SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
X SCC 61G
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 X1 Control panel
2 X2
3 X3 Clima Plus
4 X4
5 X5 Hot air heating
6 X6
7 X7 Interior cabinet
8 X8
9 X9 Water supply, quenching box
10 X10
11 X11 CleanJet
12 X12
13 X13 Exterior cabinet
14 X14
Electrical installation
Steam generator, Bypass
Motor and fan wheel
Door
Hand shower
Gas parts
Miscellaneous
Version 2006 1
SCC 61G
Gas unit
X Table of contents
Voltage: 1 NAC 120V 60Hz
1 Control panel ..................................................................................................................3
1.A Control panel..........................................................................................................................................................4
2 Electrical installation .......................................................................................................5
2.A Contactor assembly ...............................................................................................................................................6
3 Clima Plus.......................................................................................................................8
3.A Hose set f. humidity control....................................................................................................................................9
4 Steam generator, Bypass .............................................................................................10
4.A Pump connection spout cpl..................................................................................................................................12
4.B Venting valve for steam generator .......................................................................................................................13
5 Hot air heating ..............................................................................................................14
5.A Burner hot air ....................................................................................................................................................... 15
6 Motor and fan wheel.....................................................................................................16
7 Interior cabinet..............................................................................................................17
7.A Interior cabinet .....................................................................................................................................................18
7.B Gasket frame w. glass a. gaskets ........................................................................................................................ 19
7.C Air baffle...............................................................................................................................................................20
7.C Air baffle...............................................................................................................................................................21
8 Door..............................................................................................................................22
8.A Door .....................................................................................................................................................................23
9 Water supply, quenching box........................................................................................24
10 Hand shower...............................................................................................................25
11 CleanJet......................................................................................................................26
12 Gas parts....................................................................................................................27
12.A Gas valve cpl. ND 055 RG130...........................................................................................................................28
12.B Gas valve cpl. WND 055 RG130........................................................................................................................29
13 Exterior cabinet...........................................................................................................30
13.A Exterior cabinet..................................................................................................................................................31
14 Miscellaneous.............................................................................................................32
2
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
1 Control panel
1 Control panel
X 1 Control panel 1
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
A X1.A Control panel
1 87.00.002 Control panel insert with overla y
Attention! Individual parts shown might not be used in this component group!
Version 2006 3
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
1 Control panel
1.A Control panel
X 1.A Control panel 1
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 42.00.002 Control pcb
2 1104.0121 He x nut M4 self locking
3 10.00.355 Spacer black
4 2020.0400 F ixing device for cable harness
5 16.00.232 Dial f. pulse generator
6 40.02.087 Buzzer
6 3006.0107 Buzzer
7 5110.1029 Gasket mode s witch
7 5110.1028 Gasket poti hot air, core temperature
8 40.00.404 Pulse generator
9 16.00.387 Mounting device f.sealing + sealin g lip
10 1306.0218 Washer A4,3
11 1103.0122 He x nut M3 self-locking
Attention! Individual parts shown might not be used in this component group!
Version 2006 4
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
2 Electrical installation
2 Electrical installation
X 2 Electrical installation 2
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
A X2.A Contactor assembly
1 4007.0620 Membra ne DGC 29
2 4007.0621 Membra ne DGC 36
3 1106.0803 He x combination nut M6 galv
4 10.00.239 EJOT PT-Screw Torx 4x10
5 42.00.007 External memory
6 40.00.049 Relay-I/O pcb
6 42.00.045 Relay-I/O pcb w/o Sicotronic
7 40.00.417 Fixing clip f. pcb
8 1104.0801 Cage nut M4
9 10.00.243 Spacer M4x8
10 1104.0120 He x nut M4
11 40.01.579 Fixing clip f. pcb
12 10.00.112 Cable clip short
13 10.00.421 Cable clip
14 10.00.111 Cable clip long
15 10.00.471 Cable clip d10-12mm
16 40.01.597 Power supply cable 3xAWG14
17 40.00.320 Cable connection M20x1.5
18 1106.0160 He x nut M6
19 1206.0120 Tooth lock washer A6,4
20 4002.0110 Cabl e connector, junction
21 40.01.091 Bus cable 0.4m
21 40.00.471 Bus cable 0.8m
22 40.00.279 Control transformer
23 1008.0761 Hex screw M8x25
24 40.01.600 Insulating screw joint 2pol.
