.00.238
Screw Torx 4x50
2
13
40.00.277
Control transformer
1
14
10.00.239
EJOT PT-Screw Torx 4x10
1
15
40.01.483
Electronic noise filter
1
21
40.02.512
Fuse holder 2x6.3A
1
26
10.00.240
Screw Torx 3x20
2
47
2005.0106
Protective grid for cooling fan
1
48
4007.0620
Membrane DGC 29
2
53
40.00.519
Installation rail for Contactor 75mm
1
54
10.00.239
EJOT PT-Screw Torx 4x10
2
55
4001.1203
End plate for mounting rail
1
03.03.2009
1NAC230V 50/60Hz
9
SelfCooking Center 62G
validity: 10/2008
ClimaPlus
03.03.2009
1NAC230V 50/60Hz
10
SelfCooking Center 62G
validity: 10/2008
ClimaPlus
Pos.
Part No.
Description
Qty.
1
22.00.326
Mounting device f. pressure sensor
1
2
3017.1011
Pressure sensor for humidity control Huba 401
1
3
10.00.239
EJOT PT-Screw Torx 4x10
1
4
22.00.517
Inner humidity meas. Piece
1
5
22.00.200
Outer humidity meas. Piece
1
6
22.00.198
Gasket f. hum. meas. Pipe
2
7
1104.0122
Hex combination nut M4 galv
6
8
22.00.568
Humidity control cpl. with motor
1
9
3101.1010
Humidity control motor
1
10
3016.0102
Micro switch
1
11
22.00.525
Hose set f. humidity control
1
12
22.00.564
Gasket f. ventilation
1
13
2066.0504
Hose clamp 40-60mm
1
03.03.2009
1NAC230V 50/60Hz
11
SelfCooking Center 62G
validity: 10/2008
Steam generator
03.03.2009
1NAC230V 50/60Hz
12
SelfCooking Center 62G
validity: 10/2008
Steam generator
Pos.
Part No.
Description
Qty.
1
1106.0803
Hex combination nut M6 galv
1
3
72.00.008
Burner steam gen.
1
4
72.00.048
Insulation f. burner steam gen.
1
5
1104.0122
Hex combination nut M4 galv
4
6
70.00.044
Burner pipe
1
7
72.00.020
Gasket f. burner carrier
1
8
1105.0121
Hex combination nut M5 galv
4
9
44.00.251
Ignition electrode steam generator
1
10
1104.0120
Hex nut M4
2
11
44.00.250
Gasket f. ignition electrode
1
17
2066.0519
Hose clamp 35,6mm
1
18
2066.0526
Hose clamp ø46mm
1
19
44.00.207
Emptying pump
1
20
1006.0762
Hex screw M6x10
2
21
1306.0222
Washer A6,4x15x1,5
2
22
44.00.226
Fixing device f. pump steam generator
1
23
10.00.709
Hex nut M6 w. locking
2
24
44.00.234
Drain hose steam generator
1
25
2066.0518
Hose clamp 30mm
2
26
40.01.094
Thermocouple steam gen. (B5)
1
27
44.00.516
Fixing plate steam generator thermostat
1
30
2112.1006
Steam hose 50x7mm
2
31
2066.0504
Hose clamp 40-60mm
4
32
44.00.349
Steam pipe
1
34
2066.0205
Hose clamp 8-16x9 mm SW 7mm
1
35
1105.0120
Hex nut M5
1
36
1205.0120
Tooth lock washer A5,3
1
A
8354.1320
Pump connection spout cpl.
1
B
44.00.183
Steam generator insolated
1
03.03.2009
1NAC230V 50/60Hz
13
SelfCooking Center 62G
validity: 10/2008
Pump connection spout
03.03.2009
1NAC230V 50/60Hz
14
SelfCooking Center 62G
validity: 10/2008
Pump connection spout
Pos.
Part No.
Description
Qty.
1
2118.1000
Pump connection spout
1
2
2120.1259
Stop plug 10mm
1
3
2110.1008
Silicon hose ø10x2mm
1
4
2066.0527
Hose clamp ø14mm
2
5
2066.0530
Hose clamp ø16.4mm
1
6
2062.0331
Junction pressure hose GS 10
1
7
4005.0101
Tie rap 145 mm
1
03.03.2009
1NAC230V 50/60Hz
15
SelfCooking Center 62G
validity: 10/2008
Steam generator, insulated
03.03.2009
1NAC230V 50/60Hz
16
SelfCooking Center 62G
validity: 10/2008
Steam generator, insulated
Pos.
Part No.
Description
Qty.
3
5012.0566
Gasket f. inspection lid
1
4
44.00.263
Panel for revision hole steam generator
1
5
44.00.264
Clamping bar for panel revision hole
1
6
44.00.253
Filling level electrode 85mm
1
7
1105.0121
Hex combination nut M5 galv
2
03.03.2009
1NAC230V 50/60Hz
17
SelfCooking Center 62G
validity: 10/2008
Hot air heating
03.03.2009
1NAC230V 50/60Hz
18
SelfCooking Center 62G
validity: 10/2008
Hot air heating
Pos.
Part No.
Description
Qty.
10
74.00.142
Hot air heat exchanger
1
12
74.00.234
Gasket hot air heat exchanger/interior cabinet
1
13
74.00.313
Mating flange heat exchanger
1
15
74.00.296
Gasket f. heat exchanger below
2
16
1105.0122
Hex combination nut M5 V2A
10
17
1105.0122
Hex combination nut M5 V2A
8
A
74.00.247
Burner hot air
1
03.03.2009
1NAC230V 50/60Hz
19
SelfCooking Center 62G
validity: 10/2008
Burner hot air
03.03.2009
1NAC230V 50/60Hz
20
SelfCooking Center 62G
validity: 10/2008
Burner hot air
Pos.
