43-3536.fm Page 1 Wednesday, March 20, 2002 12:14 PM
406")*\"%QTFNGUU"6GNGRJQPG
YKVJ"*GCFUGV",CEM
43-3536
10-Number Memory Dialing
— lets you store up to 10
numbers (1 one-touch and 9 speed-dial) in memory for
easy dialing.
20 Channels
— you can automatically select a clear
channel when you make or answer a call, or you can
manually change channels.
Ample Talk and Standby Time
— the supplied battery
(when fully charged) provides about 7 hours of talk time or
14 days of standby time.
— lets you send a paging signal from the base to
Page
the handset to page someone or locate the handset.
Quick Talk
— lets you set the phone to answer a call by
simply lifting the handset from the base.
"+/2146#06"
#
If an icon appears at the end of a paragraph, go to the
box on that page with the corresponding icon for pertinent
information.
Rý
—
Warning
°°°°
—
Important .
#
—
Hint
#
±
—
.
..
Note
—
Caution
Please read before using this equipment.
RadioShack and RadioShack.com are trademarks used by RadioShack Corporation.
NERGYSTAR
E
and the E
OWNER’S MANUAL
2002 RadioShack Corporation.
©
All Rights Reserved.
NERGYSTAR
certification mark are registered US marks.
43-3536.fm Page 2 Wednesday, March 20, 2002 12:14 PM
Important Safety Instructions
%106'065
Introduction ................................ 4
Installation .................................. 4
Connecting and Charging the
Battery Pack ............................ 5
Setting the Ringer Tone .......... 6
Setting the Dialing Mode ......... 6
Operation ................................... 7
Making and Receiving Calls .... 7
Selecting the Channel ............. 7
Adjusting the Handset’s
Volume .................................... 7
Using Redial ............................ 7
Using Flash ............................. 7
Using Tone Services on a Pulse
Line ......................................... 8
Paging ..................................... 8
Using a Headset ..................... 8
Memory Dialing ....................... 8
Troubleshooting ....................... 10
Care .......................................... 11
Service and Repair .................... 11
Important Information ................ 11
FCC Statement ......................... 11
Lightning ............................... 12
To reduce the risk of fire or shock hazard, do
WARNING:
not expose this product to rain or moisture.
CAUTION
..
RISK OF ELECTRIC SHOCK
TO REDUCE THE RISK OF ELECTRIC SHOCK,
CAUTION:
DO NOT REMOVE COVER OR BACK. NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED PERSONNEL.
The lightning symbol is intended to alert you to the
presence of uninsulated dangerous voltage within this
product’s enclosure that might be of sufficient
magnitude to constitute a risk of electric shock. Do not
open the product’s case.
The exclamation symbol is intended to inform you that
important operating and maintenance instructions are
included in the literature acco mpanying this product.
!
NERGYSTAR
As an E
dioShack Corporation has determined that this product meets the
NERGYSTAR
E
gy efficiency.
guidelines for ener-
..
DO NOT OPEN
Partner, Ra-
+/2146#06"5#('6;"
+05647%6+105
When using your telephone equipment, basic safety
precautions should always be followed to reduce the risk of
fire, electric shock and injury to persons, including the
following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the
product.
3. Never install telephone wiring during a lightning storm.
4. Never install telephone jacks in wet locations unless
the jack is specifically designed for wet locations.
5. Never touch uninstalled telephone wires or terminals
unless the telephone line has been disconnected at the
network interface.
6. Use caution when installing or modifying telephone lines.
7. Do not fix the AC power supply cord to building surfaces
with metal fittings (if the product has an AC power cord).
8. Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
9. Do not use this product near water, for example, near a
!
bathtub, wash bowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool.
10. Do not place this product on an unstable cart, stand, or
table. The product may fall, causing serious damage to
the product.
11. Slots and openings in the cabinet and the back or bottom
are provided for ventilation. T o protect it from overheating,
these openings must not be blocked or covered. The
openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface. This
product should never be placed near or over a radiator
or heat register. This product should not be p laced in a
built-in installation unless proper ventilation is provided.
12. This product should be operated only from the type of
power source indicated on the marking label. If you are
not sure of the type of power supply to your home,
consult your local power company.
