StorNext® SNAPI 2.0.1

StorNext

6-01375-05

StorNext API Guide, 6-01375-05, Ver. A, Rel. 2.0, April 2008, Made in USA.

Quantum Corporation provides this publication “as is” without warranty of any kind, either express or implied, including but not limited to the implied warranties of merchantability or fitness for a particular purpose. Quantum Corporation may revise this publication from time to time without notice.

Your right to copy this manual is limited by copyright law. Making copies or adaptations without prior written authorization of Quantum Corporation is prohibited by law and constitutes a punishable violation of the law.

TRADEMARK STATEMENT

Quantum, DLT, DLTtape, the Quantum logo, and the DLTtape logo are all registered trademarks of Quantum Corporation.

SDLT and Super DLTtape are trademarks of Quantum Corporation.

Other trademarks may be mentioned herein which belong to other companies.

Chapter 1 Introduction 1

About This Guide .............................................................................................. 1

Product Compatibility ...................................................................................... 2

SNAPI/StorNext Compatibility Matrix.................................................. 2

Installing StorNext APIs ................................................................................... 2

Running APIs Remotely ................................................................................... 2

Explanation of Warnings, Cautions and Notes............................................. 3

Related Documents You Might Need............................................................. 3

Getting More Information or Help .......................................................... 4

Quantum Technical Assistance Center........................................................... 4

Chapter 2 StorNext Storage Manager APIs 5

Introduction........................................................................................................ 5

Installing the APIs on the Storage Manager Host......................................... 6

Installing the APIs on a Remote Client........................................................... 7

Configuring SNAPI ........................................................................................... 8

SNAPI Logs and Health Checks...................................................................... 9

Use Cases .......................................................................................................... 10

Using a C or C++ Library with XML Wrapper .................................... 12

Using the SNAPI XML Command Line Interface (snclix).................. 13

API Descriptions and Arguments ................................................................. 15

StorNext API Guide i

Chapter 3 StorNext File System APIs 86

Allocation and Space Management APIs ..................................................... 89

Quality of Service and Real Time I/O APIs.................................................98

File System Configuration and Location Management APIs .................. 108

Access Management APIs............................................................................. 119

Appendix A File System API Example 136

Appendix B Storage Manager API Example 164

C++ Test Program Example .................................................................. 164

C++ XML Interface Test Program Example........................................ 166

Makefile Example for Linux Platforms................................................ 167

Makefile Example for Solaris Platforms.............................................. 168

StorNext API Guide ii

About This Guide

Chapter 1

1Introduction

This guide contains information and instructions necessary to install and use the StorNext APIs (SNAPI). This guide is intended for system administrators, programmers, and anyone interested in learning about installing and using the StorNext APIs.

The StorNext API guide is divided into the following chapters:

• StorNext Storage Manager APIs

• StorNext File System APIs

• File System API Example

• Storage Manager API Example

StorNext API (SNAPI) contains StorNext Storage Manager APIs, StorNext File System APIs, and Client APIs that can be used to make calls to third-party applications, resulting in enhanced operations between third-party applications and StorNext.

StorNext API Guide 1

Product Compatibility

The StorNext API (SNAPI) release is compatible with a specific StorNext release. Please refer to the following compatibility matrix to verify you are running compatible versions of both products.

SNAPI/StorNext Compatibility Matrix 1

StorNext API (SNAPI) Version StorNext Version

SNAPI 1.0 StorNext 2.8.1 SNAPI 1.1.0 StorNext 3.0 SNAPI 2.0 StorNext 3.0.2, 3.1

Chapter 1 Introduction

Product Compatibility

SNAPI 2.0.1 StorNext 3.1.1, 3.1.2

Installing StorNext APIs

The StorNext File System APIs are automatically installed when you install the StorNext software.

The StorNext Storage Manager APIs on the CD must be installed before you can call them. For installation instructions, see Installing the APIs

the Storage Manager Host in the chapter StorNext Storage Manager APIs.

StorNext API Guide 2

Running APIs Remotely

Beginning with SNAPI 2.0, you can now run StorNext Storage Manager APIs remotely from a client. Functionally, operation from a remote client is identical to running the APIs locally. If you want to use this feature, remote clients must be installed and configured as described in Installing

the APIs on a Remote Client and Configuring SNAPI in the chapter StorNext Storage Manager APIs

StorNext File System APIs continue to run remotely on clients as they always have.

Explanation of Warnings, Cautions and Notes

Chapter 1 Introduction

Running APIs Remotely

The following cautions, and notes appear throughout this document to highlight important information.

Caution: Indicates a situation that may cause possible damage to

equipment, loss of data, or interference with other equipment.

Note: Indicates important information that helps you make better

use of your system.

Quantum Technical Assistance Center

• StorNext User’s Guide (6-01658-02)

• StorNext File System Quick Reference Guide (6-00361-21)

• StorNext Storage Manager Quick Reference Guide (6-00361-22)

Getting More Information or Help 1

More information about this product is available on the Customer Service Center website at www.quantum.com/csc contains a collection of information, including answers to frequently asked questions (FAQs). You can also access software, firmware, and drivers through this site.

Quantum Technical Assistance Center

For further assistance, or if training is desired, contact the Quantum Technical Assistance Center:

North America: UK, France and Germany: EMEA: Worldwide Web:

1+800-284-5101 00800 4 QUANTUM +44 1256 848 766

www.quantum.com/support

. The Customer Service Center

StorNext API Guide 4

Introduction

Chapter 2

2StorNext Storage Manager APIs

This chapter describes the application programming interfaces (APIs) available for StorNext Storage Manager.

This chapter contains the following major topics:

• Installing the APIs

• Installing the APIs on a Remote Client

• Configuring SNAPI

• SNAPI Logs and Health Checks

• Use Cases

• API Descriptions and Arguments

Note: Unlike the StorNext File System APIs which are automatically

installed with the StorNext software, you must install the Storage Manager APIs from the CD by following the installation instructions in Installing the APIs

Manager Host on page 6.

Throughout this chapter, the terms library and archive are used. Library refers to an actual physical library (e.g., with robotics), whereas archive is

StorNext API Guide 5

on the Storage Manager Host

on the Storage

Chapter 2 StorNext Storage Manager APIs

Installing the APIs on the Storage Manager Host

a more general term that may refer to a library, a vault, or anywhere else where media can be stored.

A vault is a logical archive type. It is any location that contains copies of media that have been removed from the operational system. Since a vault has no robotics, if a vault has tape drives, tape media must be manually mounted to the drive and dismounted from the drive.

Installing the APIs on the Storage Manager Host

This section describes how to install the SNAPI Storage Manager APIs and the SNAPI Server on the StorNext Storage Manager host. After installation is complete, the SNAPI Server will listen for requests from all local and remote SNAPI clients. The SNAPI Server will log operational

and error messages to /usr/adic/SNAPI/logs/. The SNAPI Server will also

handle all local and remote requests from snclix, the SNAPI command line interface utility.

1 Log on as root. 2 Insert and mount the product CD that contains the StorNext Storage

Manager APIs.

3 Use the cd command to navigate to the directory that corresponds to

your operating system:

• SunOS590sparc_32

• SunOS5100sparc_32

• RedHat40AS_26ia64

• RedHat40AS_26x86_32

• RedHat40AS_26x86_64

• SuSE90ES_26x86_64

• SuSE90ES_26ia64

• SuSE90ES_26x86_32

• SuSE100ES_26x86_64

• SuSE100ES_26ia64

StorNext API Guide 6

Chapter 2 StorNext Storage Manager APIs

• SuSE100ES_26x86_32

4 From the operating system directory, run the program install.snapi.

This program automatically decompresses the APIs and copies them

to your StorNext directory in the following location: /usr/adic/SNAPI.

5 You can access this API guide by locating the pdf file on the StorNext

API CD.

After installing the Storage Manger APIs, in order to successfully

compile and link with your applications you need the location of the

main header file and the libraries Quantum delivers.

The main header file location: /usr/adic/SNAPI/inc/API.hh

The dynamic library location: /usr/adic/SNAPI/lib/libsnapi.so

The static library location: /usr/adic/SNAPI/lib/static/libsnapi.a

Installing the APIs on a Remote Client

This section describes how to install the SNAPI Storage Manager APIs on a remote client connected to a SNAPI Server host. As a prerequisite, SNAPI must have already been installed on the Storage Manager host as described in Installing the APIs

To install a remote client:

1 Copy the script /usr/adic/SNAPI/bin/install.snapiclient from the

Storage Manager host to the remote host.

Note: To ensure that the install.snapiclient script runs properly,

before proceeding verify that RCP is enabled between the remote client host and the StorNext Storage Manager host.

2 Run the install.snapiclient script on the remote host, passing it the

name of the Storage Manager host. For example:

install.snapiclient <SNAPI_Server_Host>

The installation script also installs the snclix utility, which can be used to run SNAPI API commands on the command line.

StorNext API Guide 7

on the Storage Manager Host.

Configuring SNAPI

Chapter 2 StorNext Storage Manager APIs

Configuring SNAPI

Note: An upgrade of SNAPI on a remote client is accomplished by

running the installation procedure described above. To remove SNAPI from a remote client, simply remove all

contents of the /usr/adic/SNAPI/ directory.

SNAPI configuration for both local and remote clients is accomplished by

editing the /usr/adic/SNAPI/config/snapi.cfg file on the SNAPI server and remote hosts, respectively. The snapi.cfg file allows you to specify the

following:

•SNAPI server names

• INET socket port value for remote clients

Snapi.cfg Example 2

• Client timeout value. This value specifies how long the client should wait for a response from the SNAPI server. This value can be between 0-1000 minutes. The default value is 30 minutes.

You are not required to modify the snapi.cfg file before running the APIs

unless you are enabling HA support for remote clients, or in other special cases. (See HA Failover Support support.)

The following example describes and illustrates each of the parameters in

the snapi.cfg file. (You can find the example in the snapi.cfg.default file installed at /usr/adic/SNAPI/config/snapi.cfg.default.)

