Radio Shack TV ANTENNA User Manual

15-183 9.fm Page 1 Friday, July 16, 1999 9:21 AM
OWNER’S MANUAL
Please read before using this equipment.
AMPLIFIED PLUG²IN
TV ANTENNA
Cat. No. 15-1839
15-183 9.fm Page 2 Friday, July 16, 1999 9:21 AM
Warning: To prevent fire or shock hazard, do not ex­pose this antenna to rai n or moisture
.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
!
CAUTION
ELECTRIC SHOCK, DO NOT REMOVE COVER OR BACK. NO USER -SERVICE­ABLE PARTS INSIDE. REFER SERVIC­ING TO QUALIFIED PERSONNEL.
!
: TO REDUCE THE RISK OF
This sy mbol is in t en ded t o al ert yo u to t he pres ­ence of un insulated da ngerous vo ltage within the antenna’s enclosure that might be of suffi­cient magnitud e to constitute a risk of elec tric shock. Do not open the antenna’s case .
This sy mbol is intended to infor m you that im­portant operat ing an d mainte nance instru ctio ns are incl ud ed in the li t era tu re a cco mp an ying th is antenn a.
©
1995 Tandy Corporation.
All Rights Reserved.
Radio Shack is a registered trademark
used by Tandy Corporati on.
2
15-183 9.fm Page 3 Friday, July 16, 1999 9:21 AM
FEATURES
Your Amplified Plug-In TV Antenna is a portable an­tenna designed to eliminate the need for an outdoor or indoor (rabbit -ears ) antenn a. Th e device us es your house’s AC wiring as an antenna to receive local broadcasts on TV Channels 2-69 and all FM radio stations.
It includes th ese features:
Built-In Amplifier
to enhance your TV’s or VCR’s video reception or your FM receiver’s stereo reception.
Gold-Plated F-Connector
nal connection between the antenna and your TV/ VCR/FM receiver.
Convenient AC Outlet
power your TV/VCR/FM receiver.
Power Indicator
the antenna’s built-in amplifier.
— boosts th e received signal level
— insur e s a low -l oss sig -
— provides an AC outlet to
— lights when power is supplied to
3
15-183 9.fm Page 4 Friday, July 16, 1999 9:21 AM
SAFETY
INSTRUCTIONS
Please read all of these instructions and keep them for future reference.
Follow all warnings and instructions on the unit as well as in the operating instructions.
1. Water and Moistur e: FOR INDOOR USE ONLY — Do not use the plug-in antenna near water or moisture — for example, near a bathtub, sink, in a wet basement, etc.
2. Heat: Do not place near sources of heat — for example, radia tors, heaters, etc.
3. Power Sources: You should opera te this plug-in antenna only from a standard 120V AC, 60 Hz power source, as indicated on the m arking label.
4. Grounding or Polarization: This plug-in antenna is equipped with a safety, 3-prong grounding plug, designed to fit only into a grounded power outlet. If you are unable to insert the plug into the outlet, contact your elec­trician to replace your old outlet. Do not defeat the safety purp ose of the grounding plug.
4
15-183 9.fm Page 5 Friday, July 16, 1999 9:21 AM
5. Lightning: For added protection, unplug the plug-in anten na from the outlet duri ng a lightning storm or when leaving it unattended or unused for long periods of time.
6. Servicing: Unplug this product from the outlet and refer serv icing to qualifi ed service personnel when:
• The unit has been exposed to rain or mois-
ture.
• The unit has been dropped or the enclosure
is damaged.
• The unit does not appear to operate normally,
or exhibits a marked change in performance.
7. Cleaning: Before cleaning the plug-in antenna, unplug it from the wall outlet . Do not use liqui d or aerosol cleaner s. Use a damp cloth for cleaning.
8. Replacement Parts: When the plug-in antenna requires replacement of parts, be sure the ser­vice technician uses only approved replacement parts. Unauthorized substitutions could result in fire, electric shock, or other haza rds.
9. Overloading: Do not overload wall outlets, extension cords, or integral convenience recep­tacles as thi s can result in a risk of fir e or electric shock.
5
15-183 9.fm Page 6 Friday, July 16, 1999 9:21 AM
OPERATION
1. Plug the plug-in antenna into a standar d AC out­let. The red LED lights to indicate that the inter­nal amplifier has power.
