Quark QuarkXPress Server - 7.0 Operation Manual

User Guide

Dynamic publishing technology for creative
Web-based and data-driven solutions

LEGAL NOTICES

©2006 Quark Technology Partnership as to the content and arrangement of this material.
All rights reserved.

©1986–2006 Quark Technology Partnership and its licensors as to the technology.
All rights reserved.

Protected by one or more of U.S. Patent Nos. 5,541,991; 5,680,619; 5,907,704;
6,005,560; 6,052,514; 6,081,262; 6,633,666 B2; 6,947,959 B1; 6,940,518 B2; and other
patents pending.

Information in this document is subject to change without notice and does not represent
a commitment on the part of Quark Technology Partnership or its licensee, Quark Inc.

Quark Products and materials are subject to the copyright and other intellectual property
protection of the United States and foreign countries. Unauthorized use or reproduction
without Quark’s written consent is prohibited.

QUARK IS NOT THE MANUFACTURER OF THIRD PARTY SOFTWARE OR OTHER
THIRD PARTY HARDWARE (HEREINAFTER “THIRD PARTY PRODUCTS”) AND
SUCH THIRD PARTY PRODUCTS HAVE NOT BEEN CREATED, REVIEWED, OR
TESTED BY QUARK, THE QUARK AFFILIATED COMPANIES OR THEIR LICENSORS.
(QUARK AFFILIATED COMPANIES SHALL MEAN ANY PERSON, BRANCH, OR
ENTITY CONTROLLING, CONTROLLED BY OR UNDER COMMON CONTROL
WITH QUARK OR ITS PARENT OR A MAJORITY OF THE QUARK SHAREHOLDERS,
WHETHER NOW EXISTING OR FORMED IN THE FUTURE, TOGETHER WITH
ANY PERSON, BRANCH, OR ENTITY WHICH MAY ACQUIRE SUCH STATUS IN
THE FUTURE.)

QUARK, THE QUARK AFFILIATED COMPANIES AND/OR THEIR LICENSORS MAKE
NO WARRANTIES, EITHER EXPRESS OR IMPLIED, REGARDING THE QUARK
PRODUCTS/SERVICES AND/OR THIRD PARTY PRODUCTS/SERVICES, THEIR
MERCHANTABILITY, OR THEIR FITNESS FOR A PARTICULAR PURPOSE. QUARK,
THE QUARK AFFILIATED COMPANIES AND THEIR LICENSORS DISCLAIM ALL
WARRANTIES RELATING TO THE QUARK PRODUCTS/SERVICES AND ANY THIRD
PARTY PRODUCTS/SERVICES. ALL OTHER WARRANTIES AND CONDITIONS,
WHETHER EXPRESS, IMPLIED OR COLLATERAL, AND WHETHER OR NOT, MADE
BY DISTRIBUTORS, RETAILERS, XTENSIONS DEVELOPERS OR OTHER THIRD
PARTIES ARE DISCLAIMED BY QUARK, THE QUARK AFFILIATED COMPANIES
AND THEIR LICENSORS, INCLUDING WITHOUT LIMITATION, ANY WARRANTY
OF NON-INFRINGEMENT, COMPATIBILITY, OR THAT THE SOFTWARE IS ERROR­FREE OR THAT ERRORS CAN OR WILL BE CORRECTED. THIRD PARTIES MAY
PROVIDE LIMITED WARRANTIES AS TO THEIR OWN PRODUCTS AND/OR
SERVICES, AND USERS MUST LOOK TO SAID THIRD PARTIES FOR SUCH WAR­RANTIES, IF ANY. SOME JURISDICTIONS, STATES OR PROVINCES DO NOT
ALLOW LIMITATIONS ON IMPLIED WARRANTIES, SO THE ABOVE LIMITATION
MAY NOT APPLY TO PARTICULAR USERS.

IN NO EVENT SHALL QUARK, THE QUARK AFFILIATED COMPANIES, AND/
OR THEIR LICENSORS BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL,
CONSEQUENTIAL OR PUNITIVE DAMAGES, INCLUDING, BUT NOT LIMITED

A, LOST FEES,

TO, ANY LOST PROFITS, LOST TIME, LOST SA
OR EXPENSES OF ANY KIND ARISING FROM INSTALLATION OR USE OF THE
QUARK PRODUCTS/SERVICES, IN ANY MANNER, HOWEVER CAUSED AND
ON ANY THEOR
QUARK, THE QUARK AFFILIATED COMPANIES AND/OR THEIR LICENSORS ARE

Y OF LIABILITY. IF, NOTWITHSTANDING THE FOREGOING,

VINGS, LOST DA

T

II

|

LEGAL NOTICES

FOUND TO HAVE LIABILITY RELATING TO THE QUARK PRODUCTS/SERVICES
OR THIRD PARTY PRODUCTS/SERVICES, SUCH LIABILITY SHALL BE LIMITED
TO THE AMOUNT PAID BY THE USER TO QUARK FOR THE SOFTWARE/SERVICES
AT ISSUE (EXCLUDING THIRD PARTY PRODUCTS/SERVICES), IF ANY, OR THE
LOWEST AMOUNT UNDER APPLICABLE LAW, WHICHEVER IS LESS. THESE LIMI­TATIONS WILL APPLY EVEN IF QUARK, THE QUARK AFFILIATED COMPANIES,
THEIR LICENSORS AND/OR THEIR AGENTS HAVE BEEN ADVISED OF SUCH
POSSIBLE DAMAGES. SOME JURISDICTIONS, STATES OR PROVINCES DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THIS LIMITATION OR EXCLUSION MAY NOT APPLY. ALL OTHER
LIMITATIONS PROVIDED UNDER APPLICABLE LAW, INCLUDING STATUTES OF
LIMITATION, SHALL CONTINUE TO APPLY.

IN THE EVENT ANY OF THESE PROVISIONS ARE OR BECOME UNENFORCEABLE
UNDER APPLICABLE LAW, SUCH PROVISION SHALL BE MODIFIED OR LIMITED
IN ITS EFFECT TO THE EXTENT NECESSARY TO CAUSE IT TO BE ENFORCEABLE.

USE OF THE QUARK PRODUCTS IS SUBJECT TO THE TERMS OF THE END USER
LICENSE AGREEMENT OR OTHER APPLICABLE AGREEMENTS FOR SUCH PROD­UCT/SERVICE. IN THE EVENT OF A CONFLICT BETWEEN SUCH AGREEMENTS
AND THESE PROVISIONS THE RELEVANT AGREEMENTS SHALL CONTROL.

Quark, QuarkXPress and XTensions are trademarks of Quark Inc. and all applicable
affiliated companies, Reg. U.S. Pat. & Tm. Off. and in many other countries. The Quark
logo, Job Jackets, Composition Zones, QuarkVista and other Quark related marks which
Quark may adopt from time to time are trademarks of Quark Inc. and all applicable
affiliated companies.

Windows and OpenType are registered trademarks of Microsoft Corporation in the
United States and/or other countries.

Mac OS and QuickDraw are trademarks or registered trademarks of Apple Computer, Inc.
in the U.S.A. and other countries. QuickTime is a trademark used under license. QuickTime
is registered in the U.S. and other countries.

PostScript is a registered trademark of Adobe Systems Incorporated in the United States
and/or other countries. PANTONE

®

Colors displayed in the software application or in the
user documentation may not match PANTONE-identified standards. Consult current
PANTONE Color Publications for accurate color. PANTONE and other Pantone, Inc.
trademarks are the property of Pantone, Inc. ©Pantone, Inc., 2005.

Color Data is produced under license from Dainippon Ink and Chemicals, Inc.

TONE and FOCOL

FOCOL
The concept, structure, and form of FOCOL
protected by patent and copyright law

TONE Colour System are registered trademarks of FOCOLTONE.

TONE material and intellectual property are

. Any reproduction in any form, in whole or in part,
for private use or for sale, is strictly forbidden. Contact FOCOLTONE, Ltd. for specific
patent information.

oyo Ink Mfg. Co., Ltd. is the copyright owner of TOYO INK COLOR FINDER

T

™

SYSTEM
AND SOFTWARE which is licensed to Quark Inc. to distribute for use only in connec­tion with QuarkXPress. TOYO INK COLOR FINDER SYSTEM AND SOFTWARE shall

be copied onto another diskette or into memor

not

y unless as part of the execution
of QuarkXPress. TOYO INK COLOR FINDER SYSTEM AND SOFTWARE ©TOYO INK
MFG. CO., L
trademark of Toyo Ink Mfg. Co., Ltd. COLOR FINDER

TD., 1991. COLOR FINDER is in the process of registration as the registered

™

computer video simulation used

III

|

LEGAL NOTICES

in the product may not match the COLOR FINDER™book, and additionally some printer
color used in the product may also not match. Please use the COLOR FINDER book to
obtain the accurate color.”

TRUMATCH, TRUMATCH Swatching System, and TRUMATCH System are trademarks
of TRUMATCH, Inc.

This product includes software developed by the TTF2PT1 Project and its contributors.
Copyright ©1997–2001 by the AUTHORS: Andrew Weeks <[e-mail]>;
Frank M. Siegert <[e-mail]>; Mark Heath <[e-mail]>; Thomas
Henlich <[e-mail]>; Sergey Babkin <[e-mail]>,
<[e-mail]>; Turgut Uyar <[e-mail]>; Rihardas Hepas
<[e-mail]>; Szalay Tamas <[e-mail]>; Johan Vromans
<[e-mail]>; Petr Titera <[e-mail]>; Lei Wang
<[e-mail]>; Chen Xiangyang <[e-mail]>;
Zvezdan Petkovic <[e-mail]>. All rights reserved.

THE TTF2PT1 SOFTWARE IS PROVIDED BY THE AUTHORS AND CONTRIBUTORS
“AS IS” AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT
LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PRATICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE
AUTHORS OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCI­DENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING,
BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;
LOSSOF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER
CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT
LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN
ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGE.

As to the Apache software, copyright ©1999–2000 The Apache Software Foundation. All
rights reserved. Any Apache software which is distributed with this software is software
developed by the Apache Software Foundation (www.apache.org). APACHE SOFTWARE
IS PROVIDED “AS IS” AND ANY EXPRESSED OR IMPLIED WARRANTIES,
INCLUDING,BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANT­ABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO
EVENT SHALL THE APACHE SOFTWARE FOUNDATION OR ITS CONTRIBUTORS
BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY,
OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED

TO, PROCUREMENT OF SUBSTITUTE GOODS OR SER
OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY

Y OF LIABILITY

THEOR
(INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF
THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGE.

As to Apache technology, copyright ©1999–2002 The Apache Software Foundation. All
rights reserved. Any Apache software which is distributed with this software is devel­oped by the Apache Software Foundation (
License, Version 2.0 (the “License”); you may not use this file except in compliance with
the License. Y

LICENSE-2.0. Unless required by applicable law or agreed to in writing, software distrib-

uted under the License is distributed on an “AS IS” BASIS, WITHOUT WARRANTIES OR

ou may obtain a copy of the License at

, WHETHER IN CONTRACT

.apache.org). Licensed under the Apache

www

VICES; LOSS OF USE, DA

, STRICT LIABILITY, OR TORT

http://www

.apache.org/licenses/

TA

IV

|

LEGAL NOTICES

CONDITIONS OF ANY KIND, either express or implied. See the License for the specific
language governing permissions and limitations under the License. Portions of this
product include technology used under license from Global Graphics.

As to ICU technology, copyright ©1995–2001 International Business Machines Corporation
and others. All rights reserved.Permission is hereby granted, free of charge, to any person
obtaining a copy of this software and associated documentation files (the “Software”),
to deal in the Software without restriction, including without limitation the rights to
use, copy, modify,merge, publish, distribute, and/or sell copies of the Software,and to
permit persons to whom the Software is furnished to do so, provided that the above
copyright notice(s) and this permission notice appear in supporting documentation.
THIS SOFTWARE IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND,
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES
OF MERCHANTABILITY,FITNESS FOR A PARTICULAR PURPOSE AND NONIN­FRINGE-MENT OF THIRD PARTY RIGHTS. IN NO EVENT SHALL THE COPYRIGHT
HOLDER OR HOLDERS INCLUDED IN THIS NOTICE BE LIABLE FOR ANY CLAIM,
OR ANY SPECIAL INDIRECT OR CONSEQUENTIAL DAMAGES, OR ANY DAMAGES
WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER
IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS ACTION,
ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF
THIS SOFTWARE. Except as contained in this notice, the name of a copyright holder
shall not be used in advertising or otherwise to promote the sale, use or other dealings
in this Software without prior written authorization of the copyright holder.

This software is based in part on the work of the Independent JPEG Group.

As to Apple software, ©2002–2004 Apple Computer, Inc. All rights reserved. This Apple
software is supplied to you by Apple Computer, Inc. (“Apple”) in consideration of your
agreement to the following terms, and your use, installation, modification or redistrib­ution of this Apple software constitutes acceptance of these terms. If you do not agree
with these terms, please do not use, install, modify or redistribute this Apple software.
In consideration of your agreement to abide by the following terms, and subject to these
terms, Apple grants you a personal, non-exclusive license, under Apple’s copyrights in
this original Apple software (the “Apple Software”), to use, reproduce, modify and redis­tribute the Apple Software, with or without modifications, in source and/or binary forms;
provided that if you redistribute the Apple Software in its entirety and without modifi­cations, you must retain this notice and the following text and disclaimers in all such
redistributions of the Apple Software. Neither the name, trademarks, service marks or logos
of Apple Computer, Inc. may be used to endorse or promote products derived from the
Apple Software without specific prior written permission from Apple. Except as expressly
stated in this notice, no other rights or licenses, express or implied, are granted by
Apple herein, including but not limited to any patent rights that may be infringed by
your derivative works or by other works in which the Apple Software may be incorpo
rated. The Apple Software is provided by Apple on an “AS IS” basis.
NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION
THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY AND
FITNESS FOR A P
ITS USE AND OPERATION ALONE OR IN COMBINATION WITH YOUR PROD­UCTS. IN NO EVENT SHALL APPLE BE LIABLE FOR ANY SPECIAL, INDIRECT
INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED
TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA,
OR PROFITS; OR BUSINESS INTERRUPTION) ARISING IN ANY WAY OUT OF THE

ARTICULAR PURPOSE, REGARDING THE APPLE SOFTW

APPLE MAKES

ARE OR

,

-

V

|

LEGAL NOTICES

USE, REPRODUCTION, MODIFICATION AND/OR DISTRIBUTION OF THE APPLE
SOFTWARE, HOWEVER CAUSED AND WHETHER UNDER THEORY OF CONTRACT,
TORT (INCLUDING NEGLIGENCE), STRICT LIABILITY OR OTHERWISE, EVEN
IF APPLE HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

As to Microsoft technology, ©1988–2005 Microsoft Corporation. All rights reserved.

As to Nodeka software, ©1999–2002 Justin Gottschlich. All rights reserved. As to W3C
software, Copyright ©2001 World Wide Web Consortium, (Massachusetts Institute
of Technology, European Research Consortium for Informatics and Mathematics,
Keio University). All rights reserved. This work is distributed under the W3C Software
License (1) in the hope that it will be useful, but WITHOUT ANY WARRANTY; without
even the implied warranty of MECHANTABILITY or FITNESS FOR A PARTICULAR
PURPOSE. (1) www.w3.org/Consortium/Legal/2002/copyright-software-20021231.

As to the omniORB library, Copyright ©1996–1999 At&T Laboratories Cambridge. The
omniORB library is free software; you can redistribute it and/or modify it under the terms
of the GNU Lesser General Public License as published by the Free Software Foundation;
either version 2.1 of the License, or (at your option) any later version. This library is
distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without
even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR
PURPOSE. See the GNU Lesser General Public license for more details. You should have
received a copy of the GNU Lesser General Public License along with this library; if not,
write to the Free Software Foundation, Inc., 59 Temple Place - Suite 330, Boston,
MA 02111-1307.

As to cascading menus based on menu.js. by Gary Smith, July 1997, Copyright
©1997–1999 Netscape Communication Corp. Netscape grants you a royalty free
license to use or modify the cascading menus software provided that this copyright
notice appears on all copies. This software is provided “AS IS,” without a warranty
of any kind.

As to Dr. Brian Gladman software, Copyright ©2001, Dr. Brian Gladman
<[e-mail]>, Worcester, UK. All rights reserved. LICENSE TERMS The free
distribution and use of this software in both source and binary form is allowed (with
or without changes) provided that: 1. distributions of this source code include the
above copyright notice, this list of conditions and the following disclaimer; 2. distribu­tions in binary form include the above copyright notice, this list of conditions and the
following disclaimer in the documentation and/or other associated materials; 3. the
copyright holder’s name is not used to endorse products built using this software with­out specifi

c written permission. DISCLAIMER This software is provided ‘as is’ with no
explicit or implied warranties in respect of any properties, including, but not limited
to, correctness and fi

tness for purpose.

As to STLport technology, Copyright 1999, 2000 Boris Fomitchev. This material is pro­vided “as is”, with absolutely no warranty expressed or implied. Any use is at your own
risk. Permission to use or copy this sofware for any purpose is hereby granted without
fee, provided the above notices are retained on all cpies. Permission to modify the code
and to distribute modified code is granted, provided the above notices are retained, and
a notice that the code was modifi

ed is included with the above copyright notice. The
Licensee may distribute binaries compiled with STLport (whether original or modified)
without any royalties or restrictions. The Licensee may distribute original or modifi

ed
STLport sources, provided that: The conditions indicated in the above permission notice
are met; The following copyright notices are retained when present, and conditions

®

VI

|

LEGAL NOTICES

provided in accompanying permission notices are met: Copyright 1994 Hewlett-Packard
Company. Copyright 1996,97 Silicon Graphics Computer Systems, Inc. Copyright 1997
Moscow Center for SPARC Technology.

Permission to use, copy, modify, distribute and sell this software and its documentation
for any purpose is hereby granted without fee, provided that the above copyright notice
appear in all copies and that both that copyright notice and this permission notice
appear in supporting documentation. Hewlett-Packard Company makes no representa­tions about the suitability of this software for any purpose. It is provided “as is” without
express or implied warranty.Permission to use, copy, modify, distribute and sell this soft­ware and its documentation for any purpose is hereby granted without fee, provided that
the above copyright notice appear in all copies and that both that copyright notice and
this permission notice appear in supporting documentation. Silicon Graphics makes no
representations about the suitability of this software for any purpose. It is provided “as
is” without express or implied warranty.Permission to use, copy, modify, distribute and
sell this software and its documentation for any purpose is hereby granted without fee,
provided that the above copyright notice appear in all copies and that both that copy­right notice and this permission notice appear in supporting documentation. Moscow
Center for SPARC Technology makes no representations about the suitability of this
software for any purpose. It is provided “as is” without express or implied warranty.

As to DOM4J software, Redistribution and use of this software and associated docu­mentation (“Software”), with or without modification, are permitted provided that the
following conditions are met:

Redistributions of source code must retain copyright statements and notices.
Redistributions must also contain a copy of this document.

Redistributions in binary form must reproduce the above copyright notice, this list of
conditions and the following disclaimer in the documentation and/or other materials
provided with the distribution.

The name “DOM4J” must not be used to endorse or promote products derived from this
Software without prior written permission of MetaStuff, Ltd. For written permission,
please contact [e-mail].

Products derived from this Software may not be called “DOM4J” nor may “DOM4J”
appear in their names without prior written permission of MetaStuff, Ltd. DOM4J is a
registered trademark of MetaStuff, Ltd.

