Tavole MD
Rif. CODICE DESCRIZIONE DESCRIPTION DESCRIPCION
001
38120024
COPERCHIO DOSATORE MD
COVER FOR MD GRINDER
TAPA DOSADOR MD
002
38125014A
SERBATOIO MD40 AZZURRO
TANK MD 40 BLUE
CONTENEDOR MD40 AZUL
003
21204002
CORPO DOSATORE MD40
MD 40 MIXER BODY
CUERPO DOSADOR MD 40
004
21210502
FORCHETTA MD 40
MD 40 FORK
HORQUILLA MD 40
005
37040610
VITE M6X10
SCREW M 6 X 10
TORNILLO M 6 X 10
006
37020414
VITE M4X14
SCREW M 4 X 14
TORNILLO M 4 X 14
007
38120041
RACCOGLIT.CAFFE’MD 40
MD 40 PICKER
RECOGEDOR MD 40
008
21202301
BASAMENTO MD40
MD 40 BASE
BLOQUE MD 40
009
37030510
VITE M5X10
SCREW M5X10
TORNILLO M 5 X 10
010
38120042
GHIERA REG.MACIN.MD40
MD 40 BUSH
VIROLA MD 40
011
22208501
FERMO GHIERA MD50
MD40-50 BUSH STOP
RETENCION VIROLA MD40-50
012
37060635
VITE M6X35
SCREW M6X35 TCEI ACC.BR.
TORNILLO M 6 X 35 TCEI
013
21202101
TESTATA MD40
MD 40 HEAD
CULADA MD 40
014
39120035
MOLLA SPINETTA MD
MD PIN SPRING
RESORTE PASADOR MD
015
28100001
DISTANZIALE TEST.MD40
MD40 SPACE SLEEVE
SEPARADOR TEST. MD40
016
26122001
VITE FISS.P.MACINA MD40
SCREW
TORNILLO
018
37030407
VITE M 4X7
SCREW M4X7
TORNILLO M 4 X 7
019
36301026
GUARN.BOCCA SCAR.MD40
MD 40 GASKET
JUNTA MD40
020
37030511
VITE INOX M5X12
SCREW INOX M5X12
VITE INOX M5X12
021
34030064
INTERR.LUM.BIP.NERO 400V AC
PUSH BUTTON 400V AC
INTERR.LUM.BIP.NERO 400V AC
022
36310003
PIEDINO GOMMA MD50
MD40-50 FOOT
PIE MD40-50
023
37410500
RONDELLA PIANA D.5 FE.ZN.
PLANE WASHER DIAM.5
ARANDELA PLANA D.5
024
37174012
VITE TAPTITE 4X12
SCREW 4 X 12
TORNILLO 4 X 12
025
37410610
RONDELLA D.6 X 18 FE.ZN.
WASHER DIAM. 6 X 18
ARANDELA D.6 X 18
026
37310400
DADO M4 ALTO FE.ZN.
NUT M 4
TUERCA M 4
027
36201006
RONDELLA SCALDATAZ.GOMMA SL 50
RUBBER HEAT-CUP WASHER
ARANDELLA
028
37900505
FISSATORE TONDO D.3
ROUND FIXER D3 H106
GANCHO
029
34200212
MORSET-FISSACAVO + VITE
CLAMP + SCREW
BORNE + TORNILLO
030
26206002
PERNO GUIDA TRAM.MD40
HOPPER PIN MD40
PERNO TOLVA MD40
031
37430400
ROS.DENT.EST.D.4
OUTER TOOTHED WASHER D4
ARANDELA DENTADA D.4
032
69000032
COPPIA MACINE D.50 MD40
COUPLE GRINDERS D50
PAR MOLIENDA MD40
033
20114701
PORTAMACINA INF. MD40-ROCKY
LOWER GRINDER HOLDER
PORTAMOLIENDA MD 40
034
14000110
MOTORE MD40 115V COMPLETO
MD40 MOTOR 110V
MOTOR MD40 110V
14000220
MOTORE MD40 230V COMPLETO
MD40 MOTOR 220/240V
MOTOR MD40 220/240V
035
32330271
CARROZZERIA MD40/N
BODY MD40/N
CARROCERIA MD40/N
036
37153909
VITE 3,9 X 9,5
SELF-TAPP.SCREW 3.9 X 9.5
TORNILLO 3,9 X 9,5 AUTOR.