Attention! Individual parts shown might not be used in this component group!
Version 2006 5
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
2 Electrical installation
2.A Contactor assembly
X 2.A Contactor assembly 2
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 3014.0328 Dry up protector 275°F/135°C
2 3014.0302 Hex nut M10 for dry-up protector
3 40.01.482 Safety temperature limiter 365°C
4 3014.0327 He x nut M10x1,0
5 40.00.451 Contactor MC1A 310 AH6
7 3101.1008 Cool ing fan
8 10.00.238 Screw Torx 4x50
9 40.00.277 Control transformer
10 40.01.483 Electronic noise filter
11 10.00.240 Screw Torx 3x20
12 2005.0106 Protective grid for cooling fan
13 40.00.519 Installation rail for Contactor 75mm
14 10.00.239 EJOT PT-Screw Torx 4x10
15 4001.1203 End pl ate for mounting rail
16 10.00.111 Cable clip long
17 40.01.588 Fuse SC-8A 10x38
18 40.01.487 Fuse holder 2pol
19 40.01.484 Cable burner blo wer
19 40.00.209 Cable buzzer
19 40.00.202 Cable CDS sensor
19 40.01.299 Cable control harness
19 40.00.213 Cable control transformer sec.
19 40.00.207 Cable differencial pressure switch
19 40.00.230 Cable gas valve
19 40.00.248 Cable harness isolating transformer
19 40.00.208 Cable humidity control
19 40.00.205 Cable level electrode
19 40.00.247 Cable SC pump
19 40.00.203 Cable solenoid valve
19 40.00.231 Cable transformer for cooling fan sec.
Attention! Individual parts shown might not be used in this component group!
Version 2006 6
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
2 Electrical installation
Item no. Part no Reference Description
19 40.00.237 Ground wire
X 2.A Contactor assembly 2
Voltage 1 NAC 120V 60Hz
Attention! Individual parts shown might not be used in this component group!
Version 2006 7
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
3 Clima Plus
3 Clima Plus
X 3 Clima Plus 3
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
A 22.00.234 X3.A Hose set f. humidity control
1 22.00.199 Inner humidity meas. Piece
2 22.00.318 Humidity control cpl. with motor
3 22.00.200 Outer humidity meas. Piece
4 22.00.198 Gasket f. hum. meas. Pipe
5 22.00.174 Hose d50x83
6 2066.0531 Hose cl amp ø56
8 22.00.326 Mounting device f. pressure sensor
9 3017.1011 Pressure se nsor for humidity control Huba 401
10 10.00.239 EJOT PT-Screw Torx 4x10
11 3101.1010 Humid ity control motor
12 3016.0102 Micro switch
13 3101.1021 Protecting ca p f.12VDC humidity motor
Attention! Individual parts shown might not be used in this component group!
Version 2006 8
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
3 Clima Plus
3.A Hose set f. humidity control
X 3.A Hose set f. humidity control 3
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 4005.0101 Tie rap 145 mm
2 2110.1020 Silico n hose ø5x1.5 blue
3 2110.1019 Silico ne hose ø5x1,5 "red"
4 1900.0203 Ceramic tube 8x5x60mm for
5 2112.1338 Silico ne hose ø8x2x20
Attention! Individual parts shown might not be used in this component group!
Version 2006 9
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
4 Steam generator, Bypass
4 Steam generator, Bypass
X 4 Steam generator, Bypass 4
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
A 8354.1320 X4.A Pump connection spout cpl.
B 8354.1304 X4.B Venting valve for steam generator
1 44.00.253 Filling level electrode 85mm
2 44.00.182 Steam generator insolated
3 72.00.003 Burner steam gen.
4 72.00.048 Insulation f. burner steam gen.
5 1104.0122 He x combination nut M4 galv
6 72.00.020 Gasket f. burner carrier
7 1105.0121 He x combination nut M5 galv
8 44.00.251 Ignition electrode steam generator
9 1104.0120 He x nut M4
10 44.00.250 Gasket f. ignition electrode
11 2066.0519 Hose cl amp 35,6mm
12 2066.0526 Hose cl amp ø46mm
13 44.00.207 Emptying pump
14 1006.0762 Hex screw M6x10
15 1306.0222 Washer A6,4x15x1,5
16 44.00.226 Fixing device f. pump steam generator
17 1106.0803 He x combination nut M6 galv
18 44.00.234 Drain hose steam generator
19 2066.0518 Hose cl amp 30mm
20 40.01.094 Thermocouple steam gen. (B5)
20 40.00.291 Thermocouple steam generat or
21 44.00.516 Fixing plate steam generator thermostat
22 2112.1006 Steam hose 50x7mm
23 2066.0504 Hose cl amp 40-60mm
24 2066.0506 Hose cl amp 20-32mm
25 1105.0120 He x nut M5
26 1205.0120 Tooth lock washer A5,3
27 5012.0566 Gasket que nching chamber 0-ring
Attention! Individual parts shown might not be used in this component group!