Due credit should be given to the DOM4J Project - www.dom4j.org

THIS SOFTWARE IS PROVIDED BY METASTUFF, LTD. AND CONTRIBUTORS
“AS IS” AND ANY EXPRESSED OR IMPLIED W
NOT LIMITED TO, THE IMPLIED W
FITNESS FOR A P
METASTUFF, LTD. OR ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDI­RECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES
(INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS
OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION)
HOWEVER CAUSED AND ON ANY THEOR
TRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE)
ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED
OF THE POSSIBILITY OF SUCH DAMAGE.

Copyright 2001–2005 ©MetaStuff, Ltd. All Rights Reserved.

ARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL

ARRANTIES OF MERCHANT

ARRANTIES, INCLUDING, BUT

ABILITY AND

Y OF LIABILITY

, WHETHER IN CON

-

VII

|

LEGAL NOTICES

As to Sun Microsystems, Inc. software, Copyright ©2003, Sun Microsystems, Inc. All Rights
Reserved. Redistribution and use in source and binary forms, with or without modifica­tion, are permitted provided that the following conditions are met: Redistribution of
source code must retain the above copyright notice, this list of conditions and the fol­lowing disclaimer. Redistribution in binary form must reproduce the above copyright
notice, this list of conditions and the following disclaimer in the documentation and/or
other materials provided with the distribution. Neither the name of Sun Microsystems,
Inc. or the names of contributors may be used to endorse or promote products derived
from this software without specific prior written permission. This software is provided
“AS IS,” without a warranty of any kind. ALL EXPRESS OR IMPLIED CONDITIONS,
REPRESENTATIONS AND WARRANTIES, INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON­INFRINGEMENT, ARE HEREBY EXCLUDED. SUN MICROSYSTEMS, INC. (“SUN”)
AND ITS LICENSORS SHALL NOT BE LIABLE FOR ANY DAMAGES SUFFERED BY
LICENSEE AS A RESULT OF USING, MODIFYING OR DISTRIBUTING THIS SOFT­WARE OR ITS DERIVATIVES. IN NO EVENT WILL SUN OR ITS LICENSORS BE
LIABLE FOR ANY LOST REVENUE, PROFIT OR DATA, OR FOR DIRECT, INDIRECT,
SPECIAL, CONSEQUENTIAL, INCIDENTAL OR PUNITIVE DAMAGES, HOWEVER
CAUSED AND REGARDLESS OF THE THEORY OF LIABILITY, ARISING OUT OF
THE USE OF OR INABILITY TO USE THIS SOFTWARE, EVEN IF SUN HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

All other marks are the properties of their respective owners.

VIII

|

Introduction

bout this Guide xvi

A

What you will see xvi

1 Getting started with

QuarkXPress Server

Understanding QuarkXPress Server 1

Server templates and static projects 2

The document pool 2

Projects and layouts 2

Caching 3

QuarkXPress Server preferences 3

Quark License Administrator 3

Master-Subrenderer environment 3

The Keepalive script 4

TABLE OF CONTENTS

Understanding QuarkXPress Server
XTensions software 4

The QuarkXPress Server XTensions Application
Programming Interface (API) 5

Launching QuarkXPress Server 5

Command line options 6

Exit Codes 6

2 The QuarkXPress Server

user interface

Server configuration dialog box 7

Server (Tab) 7

Logging (Tab) 12

HTTP (Tab) 14

Email (Tab) 16

Server preferences 18

Application preferences (category) 18

IX

|

TABLE OF CONTENTS

Display (pane) 18

Input Settings (pane) 20

XTensions Manager (pane) 21

Font Mapping (pane) 22

Deconstruct (Pane) 23

EPS (pane) 24

Full Res Preview (pane) 25

Job Jackets (pane) 26

Modifier (pane) 27

PDF (Pane) 28

Placeholders (pane) 30

PSD Import (pane) 31

Fraction/Price (pane) 32

Picture Effects (pane) 33

Project preferences (category) 34

General (pane) 34

XML Import (pane) 35

Default Print Layout (category) 35

General (pane) 36

Measurements (pane) 38

Paragraph (pane) 39

Character (pane) 41

Tools (pane) 44

Trapping (pane)

Color Manager (pane)

Layers (pane) 50

Style sheets 51

Default Style Sheets (dialog box) 51

Edit Paragraph Style Sheet (dialog box) 52

General (tab) 53

44

48

X

|

Formats (tab) 55

Tabs (tab) 58

Rules (tab) 60

Edit Character Style Sheet (dialog box) 63

Colors 66

Default Colors (dialog box) 66

Edit Color (dialog box) 68

Trap Specifications (dialog box) 72

H&Js 75

Default H&Js (dialog box) 75

Edit Hyphenation & Justification (dialog box) 78

Output styles 81

Output Styles (dialog box) 81

Edit EPS Style (dialog box) 82

TABLE OF CONTENTS

Panes 83

General (pane) 84

Color (pane) 85

Marks (pane) 86

Fonts (pane) 86

Bleed (pane) 87

Transparency (pane) 88

OPI (pane) 88

JDF (pane) 89

Advanced (pane)

Summary (pane)

Edit PPML Style (dialog box) 91

Panes 92

Device (pane) 92

Pages (pane) 95

Colors (pane) 96

90

91

XI

|

TABLE OF CONTENTS

Pictures (pane) 98

Marks (pane) 99

Bleed (pane) 99

JDF (pane) 100

Advanced (pane) 101

Summary (pane) 101

Edit PDF Style (dialog box) 101

Panes 102

Pages (pane) 103

Meta Data (pane) 104

Hyperlink (pane) 104

Compression (pane) 106

Color (pane) 109

Fonts (pane) 110

Marks (pane) 110

Bleed (pane) 111

Transparency (pane) 112

OPI (pane) 113

OPI Active (check box) 113

JDF (pane) 114

Summary (pane) 115

Edit Print Style (dialog box) 115

Panes 117

Device (pane)

Pages (pane)

Colors (pane) 121

Pictures (pane) 123

Fonts (pane) 124

Marks (pane) 125

Bleed (pane) 125

117

120

XII

|

Transparency (pane) 126

OPI (pane) 127

JDF (pane) 128

Summary (pane) 129

Font mapping 129

Font Mapping (Dialog box) 129

Source Setups 130

Default Source Setups (dialog box) 131

Edit Source Setup (dialog box) 132

Output Setups 133

Default Output Setups (dialog box) 134

Edit Output Setup (dialog box) 135

Server XTensions Manager 136

Server XTensions Manager (dialog box) 136

TABLE OF CONTENTS

Status Monitor 138

Status Monitor (Window) 138

Verbose Status Monitoring (command) 140

Other menu items 141

About QuarkXPress Server (dialog box) 141

Check Out License (dialog box) 141

Pause Server (command) 141

Start Server (command) 141

Stop Server (command) 141

Shut Down Server (command)

Clear Status Monitor (command)

3 Creating URL requests

Understanding URL requests 142

Understanding QuarkXPress
Server namespaces 143

Understanding QuarkXPress
Server parameters 144

141

141

XIII

|

TABLE OF CONTENTS

QuarkXPress Server Web Integration
Guide overview 144

Render types 144

General parameters 145

Specialized parameters 146

Server control parameters 147

Preference Administration parameters 148

4 XTensions software

PDF Filter XTensions software 152

Rendering QuarkXPress projects as PDF files 152

URL parameters for PDF rendering 152

PPML Export XTensions software 153

Rendering QuarkXPress projects in PPML format 153

URL parameters for PPML rendering 153

Modifier XTensions software 153

Using Modifier XTensions software 154

Creating XML for Modifier XTensions software 154

Modifying images 155

Modifying text 158

Modifying boxes 161

Creating and deleting boxes 165

Importing data 166

Saving projects 168

DTD for Modifier XTensions software

Deconstructor XT

Using Deconstructor XTensions software 172

Using QuarkVista XTensions software 180

Creating preset files 180

Using QuarkVista XTensions software 180

Removing QuarkVista effects 181

ensions software 172

169

XIV

|

QuarkXPress Server Layer
XTensions software 182

Using QuarkXPress Server Layer
XTensions software 182

QuarkXPress Server Layers parameters 182

5 Telegraph XTensions software

Setting Telegraph preferences 184

Adding a server 185

Editing server properties 185

Deleting a server 185

Setting document cache preferences 186

Using Telegraph XTensions software 186

Identifying QuarkXPress items 186

Assigning item names 187

Viewing Box ID numbers 187

TABLE OF CONTENTS

Uploading templates 187

Uploading missing or modified pictures 189

6 QuarkXPress Server Monitor

Running QuarkXPress Server Monitor 190

Configuring QuarkXPress Server Monitor 190

Viewing QuarkXPress Server status 193

Glossary

XV

|

ABOUT THIS GUIDE

Introduction

Before you begin, take time to review this chapter so that you understand

how A Guide to QuarkXPress®Server 7 is structured and how you can get the

most out of it.

ABOUT THIS GUIDE

You do not need to read this guide from cover to cover. Instead, use this guide
to quickly look up information, find out what you need to know, and proceed
with your work. Use the detailed table of contents at the beginning of the
guide to find information quickly.

WHAT YOU WILL SEE

Various conventions (styles) in this guide highlight information to help you
quickly find what you need.

BOLD TYPE STYLE CONVENTION

The names of menu commands, dialog boxes, and other controls are set in bold
type. For example: “You can use the
text, pictures, lines, and box backgrounds.”

Colors palette to apply colors or inks to

XVI

INTRODUCTION

|

REFERENCES AND ARROWS

Whenever a feature is mentioned, a reference shows you how to access that
feature. For example: “You can use the
a copy of a project.” Arrows indicate the menu path to a feature. For example:
“Choose

MAC OS AND WINDOWS REFERENCES

QuarkXPress Server is quite consistent across operating systems. However,
some labels, buttons, key combinations, and other aspects of QuarkXPress
Server must differ between Mac OS
conventions or other factors. In such cases, both the Mac OS and Windows
versions are presented, separated by a slash, with the Mac OS version pre­sented fi
and the Windows version is labeled Browse, you are directed to “Click Select/

Browse

parenthetical statements.

NOTES

Notes cover additional information about particular features or concepts. They
may also contain suggestions to improve your workflow or to perform a step
more effi

File Þ Print to display the Print dialog box.”

rst. For example, if the Mac OS version of a button is labeled

.” More-complex cross-platform differences are mentioned in notes or

.

ciently

Save as dialog box (File menu) to save

®

and Windows®because of user interface

Select

UNDERSTANDING QUARKXPRESS SERVER

Chapter 1: Getting started with
QuarkXPress Server

QuarkXPress Server lets you use a Web browser to view and output QuarkXPress

projects in a variety of formats.

UNDERSTANDING QUARKXPRESS SERVER

QuarkXPress Server lets you output customized QuarkXPress layouts in a
variety of formats (including JPEG, Portable Document Format — PDF, and
PostScript
request to a QuarkXPress Server application, all you need to do is enter a
URL into your Web browser’s address field. For example, the following URL
instructs the QuarkXPress Server application named “QXPServer7” to return
the file “MyProject.qxp” as a PDF file:

®

) from a centralized QuarkXPress Server application. To send a

http://QXPServer7:8080/PDF/MyProject.qxp

The QuarkXPress Server application receives these requests, renders (creates)
the requested projects in the requested formats, and then returns the rendered
file to the client application (in this case, the Web browser).

The format of QuarkXPress Server URL requests is described in detail in
Chapter 3, “Creating URL requests,” and in the

Integration Guide

You can also create custom applications that communicate with a
QuarkXPress Server application using HTTP, Simple Object Access Protocol
(SOAP), or another protocol. For more information, see the
Web Integration Guide.

You can think of QuarkXPress Server as a special version of QuarkXPress that
runs on a server with the following main differences:

• Instead of accepting input from a keyboard and mouse, QuarkXPress Server
accepts input in the form of URLs.

• Instead of sending a project to a printer, QuarkXPress Server renders (creates)
output in a particular format and sends the rendered file to a client.

.

QuarkXPress Server Web

QuarkXPress

CHAPTER 1: GETTING ST

ARTED WITH QUARKXPRESS SERVER

1

|

UNDERSTANDING QUARKXPRESS SERVER

SERVER TEMPLATES AND STATIC PROJECTS

QuarkXPress Server can open, render, and serve two types of projects:

• Static projects are QuarkXPress projects that can be rendered and served as-is
in a variety of formats by the QuarkXPress Server application. For example,
you might make a product manual available as a static project and allow
customers to download that manual in a variety of formats.

Server templates are QuarkXPress projects that can be manipulated by the

•
QuarkXPress Server application before being rendered and served. For exam­ple, you might make a sales piece available as a server template so that each
person who downloads it receives a personalized copy.

QuarkXPress Server can open QuarkXPress documents, projects, and templates
created in any non-East-Asian edition of QuarkXPress 5.0 or later. QuarkXPress
Server can save and export projects only in QuarkXPress 6.x and
QuarkXPress 7.x format.

THE DOCUMENT POOL

QuarkXPress Server reads server templates and static projects from a direc­tory called the

document pool. The document pool can be any directory that
is available to QuarkXPress Server through a file system or an FTP server. You
can use any of the following methods to place files in the document pool:

• Drag the files to the document pool directory.

• Upload the files using FTP to the document pool directory.

®

• Use Telegraph XTensions

software to upload the files to the document pool
from within QuarkXPress. (For more information about Telegraph XTensions
software, see Chapter 5, “Telegraph XTensions software.”)

For more information about the document pool, see “

Server configuration

dialog box” in Chapter 2, “The QuarkXPress Server user interface.”

QuarkXPress Server 7 can also serve documents from a database, a content
management system, or other sources. Collectively, the document pool and
any other source of files to be served are referred to as

PROJECTS AND LA

YOUTS

document providers.

QuarkXPress projects can contain one or more layouts, and only one layout can
be rendered at any given time. If you do not specify a layout when you send a
rendering request, QuarkXPress Server renders the first layout in the project.

CHAPTER 1: GETTING ST

2

|

ARTED WITH QUARKXPRESS SERVER

UNDERSTANDING QUARKXPRESS SERVER

CACHING

To maximize efficiency, QuarkXPress Server uses cached versions of all rendered
projects whenever possible. You can configure projects so that they are never
cached, so that they are cached for a particular amount of time, or so that they
are rendered every time they are served. For more information about caching,

Server configuration dialog box” in Chapter 2, “The QuarkXPress Server

see “
user interface.”

QUARKXPRESS SERVER PREFERENCES

When you launch QuarkXPress Server, the application creates preferences
files that are functionally and structurally equivalent to the preferences files
created by QuarkXPress. These preferences files reside in the QuarkXPress
Server “Preferences” folder. QuarkXPress Server also creates an “XPressServer
Preferences.prf” file in the “Preferences” folder; this file contains preference
settings that are specific to QuarkXPress Server.

QuarkXPress Server uses these preferences the same way QuarkXPress uses
them. If an XTensions module creates a project in QuarkXPress Server, that
project draws its settings from the QuarkXPress Server preferences just as a
new QuarkXPress project draws its settings from the QuarkXPress preferences.

Preferences files are stored in the following locations:

• Mac OS:

[User]/Library/Preferences/Quark

• Windows: C:\Documents and Settings\[username]\Application Data\

Quark\QuarkXPress Server 7.0\Preferences

For more information about preferences, see “Server preferences” in Chapter 2,
“The QuarkXPress Server user interface.”

QUARK LICENSE ADMINISTRATOR

To prevent unauthorized use, QuarkXPress Server requires the presence of a

®

Quark

License Administrator (QLA) server to launch. QuarkXPress Server fol­lows the configuration and control rules that are enforced by QLA. For more
information about QLA, see the QLA documentation included with
QuarkXPress Server.

MASTER-SUBRENDERER ENVIRONMENT

Requests for project renders are stored in a connection queue. The requests in
the rendering queue can be processed by a single QuarkXPress Server applica­tion, or by a master QuarkXPress Server application and several subrenderers
(additional instances of QuarkXPress Server). The master QuarkXPress Server
application launches the available number of subrenderers and then passes
the requests in the connection queue to those subrenderers as they become
available. The number of subrenderers available for launch is determined by
the number of licenses available from the QLA server.

CHAPTER 1: GETTING ST

ARTED WITH QUARKXPRESS SERVER

3

|

UNDERSTANDING QUARKXPRESS SERVER

he master QuarkXPress Server application and all of the subrenderers it

T
launches share the following elements:

• The same application preferences files on disk

• The same document cache in memory

• The same memory cache

• The same server XTensions modules

• The same server document pool (if defined in the QuarkXPress Server preferences
or if a document provider is used in place of the document pool)

If a subrenderer unexpectedly quits, the master QuarkXPress Server restarts
the subrenderer without requiring any action from you.

The master-subrenderer environment can be initiated from the command line
or by any means that can issue a command-line command (such as scripts
and shortcuts).

THE KEEPALIVE SCRIPT

A script called the keepalive script can monitor a QuarkXPress Server application
and restart the application if it fails. To use this feature, launch QuarkXPress
Server by running the “keepalive.sh” script (Mac OS) or “keepalive.bat”
(Windows) script. Note that the keepalive script works only if you run it before
you launch QuarkXPress Server. You can also manually restart QuarkXPress
Server using this script.

On both platforms, information about unexpected shutdowns (including the
error date, time, code, and description) is stored in an error log file. For more
information about logging, see “Logging (tab)” in Chapter 2, “The QuarkXPress
Server user interface.”

UNDERSTANDING QUARKXPRESS SERVER XTENSIONS SOFTWARE

QuarkXPress Server ships with a collection of XTensions software that adds
capabilities to QuarkXPress Server. For example, PDF Export XTensions soft­ware lets QuarkXPress Server serve content in PDF format, Deconstructor
XTensions software lets you retrieve XML representations of projects, and
Modifier XT

ensions software lets you manipulate text, pictures, and boxes
(among other things). Telegraph XTensions software works with QuarkXPress
to allow designers to name boxes in template files so that those boxes can be
addressed by URLs and to control caching for individual items.

For more information about XT

, see Chapter 4, “XT

ver

Ser

ensions software included with QuarkXPress

ensions software,” and Chapter 5, “T

XTensions software.”

CHAPTER 1: GETTING ST

4

|

ARTED WITH QUARKXPRESS SERVER

elegraph

UNDERSTANDING QUARKXPRESS SERVER XTENSIONS SOFTWARE

THE QUARKXPRESS SERVER XTENSIONS APPLICATION PROGRAMMING INTERFACE (API)

In addition to the XTensions modules included with QuarkXPress Server, devel­opers can create custom XTensions software that add features. The complete
server XTensions Application Programming Interface (API) documentation is
available in the QuarkXPress Server XTensions Developer’s Kit (XDK).

The QuarkXPress Server XDK lets you create XTensions modules that provide
the following abilities:

• The ability to register request handlers

• The ability to register project providers

• The ability to register new render formats

• The ability to add items to the list of response properties, cookies, and HTTP
header items

• The ability to log messages in log files and in the status monitor

• The ability to initiate a new transaction to be processed by the server

• The ability to completely control how projects are processed by the server

In addition, QuarkXPress Server XTensions software can register for the
following basic callbacks:

• Pre-processing

• Content loading

• Layout modification

• Post-processing

• Removing slugs while running the QuarkXPress project renderer

• Analyzing the server after a transaction is complete

• Pre- and post-transaction callback

LAUNCHING QUARKXPRESS SERVER

QuarkXPress Server consists of a single executable that can be executed in two
modes. Both modes are available on Mac OS and Windows.

When executed in

console mode, QuarkXPress Server displays a limited user
interface for configuring the server. To access QuarkXPress Server in console
mode, double-click the program icon.