<!-- The serverName indicates the host on which the S torNext server is

running. If this is an HA system, add a line to indicate the failover host. -->

<!-- The serverPort is used for remote client connections. There i s no

need to edit this value unless the port is already in use, in which case the port value on the StorNext server must be edited also. -->

for more information about enabling HA

StorNext API Guide 8

Chapter 2 StorNext Storage Manager APIs

SNAPI Logs and Health Checks

<!-- The clientT imeOut is the maximum time (in secs) a client will spend

attempting to fulfill a request to the server. Set the value to 0 to indicate the client should try indefinitely to fulfill the request. -->

HA Failover Support 2

HA failover support applies only to remote clients, and is supported by

the snapi.cfg file on the remote hosts. To enable HA support, specify the

primary and secondary SNAPI server host names in an ordered list on

separate lines in the /usr/adic/SNAPI/config/snapi.cfg file.

For example:

Upon detecting failover, SNAPI internally will reissue the original request to the SNAPI server on behalf of the remote client. Connection attempts to the primary and secondary servers will continue until the client timeout limit is reached.

SNAPI Logs and Health Checks

Logs are available for the SNAPI server host. These logs use the existing

StorNext logging framework, and are located at /usr/adic/SNAPI/logs/tac.

You can configure SNAPI logs by adjusting the parameters located at

/usr/adic/SNAPI/logs/log_params.

Health checks are also available on the SNAPI server host. Health checks are also integrated with the existing StorNext Health Check framework.

To run health checks, from the StorNext home page, choose Health Check from the Service Menu. The Health Check Test screen appears. From this screen run one or both of these health checks:

• Network: This health check validates connections to the StorNext server

StorNext API Guide 9

Use Cases

Chapter 2 StorNext Storage Manager APIs

Use Cases

• Config: This health check validates the contents of the SNAPI

configuration file (snapi.cfg)

Alternatively, you can accomplish the same thing manually by running the following tests:

• snapiverifyConnectivity: Verifies connection to the StorNext server. Located at /usr/adic/SNAPI/bin/snapiVerifyConnectivity.

• snapiverifyConfig: Validates the SNAPI configuration file (snapi.cfg) contents. Located at /usr/adic/SNAPI/bin/snapiVerifyConfig.

There are three different programmatic entry points for accessing the StorNext Storage Manager APIs:

• Using a C or C++ Library

• Using a C or C++ Library with XML Wrapper

• Using the SNAPI XML Command Line Interface (snclix)

This section contains examples showing how to use the APIs with these methods.

Note: Data types used in these APIs are defined in the header files

located here: /usr/adic/SNAPI/inc/

Using a C or C++ Library2

StorNext API Guide 10

For each API, there is a corresponding C++ class with the same name as the API. Quantum provides both dynamic and static libraries, as well as a header file to link to the application program.

The following example illustrates typical API usage for this case.

#include <API.hh> #include <sys/types.h>

#include <unistd.h> #include <iostream> #include <sstream>

Chapter 2 StorNext Storage Manager APIs

#include <string> using namespace std;

using namespace Quantum::SNAPI; int

main() { Status status;

try { // Create object for requesting file attributes. GetFileAttribute getFileAttrReq("/snfs/testFile.dat");

// Send request to the server and get overall request status code. // Note: This method may throw exceptions (see catch block below). status = getFileAttrReq.process();

// Check the returned status code. if (status.getCode() != SUCCESS) { cout << "StatusCode: " << status.getCodeAsString() << endl; cout << "Description: " << status.getDescription() << endl; cout << "LocalStatus.StatusCode: " << getFileAttrReq.getLocalStatus().getCodeAsString() << endl; cout << "LocalStatus.Description: " << getFileAttrReq.getLocalStatus().getDescription() << endl; } else { // Get the requested data. FileInfo fileInfo = getFileAttrReq.getFileInfo();

Use Cases

cout << "FileName: " << fileInfo.getFileName() << endl; cout << "Location: " << fileInfo.getLocationAsString() << endl; cout << "Existing Copies: " << fileInfo.getNumberOfExistingCopies() << endl; cout << "Target Copies: " << fileInfo.getNumberOfTargetCopies() << endl;

MediaList media = fileInfo.getMedia(); for (int i=0; i<media.size(); i++)

{ cout << "Media ID: " << media[i] << endl; } } }

StorNext API Guide 11

Chapter 2 StorNext Storage Manager APIs

catch (SnException& exception) { switch (exception.getCode()) { case SUBFAILURE: case FAILURE: case SYNTAXERROR: default: { cout << "Exception code: " << exception.what() << endl; cout << "Exception detail: " << exception.getDetail() << endl; } break; } } catch (...) { cout << "Caught unknown exception." << endl; }

return status.getCode(); }

Use Cases

Using a C or C++ Library with XML Wrapper 2

For this approach there is a single function called doXML available to the

third-party program. This function’s input and output are string type, and their contents are in XML format. Different APIs have different specifications on the XML input and output, as described for each API.

Note: It is your responsibility to provide an input string that satisfies

the specification. Otherwise, a failure from the doXML

function call might result.

The following example illustrates typical API usage for this case.

#include <API.hh>

#include <sys/types.h> #include <unistd.h> #include <iostream> #include <sstream> #include <string>

StorNext API Guide 12

Chapter 2 StorNext Storage Manager APIs

Use Cases

using namespace std; using namespace Quantum::SNAPI;

int main() { Status status;

// Initialize input command in XML format. XML xmlIn("<?xml version=\"1.0\"?>" "<COMMAND name=\"GetFileAttribute\">" " <ARGUMENT name=\"fileName\" value=\"/snfs/testFile.dat\"/>" "</COMMAND>");

XML xmlOut;

try { // Perform the request. status = doXML(xmlIn, xmlOut); } catch (SnException& excptn) { cerr << "Exception code: " << excptn.what() << endl; cerr << "Exception detail: " << excptn.getDetail() << endl; status = excptn.getCode(); }

// Stream the results to standard out. cout << xmlOut << endl;

return status.getCode(); }

Using the SNAPI XML Command Line Interface (snclix) 2

The snclix utility is a command line utility that provides an interface for

SNAPI APIs from the SNAPI server and remote client hosts. This utility operates on XML input and output, and is very similar to the doXML() function. Both of these take an XML request definition as input, and return an XML response with requested information embedded in the response.

StorNext API Guide 13

Chapter 2 StorNext Storage Manager APIs

Use Cases

Note: It is your responsibility to generate a properly formatted XML

request and to subsequently access the relative portions of information in the XML response.

Any XML information that is not relevant to the specified request will cause an error. This also applies to cases where single arguments are expected but multiple arguments are supplied.

XML character data must comply with Section 2.4 of the XML specification. In particular, when used in value strings, the following characters must be escaped using their ASCII numeric character references:

& = "&" < = "<" > = ">"

In addition, any non-printing characters (such as new line, tab, etc.) must be escaped using their ASCII numeric character references.

When using the snclix utility, after you create a file containing properly

formatted XML (or optionally an input stream,) you then pass the

information to the snclix executable program. Internally, snclix calls the doXML() function to process the request and

send the resulting XML response to an output file (or optionally streams it to stdout).

The snclix utility is located at /usr/adic/SNAPI/bin/snclix and has the

following usage format:

snclix [-i infile] [-o outfile] [-c config]

-i infile: Specifies an input file. (File contents should be in XML format.)

-o outfile: Specifies an output file. (File contents will be in XML format.) If an

outfile exits, it will be overwritten.

-c config: Specifies a configuration file.

Example of snclix Usage 2

snclix -i /tmp/GetFileAttributeRequest.xml -o /tmp/ GetFileAttributeResponse.xml

Where the /tmp/GetFileAttributeRequest.xml file contains the following input:

StorNext API Guide 14

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

<?xml version="1.0"?> <COMMAND name="GetFileAttribute">

</COMMAND>

And the /tmp/GetFileAttributeResponse.xml file contains the following

output:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="GetFileAttribute" statusCode="0" status="SUCCESS">

</FILEINFO>

</RESPONSE>

API Descriptions and Arguments

A brief description is provided for each API, as well as its input arguments and output variables. Also provided for each API is an example showing XML input and output, and the corresponding C++ class declaration.

The following StorNext Storage Manager APIs are described in this section:

• Backup

• CheckoutMedia

• CleanMedia

• CopyMedia

• EjectMedia

• EnterMedia

• FileRetrieve

StorNext API Guide 15

• GetArchiveCapacity

• GetArchiveList

• GetBackupStatus

• GetDriveList

• GetFileAttribute

• GetFileTapeLocationI

• GetMediaList

• GetMediaStatus

• GetPolicy

• GetPortList

• GetSchedule

• GetSystemStatus

• MoveMedia

• PassThru

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

• RmDiskCopy

• SetArchiveState

• SetDirAttributes

• SetDriveState

• SetFileAttributes

• SetMediaState

• SetPolicy

• SetSchedule

For the C++ class declaration section, all API classes inherit from class Request, which has a public member function process(). The third-party program must call this function to have the API request processed. See the example code in Appendix B.

StorNext API Guide 16

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

Note: The process() function should be called only once for each

instantiation of an API object. API users should instantiate a

new API object every time they need to call the process()

function.

When you enter arguments for the StorNext Storage Manager APIs, wildcard characters such as the asterisk (*) are not

supported. For example, when you run the FileRetrieve API you cannot enter ‘*’ when entering the <filename> parameter.

Backup 2

This API initiates a backup operation.

Input

NA. This API has no command arguments.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="Backup"/>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="Backup" statusCode="0" status="SUCCESS"

statusDescription="Backup initiation successful">

<STATUSDETAIL statusCode="0" status="SUCCESS"

statusDescription="Backup initiation successful"/>

</RESPONSE>

StorNext API Guide 17

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

C++ Class Declaration 2

class Backup : public Request { public:

/// Default and Primary Contructor Backup();

/// Method to return the local status const Status& getLocalStatus() const;

}

CheckoutMedia 2

This API allows you to check out media with the specified media IDs.