037
34300049
CAVO CON SPINA
CABLE WITH PLUG
CABLE Y ENCHUFE 110V
34300052
CAVO+SPINA
CABLE WITH PLUG AUSTRALIA
CABLE Y ENCHUFE AUSTRALIA
34300085
CAVO+SPINA
CABLE WITH PLUG
CABLE Y ENCHUFE EUROPE
038
37900304
TIRANTE M4X250 MD40
TIE ROD 4 MA X 250
TIRANTE 4 MA X 250
039
23212006
SPESSORE FILETT.MD40
MD40 SHIM
ESPESOR MD40
041
42200121
TARGH.RANCILIO MM.70
RANCILIO PLATE MM 70
TARJETA RANCILIO MM 70
042
34020111
DISGIUNTORE MD40 110V
CIRC.BREAKER 110V MD40
DISYUNTOR 110V MD40
34020112
DISGIUNTORE MD40 230V
CIRC.BREAKER 220V MD40
DISYUNTOR 220V MD40
043
34200043
RESISTENZA 12
HEATING ELEMENT
RESISTOR MD40-ROCKY
044
14013009
CABLAGGIO MD40
CABLE MD40
CABLE MD40
MACINADOSATORE
COFFEE DOSING GRINDERS
MOLINOS-DOSIFICADORES
TAV.03725
MD 40
MACINADOSATORE
COFFEE DOSING GRINDERS
MOLINOS-DOSIFICADORES
TAV.03725
MD 40
Rif. CODICE DESCRIZIONE DESCRIPTION DESCRIPCION
045
34020021
CONDENS.60MF MD40 110V
ROCKY CONDENSER 110V
CONDENSADOR ROCKY 110V
34020022
CONDENS. MD40 230V
ROCKY CONDENSER 230V
CONDENSADOR ROCKY 220V
046
37430800
ROS.DENT.EST.D.8 ACC.BR.
WASHER D.8
ARANDELA DENTADA D.8
047
37320800
DADO M8
NUT M 8
TUERCA M 8
048
32339010
SQUADR.MOTORE MD40/N
MD40/N MOTOR SUPPORT
SOPORTE MOTOR MD40/N
049
34030131
COPERTURA INTERRUTTORI MD
MD SWITCH COVER
PROTECTORA INTERRUPTOR MD
050
37430600
ROS.DENT.EST.D.6
OUTER TOOTHED WASHER D.6
ARANDELA DENTADA D.6
051
37040621
VITE INOX M6X20
SCREW M 6 X 20 INOX
TORNILLO M 6 X 20 INOX
052
37420601
ROND.EL.D.6 GROWER INOX
ELASTIC WASHER D.6
ANILLO ELASTICO D.6 GROW.
053
37320601
DADO M6
INOX NUT M 6
TUERCA M 6 INOX
054
45010047
ADESIVO TERRA EQUIPOTENZ.
SELF-ADHESIVE
ADHESIVO
055
37420401
ROND.EL.D.4 GROWER INOX
ELASTIC WASHER DIAM.4
ARANDELA ELASTICA D.4
MACINADOSATORE
COFFEE DOSING GRINDERS
MOLINOS-DOSIFICADORES
TAV.03725
MD 40
MACINADOSATORE
COFFEE DOSING GRINDERS
MOLINOS-DOSIFICADORES
TAV.03725
MD 40
Rif. CODICE DESCRIZIONE DESCRIPTION DESCRIPCION
001
23308005
PERNO PALETTA MD-AT
MD-AT SHOVEL PIN
PERNO PALETA MD-AT
002
22208001
PALETTA ARRESTO MD/AT
MD/AT SHOVEL STOP
PALETA DE PARADA MD/AT
003
38125008A
SERBATOIO MD50 AZZURRO
COFFEE TANK MD50 LIGHT BLUE
CONTENEDOR MD50 AZUL
004
21204001
CORPO DOSATORE MD50-80
MD50-80 DOSING MIXER BODY
CUERPO DOSADOR MD50-80
005
34100004
MICRO AVVIAMENTO MD/AT
MD/AT MICRO START
MICRO PUEST.EN MARC.MD/AT
006
37173015
VITE TAPTITE M3X15TC
SCREW M 3 X 15 TC
TORNILLO M 3 X 15 TC
007
21210501
FORCHETTA PORTAFIL.MD
MD50-80 FORK
HORQUILLA MD50-80
008