Version 2006 10
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
4 Steam generator, Bypass
Item no. Part no Reference Description
28 44.00.263 Panel for revision hole steam generator
29 44.00.264 Clamping bar for panel revision hole
30 70.00.039 Burner pipe
X 4 Steam generator, Bypass 4
Voltage 1 NAC 120V 60Hz
Attention! Individual parts shown might not be used in this component group!
Version 2006 11
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
4 Steam generator, Bypass
4.A Pump connection spout cpl.
X 4.A Pump connection spout cpl. 4
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 2118.1000 Pump connection spout
2 2120.1259 Stop plu g 10mm
3 2066.0527 Hose cl amp ø14mm
4 2066.0530 Hose cl amp ø 16.4mm
5 2062.0331 Junction pressure hose GS 10
6 4005.0101 Tie rap 145 mm
Attention! Individual parts shown might not be used in this component group!
Version 2006 12
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
4 Steam generator, Bypass
4.B Venting valve for steam generator
X 4.B Venting valve for steam generator 4
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 2062.0332 Rece ptacle for ventilation valve SG
2 2069.0108 Ventilation valve
3 2112.1310 Form hose for ventilation of steam generator
4 2066.0506 Hose cl amp 20-32mm
Attention! Individual parts shown might not be used in this component group!
Version 2006 13
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
5 Hot air heating
5 Hot air heating
X 5 Hot air heating 5
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
A 74.00.276 X5.A Burner hot air
1 74.00.134 Hot air heat exchanger
2 74.00.234 Gasket hot air heat exchanger/interior cabinet
3 74.00.313 Mating flange heat exchanger
4 74.00.296 Gasket f. heat exchanger below
5 1105.0122 He x combination nut M5 V2A
Attention! Individual parts shown might not be used in this component group!
Version 2006 14
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
5 Hot air heating
5.A Burner hot air
X 5.A Burner hot air 5
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 74.00.340 Burner welded hot air
2 74.00.230 Ignitionelectrode1 f. hot air
3 74.00.235 Ignitionelectrode2 f. hot air
4 74.00.290 Gasket electrode hot air
5 10.00.696 Allen screw M4x6 w. Precoat 85
5 10.00.060 Pan head screw Torx M4x6
Attention! Individual parts shown might not be used in this component group!
Version 2006 15
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
6 Motor and fan wheel
6 Motor and fan wheel
X 6 Motor and fan wheel 6
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 2120.1306 Spacer SW 19x17
2 22.00.123 Flange f. motor shaft gasket
3 22.00.120 Mounting support f. gasket flange
4 22.00.083 Motor shaft gasket
5 1315.0101 Cop per washer 6x10
6 1106.0220 He x nut M6 flat
7 22.00.188 Fan wheel d340x110
8 1008.0763 He x screw M8x20
8 10.00.565 Hex screw M8x20
9 40.00.310 Exhaust pipe below
11 40.00.274 Fan motor
12 10.00.071 Hex nut M8
12 1108.0260 He x nut M8
12 10.00.710 Hex nut M8 w. locking
13 1208.0260 Sprin g washer B8
14 1008.1005 Square necked mushroom head bolt 8x40
Attention! Individual parts shown might not be used in this component group!
Version 2006 16
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
7 Interior cabinet
7 Interior cabinet
X 7 Interior cabinet 7
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
A X7.A Interior cabinet
B 40.00.091 X7.B Gasket frame w. glass a. gaskets
C 22.00.293 X7.C
C 22.00.379 X7.C Air baffle
3 3024.0201 Halo gen bulb for interior cabinet 300°C
4 40.00.211 Wiring interior light
5 20.00.394 Door gasket
6 40.00.293 Meat probe sensor
7 1315.0104 Cop per washer 16x20x1,5
8 10.00.422 Hex nut M16
9 3014.0162 Seal ing cone for thermocouple
10 3014.0163 Gasket sleeve wit h nipple
11 40.01.097 Thermocouple interior cabinet (B1)
12 2760.1089 Guide bush for core temperatur sensor
13 2005.0308 Outlet sieve
14 50.00.395 Nozzle f. moistening
15 50.00.394 Union nut M12x12
Air baffle
Attention! Individual parts shown might not be used in this component group!