Input

mediaID: The ID of the media you want to check out. You can specify

multiple media IDs to check out multiple media.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="CheckOutMedia">

<ARGUMENT name="mediaID" value="025311"/> <ARGUMENT name="mediaID" value="025312"/>

StorNext API Guide 18

</COMMAND>

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="CheckOutMedia" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STATUSDETAIL name="mediaID" value="025311"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

<STATUSDETAIL name="mediaID" value="025312"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

</RESPONSE>

C++ Class Declaration 2

class CheckOutMedia : public Request { public:

/// Primary Constructor /// This constructor is intended for primary instantiation of the object, /// given a single media ID. CheckOutMedia(const std::string& inMediaID);

/// Secondary Constructor /// This constructor is for instantiation of the object from a list of /// media ID to eject. CheckOutMedia(const MediaList& inMediaList);

/// Method to return the list of media const MediaList& getMediaList() const;

/// Method to return the collection of status pairs const StatusPairList& getLocalStatus() const;

/// Method to return the status pair for a specific mediaID const StatusPair& getLocalStatus(const std::string& mediaID) const;

}

StorNext API Guide 19

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

CleanMedia 2

This API cleans media by removing inactive files from the specified media.

Input

mediaID: The ID of the media you want to clean. You can specify multiple

media IDs to clean multiple media.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="CleanMedia">

</COMMAND>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="CleanMedia" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STATUSDETAIL name="mediaID" value="025311"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

<STATUSDETAIL name="mediaID" value="025312"

statusCode="0" status="SUCCESS"

StorNext API Guide 20

</RESPONSE>

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

statusDescription="Command Successful"/>

C++ Class Declaration

class CleanMedia : public Request { public:

/// Primary Constructor /// This constructor is intended for primary instantiation of the object. CleanMedia(const std::string& inMediaID);

/// Secondary Constructor /// This constructor is intended for instantiation of the object fro m a /// vector of media ids. CleanMedia(const MediaList& inMedia);

/// Method to return the list of media MediaList getMediaList() const;

/// Method to return the list of local status pairs const StatusPairList& getLocalStatus() const;

/// Method to return the specific local status pair for a given mediaID const StatusPair& getLocalStatus(const std::string& mediaID) const; }

CopyMedia 2

This API copies the content of all specified media to a piece of blank media.

Input

mediaID: The ID of the media you want to copy. You can specify multiple

media IDs to copy multiple media.

StorNext API Guide 21

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

Output 2

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="CopyMedia">

</COMMAND>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="CopyMedia" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STATUSDETAIL name="mediaID" value="025311"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

<STATUSDETAIL name="mediaID" value="025312"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

</RESPONSE>

C++ Class Declaration

class CopyMedia : public Request { public:

/// Primary Constructor

StorNext API Guide 22

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

/// This constructor is intended for primary instantiation of the object. CopyMedia(const std::string& inMediaID);

/// Secondary Constructor /// This constructor is intended for instantiation of the object fro m a /// vector of media ids. CopyMedia(const MediaList& inMedia);

/// Method to return the list of media MediaList getMediaList() const;

/// Method to return the list of local status pairs const StatusPairList& getLocalStatus() const;

/// Method to return the specific local status pair for a given mediaID const StatusPair& getLocalStatus(const std::string& mediaID) const;

}

EjectMedia 2

This API moves the specified media from the archive to a media I/E slot. EjectMedia does an automated media eject. This API must be used with the MoveMedia API.

After running this API, you must call the EnterMedia API to physically move the media from the mailbox into the destination library, or in the case of a vault, to logically enter the media into the vault.

Input

portID: The port used for ejecting media. The port ID is in the format

0,0,15,###. Only the digits following the final comma are needed, indicated as ### in the format example. It is not needed for vault

archives.

mediaID: The ID of the media to eject.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

StorNext API Guide 23

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

XML Example 2

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="EjectMedia">

<ARGUMENT name="portId" value="16"/> <ARGUMENT name="mediaId" value="012345"/>

</COMMAND>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="EjectMedia" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STATUSDETAIL name="mediaID" value="012345"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

</RESPONSE>

C++ Class Declaration

class EjectMedia : public Request { public:

/// Primary Constructor /// This constructor is intended for primary instantiation of the object, /// given a port Id and a single media Id. EjectMedia(const std::string& inMediaId, const std::string& inPortId = "0");

/// Method to set port Id void setPortId(const std::string& inPortId);

/// Method to return the media Id

StorNext API Guide 24

Chapter 2 StorNext Storage Manager APIs

const std::string& getMediaId() const;

/// Method to return the local status pair const StatusPair& getLocalStatus() const;

}

API Descriptions and Arguments

EnterMedia 2

This API adds (inserts) media into the specified archive from the I/E slot. This API must be used after you run the EjectMedia API, and must be used with the MoveMedia API.

Input

archiveID: The archive ID to which media is added. portID: The port used for entering media. The port ID is in the format

0,0,15,###. Only the digits following the final comma are needed,

indicated as ### in the format example. It is not needed for vault archives.

mediaID: The media ID to insert into the archive.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="EnterMedia">

StorNext API Guide 25

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

</COMMAND>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="EnterMedia" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STATUSDETAIL name="mediaID" value="012345"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

</RESPONSE>

C++ Class Declaration

class EnterMedia : public Request { public:

/// Primary Constructor /// This constructor is intended for primary instantiation of the object, /// given a archive Id, a port Id, and a single media Id. EnterMedia(const std::string& inArchiveId, const std::string& inMediaId, const std::string& inPortId = "0");

/// Method to set portId void setPortId(const std::string& inPortId);

/// Method to return the media Id const std::string& getMediaId() const;

/// Method to return the local status pair const StatusPair& getLocalStatus() const;

}

FileRetrieve 2

StorNext API Guide 26

This API retrieves the specified single file from secondary storage to primary storage.

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

Input 2

filename: The pathname of the file to be retrieved. newFileName (optional): The name you want to give the retrieved file.

The default value is an empty string, which means the file data is retrieved to disk using the original file name. This argument is optional if used by itself, but required if you use startByte and endByte.

startByte (optional): The starting byte for a partial retrieval. The default

value is 0, which means a full retrieval is expected. Do not use this argument (in conjunction with the endByte argument) if you use the

copyId argument. endByte (optional): The end byte for a partial retrieval. The default value

is 0, which means a full retrieval is expected. Do not use this argument (in conjunction with the startByte argument) if you use the copyId argument.

modAccessTime (optional): TRUE or FALSE. Indicates whether the

retrieve will modify the file's access time. The default value is FALSE.

copyId (optional): Indicates which copy to be retrieved. The default value

is 0, which refers to the primary copy. Do not use this argument if you use the startByte and endByte arguments.

Note: The filename argument is required. All other arguments are

optional except as noted.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

newFileName: The name of the retrieved file.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="FileRetrieve">

StorNext API Guide 27

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

<ARGUMENT name="fileName" value="/csofs/storage/temp"/>

</COMMAND>

Response: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="FileRetrieve" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<RETRIEVEINFO name="filename" value="/csofs/storage/temp"

statusCode="0" status="SUCCESS" statusDescription="Command Successful" />

</RESPONSE>

(The XML response is identical whether you use startByte and endByte or copyId.)

C++ Class Declaration

class FileRetrieve : public Request { public:

/// First Constructor /// This constructor is intended for instantiation of the object for a /// full retrieve. FileRetrieve(const std::string& inFileName);

/// Second Constructor /// This constructor is intended for instantiation of the object for a /// full retrieve of the specified filename into the new filename. FileRetrieve(const std::string& inFileName,

const std::string& inNewFileName);

StorNext API Guide 28

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

/// Third Constructor /// This constructor is intended for instantiation of the object for a /// partial retrieve of the specified filename into the new filename /// with startbyte and endbyte specifying the start/end of the retrieve. FileRetrieve(const std::string& inFileName,

const std::string& inNewFileName, const int64_t& inStartByte, const int64_t& inEndByte);

/// Fourth Constructor /// This constructor is intended for instantiation of the object for a /// full retrieve but with the copyId specified. FileRetrieve(const std::string& inFileName,

const int32_t& inCopyId);

/// Fifth Constructor /// This constructor is intended for instantiation of the object for a /// full retrieve of the specified filename into the new filename but /// with the copyId specified. FileRetrieve(const std::string& inFileName,

const std::string& inNewFileName, const int32_t& inCopyId);

/// There are no set functions for copyid and startbyte/endbyte /// because they are mutually exclusive options for this API. /// These are handled by the various constructors defined above.

/// Set Function for filename void setFileName(std::string& inFileName);

/// Set Function for modAccessTime void setModAccessTime(bool& inModAccessTime);

/// Set Function for newfilename void setNewFileName(std::string& inNewFileName);

/// Get Function for fileName const std::string& getFileName() const;

StorNext API Guide 29

Chapter 2 StorNext Storage Manager APIs

/// Get Function for modAccessTime const bool& getModAccessTime() const;

/// Get Function for copyId const int32_t& getCopyId() const;

/// Get Function for newFileName const std::string& getNewFileName() const;

/// Get Function for startByte const int64_t& getStartByte() const;

/// Get Function for endByte const int64_t& getEndByte() const;

/// Method to return the local status pair const StatusPair& getLocalStatus() const;

}

API Descriptions and Arguments

GetArchiveCapacity 2

StorNext API Guide 30

This API provides the amount of remaining storage capacity for all archives.

Input

NA. This API has no command arguments.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="GetArchiveCapacity"/>

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

Response: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="GetArchiveCapacity" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STRINGINFO statusCode="0" status="SUCCESS"

statusDescription="Command Successful">  <INFO name="remainingMediaCapacity" value="99999"/>

</STRINGINFO>

</RESPONSE>

C++ Class Declaration 2

class GetArchiveCapacity : public Request { public:

/// Default and Primary Constructor GetArchiveCapacity();

/// Method to return the total remaining capacity in GB. int32_t getCapacity() const;

/// Method to return the local status const Status& getLocalStatus() const;

}

GetArchiveList 2

This API provides the current configuration settings for all archives.

