43-3601.fm Page 1 Monday, April 10, 2000 5:53 PM
ET-3601
20 Number One-Touch Memory
Home/Office Speakerphone
Owner’s Manual
Please read before using this equipment.
43-3601.fm Page 2 Monday, April 10, 2000 5:53 PM
ˆ
Contents
Features ................................................................................................................... 3
FCC Statement ................................................................................................... 3
Preparation .......................................................................................................... .... 4
Selecting a Location ........................................................................................... 4
On a Desk Top ............................................................................................. 4
On a Wall Plate or Wall ................................................................................ 4
Connecting the Handset ..................................................................................... 5
Connecting an Optional AC Adapter .................................................................. 5
Setting the Ringer ............................................................................................... 6
Setting the Dialing Mode .................................................................................... 6
Setting the Volume ............................................................................................. 6
Operation ................................................................................................................. 7
Using the Speakerphone .................................................................................... 7
Switching Between the Handset and Speakerphone ................................... 7
Using a Headset ................................................................................................. 8
Using Privacy ...................................................................................................... 8
Using Redial ....................................................................................................... 8
Using Flash ......................................................................................................... 8
Using Interoffice Signals ..................................................................................... 8
Using Pause ....................................................................................................... 9
Using Special Tone Services .............................................................................. 9
Memory Dialing ................................................................................................... 9
Chain-Dialing Service Numbers ...................................... ............................. 9
Troubleshooting .................................................................. .................................. 10
Care and Maintenance .......................................................................................... 10
The FCC Wants You to Know ........................................................................... 10
Lightning ...................... ................................................................ ..................... 11
©
2000 Tandy Corporation.
RadioShack and RadioShack.com are trademarks used by Tandy Corporation.
2
All Rights Reserved.
Contents
43-3601.fm Page 3 Monday, April 10, 2000 5:53 PM
ˆ
Features
Your RadioShack 20 Number OneTouch Memory Home/Office Speakerphone lets you store frequently called
telephone numbers in memory so you
can call any stored nu mber. Its features
include:
Built-in Speakerphone
hands-free operation.
Headset J ack
al headset to make or receive calls.
Privacy
the speakerphone and handset microphone.
Adjustable Ringer and Receiver Volume
— lets you adjust the ringer and re-
ceiver’s volume to the desired level.
Hearing-Aid Compatibility
you to use your telephone with a hearing
aid that is equipped with a telephone
switch.
Your telephone is ETL li sted and meets
all applicable FCC standards.
— lets you use an option-
— lets you temporarily turn off
— gives you
— allows
FCC STATEMENT
We have designed your telephone to
conform to federal regu lations, and you
can connect it to most teleph one lines.
However, each device that y ou connect
to the telephone line draws power from
the line. We refer to this power draw as
the phone’s ringer equivalence number
(REN). The REN is on the bottom of
your phone.
If you use more than one phone or other
device on the line, add up all the RENs.
If the total is more than fiv e (three in rural areas), your phone might not ring.
The ringer operation is impaired, remove one of the devices from the line.
Your telephone c ompli es with Par t 68 o f
FCC Rules
provide the FCC registration numbers
and the REN to your te lephone company. Both numbers are shown on the bottom of the telephone.
Note:
phone to:
, you must, upon request,
You must not connect your tele-
• coin-operated systems
• party-line systems
• most electronic key telephone systems
3Features
43-3601.fm Page 4 Monday, April 10, 2000 5:53 PM
ˆ
Preparation
SELECTING A LOCATION
You can place your telephone on a
shelf, desk or table, or mount it on a
wall. Select a location that is:
• Near an accessible telephone jack
• Not in the way of no rm al activ i tie s in
the area
On a Desk Top
Use the supplied mo unting bracke t as a
stand when you place the base on a
desk, shelf, or table.
1. Insert the two smaller tabs on the
mounting bracket in to the matching
slots near the keyhole slot on the
bottom of the phone’s base. Then
press down on the bracket until its
two larger tabs snap into place.
2. Plug one end of the supplied long
modular cord into the
the back of the base.
3. Plug the modular cord’s other end
into a modular phone line jack.
LINE
LINE Jack
jack on
On a Wall Plate or Wall
1. Insert the two smaller tabs on the
mounting bracket into the matching
slots near the center bottom of the
phone’s base. Then press down on
the bracket until its two larger tabs
snap into pl ace.
2. Plug one end of the supplied short
modular cord into the
the back of the base as in “On a
Desk Top,” Step 2.
