Rancilio CLASSE 6 S User Manual

6S

CLASSE 6 S / S COMPACT / S TANK

Versatile
and essential

The semi-automatic control
of this version makes it an extremely
simple machine to use and reliable
in all situations.

www.rancilio.com

COMPACT

with 1 or 2 groups, has the same potential, but
in a smaller housing unit, allowing it to be po­sitioned even in restricted spaces.

maintenance easier, Rancilio has equipped all
its products with a revolutionary work surface.
Support grids come in a scratchproof polymer,
with an e cient liquid collection system that
keeps the work surface clean and protects
cups against unsightly marks left by drops of
co ee. The grids can be removed for washing
in a dishwasher. Rancilio quality also means
attention to details.

The compact model, available

GRID SYSTEM

To make cleaning and

6S . TECHNICAL FEATURES

6S . FEATURES

Technical Features

independent heat exchangers

electric heating

incorporated volumetric pump

boiler pressure gauge

automatic water level control

boiler pressure control with pressure stat

housing in stainless steel

electronic controls operate on supply voltage

Endowments, accessories

ENDOWMENTS: 1 fi lter holder for 2 cups per group, 1 fi lter holder for 1 cup,

2 steam wands, 1 hot water dispenser, co ee tamper, measuring scoop and washing
disks, foot extensions.

ACCESSORIES: Water softener, MD dosing grinder, interchangeable sides.

Colors

stainless steel and steel panels painted metallic grey

Technical Data

1 GROUP COMPACT

dimensions (wxdxh)

18.9(14.5)* x 19.6 x 19.2 inches

boiler power

1600

1 GROUP Tank**

dimensions (wxdxh)

18.9(14.5)* x 19.6 x 19.2 inches

boiler power

1600

2 GROUPS COMPACT

dimensions (wxdxh)

27.1(22.4)* x 19.6 x 19.2 inches

boiler power

2700 W/3000 W

2 GROUPS

dimensions (wxdxh)

33.4(28.7)* x 19.6 x 19.2 inches

boiler power

3200 W/6000 W

3 GROUPS

dimensions (wxdxh)

42.9(38.1)* x 19.6 x 19.2 inches

boiler power

6000 W

*Without side extensions, decrease the total width by 5”

**2 lt water tank

weight

79 lbs

voltage

110

weight

64 lbs

voltage

110

weight

121 lbs

voltage

120 /230

weight

137 lbs

voltage

120 / 230

weight

207 lbs

voltage

230

boiler (lt)

4

boiler (lt)

4

boiler (lt)

5

boiler (lt)

11

boiler (lt)

16

Hz

50/60

Hz

50/60

Hz

50/60

Hz

50/60

Hz

50/60

Standard

On demand

not for 1 or 2 group compact