Version 2006 17
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
7 Interior cabinet
7.A Interior cabinet
X 7.A Interior cabinet 7
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 40.00.290 Thermocouple humidit y
2 40.00.098 Reflector f. interior light
3 4001.1248 Porcel ain connector 2-pin interior light
4 1330.0100 Clamp strap f. sensor
5 1106.0224 He x nut M6 self locking
6 1306.0120 Washer A6,4
7 1104.0120 He x nut M4
8 1204.0120 Tooth lock washer A4,3
9 2120.1277 Base for sensor connection
10 1603.0167 Tubular rivet 3,2x0.25x10
11 10.00.041 Rivet nut M5 hexagon closed
Attention! Individual parts shown might not be used in this component group!
Version 2006 18
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
7 Interior cabinet
7.B Gasket frame w. glass a. gaskets
X 7.B Gasket frame w. glass a. gaskets 7
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 40.00.093 Outer gasket f. interior light
2 40.00.094 Inner gasket f. interior light
3 40.00.095 Glass pane f. interior light
4 40.00.096 Gasket frame f. interior light
5 10.00.682 Phillips countersunk-head screw M5x16
Attention! Individual parts shown might not be used in this component group!
Version 2006 19
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
7 Interior cabinet
7.C Air baffle
X 7.C Air baffle 7
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 1603.0168 Rivet 3,2x8 A4
2 1304.0160 Washer A4,3
3 1604.0167 Rivet 4x10
4 2760.1370 Latch hook for air baffle
5 22.00.332 Air sucking ring f. air baffle
6 10.00.515 Rivet 3,2x5 A4
7 22.00.484 Swing protection for core probe
Attention! Individual parts shown might not be used in this component group!
Version 2006 20
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
7 Interior cabinet
7.C Air baffle
X 7.C Air baffle 7
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 1304.0160 Washer A4,3
2 1604.0167 Rivet 4x10
3 22.00.332 Air sucking ring f. air baffle
4 2760.1370 Latch hook for air baffle
5 10.00.515 Rivet 3,2x5 A4
5 1603.0168 Rivet 3,2x8 A4
6 22.00.361 Deep-draw f. air baffle
7 22.00.484 Swing protection for core probe
Attention! Individual parts shown might not be used in this component group!
Version 2006 21
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
8 Door
8 Door
X 8 Door 8
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
A 24.00.088 X8.A Door
1 24.01.100 Spring clip f. door lock
2 1005.2000 Interlocki ng tooth screw M5x8
3 24.00.152 Door handle
4 24.00.176 Door lock
5 24.00.504 Lock cover
6 24.00.133 Door mounting support top
7 1008.0768 Ornamenta l screw M8x16
8 1308.0162 Washer A8,4
9 24.00.223 Door mounting support bottom
10 1006.1962 Countersunk screw Torx M6x16
11 10.00.090 Cap f. Torx T30
12 1006.0760 Hex screw M6x16
13 1106.0802 Cage nut M6
14 24.00.137 Door bolt
15 10.00.099 Hex screw M8x12
16 24.00.048 Door bolt
17 1008.0769 Ornamenta l screw M8x30
18 2001.0109 Compression spring
19 24.00.141 Holding bracket f. door catch
20 1306.0120 Washer A6,4
21 24.00.142 Door catch
22 1308.0160 Washer A8,4
23 24.01.200 Pan head screw Torx M4x12 T20
24 24.01.199 Slotted pan head screw M6x45 *WDS*
Attention! Individual parts shown might not be used in this component group!
Version 2006 22
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
8 Door
8.A Door
X 8.A Door 8
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 24.00.163 Inner door pane
2 24.00.147 Sleeve for door bolt top
3 24.00.146 Door setting bolt
4 24.00.502 Fixing device f. magnet with magnet
Attention! Individual parts shown might not be used in this component group!
Version 2006 23
Gas unit
9 Water supply, quenching box
SCC 61G
Valid as of G61SE0404 up to G61SE....