Input

NA. This API has no command arguments.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

archiveName: The name of the archive whose configuration settings are

listed.

StorNext API Guide 31

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

state: The current state of the archive: ONLINE or OFFLINE. archiveType: The disk type for the archive (e.g., SCSI).

serialNumber: The archive’s serial number. model: The archive’s model. numberSlots: The total number of slots in the archive. numberSlotsUsed: The number of used slots in the archive. firmwareVersion: The archive’s firmware version. totalSpace: The amount of total space in the archive, in gigabytes. remainingSpace: The amount of space, in gigabytes, remaining in the

archive.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="GetArchiveList"/>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="GetArchiveList" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<ARCHIVEINFO statusCode="0" status="SUCCESS"

statusDescription="Command Successful">    <INFO name="archiveName" value="Andromeda"/> <INFO name="state" value="online"/> <INFO name="archiveType" value="SCSI"/> <INFO name="serialNumber" value="ADIC_1_9Y2230000"/> <INFO name="model" value="Scalar 24"/> <INFO name="numberSlots" value="24"/> <INFO name="numberSlotsUsed" value="18"/> <INFO name="firmwareVersion" value="237A"/> <INFO name="totalSpace" value="93504"/> <INFO name="remainingSpac e" value="90000"/>

</ARCHIVEINFO>

StorNext API Guide 32

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

</RESPONSE>

C++ Class Declaration 2

class GetArchiveList : public Request { public:

/// Default and Primary Constructor GetArchiveList();

/// Method to return the list of Archives const std::vector<ArchiveInfo>& getArchiveInfo() const;

/// Method to return the local status const Status& getLocalStatus() const;

} class ArchiveInfo : virtual public Info

{ public:

/// Default and Primary Constructor ArchiveInfo(const std::string& inName="unknown",

const std::string& inState="unknown", const std::string& inArchiveType="unknown", const std::string& inSerialNumber="unknown", const std::string& inModel="unknown", const int32_t& inNumberSlots=0, const int32_t& inNumberSlotsUsed=0, const std::string& inFirmwareVersion="unknown", const int32_t& inTotalSpace=0, const int32_t& inRemainingCapacity=0);

/// Method to return the name of the archive. const std::string& getName() const;

/// Method to return the state of the archive. const std::string& getState() const;

/// Method to return the type of the archive. const std::string& getArchiveType() const;

/// Method to return the serialnumber of the archive.

StorNext API Guide 33

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

const std::string& getSerialNumber() const; /// Method to return the model of the archive.

const std::string& getModel() const; /// Method to return the number of slots for media in the archive.

int32_t getNumberOfSlots() const; /// Method to return the number of slots currently holding media in the

/// archive. int32_t getNumberOfSlotsUsed() const;

/// Method to return the firmware version of the archive. const std::string& getFirmwareVersion() const;

/// Method to return the total capacity of the archive in gigabytes. int32_t getTotalSpace() const;

/// Method to return the total available (unused) capacity of the /// archive in gigabytes. int32_t getRemainingSpace() const;

/// Method to set the state of the archive. void setState(const std::string& inState);

/// Method to set the type of the archive. void setArchiveType(const std::string& inArchiveType);

/// Method to set the serialnumber of the archive. void setSerialNumber(const std::string& inSerialNumber);

/// Method to set the model of the archive. void setModel(const std::string& inModel);

/// Method to set the number of slots for media in the archive. void setNumberOfSlots(const int32_t& inNumberSlots);

/// Method to set the number of slots currently holding media in /// the archive. void setNumberOfSlotsUsed(const int32_t& inNumberSlotsUsed);

/// Method to set the firmware version of the archive. void setFirmwareVersion(const std::string& inFirmwareVersion);

StorNext API Guide 34

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

/// Method to set the total capacity of the archive in gigabytes. void setTotalSpace(const int32_t& inTotalSpace);

/// Method to set the total available (unused) capacity of the /// archive in gigabytes. void setRemainingSpace(const int32_t& inRemainingSpace);

/// Method to deflate this object for client-server transmision std::string deflate() const;

/// Method to restore this object from a deflated string void inflate(std::string& inDeflatedObject);

}

Note: Currently, the GetArchiveList API assumes there is only one

media type per archive. If the archive supports more than one media type, the output might not be accurate.

GetBackupStatus 2

This API provides the current status or progress of a backup in progress.

Input

NA. This API has no command arguments.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

info: Any relevant information about the backup operation.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="GetBackupStatus"/>

StorNext API Guide 35

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

Response: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>

<RESPONSE name="GetBackupStatus" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STRINGINFO statusCode="0" status="SUCCESS"

statusDescription="Command Successful">  <INFO value="Response text goes here."/> <INFO value="Response text goes here."/> <INFO value="Response text goes here."/> <INFO value="Response text goes here."/>

</STRINGINFO>

</RESPONSE>

C++ Class Declaration 2

class GetBackupStatus : public Request { public:

/// Default and Primary Contructor GetBackupStatus();

/// Method to return the backup progression status const std::string& getBackupProgress() const;

/// Method to return the local status const Status& getLocalStatus() const;

}

GetDriveList 2

This API provides a list of available drives and their attributes.

Input

NA. This API has no command arguments.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

StorNext API Guide 36

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

driveName: The name of the drive whose attributes are listed. state: The drive’s current state: ONLINE or OFFLINE. serialNumber: The drive’s serial number. type: The type of drive. mountState: The drive’s current mount state: MOUNTED or

UNMOUNTED.

mediaID: A media ID of the drive. firmwareVersion: The drive’s firmware version.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="GetDriveList"/>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="GetDriveList" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">  <DRIVEINFO statusCode="0" status="SUCCESS"

statusDescription="Command Successful">    <INFO name="driveName" value="Andromeda_LTO_Drive1"/> <INFO name="state" value="online"/> <INFO name="serialNumber" value="1110236593"/> <INFO name="type" value="LTO"/> <INFO name="mountState" value="mounted"/> <INFO name="mediaID" value="041 32"/> <INFO name="firmwareVersion" value="4AP0"/>

</DRIVEINFO>

</RESPONSE>

StorNext API Guide 37

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

C++ Class Declaration 2

class GetDriveList : public Request { public:

/// Default Contructor GetDriveList();

/// Method to return the drive information const std::vector<DriveInfo>& getDriveInfo() const;

/// Method to return the local status const Status& getLocalStatus() const;

} class DriveInfo : virtual public Info

{ public:

/// Primary Constructor DriveInfo(const std::string& inName="",

const std::string& inState="", const std::string& inSerialNumber="", const std::string& inType="", const std::string& inMountState="", const std::string& inMediaID="", const std::string& inFirmwareVersion="");

/// Method to retrieve the name of the drive const std::string& getName() const;

/// Method to retrieve the state of the drive const std::string& getState() const;

/// Method to retrieve the serial number of the drive const std::string& getSerialNumber() const;

/// Method to retrieve the type of the drive const std::string& getType() const;

/// Method to retrieve the mount-state of the drive const std::string& getMountState() const;

/// Method to retrieve the media ID the drive contains, if any. const std::string& getMediaID() const;

StorNext API Guide 38

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

/// Method to retrieve the firmware version currently loaded on the dr ive const std::string& getFirmwareVersion() const;

/// Method to deflate this object for client-server transmision std::string deflate() const;

/// Method to restore this object from a deflated string void inflate(std::string& inDeflatedObject);

}

GetFileAttribute 2

This API returns attribute information for the specified file, which is located in either primary storage or secondary storage (tape or storage disk). See the Output section for complete details on the information retrieved.

Input

filename: The file's pathname.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

filename: The file name. location: DISK, TAPE, or DISK AND TAPE.

policyClass: The name of the policy class associated with the specified

file.

numberExistingCopies: The number of existing copies. Valid values are 1 to [numberTargetCopies].

numberTargetCopies: The number of total copies.

mediaID: The media ID where the copy resides. There could be a list of

media IDs.

StorNext API Guide 39

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

XML Example 2

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="GetFileAttribute">

<ARGUMENT name="fileName" value="/snfs/myDirectory/myFile.dat"/>

</COMMAND>

Response: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="GetFileAttribute" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<FILEINFO statusCode="0" status="SUCCESS"

statusDescription="Command Successful">  <INFO name="filename" value="/snfs/myDirectory/myFile.dat"/> <INFO name="location" value="TAPE"/> <INFO name="policyClass" value="policyclass1"/> <INFO name="numberExistingCopies" value="1"/> <INFO name="numberTargetCopies" value="1"/> <INFO name="mediaID" value="000001"/>

</FILEINFO>

</RESPONSE>

C++ Class Declaration: 2

class GetFileAttribute : public Request { public:

/// Primary Constructor /// This constructor is intended for primary instantiation of the obje ct, /// providing it the filename GetFileAttribute(const std::string& filename);

StorNext API Guide 40

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

/// Copy constructor GetFileAttribute(const GetFileAttribute& obj);

/// Destructor virtual ~GetFileAttribute();

/// Assignment Operator GetFileAttribute& operator=(const GetFileAttribute& obj);

/// Method to reset object with new filename void reset(const std::string& filename);

/// Method to return the file information const FileInfo& getFileInfo() const;

/// Method to return the local status pair const StatusPair& getLocalStatus() const;

}

class FileInfo : virtual public Info { public:

/// Location values enum Location { unknown=0, disk, tape, diskandtape, };

/// Default and Primary Constructor /// This can construct from a single mediaID string. FileInfo(const std::string& inName="",

const Location& inLocation=unknown, const std::string& inPolicyClass="", const int32_t& inNumberOfExistingCopies=0, const int32_t& inNumberOfTargetCopies=0, const std::string& inMediaID="");

StorNext API Guide 41

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

/// Secondary Constructor /// This constructs from a vector of mediaID. FileInfo(const std::string& inName,

const Location& inLocation, const std::string& inPolicyClass, const int32_t& inNumberOfExistingCopies, const int32_t& inNumberOfTargetCopies, const MediaList& inMedia);

/// Method that retrieves the file name. const std::string& getFileName() const;

/// Method that retrieves the file location. const Location& getLocation() const;

/// Method that retrieves the file location (as string). const std::string& getLocationAsString() const;

/// Method that retrieves the file's policy class. const std::string& getPolicyClass() const;

/// Method that retrieves the number of existing copies of the file. int32_t getNumberOfExistingCopies() const;

/// Method that retrieves the number of target copies of the file. int32_t getNumberOfTargetCopies() const;

/// Method that retrieves the collection of media IDs. const MediaList& getMedia() const;

/// Method to deflate this object for client-server transmision std::string deflate() const;

/// Method to restore this object from a deflated string void inflate(std::string& inDeflatedObject);

}

StorNext API Guide 42

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

GetFileTapeLocationI 2

This API returns location information for the specified file, including the copy ID, segment number, starting block, and segment size. See the Output section for complete details about the information returned.

