Quark QuarkXPress Server - 10.1 Operation Manual

Download

A Guide to QuarkXPress Server 10.1

Contents

Conventions..................................................................................9

Getting started with QuarkXPress Server.................................10

QuarkXPress Server architecture....................................................................10

Understanding QuarkXPress Server...............................................................10

Server templates and static projects.......................................................................11

The document pool and the Streaming Document Provider..................................11

Projects and layouts................................................................................................12

Job Jackets and resources......................................................................................12

Caching...................................................................................................................13

QuarkXPress Server preferences.............................................................................13

Quark License Administrator...................................................................................13

Master-renderer environment.................................................................................13

Changing logging levels in "log4j.xml"..................................................................14

Understanding QuarkXPress Server XTensions software...............................15

The QuarkXPress Server XTensions API..................................................................15

Configuring QuarkXPress Server for launch...................................................16

Launching QuarkXPress Server.......................................................................16

Quitting QuarkXPress Server..........................................................................17

The QuarkXPress Server user interface.....................................18

Navigation pane..............................................................................................18

Administration menu.......................................................................................20

General Preferences dialog box..............................................................................20

Renderer Preferences dialog box............................................................................23

Job Jackets dialog box...........................................................................................31

App Studio preferences..........................................................................................32

Check Out License dialog box................................................................................32

Using QuarkXPress Server.........................................................33

Creating URL requests....................................................................................33

Understanding URL requests...................................................................................34

Understanding QuarkXPress Server namespaces...................................................34

Understanding QuarkXPress Server parameters.....................................................35

Supported interfaces.......................................................................................35

The Dynamic Publishing Process (DPP)...........................................................36

Getting started................................................................................................36

Getting started: HTTP and HTTPS..........................................................................36

ii | A GUIDE TO QUARKXPRESS SERVER 10.1

CONTENTS

Getting started: Web services.................................................................................41

QXP Server Manager...............................................................................................49

Using the Web interface..................................................................................49

Understanding rendering........................................................................................50

Understanding logging...........................................................................................51

Understanding render types...................................................................................51

Understanding render modifiers.............................................................................73

Using content modifiers..........................................................................................82

Using XML modify...................................................................................................89

Using XML deconstruct and construct..................................................................106

Creating and using hyperlinks...............................................................................141

Using the Streaming Document Provider..............................................................142

Using administrative request handlers..................................................................143

Using the QXPSM SDK..................................................................................163

Writing a Java QXPSM client................................................................................163

Writing a .NET QXPSM client................................................................................165

Writing an Objective-C client for Mac OS or iOS..................................................167

Extending QuarkXPress Server Manager..............................................................170

Sample applications.......................................................................................175

Sample applications: QXP Server Manager..........................................................175

Sample applications legal notice..........................................................................177

QuarkXPress Server Features..................................................185

Dynamic Pagination and Flow.......................................................................185

Dynamic Pagination and Flow Problem................................................................186

Dynamic Pagination and Flow Solution.................................................................187

Landscape pagination....................................................................................190

Modifier schema (annotated)....................................................194

Entities (Modifier DTD).................................................................................194

ADDCELLS (Modifier schema).......................................................................196

ALIGNHORSETTINGS (Modifier schema)......................................................197

ALIGNVERSETTINGS (Modifier schema).......................................................198

ALLOWBOXOFFPAGE (Modifier schema).....................................................198

ALLOWBOXONTOPASTEBOARD (Modifier schema)....................................198

ANCHOREDBOXREF (Modifier schema).......................................................199

ARTICLE (Modifier schema)...........................................................................200

AUTHOR (Modifier schema)..........................................................................200

BNSTYLE (Modifier schema)..........................................................................200

BOTTOM (Modifier schema)..........................................................................201

BOTTOMGRID (Modifier schema).................................................................201

BOX (Modifier schema).................................................................................202

BOXATTRIBUTE (Modifier schema)...............................................................204

BOXREF (Modifier schema)...........................................................................205

CALLOUTANCHOR (Modifier schema)..........................................................206

A GUIDE TO QUARKXPRESS SERVER 10.1 | iii

CONTENTS

CALLOUTBOXREF (Modifier schema)...........................................................206

CELL (Modifier schema).................................................................................206

CHILDID (Modifier schema)...........................................................................208

CLIPPING (Modifier schema).........................................................................208

COLGROUP (Modifier schema)......................................................................211

COLSPEC (Modifier schema).........................................................................211

COLUMN (Modifier schema).........................................................................211

COMPONENT (Modifier schema)..................................................................212

COMPOSITIONZONE (Modifier schema)......................................................214

CONDITIONALMASTERPAGEREFERENCE (Modifier schema).....................216

CONTENT (Modifier schema)........................................................................216

CONTENTPH (Modifier schema)...................................................................217

CONTINUEDHEADER (Modifier schema)......................................................218

CONTINUEDTROWSTYLE (Modifier schema)................................................218

CONTOUR (Modifier schema).......................................................................219

CONTOURS (Modifier schema).....................................................................219

COPYFIT (Modifier schema)..........................................................................220

DATAPROVIDER (Modifier schema)..............................................................220

DEL (Modifier schema)..................................................................................221

DELETECELLS (Modifier schema)..................................................................221

DESCRIPTION (Modifier schema)..................................................................221

DROPCAP (Modifier schema)........................................................................222

EBOOKMETADATA (Modifier schema).........................................................222

ENTRY (Modifier schema)..............................................................................222

EVENTCOLSTYLE (Modifier schema)............................................................223

EVENTROWSTYLE (Modifier schema)...........................................................223

FIRSTTCOLSTYLE (Modifier schema).............................................................224

FIT (Modifier schema)....................................................................................224

FITTEXT (Modifier schema)...........................................................................225

FOOTER (Modifier schema)...........................................................................226

FOOTERTROWSTYLE (Modifier schema).......................................................226

FORMAT (Modifier schema)..........................................................................227

FRAME (Modifier schema).............................................................................229

GEOMETRY (Modifier schema)......................................................................230

GRID (Modifier schema)................................................................................231

GRIDLINE (Modifier schema).........................................................................231

GROUP (Modifier schema)............................................................................232

GROUPCHARACTERS (Modifier schema)......................................................233

GROWACROSS (Modifier schema)................................................................234

GROWDOWN (Modifier schema)..................................................................234

HEADER (Modifier schema)...........................................................................234

HEADTROWSTYLE (Modifier schema)...........................................................234

HEIGHT(Modifier schema).............................................................................235

HIDDEN (Modifier schema)...........................................................................235

HYPERLINK (Modifier schema)......................................................................236

iv | A GUIDE TO QUARKXPRESS SERVER 10.1

CONTENTS

ID (Modifier schema).....................................................................................237

INLINEBOX (Modifier schema)......................................................................237

INLINETABLE (Modifier schema)...................................................................239

INS (Modifier schema)...................................................................................239

INSET (Modifier schema)...............................................................................239

INTERACTIVITY (Modifier schema)...............................................................240

ISBN (Modifier schema).................................................................................241

KEEPLINESTOGETHER (Modifier schema)....................................................241

KEYWORDS (Modifier schema).....................................................................241

LASTTCOLSTYLE (Modifier schema)..............................................................241

LAYER (Modifier schema)..............................................................................242

LAYOUT (Modifier schema)...........................................................................243

LAYOUTREF (Modifier schema).....................................................................244

LEFT (Modifier schema).................................................................................245

LEFTCONTROLPOINT (Modifier schema)......................................................245

LEFTGRID (Modifier schema)........................................................................245

LINESTYLE (Modifier schema).......................................................................246

LINKEDBOX (Modifier schema).....................................................................247

LIST (Modifier schema)..................................................................................248

LOCATION (Modifier schema).......................................................................248

LOCKTOGRID (Modifier schema)..................................................................248

MASTERPAGESEQUENCE (Modifier schema)...............................................249

MAX (Modifier schema).................................................................................249

METADATA (Modifier schema).....................................................................249

MIN (Modifier schema)..................................................................................249

MOVEDOWN (Modifier schema)...................................................................250

MOVELEFT (Modifier schema)......................................................................250

MOVERIGHT (Modifier schema)....................................................................250

MOVEUP (Modifier schema)..........................................................................250

NOTE (Modifier schema)...............................................................................250

ODDTROWSTYLE (Modifier schema)............................................................251

ODDTCOLSTYLE (Modifier schema)..............................................................251

ORIGIN (Modifier schema)............................................................................252

OVERMATTER (Modifier schema).................................................................252

PAGE (Modifier schema)...............................................................................252

PAGEBREAK (Modifier schema)....................................................................253

PAGEREF (Modifier schema).........................................................................254

PAGESEQUENCE (Modifier schema).............................................................254

PARAGRAPH (Modifier schema)...................................................................256

PARENTTABLE (Modifier schema).................................................................257

PICTURE (Modifier schema)...........................................................................257

PLACEHOLDER (Modifier schema)................................................................260

POSITION (Modifier schema)........................................................................260

PROJECT (Modifier schema)..........................................................................260

PUBLICATION (Modifier schema)..................................................................261

PUBLICATIONCHANNEL (Modifier schema).................................................262

A GUIDE TO QUARKXPRESS SERVER 10.1 | v

CONTENTS

PUBLISHER (Modifier schema)......................................................................262

RELPOSITION (Modifier schema)..................................................................262

REPEATABLEMASTERPAGEALTERNATIVES (Modifier schema)...................262

REPEATABLEMASTERPAGEREFERENCE (Modifier Schema).......................263

RGBCOLOR (Modifier schema)......................................................................263

RICHTEXT (Modifier schema)........................................................................264

RIGHT (Modifier schema)..............................................................................272

RIGHTCONTROLPOINT (Modifier schema)...................................................272

RIGHTGRID (Modifier schema)......................................................................273

ROW (Modifier schema)................................................................................273

RUBI (Modifier schema).................................................................................275

RUBITEXT (Modifier schema)........................................................................275

RULE (Modifier schema)................................................................................276

RUNAROUND (Modifier schema)..................................................................278

SAVEAS (Modifier schema)...........................................................................280

SCALETO (Modifier schema).........................................................................281

SECTION (Modifier schema)..........................................................................282

SECTIONNUMBERFORMAT (Modifier schema)............................................282

SHADOW (Modifier schema).........................................................................282

SHRINKACROSS (Modifier schema)..............................................................284

SHRINKDOWN (Modifier schema)................................................................285

SINGLEMASTERPAGEREFERENCE (Modifier schema).................................285

SIZE (Modifier schema)..................................................................................285

SPINEIMAGE (Modifier schema)...................................................................286

SPLINESHAPE (Modifier schema)..................................................................286

SPREAD (Modifier schema)...........................................................................287

STACKINGORDER (Modifier schema)...........................................................287

STATICCONTENT (Modifier schema)............................................................287

STORY (Modifier schema)..............................................................................288

SUPPRESSOUTPUT (Modifier schema)..........................................................289

TAB (Modifier schema)..................................................................................289

TABLE (Modifier schema)..............................................................................289

TABLEBREAK (Modifier schema)...................................................................291

TABLESTYLE (Modifier schema)....................................................................292

TABSPEC (Modifier schema)..........................................................................292

TBODY (Modifier schema).............................................................................292

TCOL (Modifier schema)................................................................................293

TCOLSTYLE (Modifier schema)......................................................................293

TCONTINUED (Modifier schema)..................................................................293

TEXT (Modifier schema)................................................................................294

TEXTATTRIBUTE (Modifier schema)..............................................................295

TEXTNODEPH (Modifier schema).................................................................295

TEXTPH (Modifier schema)............................................................................296

TFOOT (Modifier schema).............................................................................297

THEAD (Modifier schema).............................................................................297

TITLE (Modifier schema)................................................................................297

vi | A GUIDE TO QUARKXPRESS SERVER 10.1

CONTENTS

TOP (Modifier schema)..................................................................................297

TOPGRID (Modifier schema).........................................................................297

TROW (Modifier schema)..............................................................................298

TROWSTYLE (Modifier schema)....................................................................299

VALUE (Modifier schema).............................................................................299

VERTEX (Modifier schema)............................................................................300

VERTEXPOINT (Modifier schema).................................................................300

VERTICES (Modifier schema).........................................................................301

WIDTH (Modifier schema).............................................................................301

Using SSL..................................................................................302

Secure Sockets Layer (SSL) support..............................................................302

Enabling SSL..........................................................................................................302

Enabling HTTP and HTTPS....................................................................................303

Verifying and using SSL.........................................................................................303

Keystores and SSL certificates...............................................................................303

QuarkXPress Server XTensions software.................................304

CopyDeskArticle XTensions software...........................................................304

Rendering articles..................................................................................................304

Exporting articles...................................................................................................304

Adding articles to projects....................................................................................305

Creating and deleting components......................................................................305

PDF Filter XTensions software......................................................................306

Modifier XTensions software........................................................................306

Using Modifier XTensions software.......................................................................307

Creating XML for Modifier XTensions software....................................................307

Layer XTensions software.............................................................................308

App Studio XTensions software....................................................................308

Telegraph XTensions software.................................................310

Setting Telegraph preferences......................................................................310

Specifying a server for template upload...............................................................311

Using Telegraph XTensions software............................................................312

Identifying QuarkXPress items and groups...........................................................312

Naming items and groups.....................................................................................313

Uploading templates.............................................................................................313

Uploading missing or modified pictures...............................................................315

QuarkXPress Server Manager..................................................316

Understanding QuarkXPress Server Manager..............................................316

Load balancing......................................................................................................316

Request timeout interval.......................................................................................317

Determining QuarkXPress Server instance availability..........................................318

Logging with QXP Server Manager.......................................................................318

A GUIDE TO QUARKXPRESS SERVER 10.1 | vii

CONTENTS

Caching.................................................................................................................319

Web services.........................................................................................................319

Working with QuarkXPress Server Manager................................................319

Starting QuarkXPress Server Manager..................................................................320

Request handler binding.......................................................................................321

Configuring QuarkXPress Server instances...........................................................321

Managing the cache..............................................................................................325

Managing logs.......................................................................................................327

Using a proxy server..............................................................................................330

Generating automatic e-mail messages................................................................330

Using other global settings...................................................................................331

Saving a server configuration................................................................................332

Using custom error messages...............................................................................333

Sending requests from a browser.........................................................................334

The XTensions Developer Kit (XDK).........................................336

Glossary....................................................................................337

Legal notices.............................................................................338

viii | A GUIDE TO QUARKXPRESS SERVER 10.1

Conventions

Formatting conventions highlight information to help you quickly find what you

need.

• Bold type style: The names of all dialog boxes, fields, and other controls are set in bold

type. For example: "Click OK."

• References: In descriptions of features, parenthetical references guide you in accessing

those features. For example: "The Find/Change dialog box (Edit menu) lets you find

and replace text."

CONVENTIONS

• Arrows: You will often see arrows (>), which map out the menu path to a feature. For

example: "Choose Edit > Style Sheets to display the Style Sheets dialog box."

• Icons: Although many tools and buttons are referenced by name, which you can see

by displaying ToolTips, in some cases icons are shown for easy identification. For

example, "Click the button on the Measurements palette to center text."

• Cross-platform issues: This application is quite consistent across operating systems.

However, some labels, buttons, key combinations, and other aspects of the application must differ between Mac OS® and Windows® because of user interface conventions

or other factors. In such cases, both the Mac OS and Windows versions are presented,

separated by a slash, with the Mac OS version presented first. For example, if the

Mac OS version of a button is labeled Select, and the Windows version is labeled

Browse, you are directed to "Click Select/Browse." More complex cross-platform

differences are mentioned in notes or parenthetical statements.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 9

GETTING STARTED WITH QUARKXPRESS SERVER

Getting started with QuarkXPress Server

QuarkXPress Server lets you render QuarkXPress projects in a variety of formats.

QuarkXPress Server architecture

The QuarkXPress Server architecture is shown in the following diagram.

QuarkXPress Server architecture diagram

Understanding QuarkXPress Server

QuarkXPress Server lets you output customized QuarkXPress layouts in a variety of formats — including JPEG, Portable Document Format (PDF), and PostScript® — from

a centralized QuarkXPress Server application. To send a request to a QuarkXPress Server

10 | A GUIDE TO QUARKXPRESS SERVER 10.1

GETTING STARTED WITH QUARKXPRESS SERVER

application, all you need to do is enter a URL into your Web browser's address field.

For example, the following URL instructs the QuarkXPress Server application named

"QXPServer" to return the file "MyProject.qxp" as a PDF file:

http://QXPServer:8080/pdf/MyProject.qxp

The QuarkXPress Server application receives these requests, renders (creates) the

requested projects in the requested formats, and then returns the rendered file to the

client application (in this case, the Web browser).

The format of QuarkXPress Server URL requests is described in detail in "Creating URL

requests" and in "Using QuarkXPress Server."

You can also create custom applications that communicate with a QuarkXPress Server

application using HTTP, Simple Object Access Protocol (SOAP), or another protocol.

For more information, see "Using QuarkXPress Server."

You can think of QuarkXPress Server as a special version of QuarkXPress that runs on

a server with the following main differences:

• Instead of accepting input from a keyboard and mouse, QuarkXPress Server accepts

input in the form of URLs and other types of requests.

• Instead of sending a project to a printer, QuarkXPress Server renders (creates) output

in a particular format and sends the rendered file to a client.

Server templates and static projects

QuarkXPress Server can open, render, and serve two types of projects:

• Static projects are QuarkXPress projects that can be rendered and served as-is in a variety

of formats by the QuarkXPress Server application. For example, you might make a

product manual available as a static project and allow customers to download that

manual in a variety of formats.

• Server templates are QuarkXPress projects that can be manipulated by the

QuarkXPress Server application before being rendered and served. For example, you

might make a sales piece available as a server template so that each person who

downloads it receives a personalized copy.

QuarkXPress Server can open QuarkXPress documents, projects, and templates created

in any language edition of QuarkXPress 7.0 or later. QuarkXPress Server can save and

export projects in QuarkXPress 8.x, 9.x and 10.x format.

The document pool and the Streaming Document Provider

QuarkXPress Server has two main ways to find or receive content for rendering.

• The document pool

• The Streaming Document Provider

QuarkXPress Server can read templates and static projects from a directory called the

document pool. The document pool can be any directory that is available to

A GUIDE TO QUARKXPRESS SERVER 10.1 | 11

GETTING STARTED WITH QUARKXPRESS SERVER

QuarkXPress Server through a file system or an FTP server. You can use any of the

following methods to place files in the document pool:

• Drag the files to the document pool directory.

• Use the Add Files command in the Document Pool screen of the QuarkXPress Server

Web interface.

• Upload the files using FTP to the document pool directory.

• Use Telegraph XTensions® software to upload the files to the document pool from

within QuarkXPress. (For more information about Telegraph XTensions software, see

"Telegraph XTensions software.")

For more information about the document pool, see "The QuarkXPress Server user

interface."

The document pool directory cannot be an encrypted directory.

QuarkXPress Server can also receive templates, projects, and other files as part of a

multipart HTTP request. For more information, see "Using the Streaming Document

Provider."

In addition, QuarkXPress Server can serve documents from a database, a content

management system, or other sources. Collectively, the document pool and any other

source of files to be served are referred to as document providers.

Projects and layouts

QuarkXPress projects can contain one or more layouts, and only one layout can be

rendered at any given time. If you do not specify a layout when you send a rendering

request, QuarkXPress Server renders the first layout in the project.

Job Jackets and resources

In QuarkXPress, resources are things such as style sheets, colors, H&Js, output styles,

and item styles. Resources are stored in a Job Jackets structure, which can be either

embedded in a project or stored in a separate Job Jackets file.

QuarkXPress Server uses a default Job Jackets file to make a default set of resources

available to all projects handled by QuarkXPress Server, regardless of whether they are

included in the projects and articles you render. You can update this file in two ways:

• Using the QuarkXPress Server Web interface. For more information, see "Job Jackets

dialog box."

• Using request handlers. For more information, see "Jobjacket" and "updateprefsfromjj."

Once you've downloaded the default Job Jackets file, you can update its resources using

QuarkXPress. For more information, see "Job Jackets" in A Guide to QuarkXPress.

The location of the default Job Jackets file is stored in the QuarkXPress Server

preferences folder. For more information, see "QuarkXPress Server preferences."

12 | A GUIDE TO QUARKXPRESS SERVER 10.1

Caching

To maximize efficiency, QuarkXPress Server uses cached versions of all rendered projects

whenever possible. You can configure projects so that they are never cached, so that

they are cached for a particular amount of time, or so that they are rendered every

time they are served.

QuarkXPress Server preferences

When you launch QuarkXPress Server, the application creates preferences files that

are functionally and structurally equivalent to the preferences files created by

QuarkXPress. These preferences files reside in the QuarkXPress Server "Preferences"

folder. QuarkXPress Server also creates a "QuarkXPress Server.prf" file in the "Preferences"

folder. This file contains preference settings that are specific to QuarkXPress Server.

QuarkXPress Server uses these preferences the same way QuarkXPress uses them. If an

XTensions module creates a project in QuarkXPress Server, that project draws its

settings from the QuarkXPress Server preferences just as a new QuarkXPress project

draws its settings from the QuarkXPress preferences.

Preferences files are stored in the following locations:

GETTING STARTED WITH QUARKXPRESS SERVER

•

Mac OS: [User]/Library/Preferences/Quark/QuarkXPress Server Renderer

10.0/

• Windows Vista, Windows 2008, or Windows 2008 R2 64-bit when QuarkXPress Server

is running normally or as a service under a domain user account: C:\Users\[user

name]\AppData\Roaming\Quark\QuarkXPress Server Renderer 10.0\

• Windows 2008 or Windows Vista, when QuarkXPress Server is running as a service

under a local user account:

C:\Windows\System32\config\systemprofile\AppData\Roaming\Quark\QuarkXPress Server Renderer 10.0\

• Windows 2008 R2 64-bit, when QuarkXPress Server is running as a service under a

local user account:

C:\Windows\SysWOW64\config\systemprofile\AppData\Roaming\Quark\QuarkXPress Server Renderer 10.0

For more information about preferences, see "Administration menu."

Quark License Administrator

To prevent unauthorized use, QuarkXPress Server requires the presence of a Quark®

License Administrator (QLA) server to launch. QuarkXPress Server follows the

configuration and control rules that are enforced by QLA. For more information about

QLA, see the QLA documentation included with QuarkXPress Server.

Master-renderer environment

Requests for project renders are stored in a connection queue. The requests in the

rendering queue can be processed by a single QuarkXPress Server application, or by a

master QuarkXPress Server application and several renderers (additional instances of

QuarkXPress Server). The master QuarkXPress Server application launches the available

number of renderers and then passes the requests in the connection queue to those

A GUIDE TO QUARKXPRESS SERVER 10.1 | 13

GETTING STARTED WITH QUARKXPRESS SERVER

renderers as they become available. The number of renderers available for launch is

determined by the number of licenses available from the QLA server.

The master QuarkXPress Server process and all of the renderers it launches share the

following elements:

• The same application preferences (each renderer has its own preferences files, but

QuarkXPress Server keeps them synchronized)

• The same document cache in memory

• The same memory cache

• The same server XTensions modules (a separate instance of each XTensions module

runs with each renderer)

• The same server document pool (if defined in the QuarkXPress Server preferences or

if a document provider is used in place of the document pool)

If a renderer unexpectedly quits, the master QuarkXPress Server restarts the renderer

without requiring any action from you.

Changing logging levels in "log4j.xml"

You can change the logging levels for QuarkXPress Server. Options include ERROR,

INFO, WARN, DEBUG, and TRACE.

•

ERROR = includes messages that indicate disrupted and failed requests.

•

INFO = includes messages that indicate the state of services.

•

WARN = includes non-critical service error messages

•

DEBUG = includes messages that indicate server resource usage.

•

TRACE = includes messages according to activity related to requests.