Part No.
Description
Qty.
1
74.00.230
Ignitionelectrode1 f. hot air
1
2
74.00.235
Ignitionelectrode2 f. hot air
1
3
74.00.290
Gasket electrode hot air
1
4
10.00.696
Allen screw M4x6 w. Precoat 85
4
03.03.2009
1NAC230V 50/60Hz
21
SelfCooking Center 62G
validity: 10/2008
Motor and fan wheel
03.03.2009
1NAC230V 50/60Hz
22
SelfCooking Center 62G
validity: 10/2008
Motor and fan wheel
Pos.
Part No.
Description
Qty.
1
40.00.274
Fan motor
1
3
10.00.710
Hex nut M8 w. locking
4
5
2120.1306
Spacer SW19x17
4
6
1008.1005
Square necked mushroom head bolt 8x40
4
7
22.00.123
Flange f. motor shaft gasket
1
8
22.00.120
Mounting support f. gasket flange
1
9
22.00.083
Motor shaft gasket
1
10
1315.0101
Copper washer 6x10
4
11
1306.0120
Washer A6,4
4
12
1106.0220
Hex nut M6 flat
4
13
22.00.192
Fan wheel d340x135
1
14
10.00.565
Hex screw M8x20
1
15
1308.0162
Washer A8,4
1
16
40.00.310
Exhaust pipe below
1
18
10.00.989
Rivet with screw
2
03.03.2009
1NAC230V 50/60Hz
23
SelfCooking Center 62G
validity: 10/2008
Interior cabinet
03.03.2009
1NAC230V 50/60Hz
24
SelfCooking Center 62G
validity: 10/2008
Interior cabinet
Pos.
Part No.
Description
Qty.
1
2120.1277
Base for sensor connection
1
2
40.00.290
Thermocouple humidity
1
3
40.00.098
Reflector f. interior light
1
4
10.00.041
Rivet nut M5 hexagon closed
4
5
1330.0100
Clamp strap f. sensor
1
6
1106.0224
Hex nut M6 self locking
1
7
1306.0120
Washer A6,4
1
8
1104.0120
Hex nut M4
1
9
1204.0120
Tooth lock washer A4,3
1
10
1006.0760
Hex screw M6x16
1
11
40.00.211
Wiring interior light
1
12
20.00.395
Door gasket
1
13
40.00.294
Meat probe sensor SCC 62
1
14
10.00.612
Hex nut M16 flat
1
15
1315.0104
Copper washer 16x20x1,5
1
17
40.01.317
Screen core temperature sensor
1
18
10.00.745
Cap nut M6*A2
2
21
40.01.097
Thermocouple interior cabinet (B1)
1
22
40.00.531
Screen interior cabinet sensor
1
23
10.00.745
Cap nut M6*A2
1
24
20.00.999
Outlet sieve Ø80
1
25
40.00.091
Gasket frame w. glass a. gaskets
1
26
3024.0201
Halogen bulb 300°C
1
28
50.00.844
Nozzle f. moistening
1
29
50.00.846
Union nut M12x13.2 N
1
A
22.00.380
Air baffle
1
03.03.2009
1NAC230V 50/60Hz
25
SelfCooking Center 62G
validity: 10/2008
Air baffle
03.03.2009
1NAC230V 50/60Hz
26
SelfCooking Center 62G
validity: 10/2008
Air baffle
Pos.
Part No.
Description
Qty.
1
10.00.515
Rivet 3,2x5 A4
1
2
40.01.289
Fixing clip core temp. cable
1
3
10.00.744
Washer A4,3 *A4
1
4
1604.0167
Rivet 4x10
1
6
2760.1370
Latch hook for air baffle
1
7
22.00.361
Deep-draw f. air baffle
1
03.03.2009
1NAC230V 50/60Hz
27
SelfCooking Center 62G
validity: 10/2008
Door
03.03.2009
1NAC230V 50/60Hz
28
SelfCooking Center 62G
validity: 10/2008
Door
Pos.
Part No.
Description
Qty.
1
24.00.152
Door handle
1
2
24.00.176
Door lock
1
8
24.00.504
Lock cover
1
10
24.00.133
Door mounting support top
1
11
1008.0768
Ornamental screw M8x16
3
12
1308.0160
Washer A8,4
3
13
24.00.223
Door mounting support bottom
1
14
1006.1962
Countersunk screw Torx M6x16
2
15
10.00.090
Cap f. Torx T30
2
16
24.00.137
Door bolt
1
17
10.00.099
Hex screw M8x12
1
18
1308.0160
Washer A8,4
1
19
24.00.048
Door bolt
1
20
1008.0769
Ornamental screw M8x30
1
21
1308.0160
Washer A8,4
1
22
2001.0109
Compression spring
1
23
24.00.141
Holding bracket f. door catch
1
24
1006.0760
Hex screw M6x16
2
25
1306.0120
Washer A6,4
2
27
24.00.142
Door catch
1
33
24.01.100
Spring clip f. door lock
1
A
24.00.105
Door
1
03.03.2009
1NAC230V 50/60Hz
29
SelfCooking Center 62G
validity: 10/2008
Door
03.03.2009
1NAC230V 50/60Hz
30
SelfCooking Center 62G
validity: 10/2008
Door
Pos.
Part No.
Description
Qty.
1
24.00.198
Inner glass pane
1
2
24.00.147
Sleeve for door bolt top
1
3
24.00.146
Door setting bolt
1
4
24.00.502
Fixing device f. magnet with magnet
1
5
24.01.188
Drain door drip collector
1
6
24.01.801
Door drip collector
1
9
24.00.171
Silicone buffer 7mm
1
03.03.2009
1NAC230V 50/60Hz
31
SelfCooking Center 62G
validity: 10/2008
Exterior cabinet
03.03.2009
1NAC230V 50/60Hz
32
SelfCooking Center 62G
validity: 10/2008
Exterior cabinet
Pos.