X 9 Water supply, quenching box 9
9 Water supply, quenching
box
Voltage
1 NAC 120V 60Hz
Item no. Part no Reference Description
1 54.00.223 Exhaust pipe
2 54.00.086 Rubber form piece venting pipe
3 40.00.287 Thermocouple quenching
4 50.00.138 Double solenoid valve
5 50.00.139 Single solenoid valve
6 50.00.070 Water distribution hor roll guide con.
7 50.00.071 Water distribution hor. w/o roll guide con.
8 50.00.086 Locking plate f. water distribution
9 50.00.078 Non return valve DW16/DN12
10 1900.0202 Water filter
11 2066.0205 Hose cl amp 8-16x9 mm SW 7mm
12 8664.1301 T-fitting water connection
13 5110.1024 Gasket for G3/4" threaded joint
14 50.00.085 Plug-in spring f. hand shower roll guide
15 54.00.357 Ball valve drain SCC cpl.
16 10.00.511 O-ring for ball valve drain 46x3.5
17 10.00.512 O-ring for ball valve drain 26x3.5
18 5003.0300 Insulation, melamin resin foam
19 54.00.228 Inspection lid f. quenching chamber
20 5012.0566 Gasket que nching chamber 0-ring
21 54.00.225 Clamping bar
22 2016.0935 Quenching nozzle 2.3 l/min.
23 2067.0050 Pressure hose d10mm
24 44.00.670 Water volume sensor with wire
25 2112.1346 Protecting h ose ø28x2x70mm
29 2120.1277 Base for sensor connection
Attention! Individual parts shown might not be used in this component group!
Version 2006 24
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
10 Hand shower
10 Hand shower
X 10 Hand shower 10
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 50.00.140 Hand shower roll guide
2 50.00.178 Connect. pipe f. hand shower roll guide
3 50.00.130 Hand shower
4 50.00.156 Clamp f. hand shower roll guide
5 1107.0100 Star lock ø4
6 50.00.279 Tulip for handshower
7 50.00.298 Tape f. tulip
8 50.00.537 Gasket f. connect.pipe hand shower roll guide
9 50.00.538 O-ring f. connect. pipe f. hand shower roll guide
Attention! Individual parts shown might not be used in this component group!
Version 2006 25
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
11 CleanJet
11 CleanJet
X 11 CleanJet 11
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 12.00.319 Housing f. Cleaning pump
2 56.00.166 Pressure hose f. cleaning
3 2066.0521 Hose cl amp 27mm
4 56.00.188 Suction hose f. cleaning
5 56.00.153 Pump f. cleaning UP30
Attention! Individual parts shown might not be used in this component group!
Version 2006 26
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
12 Gas parts
12 Gas parts
X 12 Gas parts 12
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
A 70.00.033 X12.A Gas valve cpl. ND 055 RG130
B 70.00.029 X12.B Gas valve cpl. WND 055 RG130
1 70.00.221 Air hose fixing device 40mm
2 70.00.028 Blower for burner RG130
3 1008.0750 Hex screw M5x16
4 1305.0160 Washer A5,3 x10mm
5 74.00.310 Flange f. burner blower RG130
6 1105.0122 He x combination nut M5 V2A
7 74.00.301 Gasket f. blower burner
8 10.00.065 Countersunk screw Torx T20 M4x12
9 70.00.069 Spacer sleeve f. gas burner blo wer
10 70.00.262 O-ring 21.89x2.62
11 10.00.064 Pan head screw Torx T20 M4x30
12 70.00.132 Corrugated hose 110mm
13 70.00.090 Corrugated hose 580mm
14 10.00.061 Pan head screw Torx T20 M4x12
15 10.00.063 Pan head screw Torx T20 M4x25
16 70.00.301 Combustion air angle pipe hot air
17 74.00.308 Gas connection manifold 2x3/4"
18 1006.0762 Hex screw M6x10
19 1306.0222 Washer A6,4x15x1,5
20 74.00.221 Automatic ignition controller
21 10.00.062 Pan head screw Torx T20 M4x20
22 70.00.094 Air hose D40x200mm
23 70.00.093 Air hose D40x650mm
24 10.00.456 Truss head screw Torx M4x30 T 20
25 1204.0120 Tooth lock washer A4,3
26 70.00.188 Hose fitting 3/4"-3/4"
27 70.00.280 Silicone hose ø4x1,5
Attention! Individual parts shown might not be used in this component group!