Refer to Java documentation for more information about logging levels.

To change logging levels:

Open the "conf" folder in your QuarkXPress Server folder.

Open "log4j.xml" in a text-editing application.

To define the logging level for QuarkXPerss Server errors, scroll to <logger

name=com.quark.qxps. The structure is as follows:

To define the logging level for QuarkXPress Server transactions, scroll to <logger

name=QXPSTransactionLogger. The structure is as follows:

14 | A GUIDE TO QUARKXPRESS SERVER 10.1

GETTING STARTED WITH QUARKXPRESS SERVER

To define the logging level for other activity, scroll to the <root>. The structure is as

follows:

Save and close "log4j.xml."

Understanding QuarkXPress Server XTensions software

QuarkXPress Server ships with a collection of XTensions software that adds capabilities

to QuarkXPress Server. For example, PDF Export XTensions software lets

QuarkXPress Server serve content in PDF format; Modifier XTensions software lets you

retrieve, manipulate, and reconstruct XML representations of projects; and QuarkCopyDesk® Renderer XTensions software lets you create QuarkCopyDesk articles.

Telegraph XTensions software works with QuarkXPress to allow designers to name

boxes in template files so that those boxes can be addressed by URLs.

For more information about XTensions software included with QuarkXPress Server,

see "QuarkXPress Server XTensions software" and "Telegraph XTensions software."

The QuarkXPress Server XTensions API

In addition to the XTensions modules included with QuarkXPress Server, developers

can create custom XTensions software that add features. The complete server XTensions

Application Programming Interface (API) documentation is available in the

QuarkXPress Server XTensions Developer's Kit (XDK).

As of version 8.0, the QuarkXPress Server XDK is Unicode-compliant.

The QuarkXPress Server XDK lets you create XTensions modules that provide the

following abilities:

• The ability to register request handlers

• The ability to register project providers

• The ability to register new render formats

• The ability to add items to the list of response properties, cookies, and HTTP header

items

• The ability to log messages in log files

• The ability to initiate a new transaction to be processed by the server

• The ability to completely control how projects are processed by the server

In addition, QuarkXPress Server XTensions software can register for the following basic

callbacks:

• Pre-processing

• Content loading

• Layout modification

A GUIDE TO QUARKXPRESS SERVER 10.1 | 15

GETTING STARTED WITH QUARKXPRESS SERVER

• Post-processing

• Removing slugs while running the QuarkXPress project renderer

• Analyzing the server after a transaction is complete

• Pre- and post-transaction callback

Configuring QuarkXPress Server for launch

To configure QuarkXPress Server prior to launch, open the file [QuarkXPress Server

application folder]/conf/ServerApp.properties folder) and modify it as

follows:

•

To make the server run without loading any network interface, use the -nonetwork option with the qxpservercore.serverRendererParameters. In this mode, the

only transactions a server can run are those passed to it by another process.

• To control whether renderers are monitored, set

qxpservercore.monitorrenderers.value to true or false.

• To specify the query interval for monitoring renderers, set

qxpservercore.monitorrenderers.queryinterval.value to a value in seconds.

• To specify the number of retries for monitoring renderers, set

qqxpservercore.monitorrenderers.noofretries.value to an integer. If a

renderer process has been attempting to fulfill a request for the specified number of

retries (with the specified query interval in seconds between retries), the renderer

monitor recyles that process.

• To control how many renderers the master process launches, specify a number for

qxpserver.subrenders. Note that the number of renderers you can launch depends

on your license.

• To force the renderers to restart on a periodic basis, specify a value in hours for

qxps.render.recycle.interval. The default value is 24, or 24 hours. Decimal

values are permitted. Renderers restart serially, so one renderer doesn't restart until

the other is finished restarting. If a renderer is busy, the master process waits for 15

minutes, and then if the renderer is till busy, postpones the restart until the next

interval elapses. Set this value to zero to turn the automatic restart feature off.

Launching QuarkXPress Server

On Windows, you can install QuarkXPress Server as an application or as a service

(Quark recommends that you always run it as a service). On Mac OS, QuarkXPress

Server always runs as an application.

If you install QuarkXPress Server on Windows as an application, you can launch it

using the Start menu or by double-clicking the "ServerStartup.bat" in the QuarkXPress

Server application folder.

If you want to launch QuarkXPress Server as an application on Windows Server 2008

Quark recommends executing "ServerStartup.bat" as an administrator.

16 | A GUIDE TO QUARKXPRESS SERVER 10.1

For information on launching QuarkXPress Server in a separate Tomcat installation,

see "Deploying QuarkXPress Server externally" in the QuarkXPress Server ReadMe.

QuarkXPress Server offers a browser-based user interface instead of a conventional user

interface.

Quitting QuarkXPress Server

To quit QuarkXPress Server, press Control+C.

GETTING STARTED WITH QUARKXPRESS SERVER

A GUIDE TO QUARKXPRESS SERVER 10.1 | 17

THE QUARKXPRESS SERVER USER INTERFACE

The QuarkXPress Server user interface

QuarkXPress Server offers a browser-based user interface instead of a conventional user

interface. This chapter describes that interface and explains how you can use it to

configure and customize your QuarkXPress Server application and manage your server

XTensions modules.

To view the QuarkXPress Server welcome page, launch a Web browser and enter the URL http://[server]:[port] (where [server] is the IP address or domain name of the server and [port] is the TCP/IP port on which the server is running). The

welcome screen displays.

The QuarkXPress Server welcome page

To display the administrative client, click Open Admin Client. If the server has realm

verification enabled, you will be asked to enter your user name and password. The

administrative client displays.

Navigation pane

The navigation pane on the left side of the has two areas. The Server Information

area lets you view server information and the transaction log, and the Document Pool

area lets you view the contents of the document pool. You can collapse and expand

this pane with the button at the right end of the Navigation Pane header.

If you click Server Information, the Status Monitor screen displays. The fields in the

top area provide information about the server. The icons in the area below represent

the renderers that are currently running and show which requests are being processed

by each renderer in real time. This screen also shows how many active and idle renderers

there are.

18 | A GUIDE TO QUARKXPRESS SERVER 10.1

THE QUARKXPRESS SERVER USER INTERFACE

Status Monitor screen

If you click Manage Logs, the Logs screen displays the current transaction log.

Logs screen

• To download the active log, including recent crash reports, click Download Logs at

the top of the Logs header.

• To make the log scroll automatically as events occur, check Auto Scroll.

• To clear all logs, click Clear All Logs.

• To clear the current log, click Clear Log.

• To display the Log Settings dialog box, click Log Settings. In this dialog box, you can

change the maximum log file size, the maximum rolling count, and the logging level

for the general QuarkXPress Server log, the QuarkXPress Server transaction log, and

the QuarkXPress Server fatal log.

• To view a particular log file, choose an option from the Select Log File drop-down

menu.

If you click Show XTensions Information, the XTensions Information screen displays,

allowing yout o view the status of all installed XTensions modules.

If you click Manage Fonts, a list of fonts installed on the Server machine is displayed.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 19

THE QUARKXPRESS SERVER USER INTERFACE

Fonts screen

To search fonts, use the list search box in the top right corner.

To add fonts to the Server machine, click the Add Fonts button. This will copy the

fonts to the "privatefonts" folder in the QuarkXPress Renderer folder.

Administration menu

The administration menu lets you manage QuarkXPress Server.

You do not have to restart the server in GUI mode to set preferences.

General Preferences dialog box

The General Preferences dialog box (Administration > Preferences > General) lets

you set preferences that are not related to rendering. It includes the tabs described in

the following topics.

You can also set general preferences using the setprefs request handler. For more

information, see "Setprefs."

General Preferences — Server

The Server tab (Administration > Preferences > General > Server) includes the

following controls.

Use the Document Root Folder field to specify the location of the document pool.

Putting the document pool on a network connected drive is not recommended, because

this negatively impacts the performance of QuarkXPress Server.

20 | A GUIDE TO QUARKXPRESS SERVER 10.1

THE QUARKXPRESS SERVER USER INTERFACE

Use the Allow Memory Caching check box to control whether memory is cached.

Use the Max Memory Cache Size field to specify the maximum memory size allocated

to the cache memory. Valid values are from 10MB to 1024MB.

Use the Force Served Documents Closed check box to control whether

QuarkXPress Server closes projects from the document pool after it renders them,

regardless of the Telegraph XTensions software setting. Uncheck this box to keep such

projects open on the server.

Use the Default Renderer Type drop-down menu to specify the default rendering

format for the server.

• Appstudio: Returns a .zip file containing an HTML5 App Studio article.

• Appstudio Upload: Exports an HTML5 App Studio article and uploads it to the App

Studio Publishing Portal.

• AVE: Returns a .zip file containing an AVE issue (.zave) file and its manifest.

• ePUB: Returns an ePUB file.

• EPS Document: Returns an Encapsulated PostScript (EPS) file.

• JPEG: Returns a JPEG file.

• PDF: Returns a PDF file.

• PNG: Returns a Portable Network Graphics (PNG) file.

• PostScript: Returns a PostScript file.

• QCDDOC: Returns a QuarkCopyDesk article.

• QuarkXPress Document: Returns a QuarkXPress project.

• Raw Custom: Returns a file in internal QuarkXPress format for use by server XTensions

software developers.

• RLE Raw Custom: Returns a file in internal QuarkXPress format (compressed using

Run Length Encoding) for use by server XTensions software developers.

• SWF: Returns a SWF (Flash) file.

Use the Scale field to specify the default scale percentage at which QuarkXPress Server

should render projects.

Use the Disable QXD Return check box to specify whether QuarkXPress Server can

return QuarkXPress projects to clients.

General Preferences — Log

The Log tab (Administration > Preferences > General > Log) includes the following

controls.

Use the Log Document Problems check box to specify whether to include problem

descriptions in transaction log files. The "Log" folder inside the QuarkXPress Server

application folder contains three log files:

• QuarkXPress Server Fatal Log.log: This log lists all fatal errors.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 21

THE QUARKXPRESS SERVER USER INTERFACE

• QuarkXPress Server Log.log: The log for the Java process. This log contains source

code-level logging information that can be useful in troubleshooting.

• QuarkXPress Server Transaction Log.log: This log lists all transactions and all errors.

Detailed application logging is enabled for these log files only if it is enabled in the

"log4j.xml" file.

To log detailed transaction timing data, check Log Timing Data.

Logged problems include the following:

• Missing Fonts: If fonts are missing from a project that has been requested for rendering,

a one-line description of each missing font is added to the error log. If

QuarkXPress Server receives a request to render a project and does not have access to

the fonts required by the project, it uses the fonts specified in the Fonts tab of the

Preferences dialog box (Administration > Preferences > General). If these fonts are

also unavailable, QuarkXPress Server substitutes Helvetica (Mac OS) or Arial (Windows).

This behavior is the same as it is in QuarkXPress.

• Missing Pictures

• Missing SXTs: If a required server XTensions module is missing when a rendering

request is received, a one-line description of each missing module is added to the error

log. If the name of the missing module is not returnable, the XTensions module ID

number is returned.

• Text Encoding/Character Set Problems: If text is sent to a text box in the template

and the system does not have access to the correct font glyph, the issue is logged. The

log data indicates the character set that the system attempted to convert. For example,

the log entry might show that a request for Japanese characters was sent to an English

project.

Information about missing fonts and missing pictures is also recorded in the

"QuarkXPressServerRenderer.log" file. This file also contains detailed timing information,

including the transaction UID for each transaction. This log file can be found here:

•

Mac OS: [drive]/Users/[user name]/Library/Logs/Quark

•

Windows: [drive]:\Users\[user name]\AppData\Quark\Log or

[drive]:\Documents and Settings\[user name]\Application Data\Quark\Log

To download all logs to a non-server computer, click Show Transaction Log in the

QuarkXPress Server Web interface, then click Download Logs on the home page.

General Preferences — Email

QuarkXPress Server can automatically notify someone by e-mail when the checked-out

QLA license is about to expire. The Email tab (Administration > Preferences > General

> Email) lets you specify where such e-mail messages should be sent.

Use the Server field to specify the domain name or IP address of the e-mail server that QuarkXPress Server should use to send messages (for example, mail.quark.com).

22 | A GUIDE TO QUARKXPRESS SERVER 10.1

Use the Port field to specify the port number of the e-mail server that

QuarkXPress Server should use to send messages. Valid values are from 0 to 255.

Use the From to specify the source e-mail address the QuarkXPress Server application should use to send messages (for example, QXPSserver1@quark.com).

Use the To to specify the e-mail address to which the QuarkXPress Server application should send messages (for example, QXPServerAdmin@quark.com).

General Preferences — Authentication

The Authentication tab (Administration > Preferences > General > Authentication)

includes the following controls.

Check Authenticate For Admin Requests to enable the Username and Password

fields. These fields let you control access to administrative parameters and features.

You can enter up to 32 characters.

Renderer Preferences dialog box

Use the renderer Preferences dialog box (Administration > Preferences > Renderer)

to set up default preferences for use when projects are created in QuarkXPress Server.

It includes the tabs described in the following topics.

THE QUARKXPRESS SERVER USER INTERFACE

Many of these preferences come into play only when you create a project in QuarkXPress Server, either using a construct request or through a request handled

by a custom QuarkXPress Server XTensions module.

You can also set renderer preferences using the setrendererprefs request handler.

For more information, see"Setrendererprefs."

In versions of QuarkXPress Server prior to 9.0, these resources were accessed through

the Document Controls submenu.

Preferences — Display

The Display pane (Administration > Preferences > Renderer > Display) includes the

following controls.

Use the Color TIFFs drop-down list to specify the color depth of screen previews created

for color TIFFs when they are imported.

Use the Gray TIFFs drop-down list to specify the resolution of screen previews created

for grayscale TIFFs when they are imported.

Choose a profile that corresponds to your monitor from the Monitor Profile drop-down

menu, or choose Automatic. Profiles can be placed in the "Profiles" folder in the

QuarkXPress Server application folder.

Preferences — Input Settings

The Input Settings tab (Administration > Preferences > Renderer > Input Settings)

includes the following controls.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 23

THE QUARKXPRESS SERVER USER INTERFACE

Check Smart Quotes to force QuarkXPress to replace feet (')and inches (") marks

automatically with the specified quotation marks.

Use the Format drop-down menu to specify the default characters to be used with the

Smart Quotes feature and Convert Quotes option in the Get Text dialog box (File >

Get Text).

To change the separators used for indicating sequential ranges for output, enter a value

in the Sequential Page Range Separator. This value override the preferences set for

a project.

To change the separators used for indicating nonsequential ranges for output, enter

a value in the Non Sequential Page Range Separator. This value override the

preferences set for a project.

Preferences — Font Fallback

The Font Fallback pane (Administration > Preferences > Renderer > Font Fallback)

includes the following controls.

Check Font Fallback to activate the Font Fallback feature. When this feature is active,

if the application encounters a character it cannot display in the current font, it

attempts to find a font that can display the character.

If the application encounters a missing font when opening a project, it uses the

preferences in this pane to determine which substitute fonts to use.

If you add characters to an exising project and the font cannot support those characters,

the application will search the system for a font that can display the characters.

Check Search to have the application search for a suitable font that is used in the

active project. To restrict the search to a particular range, choose an option from the

Search Type drop-down menu. To search the entire story where a missing font occurs,

choose Active Story. To search a particular number of paragraphs in both directions,

choose Paragraph and enter a number in the Search Limit field.

To indicate which fallback fonts should be used when no other font can be found

(taking the Search settings into account), choose options from each of the drop-down

menus in the Font List area.

To indicate which font should be used for the slug line when a layout is printed with

registration marks turned on, choose an option from the Slug Line Font drop-down

menu.

Preferences — Open and Save

The Open and Save pane (Administration > Preferences > Renderer > Open and

Save) includes the following controls.

Choose an option from the Encoding drop-down menu to indicate how the

applications should display characters in non-Unicode text.

Preferences — Fonts

The Fonts pane (Administration > Preferences > Renderer > Fonts) includes the

following controls.

24 | A GUIDE TO QUARKXPRESS SERVER 10.1

THE QUARKXPRESS SERVER USER INTERFACE

To specify default replacement fonts, check Specify Default Replacement Font and

choose options from the Roman and East Asian drop-down menu.

To highlight characters that are in a Traditional Chinese encoding's UDA/VDA (User

Defined Area/Vendor Defined Area) range so that these characters can be visually

verified, check Highlight character ranges defined by Traditional Chinese font

vendors.

Preferences — EPS

The EPS pane (Administration > Preferences > Renderer > EPS) includes the following

controls.

To control whether the application should generate a preview of an EPS file or use the

preview (if any) embedded in the file, choose an option from the Preview drop-down

list. The option specified in this pane is used only when the EPS preview is being

created. If you change the preference, you need to reimport the EPS file.

Preferences — PDF

Use the PDF pane of the Preferences dialog box (Administration > Preferences >

Renderer > PDF) to set preferences for rendering in PDF format.

The PDF pane displays only if PDF Filter XTensions software is loaded. For more

information, see "PDF Filter XTensions software"

Use this pane to specify a PDF workflow:

• Click DirectPDF to generate PDF output in the browser. This is the default option.

• Click PDFtoFolder to generate and save PDF files to a folder. Click Select/Browse to

specify a location for the folder in the Watched Folder field.

• Click PS4D (PostScript File for Later Distilling) to generate a PostScript file. Click

Select/Browse to specify a location for the folder in the Watched Folder field.

Use this pane to set the desired PDF output style. Choose from the following output

styles:

• Default PDF Output Style

• Print - Medium Quality/Medium Resolution

• PDF/X-1a:2001

• PDF/X-3:2002

• Press - High Quality/High Resolution

• Print - Medium Quality/Medium Resolution

• Screen - Low Quality/Low Resolution

• Screen - Medium Quality/Low Resolution

Use this pane to specify the folder path for the distiller error log file. The path is used

by the PDFFilter XTension software to create the log file to log the errors that occur

during the distillation process.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 25

THE QUARKXPRESS SERVER USER INTERFACE

The default path to the log file is <users>/Documents. If you choose to change the

default, the log folder specified must be a pre-existing folder on the system.

Preferences — Project General Settings

The Project General Settings pane (Administration > Preferences > Renderer >

Project General Settings) includes the following controls.

Check Use OpenType Kerning to activate the default kerning values for OpenType

fonts. When OpenType kerning is active, it overrides any kerning specified through

Kerning Table Edit (Utilities menu) for OpenType fonts.

To disable OpenType kerning for full-width characters, check Do Not Kern Full Width

Characters.

Preferences — Print Layout Settings

The Print Layout Settings pane (Administration > Preferences > Renderer > Print

Layout Settings) includes the following controls.

Use the Master Page Items drop-down menu to control what happens to master items

when master pages are applied.

• Click Keep Changes if you intend modified master items on your layout pages to

remain when a new master page is applied. The items that are kept are no longer master

items.

• Click Delete Changes if you want modified master items on your layout pages to be

deleted when a new master page is applied.

Use the Framing drop-down menu to specify whether frames are placed inside or

outside text and picture boxes.

• When you click Inside, the distance between the text and the frame is determined by

the box's Text Inset values (Item > Modify). When you place a frame inside a picture

box, the frame overlaps the picture.

• When you click Outside, the frame is placed outside the box, increasing the box's

width and height. The frame cannot extend beyond a constraining box or the

pasteboard.

Use the Auto Page Insertion drop-down menu (Print layouts only) to determine

whether pages are inserted automatically to contain text overflow from an automatic

text box or a chain of text boxes (on a page associated with a master page that contains

an automatic text box). The drop-down menu also enables you to determine where

any pages will be inserted.

Preferences — Print Layout Measurements

The Print Layout Measurements pane (Administration > Preferences > Renderer >

Default Print Layout Measurements) includes the following controls.

Use the Horizontal and Vertical drop-down menus to specify the measurement system

for the rulers displayed along the top and left of the layout window. Horizontal

corresponds to the top ruler; Vertical corresponds to the left ruler.

26 | A GUIDE TO QUARKXPRESS SERVER 10.1

THE QUARKXPRESS SERVER USER INTERFACE

Use the Points/Inch field to override the default value of 72 points per inch. The

application uses the value here as the basis for all point and pica measurements, as

well as for all point- and pica-to-inch conversions. The desktop publishing standard

for points per inch is 72. However, the traditional typographic standard used on most

metal typographic rulers is usually approximately 72.27 or 72.307 points per inch

(range = 60 to 80 pt, measurement system = points, smallest increment = .001).

Use the Ciceros/cm field to specify a ciceros-to-centimeter conversion value different

from the standard 2.1967 (range = 2 to 3 c, measurement system = ciceros, smallest

increment = .001).

Preferences — Paragraph

The Paragraph pane (Administration > Preferences > Renderer > Paragraph) includes

the following controls.

Use the Auto Leading feature to automatically set line spacing. Unlike paragraphs

with absolute leading (identical line spacing above every line), paragraphs with auto

leading may include lines with different leading when fonts and font sizes are mixed

in the same paragraph.

Auto leading starts with a base amount of leading, which the application calculates

by examining the ascent and descent values built into the fonts used in an auto-leaded

line and the line above it; however, the user-specified text size plays the largest part

in determining this base amount. Finally, a value specified by the user in the Auto

Leading field is added to the base amount to arrive at the total amount of leading.

To specify percentage-based auto leading, enter a value from 0% to 100% in 1%

increments. This value determines the amount of leading between two lines of text

as follows: The largest font size in the line above is multiplied by the percentage value.

This outcome is added to the base amount of auto leading between the two lines.

Although the design of certain fonts complicates the process, here is a simplified

example: 10-point text styled consistently in a "standard" font with Auto Leading set

to 20% has 12 points of leading (10 pts + [20% of 10] = 12 pts).

Use the Maintain Leading check box to control the placement of a line of text that

falls immediately below an obstruction in a column or box. If Maintain Leading is

checked, the line's baseline is placed according to its applied leading value. If Maintain

Leading is unchecked, the ascent of the line will abut the bottom of the obstruction

or any applied runaround value.

In the Lock to Grid Based On area:

• Click Ascent and Descent to lock text to grid based on the ascenders and descenders

of characters.

• Click Font Size (Em Box) to lock text to grid based on the size of the em boxes of the

characters.

Preferences — Character

The Character pane (Administration > Preferences > Renderer > Character) includes

the following controls.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 27

THE QUARKXPRESS SERVER USER INTERFACE

Use the Superscript fields to control the placement and scale (size) of superscript

characters. The Superscript Offset value determines how far below the baseline the

application places a superscript character. The Superscript Offset value is measured

as a percentage of font size. The default value is 33%. The Superscript VScale value

determines the vertical size of the character and is a percentage of font size. The

Superscript HScale value determines width and is a percentage of the normal character

width (as specified by the font designer). The default value for both scales is 60%

(range = 0 to 100%, measurement system = percentage, smallest increment = .1).

Use the Subscript fields to control the placement and scale (size) of subscript characters.

The Subscript Offset value determines how far above the baseline the application

places a subscript character. The Subscript Offset value is measured as a percentage

of font size. The default value is 33%. The Subscript VScale value determines the

vertical size of the character and is a percentage of font size. The Subscript HScale

value determines width and is a percentage of the normal character width (as specified

by the font designer). The default value for both scales is 100% (range = 0 to 100%,

measurement system = percentage, smallest increment = .1).

Use the Small Caps fields to control the scale of characters with the Small Caps type

style applied to them. The Small Caps VScale value determines the vertical size of the

character and is measured as a percentage of font size. The Small Caps HScale value

determines width and is measured as a percentage of the normal character width (as

specified by the font designer). The default value for both scales is 75% (range = 0 to

100%, measurement system = percentage, smallest increment = .1).