13. Do not allow anything to rest on the power cord. Do not
locate this product where the cord will be stepped on.
2
43-3536.fm Page 3 Wednesday, March 20, 2002 12:14 PM
14. Do not overload wall outlets and extension cords as this
can result in a risk of fire or electric shock.
15. Never push objects of any kind into this product through
cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a risk of fire
or electric shock. Never spill liquid of any kind on the
product.
16. T o reduce the risk of electric shock, do not disassemble
this product. Ta ke it to a qualified service technician
when service or repair work is required. Opening or
removing covers may expose you to dangerous voltage
or other risks. Incorrect reassembly can cause electric
shock when the product is subsequently used.
17. Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
• When the power cord plug is damaged or frayed.
• If liquid has been spilled, into the product.
• If the product has been exposed to rain or water.
• If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are covered by the operating instructions
because improper adjustment of other controls may
re-sult in damage and will often require extensive
work by a qualified technician to restore the product
to normal operation.
• If the product has been dropped or the cabinet has
been damaged.
• If the product exhibits a distinct change in performance.
Important Safety Instructions
18. Avoid using a telephone (other than a cordless type)
during an electrical storm. There may be a remote risk
of electric shock from lightning.
19. Do not use the telephone to report a gas leak in the
vicinity of the leak.
$#66'4;"5#('6;"+05647%6+105"
1. Use only the appropriate type and size battery pack
specified in the instruction manual provided for this
product.
2. Do not dispose of the battery pack in a fire. The cell
may explode. Check with local codes for possible
special disposal instructions.
....
.
"%#76+10"
To reduce the risk of fire or injury,
read and follow these instructions.
.
3
43-3536.fm Page 4 Wednesday, March 20, 2002 12:14 PM
"+/2146#06"
#
• Cordless phones such as this
one require AC power to
operate. When the power is off,
you cannot make or receive
calls using your phone. To be
safe, you should also have a
phone that does not need AC
power to operate (not a cordless phone), so you can still
make and receive calls if there
is an AC power failure.
• When AC power is lost, the
phone loses the security
access-protection code connection between the base and
Introduction
the handset. When power is
restored, put the handset on
the base briefly to restore this
connection so you can use the
handset.
• Your phone operates on
standard radio frequencies as
allocated by the FCC. It is
possible for other radio units
operating nearby on similar
frequencies to unintentionally
intercept your conversation or
cause interference. This
possible lack of privacy can
occur with any cordless phone.
#
3. Do not open or mutilate the battery pack. Released
electrolyte is corrosive and may cause damage to the
eyes or skin. It may be toxic if swallowed.
4. Exercise care in handling the battery pack in order not
to short it with conducting materials such as rings,
bracelets, and keys. The battery or conductor may
overheat and cause burns.
5. Charge the battery pack provided or identified for use
with this product only in accordance with the
instructions and limitations specified in the instruction
manual provided for this product.
6. Observe proper polarity orientation between the battery
pack and battery charger.
5#8'"6*'5'"
+05647%6+105
+0641&7%6+10
Thank you for purchasing a RadioShack 2.4 GHz Cordless
Telephone. Your phone uses the 2.4 GHz band for less
interference and greater range than many other cordless
telephones. Its headset jack lets you connect an optional
headset for hands-free convenience.
#"
.
"%#76+10"
You must use a Class
2 power source that
!
supplies 9V DC and
delivers at least 210 mA. Its
center tip must be set to
positive and its plug must fit the
phone's
supplied adapter meets these
specifications. Using an adapter
that does not meet these
specifications could damage the
phone or the adapter.
• Always connect the AC adapter
to the phone before you
connect it to AC power. When
you finish, disconnect the
adapter from AC power before
you disconnect it from the
phone.
DC IN 9V
.
jack. The
4
+056#..#6+10
You can place the phone on a desk or table, or mount it on a
standard wall plate or directly on a wal l . Sel e ct a loca ti on
that is:
• near an accessible AC outlet
• near a telephone line jack
• out of the way of normal activities
• away from electrical machinery, electrical appliances,
metal walls or filing cabinets, wireless intercoms,
alarms, and room monitors
• away from other cordless phones
The base’s location affects the handset’s range. If you have
a choice of several locations, try each to see which provides
the best performance.
....