Version 2006 27
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
12 Gas parts
12.A Gas valve cpl. ND 055 RG130
X 12.A Gas valve cpl. ND 055 RG130 12
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 70.00.220 Gas valve GB 055 ND (straight)
2 70.00.255 Premix chamber cover gas f. RG130
3 70.00.030 Premix chamber gas f. RG130
4 70.00.106 Premix disc gas
5 70.00.256 Disc premix chamber-blower RG130
6 70.00.108 Disc gas valve-premix chamber
7 70.00.260 Gas nozzle 7mm
8 70.00.261 O-ring 17x1.5
Attention! Individual parts shown might not be used in this component group!
Version 2006 28
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
12 Gas parts
12.B Gas valve cpl. WND 055 RG130
X 12.B Gas valve cpl. WND 055 RG130 12
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 70.00.031 Gas valve GB 055 WND (lateral)
2 70.00.255 Premix chamber cover gas f. RG130
3 70.00.030 Premix chamber gas f. RG130
4 70.00.106 Premix disc gas
5 70.00.256 Disc premix chamber-blower RG130
Attention! Individual parts shown might not be used in this component group!
Version 2006 29
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
13 Exterior cabinet
13 Exterior cabinet
X 13 Exterior cabinet 13
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
A X13.A Exterior cabinet
1 22.00.354 Spacer ring
1 8450.1310 Spacer ri ng
2 22.00.353 Vent cover
2 8455.1209 Vent cover
3 1110.0800 Cag e nut M10
4 2022.0101 Grommet 18 mm
5 1106.0802 Cage nut M6
6 12.00.205 Upper part of pedestal
7 12.00.206 Lower part of pedestal
8 1328.0102 Safety washer A10,2
9 10.00.107 Allen screw M10x30
12 16.01.146 Bracket for door contact switch
Attention! Individual parts shown might not be used in this component group!
Version 2006 30
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
13 Exterior cabinet
13.A Exterior cabinet
X 13.A Exterior cabinet 13
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 16.00.815 Top cover
2 1003.2265 Countersunk self tapping screw 4,2x16
3 1104.0820 Snap nut 4,2mm
4 1105.0260 Cap n ut M5, high shape
5 1305.0160 Washer A5,3 x10mm
6 16.00.135 Side panel right
7 1603.0166 Rivet 3,2x7,9 CNS closed
8 16.00.136 Side panel left
9 10.00.102 Hex self tapping screw B4,2x32
10 16.00.187 Back panel
11 16.00.294 Front panel
12 2002.0107 Tension spring for front panel
13 16.00.673 Air inlet filter
14 2039.0331 Cap for service door
15 1004.2160 He x self tapping screw 4,2x16
16 16.00.180 Crossbar top
17 10.00.103 EJOT PT-screw KA 3.5x10
18 40.00.335 Door switch
19 16.00.329 Cover f. USB interface
20 10.00.460 EJOT PT-Screw Torx 3,5x14
21 16.00.325 Crossbar below
22 16.00.338 Edge protection profile
23 40.00.469 Interface cable USB 0.9m
24 50.00.296 Clip f. drip collector
25 50.00.286 Drip collector
26 50.00.303 Bushing drip collector
27 50.00.556 Drain drip collector
27 50.00.299 Drain drip collector
28 5105.1027 Gasket f. exhaust pipe d=54mm
29 16.00.384 Bracket for door contact switch
Attention! Individual parts shown might not be used in this component group!
Version 2006 31
SCC 61G
Valid as of G61SE0404 up to G61SE....
Gas unit
14 Miscellaneous
14 Miscellaneous
X 14 Miscellaneous 14
Voltage 1 NAC 120V 60Hz
Item no. Part no Reference Description
1 60.61.055 Hinging rack left
2 60.61.056 Hinging rack right
3 10.00.448 Phillips countersunk-head screw M5x16
4 1004.0666 He x screw M4x10
5 10.00.565 Hex screw M8x20
6 1208.0160 Tooth lock washer A8,4
9 1106.0360 Cap n ut M6, high shape
10 5003.0300 Insulation, melamin resin foam
11 5006.0500 Pol yurethan-Glue for insulation 310ml
12 60.60.574 Positioning support f. core sensor
13 42.00.029 USB-Memory-Stick
16 1105.0123 He x combination nut M4
20 4019.0008 Sticker Electric /Danger
Attention! Individual parts shown might not be used in this component group!
Version 2006 32
Loading...