37040610
VITE M6X10
SCREW M 6 X 10
TORNILLO M 6 X 10
009
37030410
VITE M4X10
SCREW M 4 X 10
TORNILLO M 4 X 10
010
38120013
RACCOGLIT.CAFFE’MD 50
MD 50 PICKER
RECOGEDOR MD 50
011
38120024
COPERCHIO DOSATORE MD
COVER FOR MD GRINDER
TAPA DOSADOR MD
012
37174012
VITE TAPTITE 4X12
SCREW 4 X 12
TORNILLO 4 X 12
013
21212502
COPERCHIO SCAT.MICRO
MICRO BOX COVER
TAPA CAJA MICRO
014
34100003
MICRO ARRESTO MD/AT
MD/AT MICRO STOP
MICRO PARADA MD/AT
015
21211501
SCATOLA PORTAMICRO MD
MICRO-HOLDER BOX
CAJA MICRO
016
37040414
VITE M4X14
SCREW M 4 X 14
TORNILLO M 4 X 14
017
38120063
RIPARO TESTATA MD50/ST
PROTECTION MD50/ST
PROTECCION MD50/ST
018
37430600
ROS.DENT.EST.D.6
OUTER TOOTHED WASHER D.6
ARANDELA DENTADA D.6
019
37320600
DADO M 6
NUT M 6
TUERCA M 6
020
21203511
BASAMENTO MD50
MD50 BASE
BLOQUE MD50
021
22208501
FERMO GHIERA MD50
MD40-50 BUSH STOP
RETENCION VIROLA MD40-50
022
39120035
MOLLA SPINETTA MD
MD PIN SPRING
RESORTE PASADOR MD
023
37060650
VITE M6X50
SCREW M 6 X 50
TORNILLO M 6 X 50 ALEN
024
37410600
RONDELLA PIANA D.6
PLANE WASHER DIAM. 6
ARANDELA PLANA D.6
025
26117015
PRIGIONIERO DIST.MD50
MD 50 STUD
PRISIONERO MD 50
026
36310008
PIEDINO ADESIVO NERO
NANCY SUPPORT BLACK
PIE NEGRO
027
34030064
INTERR.LUM.BIP.NERO 400V AC
PUSH BUTTON 400V AC
INTERR.LUM.BIP.NERO 400V AC
028
37410500
RONDELLA PIANA D.5 FE.ZN.
PLANE WASHER DIAM.5
ARANDELA PLANA D.5
029
37430400
ROS.DENT.EST.D.4
OUTER TOOTHED WASHER D4
ARANDELA DENTADA D.4
031
37030410
VITE M4X10
SCREW M 4 X 10
TORNILLO M 4 X 10
032
32330783
PIASTRINA FORCHETTA MD
SUPPORT FOR FORK MD
ANGULAR POR HORQUILLA MD
034
36310003
PIEDINO GOMMA MD50
MD40-50 FOOT
PIE MD40-50
036
26216005
VITE X PORTAMAC.MD50
MD50 GRINDER HOLDER SCREW
TORNIL.PORTAMOLIENDA MD50
037
37030407
VITE M 4X7
SCREW M4X7
TORNILLO M 4 X 7
038
22104001
PORTAMACINA MD 50
MD 50 GRINDER HOLDER
PORTAMOLIENDA MD 50
040
34200212
MORSET-FISSACAVO + VITE
CLAMP + SCREW
BORNE + TORNILLO
041
36201006
RONDELLA SCALDATAZ.GOMMA SL 50
RUBBER HEAT-CUP WASHER
ARANDELLA
042
37900505
FISSATORE TONDO D.3
ROUND FIXER D3 H106
GANCHO
043
34200213
BLOCCHETTO UNIPOLARE
CLAMP MD 400V
BORNE MD 400V
044
69000033
COPPIA MACINE D.63,5 MD50
COUPLE GRINDERS MD50
PAR MOLIENDA MD50
045
14000011
MOTORE MD50 115V COMPLETO
MD50 COMPLETE MOTOR 115V
MOTOR MD50N 110V
14000022
MOTORE MD50 230V COMPLETO
MD 50 230V MOTOR COMPLETE
MOTORE MD50 230V COMPLETO
34014038
MOTORE MD50 400V
MOTOR 380V MD50
MOTOR MD 50 380V
046
37310400
DADO M4 ALTO FE.ZN.