Input

filename: The file’s pathname. copyID: Indicates which copy from which to get segment information.

The default value is 1, the primary copy.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

filename: The file name. copyID: The copy ID. segment: The segment number. (There can be multiple segments.) mediaID: The media ID where this segment resides. archiveID: The archive ID where the media belongs.

startBlock: The starting block. offset: The offset from startBlock. segmentSize: The segment size. blockSize: The media block size.

Note: The file's data can be located by startBlock and offset. Then

segsize will tell the amount of data to be read. blksize is

required for doing a correct read operation; otherwise, enough data might not be read when reading a block. Both StorNext and AMASS tape formats are supported by this API.

StorNext API Guide 43

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

XML Example 2

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="GetFileTapeLocation">

<ARGUMENT name="fileName" value="/snfs/myDirectory/myFile.dat"/> <ARGUMENT name="copyID" value="1"/>

</COMMAND>

Response: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="GetFileTapeLocation" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<LOCATIONINFO statusCode="0" status="SUCCESS"

statusDescription="Command Successful"> <INFO name="fileName" value="/stornnnnext/snfs1/d1/regfile" /> <INFO name="copyID" value="1" /> <SEGMENTINFO name="segmentNumber" value="1">

StorNext API Guide 44

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

</LOCATIONINFO>

</RESPONSE>

C++ Class Declaration 2

class GetFileTapeLocation : public Request { public:

/// Primary Constructor /// This constructor is intended for primary instantiation of the object, /// providing it the filename GetFileTapeLocation(const std::string& filename,

const int16_t& copyid = 1);

/// Method to set the copy id. void setCopyID(const int16_t inCopyID);

/// Method to return the location info const LocationInfo& getLocationInfo() const;

/// Method to return the local status pair const StatusPair& getLocalStatus() const;

}

class LocationInfo : virtual public Info { public:

/// Primary Constructor LocationInfo(const std::string& inName="",

const int16_t& inCopyID=1);

/// Method that set the file name void setFileName(const std::string& filename);

/// Method that set the copy id void setCopyID(const int16_t& copyid);

StorNext API Guide 45

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

/// Method that retrieves the file name. const std::string& getFileName() const;

/// Method that retrieves the file location. const int16_t& getCopyID() const;

/// Method that add a segment info to the segment list void addSegment(const SegmentInfo& seginfo);

/// Method that retrieves the collection of segment locations const std::vector<SegmentInfo>& getSegmentList() const;

/// Method to deflate this object for client-server transmision std::string deflate() const;

/// Method to restore this object from a deflated string void inflate(std::string& inDeflatedObject);

}

GetMediaList 2

This API returns either a list of media IDs or the number of media that meets the specified criteria.

Input arguments within brackets {} must be entered explicitly as shown. For example, when entering the argument for the format argument, you must enter “count” or “list” (without the quotation marks).

All arguments are optional. If you do not specify any arguments, the total number of media is returned.

Input

format: {count or list} location: {archive, vault, checkout, or unknown} If no argument is

specified, archive is used as the default value.

archiveID: The archive ID. classification: {data, backup, or cleaning} availability: {available or unavailable} writeAccess: {writeProtected or notWriteProtected}

StorNext API Guide 46

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

integrity: {suspect or notSuspect} space: {full or blank} percentUsed: The percentage of media space used, from 0.00 to 100.00. copyID: The number of the copy used, from 1 - 8.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

location: archive, vault, checkout, or unknown. archiveID: The archive ID. classification: data, backup, or cleaning. availability: available or unavailable. writeAccess: writeProtected or notWriteProtected. integrity: suspect or notSuspect. space: full or blank. count: The number of media that meet the specified criteria. medialist: A list of media that meet the specified criteria.

Note: Output will include either count or list (not both), depending

on what you specified as an input argument. Output will also repeat the selection criteria specified by the input.

XML Example

The following example illustrates how to return the number of blank media for a given archive.

Request Example 1:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="GetMediaList">

StorNext API Guide 47

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

<ARGUMENT name="format" value="count"/> <ARGUMENT name="location" value="archive"/> <ARGUMENT name="availability" value="available"/>

</COMMAND>

Response Example 1:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="GetMediaList" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<MEDIALIST statusCode="0" status="SUCCESS"

statusDescription="Command Successful"> <INFO name="location" value="archive"/> <INFO name="availability" value="available"/> <INFO name="count" value="6"/>

</MEDIALIST>

</RESPONSE>

Request Example 2: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <COMMAND name="GetMediaList">

</COMMAND>

Response Example 2:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="GetMediaList" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

StorNext API Guide 48

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

<MEDIALIST statusCode="0" status="SUCCESS"

statusDescription="Command Successful"> <INFO name="location" value="archive"/> <INFO name="availability" value="available"/> <INFO name="mediaID" value="000001"/> <INFO name="mediaID" value="000002"/> <INFO name="mediaID" value="000003"/> <INFO name="mediaID" value="000004"/> <INFO name="mediaID" value="000005"/> <INFO name="mediaID" value="000006"/>

</MEDIALIST>

</RESPONSE>

Request Example 3: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <COMMAND name="GetMediaList">

</COMMAND>

Response Example 3: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="GetMediaList" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<MEDIALIST statusCode="0" status="SUCCESS"

statusDescription="Command Successful"> <INFO name="archiveID" value="scsi_archive1" /> <INFO name="space" value="blank" /> <INFO name="count" value="3" />

</MEDIALIST>

</RESPONSE>

C++ Class Declaration 2

class GetMediaList : public Request { public:

/// Output format values enum Format { count=0, list };

/// Location values used as selection criteria

StorNext API Guide 49

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

enum Location { archive=0, vault, checko u t, un kn ow n };

/// Classification values used as selection criteria enum Classification { data=0, backup, cleaning };

/// Availability values used as selection criteria enum Availability { available=0, unavailable };

/// Write access values used as selection criteria enum WriteAccess { writeProtected=0, notWriteProtected };

/// Integrity values used as selection criteria enum Integrity { suspect=0, notSuspect };

/// Space values used as selection criteria enum Space { blank=0, partial, full };

/// Default Constructor (format de faults to count) GetMediaList();

/// Primary Constructor /// Note: This constructor will be deprecated in a future release. GetMediaList(const Format& inFormat,

const Location& inLocation, const std::string& inArchiveID, const Classification& inClassification, const Availability& inAvailability, const WriteAccess& inWriteAccess, const Integrity& inIntegrity, const Space& inSpace);

/// Set the output format for the media list. void setFormat(const Format& inFormat);

/// Set the location for the media selection criteria. void setLocation(const Location& inLocation);

/// Set the archive ID for the media selection criteria. void setArchiveID(const std::string& inArchiveID);

StorNext API Guide 50

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

/// Set the classification for the media selection criteria. void setClassification(const Classification& inClassification);

/// Set the availability for the media selection criteria. void setAvailability(const Availability& inAvailability);

/// Set the write access for the media selection criteria. void setWriteAccess(const WriteAccess& inWriteAccess);

/// Set the integrity for the media selection criteria. void setIntegrity(const Integrity& inIntegrity);

/// Set the space for the media selection criteria. void setSpace(const Space& inSpace);

/// Set the percentUsed for the media selection criteria. void setPercentUsed(const float inPercentUsed);

/// Set the copyID for the media selection criteria. void setCopyID(const int32_t inCopyID);

/// Return the output format specified for the media list. const Format& getFormat() const;

/// Return the media location selection criteria const Location& getLocation() const;

/// Return the media archive ID selection criteria const std::string& getArchiveID() const;

/// Return the media classification selection criteria const Classification& getClassification() const;

/// Return the media availability selection criteria const Availability& getAvailability() const;

/// Return the media write access selection criteria const WriteAccess& getWriteAccess() const;

/// Return the media integrity selection criteria

StorNext API Guide 51

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

const Integrity& getIntegrity() const;

/// Return the media space selection criteria const Space& getSpace( ) const;

/// Return the media percentUsed selection criteria const float getPercentUsed() const;

/// Return the media copyID selection criteria const int32_t getCopyID() const;

/// Return the media list output format as a string. const std::string& getFormatAsString() const;

/// Return the media location selection criteria as a string type. const std::string& getLocationAsString() const;

/// Return the media archive id selection criteria as a string type. const std::string& getArchiveIDAsString() const;

/// Return the media classification selection criteria as a string type. const std::string& getClassificationAsString() const;

/// Return the media availability selection criteria as a string type. const std::string& getAvailabilityAsString() const;

/// Return the media write access selection criteria as a string type. const std::string& getWriteAccessAsString() const;

/// Return the media integrity selection criteria as a string type. const std::string& getIntegrityAsString() const;

/// Return the media space selection criteria as a string type. const std::string& getSpaceAsString() const;

/// Method to return the count of Media int32_t getMediaCount() const;

/// Method to return the list of Media const std::vector<std::string>& getMediaList() const;

StorNext API Guide 52

Chapter 2 StorNext Storage Manager APIs

/// Method to return the local status const Status& getLocalStatus() const;

}

API Descriptions and Arguments

GetMediaStatus 2

This API returns status for the specified piece of media. See the Output section for complete details on the information retrieved.