Part No.
Description
Qty.
1
1104.0820
Snap nut 4,2mm
3
2
1110.0800
Cage nut M10
4
4
12.00.205
Upper part of pedestal
4
5
12.00.206
Lower part of pedestal
4
7
1328.0102
Safety washer A10,2
4
8
10.00.975
Hex screw M10x35
4
9
12.00.516
Turning lock f. lower part of pedestal
4
10
10.00.745
Cap nut M6*A2
1
11
1206.0120
Tooth lock washer A6,4
1
13
1005.2100
Interlocking tooth screw M5x16
1
14
22.00.354
Spacer ring
1
15
22.00.353
Vent cover
1
16
16.01.327
Opening mechanism for panel insert
1
23
1106.0802
Cage nut M6
4
A
Exterior cabinet
1
03.03.2009
1NAC230V 50/60Hz
33
SelfCooking Center 62G
validity: 10/2008
Exterior cabinet
03.03.2009
1NAC230V 50/60Hz
34
SelfCooking Center 62G
validity: 10/2008
Exterior cabinet
Pos.
Part No.
Description
Qty.
1
16.00.819
Top cover
1
2
1003.2265
Countersunk self tapping screw 4,2x16
9
3
1104.0820
Snap nut 4,2mm
10
4
1004.2160
Hex self tapping screw 4,2x16
2
5
16.00.146
Side panel right
1
6
1603.0166
Rivet 3,2x7,9 CNS closed
4
7
16.00.147
Side panel left
1
8
10.00.102
Hex self tapping screw B4,2x32
2
9
1104.0820
Snap nut 4,2mm
2
10
16.00.201
Back panel
1
11
16.00.297
Front panel
1
12
16.00.673
Air inlet filter
1
13
10.00.103
EJOT PT-screw KA 3.5x10
1
14
1104.0820
Snap nut 4,2mm
1
17
16.01.511
Crossbar below
1
18
1004.2160
Hex self tapping screw 4,2x16
3
19
1107.0100
Star lock ø4
5
20
50.00.751
Tulip for handshower with tape
1
21
16.00.186
Crossbar top
1
22
1603.0166
Rivet 3,2x7,9 CNS closed
4
24
16.01.433
Gasket f. breather tube d=53mm
1
28
16.00.329
Cover f. USB interface
1
29
10.00.103
EJOT PT-screw KA 3.5x10
1
30
40.00.469
Interface cable USB 0.9m
1
31
10.00.460
EJOT PT-Screw Torx 3,5x14
2
32
50.00.300
Drip collector
1
34
50.01.192
Drain pipe
1
35
50.00.296
Clip f. drip collector
4
36
40.00.335
Door switch
1
37
16.01.146
Bracket for door contact switch
1
03.03.2009
1NAC230V 50/60Hz
35
SelfCooking Center 62G
validity: 10/2008
Water
03.03.2009
1NAC230V 50/60Hz
36
SelfCooking Center 62G
validity: 10/2008
Water
Pos.
Part No.
Description
Qty.
1
2022.0101
Grommet d8mm
1
2
54.00.221
Exhaust pipe
1
4
54.00.241
Rubber form piece venting pipe
1
5
2066.0516
Hose clamp 60-80 mm
1
6
2066.0504
Hose clamp 40-60mm
1
7
40.00.398
Thermocouple quenching
1
8
50.01.050
Triple solenoid valve
1
9
50.00.071
Water distribution hor. w/o roll guide con.
1
10
2067.0050
Pressure hose d10mm
.88
11
2067.0050
Pressure hose d10mm
1.59
12
50.00.934
Water volume sensor
1
17
50.01.146
Single solenoid valve
1
18
50.00.070
Water distribution hor roll guide con.
1
19
2067.0050
Pressure hose d10mm
.74
20
50.00.078
Non return valve DW16/DN12
2
21
10.00.810
Hose clamp Cobra 16/8
7
22
2067.0050
Pressure hose d10mm
.4
23
1900.0202
Water filter
2
25
50.00.086
Locking plate f. water distribution
1
26
1900.0202
Water filter
1
27
10.00.873
Hose clamp CLIC d=15.5mm
2
28
8664.1301
T-fitting water connection
1
29
54.00.357
Ball valve drain SCC cpl.
1
31
10.00.449
Pan head screw M6x16
2
32
10.00.249
Plastic cable clamp D4.5
1
33
1104.0120
Hex nut M4
1
34
10.00.511
O-ring for ball valve drain 46x3.5
1
35
10.00.512
O-ring for ball valve drain 26x3.5
1
36
54.00.781
Inspection lid with quenching nozzle
1
37
54.00.805
Gasket f. inspection lid quenching
1
38
54.00.225
Clamping bar
1
39
1008.0750
Hex screw M5x16
1
40
50.00.140
Hand shower roll guide
1
41
50.01.173
Connect. pipe f. hand shower roll guide
1
42
50.00.085
Plug-in spring f. hand shower roll guide
1
43
50.00.130
Hand shower
1
03.03.2009
1NAC230V 50/60Hz
37
SelfCooking Center 62G
validity: 10/2008
Water
03.03.2009
1NAC230V 50/60Hz
38
SelfCooking Center 62G
validity: 10/2008
Water
Pos.
Part No.
Description
Qty.
44
50.00.156
Clamp f. hand shower roll guide
1
54
1105.0121
Hex combination nut M5 galv
1
55
8354.1304
Venting valve for steam generator
1
56
2067.0050
Pressure hose d10mm
.42
03.03.2009
1NAC230V 50/60Hz
39
SelfCooking Center 62G
validity: 10/2008
CleanJet + Care
03.03.2009
1NAC230V 50/60Hz
40
SelfCooking Center 62G
validity: 10/2008
CleanJet + Care
Pos.