4
Preparation
LINE
jack on
43-3601.fm Page 5 Monday, April 10, 2000 5:53 PM
3. Plug the modular cord’s other end
into the wall plate jack, then align
the base’s keyhole slots with the
wall plate studs and slide the base
downward to secure it.
4. Press and lift out
the handset hold er, rotate it 180°,
then snap it back
into place so it
holds the handset.
2. Plug one end of the supplied long
modular cord into the
LINE
jack on
the back of the base.
3. Align the base’s keyhole slots with
the mounting screws and slide the
base downward to secure it.
315/
16
Inches
5
/16
Inches
CONNECTING THE
HANDSET
Plug one end of the coiled cord into the
modular jack on the handset. Then connect it to the jack on the left side of th e
telephone’s base.
Note:
To mount the phone di rectly on a
wall, you need two screws (not supplied)
with heads that fit i nto the keyhole slots
on the bottom of the base.
Follow the steps under “O n a Wall Plate
or Wall,” then apply these additional instructions for placement on a wall.
1. Drill two holes 3
15
/16 inches (100
mm) apart. Then thread a screw into
each hole, letting the h eads extend
5
about
/16 inch (8 mm) from the wall.
Note:
Your local RadioSha ck s tore sel ls
a variety of l onger coiled hands et c ords,
which are especially useful when you
mount the phone on a wall.
CONNECTING AN
OPTIONAL AC ADAPTER
Your telephone operates from telephone
line power. In some areas, however, the
telephone line migh t not provide enough
power to operate all of your telephone’s
features. If the speakerphone’s volume
is too low, even with the volume control
set to its highest leve l, or if the speaker phone does not work, you need to connect the supplied AC adapter.
5Preparation
43-3601.fm Page 6 Monday, April 10, 2000 5:53 PM
Cautions:
You must use a Class 2
power source that su pplies
!
9V DC and delivers at least
200 mA. Its center tip must be set to
positive and its plug must fit the telephone's
DC 9V
jack. The supplied
adapter meets these specifications.
Using an adapter that does not meet
these specifications could damage
the telephone or the adapter.
• Always connect the AC adapter to
the telephone befor e you connect it
to AC power. When you finish, disconnect the adapt er from AC power
before you disconnect it from the
telephone.
Plug the barrel plug of the supplied
adapter into the
DC 9V
jack on the back
of the telephone. Plug the othe r e nd into
the AC outlet.
DC 9V Jack
SETTING THE DIALING
MODE
T/P
Set
vice you have. If y ou are not s ure which
type you have, do this simple test.
(Tone/Pulse) for the type of ser-
1. Set
T/P
to T. Lift the hands et an d lis -
ten for a dial tone.
2. Press any n umber except
0
. If your
phone requires that you dial an
access code (9, for exampl e) bef ore
you dial an outside numbe r, do not
press the access code number
either.
3. If the dial tone stops, you have
touch-tone servic e. Leave
T
.
T/P
set to
If the dial tone continues, you have
pulse service. Se t
RECEIVER VOL
T/P
to P.
SETTING THE RINGER
If you do not want to hear the phone
ring, set
RINGER
make calls with the ringer off, and you
can answer calls if you hear another
phone on the same phone line ring.
If you want to hear the p hone ring, set
RINGER
LO
6
to the desired volume (HI or
).
to
OFF
. You can still
Preparation
SPEAKER VOL
T/P
RINGER
SETTING THE VOLUME
RECEIVER VOL
Slide
(medium), or HI (high) as desired.
SPEAKER VOL
Slide
as desired.
to LO (low),
to set the volume
MED
43-3601.fm Page 7 Monday, April 10, 2000 5:53 PM
ˆ
Operation
PAUSE
Memory Buttons
(Use the memory
index card to
record numbers.)
STORE
REDIAL
To dial a number manually, lift the handset and enter the telephone number as
usual.
USING THE
SPEAKERPHONE
To use the built-in speakerphone instead of the handset at any time, pr ess
SPEAKERPHONE
PHONE indicator lights.
SPEAKERPHONE
Press
nect the telephone line.
. The SPEAKER-
again to discon-
FLASH
SPEAKERPHONE
PRIVACY
Switching Between the
Handset and Speakerphone
To switch from the handset to the
speakerphone, press
then return the handset to the cradle.
To switch from the sp eakerphone to the
handset, just lift the handset.
To switch from the sp eakerphone to the
handset during redialing or memory dialing, let the number complete ly dial, then
lift the handset.