Use the Superior fields to control the scale of superior characters. The Superior VScale

value determines the vertical size of the character and is measured as a percentage of

font size. The Superior HScale value determines width and is measured as a percentage

of the normal character width (as specified by the font designer). The default value

for both scales is 60% (range = 0 to 100%, measurement system = percentage, smallest

increment = .1).

Use the Ligatures Break Above field to use ligatures built into a font. A ligature is a

typographic convention in which certain characters are combined into a single glyph.

Most fonts contain ligatures for the characters "f" followed by "i" and "f" followed by

"l". The Ligatures Break Above field enables you to specify the kerning or tracking

value (measured in 1/200 em space increments) above which characters will not be

combined into ligatures. For example, a headline with a large tracking value would

probably not contain ligatures. The default value is 1 (range = 0 to 10, measurement

system = .005 [1/200] em space, smallest increment = .001). To prevent the second

two letters in "ffi" and "ffl" (as in office and waffle) from being combined into ligatures,

check Not "ffi" or "ffl". Three-character ligatures for these combinations, common in

traditional typesetting systems, are not standardized in fonts designed for Mac OS, so

some typographers prefer to keep all three letters separate rather than combine only

two of them. Note that many PostScript fonts do not have "ffi" and "ffl" ligatures, but

most OpenType fonts do. This option is unchecked by default.

Check Auto Kern to specify that the application should use kerning tables, which are

built into most fonts, to control intercharacter spacing. The Auto Kern Above field

enables you to specify the point size above which automatic kerning must be used.

The Auto Kern Above feature also implements custom tracking information specified

in the Tracking Values dialog box for a selected font (Utilities > Edit Tracking) in

28 | A GUIDE TO QUARKXPRESS SERVER 10.1

THE QUARKXPRESS SERVER USER INTERFACE

QuarkXPress. This option is checked by default, with a 4-point threshold (range = 0

to 72 pt, measurement system = various [", pt, cm, etc.], smallest increment = .001).

Check Standard Em Space to specify an em-space equivalent to the point size of the

text (for example, 24pt text has a 24pt em space). If Standard Em Space is unchecked,

the application uses the width of the two zeros in the current font as the em-space

width. This option is checked by default. You can insert an em space in text by pressing

Option+space/Ctrl+Shift+6.

Use the Flex Space Width field to change the 50% default width of a flexible space.

To create a breaking flexible space, press Option+Shift+space/Ctrl+Shift+5; to create a

nonbreaking flexible space, press Command+Option+Shift+space/Ctrl+Alt+Shift+5.

The Flex Space Width value is expressed as a percentage of the normal en space for

a given font and font size (range = 0 to 400%, measurement system = percentage,

smallest increment = .1).

Use the Accents for All Caps check box to specify whether to include accent marks

on accented characters with the All Caps type style applied. This option is checked by

default.

Use the Space between CJK & R field to indicate how much space should be included

by default between a Chinese, Japanese, or Korean character and an adjacent Roman

character.

Preferences — Trapping

The Trapping pane (Administration > Preferences > Renderer > Trapping) includes

the following controls.

Select a Trapping Method:

• Click Absolute to trap using the values in the Auto Amount and Indeterminate fields

according to the object and background colors involved. If the object color is darker,

the object is choked by the background using the Auto Amount value. If the object

color is lighter, the object is spread into the background using the Auto Amount value.

• Click Proportional to trap using the value in the Auto Amount field multiplied by

the difference between the luminance (lightness or brightness) of the object color and

the background color.

• Click Knockout All to turn off trapping and print objects with a zero trap amount.

Check Process Trapping to trap each process separation plate individually when a

page contains overlapping process colors.

Check Ignore White to specify that an object color in front of multiple background

colors (including white) does not take white into account when trapping.

Enter a trapping value in the Auto Amount field or choose Overprint:

• Enter a value in the Auto Amount field to control the amount of trapping that

QuarkXPress applies to object and background colors that have an Auto Amount

specified in the Trap Specifications dialog box (Edit > Colors > Edit Trap), and to

control the amount of trapping applied to items with an Auto Amount (+) Trap

Information or (–) specified in the Trap Information palette (Window > Trap

Information).

A GUIDE TO QUARKXPRESS SERVER 10.1 | 29

THE QUARKXPRESS SERVER USER INTERFACE

• Choose Overprint to cause overprinting for object and background colors with an

Auto Amount specified in the Trap Specifications dialog box (Edit > Colors > Edit

Trap), as well as for items with an Auto Amount (+) or (–) specified in the Trap

Information palette (Window > Trap Information).

Enter a trapping value in the Indeterminate field or choose Overprint:

• Enter a value in the Indeterminate field to control the amount of trapping that

QuarkXPress applies to object colors that are in front of indeterminate backgrounds

(multiple colors with conflicting trapping relationships).

• Choose Overprint to cause an object color to overprint an indeterminate background.

Enter a Knockout Limit value. The knockout limit is the value (expressed as a

percentage of darkness of the object color) that enables you to control the point at

which an object color knocks out a background color.

Enter an Overprint Limit value. Overprint limit is a trapping setting that allows an

object set to overprint to trap according to the Auto Amount value if the object's

shade is less than a particular percentage.

Preferences — Color Manager

The Color Manager pane (Administration > Preferences > Renderer > Color Manager)

includes the following controls.

To specify an engine for color transformation, choose an option from the Color Engine

drop-down menu.

To achieve the darkest possible blacks in all output methods, check Black Point

Compensation.

Use the Source Setup drop-down menu to specify the source color space of pictures

and colors used in the application.

To enable the Profile Information command in the Window menu and the Color

Management tab in the Import Picture dialog box, check Enable Access to Picture

Profiles. This option allows you to view information about profiles.

To specify a default proof output setup, choose an option from the Proof Output

drop-down menu.

To specify a rendering intent for soft proofing, choose an option from the Rendering

Intent drop-down list. Perceptual scales all the colors in the source gamut so that

they all fit within the destination gamut. Relative Colorimetric retains colors that

are in both the source gamut and the destination gamut. The only source colors that

are changed are those that are not within the destination gamut. Saturation considers

the saturation of source colors and changes them to colors with the same relative

saturation in the destination gamut. Absolute Colorimetric retains colors that are in

both the source gamut and the destination gamut. Colors that are outside the

destination gamut are adjusted in relation to how they would look when printed on

white paper. Defined by Sources uses the rendering intents defined in source setup

for all colors and images.

30 | A GUIDE TO QUARKXPRESS SERVER 10.1

THE QUARKXPRESS SERVER USER INTERFACE

To color manage vector content in imported EPS and PDF files, check Color Manage

Vector EPS/PDF. Note that this preference applies only to EPS and PDF files imported

after this box is checked.

To color manage vector content in EPS and PDF files that have already been imported

in the active project, check Include Existing Vector EPS/PDF in Layout.

Preferences — Layers

The Layers pane (Administration > Preferences > Renderer > Layers) has the following

controls.

To make new layers visible by default, check Visible.

To suppress the printout of new layers by default, check Suppress Output.

To make new layers locked by default, check Locked.

To maintain runaround on new layers so that text on visible layers flows around items

on hidden layers, click Keep Runaround.

Preferences — Kindle

Use the Kindle pane (Administration > Preferences > Renderer > Kindle) to specify

the location of the KindleGen tool, which is required for Kindle output.

To get a free copy of KindleGen, visit

https://kdp.amazon.com/self-publishing/help?topicId=A3IWA2TQYMZ5J6.

Preferences — Modifier

Use the Modifier pane (Administration > Preferences > Renderer > Modifier) to

control whether and where errors are displayed in rendered layouts.

To include descriptions of rendering errors in the layout itselt, check Annotate errors

in the Output Document. (For more information, see "annotateerrors.") In rendered

QuarkXPress files, errors are displayed as notes. In rendered PDFs, errors are displayed

as comments. In XML output, errors are displayed as notes XML markup.

To append descriptions of rendering errors after the last page, check Append errors

into the Output Document. (For more information, see "appenderrors.") Descriptions

of rendering errors are formatted in 10-point magenta Arial.

Job Jackets dialog box

The Job Jackets dialog box lets you edit the Job Jackets file used by QuarkXPress Server.

To edit the QuarkXPress Server Job Jackets file:

In the QuarkXPress Server Web interface, choose Administration > Job Jackets. The

Manage Job Jacket dialog box displays.

Click the Get Job Jacket for editing button and save the Job Jackets file to the desktop.

Open the downloaded Job Jackets file in QuarkXPress and make any necessary changes

to the QXPSJobTicket Job Ticket.

In the Job Jacket dialog box, click Choose File and select the modified Job Jackets

file.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 31

THE QUARKXPRESS SERVER USER INTERFACE

Click Submit. The QuarkXPress Server Job Jackets file is replaced with the modified

version.

App Studio preferences

The AppStudio dialog box lets you specify credentials and proxy settings so that

QuarkXPress Server can upload HTML5 App Studio articles to the App Studio Publishing

Portal. Enter your App Studio Publishing Portal user name and password, then enter

the proxy settings for your proxy server (if any).

Check Out License dialog box

To check the QuarkXPress Server license out of Quark License Administrator, choose

Administration > Check Out License. To specify the number of days for checkout,

enter a value in days in the Check out for field. To be warned in advance of license

expiration, check Warn me and use the corresponding fields.

32 | A GUIDE TO QUARKXPRESS SERVER 10.1

Using QuarkXPress Server

The xml namespace deconstructs a project according to the Modifier DTD. The

construct namespace lets the server turn an XML representation of a QuarkXPress

project back into an actual project. With these namespaces, you can deconstruct a

project into an XML representation, change the XML in accordance with the Modifier

DTD, and then have the server generate an updated version of the QuarkXPress project.

You can even create new QuarkXPress projects from scratch using XML.

In addition, you can use the construct namespace to:

USING QUARKXPRESS SERVER

• Create a page based on master page

• Create a project from XML, using a Job Jackets™ file as the basis for the project

• Modify text font and style, including OpenType® styles

• Apply style sheets and local formatting to text

• Create and populate tables

• Import pictures into picture boxes and specify picture attributes

The DTD used for XML construction and deconstruction is completely Unicode®-compliant, making it ideal for use in international publishing. Furthermore,

the use of this DTD ensures that the schema of XML output created by Constructor

does not change when server preferences change. This DTD is provided in the

QuarkXPress Server application folder and fully documented in "Modifier schema

(annotated)."

Deconstructor XTensions software and the deconstruct namespace are no longer

supported.

Creating URL requests

You can use URL requests to make QuarkXPress Server render projects in a variety of

formats, to use the features of server XTensions modules, and to control the server.

The topics below provide an overview of how to construct server requests and use URL

parameters.

This chapter also lists functions that let you control the server. For detailed information

about constructing other types of URL requests, see "Using QuarkXPress Server."

A GUIDE TO QUARKXPRESS SERVER 10.1 | 33

USING QUARKXPRESS SERVER

Understanding URL requests

QuarkXPress Server URL requests should use the following format:

http://server:port/namespace/path/projectname?parameter=value

•

server: Indicates the name or IP address of the QuarkXPress Server computer.

•

port: Indicates the QuarkXPress Server application's port number. The default port

number is 8080.

•

namespace: Sets the render type (or indicates another server functionality to access).

For more information, see "Understanding QuarkXPress Server namespaces"

•

path: Indicates the path to the directory where the target project file is stored. The

project to be rendered can either be located in the document pool (in which case paths

are evaluated relative to the document pool directory), or can be streamed as part of

a multipart HTTP Post request. When the project is streamed as part of the request,

the project name will correspond to the name given to the HTTP request part which

contains the project data.

•

projectname: Identifies the project to be rendered.

•

parameter=value: Optional parameters that provide more detailed control over how

the target project should be rendered. Multiple parameter/value pairs, separated by

the "&" character, can be included.

For example, the following URL asks the QuarkXPress Server application named

"QXPServer" to return the file "MyProject.qxp" as a PDF file with hyperlinks and all

fonts embedded:

http://QXPServer:8080/pdf/MyProject.qxp?includehyperlinks=1&embedallfonts=1

Some URL parameters require Boolean arguments. For such parameters, valid values include 1 or 0, true or false, y or n, and yes or no.

You can also send requests to QuarkXPress Server using the HTTP GET and POST

protocols and using XML with XSLT. For more information about these approaches,

see "Using QuarkXPress Server."

Understanding QuarkXPress Server namespaces

QuarkXPress Server namespaces differentiate among types of requests that are otherwise

identical. For example, consider the following three URLs:

http://QXPServer:8080/project1.qxp

http://QXPServer:8080/pdf/project1.qxp

http://QXPServer:8080/postscript/project1.qxp

These requests are identical, except each uses a different namespace (in italic). (The

first request does not specify a namespace, but this simply means the project is to be

rendered using the server's default render type.)

Namespaces can be used to determine the format in which a rendered project is

returned, as indicated above, but they can also be used to direct a request to XTensions

software that performs other functions. For example, if you use Modifier XTensions

34 | A GUIDE TO QUARKXPRESS SERVER 10.1

USING QUARKXPRESS SERVER

software's xml namespace, Modifier XTensions software can return an XML

representation of the project.

Looking up a namespace

This guide lists the namespaces for every QuarkXPress Server function. There is no

single list of namespaces because some functions do not require a particular namespace

or are available in multiple namespaces. To determine which namespace you want to

use:

In this Guide, go to the page that documents the render type you want to use. (For

more information, see "Understanding render types.")

Locate the Namespace row. If the render type or function has an associated namespace,

that namespace is listed here.

Third-party XTensions can add their own namespaces. For information about a

third-party namespace, see the documentation for the XTensions module that adds

that namespace.

Understanding QuarkXPress Server parameters

Parameters let you control the details of how a request is executed. For example, you can use the page parameter to create a request that returns only the third page of a

project:

http://QXPServer:8080/jpeg/project1.qxp?page=3

You can include multiple parameters in the same request; simply separate them with

an ampersand (&). For example, here's a new version of the above URL that returns

page three at a scale of 50%:

http://QXPServer:8080/jpeg/project1.qxp?page=3&scale=.5

Looking up a parameter

This Guide lists the parameters that are available for every QuarkXPress Server function.

To determine which parameters you can use with a request:

In this Guide, go to the page that documents the the render type you want or the

function you want to use. (For more information, see "Understanding render types" and

"Understanding render modifiers.")

Locate the Parameters row. This row lists all available parameters, and includes a

description and a list of valid values for each parameter.

Supported interfaces

The following interfaces are available in QuarkXPress Server:

• HTTP: Lets you interact with the server using URLs that contain calls or point to XML

files that contain calls. You can write client applications in any language that supports

HTTP requests. For more information, see "Getting started: HTTP and HTTPS".

A GUIDE TO QUARKXPRESS SERVER 10.1 | 35

USING QUARKXPRESS SERVER

• HTTPS: Provides secure HTTP access.

• Web services: Lets you interact with the server via Web services using the

QuarkXPress Server Manager object model. You can write client applications in

Java, .NET, or any other programming language that can consume SOAP-based Web

services. For more information, see "Getting started: Web services".

To develop a custom load balancer or a custom application in Java, you must have

version 1.5 or 1.6 of the JDK.

The Dynamic Publishing Process (DPP)

The Dynamic Publishing Process (DPP) has several stages. You may not need to use

all of these stages every time, but this the order in which they occur:

• Pre-Processing Stage: During this stage, QuarkXPress Server performs any necessary

initial steps, such as creating style sheets, colors, and H&J rules for a new QuarkXPress

project.

• Content Loading Stage: During this stage, QuarkXPress Server loads dynamic content

into boxes in the project.

• Layout Modification Stage: During this stage, QuarkXPress Server modifies the layout

of the project.

• Post-Processing Stage: During this stage, QuarkXPress Server examines the project and

performs maintenance tasks.

Getting started

The topics below describe how to create requests for the QuarkXPress Server Web

interface.

For information about the options available in such requests, see "Using the Web

interface."

Getting started: HTTP and HTTPS

You can submit HTTP and HTTPS requests to QuarkXPress Server as URLs, either

manually from a browser or automatically from an HTTP client application.

QuarkXPress Server processes such requests and returns rendered content in the HTTP

or HTTP responses. Depending on the type of request, the QuarkXPress Server

preferences, and the type of content returned, the rendered content may be downloaded

by the end user, displayed in the end-user's browser, or saved to a file system location

accessible to QuarkXPress Server.

You can write a QuarkXPress Server client application in almost any language that can

generate HTTP GET/POST requests. A QuarkXPress Server HTTP-based solution typically

consists of QuarkXPress Server (running on a server computer connected to a network)

plus a front-end application (usually Web-based) that provides a graphical user interface

(GUI) for end users. The front-end application translates end users' input into HTTP

36 | A GUIDE TO QUARKXPRESS SERVER 10.1

USING QUARKXPRESS SERVER

or HTTPS requests and sends the requests to QuarkXPress Server or QuarkXPress Server

Manager, which processes the requests and returns rendered content.

Dissecting a QXP Server URL

To interact with QuarkXPress Server from a Web browser, use a URL like the following:

http://[server]:[port]/[namespace]/[directory]/[DocumentName]?[parameter]=Value

•

[server]: The name or IP address of the computer for QuarkXPress Server or

QuarkXPress Server Manager.

•

[port]: The port number on which to contact QuarkXPress Server or

QuarkXPress Server Manager. The default port is 8080 for QuarkXPress Server and 8090

for QuarkXPress Server Manager.

•

[namespace]: Defines what the URL action will be and any parameters and conditions

available to that namespace.

•

[directory]: The path in the document pool where the project is stored, relative to

the QuarkXPress Server document pool. To access the root level, no directory path is

necessary. (Note that you can also supply assets as part of a multipart HTTP request.

For more information, see "Using HTTP POST with QXP Server.")

•

[DocumentName]: The name of the QuarkXPress project to be processed.

•

[parameter]: Further defines the URL action with attributes and values allowed for

the namespace or general call. Pass parameters in the form attribute=value, with

parameters separated by the "&" character.

For QuarkXPress Server Manager, use a URL like the following:

http://[server]:[port]/qxpsm/request/[namespace]/[directory]/ [DocumentName]?[parameter]=Value

Prior to QuarkXPress Server 9.0, you had to use different URL constructions when

sending requests to an instance of QuarkXPress Server Manager in a QPS installation

than you did when sending requests to a free-standing instance of QuarkXPress Server Manager. In versions 9.0 and later, both can use /qxpsm/request/ after [port]/ .

You can now use both absolute and relative paths when you modify a project with

SDK objects or classes. Relative paths are almost always relative to the document pool.

If you use multiple QuarkXPress Server instances, you should use a common document

pool.

Interpreting the QXP Server Manager response

When QuarkXPress Server Manager successfully processes a request through the HTTP

interface, the response is the same as QuarkXPress Server's response unless the user

has supplied additional parameters to QuarkXPress Manager. For more information,

see "Working with QuarkXPress Server Manager" in A Guide to QuarkXPress Server.

If an error occurs, QuarkXPress Server Manager retries the request, either on the same

QuarkXPress server instance or a different one (depending on the error and global

settings established in the QuarkXPress Server Manager client). If QuarkXPress Server

A GUIDE TO QUARKXPRESS SERVER 10.1 | 37

USING QUARKXPRESS SERVER

Manager cannot process the request, it returns an XML response describing the error,

plus any header error codes returned by QuarkXPress Server. For example:

<?xml version="1.0" encoding="UTF-8" ?> <error> <httpresponsecode>500</httpresponsecode> <xpressservererrorcode>-43</xpressservererrorcode> <xpressservererrormessage>File not found.</xpressservererrormessage> <xpressserverextendedmessage> <![CDATA[ Error #-43 - File not found. ]]> </xpressserverextendedmessage> <xpressservermanagererrorcode>M8000001</xpressservermanagererrorcode> <xpressservermanagererrormessage>The server could not locate the specified file. </xpressservermanagererrormessage> </error>

HTTP GET and POST Requests

The topics below describe how you can use HTML to interact with QuarkXPress Server.

QuarkXPress Server supports both the GET and POST HTML methods. When you use

the GET method, the browser encodes form data into a URL. When you use the POST

method, form data is passed within the message body. Use the GET method only when

the form processing is idempotent. In short: GET is for retrieving data, whereas POST

can involve storing or updating data, ordering a product, or sending an e-mail.

Using HTTP GET with QXP Server

Use HTML like the following to specify a server and port where you want to send a

request. You can specify the name of the target project, the output type, and a scaling

value. You can specify the name of a box and the path of a text or picture files to

import into that box, as long as the file's path is on the server's file system. You can

also use HTML like the following to specify the page number and layout number of

the project.

The form section of the HTML should begin with the following line of code:

For both GET and POST, the browser constructs a form data set and encodes it according to the ENCTYPE attribute (you can use multipart/form-data for POST and

application/x-www-form-urlencoded (the default) for both POST and GET).

To create fields that let the user specify the server IP address, the port, and the project

name, use HTML like the following:

38 | A GUIDE TO QUARKXPRESS SERVER 10.1

USING QUARKXPRESS SERVER

To create a drop-down menu that lets the end user specify a render format, use HTML

like the following:

<SELECT id="select1" name="returntype"> <OPTION value="jpeg">JPEG</OPTION> <OPTION value="pdf">PDF</OPTION> <OPTION value="qxpdoc">QuarkXPress document</OPTION> <OPTION value="eps">EPS Document</OPTION> <OPTION value="postscript">POSTSCRIPT</OPTION> <OPTION value="png">PNG</OPTION> </SELECT><td/>

To create a drop-down menu that lets the end user specify a rendering scale, use HTML

like the following:

To create input fields that let the end user specify a box name and the name of a file

to be imported into that box, use HTML like the following:

To create fields that let the end user enter a page number a layout number, use HTML

like the following:

A GUIDE TO QUARKXPRESS SERVER 10.1 | 39

USING QUARKXPRESS SERVER

To create a button that lets the end user submit the request, use HTML like the

following:

The above HTML calls a function named Submit_onclick(). You can add such a function to the <HEAD> section of the HTML. For example:

<head> <TITLE>Quark Stream</TITLE> <script ID="clientEventHandlersJS" LANGUAGE="javascript"> function Submit_onclick() { var prefix; var renderer; var file; var url; var box1Name; var dataImportStamp = "@dataimport"; prefix = "http://" + document.getElementById("Server").value + ":"; port = document.getElementById("Port").value + "/"; renderer = document.getElementById("select1").value + "/"; file = document.getElementById("Doc").value; box1Name = document.getElementById("box1").value; if (box1Name != "") { document.getElementById("box1File").name = box1Name + dataImportStamp; } else { document.getElementById("box1File").name = ""; } document.getElementById("Page").name = "Page"; document.getElementById("Layout").name = "Layout"; url = prefix + port + renderer + file; document.getElementById("form1").action = url; } </script> </head>

The Submit_onclick() function reads the values from the formand builds a request

URL using the server, port, and render type.

If the end user specifies a file name in the "File on Server" text box, he or she must add

file: to the beginning of the file path (for example, file:C:\data.txt).

The code above adds @dataimport to the end of the box name to accommodate data

import.

The action of the form is defined by this line:

document.getElementById("form1").action = url;

This form's method is GET. The user agent gets the value (the URL) of the action, appends a ? to it, adds the form data set, and submits the URL.

In this scenario, form data must be in ASCII.

40 | A GUIDE TO QUARKXPRESS SERVER 10.1

USING QUARKXPRESS SERVER

Using HTTP GET with QXP Server Manager

HTTP GET with QuarkXPress Server Manager works the same way as HTTP GET with

QuarkXPress Server (see "Using HTTP GET with QXP Server"), except that Quark does

not recommend using GET if you are working with non-ASCII characters. The behavior

of GET requests with characters is highly browser-dependent, and there is no standard

that all browsers follow. Instead, use POST.