CHAPTER 1: GETTING ST

ARTED WITH QUARKXPRESS SERVER

5

|

LAUNCHING QUARKXPRESS SERVER

hen executed in no-UI mode,QuarkXPress Server displays no visible user

W
interface and must be controlled (started and stopped) from a command
prompt. Running QuarkXPress Server in no-UI mode will slightly improve
its performance. To access QuarkXPress Server in no-UI mode, launch the
application from the command line. For example:

• To launch QuarkXPress Server in no-UI mode on Mac OS, Control+click the
QuarkXPress Server application file and choose
the “QuarkXPress Server.exe” file from the
X11 terminal window, add “ –noui” to the end of the command, and press Enter.

• To launch QuarkXPress Server in no-UI mode from the command line on
Windows, use a command such as:

Server 7\QuarkXPress Server\QuarkXPress Server.exe -noui.

COMMAND LINE OPTIONS

QuarkXPress Server supports the following command-line options:

• The

noui option makes the server run without any user interface. This is the

normal mode for production use of QuarkXPress Server.

• The

-nonetwork parameter makes the server run without loading any network

interfaces; in this mode, the only transactions a server can run are those passed
to it by another process.

-tm parameter makes the transaction layer of the server mask exceptions

• The
into transaction errors.

-tt parameter makes the transaction layer of the server throw exceptions

• The
to the server layer.

Show Package Contents. Drag

Contents Þ MacOS folder to an open

C:\Program Files\Quark\QuarkXPress

EXIT CODES

When the server shuts down, QuarkXPress Server returns exit codes. The
“keepalive.sh” file (Mac OS) or “keepalive.bat” file (Windows) uses these
codes to check the type of QuarkXPress Server shutdown. If the exit code
indicates that QuarkXPress Server shut down unexpectedly, the “keepalive”
utilities automatically relaunch QuarkXPress Server.

Valid exit codes are as follows:

• QUARK DYNAMIC DOCUMENT SERVER_EXIT_NORMAL (0): The server
exited normally.

• QUARK DYNAMIC DOCUMENT SERVER_EXIT_EXCEPTION (6969): The server
exited as a result of an exception that was handled by the server layer.

QUARK DYNAMIC DOCUMENT SER

•
exited as a result of a startup problem. In this case, restarting does not solve
the problem; you must relaunch QLA.

• QUARK DYNAMIC DOCUMENT SERVER_EXIT_RESTART (6971): The server
exited as a result of a remotely requested restart.

• QUARK DYNAMIC DOCUMENT SERVER_EXIT_SHUTDOWN (6972):
The server exited as a result of a remotely requested shutdown.

CHAPTER 1: GETTING ST

6

|

VER_EXIT_ST

ARTED WITH QUARKXPRESS SERVER

ARTUP (6970): The server

SERVER CONFIGURATION DIALOG BOX

Chapter 2: The QuarkXPress
Server user interface

This chapter describes the QuarkXPress Server user interface and explains how

you can use it to configure and customize your QuarkXPress Server application

and manage your server XTensions modules. Menu items are covered in the

same order they display in the user interface, from left to right and top

to bottom.

When you open a dialog box in the QuarkXPress Server user interface, the HTTP
server pauses to prevent conflicts with any jobs that are being processed. When
you close the dialog box, the HTTP server starts again.

SERVER CONFIGURATION DIALOG BOX

The Server Configuration dialog box (QuarkXPress Server/Server menu)
lets you specify the document pool location and control cache memory sizes,
log options, HTTP settings, and other options related to the functioning of
QuarkXPress Server.

SERVER (TAB)

Server Configuration dialog box

The Server tab in the Server Configuration dialog box lets you control mem­ory and timing settings. You can also define the location of the document pool
and designate default documents for display.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

7

|

SERVER CONFIGURATION DIALOG BOX

Server tab of Server Configuration dialog box

ALLOW MEMORY CACHING (CHECK BOX)

Server Configuration dialog box Þ Server tab

Check Allow Memory Caching to store disk-based documents in a memory­resident cache. Documents from external document providers also use this
cache.

Allow Memory Caching is checked by default.

MAX MEMORY CACHE SIZE (FIELD)

Server Configuration dialog box Þ Server tab

In the Max Memory Cache Size field, enter the maximum memory size
allocated to the cache memory. The default value is 100MB. The acceptable
range of values is from 10MB to 1024MB.

All subrenderers in a master-subrenderer environment share the same
memory cache.

CONTENT LOADING TIMEOUT (FIELD)

Server Configuration dialog box Þ Server tab

In the Content Loading T

imeoutfield, enter the amount of time (in seconds)

the server should wait for a server XTensions module (or another document
provider) to load content asynchronously before timing out the transaction.
The default value is 120 seconds. Valid values are from 1 second to 3600 seconds.

T RENDER (AREA)

AUL

DEF

Server Configuration dialog box Þ Server tab

Use the Default Render area to specify the format in which QuarkXPress Server
renders QuarkXPress projects if the client does not specify a format. Y
change the render type using URL parameters in the HTTP request.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

8

|

ou can

ACE

SERVER CONFIGURATION DIALOG BOX

TYPE (DROP-DOWN MENU)

Server Configuration dialog box Þ Server tab

To indicate the default rendering format for the server, choose an option from
the

Default Rendering Type drop-down menu:

EPS Document: Returns an Encapsulated PostScript (EPS) file

•

JPEG: Returns a JPEG file

•

PDF: Returns a PDF file

•

PNG: Returns a Portable Network Graphics (PNG) file

•

PostScript: Returns a PostScript file

•

QuarkXPress Document: Returns a QuarkXPress project

•

Raw Custom: Returns a file in internal QuarkXPress format for use by server

•
XTensions software developers

•

RLE Raw Custom: Returns a file in internal QuarkXPress format (compressed
using Run Length Encoding) for use by server XTensions software developers

If a copy of QuarkXPress Server running on Mac OS renders a project that was
created in Mac OS and returns the project in QuarkXPress format, the result­ing project has no resource fork. (A resource fork is a hidden file that contains
information about the application that created a file.) You cannot preview a
project that does not have a resource fork, but such projects function normally
in all other respects.

You can set up helper applications on local systems to display files in
formats such as PostScript on the screen, but this feature is not built into
QuarkXPress Server.

SCALE (FIELD)

Server Configuration dialog box Þ Server tab

In the Scale field, enter the default scale at which QuarkXPress Server should
render projects.

Scale is not available for PDF

, PostScript, Personalized Print Markup Language

(PPML), and QuarkXPress project rendering formats.

DISABLE QUARKXPRESS DOCUMENT RETURN (CHECK BOX)

Server Configuration dialog box Þ Server tab

Check Disable QuarkXPress Document Return to prevent QuarkXPress Server
from returning QuarkXPress projects to clients.

DOCUMENT POOL (AREA)

Server Configuration dialog box Þ Server tab

Use the Document Pool area to control location and configuration of the
document pool.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

9

|

SERVER CONFIGURATION DIALOG BOX

ENABLE FILE SYSTEM DOCUMENT POOL (CHECK BOX)

Server Configuration dialog box Þ Server tab

Check Enable File System Document Pool to enable the Document Root field
and the

Browse button. This box is checked by default.

To specify the document pool directory, click

Browse or enter a path in the

Document Root field.

The document pool directory can be on the same computer as the QuarkXPress
Server application or on a file server that is accessible on a Local Area Network
(LAN) or a Wide Area Network (WAN), as long as the drive containing the pool
can be mounted.

You cannot specify the QuarkXPress Server application folder as the document
pool directory.

ALLOW REMOTE CHANGES (CHECK BOX)

Server Configuration dialog box Þ Server tab

Check Allow Remote Changes to allow other applications to upload items to
or delete items from the document pool. You can upload or delete QuarkXPress
projects and their associated files. This box is checked by default.

FORCE SERVED DOCUMENTS CLOSED (CHECK BOX)

Server Configuration dialog box Þ Server tab

Check Force Served Documents Closed to make QuarkXPress Server close proj­ects from the document pool after it renders them, regardless of the Telegraph
XTensions software setting. Uncheck

Force Served Documents Closed to keep

such projects open on the server. This box is checked by default.

The ability of project to remain open is determined by whether Allow

Document to Stay Open

QuarkXPress

Preferences dialog box when Telegraph XTensions software

is checked in the QuarkXPress Server pane of the

uploads the file. (For more information, see Chapter 5, “Telegraph XTensions
software.”) If a project is not set to remain open by the Telegraph XTensions
software, unchecking

Force Served Documents Closed does not cause the

project to remain open.

Setting a project to remain open does not guarantee that the project will
be left open. This is because server memory and load requirements are also
involved. For example, if the server requires memory to open additional proj­ects, it might close a project that has been left open. The maximum number
of open projects is 32. This feature enhances performance, and the cache can
be cleared at any moment.

10

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SERVER CONFIGURATION DIALOG BOX

GENERATE HIERARCHY ON DOCUMENT UPLOAD (CHECK BOX)

Server Configuration dialog box Þ Server tab

Check Generate Hierarchy on Document Upload to make QuarkXPress Server
automatically generate any file hierarchy that is requested when a user uploads
content to the document pool from Telegraph XTensions software. For more
information, see Chapter 5, “Telegraph XTensions software.” This box is
checked by default.

DOCUMENTS (AREA)

Server Configuration dialog box Þ Server tab

Use the Documents area of the Server tab to specify which HTML files should
display by default when a client accesses QuarkXPress Server, when errors occur,
and when access is denied to a client.

DEFAULT DOCUMENT (FIELD)

Server Configuration dialog box Þ Server tab

To specify which HTML file should display by default when a client accesses
QuarkXPress Server, enter the file’s path in the
click

Browse and navigate to the file. This file must be an HTML file.

Default Document field or

ERROR DOCUMENT (FIELD)

Server Configuration dialog box Þ Server tab

To specify which HTML file should display by default when QuarkXPress Server
cannot process a request, enter the file’s path in the
click

Browse and navigate to the file. This file must be an HTML file.

Error Document field or

Your error document can contain whatever information you like. QuarkXPress
Server also supports the following special tags:

• If you include an

<!--ERRORNUMBER--> comment in the file, QuarkXPress

Server replaces that comment with a number that identifies the particular
error that occurred.

• If you include an

<!--ERRORSTRING--> comment in the file, QuarkXPress Server

replaces that comment with details about the particular error that occurred.

NO ACCESS DOCUMENT (FIELD)

Server Configuration dialog box Þ Server tab

To specify which HTML file should display by default when a client is denied
access to a ser

Document

field or click Browse and navigate to the file. This file can contain

ver function or project, enter the file path in the

No Access

whatever information you like, but it must be an HTML file.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

11

|

SERVER CONFIGURATION DIALOG BOX

LOGGING (TAB)

Server Configuration dialog box

Click the Logging tab in the Server Configuration dialog box to control how
errors and transactions are logged.

Logging tab of Server Configuration dialog box

The log folder contains two log files: The transaction log and the error log. You
can configure the system to save the log folder to your computer or to a file
server that is accessible over a LAN or a WAN, as long as the drive containing
the folder can be mounted.

LOGGING ENABLED (CHECK BOX)

Server Configuration dialog box Þ Logging tab

Check Logging Enabled to enable the Log Folder field and then enter the path
to the folder or click

Browse and navigate to the folder.

You cannot specify the QuarkXPress Server application folder as the document
pool directory.

LOG ERRORS (CHECK BOX)

Server Configuration dialog box Þ Logging tab

Check Log Errors to set the system to record unsuccessful transactions in the
log file.

LOG TRANSACTIONS (CHECK BOX)

Server Configuration dialog box Þ Logging tab

Check Log Transactions to enter every non-error response returned from
transactions on QuarkXPress Server into the transaction log.

LOG DETAILED TIMING DATA (CHECK BOX)

Server Configuration dialog box Þ Logging tab

Depending on the render type, certain transactions must include transac­tion timing data. Check

Log Detailed Timing Data to include the following

transaction timing data (measured in milliseconds) in the transaction log for
each transaction:

Connection acceptance and closure time: The duration between the network

•
connection opening and closing time.

12

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SERVER CONFIGURATION DIALOG BOX

TTP request and body parsed time:The total time duration in which the fol-

• H
lowing operations are performed: The client connects to the server and sends
a request, timing starts, a request is parsed, QuarkXPress Server processes the
request, and timing stops.

•

QuarkXPress Server request processing time: Same as Connection acceptance
and closure time

Opening QuarkXPress document time: The time required to open a

•

, but timing starts after request parsing is complete.

QuarkXPress project for rendering.

Instantiate document time: The time required to carry out the dynamic

•
publishing process.

• Total of rendering process time: The total amount of time spent rendering
a project.

Time required to generate an image of the QuarkXPress document: The

•
time required for the generation of files that use JPEG, PNG, or any other
compressed format.

•

Closing QuarkXPress document time: The time required to close a
QuarkXPress project.

• Data ready and all sent to client: The difference between the time when all
data for the page return has been processed and is ready to be sent and the
time when the last bit of data is sent to the client.

Server XTensions software can be configured to add module-specific timing
entries to the transaction log.

LOG SERVER EVENTS (CHECK BOX)

Server Configuration dialog box Þ Logging tab

Check Log Server Events to record QuarkXPress Server events that are not
related to error conditions in the transaction log. Server events include
the following:

Server Started: The date and time at which the server was started.

•

Server Stopped: The date and time at which the server was stopped.

•

Errors Starting Up: The server records errors, such as issues loading XTensions

•
software, in the error log. In no-UI mode, errors that cause an alert to display
in the console mode are recorded in the error log.

Exceptions Caught (Windows only): Any exceptions logged by the server.

•

Application exception-type errors: An “exception masked” notice and a code.

•
You can use this information for troubleshooting.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

13

|

SERVER CONFIGURATION DIALOG BOX

LOG DOCUMENT PROBLEMS (CHECK BOX)

Server Configuration dialog box Þ Logging tab

Check Log Document Problems to include problem descriptions in transaction
log files. Logged problems include the following:

Missing Fonts: If fonts are missing from a project that has been requested for

•
rendering, a one-line description of each missing font is added to the error log.
If QuarkXPress Server receives a request to render a project and does not have
access to the fonts required by the project, it substitutes Helvetica (Mac OS) or
Arial (Windows). This behavior is the same as in QuarkXPress.

•

Missing SXTs: If a required server XTensions module is missing when a ren­dering request is received, a one-line description of each missing module is
added to the error log. If the name of the missing module is not returnable,
the XTensions module ID number is returned.

Text Encoding/Character Set Problems: If text is sent to a text box in the tem-

•
plate and the system does not have access to the correct font glyph, the issue
is logged. The log data indicates the character set that the system attempted
to convert. For example, the log entry might show that a request for Japanese
characters was sent to an English project.

LOG NON-CONFORMANT SXT DIALOG MESSAGES (CHECK BOX)

Server Configuration dialog box Þ Logging tab

Check Log Non-conformant SXT Dialog Messages to prevent server XTensions
modules from displaying dialog boxes.

HTTP (TAB)

Server Configuration dialog box

Click the HTTP tab in the Server Configuration dialog box to control port
and connection settings.

HTTP tab

14

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SERVER CONFIGURATION DIALOG BOX

ENABLE HTTP INTERFACE (CHECK BOX)

Server Configuration dialog box Þ HTTP tab

Check Enable HTTP Interface to activate the HTTP 1.0 server that is built in
to QuarkXPress Server and enable the other controls in this area.

PORT NUMBER (FIELD)

Server Configuration dialog box Þ HTTP tab

In the Port Number field, enter the port number of the HTTP server. The
acceptable range of values is from 1024 to 65,535 (Mac OS) or from 1 to 65,535
(Windows). When the HTTP server is initialized, an alert displays if this value
falls outside this range or if the specified port number is already in use. If
QuarkXPress Server is running in no-UI mode, an entry regarding this alert is
made in the log file. The default value for this field is 8080.

MAX CONNECTIONS (FIELD)

Server Configuration dialog box Þ HTTP tab

In the Max Connections field, enter the maximum number of rendering
requests to be recognized and processed by the QuarkXPress Server connec­tion queue. The acceptable range of values is from 1 to 16. The default value
for this field is 16.

MAX LISTENS (FIELD)

Server Configuration dialog box Þ HTTP tab

In the Max Listens field, enter the maximum number of requests to be queued
up for processing while waiting for an open connection. An alert displays if
this value exceeds the maximum number of listens. The acceptable range of
values is from 1 to 32. The default value for this field is 20.

DEFAULT BUFFER SIZE (FIELD)

Server Configuration dialog box Þ HTTP tab

In the Default Buffer Size field, enter the total size (in kilobytes) of the HTTP
buffer. The HTTP buffer is the size of the data block that is sent to the client
from the server as part of the HTTP response. The smaller the block size, the
less memory consumed by the application. Large blocks facilitate faster perfor­mance, but might cause memory shortages in other parts of the application.
The acceptable range of values is from 16KB to 256KB. The default value for
this field is 32KB.

CONNECTION TIMEOUT (FIELD)

Server Configuration dialog box Þ HTTP tab

In the Connection Timeout field, enter the total time in seconds before an
HTTP connection should time out. The client must send a request within this
period. The acceptable range of values is from 1 second to 32,767 seconds.
The default value for this field is 120 seconds.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

15

|

SERVER CONFIGURATION DIALOG BOX

REALM VERIF. FOR ADMIN. REQUESTS (CHECK BOX)

Server Configuration dialog box Þ HTTP tab

Check Realm Verif. for Admin. Requests to enable the User Name, Password,
and Confirm fields. These fields let youcontrol access to administrative parame­ters and features. You must enter valid values that contain at least four characters

User Name, Password, and Confirm fields, and you can enter up to 32

in the
characters. This box is unchecked by default.

USE CONNECTION FILTERS (CHECK BOX AND AREA)

Server Configuration dialog box Þ HTTP tab

Use this check box to grant or deny QuarkXPress Server access to IP addresses.

Check Use Connection Filters to enable controls that let you enter and
modify IP addresses and subnet masks in the connection filters list. This box
is unchecked by default.

Click

Insert to display the Insert Connection Filter dialog box, in which

you can enter an IP address between 1 and 254 and a subnet mask between 0
and 255.

Click

Modify to display the Modify Connection Filter dialog box, in which

you can specify an action for a particular IP address, edit an IP address, and
edit a subnet mask. Each field in the
accepts a value between 0 and 255. The default setting is

Modify Connection Filter dialog box

Deny Connection.

Click Remove to delete the selected IP address from the connection filters list.

Click or to move the selected IP address up or down in the connection
filters list.

If no rules have been applied to an IP address, you can select the IP address
and click

Connections

Allow Connections to allow the IP address to be used or click Deny

to prevent the IP address from being used. The “allow” and “deny”
actions are performed on IP addresses in the order they display in the connection
filters list.

The maximum number of allowed IP addresses/subnet masks is 128.

EMAIL (TAB)

Server Configuration dialog box

Click the Email tab in the Server Configuration dialog box to display controls
that let you set up automatic e-mail messages to warn of license expiration.

16

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SERVER CONFIGURATION DIALOG BOX

Email tab

SMTP SERVER (CHECK BOX)

Server Configuration dialog box Þ Email tab

Check SMTP Configuration to enable QuarkXPress Server to send an e-mail
to an administrator when the application’s QLA license expires. Checking this
box enables the other controls in this area. This box is unchecked by default.

SMTP SERVER (FIELD)

Server Configuration dialog box Þ Email tab

In the SMTP Server field, enter the domain name or IP address of the e-mail
server that QuarkXPress Server should use to send messages (for example,

mail.quark.com).

SMTP SERVER PORT (FIELD)

Server Configuration dialog box Þ Email tab

In the SMTP Server Port field, enter the port number of the e-mail server that
QuarkXPress Server should use to send messages. The acceptable range of values
is from 0 to 255. The default value for this field is 25.