Part No.
Description
Qty.
1
56.00.153
Pump f. cleaning UP30
1
2
12.00.319
Housing f. Cleaning pump
1
4
56.00.166
Pressure hose f. cleaning
1
5
2066.0518
Hose clamp 30mm
1
6
2066.0521
Hose clamp 27mm
1
7
56.00.120
Suction hose f. cleaning
1
8
2066.0518
Hose clamp 30mm
2
9
56.00.162
Pipe f. Cleaning
1
10
56.00.445
Frame for drawer CareControl
1
11
1107.0100
Star lock ø4
6
12
10.00.980
EJOT PT-Screw K30x10
4
13
56.00.488
Drawer Care container
1
14
56.00.492
Care container table unit
1
15
56.00.462
Bushing care container/pump
1
16
2066.0506
Hose clamp 20-32mm
1
17
87.00.352
Pump f. CareControl DPS 35
1
18
56.00.540
Care hose 1
1
19
2066.0518
Hose clamp 30mm
1
20
2067.0156
Pressure hose ø10mm, 440mm long
1
21
2066.0202
Hose clamp 12-22 mm
1
22
56.00.380
Cover for pump
1
23
1005.2100
Interlocking tooth screw M5x16
2
24
2066.0506
Hose clamp 20-32mm
1
25
56.00.482
Care hose 2
1
26
10.00.605
Hose clamp ø25.3
2
27
2067.0050
Pressure hose d10mm
.65
03.03.2009
1NAC230V 50/60Hz
41
SelfCooking Center 62G
validity: 10/2008
Gas parts
03.03.2009
1NAC230V 50/60Hz
42
SelfCooking Center 62G
validity: 10/2008
Gas parts
Pos.
Part No.
Description
Qty.
1
70.00.028
Blower for burner RG130
1
3
70.00.028
Blower for burner RG130
1
4
1008.0750
Hex screw M5x16
4
5
1305.0160
Washer A5,3x10mm
4
6
74.00.310
Flange f. burner blower RG130
2
7
1105.0122
Hex combination nut M5 V2A
4
9
74.00.301
Gasket f. blower burner
2
10
10.00.065
Countersunk screw Torx T20 M4x12
3
13
70.00.069
Spacer sleeve f. gas burner blower
1
14
70.00.262
O-ring 21.89x2.62
1
15
10.00.068
Countersunk screw Torx T20 M4x40
4
16
10.00.456
Truss head screw Torx M4x30 T20
3
18
1204.0120
Tooth lock washer A4,3
6
22
10.00.064
Pan head screw Torx T20 M4x30
3
23
10.00.065
Countersunk screw Torx T20 M4x12
3
24
70.00.103
Corrugated hose 270mm
1
25
70.00.090
Corrugated hose 600mm
1
27
10.00.061
Pan head screw Torx T20 M4x12
8
28
10.00.063
Pan head screw Torx T20 M4x25
8
29
70.00.301
Combustion air angle pipe hot air
1
30
74.00.308
Gas connection manifold 2x3/4"
1
31
1006.0762
Hex screw M6x10
2
32
1306.0222
Washer A6,4x15x1,5
2
33
74.00.221
Automatic ignition controller
1
35
10.00.062
Pan head screw Torx T20 M4x20
1
36
70.00.115
Air hose D40x800mm
1
38
70.00.096
Air hose D50x650mm
1
40
70.00.280
Silicone hose ø4x1,5
.214
42
70.00.280
Silicone hose ø4x1,5
.214
45
70.00.221
Air hose fixing device 40mm
1
46
70.00.222
Air hose fixing device 50mm
1
A
70.00.029
Gas valve cpl. WND 055 RG130
1
B
70.00.033
Gas valve cpl. ND 055 RG130
1
03.03.2009
1NAC230V 50/60Hz
43
SelfCooking Center 62G
validity: 10/2008
Gas valve
03.03.2009
1NAC230V 50/60Hz
44
SelfCooking Center 62G
validity: 10/2008
Gas valve
Pos.
Part No.
Description
Qty.
1
70.00.031
Gas valve GB 055 WND (lateral)
1
2
70.00.255
Premix chamber cover gas f. RG130
1
3
70.00.030
Premix chamber gas f. RG130
1
4
70.00.106
Premix disc gas
1
5
70.00.256
Disc premix chamber-blower RG130
1
03.03.2009
1NAC230V 50/60Hz
45
SelfCooking Center 62G
validity: 10/2008
Gas valve
03.03.2009
1NAC230V 50/60Hz
46
SelfCooking Center 62G
validity: 10/2008
Gas valve
Pos.
Part No.
Description
Qty.
1
70.00.220
Gas valve GB 055 ND (straight)
1
2
70.00.255
Premix chamber cover gas f. RG130
1
3
70.00.030
Premix chamber gas f. RG130
1
4
70.00.106
Premix disc gas
1
5
70.00.256
Disc premix chamber-blower RG130
1
6
70.00.108
Disc gas valve-premix chamber
1
7
70.00.261
O-ring 17x1.5
1
03.03.2009
1NAC230V 50/60Hz
47
SelfCooking Center 62G
validity: 10/2008
Miscellaneous
03.03.2009
1NAC230V 50/60Hz
48
SelfCooking Center 62G
validity: 10/2008
Miscellaneous
Pos.
Part No.
Description
Qty.
1
60.62.001
Hinging rack left
1
2
60.62.002
Hinging rack right
1
3
60.71.022
Positioning support f. core sensor
1
4
10.00.400
Sticker set
1
03.03.2009
1NAC230V 50/60Hz
49
SelfCooking Center 62G
validity: 10/2008
Index
Part-no.