NUT M 4
TUERCA M 4
047
37900305
TIRANTE M 4 X 275
TIE ROD M 4 X 275
TIRANTE M 4 X 275
048
32330272
CARROZZERIA MD50/N
BODY MD50/N
CARROCERIA MD50/N
MACINADOSATORE
COFFEE DOSING GRINDERS
MOLINOS-DOSIFICADORES
TAV.03730
MD 50
MACINADOSATORE
COFFEE DOSING GRINDERS
MOLINOS-DOSIFICADORES
TAV.03730
MD 50
67
54
49
50
45
61
64
12
53
Rif. CODICE DESCRIZIONE DESCRIPTION DESCRIPCION
049
37153909
VITE 3,9 X 9,5
SELF-TAPP.SCREW 3.9 X 9.5
TORNILLO 3,9 X 9,5 AUTOR.
050
34300049
CAVO CON SPINA
CABLE WITH PLUG
CABLE Y ENCHUFE 110V
34300052
CAVO+SPINA
CABLE WITH PLUG AUSTRALIA
CABLE Y ENCHUFE AUSTRALIA
34300085
CAVO+SPINA
CABLE WITH PLUG
CABLE Y ENCHUFE EUROPE
34300087
CAVO
CABLE MD50-80 400V
CABLE MD50-80 400V
051
32920030
PROTEZ.BASAM.MD50/N
MD50/N PROTECTION
PROTECCION MD50/N
052
32339011
SOSTEGNO RELE’ MD50/N
SUPPORT RELAY MD50/N
SOPORTE RELE MD50/N
053
37900808
PIASTRINA
PLATE U-8/24/11
PLACA U-8/24/11
37900809
PIASTRINA
PLATE U/8/11/9
PLACA U/8/11/9
054
34200191
RELE’ 110V MD50
RELAY 110V MD50
RELE 110V MD50
34200192
RELE’ 230V MD50
RELAY 230V
RELE 230V
055
14701011
TESTATA MD50+PORTAMACINE
MD 50 HEAD
CULATA MD BOCA DESAGOTE
056
37510400
ANEL.EL.D.4
ELASTIC RING DIAM.4
ANILLO ELASTICO D.4
057
37410611
RONDELLA D.6X16X1 FE.ZN.
WASHER D.6X16X1
ARANDELA D.6X16X1
058
38120065
REGOLATORE MACINAT.MD50-80
MD GRINDER REGULATOR
REGULADOR MOLEDURA MD
059
26214010
PERNO REG.MACINATURA
MD REGULATOR PIN
PERNO REGULADOR MD
060
42200121
TARGH.RANCILIO MM.70
RANCILIO PLATE MM 70
TARJETA RANCILIO MM 70
061
14013011
CABLAGGIO MD50/ST 110/230V
CABLE MD50/ST 110/230V
CABLE MD50/ST 110/230V
14013013
CABLAGGIO MD50/AT 110/230V
CABLE MD50/AT 110/230V
CABLE MD50/AT 110/230V
062
32329024
SQUADR.DISGIUN.MD
SUPPORT FOR CIRC.BREAKER
ANGULAR POR DISYUNTOR MD
063
34020109
DISGIUNTORE 230V MD50
SEPARATOR MD50 4211 NEW
DISGIUNTORE MD50 4211 NUOVO
064
37420401
ROND.EL.D.4 GROWER INOX
ELASTIC WASHER DIAM.4
ARANDELA ELASTICA D.4
065
37430600
ROS.DENT.EST.D.6
OUTER TOOTHED WASHER D.6
ARANDELA DENTADA D.6
066
34030131
COPERTURA INTERRUTTORI MD
MD SWITCH COVER
PROTECTORA INTERRUPTOR MD
067
34030052
PULSANTE BIP.LUMIN.ARANCIO
PUSH BUTTON MD/AT
BOTON MD/AT
34030075
COPRIFORO CAVA 30X22
COVER HOLE 30X22
TAPON
068
34210100
MORSETTO VOLANTE SEZ.4
CLAMP
BORNE
069
37040621
VITE INOX M6X20
SCREW M 6 X 20 INOX
TORNILLO M 6 X 20 INOX
070
37420601
ROND.EL.D.6 GROWER INOX
ELASTIC WASHER D.6
ANILLO ELASTICO D.6 GROW.
071
37320601
DADO M6
INOX NUT M 6
TUERCA M 6 INOX
072
45010047
ADESIVO TERRA EQUIPOTENZ.
SELF-ADHESIVE
ADHESIVO
073
34200156
BOCCOLA PASSACAVO
CABLE PASS MD
PASA CABLE MD
074
34020023
CONDENS.MF150 MD50 110V
MD50 CONDESER 110V MF150
CONDENS.MF150 MD50 110V
075
37430800
ROS.DENT.EST.D.8 ACC.BR.