FROM (E-MAIL ADDRESS) (FIELD)

Server Configuration dialog box Þ Email tab

In the From
QuarkXPress Ser

(Email Address)field, enter the source e-mail address the

ver application should use to send messages (for example,

[e-mail]).

TO (E-MAIL ADDRESS) (FIELD)

Server Configuration dialog box Þ Email tab

In the T

o (Email Address)field, enter the e-mail address to which the

QuarkXPress Server application should send messages (for example,

[e-mail]).

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

17

|

SERVER PREFERENCES

SERVER PREFERENCES

se the Preferencesdialog box (QuarkXPress Server

U

references)to set up

Þ P

default preferences for use when projects are created in QuarkXPress Server.

Many of these preferences come into play only when you create a project in
QuarkXPress Server. You cannot directly create projects in the QuarkXPress
Server user interface, but XTensions software can create projects.

APPLICATION PREFERENCES (CATEGORY)

QuarkXPress Server Þ Preferences

Changes to preferences in the Application category affect all projects. For
example, when you create a project using a server XTensions module or other
external software, preference settings in the

Application category are applied

to the new project. Application preferences include the following panes:

• The

Display pane

Input Settings pane

• The

XTensions Manager pane

• The

Font Mapping pane

• The

Deconstruct pane (displays only if Deconstructor XTensions software

• The
is loaded)

• The EPS pane

Full Res Preview pane

• The

Job Jackets™pane

• The

Modifier pane (displays only if Modifier XTensions software is loaded)

• The

PDF pane (displays only if PDF Filter XTensions software is loaded)

• The

Placeholders pane

• The

PSD Import pane

• The

Fraction/Price pane

• The

Picture Effects pane (displays only if QuarkVista™XTensions software

• The
is loaded)

DISPLAY (PANE)

QuarkXPress Server Þ Preferences

Use the Display pane to specify how TIFF files display on screen for all projects.

18

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

Preferences dialog box displaying Display pane

SERVER PREFERENCES

COLOR TIFFS (DROP-DOWN MENU)

QuarkXPress Server Þ Preferences Þ Display pane

From the Color TIFFs drop-down menu, choose the color depth of TIFF pic­tures in rendered images using QuarkXPress Server. The default value is

32-bit

on Mac OS and 24-bit on Windows.

• Choose 8-bit to create screen previews with 256 possible colors.

• Choose

16-bit (Mac OS only) to create screen previews with thousands of

possible colors.

• Choose

24-bit (Windows only) to create screen previews with millions of

possible colors.

• Choose

32-bit (Mac OS only) to create screen previews with millions of

possible colors, which lets you print 32-bit color TIFFs in PICT format to a

®

QuickDraw

printer.

The Color TIFFs settings are applied only to TIFF files that are uploaded to
the document pool; if a user prints a project that contains TIFF files that have
not been uploaded to the document pool, the TIFF files print only at 8 bits.
This setting affects only printed projects.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

19

|

SERVER PREFERENCES

GRAY TIFFS (DROP-DOWN MENU)

QuarkXPress Server Þ Preferences Þ Display pane

From the Gray TIFFs drop-down menu, choose the resolution for TIFF pictures
in rendered images using QuarkXPress Server. The default is 256 levels.

• Choose

16 levels to create screen previews with 16 levels of gray for fast

screen redraw.

• Choose

256 levels to create screen previews with 256 levels of gray from

pictures scanned at this level.

The Gray TIFFs settings are applied only to TIFF files that are uploaded to the
document pool; if a user prints a project that contains TIFF files that have not
been uploaded to the document pool, the TIFF files print only at 8 bits. This
setting affects only printed projects.

MONITOR PROFILE (DROP-DOWN MENU)

QuarkXPress Server Þ Preferences Þ Display pane

From the Color TIFFs drop-down menu, choose a profile that corresponds to
your monitor. Profiles can be placed in the default system profile folder or in
the “Profiles” folder in the QuarkXPress Server application folder.

INPUT SETTINGS (PANE)

QuarkXPress Server Þ Preferences

Use the Input Settings pane to customize the display of quotation marks and
the selection of characters used to specify page ranges.

ences

efer

Pr

20

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

dialog box displaying Input Settings pane

ACE

SERVER PREFERENCES

QUOTES (AREA)

QuarkXPress Server Þ Preferences Þ Input Settings pane

Use the Quotes area to choose a style for converting and entering quotation
marks. The preferences set in the

Quotes area of QuarkXPress Server override

the preferences set for a project.

Use the
with the

Format drop-down menu to specify the default characters to be used

Smart Quotes feature and Convert Quotes option in the Get Text

dialog box (File Þ Get Text). The default option is “”.

Smart Quotes to force QuarkXPress to replace feet (')and inches (")

Check
marks automatically with the specified quotation marks. This box is checked
by default.

PAGE RANGE SEPARATORS (AREA)

QuarkXPress Server Þ Preferences Þ Input Settings pane

Hyphens and commas are the default separators for indicating sequential and
nonsequential ranges in the
project. In the

Sequential and Nonsequential fields, enter new characters to

Pages field of the Print dialog box for a print

be used as separators when the project is rendered by QuarkXPress Server.
The preferences set in the

Page Range Separators area of QuarkXPress Server

override the preferences set for a project.

FONT FALLBACK (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Interactive pane

Check Font Fallback to make QuarkXPress Server try to provide an acceptable
representation of characters if the font required by those characters is not
available. This box is checked by default.

XTENSIONS MANAGER (PANE)

QuarkXPress Server Þ Preferences

Use the XTensions Manager pane to customize the built-in
XTensions Manager.

Preferences dialog box displaying the XTensions Manager pane

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

21

|

SERVER PREFERENCES

SHOW XTENSIONS MANAGER AT STARTUP (AREA)

QuarkXPress Server Þ Preferences Þ XTensions Manager pane

Use the Show XTensions Manager at Startup area to specify whether the
XTensions Manager dialog box displays when you launch QuarkXPress

Server, and under what circumstances. (XTensions software are add-on soft­ware modules that customize the feature set of QuarkXPress Server. You can
use the
software or sets of XTensions software directly from QuarkXPress Server.)

XTensions Manager utility to enable or disable individual XTensions

• Click

Always to display the XTensions Manager dialog box when you launch

QuarkXPress Server.

• Click When and check XTension folder changes to display the XTensions

Manager

dialog box during launch only after XTensions software has been

added to or removed from the “XTension” folder.

• Click

When and check Error occurs while loading XTensions to display the

XTensions Manager dialog box during launch only when QuarkXPress Server

encounters an issue loading XTensions software.

If the XTensions Manager dialog box displays as a result of the When Þ
Error occurs while loading XTensions setting, the server stops (as it does
when any dialog box displays). This can be a problem during an automatic
restart, because it will prevent the server from completely restarting.

FONT MAPPING (PANE)

QuarkXPress Server Þ Font Mapping

Use the Font Mapping pane to specify a substitute font for any font that is
not available for rendered images on QuarkXPress Server.

Preferences dialog box displaying Font Mapping pane

SPECIFY DEFAULT REPLACEMENT FONT (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Font Mapping

To specify which font should be used if a font required by a rendered project
is not available, check
font from the

Default Replacement Font drop-down menu. If you leave this

Specify Default Replacement Font and then choose a

box unchecked, Courier is substituted for missing fonts.

22

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SERVER PREFERENCES

DECONSTRUCT (PANE)

QuarkXPress Server Þ Deconstruct

Use the Deconstruct pane to set preferences to control which elements
are included in the XML representations of projects when you use the

deconstruct namespace.

Preferences dialog box displaying Deconstruct pane

The Deconstruct pane displays only if Deconstructor XTensions software is
loaded. For more information, see “Deconstructor XTensions software” in
Chapter 4, “XTensions software.”

DECONSTRUCT (AREA)

QuarkXPress Server Þ Preferences Þ Deconstruct pane

In the Deconstruct area, you can select whether XML generated by
Deconstructor XTensions software includes all boxes or only named
boxes. The default option is

Named Boxes.

DECONSTRUCTED ELEMENTS (AREA)

QuarkXPress Server Þ Preferences Þ Deconstruct pane

Use the Deconstructed Elements area to control which elements are included
in the XML representation of a project.

PICTURE BOXES (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Deconstruct pane

Check Picture Boxes to include XML descriptions of picture boxes.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

23

|

SERVER PREFERENCES

CONTENT (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Deconstruct pane

Check Content to include XML descriptions of content in picture boxes.

TEXT BOXES (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Deconstruct pane

Check Text Boxes to include XML descriptions of text boxes.

CONTENT (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Deconstruct pane

Check Content to include XML descriptions of content in text boxes.

• Click

• Click

With Attributes to include XML descriptions of content in text boxes.

With Style Sheets to include XML descriptions of style sheets applied to

content in text boxes.

GROUP BOXES (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Deconstruct pane

Check Grouped Boxes to include XML descriptions of grouped boxes and
enable subsequent deconstruct attributes.

ITEM WITHIN A GROUP (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Deconstruct pane

Check Items within a Group to include XML descriptions of items in groups.

PICTURE CONTENT (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Deconstruct pane

Check Picture Content to include XML descriptions of content in picture boxes.

TEXT CONTENT (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Deconstruct pane

Check Text Content to include XML descriptions of content in text boxes.

• Click

With Attributes to include XML descriptions of the attributes of content

in text boxes.

• Click

With Style Sheets to include XML descriptions of the style sheets applied

to content in text boxes.

EPS (PANE)

QuarkXPress Server Þ Preferences

Use the EPS pane to specify options related to imported EPS pictures.

ences

efer

Pr

dialog box displaying EPS pane

24

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SERVER PREFERENCES

PREVIEW (DROP-DOWN MENU)

QuarkXPress Server Þ Preferences Þ EPS pane

Use the Preview drop-down menu to control whether QuarkXPress Server
should generate a preview of an EPS file or use the preview (if any) embedded
in the file.

VIRTUAL MEMORY (FIELD) - MAC OS ONLY

QuarkXPress Server Þ Preferences Þ EPS pane

To increase the amount of virtual memory available for rendering large EPS
files, increase the value in this field.

FULL RES PREVIEW (PANE)

QuarkXPress Server Þ Preferences

Use the Full Res Preview pane to set preferences to display full-resolution
images of rendered projects.

Preferences dialog box displaying Full Res Preview pane

PREVIEW CACHE LOCATION (AREA)

QuarkXPress Server Þ Preferences Þ Full Res Preview pane

Use the Preview Cache Location area to set a location for a cache folder that
lists the various instances of an image with different resolutions.

• Click

QuarkXPress Server Preferences Folder to set the QuarkXPress Server

preferences folder as the cache folder.

• Click Other Folder and then click Select/Browse to use another folder as the
cache folder.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

25

|

SERVER PREFERENCES

MAXIMUM CACHE FOLDER SIZE (FIELD)

QuarkXPress Server Þ Preferences Þ Full Res Preview pane

Enter the maximum size of the cache folder in megabytes (MB) in the
Maximum Cache Folder Size field.

DISPLAY FULL-RESOLUTION PREVIEWS FOR (AREA)

QuarkXPress Server Þ Preferences Þ Full Res Preview pane

Use the Display Full Resolution Previews for area to set preferences to display
images with full resolution.

• Click

• Click

All Full Resolution Previews to display all images in full-resolution mode.

Selected Full Resolution Previews to display only selected images in

full-resolution mode.

DISABLE FULL RESOLUTION PREVIEWS ON OPEN (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Full Res Preview pane

Check Disable Full Resolution Previews on Open to disable full-resolution
mode of images when a project opens.

JOB JACKETS (PANE)

QuarkXPress Server Þ Preferences Þ Job Jackets

Use the Job Jackets pane to to specify preferences for automatic layout
evaluation and to indicate a default location for Job Jackets files.

Preferences dialog box displaying Job Jackets pane

26

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SERVER PREFERENCES

LAYOUT EVALUATION (AREA)

QuarkXPress Server Þ Preferences Þ Job Jackets pane

Use the options in the Layout Evaluation area to control when QuarkXPress
Server automatically executes the
mand. For example, by checking

File Þ Job Jacket Þ Evaluate Layout com-

On Output, you can make sure that you

always evaluate a layout before the layout is rendered. This area includes the
following options:

•

On Open

• On Save

• On Close

• On Output

JOB JACKET LOCATION (AREA)

QuarkXPress Server Þ Preferences Þ Job Jackets pane

Use the options in the Job Jacket Location area to specify where Job Jackets
files are stored by default.

• To save Job Jackets files in the default location, click

Shared Job Jackets

. The default location is the “Documents” folder on Mac OS

Use Default Folder for

and the “My Documents” folder on Windows.

• To change the location where Job Jackets are stored by default, click

Folder

, click Select/Browse, and navigate to the target folder.

MODIFIER (PANE)

QuarkXPress Server Þ Preferences Þ Modifier pane

Use the Modifier pane to set preferences pertaining to the way Modifier
XTensions software updates text in projects.

The Modifier pane displays only if Modifier XTensions software is loaded.
For more information, see “Modifier XTensions software” in Chapter 4,
“XTensions software.”

Other

Preferences dialog box displaying Modifier pane

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

27

|

SERVER PREFERENCES

AMOUNT BY WHICH TEXT WILL INCREASE/DECREASE (FIELD)

QuarkXPress Server Þ Preferences Þ Modifier pane

In the Amount by which Text will Increase/Decrease field, enter the
percentage by which Modifier XTensions software can increase or decrease
text size when the parameter
field are from 0% to 20%. For example, if the font size in use is 10pt, and
you enter 20% in this field, the font size can vary from 8pt to 12pt when

<FITTEXTTOBOX> is used.

FONT SIZE (AREA)

QuarkXPress Server Þ Preferences Þ Modifier pane

In the Font Size Min and Max fields, enter the minimum and maximum
font size that the Modifier parameter
The default values are “2pt”

The value of the <SIZE> parameter does not override the value in the Amount
by which the Text will Increase/Decrease field.

ALLOW TEXT TO GROW (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Modifier pane

Check Allow Text to Grow to allow the Modifier parameter <FITTEXTTOBOX>
to increase the font size of text in a text box.

<FITTEXTTOBOX> is used. Valid values for this

<SIZE> can apply to text in a text box.

(Min) and “720pt” (Max).

ADJUST OTHER FONT ATTRIBUTES (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Modifier pane

Check Adjust Other Font Attributes to enable the font attributes in this area.
You can then use the check the boxes to allow Modifier XTensions software to

Horizontal Vertical Scale, Tracking Amount, and Baseline Shift for text.

set

PDF (PANE)

QuarkXPress Server Þ Preferences Þ PDF

Use the PDF pane to set preferences for rendering in PDF format.

28

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

Preferences dialog box displaying PDF pane

SERVER PREFERENCES

The PDF pane displays only if PDF Filter XTensions software is loaded.
For more information, see “PDF Filter XTensions software” in Chapter 4,
“XTensions software.”

PDF WORKFLOW (AREA)

QuarkXPress Server Þ Preferences Þ PDF pane

Use the PDF Workflow area to set a location for PDF files:

• Click PDF Direct to generate PDF output in the browser. This is the
default option.

• Click PDF to Folder to generate and save PDF files to a folder. Click Select/

Browse

choose a default name for PDF files from the

Click

•

to specify a location for the folder in the Watched Folder field, and

Default Name scroll list.

PostScript File for Later Distilling to generate a PostScript fi

le. Click

Select/Browse to specify a location for the folder in the Watched Folder

eld, and choose a default name for PostScript fi

fi

les from the

Default Name

scroll list.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

29

|

SERVER PREFERENCES

ERROR SETTINGS (AREA)

QuarkXPress Server Þ Preferences Þ PDF pane

Use the Error Settings area to specify whether and where PDF-generation and
PostScript-generation errors are logged.

LOG ERRORS (CHECK BOX)

QuarkXPress Server Þ Preferences Þ PDF pane

Check Log Errors to log PDF-generation and PostScript-generation errors.
Checking this box enables the

USE LOG FOLDER (CHECK BOX)

QuarkXPress Server Þ Preferences Þ PDF pane

To specify where errors should be logged, check Use Log Folder and then click
Select/Browse and navigate to the target folder. If you do not check this box,

log files are stored in the watched folder for PDF generation, as defined in the
PDF pane.

In Mac OS, you can define the amount of memory your system allocates for
rendering PDF files by entering a value in the Virtual Memory field.

PLACEHOLDERS (PANE)

QuarkXPress Server Þ Preferences

Use the Placeholders pane to customize text and text node placeholders.
(Placeholders are used by XML Import XTensions software.)

Use Log Folder check box.

Preferences dialog box displaying Placeholders pane

TEXT PLACEHOLDER (AREA)

QuarkXPress Server Þ Preferences Þ Placeholders pane

Use the Color button in the Text Placeholder area to specify the color of the
placeholders in the layout. Choose a shade percentage for the color from the
Shade drop-down menu.

TEXTNODE PLACEHOLDER (AREA)

QuarkXPress Server Þ Preferences Þ Placeholders pane

Use the Color button in the T
text node placeholders in the layout. Choose a shade per
from the

30

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

Shade drop-down menu.

extNode Placeholder

ACE

area to specify the color of

centage for the color

SERVER PREFERENCES

PSD IMPORT (PANE)

QuarkXPress Server Þ Preferences

Use the PSD Import pane to control where previews of imported PSD files are
cached and how large the cache is allowed to become.

Preferences dialog box displaying PSD Import pane

LOCATION (AREA)

QuarkXPress Server Þ Preferences Þ PSD Import pane

Use the controls in the Location area to specify the location of the folder where
previews for imported PSD pictures are stored:

• To use the QuarkXPress Server Preferences folder, click

Preferences Folder

• To use a different folder, click

.

Other Folder, then click Select/Browse and

QuarkXPress

navigate to the target folder.

MAXIMUM CACHE FOLDER SIZE (FIELD)

QuarkXPress Server Þ Preferences Þ PSD Import pane

To indicate the maximum allowable cache folder size, enter a value in this
field. When this value is reached, QuarkXPress Server begins removing files
from the cache.

CLEAR CACHE (FIELD)

QuarkXPress Server Þ Preferences Þ PSD Import pane

To clear the PSD Import preview cache, click Clear Cache.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

31

|

SERVER PREFERENCES

FRACTION/PRICE (PANE)

QuarkXPress Server Þ Preferences Þ Fraction.Price

Use the Fraction/Price pane to set preferences for fractions in text.

Preferences dialog box displaying Fraction/Price pane

NUMERATOR (AREA)

QuarkXPress Server Þ Preferences Þ Fraction/Price pane

Use the Numerator area to set preferences for the numerator of fractions
in text.

• In the

Offset field, enter the offset percentage for the numerator.

• In the VScale field, enter the percentage of vertical scaling of the numerator.

• In the HScale field, enter the percentage of horizontal scaling of the numerator.

• In the Kern field, enter the kern value for the numerator.

DENOMINATOR (AREA)

QuarkXPress Server Þ Preferences Þ Fraction/Price pane

Use the Denominator area to set preferences for the denominators of fractions
in text.

In the

•

• In the

• In the

Offset fi

VScale field, enter the percentage of vertical scaling for the denominator.

HScale field, enter the percentage of horizontal scaling for

eld, enter the offset percentage for the denominator.

the denominator.

In the Kernfi

•

eld, enter the kerning value for the numerator

.

32

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SERVER PREFERENCES

SLASH (AREA)

QuarkXPress Server Þ Preferences Þ Fraction/Price pane

Use the Slash area to set preferences for slashes in fractions.

• In the Offset field, enter the offset percentage for slashes.

• In the

• In the

• Check

VScale field, enter the percentage of vertical scaling for slashes.

HScale field, enter the percentage of horizontal scaling for slashes.