Input

mediaID: The media ID. There could be a list of media IDs.

Output

location: The current state for the specified media ID: CHECKOUT,

INTRANSIT, or UNKNOWN

writeProtected: Y or N. status: AVAIL or UNAVAIL. spaceUsed: The amount of used space in bytes. spaceFree: The amount of free space in bytes. classification: Media classification: DATA, BACKUP, or CLEANING. mediaID: The media ID.

policyClass: The policy class associated with the media.

location: Archive name.

type: The media type. writeProtected: Y or N. mountCount: The number of mounts. status: AVAIL or UNAVAIL. suspectCount: The total number of times media was marked as suspect. spaceUsed: The amount of used space in bytes. spaceFree: The amount of free space in bytes. percentUsed: The percentage of space used.

StorNext API Guide 53

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

XML Example 2

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="GetMediaStatus">

</COMMAND>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="GetMediaStatus" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<MEDIAINFO statusCode="0" status="SUCCESS"

statusDescription="Command Successful">       <INFO name="mediaID" value="025311"/> <INFO name="policyClass" value="policyclass1"/> <INFO name="location" value="Andromeda"/> <INFO name="type" value="L TO"/> <INFO name="writeProtected" value="N"/> <INFO name="mountCount" value="13"/> <INFO name="status" value="AVAIL"/> <INFO name="suspectCount" value="0"/> <INFO name="spaceUsed" value="6,442,451,356"/> <INFO name="spaceFree" value="191,973,294,080"/> <INFO name="percentUsed" value="3.25"/> <INFO name="

</MEDIAINFO>

</RESPONSE>

StorNext API Guide 54

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

C++ Class Declaration: 2

class GetMediaStatus : public Request { public:

/// Primary Constructor /// This constructor is intended for primary instantiation of the object, /// providing it the mediaId GetMediaStatus(const std::string& inMediaID);

/// Constructor from a list of media /// This constructor is intended to create the request from a list of media GetMediaStatus(const MediaList& inMedia);

/// Method to return a MediaInfo for a specific media MediaInfo getMediaInfo(const std::string& inMediaID);

/// Method to return list of media info /// The media info list contains only the good media results. const std::vector<MediaInfo>& getMediaInfo() const;

/// Method to return the list of status pairs const StatusPairList& getLocalStatus() const;

/// Method to return a specific status pair for a given mediaID const StatusPair& getLocalStatus(const std::string& mediaID) const;

} class MediaInfo : virtual public Info

{ public:

/// Default and Primary Constructor MediaInfo(const std::string& inMediaID="unknown",

const std::string& inPolicyClass="unknown", const std::string& inLocation="unknown", const std::string& inType="unknown", const std::string& inWriteProtected="unknown", const uint32_t inMountCount=0, const std::string& inStatus="unknown", const uint32_t inSuspectCount=0, const std::string& lastAccessTime="unknown", const uint64_t inSpaceUsed=0, const uint64_t inSpaceFree=0, const float inPercentUsed=0,

StorNext API Guide 55

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

const std::string& inClassification="unknown");

/// Method to return the media ID const std::string& getMediaID() const;

/// Method to return the media policy class const std::string& getPolicyClass() const;

/// Method to return the media location const std::string& getLocation() const;

/// Method to return the media type const std::string& getType() const;

/// Method to return flag indicating if the media is write-protected const std::string& getWriteProtected() const;

/// Method to return the mount count for the media const uint32_t getMountCount() const;

/// Method to return the media status const std::string& getStatus() const;

/// Method to return the total number of times the media was marked /// suspect due to errors. const uint32_t getSuspectCount() const;

/// Method to return the media last access time const std::string& getLastAccessTime() const;

/// Method to return the amount of space used on the media const uint64_t getSpaceUsed() const;

/// Method to return the amount of free space on the media const uint64_t getSpaceFree() const;

/// Method to return the percentage of space used on the media const float getPercentUsed() const;

/// Method to return the classification of media (backup, data, clean, etc.) const std::string& getClassification() const;

/// Method to deflate this object for client-server transmision std::string deflate() const;

StorNext API Guide 56

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

/// Method to restore this object from a deflated string void inflate(std::string& inDeflatedObject);

}

GetPolicy 2

This API retrieves the specified policy.

Input

policyClass: The desired policy class. Enter a valid policy class name or

all to retrieve all policy classes.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

policyClass: The policy class name(s). numberCopies: The number of copies currently maintained for the policy

class.

maxInactiveVersions: The maximum number of versions currently

maintained for the policy class.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="GetPolicy">

<ARGUMENT name="policyClass" value="mypolicyclass"/>

</COMMAND>

StorNext API Guide 57

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

Response: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="GetPolicy" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<POLICYINFO statusCode="0" status="SUCCESS"

statusDescription="Command Successful"> <INFO name="policyClass" value="mypolicyclass"/> <INFO name="numberCopies" value="2"/> <INFO name="maxInactiveVersions" value="10"/>

</POLICYINFO>

</RESPONSE>

C++ Class Declaration

class GetPolicy : public Request { public:

/// Default Contructor GetPolicy(const std::string& inPolicyClass="all");

/// Method to return the list of PolicyInfo objects const std::vector<PolicyInfo>& getPolicyInfo() const;

/// Method to return a specific PolicyInfo object const PolicyInfo& getPolicyInfo(const std::string& inPolicyClass) const;

/// Method to return the list of status pairs const StatusPairList& getLocalStatus() const;

/// Method to return a specific status pair for a given policy class const StatusPair& getLocalStatus(const std::string& inPolicyClass) const;

} class PolicyInfo : virtual public Info

{ public:

/// Primary constructor PolicyInfo(const std::string& inClassName,

const int32_t& inNumberOfCopies, const int32_t& inMaxInactiveVersions);

/// Method to return the policy classname.

StorNext API Guide 58

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

const std::string& getPolicyClassName() const; /// Method to return the number of copies to make.

const int32_t& getNumberOfCopies() const; /// Method to return the maximum inactive versions to keep.

const int32_t& getMaxInactiveVersions() const; /// Method to deflate this object for client-server transmision

std::string deflate() const; /// Method to restore this object from a deflated string

void inflate(std::string& inDeflatedObject);

}

GetPortList 2

This API retrieves the import/export port IDs for a specified archive. An archive can have multiple ports. (Vaults do not have a port, so the ID is always 0.)

Input

archiveID: The ID of the archive whose import/export port information

you want to retrieve.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

portID: The port number.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="GetPortList">

StorNext API Guide 59

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

<ARGUMENT name="archiveID" value="scsi_archive1"/>

</COMMAND>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="GetPortList" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">  <PORTINFO statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

</PORTINFO>

</RESPONSE>

C++ Class Declaration

class GetPortList : public Request { public:

/// Primary Constructor GetPortList(const std::string& inArchiveId);

/// Method to return the port IDs const std::vector<PortInfo>& getPortInfo() const;

/// Method to return the local status const Status& getLocalStatus() const;

}

class PortInfo : virtual public Info { public:

/// Default and Primary Constructor PortInfo(const int16_t& inPortID=0);

/// Method to return the port ID for the archive.

StorNext API Guide 60

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

int16_t getPortID() const;

/// Method to set the port ID for the archive void setPortID(const int16_t& inPortID);

/// Method to deflate this object for client-server transmision std::string deflate() const;

/// Method to restore this object from a deflated string void inflate(std::string& inDeflatedObject);

}

GetSchedule 2

This API provides information about previously scheduled events such as backups.

Input

scheduleType: BACKUP

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

scheduleType: The type of schedule (e.g., BACKUP) scheduleTime: Time the scheduled event is set to run, in 24-hour format:

HH:MM.

scheduleLastAttempt: Time the scheduled event last attempted to run. scheduleLastStatus: Status of the last scheduled event attempt:

SUCCESSFULL, RUNNING, LOCKED, TERMINATED, or FAILED.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>

StorNext API Guide 61

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

<ARGUMENT name="scheduleType" value="backup"/>

</COMMAND>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="GetSchedule" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<SCHEDULEINFO statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<INFO name="scheduleType" value="backup"/> <INFO name="scheduleTime" value="23:30"/> <INFO name="scheduleLastAttempt" value="Jul 9,2005 00:30"/> <INFO name="scheduleLastStatus" value="Successful"/>

</SCHEDULEINFO>

</RESPONSE>

C++ Class Declaration 2

class GetSchedule : public Request { public:

/// Default and Primary Constructor GetSchedule(const std::string& inScheduleTy pe="backup");

/// Method to return the ScheduleInfo const ScheduleInfo& getScheduleInfo() const;

/// Method to return the local status. const Status& getLocalStatus() const;

} class ScheduleInfo : virtual public Info

{ public:

/// State Values

StorNext API Guide 62

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

static const std::string unknown; /// Default and Primary Constructor

ScheduleInfo(const std::string& inType=unknown,

const std::string& inRunTime=unknown, const std::string& inLastAttempt=unknown, const std::string& inLastStatus=unknown, const std::string& inPeriod=unknown, const std::string& inDay=unknown);

/// Method to return the type of the schedule. const std::string& getType() const;

/// Method to return the run time of the schedule. const std::string& getRunTime() const;

/// Method to return the last attempted run time of the schedule. const std::string& getLastAttempt() const;

/// Method to return the status of last attempted run of the sched u le. const std::string& getLastStatus() const;

/// Method to return the period of the schedule. const std::string& getPeriod() const;

/// Method to return the day of the schedule. const std::string& getDay() const;

/// Method to set the type of the schedule. void setType(const std::string& inType);

/// Method to set the run time of the schedule. void setRunTime(const std::string& inRunTime);

/// Method to set the last attempted run time of the schedule. void setLastAttempt(const std::string& inLastAttempt);

/// Method to set the status of last attempted run of the sch e du le. void setLastStatus(const std::string& inLastStatus);

/// Method to set period (daily/weekly/monthly) the of the schedule. void setPeriod(const std::string& inPeriod);

StorNext API Guide 63

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

/// Method to set the day of the schedule. void setDay(const std::string& inWeekDay);

/// Method to deflate this object for client-server transmision std::string deflate() const;

/// Method to restore this object from a deflated string void inflate(std::string& inDeflatedObject);

}

GetSystemStatus 2

This API provides the current system status.