Description
Page
22.00.380
Air baffle
...............................................................25...................
.
70.00.115
Air hose D40x800mm
.................................................43...................
.
70.00.096
Air hose D50x650mm
.................................................43...................
.
70.00.221
Air hose fixing device 40mm
.........................................
.43...................
.
70.00.222
Air hose fixing device 50mm
.........................................
.43...................
.
16.00.673
Air inlet filter
...........................................................35...................
.
10.00.696
Allen screw M4x6 w. Precoat 85
.....................................
.21....................74.00.221
Automatic ignition controller
...........................................43...................
.
16.00.201
Back panel
.............................................................35...................
.
54.00.357
Ball valve drain SCC cpl.
.............................................
.37...................
.
2120.1277
Base for sensor connection
...........................................25...................
.
70.00.028
Blower for burner RG130
.............................................
.43...................
.
16.01.146
Bracket for door contact switch
.......................................
.35...................
.
74.00.247
Burner hot air
.........................................................
.19...................
.
70.00.044
Burner pipe
...........................................................
.13....................72.00.008
Burner steam gen.
.....................................................13...................
.
40.00.471
Bus cable 0.8m
.......................................................
.7.....................
56.00.462
Bushing care container/pump
.........................................41...................
.
40.02.087
Buzzer
.................................................................5.....................
10.00.421
Cable clip
.............................................................
.7.....................
10.00.471
Cable clip d10-12mm
.................................................
.7.....................
10.00.111
Cable clip long
.........................................................
7, 9
...................
10.00.112
Cable clip short
.......................................................
.7.....................
40.00.320
Cable connection M20x1.5
...........................................
.7.....................
4002.0110
Cable connector, junction
.............................................7.....................
1104.0801
Cage nut M4
...........................................................7.....................
1106.0802
Cage nut M6
...........................................................33...................
.
1110.0800
Cage nut M10
.........................................................33...................
.
10.00.090
Cap f. Torx T30
.......................................................
.29...................
.
10.00.745
Cap nut M6*A2
.......................................................
.
25, 33
...............
.
56.00.492
Care container table unit
.............................................
.41...................
.
56.00.540
Care hose 1
...........................................................41...................
.
03.03.2009
1NAC230V 50/60Hz
50
SelfCooking Center 62G
validity: 10/2008
Index
Part-no.
Description
Page
56.00.482
Care hose 2
...........................................................41...................
.
50.00.156
Clamp f. hand shower roll guide
.......................................39...................
.
1330.0100
Clamp strap f. sensor
.................................................
.25...................
.
54.00.225
Clamping bar
.........................................................
.37...................
.
44.00.264
Clamping bar for panel revision hole
.................................
.17...................
.
50.00.296
Clip f. drip collector
...................................................
.35...................
.
70.00.301
Combustion air angle pipe hot air
.....................................43....................2001.0109
Compression spring
...................................................29...................
.
50.01.173
Connect. pipe f. hand shower roll guide
...............................37...................
.
40.02.917
Contactor 3TG1010-2AK2
.............................................9.....................
.
87.00.000
Control panel insert with overlay
.....................................
.5.....................
.
42.00.002
Control pcb
...........................................................
.5.....................
.
40.00.277
Control transformer
...................................................
.9.....................
.
3101.1008
Cooling fan
...........................................................
.9.....................
.
1315.0101
Copper washer 6x10
.................................................
.23....................1315.0104
Copper washer 16x20x1,5
...........................................
.25...................
.
70.00.103
Corrugated hose 270mm
.............................................
.43...................
.
70.00.090
Corrugated hose 600mm
.............................................
.43...................
.
1006.1962
Countersunk screw Torx M6x16
.......................................29...................
.
10.00.065
Countersunk screw Torx T20 M4x12
.................................
.43...................
.
10.00.068
Countersunk screw Torx T20 M4x40
.................................
.43...................
.
1003.2265
Countersunk self tapping screw 4,2x16
...............................35...................
.
16.00.329
Cover f. USB interface
.................................................35....................56.00.380
Cover for pump
.......................................................
.41...................
.
16.01.511
Crossbar below
.......................................................
.35...................
.
16.00.186
Crossbar top
...........................................................35...................
.
22.00.361
Deep-draw f. air baffle
.................................................27...................
.
16.00.232
Dial f. pulse generator blue
...........................................
.5.....................
.
70.00.108
Disc gas valve-premix chamber
.......................................47...................
.
70.00.256
Disc premix chamber-blower RG130
.................................
.
45, 47
...............
.
24.00.105
Door..................................................................
.29...................
.
24.00.137
Door bolt
...............................................................29...................
.
03.03.2009
1NAC230V 50/60Hz
51
SelfCooking Center 62G
validity: 10/2008
Index
Part-no.
Description
Page
24.00.048
Door bolt
...............................................................29...................
.
24.00.142
Door catch
.............................................................29...................
.
24.01.801
Door drip collector
.....................................................31...................
.
20.00.395
Door gasket
...........................................................
.25...................
.
24.00.152
Door handle
...........................................................29...................
.
24.00.176
Door lock
.............................................................
.29...................
.
24.00.223
Door mounting support bottom
.......................................
.29....................24.00.133
Door mounting support top
...........................................
.29...................
.
24.00.146
Door setting bolt
.......................................................31...................
.
40.00.335
Door switch
...........................................................
.35...................
.
24.01.188
Drain door drip collector
...............................................31...................
.
44.00.234
Drain hose steam generator
...........................................13...................
.
50.01.192
Drain pipe
.............................................................
.35...................
.
56.00.488
Drawer Care container
...............................................
.41...................
.
50.00.300
Drip collector
.........................................................