WASHER D.8
ARANDELA DENTADA D.8
076
37320800
DADO M8
NUT M 8
TUERCA M 8
077
32339014
SOSTEGNO CONDENS.MD50
CONDENS.SUPPORT MD50 110V
SOSTEN CONDENS.MD50 110V
078
32339013
SOSTEGNO RELE’MD50
SUPPORT RELAY MD50 110V
SOPORTE RELE MD50 110V
MACINADOSATORE
COFFEE DOSING GRINDERS
MOLINOS-DOSIFICADORES
TAV.03730
MD 50
MACINADOSATORE
COFFEE DOSING GRINDERS
MOLINOS-DOSIFICADORES
TAV.03730
MD 50
67
54
49
50
45
61
64
12
53
Rif. CODICE DESCRIZIONE DESCRIPTION DESCRIPCION
001
23308005
PERNO PALETTA MD-AT
MD-AT SHOVEL PIN
PERNO PALETA MD-AT
002
22208001
PALETTA ARRESTO MD/AT
MD/AT SHOVEL STOP
PALETA DE PARADA MD/AT
003
38125009A
SERBATOIO MD80 AZZURRO
TANK MD80 BLUE
TANQUE MD 80 AZUL
004
21204001
CORPO DOSATORE MD50-80
MD50-80 DOSING MIXER BODY
CUERPO DOSADOR MD50-80
005
34100004
MICRO AVVIAMENTO MD/AT
MD/AT MICRO START
MICRO PUEST.EN MARC.MD/AT
006
37173015
VITE TAPTITE M3X15TC
SCREW M 3 X 15 TC
TORNILLO M 3 X 15 TC
007
21210501
FORCHETTA PORTAFIL.MD
MD50-80 FORK
HORQUILLA MD50-80
008
37040610
VITE M6X10
SCREW M 6 X 10
TORNILLO M 6 X 10
009
21203411
BASAMENTO MD80
MD 80 BASE
BLOQUE MD 80
010
38120026
RACCOGLIT.CAFFE’MD 80
MD 80 PICKER
REGOGEDOR MD 80
011
38120024
COPERCHIO DOSATORE MD
COVER FOR MD GRINDER
TAPA DOSADOR MD
012
37174012
VITE TAPTITE 4X12
SCREW 4 X 12
TORNILLO 4 X 12
013
21212502
COPERCHIO SCAT.MICRO
MICRO BOX COVER
TAPA CAJA MICRO
014
34100003
MICRO ARRESTO MD/AT
MD/AT MICRO STOP
MICRO PARADA MD/AT
015
21211501
SCATOLA PORTAMICRO MD
MICRO-HOLDER BOX
CAJA MICRO
016
37040414
VITE M4X14
SCREW M 4 X 14
TORNILLO M 4 X 14
017
37430600
ROS.DENT.EST.D.6
OUTER TOOTHED WASHER D.6
ARANDELA DENTADA D.6
018
37320600
DADO M 6
NUT M 6
TUERCA M 6
019
34030064
INTERR.LUM.BIP.NERO 400V AC
PUSH BUTTON 400V AC
INTERR.LUM.BIP.NERO 400V AC
020
38111003
FERMO GHIERA MD 80
MD 80 BUSH STOP
RETENCION VIROLA MD 80
022
37060870
VITE M8X70
SCREW M 8 X 70
TORNILLO M 8 X 70 ALEN
023
37410600
RONDELLA PIANA D.6
PLANE WASHER DIAM. 6
ARANDELA PLANA D.6
024
26117016
PRIGIONIERO DIST.MD80
MD 80 STUD
PRISIONERO MD 80
025
36310008
PIEDINO ADESIVO NERO
NANCY SUPPORT BLACK
PIE NEGRO
026
37320500
DADO M 5
NUT M 5
TUERCA M 5
027
37430500
ROS.DENT.EST.D.5 ACC.BR.
THUMB WASHER DIAM.5
ARANDELA DENTADA D.5
029
37030510
VITE M5X10
SCREW M5X10
TORNILLO M 5 X 10
030
32330783
PIASTRINA FORCHETTA MD
SUPPORT FOR FORK MD
ANGULAR POR HORQUILLA MD
032
36310003
PIEDINO GOMMA MD50
MD40-50 FOOT
PIE MD40-50
033
37410611
RONDELLA D.6X16X1 FE.ZN.