Fraction Slash to maintain the type size in fractions.

PRICE (AREA)

QuarkXPress Server Þ Preferences Þ Fraction/Price pane

Use the Price area to set preferences for subscript and superior text.

• Check Underline Cents to underline the superior text.

• Check

Delete Radix to suppress commas or periods in prices.

PICTURE EFFECTS (PANE)

QuarkXPress Server Þ Preferences Þ Picture Effects pane

Use the Picture Effects pane to set the location of existing picture effects to
apply to the images. You can also set a cache location for image processing.

The Picture Effects pane displays only if QuarkVista XTensions software
is loaded. For more information, see “QuarkVista XTensions software” in
Chapter 4, “XTensions software.”

Preferences dialog box displaying Picture Effects pane

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

33

|

SERVER PREFERENCES

PICTURE EFFECT PRESETS LOCATION (AREA)

QuarkXPress Server Þ Preferences Þ Picture Effects pane

Use the Picture Effects Presets Location area to set the location to save
picture presets.

QuarkXPress Server Preferences Folder to set the QuarkXPress Server

Click
“Preferences” folder as the location for using existing picture effects.

To use a different folder, click

Other Folder, click Select/Browse, and navigate

to the target folder.

PROJECT PREFERENCES (CATEGORY)

QuarkXPress Server Þ Preferences

Changes to preferences in the Project category affect all layouts in the active
project. If you change project preferences with no projects open, the new pref­erences become the default settings for all new projects. Project preferences
include the following panes:

• The General pane

• The XML Import pane (displays only if XML Import XTensions software
is loaded)

GENERAL (PANE)

QuarkXPress Server Þ Preferences Þ General

Use the General pane to to specify default settings for automatic picture import,
single layout mode, and OpenType

®

kerning (for OpenType fonts).

Preferences dialog box displaying General pane

AUTO PICTURE IMPORT (DROP-DOWN MENU)

QuarkXPress Server Þ Preferences Þ General pane

Use the Auto Picture Importarea to control whether QuarkXPress Ser
automatically updates pictures that have been modified since a project was
last opened. QuarkXPress Server can locate pictures for which there is a path
between the picture fi

o enable the Auto Picture Import feature, choose

T

•

le and the QuarkXPress layout.

Server opens a project, the application automatically reimports modified
pictures into each layout using the modified files. All content specifications
(scaling, positioning, and so on) are retained.

34

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ver

On. When QuarkXPress

ACE

SERVER PREFERENCES

To disable the Auto Picture Import feature, choose Off

•

.

• To make QuarkXPress Server display an alert before importing modified pic-

ures, choose Verify.The alert gives you the option of opening the project

t
with or without updating the pictures. If you choose to update the pictures,
QuarkXPress Server displays the

Missing/Modified Pictures dialog box. You

can use this dialog box to view the affected pictures in each layout and to
selectively update the pictures.

If the Missing/Modified dialog box displays as a result of Verify being checked,
the server stops (as it does whenever any dialog box displays). This can be a
problem during an automatic restart, because it will prevent the server from
completely restarting.

SINGLE LAYOUT MODE (CHECK BOX)

QuarkXPress Server Þ Preferences Þ General pane

Checking Single Layout Mode will cause new projects to be created in
single-layout mode. Only the project name is used when saving PDF files
or in AppleScript references.

USE OPENTYPE KERNING (CHECK BOX)

QuarkXPress Server Þ Preferences Þ General pane

Check Use OpenType Kerning to use OpenType kerning with OpenType fonts.

XML IMPORT (PANE)

QuarkXPress Server Þ Preferences Þ XML Import

The controls in the XML Import pane are not relevant to QuarkXPress Server
and should be ignored.

DEFAULT PRINT LAYOUT (CATEGORY)

QuarkXPress Server Þ Preferences

The Default Print Layout category includes the following panes:

General pane

• The

Measurements pane

• The

Paragraph pane

• The

Character pane

• The

ools

The

T

•

• The

• The

• The

pane

Trapping pane

Color Manager pane

Layers pane (displays only if QuarkXPress Server Layers XTensions

software is loaded)

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

35

|

SERVER PREFERENCES

GENERAL (PANE)

QuarkXPress Server Þ Preferences

Use the General pane to specify various default settings for page layout.

Preferences dialog box displaying General pane

GUIDES (AREA)

QuarkXPress Server Þ Preferences Þ General pane

Use the Guides area to specify whether ruler guides and page guides are placed
in front of or behind all items on a page.

• Click

In Front to place ruler and page guides in front of all items on a page.

This is the default option.

• Click Behind to place ruler and page guides behind all items on a page.

In the Snap Distance field, enter the distance at which objects snap to page
guides. The default value is 6.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

1 to 216 point 1

HYPERLINKS (AREA)

QuarkXPress Server Þ Preferences Þ General pane

Use the Hyperlinks area to choose the color for anchor icons and hyperlinks.
Anchor icon colors are available for Print and Web layouts, whereas hyperlink
colors are available for Print layouts only. You might want to choose anchor and
hyperlink colors for a Print layout if you are planning to render that layout as
a PDF file.

36

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SERVER PREFERENCES

MASTER PAGE ITEMS (AREA)

QuarkXPress Server Þ Preferences Þ General pane

A master page item is an item that is automatically placed on a layout page
when you apply a master page. When you apply a new master page to a lay­out page, unmodified master items (placed by the original master page) on a
layout page are deleted, but modified master items might not be.

• Click

Keep Changes to keep modified master items on layout pages when a

new master page is applied. The items that are kept are no longer master items.
Keep Changes is the default option.

• Click

Delete Changes to delete modified master items on layout pages when

a new master page is applied.

FRAMING (AREA)

QuarkXPress Server Þ Preferences Þ General pane

Use the Framing area to specify whether frames are placed inside or outside
text and picture boxes.

• Click

• Click

Inside to place the frame inside the box. Inside is the default option.

Outside to place the frame outside the box, increasing the box’s width and

height. The frame cannot extend beyond a constraining box or the pasteboard.

AUTO PAGE INSERTION (DROP-DOWN MENU)

QuarkXPress Server Þ Preferences Þ General pane

From the Auto Page Insertion drop-down menu, determine whether pages
are inserted automatically to contain text overflow from an automatic text
box or a chain of text boxes (on a page associated with a master page that
contains an automatic text box). You can also use the Auto Page Insertion
drop-down menu to determine where pages must be inserted.

• Choose

• Choose

Off to disable Auto Page Insertion.

End of Story to place new pages immediately after the page containing

the last overflowing text box in the chain. Inserted pages use the master page
of the page containing the overflow. It is the default option.

• Choose

End of Section to place new pages at the end of the section in which the

overflow occurs. Inserted pages use the master page of the last page in the section.

• Choose

End of Document to place new pages at the end of the layout. Inserted

pages use the master page of the layout’s last page.

Text overflow causes pages to be automatically inserted only if (1) Auto Page
Insertion is enabled, (2) the master page that is used has an automatic text
chain (as indicated by the intact chain icon in the upper left corner of the
master page), or (3) the overfl

ow is either from the text box defined on the
master page as the automatic text box or from a chain of at least two text boxes.
If there is no automatic text chain on the applied master page (indicated by the
broken chain icon, QuarkXPress Ser

ver does not add pages during overfl

ow

regardless of the Auto Page Insertion setting.

,

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

37

|

SERVER PREFERENCES

MEASUREMENTS (PANE)

QuarkXPress Server Þ Preferences

Use the Measurements pane to specify default measuring units.

Preferences dialog box displaying Measurements pane

HORIZONTAL, VERTICAL (DROP-DOWN MENUS)

QuarkXPress Server Þ Preferences Þ Measurements pane

From the Horizontal and Vertical drop-down menus, choose the measurement
system for horizontal and vertical values.
the left to the right of the layout.
the bottom.

Horizontal values are applied from

Vertical values are applied from the top to

SYSTEM ABBREVIATION MEASUREMENT

Inches in or " inches in eighths

Inches

in or " with inches in tenths

decimal a decimal

Picas p 1/6" or 12pt

Points pt 1/72"

Millimeters mm 0.04"

Centimeters cm 0.39"

Ciceros c 0.179"

Agates ag 0.071"

POINTS/INCH (FIELD)

QuarkXPress Server Þ Preferences Þ Measurements pane

In the Points/Inch fi

eld, enter a value that forms the basis for all point and
pica measurements and for all point and pica-to-inch conversions. The default
value is 72 points per inch. However

, the traditional typographic standard used
on most metal typographic rulers is usually approximately 72.27 or 72.307
points per inch.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

60pt to 80pt

points

.001

38

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SERVER PREFERENCES

CICEROS/CM (FIELD)

QuarkXPress Server Þ Preferences Þ Measurements pane

In the Ciceros/cm field, enter a ciceros-to-centimeter conversion value.
The default value is 2.197.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

2c to 3c ciceros .0001

ITEM COORDINATES (BUTTONS)

QuarkXPress Server Þ Preferences Þ Measurements pane

Use the Item Coordinates buttons to determine the functionality of the
horizontal ruler.

Item Coordinates are applicable only to Print layouts.

• Click Page to start the horizontal ruler from zero for each page. This is the

default setting.

• Click

Spread to continue the horizontal ruler across the layout.

PARAGRAPH (PANE)

QuarkXPress Server Þ Preferences

Use the Paragraph pane to specify how paragraph formats such as auto leading
are calculated in QuarkXPress Server when projects are created on the fly.

ences

Prefer

dialog box displaying Paragraph pane

LEADING (AREA)

QuarkXPress Server Þ Preferences Þ Paragraph pane

Use the Leading area to defi

ne the distance between text baselines

in paragraphs.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

39

|

SERVER PREFERENCES

MODE (BUTTONS)

QuarkXPress Server Þ Preferences Þ Paragraph pane

Using the Mode buttons, you can specify the leading method used to space
lines of text.

• Click

Typesetting for leading to be measured upward from the baseline on one

line of text to the baseline of the line above. This is the method preferred by
most typesetters and is selected by default.

• Click

Word Processing for leading to be measured downward from the top of

the ascent on one line of text to the top of the ascent on the line below it.

AUTO LEADING (FIELD)

QuarkXPress Server Þ Preferences Þ Paragraph pane

In the Auto Leading field, enter the line spacing percentage. Unlike paragraphs
with absolute leading (which applies identical line spacing above every line),
paragraphs with auto leading can include lines with different leading when
different fonts and font sizes are mixed in the same paragraph.

Auto leading starts with a base amount of leading, which is calculated by exam­ining the

ascent and descent values built in to the fonts used in an auto-leaded

line and the line above it; however, the user-specified text size is the major
factor that determines this base amount. Finally, any value you specify in the
Auto Leading field is added to the base amount to arrive at the total amount
of leading.

MAINTAIN LEADING (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Paragraph pane

With Maintain Leading, you can control the placement of a line of text that
falls immediately below an obstruction in a column or box. Check

Leading

Uncheck
the obstruction or any applied runaround value

to place the line’s baseline according to its applied leading value.

Maintain Leading to place the ascent of the line at the bottom of

(Item Þ Runaround). This

Maintain

box is checked by default.

BASELINE GRID (AREA)

QuarkXPress Server Þ Preferences Þ Paragraph pane

A baseline grid is a layout-wide grid; you can lock the baselines of text in
paragraphs to this grid. When you lock text baselines in adjacent columns
to the grid, the baselines align across columns.

• In the

Start field, enter how far from the top of the page the first line of the grid

must be placed. The default value is 0.5 mm.

• In the

Increment field, enter the space between the grid’s baselines. The default

value is 12pt.

INCREMENT MEASUREMENT SMALLEST
RANGE SYSTEM INCREMENT

5pt to 144pt points .001

40

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SERVER PREFERENCES

METHOD (DROP-DOWN MENU)

QuarkXPress Server Þ Preferences Þ Paragraph pane Þ
Hyphenation area

From the Method drop-down menu in the Hyphenation area, choose a
method to hyphenate paragraphs automatically for the chosen languages.
The setting you choose affects only paragraphs for which

(Server/QuarkXPress Server

Þ Document Controls Þ H&Js) is enabled.

Auto Hyphenation

• Choose

Standard to hyphenate using the algorithm built in to versions of

QuarkXPress earlier than QuarkXPress 3.1.

• Choose

Enhanced to hyphenate using the algorithm built in to versions of

QuarkXPress later than QuarkXPress 3.1.

• Choose
resorting to the same algorithm as the one used for the

Expanded to check any built-in hyphenation dictionaries before

Enhanced option.

This option was added in QuarkXPress 4.0 and is the default method for
projects created in QuarkXPress 6.5.

• Choose

Extended 2 to use algorithms using third-party Dieckman resources.

Projects created in earlier versions of QuarkXPress maintain their hyphenation
method (

Standard or Enhanced) when opened in a later version. If you choose

Expanded for these projects, text reflow might occur.

CHARACTER (PANE)

QuarkXPress Server Þ Preferences

Use the Character pane to specify how mathematically calculated typographical
styles such as

Superscript and Subscript are created in QuarkXPress Server.

Pr

efer

ences

dialog box displaying Character pane

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

41

|

SERVER PREFERENCES

SUPERSCRIPT (AREA)

QuarkXPress Server Þ Preferences Þ Character pane

Use the Superscript area to control the placement and scale (size) of
superscript characters.

• In the

Offset field, enter how far below the baseline QuarkXPress Server places

a superscript character. The

Offset value is measured as a percentage of font

size. The default value is 33%.

• In the VScale field, enter the vertical size of the character. This value is measured
as a percentage of the font size.

• In the

HScale field, enter the horizontal size of the character. This value is

measured as a percentage of the normal character width (as specified by the
font designer). The default value for both scales is 100%.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

0% to 100% percent .1

SUBSCRIPT (AREA)

QuarkXPress Server Þ Preferences Þ Character pane

Use the Subscript area to control the placement and scale (size) of
subscript characters.

• In the

Offset field, enter how far below the baseline QuarkXPress Server places

a subscript character. The

Offset value is measured as a percentage of font size.

The default value is 33%.

• In the

VScale field, enter the vertical size of characters. This value is measured

as a percentage of the font size. The default value is 100%.

• In the

HScale field, enter the width of characters. This value is measured as a

percentage of the normal character width (as specified by the font designer).
The default value is 100%.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

0% to 100% percent .1

SMALL CAPS (AREA)

QuarkXPress Server Þ Preferences Þ Character pane

Use the Small Caps area to control the scale of characters with the Small Caps
type style applied to them.

• In the VScale field, enter the vertical size of the character. This value is measured
as a percentage of font size. The default value is 75%.

• In the HScale field, enter the width of the character. This value is measured as
a percentage of the normal character width (as specified by the font designer).
The default value is 75%.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

0% to 100% percent .1

42

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SERVER PREFERENCES

SUPERIOR (AREA)

QuarkXPress Server Þ Preferences Þ Character pane

Use the Superior area to control the scale of superior characters.

• In the VScale field, enter the vertical size of the character. This value is measured
as a percentage of font size. The default value is 50%.

• In the

HScale field, enter the width of the character. This value is measured as

a percentage of the normal character width (as specified by the font designer).
The default value is 50%.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

0% to 100% percent .1

LIGATURES (AREA) — MAC OS ONLY

QuarkXPress Server Þ Preferences Þ Character pane

Use the Ligatures area to use ligatures built in to a font. A ligature is a typo­graphic convention in which certain characters are combined into a single
character. Most fonts designed for the Mac OS contain ligatures for the character
“f” followed by the character “i,” and “f” followed by the the character “l.”

• Check Ligatures to combine all instances of “f” followed by “i” and “f” followed
by “l” into ligatures. You can edit and check the spelling of words that contain
ligatures as if the ligatures were separate characters. Ligatures is unchecked
by default.

When you check

Above

field, enter the kerning or tracking value (measured in 1/200 em space

Ligatures, the Break Above field is enabled. In the Break

increments) above which characters are not combined into ligatures. For
example, a headline with a large tracking value would probably not contain
ligatures. The default value is 1.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

0 to 10 .005 (1⁄200) em space .001

• Check

Not “ffi” or “ffl” to prevent the last two letters in “ffi” and “ffl” (as in

“office” and “waffle”) from being combined into ligatures. Three-character
ligatures for these combinations, common in traditional typesetting systems,
are not standardized in fonts designed for Mac OS; therefore, some typogra­phers prefer to keep all three letters separate rather than combine only two of
them. This option is unchecked by default.

AUTO KERN ABOVE (CHECK BOX AND FIELD)

QuarkXPress Server Þ Preferences Þ Character pane

Check Auto Kern Above to use kerning tables, which are built in to most fonts,
to control inter-character spacing.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

43

|

SERVER PREFERENCES

n the Auto Kern Abovefield, enter the point size above which to use

I
automatic kerning.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

2pt to 720pt various .001

STANDARD EM SPACE (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Character pane

An em space consists of two en spaces. Check Standard Em Space to specify
an em space equivalent to the point size of the text (for example, 24pt text
has a 24pt em space).

Uncheck

Standard Em Space to use the width of the two zeros in the current

font as the em space width. This box is unchecked by default.

FLEX SPACE WIDTH (FIELD)

QuarkXPress Server Þ Preferences Þ Character pane

A flexible space is a user-modifiable variation of a standard en space.
Typographers use it when a standard space is not aesthetically appealing.

In the

Flex Space Width field, enter the desired width of a flexible space. The

Flex Space Width value is expressed as a percentage of the normal en space for

a given font and font size. The default value is 50%.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

0% to 400% percent .1

ACCENTS FOR ALL CAPS (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Character pane

Check Accents for All Caps to specify whether to include accent marks on
accented characters to which the

All Caps type style is applied. It is checked

by default.

The Accents for All Caps check box applies to projects created in
QuarkXPress 5.0 or later. To update the text flow in earlier versions, press Option
(Mac OS) or Alt (Windows) while you click Open in the Open dialog box.

TOOLS (PANE)

QuarkXPress Server Þ Preferences Þ Tools

The controls in the T

ools

pane are not relevant to QuarkXPress Server and

should be ignored.

TRAPPING (PANE)

QuarkXPress Server Þ Preferences

Use the Trapping pane to specify default settings for the way QuarkXPress
Server traps colors and objects when you color-separate a Print layout.

44

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SERVER PREFERENCES

Preferences dialog box displaying Trapping pane

TRAPPING METHOD (AREA)

QuarkXPress Server Þ Preferences Þ Trapping pane

Use the Trapping Method drop-down menu to choose the method QuarkXPress
Server uses to determine the trapping relationship between object colors and
background colors.

• Choose

Absolute to trap using the values in the Auto Amount and

Indeterminate fields according to the object and background colors

involved. If the object color is dark, the background chokes the object
color by the
spread into the background by the

Auto Amount value. If the object color is light, the object is

Auto Amount value. Absolute is the

default option.

• Choose Proportional to trap using the value in the Auto Amount field mul­tiplied by the difference between the luminosity (lightness or brightness) of
the object color and background color.

Proportional trapping compares the

luminosity of the object color and background color to determine how different
they are and applies trapping accordingly.

• Choose

Knockout All to turn off trapping.

PROCESS TRAPPING (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Trapping pane

Check Process Trapping to trap each process separation plate individually
when a page contains overlapping process colors. When you print color sepa­rations, QuarkXPress Server compares the darkness of each process component
of an object color to the darkness of the corresponding process component of
the background color and traps accordingly. For example, the shade of cyan in
an object color is compared with the shade of cyan in the background color;
similar comparisons are made for the other plates that are used for output.
This option is checked by default.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

45

|

SERVER PREFERENCES

hen working with QuarkXPress Server:

W

When adjoining process colors have an absolute trapping relationship and

•

Process Trapping is checked, QuarkXPress Server divides the Auto Amount
trapping

of the color on each plate (as shown in the table). Dividing the value among
plates creates a smoother trap while providing the same area of overlap.