.35....................40.02.515
Dry up protector 315°F/157°C
.........................................9.....................
10.00.980
EJOT PT-Screw K30x10
.............................................
.41...................
.
10.00.103
EJOT PT-screw KA 3.5x10
...........................................
.35...................
.
10.00.460
EJOT PT-Screw Torx 3,5x14
.........................................
.35...................
.
10.00.239
EJOT PT-Screw Torx 4x10
...........................................
.
7, 9, 11
...............
40.01.483
Electronic noise filter
.................................................
.9.....................
44.00.207
Emptying pump
.......................................................
.13...................
.
4001.1203
End plate for mounting rail
...........................................
.9.....................
54.00.221
Exhaust pipe
...........................................................37...................
.
40.00.310
Exhaust pipe below
...................................................
.23...................
.
40.00.274
Fan motor
.............................................................
.23...................
.
22.00.192
Fan wheel d340x135
.................................................
.23...................
.
44.00.253
Filling level electrode 85mm
...........................................17...................
.
40.01.289
Fixing clip core temp. cable
...........................................27...................
.
40.00.417
Fixing clip f. pcb
.......................................................7.....................
40.01.579
Fixing clip f. pcb
.......................................................7.....................
24.00.502
Fixing device f. magnet with magnet
.................................
.31...................
.
03.03.2009
1NAC230V 50/60Hz
52
SelfCooking Center 62G
validity: 10/2008
Index
Part-no.
Description
Page
44.00.226
Fixing device f. pump steam generator
...............................
.13...................
.
2020.0400
Fixing device for cable harness
.......................................5.....................
.
44.00.516
Fixing plate steam generator thermostat
.............................
.13...................
.
74.00.310
Flange f. burner blower RG130
.......................................
.43...................
.
22.00.123
Flange f. motor shaft gasket
...........................................23...................
.
56.00.445
Frame for drawer CareControl
.......................................
.41...................
.
16.00.297
Front panel
...........................................................
.35....................40.02.512
Fuse holder 2x6.3A
...................................................
.9.....................
.
74.00.308
Gas connection manifold 2x3/4"
.......................................43...................
.
70.00.033
Gas valve cpl. ND 055 RG130
.......................................
.43...................
.
70.00.029
Gas valve cpl. WND 055 RG130
.....................................
.43...................
.
70.00.220
Gas valve GB 055 ND (straight)
.......................................47...................
.
70.00.031
Gas valve GB 055 WND (lateral)
.....................................
.45...................
.
74.00.290
Gasket electrode hot air
...............................................21...................
.
74.00.301
Gasket f. blower burner
...............................................
.43....................16.01.433
Gasket f. breather tube d=53mm
.....................................
.35...................
.
72.00.020
Gasket f. burner carrier
...............................................
.13...................
.
74.00.296
Gasket f. heat exchanger below
.......................................19...................
.
22.00.198
Gasket f. hum. meas. Pipe
...........................................
.11...................
.
44.00.250
Gasket f. ignition electrode
...........................................
.13...................
.
5012.0566
Gasket f. inspection lid
...............................................
.17...................
.
54.00.805
Gasket f. inspection lid quenching
.....................................37...................
.
22.00.564
Gasket f. ventilation
...................................................11....................40.00.091
Gasket frame w. glass a. gaskets
.....................................25...................
.
74.00.234
Gasket hot air heat exchanger/interior cabinet
.......................
.19...................
.
5110.1029
Gasket mode switch
...................................................5.....................
.
2022.0101
Grommet d8mm
.......................................................37...................
.
3024.0201
Halogen bulb 300°C
...................................................25...................
.
50.00.130
Hand shower
.........................................................
.37...................
.
50.00.140
Hand shower roll guide
...............................................
.37...................
.
1104.0122
Hex combination nut M4 galv
.........................................
.
11, 13
...............
.
1105.0121
Hex combination nut M5 galv
.........................................
.
13, 17, 39
...........
.
03.03.2009
1NAC230V 50/60Hz
53
SelfCooking Center 62G
validity: 10/2008
Index
Part-no.
Description
Page
1105.0122
Hex combination nut M5 V2A
.........................................
19, 43
...............
.
1106.0803
Hex combination nut M6 galv
.........................................
.13...................
.
1104.0120
Hex nut M4
...........................................................
.
7, 13, 25, 37
.........
1104.0121
Hex nut M4 self locking
...............................................
.5.....................
10.00.916
Hex nut M4 w. locking
.................................................5.....................
1105.0120
Hex nut M5
...........................................................
.13...................
.
1106.0160
Hex nut M6
...........................................................
.7.....................
1106.0220
Hex nut M6 flat
.......................................................
.23...................
.
1106.0224
Hex nut M6 self locking
...............................................
.25...................
.
10.00.709
Hex nut M6 w. locking
.................................................
7, 13
.................
10.00.710
Hex nut M8 w. locking
.................................................23...................
.
3014.0302
Hex nut M10 for dry-up protector
.....................................
.9.....................
3014.0327
Hex nut M10x1,0
.....................................................
.9.....................
10.00.612
Hex nut M16 flat
.......................................................25...................
.
1008.0750
Hex screw M5x16
.....................................................
37, 43
................1006.0762
Hex screw M6x10
.....................................................
13, 43
...............
.
1006.0760
Hex screw M6x16
.....................................................
25, 29
...............
.
10.00.099
Hex screw M8x12
.....................................................29...................
.
10.00.565
Hex screw M8x20
.....................................................23...................
.
10.00.975
Hex screw M10x35
...................................................
.33...................
.
1004.2160
Hex self tapping screw 4,2x16
.......................................
.35...................
.
10.00.102
Hex self tapping screw B4,2x32
.......................................35...................
.
