Radio Shack 1500044T Users manual

T H E PERFO R M A N C E Y O U N E E D
®
®
Quick Start 1500044
See the User’s Guide for complete instructions.
Wireless Speaker Kit
Package contents
Transmitter
Receiver
2
Connect the Receiver
9V AC Adapter
6-foot Speaker Wires
15V AC Adapter
Stands (2)
1
Connect the Transmitter
From amplifier speaker output
User’s Guide
Quick Start
Amplifier
- OR ­From line out
3
Use Your Speaker Kit
Transmitter
To rear speakers
© 2011. Ignition L.P. All rights reserved. Auvio is a registered trademark used by Ignition L.P. Package and user documentation are recyclable. User documentation contains recycled material.
1500044 QS_022411.indd 1 3/1/2011 11:05:44 AM
Receiver
Printed in China
AO0468AAA1
03A11
1500044
T H E P E R F O R M A N C E Y O U N EE D
®
®
Wireless Speaker Kit
Please read this user’s guide before using your new speaker kit.
User’s Guide 1500044
Package contents
 Transmitter D Receiver  9V AC Adapter D 15V AC Adapter  Stands (2) D 6-foot speaker wire (2)  User’s Guide D Quick Start
Features
 2.4GHz digital wireless link provides crystal clear audio
signals.
 Three-channel selection to avoid potential interference
in the environment.
 Up to 115 feet (35m) operation distance between
transmitter and receiver (line of sight).
1 Install the Transmitter
1. Make sure your amplifier is off. Connect the
transmitter to your amplifier‘s speaker output terminals with the provided 6-foot speaker cords, matching polarities. Or connect your transmitter to the amplifier’s RCA output ports with RCA cables (not included).
2. Connect the supplied AC adapter (9V, 200mA) to the
DC IN 9V jack, then plug it into a standard household outlet.
To rear speakers
From amplifier speaker output
- OR -
From line out
DC IN 9V
2 Install the Receiver
1. Connect the surround speakers to the receiver with
speaker wires, matching polarities.
2. Connect the supplied AC adapter (15V, 4A) to the
DC IN 15V jack, and then plug it into a standard household outlet.
n Notes:
 Make sure the exposed tips of each cord do not touch
each other, and make sure they are fully inserted into the terminals.
 This rear speaker kit is designed for connecting to your
amplifier surround speaker terminals only.
 For speaker wires that have proprietary connectors, you may
strip the end of the wires to allow connection to the receiver. However, check with the speaker manufacturer before doing this, as it may void the warranty.
 When the RCA cables are connected, audio input from the
speaker terminal will be disabled.
 Unplug the AC adapters from the AC outlet before unplugging
it from the transmitter or receiver.
 Use the supplied AC adapters only. Using an AC adapter not
designed for this product may cause damage.
3 Place the Transmitter and
Receiver
The transmitter and receiver must be placed within 100 feet for proper operation. They can be placed horizontally on a flat surface, vertically in the provided stands or mounted on a wall, using the mounting holes on the bottom.
DC IN 15V
2
2
1500044_UG_EN 022411.indd 1-5 3/1/2011 3:56:49 PM
3
3
4
4
5
5