WASHER D.6X16X1
ARANDELA D.6X16X1
034
26220020
VITE X PORTAMAC.MD 80
MD80 GRINDER HOLDER SCREW
TORNILLO PORTAMOLIENDA 80
035
20114801
PORTAMACINA MD 80
MD 80 GRINDER HOLDER
PORTAMOLIENDA MD 80
037
34200212
MORSET-FISSACAVO + VITE
CLAMP + SCREW
BORNE + TORNILLO
038
36201006
RONDELLA SCALDATAZ.GOMMA SL 50
RUBBER HEAT-CUP WASHER
ARANDELLA
039
37900505
FISSATORE TONDO D.3
ROUND FIXER D3 H106
GANCHO
040
34200213
BLOCCHETTO UNIPOLARE
CLAMP MD 400V
BORNE MD 400V
041
69000034
COPPIA MACINE D.75 MD80
COUPLE GRINDERS MD80
PAR MOLIENDA MD80
042
34014003
MOTORE MD80 400V
MOTOR 400V MD80
MOTOR MD 80 380V
042
34040012
ELETTR.3VIE 220V 50HZ MISS
220V 3WAY ELEC.VALVE
ELECTROV.3VIAS 220V MISS
043
37900313
TIRANTE M 6 X 320 MD80
TIE ROD M 6 X 320
TIRANTE M 6 X 320
044
32330273
CARROZZERIA MD80/N
BODY MD80/N
CARROCERIA MD80/N
045
37153909
VITE 3,9 X 9,5
SELF-TAPP.SCREW 3.9 X 9.5
TORNILLO 3,9 X 9,5 AUTOR.
046
34300052
CAVO+SPINA
CABLE WITH PLUG AUSTRALIA
CABLE Y ENCHUFE AUSTRALIA
34300072
CAVO+SPINA
CABLE+PLUG
CABLE Y ENCHUFE
34300087
CAVO
CABLE MD50-80 400V
CABLE MD50-80 400V
34549022
CAVO+SPINA UL
CABLE WITH PLUG S26/7 UL
CABLE Y ENCHUFE S26/7 UL
MACINADOSATORE
COFFEE DOSING GRINDERS
MOLINOS-DOSIFICADORES
TAV.03735
MD 80
MACINADOSATORE
COFFEE DOSING GRINDERS
MOLINOS-DOSIFICADORES
TAV.03735
MD 80
46
45
57
Rif. CODICE DESCRIZIONE DESCRIPTION DESCRIPCION
047
32559024
PROTEZ.BASAMENTO MD80
MD 80 PROTECTION
PROTECCION MD 80
048
14701012
TESTATA MD80+PORTAMACINE
MD 80 HEAD
CULATA MD 80
049
37510400
ANEL.EL.D.4
ELASTIC RING DIAM.4
ANILLO ELASTICO D.4
050
38120065
REGOLATORE MACINAT.MD50-80
MD GRINDER REGULATOR
REGULADOR MOLEDURA MD
051
26214010
PERNO REG.MACINATURA
MD REGULATOR PIN
PERNO REGULADOR MD
053
37030408
VITE M4X8 INOX
SCREW M 4 X 8
TORNILLO M 4 X 8
37113509
VITE 3,5 X 9,5
SCREW 3,5 X 9,5
TORNILLO 3,5 X 9,5
054
37430400
ROS.DENT.EST.D.4
OUTER TOOTHED WASHER D4
ARANDELA DENTADA D.4
055
32339012
SOSTEGNO RELE’ MD80/N
SUPPORT RELAY MD80/N
SOPORTE RELE MD80/N
056
34200181
RELE’230V MD80
RELAY 230V MD80
RELE’230V MD80
34200182
ADATTATORE RELE’ MD80
RELAY ADAPTE
ADATTATORE RELE’ MD80
34200193
RELE’ 110V MD80
RELAY 110V MD80
RELE 110V MD80
057
34020009
CONDENS.250 MF 150V.MD80V.110
MD80 110V CONDENSER
CONDENSADOR MD80 110V
34020012
CONDENS.80/100MF.240 MD 80 220
MD80 220V CONDENSER
CONDENSATOR MD80 220V
058
34200069
FASCETTA
“LEGRAND”CLAMP 320.43
ABRAZADERA 320.43 LEGRAND
059
14013015
CABLAGGIO MD80 110/230V
CABLE MD80 110/230V
CABLE MD80 110/230V
14013016
CABLAGGIO MD50AT-80 400V
CABLE MD80 400V
CABLE MD80 400V
060
34020103
DISGIUNTORE MD80 115V
CIRC.BREAKER MD80 110V
DISYUNTOR MD80 110V
34020105
DISGIUNTORE MD80/220V
CIRC.BREAKER MD80 220V
DISYUNTOR MD80 220V
061
34020106
ATTACCO DISGIUNTORE MD
MD80 CIRC.BREAKER CONNECT
SOPORTE DISYUNT.MD80
062
37420401
ROND.EL.D.4 GROWER INOX
ELASTIC WASHER DIAM.4
ARANDELA ELASTICA D.4
063
34030131
COPERTURA INTERRUTTORI MD
MD SWITCH COVER
PROTECTORA INTERRUPTOR MD
064
34030052
PULSANTE BIP.LUMIN.ARANCIO
PUSH BUTTON MD/AT
BOTON MD/AT
065
37430800
ROS.DENT.EST.D.8 ACC.BR.