60.62.001
Hinging rack left
.......................................................49....................60.62.002
Hinging rack right
.....................................................
.49...................
.
24.00.141
Holding bracket f. door catch
.........................................
.29...................
.
2066.0205
Hose clamp 8-16x9 mm SW 7mm
.....................................13...................
.
2066.0202
Hose clamp 12-22 mm
...............................................
.41...................
.
2066.0506
Hose clamp 20-32mm
.................................................41...................
.
2066.0521
Hose clamp 27mm
...................................................
.41...................
.
2066.0518
Hose clamp 30mm
...................................................
.
13, 41
...............
.
2066.0519
Hose clamp 35,6mm
.................................................
.13...................
.
2066.0504
Hose clamp 40-60mm
.................................................
11, 13, 37
...........
.
03.03.2009
1NAC230V 50/60Hz
54
SelfCooking Center 62G
validity: 10/2008
Index
Part-no.
Description
Page
2066.0516
Hose clamp 60-80 mm
...............................................
.37...................
.
10.00.873
Hose clamp CLIC d=15.5mm
.........................................
.37...................
.
10.00.810
Hose clamp Cobra 16/8
...............................................37...................
.
2066.0527
Hose clamp ø14mm
...................................................15...................
.
2066.0530
Hose clamp ø16.4mm
.................................................15...................
.
10.00.605
Hose clamp ø25.3
.....................................................41...................
.
2066.0526
Hose clamp ø46mm
...................................................13....................22.00.525
Hose set f. humidity control
...........................................
.11...................
.
74.00.142
Hot air heat exchanger
...............................................
.19...................
.
12.00.319
Housing f. Cleaning pump
.............................................41...................
.
22.00.568
Humidity control cpl. with motor
.......................................11...................
.
3101.1010
Humidity control motor
...............................................
.11...................
.
44.00.251
Ignition electrode steam generator
...................................
.13...................
.
74.00.230
Ignitionelectrode1 f. hot air
...........................................
.21...................
.
74.00.235
Ignitionelectrode2 f. hot air
...........................................
.21....................24.00.198
Inner glass pane
.......................................................31...................
.
22.00.517
Inner humidity meas. Piece
...........................................
.11...................
.
54.00.781
Inspection lid with quenching nozzle
.................................
.37...................
.
40.00.519
Installation rail for Contactor 75mm
...................................9.....................
.
72.00.048
Insulation f. burner steam gen.
.......................................
.13...................
.
40.00.469
Interface cable USB 0.9m
.............................................35...................
.
1005.2100
Interlocking tooth screw M5x16
.......................................
33, 41
...............
.
2062.0331
Junction pressure hose GS 10
.......................................
.15....................2760.1370
Latch hook for air baffle
...............................................27...................
.
24.00.504
Lock cover
.............................................................29...................
.
50.00.086
Locking plate f. water distribution
.....................................
.37...................
.
12.00.206
Lower part of pedestal
.................................................33...................
.
74.00.313
Mating flange heat exchanger
.........................................19...................
.
40.00.294
Meat probe sensor SCC 62
...........................................25...................
.
4007.0620
Membrane DGC 29
...................................................
.9.....................
.
3016.0102
Micro switch
...........................................................11...................
.
22.00.083
Motor shaft gasket
.....................................................23...................
.
03.03.2009
1NAC230V 50/60Hz
55
SelfCooking Center 62G
validity: 10/2008
Index
Part-no.
Description
Page
22.00.326
Mounting device f. pressure sensor
...................................11...................
.
16.00.387
Mounting device f.sealing + sealing lip
...............................
.5.....................
22.00.120
Mounting support f. gasket flange
.....................................23...................
.
50.00.078
Non return valve DW16/DN12
.........................................37...................
.
50.00.844
Nozzle f. moistening
...................................................25...................
.
70.00.261
O-ring 17x1.5
.........................................................
.47...................
.
70.00.262
O-ring 21.89x2.62
.....................................................43....................10.00.512
O-ring for ball valve drain 26x3.5
.....................................
.37...................
.
10.00.511
O-ring for ball valve drain 46x3.5
.....................................
.37...................
.
16.01.327
Opening mechanism for panel insert
.................................
.33...................
.
1008.0768
Ornamental screw M8x16
.............................................29...................
.
1008.0769
Ornamental screw M8x30
.............................................29...................
.
22.00.200
Outer humidity meas. Piece
...........................................11...................
.
20.00.999
Outlet sieve Ø80
.......................................................25...................
.
10.00.449
Pan head screw M6x16
...............................................37....................10.00.061
Pan head screw Torx T20 M4x12
.....................................43...................
.
10.00.062
Pan head screw Torx T20 M4x20
.....................................43...................
.
10.00.063
Pan head screw Torx T20 M4x25
.....................................43...................
.
10.00.064
Pan head screw Torx T20 M4x30
.....................................43...................
.
44.00.263
Panel for revision hole steam generator
...............................17...................
.
56.00.162
Pipe f. Cleaning
.......................................................
.41...................
.
10.00.249
Plastic cable clamp D4.5
.............................................
.37...................
.
50.00.085
Plug-in spring f. hand shower roll guide
...............................37....................60.71.022
Positioning support f. core sensor
.....................................49...................
.
40.01.596
Power supply cable 3x2,5mm² 3m
...................................
.7.....................
70.00.255
Premix chamber cover gas f. RG130
.................................
.
45, 47
...............
.
70.00.030
Premix chamber gas f. RG130
.......................................
.
45, 47
...............
.
70.00.106
Premix disc gas
.......................................................
.
45, 47
...............
.
2067.0050
Pressure hose d10mm
...............................................
.
37, 39, 41
...........
.
56.00.166
Pressure hose f. cleaning
.............................................41...................
.