Using HTTP POST with QXP Server

Use HTML like the HTML in "Using HTTP GET with QXP Server" to specify a server and

port where you want to send a request. You can specify the name of the target project,

the output type, and a scaling value. You can specify the name of a box and the path

of a text or picture files to import into that box, as long as the file's path is on the

server's file system. You can also use HTML like the HTML in "Using HTTP GET with

QXP Server" to specify the page number and layout number of the project. Differences

between the GET method and the POST method are described below.

The form section of the HTML should begin with the following line of code:

The following HTML creates a input fields that let the end user specify the name of a

file to be imported into a box:

The action of the form is defined by this line:

document.getElementById("form1").action = url;

The form's method is POST. The user agent conducts an HTTP post transaction using

the value of the action attribute (the URL), and a message is created according to the content type specified by the enctype attribute.

When you use a multipart HTTP post request, you can include in the request any files

which are required by the rendering process, including QuarkXPress templates, picture

files, modifier XML, and digital publishing assets. For more information, see "Using

the Streaming Document Provider."

Using HTTP POST with QXP Server Manager

HTTP POST with QuarkXPress Server Manager works the same way as HTTP POST with

QuarkXPress Server (see "Using HTTP POST with QXP Server"), except that with

QuarkXPress Server Manager, you must use UTF-8.

Getting started: Web services

The Web services interface is a collection of request classes. You can download the

SDK WSDL class definitions from

http://[server]:[port]/qxpsm/services/RequestService?wsdl (replace [server] with the QuarkXPress Server Manager computer's IP address and [port]

with the QuarkXPress Server Manager port number.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 41

USING QUARKXPRESS SERVER

These classes can be chained together to form compound QuarkXPress Server requests.

The sample applications (see "Sample applications") show how to use these classes to

invoke a QuarkXPress Server command and manipulate the response.

For more information, see "Using the Web interface." In addition to the classes listed

there, the Web services interface includes the following:

•

RequestService processes QuarkXPress Server requests. This object's generic processRequest() method takes a QRequestContext argument and returns a QContentData object containing the response. For more information, see the sample

applications and "Using the Web interface."

•

QRequestContext is the argument you pass to RequestService's generic processRequest() method.This object contains settings which must be set once per

request. Set all chained requests inside the request context.

•

QRequest is the base class for all request objects (such as PDFRenderRequest).

Consequently, all request objects share some common data members.

•

RequestParameters is a generic class for executing any request and for adding

dynamic properties to a request.

•

NameValueParam is a generic class for adding dynamic properties to a request. This

class is specifically for requests that take a box's name and/or ID as the parameter name

and the box's content as the value.

•

QContentData is the response returned when a request is executed. QContentData

is a hyperlink that follows the same pattern as the classes above.

•

QException is the exception class for QuarkXPress Server Manager. Web services

returns a QException object if an error occurs with any Web service method. You can use try/catch blocks to handle QException objects.

If you've written a Server XTensions module, you can extend the XML interface to

include any changes it makes to the Modifier DTD by simply modifying an XML file

and regenerating the stubs.

To exclude empty tags in the request HTML, set the value of the appropriate variable to null.

For Javadocs, WSDL schemas, and JSP samples, see the Welcome page that displays

when you launch QuarkXPress Server Manager.

The following topics describe the general Web services classes.

QRequestContext

Description

An argument passed to RequestService. Contains settings that must be set once per request. All chained requests must be set inside the request context.

Web service data objectType

NameMembers

documentName

42 | A GUIDE TO QUARKXPRESS SERVER 10.1

DescriptionTypes

File or object name on which the command will be rendered.String

USING QUARKXPRESS SERVER

serverName

serverPort

userName

userPassword

maxRetries

requestTimeout

useCache

responseAsURL

bypassFileInfo

context

String

Integer

Boolean

Server name. Default is NULL. Load balancer searches for the host itself in this case.

Port at which the desired server is listening.Integer

Server admin username.String

Server admin password.String

Max number of times to try executing the command before returning failure.

Max time out in milliseconds.Integer

Indicates whether the cache should be checked for an existing result or if the command should be executed again.

This value indicates whether the server should send the response as-is (text or binary) or store the response on the server and return its location as a URL. Because the object model works on SOAP, which can be slow when transferring large binary files, you might choose to set this value to "true" if you suspect that the response is going to be several megabytes or larger.

Indicates whether file info should be fetched before executing the command.

Context in which the command is being executed.String

Example, object model

RequestService

Description

Methods

QRequestrequest

com.quark.qxpsm.QRequestContext rc = new com.quark.qxpsm.QRequestContext(); rc.documentName = this.DocumentSettings1.documentName.Text; rc.responseAsURL = this.DocumentSettings1.responseAsURL.Checked; rc.useCache = this.DocumentSettings1.useCache.Checked; rc.bypassFileInfo = this.DocumentSettings1.bypassFileInfo.Checked;

//Create the service and call it QRequestContext object RequestService svc = new RequestService(); com.quark.qxpsm.QContentData qc = svc.processRequest(rc);

Web service called to process the QuarkXPress Server request. RequestService has a generic method named processRequest() that takes QRequestContext as an argument and returns

QContentData as the QuarkXPress Server response.

Web serviceType

processRequest

Processes the request context and returns the result.

QuarkXPress Server request is instances of request objects chained together.

DescriptionTypeParameter

QRequestContextrequestCmd

Argument passed to

RequestService. Contains

settings that must be set once per request. All chained requests are set inside the request context.

createSession

Creates a new session and returns a session ID.

DescriptionTypeParameter

A GUIDE TO QUARKXPRESS SERVER 10.1 | 43

USING QUARKXPRESS SERVER

closeAlldocs

closeDoc

timeout

Closes all open documents in the session without saving them. If the session does not exist, an error is returned. If an error occurs while closing the document, it is logged and the document is marked closed in the internal cache. No error is returned.

sessionId

Closes the specified document without saving it. If the session does not exist, an error is returned. If the document is not open, and error is returned. If the document is open in another session, an error is returned. If an error occurs while closing the document, it is logged and the document is marked closed in the internal cache. No error is returned.

Long

String

Timeout for the session in milliseconds. If no call is executed in that time, session is expired and all the open documents in that session are closed without saving. If 0 is passed as value of timeout, default timeout is used. If a negative value is passed as timeout, the session never expires.

DescriptionTypeParameter

Session whose documents are to be closed.

DescriptionTypeParameter

closeSession

getOpenDocs

getOpenSessions

getPreferences

setPreferences

getXPressDOM

docName

sessionId

Closes the specified session. If the session does not exist, an error is returned. If any documents are still open in the session, an error is returned.

sessionId

Gets all the open documents in the session. If the session does not exist, an error is returned.

sessionId

Gets all open sessions.

Gets QuarkXPress Server preferences.

Sets QuarkXPress Server preferences.

Creates a DOM for the specified document.

String

Document to be closed.String

Session in which document was opened.

DescriptionTypeParameter

Session to be closed.String

DescriptionTypeParameter

Session whose open documents are sought.

newDoc

Creates a new document for modification and keeps it open until further notice. The document is created with a single layout. To create a more complex document, use the processRequestEx API. If a document with the same name is already open, an error is returned. If the session does not exist, an error is returned.

44 | A GUIDE TO QUARKXPRESS SERVER 10.1

DescriptionTypeParameter

USING QUARKXPRESS SERVER

docName

jobJacketName

jobTicketName

host

port

sessionId

String

Integer

String

Document to be opened for modification. Provide the name only. You can proivde a relative path when you save the document.

Name of the Job Jackets file to be used. The Job Jackets file is assumed to be already available on the QuarkXPress server computer.

Name of the Job Ticket to be used.String

The QuarkXPress Server instance that should be used for this document modification. If null, this value is supplied by the load balancer. If the indicated server is not an active registered server, an error is thrown.

The port for the server specified in the host parameter.

Session in which the document should be opened.

openDoc

processRequestEx

Opens the specified document and keeps it open until further notice. If the document is already open, an error is returned. If the session does not exist, an error is returned.

DescriptionTypeParameter

docName

host

port

sessionId

Executes the request context. If a session ID is specified, the document is kept open after the request is executed. If no session ID is specified, the request is executed normally without keeping the document open. If the document is open in another session, an error is returned. If the document is marked dirty, an error is returned (a document is marked dirty when the server that opened the document has become inactive; in such a case, the document must be closed and opened again).

String

Integer

String

Document (along with relative path if required) to be opened for modification.

QuarkXPress Server instance which should be used for this document modification. If null, this value is supplied by the load balancer. If the indicated server is not an active registered server, an error is thrown.

The port for the server specified in the host parameter.

Session in which the document should be opened.

DescriptionTypeParameter

QRequestContextreqContextObj

Request to be executed.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 45

USING QUARKXPRESS SERVER

saveAllDocs

sessionId

Saves all open documents in the session. The documents are saved one by one. If error occurs while saving a document, an error is returned immediately and the rest of the documents remain unsaved. If a document is marked dirty, an error is returned (a document is marked dirty when the server that opened the document has become inactive; in such a case, the document must be closed and opened again).

relativePath

String

Session in which the request should be executed. This value may be null. If a session ID is provided, the document is kept open. If no session ID is provided, the request is executed normally, as if processRequest had been called.

DescriptionTypeParameter

Relative path where open documents should be saved. If this value is provided, copies of open documents with changes made so far are saved in the new location. The open documents are not saved but have all of the changes made so far.

saveDoc

sessionId

Saves the open document. If a document is marked dirty, an error is returned (a document is marked dirty when the server that opened the document has become inactive; in such a case, the document must be closed and opened again).

docName

newName

relativePath

String

Session in which the document exists.

DescriptionTypeParameter

Document to be saved. Must be the same name that was used when opening or creating the document.

New name of the document. If null, the document is saved with the old name.

Relative path where the document should be saved. The relative path can also contain the new name of the document. If this is provided, a copy of the open document with changes made so far is saved in the new location. The open document is not saved but has all of the changes made so far.

sessionId

getXPressDOMEx

getXMLFromXPressDOM

Lets you create a DOM of a particular layout or portion of a layout.

Creates an XML string out of the DOM.

46 | A GUIDE TO QUARKXPRESS SERVER 10.1

String

Session in which the document exists.

USING QUARKXPRESS SERVER

Example, object model

Description

getXPressDOMFromXML

QRequestContext rc = new QRequestContext(); rc.documentName = "test.qxp"; rc.responseAsURL = false;

JPEGRenderRequest jpegRequest = new JPEGRenderRequest(); rc.request = jpegRequest;

RequestService svc = new RequestService(); QContextData response = svc.processRequest(rc);

Takes a raw XML representation of a project as a string and returns an object model representing that project, with Project as the root class.

QRequest

Base class for all request objects (such as PDFRenderRequest). All request objects share some common data members, which are described below.

Web service data objectType

NameMembers

QRequestrequest

DescriptionTypes

QuarkXPress Server request that includes instances of request objects chained together.

RequestParameters

Additional comments

Example, object model

NameValueParam

Generic class for executing any request and for adding dynamic properties to a request.Description

Web service data objectType

NameMembers

requestNamespace

You can use this class to send any request for which a specific class does not exist. When this request exists in the chain, its namespace is concatenated with the namespaces of other requests. That means the namespace provided here can be null.

The parameters of this class can be used to parameterize a request being sent to the server.

QRequestContext rc = new QRequestContext(); RequestParameters request = new RequestParameters(); request.setRequestNamespace("jpeg"); rc.setRequest = request; NameValueParam p1 = new NameValueParam(); p1.setParamName = "jpegquality"; p1.setTextValue = "4"; request.setParams(new NameValueParam[]{p1});

String

NameValueParam[]params

DescriptionType

Namespace of the request (for example, jpeg).

Parameter array for the specified request (for example, jpegquality).

Description

Generic class for adding dynamic properties to a request. This class is specifically for requests that take a box name/id as the parameter name and the box content as the parameter value.

Web service data objectType

NameMembers

DescriptionType

A GUIDE TO QUARKXPRESS SERVER 10.1 | 47

USING QUARKXPRESS SERVER

paramName

textValue

streamValue

contentType

QContentData

A response to a Web Services call to QuarkXPress Server.Description

Web service data objectType

NameMembers

contentType

textData

responseURL

String

byte[]

Name of the parameter. In most cases this will be the name/ID of the box.

Text value of the box. (You can set either textValue or

streamValue.)

Stream value of the box. (You can set either textValue or

streamValue.)

The MIME content type of the parameter.String

DescriptionTypes

String

The type of the response. For example, "text/xml" or "text/plain."

If the response type is text, this contains the text. Otherwise, this value is null.

If the responseAsURL parameter was set to "true" in the request, this contains the URL of the response. Otherwise, this value is null.

Example, object model

QException

streamValue

encodingType

actualServerPortUsed

actualServerUsed

headers

multipartResponse

QRequestContext context = new QRequestContext(); context.setDocumentName("sample.qxp"); context.setResponseAsURL(true); JPEGRenderRequest request = new JPEGRenderRequest(); request.setJPEGQuality("4"); context.setRequest(request); RequestService requestService = new RequestServiceStub(); QContentData response = requestService.processRequest(context); System.out.println(response.getResponseURL());

binary

String

If the response type is binary, this contains the byte array. Otherwise, this value is null.

If the response type is text, this value indicates the encoding of the text (for example, UTF-8 or ANSI).

Identifies the server port.String

Identifies the server.String

If the response returned by the server is a set of headers, this array contains the header response.

If the response returned by the server is multipart, this array contains the multipart response parts.

Exception class for QuarkXPress Manager.Description

Type

Exception

NameMembers

48 | A GUIDE TO QUARKXPRESS SERVER 10.1

DescriptionTypes

USING QUARKXPRESS SERVER

Example, object model

QXP Server Manager

httpResponseCode

managerErrorCode

managerErrorMessage

serverErrorCode

serverErrorMessage

serverExtendedMessage

String docName = "notexisting.qxp"; try { QRequestContext ctx = getRequestContext(docName); QRequest request = getJPEGRequest(); ctx.setRequest(ctx); QContentData response = getService().processRequest(ctx); System.out.println(response.getResponseURL()); } catch (QException ex) { // QuarkXPress Manager threw an QException and it is not // a runtime exception. QException object will be returned. System.out.println(ex.getServerErrorCode()); }

String

HTTP response code.String

QuarkXPress Server Manager error code.String

QuarkXPress Server Manager localized error message.

QuarkXPress Server error code.String

QuarkXPress Server response message.String

QuarkXPress Server extended error message.String

The following topics are for people who want to enhance QuarkXPress Server Manager

or integrate it with other software.

Please refer to http://localhost:8090/qxpsmdocs/apidocs/index.html for

manager API documentation. (Note that the port number used to retrieve the API

documentation is 8090 by default, but you should use whatever port number you

specified when installing QuarkXPress Server Manager.)

QuarkXPress Server Manager was developed using interface-based programming and

uses the Spring Framework to instantiate pluggable objects. When QuarkXPress Server

Manager starts up, it reads the contents of a Spring context definition file named

"ManagerContainerConfig.xml" and instantiates all of the beans listed in the file.

QuarkXPress Server Manager then initializes by reading various configuration options

from a file named "ManagerConfig.xml."

You can deploy QuarkXPress Server Manager in its own Tomcat container, in an

external Tomcat container, or in a shared Spring context. For more information, see

"Deploying QuarkXPress Server Manager" in the QuarkXPress Server ReadMe.

Using the Web interface

The topics below describe the features available via the QuarkXPress Server Web

interface. The topics covered here include the following:

• Render types are namespaces you can use to return a QuarkXPress project in a specified

file format.

• Render modifiers let you control which parts of a project are rendered and set the scale

of the returned renderings.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 49

USING QUARKXPRESS SERVER

• Content modifiers let you alter the content and formatting of boxes in layouts without

using the XML modify parameter.

• XML modify lets you modify QuarkXPress projects using XML.

•

The xml namespace deconstructs a project according to the Modifier DTD. The

construct namespace lets you turn an XML representation of a QuarkXPress project

back into a QuarkXPress project.

• Administrative request handlers let you change the behavior of QuarkXPress Server.

QuarkXPress Server uses case-sensitive XML.

Understanding rendering

Rendering is the process in which QuarkXPress Server opens a QuarkXPress project,

transforms it into a different format (the render type), and then sends a response to the

requestor. Depending on the type of rendering operation, the response may be a

message or a rendered file.

Alerts

For information on how to submit a render request, see "Getting started: HTTP and

HTTPS."

HTTP Error #500Cannot open this document type. Please select a QuarkXPress document or template.

read or write to disk.

required volume or folder.

This alert displays if you try to render a file that is not a QuarkXPress

project.

HTTP Error #404File not found

QuarkXPress Server Error #–43

This alert displays if you try to render a project that does not exist.

HTTP Error #500I/O error trying to

QuarkXPress Server Error #–36

This alert displays if QuarkXPress Server is running on Windows and a

shared network folder was selected as the document pool, but the folder

is no longer shared.

What to do: In the QuarkXPress Server administration interface, choose

Administration > Preferences > General and set Document Root Folder

to a shared folder.

HTTP Error #404Cannot find

QuarkXPress Server Error #–35

This alert displays if QuarkXPress Server is running on Mac OS and a

shared network volume was selected as the document pool, but the

volume is no longer shared.

What to do: In the QuarkXPress Server administration interface, choose

Administration > Preferences > General and set Document Root Folder

to a shared folder.

See Understanding loggingLogs

50 | A GUIDE TO QUARKXPRESS SERVER 10.1

USING QUARKXPRESS SERVER

Example, GET URL

Understanding logging

http://localhost:8080/sample.qxp

There are two ways to specify a render format:Notes

1. Enter the render type directly in the browser address field:http://localhost:8080/pdf/project.qxp.

2. In the QuarkXPress Server administration interface, choose Administration > Preferences > General and choose the default render type from the Default Renderer Type drop-down menu.

If a request succeeds, a transaction success message is written to the QuarkXPress Server

transaction log file. This message includes the transaction ID, date, time, request type,

project name, response type, response size in bytes, and client IP address. For example:

07/03/2011 14:37:47 - RequestURI = /xml/sample.qxp TransactionUUID = afb6f457-80ae-4d5d-a434-ce9f3e089761 Client = 10.91.30.216 Type = text/xml Size = 4846

If an alert is displayed, an error message is written to the QuarkXPress Server transaction

log file. The transaction entry contains the date and time of the request, the error

code, and the error message. The following is a sample of an error log transaction

entry:

09/03/2011 13:54:33 - RequestURI = /sample.qcd TransactionUUID = dffc3a7e-11fd-4d97-b3fe-8f2129353d58 Client = 10.91.30.216 Error #10120

- Cannot open this document type. Please select a QuarkXPress document or template.

appstudio

ave

The "QuarkXPress Server Log.log" file also contains system-level log information. For

example, if a request makes a renderer stop working, you can figure out which request

it was using the transaction ID and the transaction log.

09/03/2011 014:00:07 ERROR [com.quark.qxps.core.server.ServerRendererMonitor][pool-1-thread-1] - The QuarkXPress Server Renderer with processId 2620 had quit while processing the transaction 87212dae-6ba3-4b3f-97bb-ea8f0c255bf9.

To download all logs to a non-server computer, click Show Transaction Log in the

QuarkXPress Server Web interface, then click Download Logs on the upper right.

Understanding render types

Render types are namespaces you can use to return a QuarkXPress project in a specified

file format. The topics covered here include the following:

Returns a .zip file containing an App Studio article rendered from the App Studio layout(s) in the source project.

Returns a .zip file containing an AVE issue file and its corresponding manifest.

QuarkXPress Server Manager object model classesDescriptionFunction

AppStudioRenderRequest

AVERenderRequest

Returns an EPS file.eps

Returns an ePUB file.epub

Returns a JPEG image.jpeg

Returns a PDF file.pdf

EPSRenderRequest

EPubRenderRequest

JPEGRenderRequest

PDFRenderRequest

A GUIDE TO QUARKXPRESS SERVER 10.1 | 51

USING QUARKXPRESS SERVER

QuarkXPress Server Manager object model classesDescriptionFunction

raw

Returns a PNG image.png

Returns a PostScript file.postscript

Returns a QuarkCopyDesk article.qcddoc

Returns a QuarkXPress project file.qxpdoc

Returns an RLE Raw Custom format image.qxpr

Returns a project in a QuarkXPress internal format.

Returns a low-resolution PDF file.screenpdf

Returns a SWF file.swf

PNGRenderRequest

PostScriptRenderRequest

CopyDeskDocRequest

QuarkXPressRenderRequest

RLERawCustomRenderRequest

RawCustomRenderRequest

ScreenPDFRenderRequest

SWFRenderRequest

The default render type is JPEG.

Developers can implement additional rendering formats through server XTensions

software.

appstudio

The appstudio render type returns a .zip file containing an App Studio article rendered

from the App Studio layout(s) in the source project. It also includes mechanisms for

uploading an article to the App Studio Publishing Portal, retrieving and updating server

settings, and presenting and clearing App Studio Publishing Portal credentials.

Namespace

Parameters

appstudio

upload

html

setcredential

clearcredential

String

Lets you generate an HTML5 article and upload it to the App Studio Publishing Portal. For example:

http://localhost:8080/ appstudio/upload/template.qxp? organization=XXX& publication=YYY&issue=ZZZ& article=AAA

Lets you gerate an HTML5 article and returns it as a .zip file. For example:

http://localhost:8080/ appstudio/html/template.qxp

Lets you log in to the App Studio Publishing Portal. For example:

http://localhost:8080/ appstudio/setcredential? username=XXX&password=YYY

Lets you log out of the App Studio Publishing Portal. For example:

http://localhost:8080/ appstudio/clearcredential

52 | A GUIDE TO QUARKXPRESS SERVER 10.1

USING QUARKXPRESS SERVER

Render modifier parameters

Alerts

config

layout

page

pages

A .zip file containing an HTML5 article.Response

no way of rendering the desired objects.

Please select a QuarkXPress document or template.

See Understanding loggingLogs

String

range)

HTTP Error #406The renderer for this image type has

This alert displays if you submit a render request with the box parameter.

HTTP Error #10120Cannot open this document type. This alert displays if you submit an appstudio

request for a QuarkCopyDesk article.

Lets you retrieve the current publication hierarchy from the App Studio Publishing Portal. For example:

http://qxpserver:port/ appstudio/config

Lets you specify a layout by name or ID. The first layout is Layout 1.

Lets you specify a page.Integer

Lets you specify a range of pages.String (page

Example, GET URL

Example, object model

ave

The ave render type returns a .zip file containing an AVE issue file and its corresponding

manifest.

http://localhost:8080/appstudio/sample.qxp

Request object name: AppStudioRenderRequest

// STEP 1: Create the QuarkXPress Server Request // Context and set the necessary properties com.quark.qxpsm.QRequestContext requestCtx = new com.quark.qxpsm.QRequestContext(); Boolean responseAsURL = false; requestCtx.setDocumentName(docName);

// STEP 2 (SPECIFIC TO REQUESTS): // Create the App Studio renderer // request and embed it in the request context. AppstudioRenderRequest req = new AppstudioRenderRequest(); req.setAppStudioData(request.getParameter("AppStudioData")); requestCtx.setRequest(req);

// STEP 3: Create the service and call the // processRequest() API RequestService service = new RequestServiceStub(); com.quark.qxpsm.QContentData data = service.processRequest(requestCtx);

Namespace

Parameters

AVE

outputstyle

stylename

Lets you specify an output style. To use a named output style, use the name of that output style. For example:

http://localhost:8080/ave/ sample.qxp?outputstyle=stylename

A GUIDE TO QUARKXPRESS SERVER 10.1 | 53

USING QUARKXPRESS SERVER

To use settings that have been captured with the Capture

Settings in the QuarkXPress Export AVE for iPad dialog box,

use document. For example:

http://localhost:8080/ave/ sample.qxp?outputstyle=document

Render modifier parameters

Alerts

format

layout

page

pages

A .zip file containing an AVE issue file and its corresponding manifest.Response

no way of rendering the desired objects.

