This manual provides instructions on installing your new TapeStor Travan 20GB tape drive. Two sets
of drive installation instructions are provided: one for ATAPI drives and another for SCSI drives.
This manual also describes how to operate your tape drive and how to care for the tape drive and
cartridges.
NOTE: Wherever a page number is referenced in this online manual, you can click on the page
number to jump to that page. You can return to the original page by clicking the back button
in your viewer software.
About your Travan tape drive
The TapeStor Travan 20GB features a capacity of 20 Gbytes and a data transfer rate of up to
120 Mbytes per minute.
NOTE: These values are based on 2:1 data compression. Uncompressed values are one half as
high. Capacities, backup speeds and transfer rates will vary with file type and system
configuration.
This drive includes Certance FastSense(TM) technology for optimizing drive and host data transfer
rates.
For a list of supported tape formats, see page 16.
NOTE: The TapeStor Travan 20GB cannot use TR-1, TR-2, TR-3 or QIC-80 tapes.
1
IntroductionItems you many need for the installation
Items you many need for the installation
•You will need standard (flat-blade) and Phillips screwdrivers to install the tape drive in your
computer.
NOTE: Before you install the drive, write down its model number (CTXXX) and serial number in
a safe place. You will need these numbers if you ever have to call for service. The numbers are
listed on the underside of the drive.
ATAPI drives
•If your computer has only a single IDE port, it will probably be attached to your hard disc. In
this case, you will need to obtain and install an ATAPI host adapter to provide a secondary
IDE port for the tape drive.
•If you have two IDE ports but do not have any devices attached to the secondary port, you will
need a 40-pin IDE interface cable for your tape drive.
SCSI drives
•You must have a SCSI host adapter to use the TapeStor Travan SCSI drives.
•You will need a 50-pin SCSI cable with enough connectors for all your SCSI devices.
Important precautions
To protect your computer and drive from electrostatic damage, follow these guidelines:
•Before you open your computer or remove the drive from its antistatic bag, ground yourself by
touching the metal chassis of your computer or some other grounded object. For optimal protection, use an electrostatic grounding strap.
NOTE: To be properly grounded, your computer must be plugged into a grounded electrical
outlet.
•Do not touch any printed circuit boards or electronic chips on your drive or in your computer.
NOTE: We recommend that you install your backup software before you install your tape drive.
For more information, see the instructions that came with the backup software.
2
2. Installing an ATAPI Drive
This section describes how to install the TapeStor 20GB ATAPI tape drive. If you are installing a SCSI
drive, go to page 8.
1. Examine your computer
Before you install your tape drive, look inside your computer or read your computer manual to
answer the following questions. This will help you determine if you need additional hardware to
install the drive.
Do you have two IDE ports?
•If your computer has only one IDE port, it is probably being used by a hard disc, as shown in
Example 1. In this case you must obtain an ATAPI host adapter card and attach your tape
drive to the secondary IDE port on this card.
Hard
Hard
Disc
Computer
Motherboard
Primary
IDE port
(no secondary
IDE port)
EXAMPLE 1: Existing computer with only one
IDE port—hard disc attached to primary port
Disc
•If you have two IDE ports, the primary IDE port is probably being used by a hard disc (see
Example 2). In this case, the tape drive must be attached to the secondary IDE port.
Hard
Hard
Disc
Computer
Motherboard
Primary
IDE port
Secondary
IDE port
EXAMPLE 2: Existing computer with two IDE ports
(hard disc attached to the primary IDE port)
Attach tape drive and cable here
(tape drive must be configured
as master--see page 4)
Disc
3
Installing an ATAPI DriveSet the master/slave jumpers
(
)
Is there a 40-pin IDE cable already attached to your secondary IDE port?
•If you do not already have a cable for your secondary IDE adapter, you will need to obtain
one before installing your tape drive.
2. Set the master/slave jumpers
Are any other devices attached to your secondary IDE port?
•If a compatible ATAPI device, such as a CD-ROM, is already attached to your secondary IDE
port (as shown in Example 3), make sure that the tape drive is configured as a “slave.” See
the figure for master/slave jumper settings. The existing ATAPI device should be configured as
a “master.”