COLOR OBJECT BACKGROUND TRAP TRAP

C 70% 30%

M 30% 50%

Y 70% 80%

K 20% 15%

• When abutting process colors have a proportional trapping relationship,
QuarkXPress Server multiplies the Auto Amount value specified in the
Trapping pane by the difference in darkness between the object color and
the background color. The resulting trapping value is then applied the same
way as adjoining colors for colors with absolute trapping relationships.

value in half and applies the resulting value to the darker component

ABSOLUTE PROPORTIONAL

1

+

⁄2 trap amount Auto Amount

(70%–30%)÷2

1

–

⁄2 trap amount Auto Amount

(30%–50%)÷2

1

–

⁄2 trap amount Auto Amount

(70%–80%)÷2

1

+

⁄2 trap amount Auto Amount

(20%–15%)÷2

Uncheck

Process Trapping to trap all process components equally using the

trapping value associated with the object color relative to the background color.

For text up to 24pt and small items (dimensions up to 10pt), QuarkXPress
Server attempts to preserve the item’s shape during process trapping by not
allowing automatic spreads or chokes when the item’s shape would be com­promised. QuarkXPress Server attempts to preserve item shape by comparing
the darkness of each process component of an item to the darkness of its
entire background. A spread is applied only when the process components of
an item are less than or equal to half the darkness of its background. A choke
is applied only when the process components of a background are less than
or equal to half the darkness of the item in front of it. You cannot choke text.

IGNORE WHITE (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Trapping pane

Check Ignore White to specify that an object color in front of multiple back­ground colors — including white — does not take white into account when
trapping. It is checked by default.

46

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SERVER PREFERENCES

ncheck Ignore Whiteto overprint white background (overprint is treated as

U
an infinite choke) by all items. If an object color is in front of both a white
background and a background color against which the object color is spec­ified to spread, the object color traps to the indeterminate color. If an object
color is in front of both a white background and two or more background colors
to which the object color is specified to choke, the object color chokes (traps)
using the smallest choke value.

AUTO AMOUNT (DROP-DOWN MENU)

QuarkXPress Server Þ Preferences Þ Trapping pane

From the Auto Amount drop-down menu, choose or enter the amount of
trapping that QuarkXPress applies to object and background colors that have

Auto Amount (+/–) relationship specified in the Trap Specifications dialog

an

(Edit Þ Colors Þ Edit Trap) or the Trap Information palette (View Þ

box
Show Trap Information). The default value is .144pt.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

0pt to 36pt points .001

Choose
objects and background colors with

Specifications

Overprint from the Auto Amount drop-down menu to overprint the

Auto Amount (+/–) specified in the Trap

dialog box or the Trap Information palette.

INDETERMINATE (DROP-DOWN MENU)

QuarkXPress Server Þ Preferences Þ Trapping pane

From the Indeterminate drop-down menu, choose or enter the trapping applied
by QuarkXPress Server to object colors that are in front of indeterminate back­grounds (multiple colors with conflicting trapping relationships or imported
pictures). The default amount is .14pt.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

±36pt points .001

Choose

Overprint from the Indeterminate drop-down menu to cause object

colors to overprint indeterminate backgrounds.

KNOCKOUT LIMIT (FIELD)

QuarkXPress Server Þ Preferences Þ Trapping pane

In the Knockout Limit fi

eld (expressed as a per

centage of luminosity of the
object color compared with the background color), enter the point at which
an object color knocks out a background color. The default value is 0%.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

0% to 100% percent .1

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

47

|

SERVER PREFERENCES

OVERPRINT LIMIT (FIELD)

QuarkXPress Server Þ Preferences Þ Trapping pane

The Overprint Limit value controls the following trapping behavior:

• Although the default color Black overprints by default, objects colored black
with shade values below the

• Any object that has a color that is set to
dialog box) and that has a shade value below the Overprint Limit does
not overprint.

• If the value of the black component of a “rich black” is below the overprint
limit, rich black trapping does not occur.

For example, if you enter 95% in this field, a 90% shaded object that has a
color set to
box) does not overprint; instead, it traps according to the
specified. The default

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

0% to 100% percent .1

When you open a dialog box in QuarkXPress Server, the HTTP server pauses,
which prevents conflict with any jobs that are being processed. When you
close the dialog box, the HTTP server starts again.

Overprint Limit do not overprint.

Overprint (in the Trap Specifications

Overprint a background color (in the Trap Specifications dialog

Auto Amount value

Overprint Limit is 95%.

COLOR MANAGER (PANE)

QuarkXPress Server Þ Preferences Þ Color Manager

Use the Color Manager pane to specify color management preferences for
monitors and output devices, imported pictures, and any colors used in
QuarkXPress projects.

Preferences dialog box displaying Color Manager pane

48

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SERVER PREFERENCES

TRANSFORMATION METHOD (AREA)

QuarkXPress Server Þ Preferences Þ Color Manager pane

Use the controls in this area to control which color engine is used to transform
color and to turn black point compensation on and off.

COLOR ENGINE (DROP-DOWN MENU)

QuarkXPress Server Þ Preferences Þ Color Manager pane

To specify a particular color management engine, choose the engine’s name
from this drop-down menu. To let QuarkXPress Server choose the appropriate
color management engine, choose

Automatic.

BLACK POINT COMPENSATION (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Color Manager pane

Black point compensation is a method of tuning blacks to more accurately
simulate the capabilities of various output devices. To turn on black point
compensation, check this box. This box is checked by default.

SOURCE OPTIONS (AREA)

QuarkXPress Server Þ Preferences Þ Color Manager pane

Use controls in this area to specify which source color setup QuarkXPress Server
should use, and to turn access to picture profiles on and off.

SOURCE SETUP (DROP-DOWN MENU)

QuarkXPress Server Þ Preferences Þ Color Manager pane

Use this drop-down menu to specify the source color space of pictures and colors
used in QuarkXPress Server.

ENABLE ACCESS TO PICTURE PROFILES (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Color Manager pane

This control is not relevant to QuarkXPress Server and should be ignored.

SOFT PROOFING (AREA)

QuarkXPress Server Þ Preferences Þ Color Manager pane

The controls in the Soft Proofing area are not relevant to QuarkXPress Server
and should be ignored.

VECTOR EPS/PDF FILES (AREA)

QuarkXPress Server Þ Preferences Þ Color Manager pane

Use the V

ector EPS/PDF Files

area to choose the International Color

Consortium (ICC) profiles that correspond to your devices.

COLOR MANAGE VECTOR EPS/PDF (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Color Manager pane

To turn on color management for vector EPS and PDF pictures, check this box.
This box is unchecked by default.

INCLUDE EXISTING VECTOR EPS/PDF IN LAYOUT (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Color Manager pane

To apply the specified color management settings to pictures, check this box.
This box is unchecked by default.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

49

|

SERVER PREFERENCES

LAYERS (PANE)

QuarkXPress Server Þ Preferences Þ Layers

Use the Layers pane to specify the settings used when a layer is created.

Preferences dialog box Layers pane in Default Print Layout list

NEW LAYER DEFAULTS (AREA)

QuarkXPress Server Þ Preferences Þ Layers pane

Use the New Layer Defaults area to set layer preferences for layers to be added
using QuarkXPress Server.

VISIBLE (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Layers pane

Check Visible to make new layers visible by default, and to enable the Suppress
Output

check box.

SUPPRESS OUTPUT (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Layers pane

Check Suppress Output to prevent new layers from being rendered.

LOCKED (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Layers pane

Check Locked to make new layers locked by default. This box is unchecked
by default.

KEEP RUNAROUND (CHECK BOX)

QuarkXPress Server Þ Preferences Þ Layers pane

Check Keep Runaround to make text on visible new layers flow around items
on hidden layers.

50

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

STYLE SHEETS

se style sheets to group paragraph formats, character attributes, rules, and

U
tab settings so that you can apply them collectively with one action. The

Sheets
Style Sheets) displays the Style Sheets dialog box, which lets you create and

manage paragraph and character style sheets.

Default style sheets can be applied to content in projects using Modifier
XTensions software. For more information, see “Modifier XTensions software”
in Chapter 4, “XTensions software.”

DEFAULT STYLE SHEETS (DIALOG BOX)

Server/QuarkXPress Server Þ Document Controls Þ Style Sheets

Use the Default Style Sheets dialog to create, edit, duplicate, and delete default
paragraph and character style sheets for your QuarkXPress Server application.

STYLE SHEETS

Style

command (Server/QuarkXPress Server Þ Document Controls Þ

Default Style Sheets dialog box

NEW (DROP-DOWN BUTTON)

Default Style Sheets dialog box

To create a default style sheet, choose an option from the New
drop-down button:

• Choose Paragraph ( ) to create a style sheet that contains paragraph attrib­utes. (Paragraph style sheets also contain a default character style sheet.) The
Edit Paragraph Style Sheet dialog box displays.

• Choose
attributes. The

Character ( ) to create a style sheet that contains only character

Edit Character Style Sheet dialog box displays.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

|

51

STYLE SHEETS

EDIT (BUTTON)

Default Style Sheets dialog box

Click the Edit button to display the Edit Paragraph Style Sheet dialog box or
the

Edit Character Style Sheet dialog box, depending on what type of style

sheet you select in the list. The dialog box displays the current

Description

for the selected style sheet. You can also double-click a style sheet in the list
to display the dialog box.

DUPLICATE (BUTTON)

Default Style Sheets dialog box

Click Duplicate to create a copy of the selected style sheet. QuarkXPress Server
automatically displays the

Character Style Sheet

Edit Paragraph Style Sheet dialog box or the Edit

dialog box so that you can rename and edit the duplicate

style sheet.

DELETE (BUTTON)

Default Style Sheets dialog box

Click Delete to remove the selected style sheets. You cannot delete the Normal
style sheets.

APPEND (BUTTON)

Default Style Sheets dialog box

Use the Append button to import style sheets from a QuarkXPress project,
document, template, or library:

1 Click Append to display the Append Style Sheets dialog box.

2 Select a QuarkXPress project, document, template, or library and click Open.

The

Append dialog box displays. The Available column lists all the appropriate

style sheets in the source file.

3 Select the style sheets to import and double-click them or click to move

them to the

Include column. To select a range of style sheets, click the first

style sheet and press Shift while you click the last style sheet in the range. To
select non-consecutive style sheets, press Command/Ctrl while you click each
style sheet.

SAVE (BUTTON)

Default Style Sheets dialog box

Click Save to save changes made to style sheets in the Style Sheets dialog box.

EDIT PARAGRAPH STYLE SHEET (DIALOG BOX)

Server/QuarkXPress Server Þ Document Controls Þ Style Sheets Þ
New Þ Paragraph

Choose New Þ Paragraph (or click Edit or Duplicate when a paragraph style
sheet is selected) to display the

Edit Paragraph Style Sheet dialog box, which

lets you create or edit a paragraph style sheet.

52

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

STYLE SHEETS

Edit Paragraph Style Sheet dialog box

NAME (FIELD)

Edit Paragraph Style Sheet dialog box

In the Name field, enter a name for a new style sheet or rename an existing
style sheet.

Below the

Name field are four tabs: General, Formats, Tabs, and Rules. The

Formats, Tabs, and Rules tabs enable you to specify the paragraph formats that

are automatically applied to text when you apply a paragraph style sheet. The
controls in these three tabs are the same as those in the

Attributes

dialog box (Style Þ Formats).

QuarkXPress Paragraph

GENERAL (TAB)

Edit Paragraph Style Sheet dialog box

Click the General tab to specify keyboard commands and other attributes for
a style sheet.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

53

|

STYLE SHEETS

General tab

KEYBOARD EQUIVALENT (FIELD)

Edit Paragraph Style Sheet dialog box Þ General tab

The Keyboard Equivalent field is not relevant to QuarkXPress Server and
should be ignored.

BASED ON (DROP-DOWN MENU)

Edit Paragraph Style Sheet dialog box Þ General tab

From the Based On drop-down menu, choose a style sheet to base your new
style sheet on. The default option is

No Style.

Modifications made to a style sheet that serves as the foundation for another
style sheet affect both style sheets.

NEXT STYLE (DROP-DOWN MENU)

Edit Paragraph Style Sheet dialog box Þ General tab

From the Next Style drop-down menu, choose a style sheet to follow the cur­rent style sheet when you are entering text. For example, you can specify that
a paragraph with a “subheading” style sheet be followed automatically by
a paragraph with a “byline” style sheet, which in turn can be followed by a
paragraph with a “body copy” style sheet. The style automatically changes to
the style specified in the
at the end of the paragraph. Choosing a

Next Style drop-down menu after a return is inserted

Next Style option does not affect

existing text.

•

The drop-down menu lists all default style sheets.

• Choose Self from the Next Style drop-down menu to continue using the same
style sheet in the next paragraph.

54

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

STYLE SHEETS

CHARACTER ATTRIBUTES (AREA)

Edit Paragraph Style Sheet dialog box Þ General tab

Paragraph style sheets contain a character style sheet. The character style sheet
is applied to all the characters in a paragraph when you apply a paragraph style
sheet to it.

STYLE (DROP-DOWN MENU)

Edit Paragraph Style Sheet dialog box Þ General tab

From the Character Style drop-down menu, choose a character style sheet.

• Click

New to create a character style sheet in the Edit Paragraph Style Sheet

dialog box. The Edit Character Style Sheet dialog box displays. After you
make your edits, click
box. The new style sheet name automatically displays in the

OK to return to the Edit Paragraph Style Sheet dialog

Character Style

drop-down menu.

• Click

Edit to edit the character style sheet selected in the Character Style

drop-down menu. The Edit Character Style Sheet dialog box displays. After
you make your edits, click

OK to return to the Edit Paragraph Style Sheet

dialog box.

FORMATS (TAB)

Edit Paragraph Style Sheet dialog box

Click the Formats tab to specify indentations, line spacing, paragraph spacing,
drop caps, and other characteristics for a paragraph or range of paragraphs.
Not all of these controls apply to text paths.

Formats tab

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

55

|

STYLE SHEETS

LEFT INDENT (FIELD)

Edit Paragraph Style Sheet dialog box Þ Formats tab

In the Left Indent field, enter the distance from the left edge of a column,
text box, or text path to the left edge of a paragraph.

FIRST LINE (FIELD)

Edit Paragraph Style Sheet dialog box Þ Formats tab

In the First Line field, enter the distance from the Left Indent to the begin­ning of the first line of a paragraph. Enter a positive value to indent the first
line to the right of the

Left Indent. To indent the first line to the left of the

Left Indent (a hanging indentation), enter a negative value in this field and

enter a positive value in the

Left Indent field. If you are specifying formats

for a text path, the field works the same way; however, you cannot have more
than one line of text on a text path.

RIGHT INDENT (FIELD)

Edit Paragraph Style Sheet dialog box Þ Formats tab

In the Right Indent field, enter the distance from the right edge of a column,
text box, or text path to the right edge of a paragraph.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

column width various .001

LEADING (FIELD)

Edit Paragraph Style Sheet dialog box Þ Formats tab

In the Leading field, enter the amount of space between lines of text. For
information about leading, see “

Auto Leading (field)” earlier in this chapter.

SPACE BEFORE, SPACE AFTER (FIELDS)

Edit Paragraph Style Sheet dialog box Þ Formats tab

In the Space Before and Space After fields, enter how much space precedes
and follows a paragraph. The space between two paragraphs is the sum of the
Space After the first paragraph and the Space Before the second paragraph.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

0 to 15" various .001

Space Before is not applied when a paragraph falls at the top of a column.
Space After is not applied when a paragraph falls at the bottom of a column.

Neither is applied to text paths.

ALIGNMENT (DROP-DOWN MENU)

Edit Paragraph Style Sheet dialog box Þ Formats tab

From the Alignment drop-down menu, choose an alignment for paragraphs:

• Left aligns paragraphs with the left indentation.

Centered centers each line between the left and right indentations.

•

56

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

STYLE SHEETS

ightaligns paragraphs with the right indentation.

• R

•

Justified aligns paragraphs with the left and right indentations; the last line

ight be shorter than the width of the paragraph.

m

•

Forced aligns all lines in a paragraph, including the last line, with the left and
right indentations.

Paragraphs are aligned within the bounds established by the First Line,

Left Indent,

and Right Indent values. If the paragraph alignment is set to

Centered, the First Line value is added to any line indentation caused by the

centered alignment.

H&J (DROP-DOWN MENU)

Edit Paragraph Style Sheet dialog box Þ Formats tab

H&Js (hyphenation and justification specifications) control the hyphenation
and spacing of text.

From the
that is defined in the

H&J drop-down menu, choose a hyphenation and spacing style

H&Js dialog box (Server/QuarkXPress Server Þ

Document Controls Þ H&Js).

LANGUAGE (DROP-DOWN MENU)

Edit Paragraph Style Sheet dialog box Þ Formats tab

From the Language drop-down menu, choose the applicable language from
a list of languages.

DROP CAPS (CHECK BOX)

Edit Paragraph Style Sheet dialog box Þ Formats tab

Check Drop Caps to specify an initial drop cap character for a paragraph.

Character Count and Line Count fields are enabled.

The

• In the Character Count field, enter the number of drop cap characters (from 1
to 127).

• In the

Line Count field, enter the number of lines the characters drop (from 2

to 16).

KEEP LINES TOGETHER (CHECK BOX)

Edit Paragraph Style Sheet dialog box Þ Formats tab

Check Keep Lines Together to prevent widows and orphans by specifying
how paragraphs break at the bottom of columns. (In QuarkXPress, a widow
is defined as the last line of a paragraph that falls at the top of a column; an
orphan is defined as the first line of a paragraph that falls at the bottom of a

¶

column.) Checking

Keep Lines Together lets you use the All Lines in

and

Start/End options.

¶

• Click All Lines in

to specify that a paragraph does not break at the bottom of
a column. If all the lines in a paragraph do not fit in one column, the entire
paragraph is carried to the next column.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

57

|

STYLE SHEETS

In the Startfield, enter the minimum number of lines to remain at the bottom

•
of a column.

In the Endfield, enter the minimum number of lines to be carried over to the

•
next column.

If a paragraph does not contain enough lines to meet the start and end criteria,
the entire paragraph is carried to the next column.

KEEP WITH NEXT ¶ (CHECK BOX)

Edit Paragraph Style Sheet dialog box Þ Formats tab

¶

Check Keep with Next

to force a paragraph to flow with the following
paragraph (for example, to ensure that a subheading stays connected with
the first related paragraph).

LOCK TO BASELINE GRID (CHECK BOX)

Edit Paragraph Style Sheet dialog box Þ Formats tab

Using a baseline grid aligns paragraphs horizontally across columns and text
boxes. Check

Lock to Baseline Grid to lock selected paragraphs to the grid.

The grid is defined in the Baseline Grid area in the Paragraph pane of the
Preferences dialog box (QuarkXPress Server Þ Preferences).

TABS (TAB)

Edit Paragraph Style Sheets dialog box

Click the Tabs tab of the Paragraph Attributes dialog box to specify the
alignment, position, and fill character for tab stops.

abs

T

tab

58

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

STYLE SHEETS

ALIGNMENT (BUTTONS)

Edit Paragraph Style Sheets dialog box Þ Tabs tab

The alignment buttons enable you to choose an alignment for a tab stop.

• Choose Left to align tabbed text flush left along a tab stop.

• Choose

• Choose

Center to center align tabbed text along a tab stop.

Right to align tabbed text flush right along a tab stop. To align char-

acters flush along the right indent of a column regardless of other tab stops,
place the

Text Insertion bar (I) immediately to the left of the characters and

press Option/Shift+Tab.