WASHER D.8
ARANDELA DENTADA D.8
066
34210100
MORSETTO VOLANTE SEZ.4
CLAMP
BORNE
067
37040621
VITE INOX M6X20
SCREW M 6 X 20 INOX
TORNILLO M 6 X 20 INOX
068
37420601
ROND.EL.D.6 GROWER INOX
ELASTIC WASHER D.6
ANILLO ELASTICO D.6 GROW.
069
37320601
DADO M6
INOX NUT M 6
TUERCA M 6 INOX
070
45010047
ADESIVO TERRA EQUIPOTENZ.
SELF-ADHESIVE
ADHESIVO
071
37175012
VITE TAPTITE M5X12TC CROS FECD
SCREW 5 X 12
TORNILLO 5 X 12
072
34200156
BOCCOLA PASSACAVO
CABLE PASS MD
PASA CABLE MD
MACINADOSATORE
COFFEE DOSING GRINDERS
MOLINOS-DOSIFICADORES
TAV.03735
MD 80
46
45
57
MACINADOSATORE
COFFEE DOSING GRINDERS
MOLINOS-DOSIFICADORES
TAV.03735
MD 80
Rif. CODICE DESCRIZIONE DESCRIPTION DESCRIPCION
001
37060645
VITE M6X45
SCREW M 6 X 45
TORNILLO M 6 X 45 ALEN
002
37113913
VITE 3,9 X 13
SCREW 3,9 X 13
TORNILLO 3,9 X 13
003
14701027
PRESSINO X MD COMPLETO
WHOLE MD PRESS
PRENSADOR MD COMPLETO
21208301
PARTE SUP.PRESS.MD
SUPERIOR PART FOR PRESS
PARTE SUPERIOR PRENSADOR
004
38120031
PARTE INFER.PRESSINO
INFERIOR PART FOR PRESSE
PARTE INFERIOR PRENSADOR
38120032
PARTE INF.PRESS.RIDOT
INFERIOR PART FOR PRESSE
PARTE INFERIOR PRENSAND
005
14030001
TRAMOGGIA MD50 COMPLETA
WHOLE MD 50 HOPPER
TOLVA MD 50 COMPLETA
14030005
TRAMOGGIA MD40 COMPLETA
COMPLETE MD 40 HOPPER
TOLVA MD 40 COMPLETA
14030011
TRAMOGGIA MD80 COMPLETA
WHOLE MD 80 HOPPER
TOLVA MD 80 COMPLETA
006
38120012
COPERCHIO TRAMOG.MD50
MD 50 HOPPER COVER
TAPA TOLVA MD 50
38120025
COPERCHIO TRAMOG.MD80
MD 80 HOPPER COVER
TAPA TOLVA MD 80
38120040
COPERCHIO TRAMOG.MD40
MD 40 HOPPER COVER
TAPA TOLVA MD 40
007
37030420
VITE M4X20
SCREW M 4 X 20
TORNILLO M 4 X 20
37030425
VITE M4X25
SCREW M 4 X 25
TORNILLO M 4 X 25
008
37430400
ROS.DENT.EST.D.4
OUTER TOOTHED WASHER D4
ARANDELA DENTADA D.4
009
38120061
RIPARO MACINE MD40
MD40 GRINDERS COVER
CUBRE MOLIENDA MD40
38120062
RIPARO MACINE MD50-80
MD50-80 GRINDERS COVER
CUBRE MOLIENDA MD50-80
011
37900505
FISSATORE TONDO D.3
ROUND FIXER D3 H106
GANCHO
012
32329015
CHIUSURA TRAMOGGIA MD50-80
MD50-80 HOPPER LOCK
CARRADURA TOLVA MD50-80
32329038
CHIUSURA TRAM.MD 40
MD 40 HOPPER LOCK
CARRADURA TOLVA MD 40
013
37030307
VITE M3X7
SCREW M 3 X 7
TORNILLO M 3 X 7
014