Input

NA. This API has no command arguments.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

version: The current StorNext software version number. systemState: The overall system status. tsm: The current TSM state (ONLINE or OFFLINE). msm: The current MSM state (ONLINE or OFFLINE). dsm: The current DSM state (ONLINE or OFFLINE). database: The current database state (ONLINE or OFFLINE). svclog: The current service log state (ONLINE or OFFLINE).

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="GetSystemStatus"/>

StorNext API Guide 64

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

Response: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="GetSystemStatus" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<SYSTEMINFO statusCode="0" status="SUCCESS"

statusDescription="Command Successful"> <INFO name="version" value="2.7.0(18)"/>   <INFO name="systemState" value="online"/> <INFO name="tsm" value="online"/> <INFO name="msm" value="online"/> <INFO name="dsm" value="online"/> <INFO name="database" value="online"/> <INFO name="svclog" value="online"/>

</SYSTEMINFO>

</RESPONSE>

C++ Class Declaration 2

class GetSystemStatus : public Request { public:

/// Default and Primary Constructor GetSystemStatus();

/// Method to return the system information const SystemInfo& getSystemInfo() const;

/// Method to return the local status const Status& getLocalStatus() const;

} class SystemInfo : virtual public Info

{ public:

/// Component Values enum Component { system=0, database, dsm, msm,

StorNext API Guide 65

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

svclog, tsm, };

/// State Values static const std::string unknown; static const std::string online; static const std::string offline;

/// Default and Primary Constructor SystemInfo(const std::string& inSystemVersion=unknown,

const std::string& inSystemState=unknown, const std::string& inTsmState=unknown, const std::string& inMsmState=unknown, const std::string& inDsmState=unknown, const std::string& inDatabaseState=unknown, const std::string& inSvclogState=unknown);

/// Method to return the version of the system const std::string& getSystemVersion() const;

/// Method to return the state of the specified component const std::string& getState(const Component& inComponent) const;

/// Method to set the system version. void setSystemVersion(const std::string& inSystemVersion);

/// Method to set the state of the specified componen t. void setState(const Component& inComponent, const std::string& inState);

/// Method to deflate this object for client-server transmision std::string deflate() const;

/// Method to restore this object from a deflated string void inflate(std::string& inDeflatedObject);

}

MoveMedia 2

This API logically marks a media to move from one archive to another. It does not do the physical moving. In order to both physically and logically move a media between two archives, you must take three steps:

1 Call MoveMedia.

StorNext API Guide 66

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

2 Call EjectMedia to physically move the media to the mailbox at the

source archive.

3 Call EnterMedia to physically move the media from mailbox into the

destination archive.

Note: If the media is entered or ejected from a vault, EjectMedia and

EnterMedia are logical operations.

Input

mediaID: The media ID to move. destArchiveID: The destination archive ID to move to.

Note: Both of these arguments are required.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="MoveMedia">

<ARGUMENT name="mediaID" value="000455"/> <ARGUMENT name="destArchiveID" value="vault1"/>

</COMMAND>

StorNext API Guide 67

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

Response: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="MoveMedia" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STATUSDETAIL name="mediaID" value="000455"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

</RESPONSE>

PassThru 2

C++ Class Declaration

class MoveMedia : public Request { public:

/// Primary Constructor /// This constructor is intended for primary instantiation of the object, /// given a destination archive ID and a single media ID. MoveMedia(const std::string& inMediaID,

const std::string& inDestArchiveID);

/// Method to return the local status pair const StatusPair& getLocalStatus() const;

}

This API executes the specified command line argument. The PassThru

API supports running only one CLI command at a time. You cannot

string together multiple concatenated commands (e.g. ls /tmp/; ls /var/ tmp/; cd /tmp/).

Input

commandString: The command you want to execute from the command line (e.g., ls -laF /tmp /)

StorNext API Guide 68

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

Output 2

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

Any response for the executed command.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="PassThru">

<ARGUMENT name="commandString" value="ls -laF /tmp"/>

</COMMAND>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="PassThru" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STRINGINFO statusCode="0" status="SUCCESS"

</STRINGINFO>

</RESPONSE>

C++ Class Declaration

class PassThru : public Request {

StorNext API Guide 69

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

public:

/// Primary Constructor /// This constructor is intended for primary instantiation of the object, /// given a command string. PassThru(const std::string& inCommand);

/// Method to return the passthru command string const std::string& getCommandString() const;

/// Method to return the results of the passthru command const std::string& getCommandResults() const;

/// Method to return the local status pair const StatusPair& getLocalStatus() const;

}

RmDiskCopy 2

This API removes the disk copy of the specified file through explicit truncation.

Input

filename: The pathname of the file whose on-disk copy will be removed.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="RmDiskCopy">

StorNext API Guide 70

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

<ARGUMENT name="fileName" value="/snfs/myDirectory/myFile.dat"/>

</COMMAND>

Response: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="RmDiskCopy" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STATUSDETAIL name="filename" value="/snfs/myDirectory/myFile.dat"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

</RESPONSE>

C++ Class Declaration 2

class RmDiskCopy : public Request { public:

/// Primary Constructor /// This constructor is intended for primary instantiation of the object, /// given a single filename. RmDiskCopy(const std::string& filename);

/// Method to return the local status pair const StatusPair& getLocalStatus() const;

}

SetArchiveState 2

This API allows you to set the archive state to ON or OFF.

Input

archiveName: The name of the archive for which you want to set the

state.

state: ON or OFF.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

StorNext API Guide 71

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

XML Example 2

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="SetArchiveState">

<ARGUMENT name="archiveName" value="Andromeda"/> <ARGUMENT name="state" value="ON"/>

</COMMAND>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="SetArchiveState" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STATUSDETAIL name="archiveName" value="Andromeda"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

</RESPONSE>

C++ Class Declaration 2

class SetArchiveState : public Request { public:

/// State values enum StateType { ONLINE=0, OFFLINE };

/// Primary Constructor /// This constructor is intended for primary instantiation of the /// object, providing it the archive name and state. SetArchiveState(const std::string& inArchiveName,

StorNext API Guide 72

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

const StateType& inArchiveState );

/// Method to return the archive name const std::string& getArchiveName() const;

/// Method to return the archive state const StateType& getArchiveState() const;

/// Method to return the archive state as a string const std::string& getArchiveStateAsString() const;

/// method to return the local status const Status& getLocalStatus() const;

}

SetDirAttributes 2

This API allows you to set the following directory attributes:

• store (enable or disable)

• truncate (enable or disable)

• policy class name for the directory

Input

directoryName: The name of the directory for which you want to set

attributes.

noTruncate: TRUE or FALSE. noStore: TRUE or FALSE. policyClass: The name of the policy class you want to apply to the

directory.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

StorNext API Guide 73

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

XML Example 2

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="SetDirAttributes">

<ARGUMENT name="directoryName" value="/snfs/mydirectory"/> <ARGUMENT name="noTruncate" value="TRUE"/> <ARGUMENT name="noStore" value="TRUE"/> <ARGUMENT name="policyClass" value="mypolicyclass"/>

</COMMAND>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="SetDirAttributes" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STATUSDETAIL name="directoryName" value="/snfs/mydirectory"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

</RESPONSE>

C++ Class Declaration 2

class SetDirAttributes : public Request { public:

/// Primary Constructor

StorNext API Guide 74

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

/// This constructor is intended for primary instantiation of the object, /// providing it the directory name, policy class, truncate, and store /// settings. /// the state SetDirAttributes(const std::string& inDirectoryName,

const std::string& inPolicyClass, const bool& inNoTruncate, const bool& inNoStor e);

/// Secondary Constructor /// This constructor is a secondary means to instantiate the object, /// the state SetDirAttributes(const std::string& inDirectoryName);

/// Method to return the directory name const std::string& getDirectoryName() const;

/// Method to return the policy class const std::string& getPolicyClass() const;

/// Method to return the noTruncate flag bool getNoTruncateFlag() const;

/// Method to return the noStore flag bool getNoStoreFlag() const;

/// Method to return the local status const StatusPair& getLocalStatus() const;

}

SetDriveState 2

This API allows you to set the drive state to ON or OFF.

Input

drivename: The name of the drive whose state you want to set. state: ON or OFF.

StorNext API Guide 75

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

Output 2

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="SetDriveState">

<ARGUMENT name="drivename" value="lto2-001"/> <ARGUMENT name="state" value="ON"/>

</COMMAND>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="SetDriveState" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STATUSDETAIL name="drivename" value="Andromeda_LTO_Drive1"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

</RESPONSE>

C++ Class Declaration 2

class SetDriveState : public Request { public:

/// Drive state values. enum DriveState { ON = 0, OFF

StorNext API Guide 76

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

}; /// Primary Constructor

/// This constructor is intended for primary instantiation /// of the object, providing it the drive name and state. SetDriveState(const std::string& inDriveName,

const DriveState& inDriveState);

/// Method to return the drivename std::string getDrivename() const;

/// Method to return the drive state DriveState getDriveState() const;

/// Method to return the drive state as a string std::string getDriveStateAsString() const;

/// Method to return the local status pair const StatusPair& getLocalStatus() const;

}

SetFileAttributes 2

This API allows you to set the following attributes for a file:

• store (enable or disable)

• truncate (enable or disable)

Input

fileName: The name of the file for which you want to set attributes. noStore: TRUE or FALSE. noTruncate: TRUE or FALSE.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

StorNext API Guide 77

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

XML Example 2

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="SetFileAttributes">

<ARGUMENT name="fileName" value="/snfs/myDirectory/myFile.dat"/> <ARGUMENT name="noTruncate" value="TRUE"/> <ARGUMENT name="noStore" value="TRUE"/>

</COMMAND>

Response: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="SetFileAttributes" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STATUSDETAIL name="filename" value="/snfs/myDirectory/myFile.dat"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

</RESPONSE>

C++ Class Declaration 2

class SetFileAttributes : public Request { public:

/// Primary Constructor /// This constructor is intended for primary instantiation of the object, /// providing it the file name, notruncate, and nost or e at trib u te s to be /// set for the file. SetFileAttributes(const std::string& inFileName,

const bool& inNoTruncate,

StorNext API Guide 78

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

const bool& inNoStore);

/// Secondary Constructor /// This constructor is a secondary means to instantiate the object, SetFileAttributes(const std::string& inFileName);

/// Method to return the fileName const std::string& getFileName() const;

/// Method to return the noTruncate flag bool getNoTruncateFlag() const;

/// Method to return the noStore flag bool getNoStoreFlag() const;

/// Method to return the local status const StatusPair& getLocalStatus() const;

}

SetMediaState 2

This API allows you to set the state for one or more piece of media.