• Choose

Decimal to position tabbed text by aligning decimal points (periods)

along a tab stop.

• Choose Comma to align commas in tabbed text along a tab stop.

• Choose
text along a tab stop. The
in the

Align On to align occurrences of a user-specified character in tabbed

Align On option enables you to enter this character

Align On field. You can enter any printing character.

Alignment buttons

If you choose Decimal, Comma, or Align On and the text (usually a number)
does not contain a period, comma, or a specified alignment character, the text
aligns on the first non-numeric character following the text (such as a tab, space,
or carriage return).

POSITION (FIELD)

Edit Paragraph Style Sheets dialog box Þ Tabs tab

In the Position field, enter tab stops. Tab stops are measured from the Text Inset
value on the left edge of a box or column. When you enter the tab stop value

Position field, the new tab stops immediately display on the tab ruler.

in the

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

column width

Set to deselect the tab stop. You can enter values for the next tab stop.

Click

various .001

FILL CHARACTERS (FIELD)

Edit Paragraph Style Sheets dialog box Þ Tabs tab

A fill character, such as a dot leader in a table of contents, “fills” the space
between a tab character and the next tab stop.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

59

|

STYLE SHEETS

n the Fill Charactersfield, enter any character to be repeated or any two

I
characters to alternate (one of the characters can be a space). Fill characters
are aligned flush right with the tab stop position. (Fill characters cannot be
invisible characters; they must be printed characters.)

ALIGN ON (FIELD)

Edit Paragraph Style Sheets dialog box Þ Tabs tab

In the Align On field, enter any printing character to align tabbed text with.
This field is available when the

Align On button is chosen.

SET (BUTTON)

Edit Paragraph Style Sheets dialog box Þ Tabs tab

Click Set to deselect a selected tab stop in the tab ruler that displays above the
active column. You can enter values for the next tab stop.

CLEAR ALL (BUTTON)

Edit Paragraph Style Sheets dialog box Þ Tabs tab

Click Clear All to delete all custom tab stops from the active paragraphs.

RULES (TAB)

Edit Paragraph Style Sheets dialog box

Click the Rules tab of the Paragraph Attributes dialog box to specify the
length, position, style, width, color, and shade of paragraph rules.

Rules tab

60

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

STYLE SHEETS

RULE ABOVE, RULE BELOW (CHECK BOXES)

Edit Paragraph Style Sheets dialog box Þ Rules tab

Use Rule Above and Rule Below to specify whether horizontal lines display
above or below a paragraph. Check

Rule Above or Rule Below to access

controls for specifying the placement and style of the rules.

LENGTH (DROP-DOWN MENU)

Edit Paragraph Style Sheets dialog box Þ Rules tab

From the Length drop-down menu, choose whether rules fit within the
paragraph indentations or match the length of the text.

• Choose
tation to its right indentation. Indentations are specified in the
of the

• Choose

Indents to specify a rule that extends from the paragraph’s left inden-

Formats tab

Paragraph Attributes dialog box (Style Þ Formats).

Text to specify a rule above that matches the length of the first line

of text in the paragraph and a rule below that matches the length of the last
line of text in the paragraph.

The From Left and From Right values in the Rules tab of the Paragraph
Attributes dialog box apply regardless of whether you choose Indents or Text.

FROM LEFT, FROM RIGHT (FIELDS)

Edit Paragraph Style Sheets dialog box Þ Rules tab

In the From Left and From Right fields, enter the placement of a rule in
relation to the specified length.

• In the

• In the

From Left field, enter the distance between the left end of a rule and

either the left indentation of the paragraph
end of a line of text

(Length set to Text).

(Length set to Indents) or the left

From Right field, enter the distance between the right end of a rule and

either the right indentation of the paragraph
right end of a line of text

(Length set to Text).

(Length set to Indents) or the

Large positive values create short rules, and small positive values create
long rules. You can enter negative values if an indentation is applied to
the paragraph.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

Column width various .001

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

61

|

STYLE SHEETS

OFFSET (FIELD)

Edit Paragraph Style Sheets dialog box Þ Rules tab

In the Offset field, enter the amount of vertical space between a paragraph
and a rule. You can enter an absolute value or a percentage. (The

Offset field

is not available in HTML text boxes.)

• Absolute values are measured from the baseline of the first line of a paragraph to
the bottom of a rule above, and from the baseline of the last line of a paragraph
to the top of a rule below. Positive values move the rule farther away from the
text. Negative values move the rule closer to the text. Using an absolute nega­tive offset value for a rule above, you can overlap white text with a dark-colored
rule to create reverse type.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

0" to 15" or various .001

–1

⁄2 rule width

• In the

Offset field, enter a percentage to make the rule act like an auto-leaded

line of text, which prevents text from overlapping. The 100% value in the

Offset

field is defined by the total distance between paragraphs. For example, a 30%
Offset for a Rule Above adds 30% of the total inter-paragraph space below the
center of the rule. The default rule

Offset percentage is 0%.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

0% to 100% percent .1

STYLE (DROP-DOWN MENU)

Edit Paragraph Style Sheets dialog box Þ Rules tab

From the Style drop-down menu, choose from a list of default line styles.

WIDTH (FIELD AND DROP-DOWN MENU)

Edit Paragraph Style Sheets dialog box Þ Rules tab

In the Width field, choose from a list of line widths from the drop-down menu
or enter a value.

Choose

Hairline to print the rule at .125pt to a PostScript imagesetter

(but wider on a laser printer). Entering a “0” in any line width field specifies

Hairline value.

a

RANGE

MEASUREMENT SYSTEM SMALLEST INCREMENT

0pt to 864pt various .001

COLOR (DROP-DOWN MENU)

Edit Paragraph Style Sheets dialog box Þ Rules tab

From the Color drop-down menu, choose from a list of colors defined in the
Colors dialog box (Server/QuarkXPress Server Þ Document Controls Þ
Colors). The list includes default colors, custom colors, and spot colors

imported with EPS picture files.

62

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

STYLE SHEETS

SHADE (FIELD)

Edit Paragraph Style Sheets dialog box Þ Rules tab

In the Shade drop-down menu and field, choose a shade value in 10%
increments or enter a value in the field.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

0% to 100% percent .1

OPACITY (FIELD)

Edit Paragraph Style Sheets dialog box Þ Rules tab

In the Opacity drop-down menu and field, choose an opacity value in 10%
increments or enter a value in the field.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

0% to 100% percent .1

EDIT CHARACTER STYLE SHEET (DIALOG BOX)

Server/QuarkXPress Server Þ Document Controls Þ Style Sheets Þ
New Þ Character

Use the Edit Character Style Sheet dialog box to create or edit a character
style sheet.

Edit Character Style Sheet dialog box

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

63

|

STYLE SHEETS

NAME (FIELD)

Edit Character Style Sheet dialog box

In the Name field, enter a name for a new style sheet or rename an existing
style sheet.

KEYBOARD EQUIVALENT (FIELD)

Edit Character Style Sheet dialog box

The Keyboard Equivalent field is not relevant to QuarkXPress Server and
should be ignored.

BASED ON (DROP-DOWN MENU)

Edit Paragraph Style Sheet dialog box Þ General tab

To specify a style sheet to base your new style sheet on, choose an option from
the

Based On drop-down menu. The default option is No Style.

Modifications made to a style sheet that serves as the foundation for another
style sheet affect both style sheets.

FONT (DROP-DOWN MENU)

Edit Character Style Sheet dialog box

To specify a font for the style sheet, choose an option from the Font drop-down
menu or enter the first few characters of the name until the system recognizes
the font name.

SIZE (DROP-DOWN MENU)

Edit Character Style Sheet dialog box

To specify a font size for the style sheet, choose an option from the Size
drop-down menu or enter a value in the field.

COLOR (DROP-DOWN MENU)

Edit Character Style Sheet dialog box

To specify a font color for the style sheet, choose an option from the Color
drop-down menu.

SHADE (DROP-DOWN MENU)

Edit Character Style Sheet dialog box

To specify a shade for the style sheet, choose an option from the Shade
drop-down menu or enter a percentage value in the field.

OPACITY (DROP-DOWN MENU AND FIELD)

Edit Character Style Sheet dialog box

To specify an opacity for the style sheet, choose an option from the Opacity
drop-down menu or enter a percentage value in the field.

64

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

STYLE SHEETS

SCALE (DROP-DOWN MENU AND FIELD)

Edit Character Style Sheet dialog box

To specify a horizontal or vertical scale for the style sheet, choose Horizontal
or Vertical from the Scale drop-down menu and enter a percentage value in
the field.

TRACK AMOUNT (FIELD)

Edit Character Style Sheet dialog box

In the Track Amount field, enter the amount of space between selected
characters and words for copyfitting and special typographic effects.

BASELINE SHIFT (FIELD)

Edit Character Style Sheet dialog box

In the Baseline Shift field, enter a value that raises or lowers either text or
an anchored box relative to its normal baseline position.

ENABLE LIGATURES (CHECK BOX)

Edit Character Style Sheet dialog box

To activate standard ligatures for the style sheet, check Enable Ligatures.

TYPE STYLE (AREA)

Edit Character Style Sheet dialog box

Check Plain or combinations of the other type styles in the Type Style area.

Underline and Word Underline, All Caps and Small Caps, and Superscript

and Subscript are mutually exclusive type styles, so you can apply only one of
each pair.

LANGUAGE (DROP-DOWN MENU)

Edit Character Style Sheet dialog box

To specify a character language for the style sheet, choose an option from the
Language drop-down menu.

OPENTYPE STYLES (AREA)

Edit Character Style Sheet dialog box

Click the disclosure triangle at the left of the OpenType area to display
the various available OpenType styles. These styles might not be available,
depending on the font applied. OpenType options are not available in HTML
text boxes. Note the following rules:

• All Small Caps and Small Caps are mutually exclusive.

Tabular Lining, Proportional Old Styles, Proportional Lining, and Tabular

•

Old Style

Subscript, Superscript, Numerator, and Denominator (in the Position

•

are mutually exclusive.

drop-down menu) are mutually exclusive.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

65

|

COLORS

COLORS

olorscommand (Shift+F12) displays the Colorsdialog box, which enables

TheC
you to create and manage colors. You can also change the way a color traps to
other colors.

Default colors can be applied to content in projects using Modifier XTensions
software. For more information, see “Modifier XTensions software” in Chapter 4,
“XTensions software.”

DEFAULT COLORS (DIALOG BOX)

Server/QuarkXPress Server Þ Document Controls Þ Colors

Use the Colors dialog box to create, edit, duplicate, delete, and specify trapping
for default colors. You can also append colors from a QuarkXPress file.

Default Colors dialog box

• Cyan, Magenta, Yellow, Black, and White: You cannot edit or delete
these colors.

Registration: You can edit the Registration color, but you cannot delete

•
it. Changing the Registration color only changes the way the color
displays on-screen.

NEW (BUTTON)

Default Colors dialog box

Click New to display the Edit Color dialog box, which enables you to add,
create, or name a color. You can create up to 1,000 colors.

66

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

COLORS

EDIT (BUTTON)

Default Colors dialog box

Click Edit to display the Edit Color dialog box, which enables you to modify
the color selected in the Colors list. You can also double-click a color to display

Edit Color dialog box. You cannot edit or delete the following default

the
colors: Cyan, Magenta, Yellow, Black, and White.

DUPLICATE (BUTTON)

Default Colors dialog box

Click Duplicate to create a copy of the color selected in the Colors list.
QuarkXPress Server automatically opens the

Edit Color dialog box so that

you can rename and edit the copied color.

DELETE (BUTTON)

Default Colors dialog box

Click Delete to remove the selected colors.

APPEND (BUTTON)

Default Colors dialog box

The Append button lets you import colors from a QuarkXPress project,
document, template, or library:

1 Click Append to display the Append Colors dialog box.

2 Select a QuarkXPress project, document, template, or library and click Open.

The

Append dialog box displays. The Available column lists all the applicable

colors in the source file.

3 Select the colors to import and double-click them, or click to move them to

Include column. To select a range of colors, click the first color and press

the
Shift while you click the last color in the range. To select non-consecutive
colors, press Command/Ctrl while you click each color.

EDIT TRAP (BUTTON)

Default Colors dialog box

Click Edit Trap to specify trapping values for any item color relative to any back­ground color. The

Trap Specifications dialog box displays the specifications of

the color selected in the list.

SAVE (BUTTON)

Default Colors dialog box

Click Save to save changes made to any colors.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

67

|

COLORS

EDIT COLOR (DIALOG BOX)

Default Color dialog box Þ New, Edit, or Duplicate

Click New, Edit, or Duplicate in the Default Colors dialog box to display the
Edit Color dialog box, which enables you to create or edit a color.

Edit Color dialog box

NAME (FIELD)

Edit Color dialog box

In the Name field, enter a name for a new color or rename an existing color.

MODEL (DROP-DOWN MENU)

Edit Color dialog box

From the Model drop-down menu, choose a color model for creating and
editing colors. For example, you can use the HSB or CMYK model to modify
a color created in the RGB model. You can also edit a spot color such as a
PANTONE, Toyo®, or DIC color using one of the other color definition mod­els, but a spot color edited in this manner no longer matches the originally
selected version.

You can choose from among the following options:

RGB: An additive color system, usually used with slide recorders or color

•
video monitors. Red, green, and blue light is mixed to represent colors on a
video screen.

•

HSB: Resembles the manner in which artists mix colors, using hue, saturation,
and brightness. Hue describes color pigment; saturation measures the amount
of color pigment; and brightness measures the amount of black in a color.

LAB: Also referred to as “LAB color space” or “CIELAB.” A standard three-

•
dimensional model for representing colors. LAB is a color space designed to
be independent of differing interpretations imposed by monitor or printer
manufacturers. The LAB model used in QuarkXPress Server and QuarkXPress
uses the “D50 illuminant” to be consistent with most usage.

68

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

COLORS

MYK: Asubtractive color system and the color model used by professional

• C
printers. Cyan, magenta, yellow, and black inks combine to “subtract” from
white and thus reproduce most colors.

•

Multi-Ink: A special model in QuarkXPress Server and QuarkXPress that
allows you to create a multi-ink color based on screen percentages of existing
process inks or spot colors. Before using this feature, consult your printer or
service bureau to make sure that the percentages you choose do not cause
ink-coverage problems.

• PANTONE: Consists of the PANTONE MATCHING SYSTEM®colors in solid
colors for printing on coated stock. The PANTONE MATCHING SYSTEM was
designed to specify spot colors. The PANTONE MATCHING SYSTEM prints
each color on its own plate when you print separations. Use the PANTONE
Color Formula Guide for accurate PANTONE-identified solid color standards

®

for coated and uncoated paper stock. The PANTONE Hexachrome

color sys­tem is designed to reproduce colors using six unique PANTONE process inks.
This matching system enables you to choose from more than 2,000 ultra
high-fidelity colors, which are arranged chromatically. Use the PANTONE
Hexachrome Color Selector for accurate PANTONE Hexachrome-identified
color standards for coated and uncoated paper stock.

TOYO or DIC: These are spot-color-matching systems popular in Japan.

•

TRUMATCH®and FOCOLTONE®: These are matching systems that enable you

•
to specify colors that can be built on-press using the four process colors — cyan,
magenta, yellow, and black.

Hexachrome Uncoated and Hexachrome Coated: These are hi-fidelity color

•
matching systems from Pantone Inc. that consist of colors printed with six
process plates instead of the usual four. Orange and green are added to the
CMYK plates to create better impact and increase the range of reproducible
colors. Choose Hexachrome colors in your projects only after you have talked
to your printer and planned printing a Hexachrome job.

•

Web-safe: This color model displays in the Model drop-down menu only if the
corresponding Color Library files are installed in your “Color” folder.

Web Named Colors: This model enables you to select a Web-safe color using

•
its assigned color name — for example, “Dark Blue.” Not all Web-safe colors

eb Named Colors

are included in the
the

Model drop-down menu only if the corresponding Color Library files are

W

palette. This color model displays in

installed in your “Color” folder.

COLOR WHEEL OPTIONS (COLOR SELECTOR)

Edit Color dialog box Þ New, Edit or Duplicate

If you choose HSB, RGB, LAB, or CMYK from the Model drop-down menu,
the color wheel, brightness slider, and numeric sliders display.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

69

|

COLORS

Color selector for a CMYK color

• You can use the color wheel to specify a color. Click or drag the pointer inside
the wheel; a small square indicates the location of the active color. The

New

field displays this color. The numeric values for the components of the current
color are displayed in the fields below the wheel. You can use the numeric
fields to make modifications to colors you picked using the color wheel.

• Using the brightness slider to the right of the color wheel, you can quickly
change the amount of black present in the colors that are accessible through
the color wheel. Move the slider downward to add more black.

• To define colors without using the color wheel (or after clicking the general
area of a color), use the sliders or enter values for each color component in the
fields below the wheel.

Black-and-white or grayscale monitors use levels of gray with letters (such as
R, G, B) to represent the corresponding color areas of the wheel.

MULTI-INK OPTIONS (COLOR SELECTOR)

Model drop-down menu

If you choose Multi-Ink from the Model drop-down menu, a list on the right
of the dialog box displays all available spot colors and process inks.

Color selector for a multi-ink color

70

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

COLORS

From the Process Inksdrop-down menu, choose CMYKprocess inks or

•
Hexachrome process inks.

Choose Hexachrome after you have spoken to your printer and planned to
print a six-color hexachrome job.

• From the

Shade drop-down menu, choose a screen percentage from 0%–100%

for the color you select in the list. Specify shades for any number of process
inks or spot colors in the list to build your own custom multi-ink color.

Before using the Multi-Ink feature, consult with your printer or service bureau to
make sure that the percentages you choose do not cause ink-coverage problems.

SWATCHBOOK OPTIONS (COLOR SELECTOR)

Model drop-down menu

If you choose TOYO, DIC, TRUMATCH, FOCOLTONE, HEXACHROME,
Web-safe, Web Named Colors,

Model drop-down menu, the corresponding color selector displays.

the

or one of the PANTONE color models from

Color selector containing swatchbook options for the Web Safe Colors model

• Select a color from one of these matching systems or enter the catalog number
in the field below the color selector.

• When you enter a catalog number in the field, the color corresponding to that
number displays in the color selector and in the

• The name of a specified color automatically displays in the
upper left corner of the dialog box. The “CV” that follows a

New field.

Name field in the

ANTONE

P

color
number indicates that the selected color is a computer video simulation of the
actual

ANTONE

P

color

.

SPOT COLOR (CHECK BOX)

Edit Color dialog box

Check Spot Color to print the color as a spot color to its own separate printing
plate. If you specify a spot color from one of the color selectors, you can uncheck
Spot Color to separate the color into cyan, magenta, yellow

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

, and black plates.

ACE

71

|

COLORS

As the gamut of CMYK process color is limited, any spot color that you repro­duce using process plates looks slightly different from the actual spot ink that

ou see in a printed swatch book.

y

HALFTONE (DROP-DOWN MENU)

Edit Color dialog box

From the Halftone drop-down menu, choose the screen values used when you
print a color separation plate that contains a screen for a spot color. A spot color
means a color for which

Spot Color is checked.

When Spot Color is checked, the Halftone drop-down menu is available. Choose

Process Cyan to specify a screen angle of 105°, Process Magenta for 75°, Process
Yellow

for 90°, and Process Black for 45°. These values might be overridden by

values built in to an imagesetter or printer description file. You can also over­ride them using the

Style

dialog box (Server/QuarkXPress Server Þ Document Controls Þ

Angle drop-down menu in the Output tab of the Output

Output Style).