2067.0156
Pressure hose ø10mm, 440mm long
.................................
.41...................
.
3017.1011
Pressure sensor for humidity control Huba 401
.......................11...................
.
03.03.2009
1NAC230V 50/60Hz
56
SelfCooking Center 62G
validity: 10/2008
Index
Part-no.
Description
Page
2005.0106
Protective grid for cooling fan
.........................................9.....................
.
40.00.404
Pulse generator
.......................................................
.5.....................
.
2118.1000
Pump connection spout
...............................................15...................
.
8354.1320
Pump connection spout cpl.
...........................................13...................
.
87.00.352
Pump f. CareControl DPS 35
.........................................
.41...................
.
56.00.153
Pump f. cleaning UP30
...............................................
.41...................
.
40.00.098
Reflector f. interior light
...............................................
.25....................42.00.065
Relay-I/O pcb
.........................................................
.7.....................
.
10.00.515
Rivet 3,2x5 A4
.........................................................27...................
.
1603.0166
Rivet 3,2x7,9 CNS closed
.............................................35...................
.
1604.0167
Rivet 4x10
.............................................................27...................
.
10.00.041
Rivet nut M5 hexagon closed
.........................................
.25...................
.
10.00.989
Rivet with screw
.......................................................23...................
.
54.00.241
Rubber form piece venting pipe
.......................................37...................
.
40.01.482
Safety temperature limiter 365°C
.....................................
.9......................1328.0102
Safety washer A10,2
.................................................
.33...................
.
40.01.317
Screen core temperature sensor
.....................................
.25...................
.
40.00.531
Screen interior cabinet sensor
.........................................25...................
.
10.00.240
Screw Torx 3x20
.....................................................
.9.....................
.
10.00.238
Screw Torx 4x50
.....................................................
.9.....................
.
16.00.147
Side panel left
.........................................................35...................
.
16.00.146
Side panel right
.......................................................
.35...................
.
2110.1008
Silicon hose ø10x2mm
...............................................
.15....................24.00.171
Silicone buffer 7mm
...................................................31...................
.
70.00.280
Silicone hose ø4x1,5
.................................................
.43...................
.
50.01.146
Single solenoid valve
.................................................
.37...................
.
24.00.147
Sleeve for door bolt top
...............................................
.31...................
.
1104.0820
Snap nut 4,2mm
.......................................................
33, 35
...............
.
10.00.355
Spacer black
...........................................................5.....................
.
10.00.243
Spacer M4x8
.........................................................
.7.....................
.
22.00.354
Spacer ring
...........................................................
.33...................
.
70.00.069
Spacer sleeve f. gas burner blower
...................................43...................
.
03.03.2009
1NAC230V 50/60Hz
57
SelfCooking Center 62G
validity: 10/2008
Index
Part-no.
Description
Page
2120.1306
Spacer SW19x17
.....................................................
.23...................
.
24.01.100
Spring clip f. door lock
.................................................29...................
.
1008.1005
Square necked mushroom head bolt 8x40
...........................
.23...................
.
1107.0100
Star lock ø4
...........................................................
.
35, 41
...............
.
44.00.183
Steam generator insolated
...........................................
.13...................
.
2112.1006
Steam hose 50x7mm
.................................................
.13...................
.
44.00.349
Steam pipe
...........................................................
.13....................10.00.400
Sticker set
.............................................................49...................
.
2120.1259
Stop plug 10mm
.......................................................15...................
.
56.00.120
Suction hose f. cleaning
...............................................41...................
.
8664.1301
T-fitting water connection
.............................................
.37...................
.
40.00.290
Thermocouple humidity
...............................................
.25...................
.
40.01.097
Thermocouple interior cabinet (B1)
...................................
.25...................
.
40.00.398
Thermocouple quenching
.............................................37...................
.
40.01.094
Thermocouple steam gen. (B5)
.......................................13....................4005.0101
Tie rap 145 mm
.......................................................
.15...................
.
1204.0120
Tooth lock washer A4,3
...............................................
25, 43
...............
.
1205.0120
Tooth lock washer A5,3
...............................................13...................
.
1206.0120
Tooth lock washer A6,4
...............................................
7, 33
.................
16.00.819
Top cover
.............................................................
.35...................
.
50.01.050
Triple solenoid valve
...................................................37...................
.
10.00.456
Truss head screw Torx M4x30 T20
...................................43...................
.
50.00.751
Tulip for handshower with tape
.......................................
.35....................12.00.516
Turning lock f. lower part of pedestal
.................................
.33...................
.
50.00.846
Union nut M12x13.2 N
.................................................25...................
.
12.00.205
Upper part of pedestal
.................................................33...................
.
22.00.353
Vent cover
.............................................................33...................
.
8354.1304
Venting valve for steam generator
...................................
.39...................
.
10.00.744
Washer A4,3 *A4
.....................................................
.27...................
.
1305.0160
Washer A5,3x10mm
...................................................43...................
.
1306.0120
Washer A6,4
...........................................................
23, 25, 29
...........
.
1306.0222
Washer A6,4x15x1,5
.................................................
.
13, 43
...............
.
03.03.2009
1NAC230V 50/60Hz
58
SelfCooking Center 62G
validity: 10/2008
Index
Part-no.
Description
Page
1308.0162
Washer A8,4
...........................................................23...................
.
1308.0160
Washer A8,4
...........................................................29...................
.
50.00.070
Water distribution hor roll guide con.
.................................
.37...................
.
50.00.071
Water distribution hor. w/o roll guide con.
.............................37...................
.
1900.0202
Water filter
.............................................................37...................
.
50.00.934
Water volume sensor
.................................................
.37...................
.
40.00.211
Wiring interior light
.....................................................25...................
.
03.03.2009
1NAC230V 50/60Hz
59
Loading...