2. Connect a coaxial cable (RG-6 or RG-59, not supplied) between your TV/VCR/FM receiver’s antenna input jack and the F-Connector output jack at the base of the plug-in antenna. Your local Radio Shack store has a wide selec­tion of coaxial cables.Plug your TV/VCR/FM receiver’s AC power cord into the plug-in antenna’s AC outlet.
Note
:
6
15-183 9.fm Page 7 Friday, July 16, 1999 9:21 AM
CARE AND MAINTENANCE
Your Amplified FM/VHF/UHF Plug-In Antenna is an example of superior design and craftsmanship. The following suggestions will help you care for your an­tenna so you can enjoy it fo r years.
Keep the antenna dry. If it gets wet, wipe it dry immediately. Liquids might contain minerals that can cor­rode the electronic circuits.
Handle the antenna gent ly and care­fully. Dropping it can damage circuit boards and cases and can cause the antenna to work imprope rl y.
Use and store the antenna only in normal temperature environments. Temperature extremes can shorten the life of electronic devices and dis­tort or melt pl astic parts.
Keep the antenna away from dust and dirt, which can cause premature wear of parts.
7
15-183 9.fm Page 8 Friday, July 16, 1999 9:21 AM
Wipe the antenna with a damp cloth
CLEANER
occasionally to keep it looking new. Do not use harsh chemicals, clean­ing solvents, or strong detergents to clean the antenna.
Modifying or tampering with the antenna’s internal components c an cause a mal function and might i nval­idate your antenna’s warranty. If your antenna is not performing as it should, take it to your local Radio Shack store for assistance.
8
15-183 9.fm Page 9 Friday, July 16, 1999 9:21 AM
SPECIFICATIONS
Connections:
AC Input .....................Non-Polarized AC Blades
Straight, with Ground Pin
(NEMA 5-15P configuration)
AC Output..................Polarized AC Receptacles
Straight, with Ground Pin
(NEMA 5-15R configuration)
Antenna Output........... .. .......... .. .. ..........75-Ohm
Gold-Plated, F-Connector
AC Input:
Voltage ..........................................105-135 VAC
Current
Frequency ....... ............ ............ .. ...........50-60 Hz
AC Output:
Voltage ..........................................105-135 VAC
Current ..................................... 15 A (maximum)
Frequency ....... ............ .. ............ .. .........50-60 Hz
......................................<
40 mA (typical)
9
15-183 9.fm Page 10 Fr iday, July 16, 1999 9:21 AM
Antenna Signal Amplification:
(VHF/FM) .....................................20 dB (typical)
(UHF bands).................................10 dB (typical)
Amplifier Power On Display......................... Red LED
Dimens io ns (HWD ) . ...............4
3
/4 ¥ 23/8 ¥ 23/4 inches
(121
60 ¥ 70 mm)
¥
(Incl. AC plug and F-Connector)
Weight ..... ... ......................................................7.9 oz
(224 g)
Specifications are typical; individual units might vary. Specifications are subject to change and improve­ment without notice.
10
15-183 9.fm Page 11 Fr iday, July 16, 1999 9:21 AM
NOTES
11
g
15-183 9.fm Page 12 Fr iday, July 16, 1999 9:21 AM
RADIO SHACK LIMITED WARRANTY
This product is warranted against defects for 90 days from date of purchase from Radio Shack company-owned stores and authorized Radio Shack franchisees and dealers. Within this period, we will repair it without charge for parts and labor. Simply bring your Radio S hack s ales slip as proof of purch as e date to an y R a dio S h ac k s t o re. Wa rr a nty does not cover transportation costs. Nor does it cover a produc t subjected to misuse or accidental damage. EXCEPT AS PROVIDED HEREIN, RADIO SHACK MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED HEREIN. Some states do not permit l im ita tion or ex clus ion of imp lied wa rra nties ; t here fo re, th e afor es aid limitation(s ) or exclusion(s) may not apply to the purchaser.
This warranty gives you specific legal rights and you may also have other ri
hts which vary from state to state.
We Service What We Sell
9/94
A Division of Tandy Corporation
RADIO SHACK
Fort Worth, Texas 76102
11/95 Printed in the USA