To switch from the handset to the
speakerphone durin g redialing or memory dialing, let the number completely
SPEAKERPHONE
,
7Operation
43-3601.fm Page 8 Monday, April 10, 2000 5:53 PM
dial, then press
return the handset to the cradle.
SPEAKERPHONE
and
USING A HEADSET
For hands-free convenience, you can
connect an optional headset with a
inch (2.5 mm) plug to the telephone.
Contact your local Rad ioShack s tore for
a suitable headset.
With the handset off the hook, plug the
headset's cord into the
on the left side of the telephone.
HEADSET Jack
To switch from the heads et to the hand set, unplug the headset cord from the
telephone, replace the handset on the
cradle, then pick up the handset to make
or receive a call.
HEADSET
3
/32-
jack
USING PRIVACY
USING REDIAL
You can quickly redial the last number
dialed by pressing
hear a dial tone. The redial number is replaced each time you dial a new number.
Note:
If you press
number, only the digits preceding
FLASH
are stored in redial memory.
REDIAL
FLASH
while you
while dialing a
USING FLASH
Many special telephone services, such
as Call Waiting, require a switchhook
signal.
equivalent of a switchhook operation.
For example, if you have Call Waiting,
you can put a call on hold and take a
second incoming call on the same line
by pressing
Neither the flash entry nor any digits you
dial after you press
redial memory. Howev er, you can store
a flash entry within a memory dialing sequence as the first di git. The flash entry
counts as one digit in memory.
FLASH
provides the electronic
FLASH
.
FLASH
are stored in
To temporarily disconnect the speakerphone or handset without ending the call
(so you can talk privately wi th someone
in the room), press
VACY indicator lights an d the person on
the other end of the phone line cannot
hear you.
To resume your call, press
again. The PRIVACY indicator goes off.
You can also use the privacy feature
with the handset microphone.
8
PRIVACY
. The PRI-
PRIVACY
Operation
Note:
If you do not have any special
phone services, pressing
disconnect the curren t call .
FLASH
might
USING INTEROFFICE
SIGNALS
Some interoffice telephone systems provide special services that require a
switchhook signal. For example, a single
switchhook signal followed by an ext ension can transfer a call from one office to
another inside th e office telephone network.
43-3601.fm Page 9 Monday, April 10, 2000 5:53 PM
You can store a single switchhook signal
in memory at t he begin ning of a n ex tension. Then, when a call c omes in as king
for the person at that extension, you can
transfer the call with the push of a single
button.
USING PAUSE
In some telephone systems, you must
dial an access code (9, for example) and
wait for a second dial tone before dialing
an outside number. Whe n you manua lly
dial a number, or when you store a number in memory, you c an have your telephone pause anywhere during the
dialing sequence. Simply press
at the desired location.
When you redial or memory dial a number, the telephone pause s for about 3.6
seconds at the pa uses en try. For lo nger
pauses, press
Each pause entry coun ts as one digit in
memory.
PAUSE
more than once.
PAUSE
USING SPECIAL TONE
SERVICES
Some computer serv ices, such as alternate long-distance and bank-by-phone,
require tone signals for communications.
If you have pulse service, you can still
use these special tone services by following these steps.
1. Connect to the special service using
pulse dialing.
MEMORY DIALING
The telephone ca n st o re up to 20 phone
numbers in memo ry. Follow the se st eps
to store a number in memory.
1. With the handset off hook or the
speakerphone on, press
2. Enter the telephone number, then
STORE
press
3. Press the desired memory location
button.
4. Use a pointed object, such as a
straightened paper clip, to pry up
the plastic cover from over the
memory index c ard. Write the number you stored next to the memory
location button, then replace the
plastic cover.
To dial a stored number, press the
memory location button for the number.
.
Chain-Dialing Service Numbers
For quick recall of numbers for special
services (such as bank by phone), st ore
each group of numbers in it s own memory location.
Dial the service’s main number first.
Then, at the appropriate place in the
call, press the memory location button
for the location whe re the additional information is stored.
STORE
.
2. When the special service answers,
T/P
set
3. When you complete the call, hang
up the handset and set
P
to T.
T/P
back to
.
9Operation
43-3601.fm Page 10 Monday, April 10, 2000 5:53 PM
ˆ
Troubleshooting
If your telephone i s not operating properly, check these items:
• Is the phone properly connected?