NEW/ORIGINAL (AREA)

Edit Color dialog box

The New/Original area displays colors as you create and edit them. The New
field displays a new color or an edited version of the chosen color. The Original
field is used for comparison; it displays the original color when you are editing
an existing color.

TRAP SPECIFICATIONS (DIALOG BOX)

Default Colors dialog box Þ Edit Trap

Click Edit Trap in the Colors dialog box to display the Trap Specifications
dialog box for a chosen color. Use the Trap Specifications dialog box to specify
trapping values for any object color relative to any background color. By spec-

Overprint, Knockout, Auto Amount (+) for spreads, Auto Amount (–)

ifying
for chokes, or Custom trap values in the Trap drop-down menu, you can control
the trapping relationships for every color except

Trap Specifications dialog box

72

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

White and Registration.

ACE

COLORS

Color-specific trapping values you specify in the Trap Specifications dialog box
directly affect color relationships and override all default trapping preferences.

spread occurs when items with a lighter color enlarge slightly to overlap a

A
darker background color. A

choke occurs when items with a darker color are

trapped by a slight reduction in the size of the “knocked out” area in a lighter
background color.

BACKGROUND COLOR (COLUMN)

Trap Specifications dialog box

The Background Color column displays all the colors defined for the project,
with the exception of White, Registration, and the object color. When the
object color is placed against a background of more than one color with
which the object color has conflicting trapping relationships or against a
color QuarkXPress is unable to identify, the program traps according to the
value specified for the

Indeterminate background color.

TRAP (DROP-DOWN MENU)

Trap Specifications dialog box

The Trap drop-down menu determines the trapping relationship when the
selected

Background Color occurs behind the object color selected in the

Default Colors dialog box. The Trap column displays the current setting.

Entries different from the default values are marked with an asterisk (*).

Trap drop-down menu

• The Default option works like the Auto Amount (+/–) settings, but when
Default is chosen, an algorithm determines which colors choke, which colors

spread, and which colors overprint or knock out. The amount of a choke or
spread is based on the

Preferences dialog box (QuarkXPress Server Þ Preferences). However,

the
when

Default is chosen, black always overprints and white always knocks out.

Overprint option specifies that the object color named in the dialog

• The

Auto Amount value specified in the Trapping pane of

box title overprints the selected background color in all instances where the
shade value of the object color is greater than the percentage entered in the

Overprint Limit field of the Trapping pane of the Preferences dialog box
(QuarkXPress Server Þ Preferences).

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

|

73

COLORS

Even with Overprint specified, overprinting occurs only when an object
color has a shade value greater than the

he

rappingpane of the Preferencesdialog box (QuarkXPress Server

t

T

Overprint Limit value specified in

Preferences).

• The

Knockout option specifies that the object color named in the dialog box

title knocks out the selected background color using no trapping.

• The Auto Amount (+) option assigns the default spread value (the value
specified in the

Auto Amount field of the Trapping pane of the Preferences

dialog box) to the object color named in the dialog box title.

Auto Amount (–) option assigns the default choke value (the negative

• The
of the value specified in the

Auto Amount field of the Trapping pane of the

Preferences dialog box) to the object color named in the dialog box title.

Custom option displays the Custom dialog box, which enables you to

• The
specify a custom trapping value for the object and background color. Enter a
value and click

OK. A negative value causes the background color to choke.

A positive value causes the object color to spread. A value of zero knocks out
the object from the selected background color with no trapping.

RANGE MEASUREMENT SYSTEM SMALLEST INCREMENT

±36pt points .001

Þ

If you specify a negative Custom value between the object color named in
the dialog box title and the

Indeterminate background color, text to which

the object color is applied is not choked; instead, it is knocked out of the
background without any trapping.

DEPENDENT/INDEPENDENT (DROP-DOWN MENU)

Trap Specifications dialog box

The Dependent Traps/Independent Traps drop-down menu determines
whether the
other. The

Trap and Reverse drop-down menu settings directly affect each

Reverse column indicates how trapping occurs when the selected

Background Color takes on the role of object color and vice versa.

Dependent/Independent drop-down menu

Choose

•

Dependent T

raps

for QuarkXPress Ser

ver to calculate a reverse trap

value automatically.

Choose

•

Independent T

raps

to specify a custom reverse trap value.

74

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

COLORS

REVERSE (DROP-DOWN MENU)

Trap Specifications dialog box

The Reverse drop-down menu determines how trapping occurs when the
selected

Background Color takes on the role of object color, and the color

identified in the name of the dialog box takes on the role of background
color. The

Reverse value is calculated automatically when you choose

Dependent Traps. If you change the Reverse value when Dependent Traps

is chosen, the corresponding opposite trap is calculated automatically.

Reverse drop-down menu

The Reverse column displays the current setting. When an entry is different
from the default values, it is marked with an asterisk (*). The options avail­able in the

Reverse drop-down menu are the same as those in the Trap

drop-down menu.

H&JS

Hyphenation and justification specifications (H&Js) are sets of automatic
hyphenation rules and justification settings that you can apply to paragraphs.
The

H&Js command (Server/QuarkXPress Server Þ Document Controls Þ

H&Js) displays the H&Js dialog box, which enables you to create and manage

hyphenation and justification specifications. You apply hyphenation and jus­tification specifications to selected paragraphs using the
in the

Formats tab of the Edit Paragraph Style Sheet dialog box. Hyphenation

H&J drop-down menu

and justification specifications are included in paragraph style sheets.

Default H&Js come into play only when you create a project in QuarkXPress
Server. You cannot directly create projects in the QuarkXPress Server user
interface, but client requests can trigger the creation of projects.

DEFAULT H&JS (DIALOG BOX)

Server/QuarkXPress Server Þ Document Controls Þ H&Js

Use the H&Js dialog box to create, edit, duplicate, and delete the current
hyphenation and justification specifications. You can also append hyphenation
and justification specifications from another project.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

75

|

H&JS

he top list displays the available hyphenation and justification specifications;

T
the bottom list displays the specifications for the selected hyphenation and
justification.

Default H&Js dialog box

H&JS (LIST)

Default H&Js dialog box

When no projects are open, the H&J list displays all default hyphenation and
justification specifications.

All projects contain the
By default,

Normal paragraph style sheet. The default Standard hyphenation and

the

Standard is the hyphenation and justification specification for

Standard hyphenation and justification specification.

justification specification is defined as follows:

Auto Hyphenation: Checked

•

Smallest Word: 6

•

Minimum Before: 3

•

Minimum After: 2

•

Break Capitalized Words: Unchecked

•

Hyphens in a Row: Unlimited

•

Hyphenation Zone: 0"

•

Space: 85% Min., 110% Opt., 250% Max.

•

Char: 0% Min., 0% Opt., 4% Max.

•

Flush Zone: 0"

•

Single W

•

ord Justify:

Checked

76

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

H&JS

NEW (BUTTON)

Default H&Js dialog box

The New button displays the Edit Hyphenation & Justification dialog box,
which enables you to create a hyphenation and justification specification. You
can create up to 1,000 default or project-specific hyphenation and justification
specifications. Use the

Edit Hyphenation & Justification dialog box to name

and define a hyphenation and justification specification.

EDIT (BUTTON)

Default H&Js dialog box

The Edit button displays the Edit Hyphenation & Justification dialog box for
the hyphenation and justification specification selected in the

H&J list. Use the

Edit Hyphenation & Justification dialog box to modify a hyphenation and

justification specification’s name and definition. You can also double-click a
hyphenation and justification specification to display the

Justification

dialog box.

Edit Hyphenation &

DUPLICATE (BUTTON)

Default H&Js dialog box

The Duplicate button creates a copy of the hyphenation and justification
specification selected in the
the

Edit Hyphenation & Justification dialog box so that you can rename and

H&J list. QuarkXPress Server automatically opens

edit the copied hyphenation and justification specification.

DELETE (BUTTON)

Default H&Js dialog box

The Delete button removes the selected hyphenation and justification speci­fications. If the hyphenation and justification specification was used in the
active project, an alert enables you to choose a replacement hyphenation and
justification specification.

APPEND (BUTTON)

Default H&Js dialog box

Click Append to display the Append H&J dialog box. Use the Append H&J
dialog box to import hyphenation and justification specifications from a
QuarkXPress project, document, template, or library.

Selecting a fi

le in the dialog box and clicking

Open displays the Append H&Js

dialog box. The Append H&Js dialog box enables you to import H&Js selec­tively from source documents, projects, templates, or libraries. Click the

H&Js

tab to choose from a list of H&Js. The Available column lists all the applica-
ble

H&Js in the source file. Select the H&Js to import into the target project

and double-click them, or click to move them to the
select a range of

H&J in the range. To select non-consecutive H&Js, press Command/Ctrl

last
while you click each

H&Js, click the first H&J and press Shift while you click the

H&J.

Include column. To

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

77

|

H&JS

SAVE (BUTTON)

Default H&Js dialog box

The Save button saves changes made to any hyphenation and justification
specifications in the

H&Js dialog box.

EDIT HYPHENATION & JUSTIFICATION (DIALOG BOX)

Default H&Js dialog box Þ New, Edit or Duplicate

Click New, Edit, or Duplicate in the H&Js dialog box to display the Edit
Hyphenation & Justification

dialog box, which enables you to create or edit

a hyphenation and justification specification.

Edit Hyphenation & Justification dialog box

NAME (FIELD)

Edit Hyphenation & Justification dialog box

In the Name field, enter a name for a new hyphenation and justification
specification, or rename an existing hyphenation and justification specification.

AUTO HYPHENATION (AREA)

Edit Hyphenation & Justification dialog box

Use the Auto Hyphenation area to determine the way QuarkXPress Server
performs automatic hyphenation.

• Check

Auto Hyphenation to hyphenate paragraphs automatically. It is checked

by default.

Smallest Word field specifies the minimum number of characters a word

• The
must contain to be hyphenated. Enter a value from 3 to 20. The default setting
is 6.

Minimum Before field specifies the smallest number of characters that

• The
must precede an automatic hyphen. Enter a value from 1 to 6. The default
setting is 3.

78

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

H&JS

The Minimum Afterfield specifies the smallest number of characters that must

•
follow an automatic hyphen. Enter a value from 2 to 8. The default setting is 2.

Check Break Capitalized Wordsto hyphenate words that start with an upper-

•
case character (for example, proper nouns and the first words of sentences).
It is unchecked by default.

The Auto Hyphenation controls do not affect manual hyphenation (the use
of manually inserted hyphens and discretionary hyphens to control word
breaks and text flow within projects).

HYPHENS IN A ROW (DROP-DOWN MENU & FIELD)

Edit Hyphenation & Justification dialog box

In the Hyphens in a Row field, enter the maximum number of consecutive
lines that can end in manually or automatically hyphenated words. You can
enter any value from 0 to 7. If you do not want to limit the number of con­secutive lines that end with a hyphen, enter “0” or choose
the field’s drop-down menu. The default setting is

unlimited.

unlimited from

HYPHENATION ZONE (FIELD)

Edit Hyphenation & Justification dialog box

Enter a value in the Hyphenation Zone field, to define the area within which
hyphenation (automatic or manual) can occur. The

Hyphenation Zone is

measured from the right indentation to the end of a line of text.

• When you specify a
hyphenates a word only when the previous word ends before the

Zone

and an acceptable hyphenation point falls within the Hyphenation Zone.

Hyphenation Zone greater than 0", QuarkXPress Server

Hyphenation

Hyphenation Zone values apply only to non-justified text.

Hyphenation Zone value of 0" indicates a no Hyphenation Zone. In this

•A
case, QuarkXPress Server either hyphenates a word according to the other
hyphenation criteria or wraps it to the next line if it does not fit completely
on the line. This is the default setting.

JUSTIFICATION METHOD (AREA)

Edit Hyphenation & Justification dialog box

Justified lines of text extend from the left to the right indentation within a
column or box. Lines are justifi
words and characters. The values in the
word space and characters are adjusted to justify a line. The

ed by adding or removing the spacing between

Space and Char fields determine how

Opt. (Mac OS) or

Optimum (Windows) spacing values apply to all text.

SPACE (FIELDS)

Edit Hyphenation & Justification dialog box

Use the Space fields to enter the amount of space QuarkXPress Server can add
or remove between words in lines of justified text.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

79

|

H&JS

Enter percentages of the normal interword space for the font and size in use

•
in the

Min./Minimum, Opt./Optimum, and Max./Maximum fields.

Enter the number of lines of text for justifying in the

•
If the application is unable to justify text using the
varies word spacing within the range specified in the

pt./Optimumvalue.

O

Opt./Optimum value, it

Min./Minimum and

Max./Maximum fields.

• QuarkXPress Server never spaces words closer than the
but the application might exceed the

Max./Maximum value if there is no

Min./Minimum value,

other way to justify a line.

• For non-justified text, QuarkXPress Server always spaces words according to
the

Opt./Optimum value.

CHARACTER (FIELDS)

Edit Hyphenation & Justification dialog box

Use the Char fields to enter the amount of space QuarkXPress Server can add
or remove between the characters in lines of justified text.

• Enter percentages of an en space for the current font size in the

Opt./Optimum,

and Max./Maximum fields.

• Enter the space characters for justifying lines of text in the

Min./Minimum,

Opt./Optimum

fields. If the application is unable to justify text using the Opt./Optimum value,
it varies character spacing within the range specified in the

Min./Minimum and

Max./Maximum fields.

• QuarkXPress Server never spaces characters closer than the

Min./Minimum

value, but the application might exceed the Max./Maximum value if there is
no other way to justify a line.

• For non-justified text, QuarkXPress Server always spaces characters according

Opt./Optimum value.

to the

By default, QuarkXPress Server defines an en space as the width of a zero in the
current font. However, if you check
of the

Preferences dialog box (QuarkXPress Server Þ Preferences), QuarkXPress

Standard Em Space in the Character pane

Server uses half the width of the current font size for the en space (for example,
24-point text has a 12-point en space).

FLUSH ZONE (FIELD)

Edit Hyphenation & Justification dialog box

Use the Flush Zone field to control whether the last line of text in a justified
paragraph automatically extends to the right indentation. When the last line
of a justified paragraph ends within the

Flush Zone (measured from the right

indentation), space is added between characters and words so that the text
extends from the left to the right indentation. If the last line of a paragraph
does not fall within the specified Flush Zone (the text ends to the left of the
Flush Zone), the last line is not justified.

80

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

SINGLE WORD JUSTIFY (CHECK BOX)

Edit Hyphenation & Justification dialog box

Check Single Word Justify to specify that a single word alone on a line in a
justified paragraph extends from the left indentation to the right indentation.
When

OUTPUT STYLES

The Output Styles command displays the Output Styles dialog box, which
enables you to create and manage custom output styles. An output style is a
group of print settings that you implement at output. Using output styles
eliminates the need to re-create complex or frequently used print settings
every time you print. Output styles are available when rendering a project in
EPS, PDF, PPML, and PostScript format.

When QuarkXPress Server renders a project, any output style that was applied by
QuarkXPress is overridden. If the client specifies an output style in the request,
that output style is used; otherwise, the default QuarkXPress Server output
style is applied instead.

OUTPUT STYLES (DIALOG BOX)

Server/QuarkXPress Server Þ Document Controls Þ Output Styles

Use the Output Styles dialog box to create, edit, duplicate, and delete output
styles. You can also import and export output styles. You can select output
styles from the top list of this dialog box, which displays the available output
styles; the bottom list displays the attributes of the selected output style.

H&JS

Single Word Justify is unchecked, single words are not justified.

Output Styles dialog box

OUTPUT STYLES (LIST)

Output Styles dialog box

The Output Styles list displays all output styles. Output styles are always
created as default settings for the application and never for the project.

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

|

81

OUTPUT STYLES

NEW (DROP-DOWN BUTTON)

Output Styles dialog box

To create an output style, choose an option from the New drop-down button:
PDF, Print, PPML, or EPS. Depending on the option you choose, the Edit PDF
Style, Edit Print Style, Edit PPML Style,

or Edit EPS style dialog box displays.

You can create up to 1,000 output styles.

EDIT (BUTTON)

Output Styles dialog box

Click Edit to display the Edit Output Style dialog box for the output style
selected in the

Output Styles list. Use the Edit Output Style dialog box to

modify an output style’s name and definition. You can also double-click an
output style to display the

Edit Output Style dialog box.

DUPLICATE (BUTTON)

Output Styles dialog box

Click Duplicate to create a copy of the selected output style. QuarkXPress Server
opens the

Edit Output Style dialog box so that you can rename and edit the

copied output style.

DELETE (BUTTON)

Output Styles dialog box

Click Delete to remove the selected output styles. You cannot delete the Default
output style.

IMPORT (BUTTON)

Output Styles dialog box

Click Import to import an output style file that you have created using the
Export button. The Import Output Styles dialog box displays; use this dialog

box to select an output style file to import.

EXPORT (BUTTON)

Output Styles dialog box

To export the selected output styles to a file, click Export. In the dialog box
that displays, specify the name and the location for the new output styles file.

Save to complete the export.

Click

SAVE (BUTTON)

Output Styles dialog box

Click Save to save changes made to any output styles and close the Output
Styles

dialog box.

EDIT EPS STYLE (DIALOG BOX)

Output Styles dialog box Þ New, Edit, or Duplicate

Use the the Edit EPS Style dialog box to create or edit EPS output styles. T
display the
button or click

Edit EPS Style dialog box, choose EPS from the New drop-down

Edit or Duplicate in the Output Styles dialog box.

o

82

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

|

ACE

OUTPUT STYLES

Edit EPS Style dialog box

EPS STYLE (FIELD)

Edit EPS Style dialog box

In the EPS Style field, enter a name for a new EPS output style or rename an
existing EPS output style.

FORMAT (DROP-DOWN MENU)

Edit EPS Style dialog box

Use the Format drop-down menu to indicate which format EPS files should be
rendered in:

•

Standard EPS: Choose this option to create single-file EPS files.

Multiple File DCS: Choose this option to create multiple-file DCS files.

•

Single File DCS: Choose this option to create single-file DCS files.

•

PANES

Edit EPS Style dialog box

The Edit EPS Style dialog box includes the following panes:

• The General pane

The

Color pane

•

Marks pane

• The

Fonts pane

• The

Bleed pane

• The

Transparency pane

• The

OPI pane

• The

JDF pane

• The

Advanced pane

• The

Summary pane

• The

CHAPTER 2: THE QUARKXPRESS SERVER USER INTERF

ACE

83

|

OUTPUT STYLES

GENERAL (PANE)

Edit EPS Style dialog box

Use the General pane to set scaling, preview, and other general options for
EPS output.

Edit EPS Style dialog box displaying General pane

SCALE (FIELD)

Edit EPS Style dialog box Þ General pane

Enter a percentage value in the Scale field to specify the dimensions of your
EPS image.

PREVIEW (DROP-DOWN MENU)

Edit EPS Style dialog box Þ General pane

Choose an option from the Preview drop-down menu to create a preview.
On Mac OS, choose

PICT or TIFF to create a screen preview, or choose None

to exclude the preview. On Windows, choose TIFF to create a screen preview
of the EPS file, or choose

None to exclude the preview.

DATA (DROP-DOWN MENU)

Edit EPS Style dialog box Þ General pane

For pages that contain bitmap (raster) data, choose an option from the Data
drop-down menu to control how the data is included in the EPS file. Choose

Binary, ASCII, or Clean 8-bit.

from

EXCLUDE PAGE WHITE (CHECK BOX)

Edit EPS Style dialog box Þ General pane

Check Exclude Page White to make the page area transparent. If Exclude
Page White

is unchecked, everything within the EPS fi

le’s bounding box will

be opaque.

SPREAD (CHECK BOX)

Edit EPS Style dialog box Þ General pane

Check Spread to generate an EPS fi

le of the entire spread where the specifi

ed

page is located.