Hard
Hard
Disc
Disc
Computer
Motherboard
CD-ROM
Primary
IDE port
CD-ROM
Secondary
IDE port
EXAMPLE 3: Existing computer with two IDE ports
existing ATAPI devices on both primary and secondary IDE Ports
NOTE: Do not attach your tape drive to an IDE port that is being used by a hard disc or a
sound card.
CD-ROM
configured as Master
Attach tape drive here
configured as Slave
Master
Slave
Cable
select
Note: Drive is shown upside down
•If your tape drive will be the only device on the IDE cable, you need to configure your tape
drive as a “master.” Turn the drive over and set the master/slave jumper to the “master” position, as shown.
4
Installing an ATAPI DriveAttach or remove mounting brackets
3.
Attach or remove mounting brackets
Are you mounting the drive in a 3.5-inch or 5.25-inch drive bay?
•If you are mounting the drive in a 5.25-inch drive bay and your drive did not come with brack-
ets already attached, you must attach mounting brackets to each side of the drive, as shown.
•If you are mounting the tape drive in a 3.5-inch drive bay, you may need to remove the mount-
ing brackets from each side of the drive.
5.25-inch
drive bay
4. Mount the drive
Slide the drive into an unused drive bay, so that the bezel is flush with the front of the computer.
Secure the drive using four mounting screws. Do not overtighten the screws.
3.5-inch
drive bay
5
Installing an ATAPI DriveAttach your tape drive to the secondary IDE port
5.
Attach your tape drive to the secondary
IDE port
Are any other devices attached to your secondary IDE port?
•If no other devices are attached to your secondary IDE port, use a new 40-pin IDE cable to
attach the tape drive to the secondary IDE port. The tape drive must be configured as
“master.”
Hard
Hard
Disc
Disc
Computer
Motherboard
TAPE
Primary
IDE port
Secondary
IDE port
Stripe
cable
Pin 1 (typical)
on
•If you already have a CD-ROM or other device attached to your secondary IDE port, attach
the tape drive to the middle connector on the IDE cable, as shown in the illustration.
Hard
Hard
Disc
Disc
Computer
Motherboard
Primary
IDE port
Secondary
IDE port
Pin 1 (typical)
NOTE: Do not attach your tape drive to a cable that is already being used by a hard disc or a
sound card.
CD-
CD-
ROM
ROM
TAPE
TAPE
In either case, make sure that pin 1 on the tape drive is connected with pin 1 on the IDE cable and
on the IDE port connector. Pin 1 on the tape drive is located next to the 4-pin power cable. Pin 1 on
the IDE cable is indicated by a stripe on the edge of the cable.
6
Installing an ATAPI DriveConnect the power cable
6.
Connect the power cable
Connect a 4-pin power cable to the back of the tape drive. If all the power cables in your computer
are being used by other devices, you can purchase a Y-shaped power-cable splitter from your computer dealer.
7. Check all cables in your computer system
Make sure that none have loosened during the installation. Make sure that all cables are routed so
that they will not bind or become crimped when you replace the cover of your computer.
8. Reinstall your computer cover
Your new tape drive is now ready for use.
7
3. Installing a SCSI Drive
This section describes how to configure and install a TapeStor Travan SCSI tape drive. If you are
installing an ATAPI drive, see page 3.
NOTE: In order to use your TapeStor Travan SCSI tape drive, you must have a SCSI controller
and a 50-pin (narrow) SCSI cable with at least one unused SCSI connector. These drives cannot
be attached to 68-pin (wide) SCSI connectors.
1. Set the drive’s SCSI ID number
Are any other SCSI devices going to be attached to the same SCSI cable as the tape drive?
•If the tape drive is the only device on the SCSI bus, skip ahead to step 4 on page 11.
•If the tape drive is going to be sharing a SCSI bus with other devices, check the SCSI ID num-
bers used by the other devices. Then set the drive’s SCSI ID to a number that is not being used
by any of the other devices. The illustration shows jumper settings for each SCSI ID number.
Note: Drive is shown
upside down
Jumper
Positions
SCSI ID 0
SCSI ID 1
SCSI ID 2
SCSI ID 3
SCSI ID 4
SCSI ID 5
SCSI ID 6
SCSI ID 7
8
Installing a SCSI DriveCheck SCSI termination
2.
Check SCSI termination
Will your new tape drive be the last or only SCSI device on a SCSI cable?