38120010
MANOPOLA FILTRO GRZ
GRZ FILTER HANDLE
MANECILLA FILTRO GRZ
015
37320300
DADO M3
NUT M 3
TUERCA M 3
016
26206002
PERNO GUIDA TRAM.MD40
HOPPER PIN MD40
PERNO TOLVA MD40
26206003
PERNO GUIDA TRAM.MD50-80
HOPPER PIN MD50-80
PERNO TOLVA MD50-80
017
38123002
RASCHIAVETRO MD
MD50-80 GLASS SCRAPER
RASCAVIDRIO MD50-80
018
21208701
POMOLO REG.DOSE CAFFE’
MD50-80 DOSE HANDLE
MANOPLA DOSIS MD50-80
21208702
POMOLO DOSE MD 40
DOSE HANDLE MD40
MANOPLA DOSIS MD 40
019
21208501
STELLA SUPERIORE MD
UPPER STAR MD
ESTRELLA SUPERIOR MD
020
32329014
DIVISORE CAFFE’ MD
MD COFFEE DIVIDER
DIVISOR CAFE MD
021
21206501
STELLA INTERMEDIA MD
MD MEDIUM STAR
ESTRELLA INTERMEDIA MD
022
39120025
MOLLA DOSATORE MD
DOSING SPRING MD
RESORTE DOSATOR MD
023
37510600
ANEL.EL.D.6
ELASTIC RING DIAM.6
ANILLO ELASTICO ECONOMIZADOR D.6
024
14701020
STELLA INF.MD CON PERNO
LOWER STAR MD
ESTRELLA INFERIOR MD
025
69000085
CONTACOLPI M 20 + LEV.
STROKE COUNTER M 20
CUENTAGOLPES M 20
026
36910021
GOMMA X CONTACOLPI MD
MD STROKE RECORDER RUBBER
GOMA CUENTAGOLPES MD
027
21103000
CAMME DOSATORE
MD DOSING MIXER CAMS
LEVA DOSADOR MD
028
22206501
COPERTURA DOSATORE MD
MD GRINDER COVER
PROTECCION DOSADOR MD
029
37184012
VITE TAPTITE M4X10TS
SCREW M 4 X 12
TORNILLO M 4 X 12
030
39220015
MOLLA CONTACOLPI MD
MD SPRING
RESORTE CUENTAGOLPES MD
032
26105005
SPINETTA DOSATORE MD
PIN FOR MD GRINDER
PASADOR DOSADOR MD
033
39520008
MOLLA TAZZA D.18 X 8 SP.1
SPRING DIAM. 18 X 8
RESORTE D.18 X 8
034
37320805
DADO M 8 SINISTRO
LEFT NUT M 8
TUERCA M 8 IZQUIERDA
035
26208006
PROLUNGA RASCH.MD 80
EXTENSION GLASS SCRAPER
PROLONGACION RASCAVIDRIO
036
39220010
MOLLA RICHIAMO LEVA MD
MD LEVER SPRING
RESORTE PALANCA MD
037
36901101
GOMMINO FERMO LEVA MD
MD STOP RUBBER
ANILLO TOPE MD
038
37174012
VITE TAPTITE 4X12
SCREW 4 X 12
TORNILLO 4 X 12
039
22105001
LEVA DOSATORE MD
MD LEVER FOR GRINDER
PALANCA DOSADOR MD
040
14701021
COP+SERRAT.MD50-80 COMPLETA
WHOLE MD50-80 LOCK
CERRADURA MD50-80 COMPL.
DOSIFICADOR/TOLVA
DISPENSER/HOPPER
DISPENSER/HOPPER
DOSIFICADOR/TOLVA
DISPENSER/HOPPER
DISPENSER/HOPPER
VERSIONE
µF
VERSIONE
µF
AVVIO IN PRODUZIONE DEI MACINADOSATORI CON MOTORI MOD.ARDUINI
Loading...