This Output Style does not exist.

This Output Style cannot be used with this render type.

Please select a QuarkXPress document or template.

String

range)

HTTP Error #406The renderer for this image type has

This alert displays if you submit a render request with the box parameter.

This alert displays if you specify a nonexistent output style.

This alert displays if you specify an output style that is incompatible with this render type.

HTTP Error #10120Cannot open this document type. This alert displays if you submit an ave request for

a QuarkCopyDesk article.

Lets you specify an output format. Use avemag for AVE-Mag or

avedoc for AVE-Doc. The default

is avemag.

Lets you specify a layout by name or ID. The first layout is Layout 1.

Lets you specify a page.Integer

Lets you specify a range of pages.String (page

Example, GET URL

Example, object model

HTTP Error #10545AVE-Doc for an App Studio layout is

not supported.

See Understanding loggingLogs

http://localhost:8080/ave/sample.qxp? format=avemag&layout=2

Request object name: AVERenderRequest

//STEP1: Create the QuarkXPress Server Request //Context and set the necessary properties com.quark.qxpsm.QRequestContext requestCtx = new com.quark.qxpsm.QRequestContext(); Boolean responseAsURL = false; requestCtx.setDocumentName(docName);

//STEP 2(SPECIFIC TO REQUESTS): //Create the AVE renderer //request and embed it in the request context. AVERenderRequest avereq = new AVERenderRequest(); avereq.setAVEData(request.getParameter("AVEData")); avereq.setFormat(request.getParameter( "Format")); avereq.setLayout(request.getParameter( "Layout")); requestCtx.setRequest(avereq);

This alert displays if you submit an ave request with format=avedoc for an App Studio layout.

54 | A GUIDE TO QUARKXPRESS SERVER 10.1

//STEP3: Create the service and call the //processRequest() API RequestService service = new RequestServiceStub(); com.quark.qxpsm.QContentData data = service.processRequest(requestCtx);

The default AVE output style is used.Notes

eps

The eps render type returns an EPS rendering of a page or spread.

USING QUARKXPRESS SERVER

Namespace

Parameters

EPS

outputstyle

epsformat

epspreview

epsdata

epstransparent

stylename

color

tiff | none

ascii | binary | clean8bit

1 | 0 | true | false | yes | no

Lets you specify an output style. To use a named output style, use the name of that output style. For example:

http://localhost:8080/pdf/ sample.qxp?outputstyle=stylename

To use settings that have been captured with the Capture Settings in the QuarkXPress Print dialog box, use document. For example:

http://localhost:8080/pdf/ sample.qxp?outputstyle=document

Lets you specify an EPS format. The default value is color.

Lets you include or omit a TIFF preview. The default value is tiff.

Lets you specify a data type for the EPS file. The default value is

clean8bit.

Lets you specify whether the EPS can include transparent areas.

Render modifier parameters

updateimage

updateflow

page

produceblankpages

scale

spread

true | false

1 | 0 | true | false | yes | no

Float .1 to 6.92 for Windows

Mac OS Mac OS or 6.92 (692%) on

Integer

Lets you specify whether to update imported pictures.

Lets you specify whether to update the text flow version of a project to the current version.

Lets you specify a page.Integer

Lets you specify whether to render blank pages.

Lets you specify a scaling percentage. The valid values are from .1 (10%) to 8 (800%) on .1 to 8 on

Windows.

Lets you specify a spread. The first spread is spread 1. In a facing-page

A GUIDE TO QUARKXPRESS SERVER 10.1 | 55

USING QUARKXPRESS SERVER

document, spread 1 consists of the first page.

Alerts

Example, GET URL

layout

downloadlayoutFonts

downloadImportedPdfEpsFonts

An EPS file.Response

no way of rendering the desired objects.

This Output Style does not exist.

This Output Style cannot be used with this render type.

See Understanding loggingLogs

http://localhost:8080/eps/sample.qxp?epsformat= color&epsdata=clean8bit&epspreview=tiff&epsbleed= 0&epstransparent=0

String

1 | 0 | true | false | yes | no

HTTP Error #406The renderer for this image type has

This alert displays if you submit a render request with the pages or box parameter.

This alert displays if you specify a nonexistent output style.

This alert displays if you specify an output style that is incompatible with this render type.

Lets you specify a layout by name or ID. The first layout is Layout 1.

Lets you specify whether to download all fonts used in the layout and all system fonts.

Lets you specify whether to download all fonts required by imported PDF and EPS files.

Example, object model

Notes

Request object name: EPSRenderRequest

//STEP1: Create the QuarkXPress Server Request //Context and set the necessary properties com.quark.qxpsm.QRequestContext requestCtx = new com.quark.qxpsm.QRequestContext(); Boolean responseAsURL = false; requestCtx.setDocumentName(docName);

//STEP 2(SPECIFIC TO REQUESTS): //Create the EPS renderer //request and embed it in the request context. EPSRenderRequest epsreq = new EPSRenderRequest(); epsreq.setEPSData(request.getParameter("EPSData")); epsreq.setEPSFormat(request.getParameter( "EPSFormat")); epsreq.setEPSPreview(request.getParameter( "EPSPreview")); requestCtx.setRequest(epsreq);

//STEP3: Create the service and call the //processRequest() API RequestService service = new RequestServiceStub(); com.quark.qxpsm.QContentData data = service.processRequest(requestCtx);

You can specify an output style and set additional local parameters of that output style. For example, if no bleed setting is specified in the output style named "mystylename", you can specify a bleed setting with a URL like the following:

http://localhost:8080/eps/sample.qxp? outputstyle=mystylename?bleed=symmetric

You can override settings in an output style. For example, if an asymmetric bleed is specified in the output style named "mystylename," you could override it with the same URL.

56 | A GUIDE TO QUARKXPRESS SERVER 10.1

If you do not specify an EPS output style, the default EPS output style is used.

epub

The epub render type returns an ePUB rendering of a layout.

USING QUARKXPRESS SERVER

Namespace

Render modifier parameters

Alerts

Example, GET URL

Example, object model

ePUB

layout

outputstyle

An ePUB (.epub) file.Response

no way of rendering the desired objects.

layout in the document.

See Understanding loggingLogs

http://localhost:8080/epub/sample.qxp? outputstyle=epub1&layout=2

Request object name: EPubRenderRequest

//STEP1: Create the QuarkXPress Server Request //Context and set the necessary properties com.quark.qxpsm.QRequestContext requestCtx = new com.quark.qxpsm.QRequestContext(); Boolean responseAsURL = false; requestCtx.setDocumentName(docName);

String

HTTP Error #406The renderer for this image type has

This alert displays if you submit a render request with the pages or box parameter.

HTTP Error #10543ePub not created. There is no reflow

This error appears if there is no reflow layout.

Lets you specify a layout by name or ID. The first layout is Layout 1.

Lets you specify an ePUB output style by name or ID.

Namespace

Parameters

//STEP 2(SPECIFIC TO REQUESTS): //Create the ePUB renderer //request and embed it in the request context. EPubRenderRequest epubreq = new EPubRenderRequest(); epubreq.setEPubData(request.getParameter("EPubData")); epubreq.setCreateTOC(request.getParameter( "CreateTOC")); epubreq.setLayout(request.getParameter( "Layout")); requestCtx.setRequest(epubreq);

//STEP3: Create the service and call the //processRequest() API RequestService service = new RequestServiceStub(); com.quark.qxpsm.QContentData data = service.processRequest(requestCtx);

You can only create an ePUB file from a project that includes a reflow article.Notes

jpeg

The jpeg render type returns a JPEG rendering of a page or spread.

JPEG

jpegquality

1 | 2 | 3 | 4

Lets you specify the image quality of a rendered JPEG image. The valid values are: 1 (highest quality), 2 (high

A GUIDE TO QUARKXPRESS SERVER 10.1 | 57

USING QUARKXPRESS SERVER

quality), 3 (medium quality), and 4 (lowest quality). The default value is 1.

Render modifier parameters

upadateimage

updateflow

pasteboard

showboxoutline

boxes

page

scale

box

spread

true | false

Float .1 to 6.92 for Windows .1 to 8 on Mac OS)

Integer

Lets you specify whether to update imported pictures.true | false

Lets you specify whether to update the text flow version of a project to the current version.

Lets you specify whether to display pasteboard items. Works only with spread parameter. The default value is true. For example:

http://localhost:8080/jpeg/document.qxp? spread=1&pasteboard=true

Lets you specify whether to include bounding box outlines in the response JPEG image even if the boxes have no content.. The default value is false.

Lets you request multiple boxes.String

Lets you request a single page.Integer

Lets you specify a scaling percentage. The valid values are from .1 (10%) to 8 (800%) on Mac OS or 6.92 (692%) on Windows.

Lets you request a single box.String

Lets you specify a spread. The first spread is spread 1. In a facing-page document, spread 1 consists of the first page.

Example, GET URL

Example, object model

layout

A JPEG file.Response

See Understanding loggingLogs

http://localhost:8080/jpeg/sample.qxp?jpegquality=1

Request object name: JPEGRenderRequest

// STEP1: Create the QuarkXPress Server Request // Context and set the necessary properties com.quark.qxpsm.QRequestContext requestCtx = new com.quark.qxpsm.QRequestContext(); Boolean responseAsURL = false; requestCtx.setDocumentName(docName);

// STEP2: Create the JPEG renderer request and attach it // to the request context. JPEGRenderRequest jpreq = new JPEGRenderRequest(); jpreq.setJPEGQuality(request.getParameter("jpegQuality")); jpreq.setLayout(request.getParameter("Layout")); requestCtx.setRequest(jpreq);

// STEP3: Create the service and // call the processRequest() API RequestService service = new RequestServiceStub(); com.quark.qxpsm.QContentData data = service.processRequest(requestCtx);

String

Lets you specify a layout by name or ID. The first layout is Layout 1.

58 | A GUIDE TO QUARKXPRESS SERVER 10.1

USING QUARKXPRESS SERVER

kindle

The kindle render type returns a rendering of a layout that can be viewed on Amazon

Kindle readers.

Namespace

Render modifier parameters

Alerts

Example, GET URL

Example, object model

kindle

layout

outputstyle

A Kindle (.mobi) file.Response

no way of rendering the desired objects.

layout in the document.

See Understanding loggingLogs

http://localhost:8080/kindle/sample.qxp? outputstyle=kindle&layout=2

Request object name: KindleRenderRequest

//STEP1: Create the QuarkXPress Server Request //Context and set the necessary properties com.quark.qxpsm.QRequestContext requestCtx = new com.quark.qxpsm.QRequestContext(); Boolean responseAsURL = false; requestCtx.setDocumentName(docName);

String

HTTP Error #406The renderer for this image type has

This alert displays if you submit a render request with the pages or box parameter.

HTTP Error #10543Kindle not created. There is no reflow

This error appears if there is no reflow layout.

Lets you specify a layout by name or ID. The first layout is Layout 1.

Lets you specify a Kindle output style by name or ID.

Namespace

//STEP 2(SPECIFIC TO REQUESTS): //Create the Kindle renderer //request and embed it in the request context. KindleRenderRequest kindlereq = new KindleRenderRequest(); kindlereq.setKindleData(request.getParameter("KindleData")); kindlereq.setCreateTOC(request.getParameter( "CreateTOC")); kindlereq.setLayout(request.getParameter( "Layout")); requestCtx.setRequest(kindlereq);

//STEP3: Create the service and call the //processRequest() API RequestService service = new RequestServiceStub(); com.quark.qxpsm.QContentData data = service.processRequest(requestCtx);

You can only create a Kindle file from a project that includes a reflow article.Notes

literal

The literal render type returns the contents of a file without any attempt to process

it as a template. Depending on the file's MIME type, the requested project can be

displayed within the browser (for example, if the response is a JPEG file) or saved to

disk (for example, if the response is a Microsoft Word document).

literal

A GUIDE TO QUARKXPRESS SERVER 10.1 | 59

USING QUARKXPRESS SERVER

The requested file returned in the HTTP response.Response

Alerts

Example, GET URL

Example, object model

pdf

Incorrect administration realm username and password.

See Understanding loggingLogs

http://localhost:8080/literal/Story.doc

Request object name: LiteralRequest

com.quark.qxpsm.QRequestContext rc = new com.quark.qxpsm.QRequestContext(); if(!this.DocumentSettings1.documentName.Text.Equals("")) rc.documentName = this.DocumentSettings1.documentName.Text; rc.request = new LiteralRequest();

//Create the service and call it with QRequestContext object RequestService svc = new RequestService(); com.quark.qxpsm.QContentData qc = svc.processRequest(rc);

HTTP Error #401

This alert displays if you specify an invalid administrator user name and password.

What to do: Use the user name and password set in the Authentication pane of the General Preferences dialog box (Administration > Preferences > General) in the QuarkXPress Server Web interface.

The pdf render type returns a PDF rendering of a project.

Namespace

Parameters

PDF

outputstyle

title

subject

author

keywords

includehyperlinks

exportlistsashyperlinks

stylename, document

1 | 0 | true | false | yes | no

Lets you specify an output style. To use a named output style, use the name of that output style. For example:

http://localhost:8080/pdf/ sample.qxp?outputstyle=stylename

To use settings that have been captured with the Capture Settings in the QuarkXPress Export as PDF dialog box, use document. For example:

http://localhost:8080/pdf/ sample.qxp?outputstyle=document

Lets you specify the title of the PDF file.String

Lets you specify the subject of the PDF file.String

Lets you specify the author of the PDF file.String

Lets you specify keywords for the PDF file.String

Lets you specify whether to include hyperlinks in the PDF file.

Lets you specify whether to export lists as hyperlinks. To use this parameter, you must set

includehyperlinks to true.

exportindexesashyperlinks

60 | A GUIDE TO QUARKXPRESS SERVER 10.1

1 | 0 | true | false | yes | no

Lets you specify whether to export the index as hyperlinks. To use this parameter, you must set includehyperlinks to true.

USING QUARKXPRESS SERVER

exportlistsasbookmarks

mode

printcolors

plates

produceblankpages

useopi

images

1 | 0 | true | false | yes | no

composite or separations

cmyk, rgb, grayscale, cmykandspot, asis

inripseps

1 | 0 | true | false | yes | no

false | yes | no

includeimages, omittiff, omittiffandeps

Lets you specify whether to export lists as bookmarks. To use this parameter, you must set includehyperlinks to true.

Lets you specify whether the PDF file is a composite or includes separations.

Lets you specify the color space of the PDF file. This option is available only when mode is set to composite.

Lets you specify a separation method. This option is available only when mode is set to

separations.

Lets you specify whether to include blank pages. This option is available only when mode is set to composite.

Lets you specify whether to use OPI.1 | 0 | true |

Lets you specify whether to include TIFF and EPS images from an OPI server.

registration

offset

bleed

offsetbleed

spreads

lowresolution

colorimagedownsample

grayscaleimagedownsample

monochromeimagedownsample

colorcompression

off, centered, offcenter

points)

symmetric

0–6 (in inches)

false | yes | no

9–2400

true | false

Lets you include, omit, and configure registration marks.

Lets you specify the offset of registration marks.0–30 (in

Lets you specify a bleed type.pageitemsonly,

Lets you specify a bleed offset to use. This option is available only when bleed is set to

symmetric.

Lets you specify whether to output spreads.1 | 0 | true |

Lets you request a low-resolution (36 dpi) PDF.1 | 0 | true |

Lets you specify the resolution of color images.9–2400

Lets you specify the resolution of grayscale images.

Lets you specify the resolution of monochrome images.

Lets you specify whether medium-quality manual JPEG compression should be applied to color images.

grayscalecompression

monochromecompression

true | false

Lets you specify whether medium-quality manual JPEG compression should be applied to grayscale images.

Lets you specify whether ZIP compression should be applied to monochrome images.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 61

USING QUARKXPRESS SERVER

pdffile

psfile

thumbnail

mode

fontdownload

layers

verification

separate

produceblankplates

String

separations

yes | no

String

yes | no

Lets you specify the PDF name. This option is available only when PDF to Folder is selected in QuarkXPress Server PDF preferences.

Lets you specify the PostScript file name. This option is available only when PostScript for later Distilling is selected in QuarkXPress Server PDF preferences.

Lets you embed a thumbnail in the PDF file.bw | color

Lets you specify the PDF file's color mode.composite |

Lets you turn font download on or off. You cannot specify which fonts are downloaded.

Lets you specify which layers should be included, as a comma-separated list.

Lets you use PDF/X–1a or PDF/X–3 verification.pdfx1a | pdfx3

Lets you specify whether to output each page as a separate file.

Lets you specify whether to include blank plates.

download

layoutstart

layoutend

1 | 0 | true | false

1 | 0 | true | false | yes | no

Integer

When download is true, the browser always displays a dialog box that lets the end user save the returned file, even if the browser can display it.

When download is false, the browser attempts to display the returned file. If the browser cannot display the file, it lets the end user save the returned file.

The default value is false.

Lets you specify the number of the first layout to render when you render multiple layouts as separate PDF files. PDF files are saved at the location specified in QuarkXPress Server preferences (Administration > Preference > General > Server > Document Root Folder). The first layout in a project is layout 0. For example:

http://localhost:8080/pdf/multilayout.qxp? layoutstart=0&layoutend=3

Lets you specify the number of the last layout to render when you render multiple layouts as separate PDF files. PDF files are saved at the location specified in QuarkXPress Server preferences (Administration > Preference > General > Server > Document Root Folder). The first layout in a project is layout 0. For example:

http://localhost:8080/pdf/multilayout.qxp? layoutstart=0&layoutend=3

updateimage

62 | A GUIDE TO QUARKXPRESS SERVER 10.1

true | false

Lets you specify whether to update imported pictures.

USING QUARKXPRESS SERVER

Render modifier parameters

updateflow

page

pages

spread

layout

spreads

A PDF file.Response

requested contains only blank pages.

true | false

range)

Integer

String

true | false | yes | no

HTTP Error #500This page range is invalidAlerts

QuarkXPress Server Error #147

Lets you specify whether to update the text flow version of a project to the current version.

Lets you specify a single page.Integer

Lets you specify a range of pages.String (page

Lets you specify a spread. The first spread is spread 1. In a facing-page document, spread 1 consists of the first page.

Lets you specify a layout by name or ID. The first layout is Layout 1.

Lets you specify that the output use spreads.Boolean 1 | 0 |

This alert displays if you try to render an invalid page range.

HTTP Error #500No file produced. The project

This alert displays if you try to render a a project that contains only blank pages.

Example, GET URL

Example, object model

This alert displays if you specify a nonexistent output style.This Output Style does not

exist.

This Output Style cannot be used with this render type.

See Understanding loggingLogs

This URL renders "sample.qxp" as a PDF with a symmetric bleed:

http://localhost:8080/pdf/sample.qxp? bleed=symmetric&offsetbleed=2

This URL renders a PDF in which color images are downsampled to a resolution of 300 dpi and manual medium-quality JPEG compression is applied:

http://localhost:8080/pdf/sample.qxp? colorimagedownsample=300&colorcompression=true

Request object name: PDFRenderRequest

// STEP1: Create the QuarkXPress Server Request Context // and set the nescessary properties com.quark.qxpsm.QRequestContext requestCtx = new com.quark.qxpsm.QRequestContext(); Boolean responseAsURL = false; requestCtx.setDocumentName(docName);

// STEP 2(SPECIFIC TO REQUESTS): // Create the PDF renderer request // and embed it in the request context. PDFRenderRequest pdfreq = new PDFRenderRequest(); pdfreq.setAuthor(request.getParameter("Author")); pdfreq.setTitle(request.getParameter("Title")); pdfreq.setLayout(request.getParameter("Layout")); pdfreq.setSpread(request.getParameter("Spread")); pdfreq.setPage(request.getParameter("mPage")); pdfreq.setPages(request.getParameter("Pages"));

This alert displays if you specify an output style that is incompatible with this render type.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 63

USING QUARKXPRESS SERVER

if( strLowResolution !=null && strLowResolution.equals("True")) pdfreq.setLowResolution("true"); requestCtx.setRequest(pdfreq);

// STEP3: Create the service and // call the processRequest() API RequestService service = new RequestServiceStub(); com.quark.qxpsm.QContentData data = service.processRequest(requestCtx);

For more information about the object model, see the samples.

Notes

There are three ways to generate PDF files with QuarkXPress Server. You can generate a PDF file in QuarkXPress Server and return it to the end user, generate the PDF in QuarkXPress server and save it to a folder on the server computer, or generate a PostScript file for later distilling and save it to a folder on the server computer. To choose one of these output methods in QuarkXPress Server, choose Administration > Preferences > Renderer > PDF) and then click DirectPDF, PDFtoFolder, or PS4D (PostScript for Later Distilling). If you choose either of the last two options, click Browse and navigate to the target folder, then choose an option from the Default Name drop-down menu.

http://localhost:8080/pdf/sample.qxp? outputstyle=mystylename&bleed=symmetric

You can override settings in an output style. For example, if an asymmetric bleed is specified in the output style named "mystylename," you could override it with the same URL.

If you do not specify a PDF output style, the default PDF output style is used. The default PD output style is Screen - Low Quality/Low Resolution.

You can still obtain a high resolution PDF by specifying the output style. Output style names are case-sensitive and should be precise.

The following will return a list of output styles from the server:

http://<server><port>/getserverinfo

<OUTPUTSTYLES> <OUTPUTSTYLE TYPE = "PDF">Default PDF Output Style</OUTPUTSTYLE> <OUTPUTSTYLE TYPE = "PDF">Press - High Quality/High Resolution</OUTPUTSTYLE> <OUTPUTSTYLE TYPE = "PDF">Print - Medium Quality/Medium Resolution</OUTPUTSTYLE> <OUTPUTSTYLE TYPE = "PDF">Screen - Medium Quality/Low Resolution</OUTPUTSTYLE> <OUTPUTSTYLE TYPE = "PDF">Screen - Low Quality/Low Resolution</OUTPUTSTYLE>

<OUTPUTSTYLE TYPE = "PDF">PDF/X-3:2002</OUTPUTSTYLE> <OUTPUTSTYLE TYPE = "PDF">PDF/X-1a:2001</OUTPUTSTYLE> <OUTPUTSTYLE TYPE = "Print">Default Print Output Style</OUTPUTSTYLE> <OUTPUTSTYLE TYPE = "EPS">Default EPS Output Style</OUTPUTSTYLE> <OUTPUTSTYLE TYPE = "ePub">Default ePub Output Style</OUTPUTSTYLE> <OUTPUTSTYLE TYPE = "Kindle">Default Kindle Output Style</OUTPUTSTYLE> <OUTPUTSTYLE TYPE = "PDF">Default PDF For AVE</OUTPUTSTYLE> <OUTPUTSTYLE TYPE = "AVE">Default AVE Output Style</OUTPUTSTYLE> </OUTPUTSTYLES >

png

The png render type returns a PNG rendering of a page or spread.

Namespace

Parameters

PNG

pngcompression

1 | 2 | 3 | 4

64 | A GUIDE TO QUARKXPRESS SERVER 10.1

Lets you specify the compression of a PNG response. The valid values are: 1 (lowest compression), 2 (medium compression), 3 (high compression), and 4 (highest compression). The default value is 1.

USING QUARKXPRESS SERVER

Render modifier parameters

transparentpng

upadateimage

updateflow

boxes

page

scale

box

spread

layout

A PNG file.Response

true | false

Float .1 to

6.92 for Windows .1 to 8 on Mac OS

Integer

String

Lets you specify whether to generate a PNG file that uses transparency.

Lets you specify whether to update imported pictures.true | false

Lets you specify whether to update the text flow version of a project to the current version.

Lets you request multiple boxes.String

Lets you specify a single page.Integer

Lets you specify a scaling percentage. The valid values are from .1 (10%) to 8 (800%) on Mac OS or 6.92 (692%) on Windows.