•If your drive will be the last device on the SCSI cable or the only device on the cable, as
shown in Example 1, make sure that a jumper is installed on the SCSI termination jumper pins,
as shown.
•If your tape drive will be in the middle of a SCSI chain, as shown in Example 2, you must dis-
able SCSI termination on the drive. To disable SCSI termination on the tape drive, remove the
termination jumper (see figure). Make sure that the last SCSI device on the cable has termination enabled.
SCSI Host Adapter
(termination enabled)
SCSI Host Adapter
(termination enabled)
Tape drive
(termination enabled)
EXAMPLE 1: SCSI termination
where the tape drive is the
last or only SCSI device.
Tape drive
(termination disabled)
CD-ROM drive
(termination disabled)
Hard drive
(termination enabled)
EXAMPLE 2: SCSI termination
in a system with three internal
SCSI devices.
NOTE: If your computer has external SCSI devices or SCSI devices attached to a wide (68-pin)
SCSI cable, see your SCSI host adapter manual for termination instructions.
Note: Drive is shown
upside down
Jumper must be installed here to enable SCSI
termination. Remove jumper to disable termination.
9
Installing a SCSI DriveCheck additional SCSI options (optional)
3.
Check additional SCSI options (optional)
The drive’s factory-default settings for termination power and parity should work with most computer
systems and SCSI host adapters. Do not change these settings unless you have problems accessing
your tape drive.
•SCSI termination power: If you need to disable termination power, remove the termination
power jumper shown at left.
•Parity checking: If you need to disable parity checking, remove the parity jumper.
Note: Drive is shown
upside down
Enable termination power (default is ON)
Enable parity checking (default is ON)
10
Installing a SCSI DriveAttach or remove mounting brackets
4.
Attach or remove mounting brackets
Are you mounting the drive in a 3.5-inch or 5.25-inch bay?
•If you are mounting the drive in a 5.25-inch drive bay and your drive did not come with brack-
ets already attached, you must attach mounting brackets to each side of the drive, as shown.
•If you are mounting the tape drive in a 3.5-inch drive bay, you may need to remove the mount-
ing brackets from each side of the drive. See figure.
5. Mount the drive
Slide the drive into an unused drive bay, so that the bezel is flush with the front of the computer.
Secure the drive using four mounting screws. Do not overtighten the screws.
5.25-inch
drive bay
3.5-inch
drive bay
11
Installing a SCSI DriveConnect the drive to your SCSI host adapter
p
6.
Connect the drive to your SCSI host adapter
If you have enabled SCSI termination for the tape drive, attach the drive to the last 50-pin connector
on the SCSI cable. Otherwise, attach the tape drive to the unused 50-pin connector nearest the end
of the SCSI cable (see figure). Make sure that pin 1 on the cable (indicated by a stripe) is attached
to pin 1 on the host adapter and on the drive.
Hard
Hard
Disc
Pin 1 (typical)
SCSI Host
Adapter
Note. In this configuration,
SCSI termination for the hard drive must be
SCSI termination for the ta
Stripe on
cable
NOTE: The TapeStor Travan SCSI drives use a 50-pin SCSI connector. These drives cannot be
attached to 68-pin wide SCSI connectors.
Disc
e must be
TAPE
TAPE
disabled
enabled
.
.
7. Connect the power cable
Connect a 4-pin power cable to the back of the tape drive (see figure). If all the power cables in
your computer are being used by other devices, you can purchase a Y-shaped power-cable splitter
from your computer dealer.
12
Installing a SCSI DriveCheck all cables in your computer system
8.
Check all cables in your computer system
Make sure that none have loosened during the installation. Make sure that all cables are routed so
that they will not bind or become crimped when you replace the cover of your computer.
9. Reinstall your computer cover
Your new tape drive is ready to use.
13
4. Operation and Maintenance
Loading and unloading cartridges
On the front of your drive is an opening for inserting Travan cartridges. A protective door covers the
opening. Above and to the left of the door is the drive-activity light.
To load a cartridge: Insert the cartridge in the drive with the metal baseplate facing down and
the red write-protect tab on the left. The cartridge only fits in one orientation. Push the cartridge
firmly into the drive until it stops (about 1/3 of the cartridge remains visible outside the drive).
