Radio Shack 15-248 User Manual

Thank you for purchasing your Picture Frame
Indoor HDTV Antenna from RadioShack. Please
read this user’s guide before installing, setting
up, and using your new Frame Antenna.

Picture Frame Indoor HDTV Antenna

User’s Guide 15-248

2

Package contents

• Frame Antenna • User’s Guide

• Quick Start

Features

• Receive HDTV, VHF, UHF, HD Radio
signals, and FM radio signals.

• Adjustable VHF dipoles with built-in
UHF loop.

1 Put a picture in the frame

1. Press the locking tabs on the four
corners to remove the frame cover.

2. Place your 4” x 6” photo in the frame.

3. Replace the frame cover.

2 Install your antenna

1. Place the antenna on or near your TV
set or FM receiver.

2. Connect the antenna cable’s F-
connector to the input terminal on your
TV or FM receiver.

3

3. Adjust the length and position of the

antenna rods and rotate the antenna
base to get the best reception.

n Note: Do not place the antenna

near metal objects such as cabinets,
bookshelves, refrigerators, doors, walls, or
water pipes inside a wall. This can greatly
reduce the antenna’s ability to receive
signals.

Specifications

Frequency range................. .........FM: 88-108 MHz

...................................................UHF: 470-806 MHz

........................................VHF: 54-88, 174-216 MHz

Output Impedance........................... .........75 Ohm

Specifications are subject to change and
improvement without notice. Actual product may
vary from the images found in this document.

4

HD Radio broadcasting in VHF:
To improve reception, extend
both rods about two segments
straight up

F-connector cable

Connect to TV/ FM
receiver input terminal

Locking tabs (4)

Press to open/
close frame cover

FM radio: swivel both
rods up to 360º to
improve reception

5

Care and Service

• Keep the antenna dry; if it gets wet,
wipe it dry immediately. Handle the
antenna carefully; do not drop it.

• Use and store the antenna only in
normal temperature environments.

• Keep the antenna away from dust and
dirt, and wipe it with a damp cloth
occasionally to keep it looking new.

• Modifying or tampering with the
antenna’s internal components can
cause a malfunction and might
invalidate its warranty. If your antenna
is not performing as it should, take
it to your local

RadioShack store for

assistance.

• If your receiver has a 300-ohm twin­lead connector, you need an adapter
(available from your local

RadioShack

store or

www.RadioShack.com). Screw
the adapter onto the antenna cable,
then tighten and secure the adapter’s
lead to the terminal on your TV or FM
receiver.

6

Limited Warranty

RadioShack warrants this product against defects in materials and
workmanship under normal use by the original purchaser for

ninety (90)

days after the date of purchase from a RadioShack-owned store or an

authorized

RadioShack franchisee or dealer. RADIOSHACK MAKES NO

OTHER EXPRESS WARRANTIES.
This warranty does not cover: (a) damage or failure caused by or

attributable to abuse, misuse, failure to follow instructions, improper
installation or maintenance, alteration, accident, Acts of God (such
as floods or lightning), or excess voltage or current; (b) improper or
incorrectly performed repairs by persons who are not a

RadioShack
Authorized Service Facility; (c) consumables such as fuses or batteries; (d)
ordinary wear and tear or cosmetic damage; (e) transportation, shipping
or insurance costs; (f) costs of product removal, installation, set-up service,
adjustment or reinstallation; and (g) claims by persons other than the
original purchaser.

Should a problem occur that is covered by this warranty, take the
product and the

RadioShack sales receipt as proof of purchase date to

any

RadioShack store in the U.S. RadioShack will, at its option, unless
otherwise provided by law: (a) repair the product without charge for
parts and labor; (b) replace the product with the same or a comparable
product; or (c) refund the purchase price. All replaced parts and products,
and products on which a refund is made, become the property of
RadioShack. New or reconditioned parts and products may be used
in the performance of warranty service. Repaired or replaced parts and
products are warranted for the remainder of the original warranty period.
You will be charged for repair or replacement of the product made after
the expiration of the warranty period.

RADIOSHACK EXPRESSLY DISCLAIMS ALL WARRANTIES AND CONDI­TIONS NOT STATED IN THIS LIMITED WARRANTY. ANY IMPLIED WAR

­RANTIES THAT MAY BE IMPOSED BY LAW, INCLUDING THE IMPLIED
WARRANTY OF MERCHANTABILITY AND, IF APPLICABLE, THE IMPLIED
WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE, SHALL EXPIRE
ON THE EXPIRATION OF THE STATED WARRANTY PERIOD.

EXCEPT AS DESCRIBED ABOVE,

RADIOSHACK SHALL HAVE NO
LIABILITY OR RESPONSIBILITY TO THE PURCHASER OF THE PRODUCT
OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO ANY
LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY
USE OR PERFORMANCE OF THE PRODUCT OR ARISING OUT OF
ANY BREACH OF THIS WARRANTY, INCLUDING, BUT NOT LIMITED

7

TO, ANY DAMAGES RESULTING FROM INCONVENIENCE AND ANY
LOSS OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT AND ANY
INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES,
EVEN IF

RADIOSHACK HAS BEEN ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES.
Some States do not allow limitations on how long an implied warranty

lasts or the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other
rights which vary from State to State. You may contact

RadioShack at:

RadioShack Customer Relations

300 RadioShack Circle, Fort Worth, TX 76102 04/08

www.RadioShack.com

Printed

in China

08A09

15-248 A

AO0389AAA1

Patent Pending
©2009.

RadioShack Corporation.
All rights reserved. RadioShack and RadioShack.com are
trademarks used by RadioShack Corporation.

Protect the environment by recycling used electronics.
Go to E-CyclingCentral.com to find an electronic
recycling center near you.