Lets you request a single box.String

Lets you specify a spread. The first spread is spread 1. In a facing-page document, spread 1 consists of the first page.

Lets you specify a layout by name or ID. The first layout is Layout 1.

Example, GET URL

Example, object model

See Understanding loggingLogs

http://localhost:8080/png/sample.qxp?pngcompression=1

Request object name: PNGRenderRequest

// STEP1: Create the QuarkXPress Server Request // Context and set the nescessary properties com.quark.qxpsm.QRequestContext rc = new com.quark.qxpsm.QRequestContext(); Boolean responseAsURL = false; rc.setDocumentName(docName);

// STEP 2(SPECIFIC TO REQUESTS):Create the PNG renderer // request and embed it in the request context. PNGRenderRequest pngreq = new PNGRenderRequest(); pngreq.setPNGCompression(request.getParameter( "PNGCompression")); pngreq.setLayout(request.getParameter("Layout")); pngreq.setSpread(request.getParameter("Spread")); pngreq.setPage(request.getParameter("mPage")); rc.setRequest(pngreq);

// STEP3: Create the service and // call the processRequest() API RequestService service = new RequestServiceStub(); com.quark.qxpsm.QContentData data = service.processRequest(rc);

Namespace

Parameters

postscript

The postscript render type returns a PostScript rendering of a project.

PostScript

prntbleed

clip<Boolean>,

Lets you specify bleed values for a page.Page | asym,

A GUIDE TO QUARKXPRESS SERVER 10.1 | 65

USING QUARKXPRESS SERVER

outputstyle

top<float>, bottom<float>, left<float>, right<float> | sym, clip<Boolean>, amount<float>

stylename, document

To specify an asymmetric bleed, use the following format:

prntbleed=asym,clip,top,bottom, left, right

The clip value is Boolean (yes/no). The top, bottom,

left, and right values are float values. For example: http://localhost:8080/

postscript/Sample.qxp? prntbleed=asym,true,1,2,2,1

The above example results in an asymmetric bleed of 1 on the top, 2 on the bottom, 2 on the left, and 1 on the right.

To specify a symmetric bleed, use the following format:

prntbleed=sym,clip,amount

The clip value is Boolean (yes/no). The amount value is a float value. For example:

http://localhost:8080/ postscript/Sample.qxp? prntbleed=sym,true,1

The above example results in a symmetric bleed of 1 on all sides. Default: prntbleed=sym,yes,0

Lets you specify an output style. To use a named output style, use the name of that output style. For example:

http://localhost:8080/ postscript/ sample.qxp?outputstyle=stylename

To use settings that have been captured with the Capture Settings in the QuarkXPress Print dialog box, use

document. For example: http://localhost:8080/

postscript/ sample.qxp?outputstyle=document

Render modifier parameters

Alerts

updateimage

updateflow

page

pages

spread

layout

A PostScript file.Response

invalid.

The document requested

Lets you specify whether to update imported pictures.true | false

true | false

range)

Integer

String

HTTP Error #500This page range is

QuarkXPress Server Error #147

This alert displays if you try to render an invalid page range.

HTTP Error #500No file produced.

This alert displays if you try to render a a project that contains only blank pages.

Lets you specify whether to update the text flow version of a project to the current version.

Lets you specify a single page.Integer

Lets you specify a range of pages.String (page

Lets you specify a spread. The first spread is spread 1. In a facing-page document, spread 1 consists of the first page.

Lets you specify a layout by name or ID. The first layout is Layout 1.

66 | A GUIDE TO QUARKXPRESS SERVER 10.1

contains only blank pages.

mapped to file not found

does not exist.

USING QUARKXPRESS SERVER

HTTP Error #500PostScript printer

This alert displays if the PostScript printer or driver is not set to Print to File.

This alert displays if you specify a nonexistent output style.This Output Style

Example, GET URL

Example, object model

This Output Style cannot be used with this render type.

See Understanding loggingLogs

http://localhost:8080/postscript/Sample.qxp

Request object name: PostScriptRenderRequest

// STEP1: Create the QuarkXPress Server Request // Context and set the nescessary properties com.quark.qxpsm.QRequestContext requestCtx = new com.quark.qxpsm.QRequestContext(); Boolean responseAsURL = false; requestCtx.setDocumentName(docName);

// STEP 2(SPECIFIC TO REQUESTS): // Create the Post Script renderer // request and embed it in the request context. PostScriptRenderRequest pscreq = new PostScriptRenderRequest(); pscreq.setPrintBleed(request.getParameter("PrintBleed")); pscreq.setPrintPPD(request.getParameter("PrintPPD")); pscreq.setPages(request.getParameter("Pages")); requestCtx.setRequest(pscreq);

This alert displays if you specify an output style that is incompatible with this render type.

Namespace

// STEP3: Create the service and call the // processRequest() API RequestService service = new RequestServiceStub(); com.quark.qxpsm.QContentData data = service.processRequest(requestCtx);

To create a PostScript file, you must have a PostScript driver on the server computer.Notes

http://localhost:8080/eps/sample.qxp? outputstyle=mystylename&bleed=symmetric

You can override settings in an output style. For example, if an asymmetric bleed is specified in the output style named "mystylename," you could override it with the same URL.

If you do not specify a PostScript-compatible output style, the default PostScript-compatible output style is used.

qcddoc

The qcddoc render type returns a QuarkCopyDesk article.

qcddoc

A GUIDE TO QUARKXPRESS SERVER 10.1 | 67

USING QUARKXPRESS SERVER

Parameters

article

component

format

saveastemplate

String

lightweight | fullfeatured

true | false

Lets you specify which article in a project to render. For example:

http://localhost:8080/qcddoc/ abc.qxp?article=article1

Lets you specify which component in an article to render. For example:

http://localhost:8080/copydesk/ abc.qcd?component=comp1

Lets you render an article in lightweight or full-featured format. For example:

http://localhost:8080/qcddoc/ abc.qxp?article=article1& format=fullfeatured

Lets you save a copy of an article that was created in QuarkCopyDesk as a template. The default value is true. For example:

http://QXPServer8:8080/saveas/ qcddoc/article.qcd?saveastemplate=true

You can also use this parameter to save a copy of a template as an article. For example:

http://QXPServer8:8080/saveas/ qcddoc/template.qct?saveastemplate=false

Render modifier parameters

Alerts

includepagepicture

A QuarkCopyDesk article.Response

There is no box with the specified identifier.

in the article name can't be greater than max limit.

true | false | 1 | 0

XMLmodify

This alert displays if the box corresoponding to a referenced component does not exist.

This alert displays if an article name is longer than 32 characters.The number of characters

Lets you include a page picture when you export an article from a QuarkXPress layout. Valid options are:

picformat (embedded or separate) quality (blackandwhite or color) picdpi (72, 144, or 200) spreadrange (all or first)

For example:

http://localhost:8080/saveas/qcddoc/

4.qxp?includepagepicture=1& quality=blackandwhite&picdpi=144& spreadrange=first

http://localhost:8080/saveas/qcddoc/ PagePicture.qxp?includepagepicture=true

Lets you modify the article with XML. For more information, see "Using XML modify."

The article/component name is not unique.

See Understanding loggingLogs

68 | A GUIDE TO QUARKXPRESS SERVER 10.1

This alert displays if you create or change the name of an article or component so that it is the same as the name of an existing article or component.

USING QUARKXPRESS SERVER

Example, GET URL

Example, object model

qxpdoc

Namespace

Parameters

http://localhost:8080/qcddoc/copydesk/sample.qcd

Request object name: CopyDeskDocRequest

The qxpdoc render type returns a QuarkXPress project.

qxpdoc

qxpdocver

upadateimage

saveastemplate

8 | 9

true | false

Indicates the QuarkXPress version format to use. For example:

http://localhost:8080/qxpdoc/ construct/project1.qxp?qxpdocver=8

Lets you specify whether to return modified pictures in the response or not. If set to false, modified pictures are not returned. If set to true, modified pictures are returned. The default value is true.

Lets you save a copy of a project as a template. The default value is true. For example:

http://localhost:8080/saveas/ qxpdoc/project.qxp?saveastemplate=true

You can also use this parameter to save a copy of a template as a project. For example:

http://localhost:8080/saveas/ qxpdoc/template.qpt?saveastemplate=false

Render modifier parameters

Alerts

Example, GET URL

Example, object model

layout

A QuarkXPress project.Response

document return is disabled.

this image type has no way of rendering the desired objects.

QuarkXPress Project down to an earlier version.

See Understanding loggingLogs

http://localhost:8080/qxpdoc/sample.qxp

Request object name: QuarkXPressRenderRequest

String

HTTP Error #500QuarkXPress

This alert displays if Disable QXD Return is checked in the QuarkXPress Server administration interface (Administration > Preferences > General > Server).

HTTP Error #406The renderer for This alert displays if you submit a qxpdoc render request with the page,

pages, box, or spread parameter.

HTTP Error #500Cannot save a

This alert displays if you attempt to save a QuarkXPress 6.x project to an earlier version of QuarkXPress with the qxpdocver parameter.

Lets you specify a layout by name or ID. The first layout is Layout 1.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 69

USING QUARKXPRESS SERVER

requestCtx.setDocumentName(docName);

// STEP 2(SPECIFIC TO REQUESTS):Create the QuarkXPress // renderer request and embed it in the request context. QuarkXPressRenderRequest qxpreq = new QuarkXPressRenderRequest(); qxpreq.setDocumentVersion(request.getParameter( "XpressDocVersion")); qxpreq.setLayout(request.getParameter("Layout")); requestCtx.setRequest(qxpreq);

// STEP3: Create the service and call the processRequest() API RequestService service = new RequestServiceStub(); com.quark.qxpsm.QContentData data = service.processRequest(requestCtx);

screenpdf

The screenpdf render type returns a low-resolution PDF rendering of a project. This

render type overrides the PDF Workflow setting in the QuarkXPress Server

administration interface (Administration > Preferences > Renderer > PDF) and always

sends the PDF file to the browser.

Namespace

Parameters

Screenpdf

outputstyle

title

subject

author

keywords

includehyperlinks

exportlistsashyperlinks

stylename

1 | 0 | true | false | yes | no

Lets you specify an output style. To use a named output style, use the name of that output style. For example:

http://localhost:8080/screenpdf/ sample.qxp?outputstyle=stylename

To use settings that have been captured with the Capture Settings in the QuarkXPress Print dialog box, use document. For example:

http://localhost:8080/screenpdf/ sample.qxp?outputstyle=document

Lets you specify the title of the PDF file.String

Lets you specify the subject of the PDF file.String

Lets you specify the author of the PDF file.String

Lets you specify keywords of the PDF file.String

Lets you specify whether to include hyperlinks in the PDF file.

Lets you specify whether to export lists as hyperlinks. To use this parameter, you must set

includehyperlinks to true.

exportindexesashyperlinks

exportlistsasbookmarks

mode

70 | A GUIDE TO QUARKXPRESS SERVER 10.1

1 | 0 | true | false | yes | no

composite or separations

Lets you specify whether to export the index as hyperlinks. To use this parameter, you must set

includehyperlinks to true.

Lets you specify whether to export lists as bookmarks. To use this parameter, you must set includehyperlinks to true.

Lets you specify whether the PDF file is a composite or includes separations.

USING QUARKXPRESS SERVER

printcolors

plates

produceblankpages

useopi

images

registration

offset

bleed

offsetbleed

cmyk, rgb, grayscale, cmykandspot, asis

inripseps

1 | 0 | true | false | yes | no

yes | no

includeimages, omittiff, omittiffandeps

off, centered, offcenter

symmetric

0–6 (in inches)

Lets you specify the color space of the PDF file. This option is available only when mode is set to composite.

Lets you specify a separation method. This option is available only when mode is set to

separations.

Lets you specify whether to include blank pages. This option is available only when mode is set to composite.

Lets you specify whether to use OPI.1 | 0 | true | false |

Lets you specify whether to include TIFF and EPS images from an OPI server.

Lets you include, omit, and configure registration marks.

Lets you specify the offset of registration marks.0–30 (in points)

Lets you specify a bleed type.pageitemsonly,

Lets you specify a bleed offset to use. This option is available only when bleed is set to

symmetric.

spreads

lowresolution

colorimagedownsample

grayscaleimagedownsample

monochromeimagedownsample

colorcompression

grayscalecompression

monochromecompression

pdffile

yes | no

9–2400

true | false

String

Lets you specify whether to output spreads.1 | 0 | true | false |

Lets you request a low-resolution (36 dpi) PDF.1 | 0 | true | false |

Lets you specify the resolution of color images.9–2400

Lets you specify the resolution of grayscale images.

Lets you specify the resolution of monochrome images.

Lets you specify whether medium-quality manual JPEG compression should be applied to color images.

Lets you specify whether medium-quality manual JPEG compression should be applied to grayscale images.

Lets you specify whether ZIP compression should be applied to monochrome images.

Lets you specify the PDF name. This option is available only when PDF to Folder is selected in QuarkXPress Server PDF preferences.

psfile

String

Lets you specify the PostScript file name. This option is available only when PostScript for later Distilling is selected in QuarkXPress Server PDF preferences.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 71

USING QUARKXPRESS SERVER

thumbnail

mode

fontdownload

layers

transparencyres

verification

separate

produceblankplates

updateimage

updateflow

separations

yes | no

String

Integer value from 36 to 3600

yes | no

true | false

Lets you embed a thumbnail in the PDF file.bw | color

Lets you specify the PDF file's color mode.composite |

Lets you turn font download on or off. You cannot specify which fonts are downloaded.

Lets you specify which layers should be included, as a comma-separated list.

Lets you specify the resolution for flattened content.

Lets you use PDF/X–1a or PDF/X–3 verification.pdfx1a | pdfx3

Lets you specify whether to output each page as a separate file.

Lets you specify whether to include blank plates.

Lets you specify whether to update imported pictures.

Lets you specify whether to update the text flow version of a project to the current version.

Render modifier parameters

Example, GET URL

page

pages

spread

layout

spreads

A screen-resolution PDF fileResponse

document requested contains only blank pages.

See Understanding loggingLogs

http://localhost:8080/screenpdf/sample.qxp? colorimagedownsample=72&colorcompression=0

Integer

String

| false | yes | no)

HTTP Error #500This page range is invalid.Alerts

QuarkXPress Server Error #147

This alert displays if you try to render an invalid page range.

HTTP Error #500No file produced. The

This alert displays if you try to render a a project that contains only blank pages.

Lets you specify a single page.Integer

Lets you specify a range of pages.String (page range)

Lets you specify a spread. The first spread is spread 1. In a facing-page document, spread 1 consists of the first page.

Lets you specify a layout by name or ID. The first layout is Layout 1.

Lets you specify that the output use spreads.Boolean (1 | 0 | true

Example, object model

Request object name: ScreenPDFRenderRequest

// STEP1: Create the QuarkXPress Server Request Context // and set the nescessary properties com.quark.qxpsm.QRequestContext requestCtx = new com.quark.qxpsm.QRequestContext(); String docName = request.getParameter("documentName") ; requestCtx.setDocumentName(docName);

72 | A GUIDE TO QUARKXPRESS SERVER 10.1

// STEP 2(SPECIFIC TO REQUESTS): // Create the QuarkXPress renderer // request and embed it in the request context. ScreenPDFRenderRequest screenpdfRequest = new ScreenPDFRenderRequest(); screenpdfRequest.setColorImageDownSample( request.getParameter("ColorImageDownSample")); screenpdfRequest.setCompression(request.getParameter( "Compression")); requestCtx.setRequest(screenpdfRequest);

// STEP3: Create the service and // call the processRequest() API RequestService service = new RequestServiceStub(); com.quark.qxpsm.QContentData data = service.processRequest(requestCtx);

Understanding render modifiers

Render modifiers let you control which parts of a project are rendered and set the scale

of the returned renderings. The topics covered here include the following:

USING QUARKXPRESS SERVER

box

boxes

layer

layout

movepages

page

pages

scale

spread

spreads

DescriptionProperty

The box render modifier lets you render a single box.

The boxes render modifier lets you render multiple boxes.

The layer render modifier lets you show and hide layers prior to rendering. This render modifier also lets you add and remove layers from a project on the server.

The layout render modifier lets you render a particular layout.

The movepages render modifier lets you move pages prior to rendering.

The page render modifier lets you render a single page.

The pages render modifier lets you render multiple pages.

The scale render modifier lets you specify the scale at which content is rendered.

The spread render modifier lets you render a single spread.

The spreads render modifier lets you render multiple spreads.

Additional render-type-specific parameters are listed on each render type's page.

In the QuarkXPress Server Manager API, render modifiers are properties of render

request classes.

Render modifier names are not case-sensitive.

Annotate and append errors

The annotate and append errors feature allows PDF output to be generated regardless

of the errors in the modifier xml.

Errors recorded by this feature are:

A GUIDE TO QUARKXPRESS SERVER 10.1 | 73

USING QUARKXPRESS SERVER

• Missing image file.

• Missing text file.

•

Box/table node referenced by ANCHOREDBOXREF isn't available in the modifier XML

• Anchored box/table is created but is not referenced in the parent box.

•

Invalid ROWCOUNT/COLUMNCOUNT/MERGE.

•

Invalid TABLEBREAK.

•

Applying INVALID Gridline attribute to row/column.

• Table creation of incorrect rows and columns.

• Invalid Cell Attributes

• Invalid paragraph/character/conditional/Bullet numbering styles.

• Invalid Box attributes.

• Invalid geometry.

• Invalid Text attributes.

• While applying invalid picture attributes.

Parameters

Renderer preferences Annotate errors in the Output Document and Append errors

into the Output Document can be specified under the Modifier pane of the QXPS

Renderer preferences:

• If Annotate errors in the Output Document preference is checked, the errors are

annotated as notes inline in the PDF output.

• If Append errors into the Output Document preference is checked, the errors are

appended at the end of the PDF output.

Annotation can also be done through the URL modify request params annotateerrors and appenderrors that can be set to true or false.

http://localhost:8080/pdf/template.qxp?modify=file:InvalidImage.xml?appenderrors=true

annotateerrors

The annotateerrors render modifier lets you include descriptions of rendering errors

as notes in the layout itself. In rendered QuarkXPress files, errors are displayed as notes.

In rendered PDFs, errors are displayed as comments. In XML output, errors are displayed

as notes XML markup.

annotateerrors

String

Includes descriptions of rendering errors as notes in the layout.

Compatible with

Example GET URL

pdf, qxpdoc, xml, postscript

See Understanding loggingLogs

http://localhost:8080/png/sample.qxp?box=annotateerrors

Descriptions of rendering errors are formatted with the default character style sheet.Notes

74 | A GUIDE TO QUARKXPRESS SERVER 10.1

USING QUARKXPRESS SERVER

appenderrors

The appenderrors render modifier lets you include descriptions of rendering errors

after the last page in the layout. Descriptions of rendering errors are formatted in

10-point magenta Arial.

Parameters

Compatible with

Example GET URL

box

Parameters

Compatible with

Alerts

appenderrors

pdf, qxpdoc, xml, postscript

See Understanding loggingLogs

http://localhost:8080/png/sample.qxp?box=appenderrors

Descriptions of rendering errors are formatted in 10-point magenta Arial.Notes

String

Includes descriptions of rendering errors after the last page in the layout.

The box render modifier lets you render a single box.

box

overlap

jpeg, png, raw

the specified identifier.

String

HTTP Error #500There is no box with

This alert displays if you request a box that does not exist.

Lets you specify which box to render.String

Lets you specify whether to show the area overlapped by the specified box.

Example GET URL

Notes

HTTP Error #500Cannot render box. The box must be within the page boundaries.

image type has no way of rendering the desired objects.

See Understanding loggingLogs

http://localhost:8080/png/sample.qxp?box=pictbox

To render a box in a particular layout, use a URL like the following:

http://localhost:8080/png/sample.qxp? layout=2&page=3&box=textbox

This alert displays if you request a box that is outside the page boundary.

HTTP Error #406The renderer for this

This alert displays if you try to use the box parameter with the eps, pdf,

or qxpdoc render types.

When you render using the box parameter, the box ID has a higher priority than

the box name.

boxes

The boxes render modifier lets you render multiple boxes.

Parameters

boxes

Lets you specify which boxes to render.String

A GUIDE TO QUARKXPRESS SERVER 10.1 | 75

USING QUARKXPRESS SERVER

Compatible with

Alerts

Example GET URL

Notes

overlap

jpeg, png, raw

the specified identifier.

The box must be within the page boundaries.

image type has no way of rendering the desired objects.

See Understanding loggingLogs

http://server:port/jpeg/doc.qxp?boxes=box1,box2

To render boxes in a particular layout, use a URL like the following:

http://localhost:8080/png/sample.qxp? layout=2&page=3&box=textbox

String

HTTP Error #500There is no box with

This alert displays if you request a box that does not exist.

HTTP Error #500Cannot render box.

This alert displays if you request a box that is outside the page boundary. .

HTTP Error #406The renderer for this This alert displays if you try to use the boxes parameter with the eps,

pdf, or qxpdoc render types.

Lets you specify whether to show the area overlapped by the specified boxes.

compositionzone

Parameters

Compatible with

Alerts

When you render using the box parameter, the box ID has a higher priority than

the box name.

The compositionzone parameter lets you return an XML representation of one or

more Composition Zones items.

compositionzone

compositionzones

xml

Param.

String

Error #10401Invalid box given in Box

This alert displays if you request a box that is not a Composition Zones item.

Lets you specify which Composition Zones item to return. For example:

http://localhost:8080/xml/sample.qxp? compositionzone=czbox

Lets you specify which Composition Zones items to return. For example:

http://localhost:8080/xml/sample.qxp? compoxitionzones=czbox1, czbox2

See Understanding loggingLogs

layer

The layer render modifier lets you show and hide layers prior to rendering. This

render modifier also lets you add and remove layers from a project on the server.

76 | A GUIDE TO QUARKXPRESS SERVER 10.1

USING QUARKXPRESS SERVER

Parameters

layer

addlayer

deletelayer

alllayers

layerattribute

name

visible

suppressoutput

String

Boolean (1 | 0 | true | false | yes | no)

String

Boolean (1 | 0 | true | false | yes | no)

Lets you specify which layer to render. You can specify multiple layer names in one request.

Lets you add a new layer. You can add one layer per request.

Lets you delete a layer and the items on that layer. You can delete one layer per request.

Lets you render every layer in the project, including hidden and suppressed layers.

Lets you modify the attributes of a layer. You can modify one layer per request.

Lets you specify a new name for a layer. You must use this parameter in conjunction with the

layerattribute parameter.

Lets you make a layer visible or invisible. You can use this parameter in conjunction with the

addlayer and layerattribute parameters. This

parameter overrides QuarkXPress layer visibility preferences.

Lets you suppress or allow the output of a layer. You can use this parameter in conjunction with the

addlayer and layerattribute parameters. This

parameter overrides QuarkXPress suppress output preferences.

Compatible with

Alerts

locked

keeprunaround

eps, jpeg, png, postscript, qcddoc, qxpdoc, raw, pdf, screenpdf, swf, xml

exist. Please verify the layer name.

name.

same name already exists.

name of the default layer.

Boolean (1 | 0 | true | false | yes | no)

HTTP Error #500This layer does not This alert displays if you specify an invalid layer name with the layer,

layerattribute, or deletelayer parameter.

HTTP Error #500Specify a layer This alert displays if you do not specify a layer name with the layer,

layerattribute, addlayer, or deletelayer parameter.

HTTP Error #500A layer with the

This alert displays if you try to add a layer that already exists or change the name of a layer to a name is already used in the project.

HTTP Error #500Cannot change the

This alert displays if you try to change the name of the default layer.

Lets you lock or unlock a layer. You can use this parameter in conjunction with the addlayer and

layerattribute parameters. This parameter

overrides QuarkXPress layer locking preferences.