To unload a cartridge: Wait until the drive-activity light is OFF. Then grasp the exposed sides of
the cartridge and pull the cartridge straight out. If the drive-activity light has gone out, but you
believe your backup or restore operation did not complete, repeat the operation.
Drive-activity
light
Write-protect
switch (red)
CAUTION: Do not remove a tape cartridge while the drive-activity light is on.
14
Operation and MaintenanceHandling Travan cartridges
Handling Travan cartridges
Although Travan tape cartridges are ruggedly built, they must be handled with care. Observe the following precautions:
•Store cartridges in their protective cases when you are not using them.
•Keep cartridges away from dust, dirt and moisture.
•Keep cartridges away from direct sunlight and heat sources, such as radiators or warm air
ducts.
•Do not expose cartridges to temperature extremes or rapid changes in temperature.
•Keep cartridges away from sources of electromagnetic fields, such as telephones, computer
monitors, printers, dictation equipment, mechanical or printing calculators, motors or bulk
erasers.
•Do not open the tape access door of a cartridge or touch the tape itself. One fingerprint can
prevent the drive from reading information on the tape.
Retensioning tapes
Travan tapes must be retensioned frequently to ensure data integrity and optimize
drive performance. If you ever have a problem reading a tape, retensioning may solve the prob-
lem. See your software manual for tape retensioning instructions.
We recommend retensioning whenever:
•A cartridge is being used for the first time
•A cartridge has not been used for over a month
•A cartridge has been dropped
•A cartridge has been shipped from one location to another
•A cartridge has been exposed to a significant change in temperature
For optimum performance, cartridges should be retensioned prior to each use, if your backup software does not retension them automatically. See the literature included with your tape cartridge for
additional cartridge-handling recommendations.
Cleaning the tape drive mechanism
We recommend periodic cleaning of the tape drive mechanism using an approved dry-process Travan cleaning cartridge. Generally, the more severe the operating conditions (the greater the amount
of dust or moisture in the air), the more often the drive should be cleaned. Be sure to clean the drive
immediately if you observe an increase in the number of errors while running your backup software,
or if a TapeAlert cleaning message is displayed.
With the newer generation of Travan tape drive heads used in these drives, only the dry-process
cleaning-cartridge method is recommended. This method does not involve any flammable materials
and provides a clean recording surface by wiping away debris as the cleaning material passes
across the recording head. Residents of the U.S. can purchase Travan cleaning cartridges (model
number CTMCL) directly from Certance on the web at: http://shop.certance.com.
15
Operation and MaintenanceSetting the write-protect switch
Setting the write-protect switch
Travan cartridges feature a write-protect or “lock” switch near the upper left corner of the cartridge.
When the write-protect switch is in the “unlocked” position, the cartridge is ready for normal writing
and reading. When the write-protect switch is in the “locked” position, the drive can read data from
the cartridge, but cannot write to the cartridge. Cartridges are shipped from the factory with the
write-protect switch set to the “unlocked” position.
Unlocked
Locked
Recommended tape cartridges
The table below summarizes the types of tape cartridges that can be used with the TapeStor Travan
20GB drive.
Tape formatCapacity*
Read/writeTravan 20/NS20 (TR-5)
(all other tape formats are incompatible)
Read onlyTravan 8 (TR-4)
(all other tape formats are incompatible)
NOTE: “Capacities based on 2:1 data compression. Uncompressed values are one half as
high. Capacities, backup speeds and transfer rates will vary with file type and system
configuration.
20 Gbytes
8 Gbytes
16
5. Troubleshooting
If you have problems installing or operating your drive, please read through this section and try the
proposed solutions.
Installation troubleshooting (ATAPI drives)
If, after installing an ATAPI tape drive, your computer does not recognize your
tape drive or CD-ROM:
•Make sure all cables are attached firmly.
•Make sure you have installed and configured your backup software properly.
•Check with the manufacturer of your ATAPI controller chip set to make sure that you have the
latest drivers for your operating system. Outdated or incorrect drivers provide limited hardware support and can result in Windows being unable to detect your tape drive.
•You may need to reconfigure your tape drive as a “master” or “slave” using the master/slave
jumpers. The master/slave jumpers are located on the underside of the drive, behind the interface connector.
–If the tape drive is the only device on the IDE cable, set the jumper to configure it as a
“master.”
–If there are two ATAPI devices on a single cable, make sure that the tape drive as set as