T/P
•Is
• This phone might n ot operate when
ˆ
To enjoy your telephone for a long time:
• Keep the telephone dry. If it gets
• Use and store the telephone only in
• Handle the telephone gently and
• Keep the telephone away from dust
• Wipe the telephone with a damp
Modifying or tampering with the telephone’s internal com ponents can cause
a malfunction an d invalidate its warr anty. If your telephone is not performing as
it should, take it to your local RadioShack store for assistance. If the
set correctly?
another phone is in use on the same
line (especially in areas with low
telephone voltage). If the telephone’s volume drops or you hear
unusual sounds, check to see if
another phone on the same line is
Care and Maintenance
wet, wipe it dry immediately.
normal temperature environ men ts .
carefully. Don’t drop it.
and dirt.
cloth occasionall y to keep it lookin g
new.
off hook. Hang up the other phones
to correct the problem.
• When the party on the phone cannot
hear you, but you can hear them,
check the PRIVACY indicator. If the
light is on, pre ss
If you still have problems, disconnect the
phone. If other phones on th e same lin e
work properly, th e fault is in this phone
or its installati on. If you cannot find the
problem, take your phone to your local
RadioShack store for assistance.
trouble is affecting the telephone lines,
the phone company can ask y ou to disconnect your telephone until you have
resolved the problem.
PRIV ACY
so it is off.
THE FCC WANTS YOU TO
KNOW
In the unlikely event that your telep hone
causes problems on the tel ephone line,
the telephone compan y can disconnect
your service. The telephone company
attempts to notify you in advance. If advance notice is not practical, the telephone company notifi es you as soo n as
possible and advises you of your right to
file a complaint with FCC.
Also, the telephone com pany can make
changes to its li nes, equipment, operations, or procedures that could affect the
operation of this telephone. The tele-
10
Troubleshooting
43-3601.fm Page 11 Monday, April 10, 2000 5:53 PM
phone company notifies you of these
changes in advance, so that you can
take the necessary steps to prevent interruption of your telephone service.
LIGHTNING
Your telephone has built- in protection
circuits to reduce the risk of damage
from surges in (telephone and power)
line current. These protection circuits
meet or exceed th e FCC requirements.
However, lightning striking the telephone or power lines can d amage your
telephone.
Lightning damage i s not common. Nevertheless, if you li ve in an area that has
frequent electrical storms, we suggest
that you unplug your telephone during
storms to reduce the possibilit y of damage.
11Care and Maintenance
43-3601.fm Page 12 Monday, April 10, 2000 5:53 PM
Limited One-Year Warranty
This product is warrante d by RadioSha ck against manufac turing defect s in material and wor kmanship under normal use for one (1) year from the date of purchase from RadioShack company-owned
stores and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED HEREIN, RadioShack MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING
THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED
IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED
HEREIN. EXCEPT AS PROVIDED HEREIN, RadioShack SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO CUSTOMER OR ANY OTHER PERSON OR ENTITY WI TH RESPECT TO ANY
LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUDING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM INCONVENIENCE, LOSS
OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT OR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, EVEN IF RadioShack HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to
you.
In the event of a pr oduct defect durin g the warranty pe riod, take the pro duct and the RadioShack
sales receipt as proof of purchase date to any RadioShack store. RadioShack will, at its option, unless otherwise provid ed by law: (a) correct the def ect by product repair wi tho ut c har ge for pa rts a nd
labor; (b) replace the product wi th one of the same or similar design; or (c) refund the purch ase
price. All replace d parts a nd prod ucts, and p roducts o n which a refund is made, become th e property of RadioShack. New or recond itioned parts a nd products may be used in the performance of
warranty service. Re paired or replace d parts and pro ducts are warran ted for the rem ainder of the
original warranty period. You will be charged for repair or replacement of the product made after the
expiration of the warranty period.
This warranty does not cover: (a) damage or failure caused by or attributable to acts of God, abuse,
accident, misuse, i mproper or abnormal usag e, fa ilu re to fo ll ow instr ucti o ns, imp rop er installation or
maintenance, altera tion, lightning or othe r incidence of excess voltage or current; (b ) any repairs
other than those provided by a RadioShack Authorized Service Facility; ( c) consumables such as
fuses or batteries; (d) cosmetic dam age; (e) tra nsportation , shipping or insurance costs; or (f) costs
of product removal, installation, set-up service adjustment or reinstallation.
This warranty give s you specific l egal rights, an d you may al so have other r ights which var y from
state to state.
RadioShack Customer Relations, 200 Taylor Street, 6th Floor, Fort Worth, TX 76102
We Service Wh at We Sell
12/99
RadioShack
A Division of Tandy Corporation
Fort Worth, Texas 76102
43-3601
03A00
Printed in China
Loading...