Lets you set or change a layer's Keep Runaround setting. You can use this parameter in conjunction with the addlayer and layerattribute parameters. This parameter overrides QuarkXPress Keep Runaround preferences.

default layer.

HTTP Error #500Cannot delete the

This alert displays if you try to delete the default layer.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 77

USING QUARKXPRESS SERVER

value.

locked and cannot be modified.

See Understanding loggingLogs

HTTP Error #500Invalid parameter

This alert displays if you do not specify additional attributes or specify attributes with invalid values in an addlayer or layerattribute request.

HTTP Error #500This layer has been

This alert displays if you try to add or modify an item on a locked layer.

Example GET URL

Example, object model

To render a single layer, use a URL like the following:

http://localhost:8080/doc.qxp?layer=layer1

To add a layer, use a URL like the following:

http://localhost:8080/qxpdoc/doc.qxp?addlayer= NewLayer&visible=yes&suppressoutput=yes&locked=no

To delete a layer, use a URL like the following:

http://localhost:8080/qxpdoc/doc.qxp?deletelayer=Layer1

To render all layers in a project, use a URL like the following:

http://localhost:8080/qxpdoc/doc.qxp?alllayers=true

To set layer attributes, use a URL like the following:

http://localhost:8080/qxpdoc/doc.qxp?layerattribute= Layer1&name=Layer2&visible=true&keeprunaround=true

To add a new layer to a project, use code like the following:

Layer layer = new Layer(); layer.name = "New Layer"; layer.operation = "CREATE"; RGBColor rgbcolor = new RGBColor(); layer.RGBColor = rgbcolor; layout.layer = new Layer[]{layer};

To edit the properties of an existing layer, use the following object hierarchy:

ModifierRequest < Project < Layout < Layer

To delete a layer, set its operation attribute to "DELETE".

layout

Parameters

Compatible with

You cannot add, modify, or delete multiple layers in a single request.Notes You cannot print layers whose visible and suppressoutput properties are set to false. You can render a hidden or suppressed layer by referencing it with the layer parameter. Suppressed layers are rendered for the jpeg, png, and qxpdoc render types, but not for the

pdf, postscript, and eps render types.

You can use the deconstruct and getdocinfo request handlers to view information about the layers in a project.

When you add a layer using addlayer, any unspecified attributes use the settings in the QuarkXPress Server layer preferences (Administration > Preferences > Renderer > Layers).

If the visible property is set to false, the suppressoutput property is automatically set to true.

The layout render modifier lets you render a specific layout.

layout

eps, jpeg, png, postscript, raw, pdf, screenpdf

String

Lets you specify which layout to render. The first layout is layout 1.

78 | A GUIDE TO QUARKXPRESS SERVER 10.1

USING QUARKXPRESS SERVER

Alerts

Example GET URL

movepages

Parameters

Compatible with

HTTP Error #500The requested layout does not exist.

See Understanding loggingLogs

To render a layout by its layer ID, use a URL like the following:

http://localhost:8080/png/sample.qxp?layout=2

To render a layout by its name, use a URL like the following:

http://localhost:8080/png/sample.qxp?layout=Layout 2

This alert displays if you supply an invalid layout value.

The movepages render modifier lets you move pages prior to rendering.

movepages

afterpage

eps, jpeg, png, postscript, qcddoc, qxpdoc, raw, pdf, screenpdf, xml

String

Lets you specify which pages to move. You can use a single page number (for example, 2) or a range of pages with the starting and ending page numbers separated by a hyphen (for example, 2–5).

Lets you specify the page after which the page or pages should be moved. To move pages to the beginning of a layout, use afterpage=start. To move pages to the end of a layout, use afterpage=end.

Alerts

Example GET URL

Example, object model

QuarkXPress Server Error #61This page does not

exist.

QuarkXPress Server Error #62Invalid page range.

QuarkXPress Server Error #51The specified page range cannot be moved there.

QuarkXPress Server Error #146This page range is invalid.

QuarkXPress Server Error #10108Invalid parameter value.

See Understanding loggingLogs

To move pages 2–3 to after page 5, use a URL like the following:

http://localhost:8080/abc.qxp?movepages=2–3&afterpage=5

To move page 7 to the beginning of a layout, use a URL like the following:

http://localhost:8080/abc.qxp?movepages=7&afterpage= start

To move pages before rendering a layout, use code like the following:

// STEP 2(SPECIFIC TO REQUESTS):Create the PDF // renderer request and embed it in the request context. the request context. PDFRenderRequest pdfreq = new PDFRenderRequest();

A GUIDE TO QUARKXPRESS SERVER 10.1 | 79

USING QUARKXPRESS SERVER

pdfreq.setMovePages("2-4"); pdfreq.setAfterPage("7"); requestCtx.setRequest(pdfreq);

// STEP3: Create the service and call the // processRequest() API RequestService service = new RequestServiceStub(); com.quark.qxpsm.QContentData data = service.processRequest( requestCtx);

Notes

Parameters

Compatible with

Alerts

Example GET URL

The movepages operation executes only after all other modifications are complete. For example, if you use movepages in a modify request, the pages are moved only after the modify request is complete.

page

The page render modifier lets you render a single page.

page

eps, jpeg, png, postscript, qcddoc, raw, pdf, screenpdf

HTTP Error #500The requested page does

not exist.

image type has no way of rendering the desired objects.

See Understanding loggingLogs

http://localhost:8080/png/sample.qxp?page=2

This alert displays if you attempt to render a page that does not exist.

HTTP Error #406The renderer for this This alert displays if you use a page parameter with the qxpdoc render

type.

Lets you specify which page to render.Integer

Example, object model

Notes

pages

Parameters

Compatible with

Alerts

To add a new page to an existing spread in a project, use code like the following:

Spread spread = new Spread(); Page page = new Page(); page.UID = "5"; page.operation = "CREATE"; spread.page = new Page[]{page};

To edit the properties of an existing page, use the following object hierarchy:

ModifierRequest < Project < Layout < Spread < Page

To delete a page, set its operation attribute to "DELETE".

To render a page in a particular layout, use a URL like the following:

http://localhost:8080/png/sample.qxp?layout=2&page=3

The pages render modifier lets you render multiple pages. The pdf and postscript

namespaces support this parameter.

pages

eps, jpeg, png, postscript, raw, pdf, screenpdf

HTTP Error #500This page range is

invalid.

QuarkXPress Server Error #147

Lets you specify which pages to render.String (page range)

80 | A GUIDE TO QUARKXPRESS SERVER 10.1

this image type has no way of rendering the desired objects.

See Understanding loggingLogs

USING QUARKXPRESS SERVER

This alert displays if you try to render a page range that exceeds the number of pages in the project.

HTTP Error #406The renderer for This alert displays if you use the pages parameter with the jpeg, eps, png,

or qxpdoc render type.

Example, GET URL

Notes

scale

Parameters

Compatible with

Alerts

Example, GET URL

http://localhost:8080/pdf/sample.qxp?pages=2–4

To render pages in a particular layout, use a URL like the following:

http://localhost:8080/pdf/sample.qxp?layout=2&pages=2,3

The scale render modifier lets you specify the scale at which content is rendered.

scale

eps, jpeg, png, raw

parameter.

See Understanding loggingLogs

http://localhost:8080/png/sample.qxp?scale=2

Float

HTTP Error #500Invalid scale

This alert displays if an invalid scale value is provided.

What to do: Enter a valid scale value.

Lets you specify a scaling percentage. The valid values are from .1 (10%) to 8 (800%) on Mac OS or 6.92 (692%) on Windows.

spread

Parameters

Compatible with

Alerts

Example, GET URL

Example, Object Model

The spread render modifier lets you render a single spread.

spread

eps, jpeg, png, postscript, raw, pdf, screenpdf

spread does not exist.

See Understanding loggingLogs

http://localhost:8080/png/sample.qxp?spread=2

To add a spread to a project, use code like the following:

Spread spread = new Spread(); spread.UID = "5"; spread.operation = "CREATE"; layout.spread = new Spread[]{spread};

Integer

HTTP Error #500The requested

This alert displays if you specify an invalid spread.

Lets you specify which spread to render. Spread numbers start with 1. The first spread is spread 1. In a facing-page document, spread 1 consists of the first page.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 81

USING QUARKXPRESS SERVER

Spread is located at the following place in the object hierarchy:

ModifierRequest < Project < Layout < Spread

To delete a spread, set its operation attribute to "DELETE".

spreads

The spreads render modifier lets you render layouts in spreads mode, so that pages

in spreads are rendered side-by-side rather than as individual pages.

Parameters

Compatible with

Example, GET URL

suppresserrors

Parameters

Compatible with

Example GET URL

Using content modifiers

spreads

eps, jpeg, png, postscript, raw, pdf, screenpdf

See Understanding loggingLogs

http://localhost:8080/pdf/sample.qxp?spreads=true

Boolean (1 | 0 | true | false | yes | no)

Lets you specify whether to render spreads (true) or individual pages (false).

The suppresserrors render modifier forces QuarkXPress Server to render as much

of a layout as it can, despite any errors that occur.

suppresserrors

pdf, qxpdoc, xml, postscript

See "Understanding logging."Logs

http://localhost:8080/png/sample.qxp?box=suppresserrors

String

Forces the layout to render despite any errors that may occur.

Content modifiers let you alter the content and formatting of boxes in layouts without

using the XML modify parameter.

Inserting text

This topic explains how to import text into a box. Any existing text in the box is

replaced.

A preview of the project with the imported text.Response

HTTP Error #404File not found.Alerts

82 | A GUIDE TO QUARKXPRESS SERVER 10.1

The name of the target box.String[box name]Parameters

Specify the name and location of the imported file with the

file: prefix. The imported file must be available to

QuarkXPress Server.

To import a file that is in a subfolder of the document pool on Mac OS, use a path like the following:

file:subfolder:MyFile.ext

To import a file that is in a subfolder of the document pool on Windows, use a path like the following:

file:subfolder\MyFile.ext

USING QUARKXPRESS SERVER

QuarkXPress Server Error #–43

This alert displays if the imported file is not available to QuarkXPress Server.

Logs

Example, GET URL

Example, object model

If the request succeeds, a transaction success message is written to the QuarkXPress Server transaction log file. For example:

8/3/2005 11:27:42 — jpeg/sample.qxp — Type: image/jpeg — Size: 31715 — Client: 127.0.0.1

If an alert displays, an error message is written to the QuarkXPress Server error log file. For example:

8/10/2005 10:32:57 — Error — Error Code: –43 — File not found.

http://localhost:8080/sample.qxp?Author=NewText http://localhost:8080/sample.qxp?TopStory=file:TopStory.doc

Request object name: RequestParameters

com.quark.qxpsm.QRequestContext rc = new com.quark.qxpsm.QRequestContext();;

if(!this.DocumentSettings1.documentName.Text.Equals("")) rc.documentName = this.DocumentSettings1.documentName.Text;

// STEP 2 (SPECIFIC TO REQUESTS):Create the Box Param // renderer request and embed it in RequestParameters request = new RequestParameters(); NameValueParam nameValue1 = new NameValueParam(); nameValue1.paramName = this.boxname1.Text; if(!this.boxvalue1.Text.Equals("")) nameValue1.textValue = this.boxvalue1.Text;

request.params = new NameValueParam[]{nameValue1}; rc.request = request; // Create the service and // call it with QRequestContext object RequestService svc = new RequestService(); com.quark.qxpsm.QContentData qc = svc.processRequest(rc);

Parameters

Alerts

Logs

Box names are case-sensitive.Notes

Use "&" to change the contents of multiple boxes in one request. The general URL for the multiple-box request is:http://localhost:8080/sample.qxp?text1=

NewText1&text2=NewText2 where text1 and text2 are the names of the two different boxes.

You can use "&" to change the contents of multiple boxes in one request. For example:

http://localhost:8080/sample.qxp? Headline=headline.txt&Story=file:Story.doc

You can import an XTags file generated by QuarkXPress.

Applying a font at import

This topic explains how to apply a font to a new text flow. When you use this method,

QuarkXPress Server ignores the original font of the target text box and inserts the new

text with the font specified by the parameter.

fontname

A preview of the project with the font applied to the imported text.Response

This alert displays if you specify a font that is unavailable.The specified font is not

available.

If the request succeeds, a transaction success message is written to the QuarkXPress Server transaction log file. For example:

12/2/2005 16:24:13 — project2.qxp — Type: image/jpeg — Size: 11380 — Client: 127.0.0.1

The name of the font to be applied.String

A GUIDE TO QUARKXPRESS SERVER 10.1 | 83

USING QUARKXPRESS SERVER

If an error occurs, the error message is written to the QuarkXPress Server Error Log. The transaction entry in the error log contains the date and time of the request, the error code, and the error message. The following is a sample of an error transaction log entry:

12/2/2005 16:16:26 — Error — Error Code: –43 — File not found.

Example, GET URL

Example, object model

Inserting a picture

To apply Comic Sans MS to text in the box named "HeadBox," use a URL like the following:

http://localhost:8080/png/sample.qxp?HeadBox=Headline&fontname=Comic Sans MS

Request object name: RequestParameters

com.quark.qxpsm.QRequestContext rc = new com.quark.qxpsm.QRequestContext(); if(!this.DocumentSettings1.documentName.Text.Equals("")) rc.documentName = this.DocumentSettings1.documentName.Text;

// STEP 2(SPECIFIC TO REQUESTS):Create the fontname // renderer request and embed it in RequestParameters request = new RequestParameters(); NameValueParam nameValue1 = new NameValueParam(); nameValue1.paramName = this.boxname.Text; if(!this.boxvalue1.Text.Equals("")) nameValue1.textValue = this.fontname.Text; request.params = new NameValueParam[]{nameValue1}; rc.request = request;

// Create the service and // call it with QRequestContext object RequestService svc = new RequestService(); com.quark.qxpsm.QContentData qc = svc.processRequest(rc);

This topic explains how to import a picture into an empty box or replace an existing

picture with a new one.

Parameters

Logs

[box name[

A preview of the project with the imported picture.Response

HTTP Error #404File not found.Alerts

QuarkXPress Server Error #–43

This alert displays if the imported file is not available to QuarkXPress Server.

HTTP Error #500The specified file failed to load in the picture box.

If the request succeeds, a transaction success message is written to the QuarkXPress Server transaction log file. For example:

8/3/2005 11:27:42 — jpeg/sample.qxp — Type: image/jpeg — Size: 31715 — Client: 127.0.0.1

If an alert is displayed, an error message is written to the QuarkXPress Server error log. The following is a sample of the error log entry:

This alert displays if you attempt to import an invalid picture file.

The name of the target box.String Specify the name and location of the imported file with the file:

prefix. The imported file must be available to QuarkXPress Server.

To import a file that is in a subfolder of the document pool on Mac OS, use a path like the following:

file:subfolder:MyFile.ext

To import a file that is in a subfolder of the document pool on Windows, use a path like the following:

file:subfolder\MyFile.ext

84 | A GUIDE TO QUARKXPRESS SERVER 10.1

USING QUARKXPRESS SERVER

8/10/2005 10:39:07 — Error — Error Code: 10339 — The specified file failed to load in the picture box.

Example, GET URL

Example, object model

http://localhost:8080/sample.qxp? PictureBox=file:FrenchOpen.pdf

Request object name: RequestParameters

com.quark.qxpsm.QRequestContext rc = new com.quark.qxpsm.QRequestContext();

if(!this.DocumentSettings1.documentName.Text.Equals("")) rc.documentName = this.DocumentSettings1.documentName.Text; //STEP 2(SPECIFIC TO REQUESTS):Create the Box Param //renderer request and embed it in RequestParameters request = new RequestParameters(); NameValueParam nameValue1 = new NameValueParam(); nameValue1.paramName = this.boxname1.Text; if(!this.boxvalue1.Text.Equals("")) nameValue1.textValue = this.boxvalue1.Text;

request.params = new NameValueParam[]{nameValue1}; rc.request = request; //Create the service and call it with QRequestContext object RequestService svc = new RequestService(); com.quark.qxpsm.QContentData qc = svc.processRequest(rc);

Box names are case-sensitive.Notes

You can use "&" to change the contents of multiple boxes in one request. For example:

http://localhost:8080/sample.qxp? Logo=file:logo.jpeg&TopPicture=file:TopPicture.eps

Parameters

Saving a projects with a new name

The saveas content modifier lets you save modified QuarkXPress projects in any

supported format to the document pool or to any network location accessible to

QuarkXPress Server.

If you send a saveas request to QuarkXPress Server Manager using HTTP or the Web

services interface while the common doc pool switch is set to off in the

QuarkXPress Server Manager client, the file is saved to all registered QuarkXPress Server

instances. If the common doc pool is enabled, the file can be saved to any one registered

QuarkXPress server instance.

newname

path

savetopool

replace

String

true | false

Lets you specify a name for the saved-as project.String

Lets you specify a location for the saved-as project (other than the document pool).

Lets you specify whether the project should be saved to the document pool.

The default value for this paramter is true. However, if you specify a path value, the default value changes to false, which means if you want the project saved to the document pool, you must explicitly set savetopool to true.

Lets you specify whether the saved project should replace a project with the same name. The default value is true.

The message "Document successfully saved."Response

HTTP Error #404File not found.Alerts

QuarkXPress Server Error #–43

A GUIDE TO QUARKXPRESS SERVER 10.1 | 85

USING QUARKXPRESS SERVER

pathname.

invalid.

folder is Read-Only.

This alert displays if you supply an incorrect file name or the file is not available to QuarkXPress Server.

HTTP Error #404Bad filename/

QuarkXPress Server Error #–43

This alert displays if you supply an incorrect file name or the file is not available to QuarkXPress Server.

HTTP Error #500The file path is This alert displays if you supply an invalid path parameter.

What to do: Specify the correct file path with the path parameter.

HTTP Error #500The specified

This alert displays if you try to save a project to a folder with read-only access.

Logs

Example, GET URL

Example, object model

If the request succeeds, a transaction success message is written to the QuarkXPress Server transaction log file. For example:

11/16/2005 15:41:42 — saveas/5mb.qxp — Type: — Size: 28 — Client: 127.0.0.1

If an alert displays, an error message is written to the QuarkXPress Server error log file. For example:

11/16/2005 15:42:12 — Error — Error Code: 10371 — The file path is invalid.

To save a PDF file named "Customer1.pdf" in the folder HDD:temp and also in the document pool, use a URL like the following. Note that this URL will cause the saved-as file to replace any existing file with the same name.

http://localhost:8080/saveas/pdf/sample.qxp? newname=Customer1&path=HDD:temp&savetopool=true

Request object name: SaveAsRequest

com.quark.qxpsm.QRequestContext rc = new com.quark.qxpsm.QRequestContext();

if(!this.DocumentSettings1.documentName.Text.Equals("")) rc.documentName = this.DocumentSettings1.documentName.Text;

// STEP 2 (SPECIFIC TO REQUESTS): // Create the Save as request and chain it to the document context SaveAsRequest saveasreq = new SaveAsRequest(); saveasreq.newName = this.newname.Text; if((this.path.Text != null) && (!this.path.Text.Equals(""))) saveasreq.newFilePath = this.path.Text; saveasreq.replaceFile = this.replace.Checked.ToString(); saveasreq.saveToPool = this.savetopool.Checked.ToString(); rc.request = saveasreq;

// Create the service and call it with QRequestContext object RequestService svc = new RequestService(); com.quark.qxpsm.QContentData qc = svc.processRequest(rc);

Importing XML with placeholders

This topic explains how to import XML data into boxes using QuarkXPress placeholders.

To use this feature, you must have a QuarkXPress project that has been set up with

placeholders that correspond to the element types in a source XML file. For more

information, see A Guide to XML Import.

86 | A GUIDE TO QUARKXPRESS SERVER 10.1

USING QUARKXPRESS SERVER

Parameters

Alerts

Logs

thexmldoc

layout

paginate

The layout with the imported XML.Response

String

If the project is successfully rendered, a transaction success message is written to the QuarkXPress Server transaction log file. The transaction entry consists of the date and time of the request, the render type, the project name, the type of response produced by the server, the size of the response returned in bytes, and the client IP address. The following is a sample of a transaction entry:

8/5/2005 18:11:54 — sample.qxp — Type: image/jpeg — Size: 65982 — Client: 127.0.0.1

If an alert displays, an error message is written to the QuarkXPress Server error log file. For example:

8/9/2005 12:38:42 — Error — Error Code: 10396 — Invalid XML String.

XML

String

XML

HTTP Error #500Invalid XML This alert displays if you supply an invalid XML string in the thexmldoc

parameter.

Lets you specify the XML file containing the data to import. The path can be absolute or relative to the location of the XML file. You can also supply XML as a string.

Lets you specify which layout to render. The first layout is layout

1. You can also specify a layout by name.

Lets you specify the XML file containing the data to import. The

paginate parameter reates enough pages in the target layout to

accommodate the records in the XML. This parameter works only with the pdf, postscript, and qxp

render types. If you use it with any other render type, the server returns only the first page of the paginated layout.

If you do not supply an XML string or file (for example:

http://localhost:8080/pdf/Sample.qxp?paginate),

QuarkXPress Server attempts to use the XML file that was associated with the layout in QuarkXPress.

Example, GET URL

Example, object model

When QuarkXPress Server is running on Windows, use a URL like the following:

http://localhost:8080/Sample.qxp?thexmldoc=<?xml version="1.0"?> <BookReview><Book><Title>C:\Autumn.jpg</Title> <Author> Brian Kernighan and Dennis Ritchie</Author> </Book></BookReview>

When QuarkXPress Server is running on Mac OS, use a URL like the following:

http://localhost:8080/Sample.qxp?thexmldoc=<?xml version= "1.0"?> <BookReview><Book><Title>/Volumes/MacHD/Pictures/abc.tiff</ Title> <Author> Brian Kernighan and Dennis Ritchie</Author> </Book></BookReview>

Alternatively, you can specify a path to a file containing the XML:

http://localhost:8080/Sample.qxp?paginate= file:MacHD:Sample.xml

Request object names: XMLImportRequest

com.quark.qxpsm.QRequestContext rc = new com.quark.qxpsm.QRequestContext();

A GUIDE TO QUARKXPRESS SERVER 10.1 | 87

USING QUARKXPRESS SERVER

rc.request = xmlimportreq;

// STEP 3(SPECIFIC TO REQUESTS): Create the JPEG renderer request JPEGRenderRequest jpreq = new JPEGRenderRequest(); xmlimportreq.request = jpreq;

// Create the service and call it with QRequestContext object RequestService svc = new RequestService(); com.quark.qxpsm.QContentData qc = svc.processRequest(rc);

Updating article geometry and content

This topic explains how to update the geometry and contents of a QuarkCopyDesk

article using another article file or an article in a QuarkXPress project.

Parameter

Alerts

Logs

Example, GET URL

updategeometry

updatecontent

WHAT DOES THIS RETURN?Response

WHAT ERRORS APPLY?

8/5/2005 18:11:54 — sample.qxp — Type: image/jpeg — Size: 65982 — Client: 127.0.0.1

If an alert displays, an error message is written to the QuarkXPress Server error log file. For example:

8/9/2005 12:38:42 — Error — Error Code: 10396 — Invalid XML String.

To update the geometry of an article using the geometry of another article, use a URL like the following:

http://localhost:8080/updategeometry/destination.qcd?updatefromfile=source.qcd

To update the geometry of an article in a QuarkXPress file using the geometry of a QuarkCopyDesk article file, use a URL like the following:

http://localhost:8080/updatecontent/destination.qxp?updatefromfile=source.qcd&articleid=1

To update the geometry of a QuarkCopyDesk article file using the geometry of an article in a QuarkXPress project, use a URL like the following:

http://localhost:8080/updategeometry/source.qxp?updatetofile=destination.qcd&articleid=1

String

If you use this parameter with updatefromfile, this lets you specify the file in which you want to update the geometry. If you use this parameter with updatetofile, this lets you specify the QuarkXPress project with which you want to update the geometry of an article.

Lets you specify the file in which you want to update the content. Can be used only with updatefromfile.

CAN YOU DO THIS WITH QXPSM? IF SO, HOW?Example, object

model

Request object names: XMLImportRequest

com.quark.qxpsm.QRequestContext rc = new com.quark.qxpsm.QRequestContext();

88 | A GUIDE TO QUARKXPRESS SERVER 10.1

rc.request = xmlimportreq;

// STEP 3(SPECIFIC TO REQUESTS): Create the JPEG renderer request JPEGRenderRequest jpreq = new JPEGRenderRequest(); xmlimportreq.request = jpreq;

// Create the service and call it with QRequestContext object RequestService svc = new RequestService(); com.quark.qxpsm.QContentData qc = svc.processRequest(rc);

Highlighting text in rendered output

To apply highlighting to text in rendered output, use XML like the following.

<RICHTEXT BACKGROUNDCOLOR="Yellow">This text is highlighted.</RICHTEXT>

Highlighting is applied only to rendered output. It is not retained in the QuarkXPress

project.

Using XML modify

The modify parameter lets you modify a QuarkXPress project using XML.

USING QUARKXPRESS SERVER

Parameters

Example GET URL

This topic covers the modify parameter when it is used without the construct namespace. You can also use the modify parameter to specify an XML file to use when

constructing a project; for more information, see "Constructing a project".

The xml namespace takes two arguments: the name of the project to be modified, and a modify parameter with the string or the path of the XML file that describes how to

create the project:

http://QXPServer8:8080/project1.qxp?modify= file:path to XML file on server http://QXPServer8:8080/ project1.qxp?modify=XML string

You can also modify QuarkCopyDesk articles. To modify a QuarkCopyDesk article:

http://localhost:8080/copydesk/abc.qcd?modify= file:XMLfile.xml

Modifier DTDDTD

modify

http://QXPServer8:8080/project1.qxp?modify=file:sample.xml

String

Lets you specify an XML file or string that describes how to create a project. The path can be absolute or a relative path in the document pool. Use the file: indicator to specify the path.

Note that you can also include an XML file as part of a multipart HTTP request.

Example XML

This XML deletes page 2 of a QuarkXPress layout:

A GUIDE TO QUARKXPRESS SERVER 10.1 | 89

USING QUARKXPRESS SERVER

The updated QuarkXPress project.Response

Logs

If the request succeeds, a transaction success message is written to the QuarkXPress Server transaction log file. For example:

8/3/2005 11:27:42 — jpeg/sample.qxp — Type: image/jpeg — Size: 31715 — Client: 127.0.0.1

If an alert is displayed, an error message is written to the QuarkXPress Server error log. The following is a sample of the error log entry:

8/10/2005 10:39:07 — Error — Error Code: 10339 — The specified file failed to load in the picture box.

Modifying box properties and content

To modify box properties and content, use the following parameters in the Modifier

DTD:

• "BOX (Modifier schema)"

• "ID (Modifier schema)"

• "TEXT (Modifier schema)"

• "PICTURE (Modifier schema)"

• "GEOMETRY (Modifier schema)"

• "CONTENT (Modifier schema)"

• "SHADOW (Modifier schema)"

• "FRAME (Modifier schema)"

• "PLACEHOLDER (Modifier schema)"

• "METADATA (Modifier schema)"

The following XML shows how some of these parameters work.

<?xml version="1.0" encoding="UTF-8"?> <PROJECT> <LAYOUT> <ID NAME="Layout 1"/> <SPREAD> <ID UID="1"/> <BOX BOXTYPE="CT_TEXT"> <ID NAME="SERVICES"/> <GEOMETRY> <MOVEUP>50</MOVEUP> <MOVELEFT>30</MOVELEFT> <ALLOWBOXONTOPASTEBOARD>true</ALLOWBOXONTOPASTEBOARD> </GEOMETRY> <CONTENT CONVERTQUOTES="true"> HD:QuarkXPress:DocPool:Services.txt</CONTENT> </BOX> <BOX BOXTYPE="CT_TEXT"> <ID NAME="FAMILY"/> <GEOMETRY> <MOVERIGHT>20</MOVERIGHT> <MOVEDOWN>30</MOVEDOWN> <ALLOWBOXONTOPASTEBOARD>true</ALLOWBOXONTOPASTEBOARD> <ALLOWBOXOFFPAGE>true</ALLOWBOXOFFPAGE> </GEOMETRY> </BOX> <BOX BOXTYPE="CT_TEXT"> <ID NAME="PRODUCTS"/> <GEOMETRY> <GROWACROSS>44</GROWACROSS> <GROWDOWN>30</GROWDOWN> <ALLOWBOXONTOPASTEBOARD>false</ALLOWBOXONTOPASTEBOARD> </GEOMETRY> </BOX> <BOX BOXTYPE="CT_PICT"> <ID NAME="MAP"/>

90 | A GUIDE TO QUARKXPRESS SERVER 10.1

USING QUARKXPRESS SERVER

<GEOMETRY> <SHRINKACROSS>30</SHRINKACROSS> <SHRINKDOWN>30</SHRINKDOWN> </GEOMETRY> </BOX> <BOX COLOR="Blue" BOXTYPE="CT_PICT"> <ID NAME="CONTACT"/> <GEOMETRY> <STACKINGORDER>BRINGTOFRONT</STACKINGORDER> <RUNAROUND TYPE="ITEM" TOP="4" RIGHT="4" LEFT="4" BOTTOM="4"/> <ALLOWBOXOFFPAGE>false</ALLOWBOXOFFPAGE> </GEOMETRY> </BOX> </SPREAD> </LAYOUT> </PROJECT>

If you know the UID attribute of a <CONTENT> element, you can insert content into that <CONTENT> element without having to specify where it is. For example:

<PROJECT> <CONTENT UID="0">NewPicture.jpg</CONTENT> </PROJECT>

You an also use a <CONTENT> element to insert additional text between two

<RICHTEXT> elements, like so:

<PROJECT> <STORY> <ID UID="0"/> <PARAGRAPH PARASTYLE="Normal"> <RICHTEXT>Text before external file</RICHTEXT> <CONTENT>file:NewText.doc<CONTENT> <RICHTEXT>Text after external file</RICHTEXT> </PARAGRAPH> </STORY> </PROJECT>

Logs

A preview of the QuarkXPress project with a new box created in the specified position.Response

File not found.Alerts

filename/pathname.

document is not valid or well formed.

document contains an invalid tag value.

If the request succeeds, a transaction success message is written to the QuarkXPress Server transaction log file. For example:

8/3/2005 11:27:42 — jpeg/sample.qxp — Type: image/jpeg — Size: 31715 — Client: 127.0.0.1

If an alert displays, an error message is written to the QuarkXPress Server error log file. For example:

HTTP Error #404

QuarkXPress Server Error #–43

This alert displays if you specify an invalid XML file or request a document that is not available to QuarkXPress Server.

HTTP Error #404Bad

QuarkXPress Server Error #–37

This alert displays if you specify an invalid file name or path.

HTTP Error #500The XML

This alert displays if the XML you supply is not well-formed or does not adhere to the Modifier DTD.

HTTP Error #500The XML

This alert displays if you supply an invalid value in the XML.

Example GET URL

When QuarkXPress Server is running on Windows, use a URL like the following:

http://localhost:8080/sample.qxp?modify= file:C:\updateBox.xml

A GUIDE TO QUARKXPRESS SERVER 10.1 | 91

USING QUARKXPRESS SERVER

When QuarkXPress Server is running on Mac OS, use a URL like the following:

http://localhost:8080/sample.qxp?modify= file:MacHD:xml:updateBox.xml

You can also supply a string that consists of valid XML commands. For example:

http://localhost:8080/sample.qxp?modify= <PROJECT><LAYOUT><ID UID="Layout1"/><SPREAD><ID UID="1"/> <BOX BOXTYPE="CT_PICT" COLOR="Blue" SHADE="50" OPACITY="50"> <ID NAME="MOUNTAINS"/><CONTENT> file:Services.eps</CONTENT> </BOX></SPREAD></LAYOUT></PROJECT>

Example 1, object model

Request object names:

ModifierRequest ModifierRequestContents Layout ID Box Geometry Runaround ModifierFileRequest

For ModifierFileRequest, the member contents are used to set the file path or

send the XML itself.

com.quark.qxpsm.QRequestContext rc = new com.quark.qxpsm.QRequestContext();

if(!this.DocumentSettings1.documentName.Text.Equals("")) rc.documentName = this.DocumentSettings1.documentName.Text;

//STEP 2(SPECIFIC TO REQUESTS): //Create the BOX modifier renderer request and //embed it in request context ModifierRequest request = new ModifierRequest(); Project contents = new Project(); Geometry geo = new Geometry(); geo.moveUp = this.moveup.Text; geo.color = this.color.Text; geo.growDown = this.growdown.Text; geo.shrinkAcross = this.shrinkacross.Text; Box box = new Box(); box.UID = this.Boxid.Text; box.geometry = geo; Layout layout1 = new Layout(); layout1.name = this.layout.Text; layout1.boxes = new Box[]{box}; if(this.runaround.Checked == true) { Runaround runaround = new Runaround(); runaround.type = this.runaroundtype.Text; runaround.top = this.top.Text; runaround.left = this.left.Text; runaround.right = this.right.Text; geo.runaround = runaround; } contents.layouts = new Layout[]{layout1}; request.project = contents; rc.request = request;

//Create the service and call it with QRequestContext object RequestService svc = new RequestService(); com.quark.qxpsm.QContentData qc = svc.processRequest(rc);

Example 2, object model

To edit the geometrical properties of an existing box in a QuarkXPress project, use the following object hierarchy:

ModifierRequest < Project < Layout < Spread < Box < Geometry

92 | A GUIDE TO QUARKXPRESS SERVER 10.1

The Geometry object has the following properties:

allowBoxOffPage allowBoxOnToPasteBoard angle growAcross growDown layer linestyle (of type 'Linestyle') moveDown moveLeft moveRight moveUp page position (of type 'Position') runaround (of type 'Runaround') shape shrinkAcross shrinkDown stackingOrder suppressOutput

The Runaround object has the following properties:

bottom edited invert left noise outset outsideOnly pathName restrictToBox right smoothness threshold top type

USING QUARKXPRESS SERVER

Creating boxes

To create a new box, use the following parameters in the Modifier DTD:

• "BOX (Modifier schema)"

• "ID (Modifier schema)"

• "TEXT (Modifier schema)"

• "PICTURE (Modifier schema)"

• "GEOMETRY (Modifier schema)"

• "CONTENT (Modifier schema)"

• "SHADOW (Modifier schema)"

• "FRAME (Modifier schema)"

The following XML shows how some of these parameters work.

A GUIDE TO QUARKXPRESS SERVER 10.1 | 93

USING QUARKXPRESS SERVER

A preview of the QuarkXPress project with new box created in specified position.Response

Logs

File not found.Alerts

pathname.

is not valid or well formed.

contains an invalid tag value.

If the request succeeds, a transaction success message is written to the QuarkXPress Server transaction log file. For example:

The following is a sample of a transaction entry: 8/3/2005 11:27:42 — jpeg/sample.qxp — Type: image/jpeg — Size: 31715 — Client: 127.0.0.1

If an alert displays, an error message is written to the QuarkXPress Server error log file. For example:

4/12/2007 14:51:50 — Error — Error Code: 10207 — The XML document is not valid or well formed. Project: /table.qxp

HTTP Error #404

QuarkXPress Server Error #–43

This alert displays if you specify an invalid XML file or request a document that is not available to QuarkXPress Server.

HTTP Error #404Bad filename/

QuarkXPress Server Error #–37

This alert displays if you specify an invalid file name or path.

HTTP Error #500The XML document

This alert displays if the XML you supply is not well-formed or does not adhere to the Modifier DTD.

HTTP Error #500The XML document

This alert displays if you supply an invalid value in the XML.

Example, GET URL

Example, object model

When QuarkXPress Server is running on Windows, use a URL like the following:

http://localhost:8080/sample.qxp?modify= file:C:\createBox.xml

When QuarkXPress Server is running on Mac OS, use a URL like the following:

http://localhost:8080/sample.qxp?modify= file:MacHD:xml:createBox.xml

You can also supply a string that consists of valid XML commands. For example:

http://localhost:8080/sample.qxp?modify=<PROJECT><LAYOUT> <ID UID="layout 1"/><SPREAD><ID UID="1"/><ID/> <BOX OPERATION="CREATE" BOXTYPE="CT_PICT"><ID NAME="PRODUCTS"/> <GEOMETRY PAGE="2" SHAPE="SH_RECT"><POSITION><TOP>5</TOP> <LEFT>5</LEFT><BOTTOM>10</BOTTOM><RIGHT>10</RIGHT></POSITION> </GEOMETRY></BOX></SPREAD></LAYOUT></PROJECT>

To create a new box, use code like the following:

Spread spread = new Spread(); Box box = new Box(); box.name = "textbox1"; Geometry geometry = new Geometry(); Position position = new Position();

position.top = "110"; position.left = "89"; position.bottom = "220"; position.right = "300";

94 | A GUIDE TO QUARKXPRESS SERVER 10.1

geometry.position = position; geometry.shape = "SH_RECT"; geometry.page = "1"; geometry.layer = "Default";

box.geometry = geometry; box.boxType = "CT_TEXT";

box.operation = "CREATE"; spread.box = new Box[]{box};

Use the following object hierarchy:

ModifierRequest < Project < Layout < Spread < Box < Geometry

Deleting boxes

To delete a box, use the following parameters in the Modifier DTD:

• "BOX (Modifier schema)"

• "ID (Modifier schema)"

The following XML shows how these parameters work.

USING QUARKXPRESS SERVER

A preview of the QuarkXPress project with the box deleted.Response

File not found.Alerts

pathname.

document is not valid or well formed.

document contains an invalid tag value.

HTTP Error #404

QuarkXPress Server Error #–43

This alert displays if you specify an invalid XML file or request a document that is not available to QuarkXPress Server.

HTTP Error #404Bad filename/

QuarkXPress Server Error #–37

This alert displays if you specify an invalid file name or path.

HTTP Error #500The XML

This alert displays if the XML you supply is not well-formed or does not adhere to the Modifier DTD.

HTTP Error #500The XML

This alert displays if you supply an invalid value in the XML.

Logs

If the request succeeds, a transaction success message is written to the QuarkXPress Server transaction log file. For example:

8/3/2005 11:27:42 — jpeg/sample.qxp — Type: image/jpeg — Size: 31715 — Client: 127.0.0.1

If an alert displays, an error message is written to the QuarkXPress Server error log file. For example:

A GUIDE TO QUARKXPRESS SERVER 10.1 | 95

USING QUARKXPRESS SERVER

Example GET URL

Notes

When QuarkXPress Server is running on Windows, use a URL like the following:

http://localhost:8080/sample.qxp?modify= file:C:\deleteBox.xml

When QuarkXPress Server is running on Mac OS, use a URL like the following:

http://localhost:8080/sample.qxp?modify= file:MacHD:xml:deleteBox.xml

You can also supply a string that consists of valid XML commands. For example:

http://localhost:8080/sample.qxp?modify= <PROJECT><LAYOUT><ID UID="Layout1"/><SPREAD> <ID UID="1"/><BOX OPERATION="DELETE"> <ID NAME="HISTORY"/></BOX></SPREAD> </LAYOUT></PROJECT>

You can use the xml namespace or Telegraph XTensions software to determine the ID or name of the box you want to delete.

Grouping and ungrouping items

To group boxes using XML modify, use XML like the following:

To add a box to an existing group, use XML like the following:

To remove a box from an existing group, use XML like the following:

To ungroup an existing group, use XML like the following:

To proportionally scale all of the items in a group, add a <GEOMETRY> element that

indicates the new size of the group, like so:

</GROUP>

96 | A GUIDE TO QUARKXPRESS SERVER 10.1

USING QUARKXPRESS SERVER

The order of the <BOXREF> elements in a <GROUP> indicates the order in which the

boxes were selected prior to grouping. The z-order of boxes in the layout is determined by the order of the <BOX> elements in the XML, from rearmost to frontmost.

XML representations of groups created by versions of QuarkXPress Server prior to 8.1

are ignored during construct and modify calls, as they were in earlier versions of

QuarkXPress Server.

Modifying text attributes

You can use the modify parameter to change the attributes of text in a QuarkXPress

project. All modifications are done on a text box basis. To modify text properties, use

the following parameters in the Modifier DTD:

• "BOX (Modifier schema)"

• "ID (Modifier schema)"

• "TEXT (Modifier schema)"

• "STORY (Modifier schema)"

• "PARAGRAPH (Modifier schema)"

• "FORMAT (Modifier schema)"

• "DROPCAP (Modifier schema)"

• "TABSPEC (Modifier schema)"

• "TAB (Modifier schema)"

• "RULE (Modifier schema)"

• "RICHTEXT (Modifier schema)"

The following XML shows how some of these parameters work.

<PROJECT> <LAYOUT> <ID UID="Layout 1"/> <SPREAD> <ID UID="1"/> <BOX BOXTYPE="CT_TEXT"> <ID NAME="ABOUT"/> <TEXT> <STORY CLEAROLDTEXT="true" FITTEXTTOBOX="true" CONVERTQUOTES="true"> <RICHTEXT FONT="Castellar" PLAIN="true"/> </STORY> </TEXT> </BOX> <BOX BOXTYPE="CT_TEXT"> <ID NAME="HISTORY"/> <TEXT> <STORY> <PARAGRAPH> <FORMAT ALIGNMENT="RIGHT"/> <RICHTEXT SIZE="12">This text is 12pt and right justified.</RICHTEXT> </PARAGRAPH> </STORY> </TEXT> </BOX> <BOX BOXTYPE="CT_TEXT"> <ID NAME="PRODUCTS"/> <TEXT> <STORY> <RICHTEXT BOLD="true">This is bold text.</RICHTEXT> <RICHTEXT BOLD="true" COLOR="Red" ITALIC="true"

A GUIDE TO QUARKXPRESS SERVER 10.1 | 97

USING QUARKXPRESS SERVER

SIZE="20">This text is bold, red, italic, and 20pt. </RICHTEXT> </STORY> </TEXT> </BOX> </SPREAD> </LAYOUT> </PROJECT>

Response

A preview of a QuarkXPress project with the values in the ModifierXT tags applied on text boxes.

File not found.Alerts

pathname.

document is not valid or well formed.

with the specified identifier.

value is outside the valid range.

HTTP Error #404

QuarkXPress Server Error #–43

This alert displays if you specify an invalid XML file or request a document that is not available to QuarkXPress Server.

HTTP Error #404Bad filename/

QuarkXPress Server Error #–37

This alert displays if you specify an invalid file name or path.

HTTP Error #500The XML

This alert displays if the XML you supply is not well-formed or does not adhere to the Modifier DTD.

HTTP Error #500There is no box This alert displays if the box specified by the child text node of an <ID>

element does not exist.

HTTP Error #500The text size This alert displays if the value specified in a <SIZE> element is invalid.

What to do: Specify a value between 2 and 720 points.

Logs

HTTP Error #500The specified color is not available to the document

font is not available

document contains an invalid tag value.

box cannot be modified.

If the request succeeds, a transaction success message is written to the QuarkXPress Server transaction log file. For example:

8/3/2005 11:27:42 — jpeg/sample.qxp — Type: image/jpeg — Size: 31715 — Client: 127.0.0.1

If an alert displays, an error message is written to the QuarkXPress Server error log file. For example:

8/5/2005 13:32:10 — Error — Error Code: 10006 — There is no box with the specified identifier.

This alert displays if the value specified in a <COLOR> element is invalid.

HTTP Error #500The specified

This alert displays if the value specified in a <FONT> element is invalid or the

specified font is not present on the server.

HTTP Error #500The XML

This alert displays if you supply an invalid value in the XML.

HTTP Error #500The specified

This alert displays if you try to modify text properties on a box that is not a

text box.

98 | A GUIDE TO QUARKXPRESS SERVER 10.1

USING QUARKXPRESS SERVER

Example GET URL

Example 1, object model

When QuarkXPress Server is running on Windows, use a URL like the following:

http://localhost:8080/sample.qxp?modify= file:C:\modifier.xml

When QuarkXPress Server is running on Mac OS, use a URL like the following:

http://localhost:8080/sample.qxp?modify= file:MacHD:xml:modifier.xml

You can also supply a string that consists of valid XML commands. For example:

http://localhost:8080/sample.qxp?modify= <PROJECT><LAYOUT><ID UID="1"/><SPREAD><ID UID="1"/> <BOX BOXTYPE="CT_TEXT"><ID NAME="BACKGROUND"/> <TEXT><STORY><RICHTEXT FONT="Castella" PLAIN="true"> This is text.</RICHTEXT></STORY></TEXT></BOX> </SPREAD></LAYOUT></PROJECT>

Request object names:

ModifierRequest ModifierStreamRequest Project RichText Text ID Box Layout ModifierFileRequest

For ModifierFileRequest, the member contents are used to set the file path or

send the XML itself.

com.quark.qxpsm.QRequestContext rc = new com.quark.qxpsm.QRequestContext();

if(!this.DocumentSettings1.documentName.Text.Equals("")) rc.documentName = this.DocumentSettings1.documentName.Text;

// STEP 2 (SPECIFIC TO REQUESTS):Create the Text Modifier // renderer request and embed it in request context ModifierRequest textReq = new ModifierRequest(); Project contents = new Project(); RichText richText1 = new RichText(); richText1.value = this.text1.Text; richText1.color = this.color1.Text; Text boxText1 = new Text(); Story story = new Story(); story.richText = new RichText[]{richText1}; boxText1.story = story; if(this.fittextbox1.Checked) boxText1.fitTextToBox = "true"; if(this.clearoldtext1.Checked) boxText1.clearOldText = "true"; Box box1 = new Box(); box1.UID = txtBox1; box1.text = boxText1; Layout layout1 = new Layout(); layout1.name = layoutText; layout1.boxes = new Box[]{box1}; contents.layouts = new Layout[]{layout1}; textReq.contents = contents; rc.request = textReq;

// Create the service and call it with QRequestContext object RequestService svc = new RequestService(); com.quark.qxpsm.QContentData qc = svc.processRequest(rc);

A GUIDE TO QUARKXPRESS SERVER 10.1 | 99

USING QUARKXPRESS SERVER

Example 2, object model

Notes

To edit the properties of an existing text box in a QuarkXPress project, use the following object hierarchy:

ModifierRequest < Project < Layout < Spread < Box < Text < Story < Paragraph < RichText

For a list of the RichText object's properties, see the JavaDoc installed with QuarkXPress Manager.

The Story object also contains some text-related properties: fitTextToBox,

includeStylesheets, convertQuotes, and clearOldText.

The <FITTEXTTOBOX> attribute depends on two preferences: Allow Text to Grow and Font Size. To set these preferences in QuarkXPress Server, choose QuarkXPress > Server > Preferences and then click Modifier in the list on the left.

Modifying picture properties

You can modify the properties (such as origin, scale, angle, skew, and orientation) of

pictures in a QuarkXPress project with XML. To modify picture properties, use the

following parameters in the Modifier DTD:

• "BOX (Modifier schema)"

• "ID (Modifier schema)"

• "PICTURE (Modifier schema)"

The following XML shows how some of these parameters work.

A preview of the QuarkXPress project with image modifier tags applied to the picture boxes.Response

File not found.Alerts

HTTP Error #404

QuarkXPress Server Error #–43

This alert displays if you specify an invalid XML file or request a document that is not available to QuarkXPress Server.

100 | A GUIDE TO QUARKXPRESS SERVER 10.1