Input

state: AVAIL (available), UNAVAIL (not available), PROTECT (write protected), UNPROTECT (not write protected), UNMARK (not marked), or UNSUSP (not suspect).

mediaID: The ID of the media whose state you want to set. When entering

multiple media IDs, enter one media ID per line.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code for each media ID entered.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>

StorNext API Guide 79

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

<COMMAND name="SetMediaState">

<ARGUMENT name="state" value="avail"/> <ARGUMENT name="mediaID" value="025311"/> <ARGUMENT name="mediaID" value="025312"/>

</COMMAND>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="SetMediaState" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STATUSDETAIL name="mediaID" value="025311"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

<STATUSDETAIL name="mediaID" value="025312"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

</RESPONSE>

C++ Class Declaration 2

class SetMediaState : public Request { public:

/// Media State values enum MediaState {

MEDIA_STATE_TYPE_START=0, AVAIL=MEDIA_STATE_TYPE_START, UNAVAIL, PROTECT, UNPROTECT,

StorNext API Guide 80

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

UNMARK, UNSUSP, MEDIA_STATE_TYPE_END

}; /// Primary Constructor

/// This constructor is intended for primary instantiation of the object, /// providing it the media name and state. SetMediaState(const std::string& inMediaID,

const MediaState& inState);

/// Secondary Constructor /// This constructor is intended for instantiation of the object fro m a /// vector of media ids SetMediaState(const MediaList& inMedia,

const MediaState& inState);

/// Method to retrieve the map of mediaIDs to their status' std::map<std::string, Status> getMediaMap() const;

/// Method to return the media state const MediaState& getMediaState() const;

/// Method to return the media state as a string const std::string& getMediaStateAsString() const;

/// Method to return the list of media MediaList getMediaList() const;

/// Method to return the list of local status pairs const StatusPairList& getLocalStatus() const;

/// Method to return the specific local status pair for a given mediaID const StatusPair& getLocalStatus(const std::string& mediaID) const;

}

SetPolicy 2

StorNext API Guide 81

This API allows you to set the number of copies and the maximum number of inactive versions for a policy class.

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

Input 2

policyClass: The name of the policy class for which you want to set arguments, or enter “all” to apply arguments to all policy classes.

numberOfCopies: The number of copies to maintain for the policy class. maxInactiveVersions: The maximum of versions to maintain for the

policy class.

Note: You must enter one policy class name. You can enter either the

number of copies, the maximum number of versions, or both arguments.

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>  <COMMAND name="SetPolicy">

<ARGUMENT name="policyClass" value="mypolicyclass"/> <ARGUMENT name="numberOfCopies" value="2"/> <ARGUMENT name="maxInactiveVersions" value="10"/>

StorNext API Guide 82

</COMMAND>

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="SetPolicy" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STATUSDETAIL name="policyClass" value="all"

statusCode="0" status="SUCCESS" statusDescription="Command Successful"/>

</RESPONSE>

C++ Class Declaration

class SetPolicy : public Request { public:

/// Primary Constructor /// This constructor is intended for primary instantiation of the object. SetPolicy(const std::string& inPolicyClass,

const uint32_t inNumberOfCopies, const uint32_t inMaxInactiveVersions);

/// Secondary Constructor /// This constructor is a secondary means to instantiate the object. SetPolicy(const std::string& inPolicyClass);

/// Get the policy class name const std::string& getPolicyClass() const;

/// Get the number of copies uint32_t getNumberOfCopies() const;

/// Get the maximum inactive versions uint32_t getMaxInactiveVersions() const;

/// Return the list of local status pairs. const StatusPairList& getLocalStatus() const;

/// Return a specific local status pair for a given policy class const StatusPair& getLocalStatus(const std::string& inPolicyClass) const;

}

StorNext API Guide 83

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

SetSchedule 2

This API allows you to specify a schedule for a backup. Running this API affects only system default full backups and default partial backups, not any user-configured backup events.

Input

scheduleType: BACKUP or other scheduled event type. timeOfDay: The time the scheduled event begins, in 24-hour format

(HH:MM).

Output

status: SUCCESS, FAILURE, SUBFAILURE, or SYNTAXERROR status

code.

XML Example

Request: 2

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?>   <COMMAND name="SetSchedule">

<ARGUMENT name="scheduleType" value="backup"/> <ARGUMENT name="timeOfDay" value="23:59"/>

</COMMAND>

Response:

<?xml version="1.0" encoding="UTF-8" standalone="yes" ?> <RESPONSE name="SetSchedule" statusCode="0" status="SUCCESS"

statusDescription="Command Successful">

<STATUSDETAIL name="scheduleType" value="backup"

statusCode="0" status="SUCCESS"

StorNext API Guide 84

Chapter 2 StorNext Storage Manager APIs

API Descriptions and Arguments

statusDescription="Command Successful"/>

</RESPONSE>

C++ Class Declaration 2

class SetSchedule : public Request { public:

/// Enumerator for the schedule types enum ScheduleType {backup=0};

/// Primary Constructor /// schedule type. SetSchedule(const ScheduleType& inScheduleType,

const std::string& inTimeOfDay);

/// Return the string associated to a ScheduleType static std::string getTypeString(const ScheduleType& inType);

/// Return the schedule type const ScheduleType& getScheduleType() const;

/// Return the scheduled time-of-day const std::string& getScheduleTimeOfDay() const;

/// Return the local status const Status& getLocalStatus() const;

}

StorNext API Guide 85

Chapter 3

3StorNext File System APIs

This chapter describes the Application Programming Interfaces (APIs) that are available for StorNext File System. These file system APIs are automatically installed with the StorNext software and do not need to be installed separately.

The file system APIs are grouped into the following categories:

• Allocation and Space Management APIs

• Quality of Service and Real Time I/O APIs

• File System Configuration and Location Management APIs

• Access Management APIs

Appendix A at the end of this guide provides a test API sample program that illustrates how to use many of the StorNext File System APIs described in this guide.

Most of these APIs take two parameters: a request structure and a reply structure. On Windows, these correspond to the inbuffer and outbuffer

parameters of DeviceIoControl(). On UNIX, the two structures (request

and response) are consolidated into a single union so that we can still use

the ioctl() and fcntl() interface. The functionality remains the same.

For example, the UNIX definition of the call to allocate space would be:

typedef union allocspacereqreply {

AllocSpaceReq_treq; AllocSpaceReply_treply;

} AllocSpaceReqReply_t;

StorNext API Guide 86

Chapter 3 StorNext File System APIs

Field names for request structures are prefaced with xq_ where <x> is

representative of the structure’s name. Field names for reply structures

are similarly prefaced with xr_.

All structures are 64-bit aligned and use the following typedefs on Windows:

typedef UCHARuint8_t; typedef USHORTuint16_t; typedef ULONGuint32_t; typedef ULONGLONGuint64_t; typedef CHARint8_t; typedef SHORTint16_t; typedef LONGint32_t; typedef LONGLONGint64_t;

The control code definitions are platform dependent, and are defined in a separate file for each platform. The version number is encoded in each control code so that individual calls can be modified without affecting the

rest of the interface. The macro name (for example, CvApi_PunchHole,) is

the same on all platforms.

Platform Filename Interface Routine

Linux cv_linux_ioctl.h ioctl(2) Solaris cv_sol_ioctl.h ioctl(2) Irix cv_irix_ioctl.h fcntl(2) Windows cv_nt_ioctl.h DeviceIoControl()

Except where noted, all calls return 0 (zero) on success, and a standard

platform-specific error code on error. On UNIX, it is a standard errno. On Windows, it is one of the status codes listed in ddk\inc Windows Driver

Development Kit. Internally, StorNext maps all error codes to a platformindependent value and only maps to platform error codes just before returning to the user. In this document the following error codes are defined:

VOP_ENOENT 2 VOP_EACCESS 5 VOP_EXIST 7 VOP_EINVAL 11

StorNext API Guide 87

Chapter 3 StorNext File System APIs

VOP_ENOSPC 12 VOP_EFAULT 19

These error codes are mapped to their closest platform-specific error. For

example, the error VOP_ENOENT maps to ENOENT on most UNIX

platforms, and the Windows error code

STATUS_OBJECT_NAME_NOT_FOUND on Windows (which may map to a Win32 definition such as ERROR_NOT_FOUND).

All offsets and sizes are given in bytes and are rounded up, if necessary, to the next file system block size.

For calls that return variable length buffers (such as extent lists), the call will return the total number of items available, as well as the number returned in this particular call. If more data is available than can be returned in the user’s buffer, as much as possible is copied into the buffer, and no error is returned. For subsequent calls, the user can specify a different starting location (ordinal for stripe groups, starting offset for

extents). This is similar to the getdents/getdirentries semantic on UNIX.

Note that if the list is changing while the user is attempting to retrieve it, inconsistent results may be returned. When there are no more entries

available, ENOENT is returned.

In this document, the word handle is synonymous with a file descriptor in UNIX.

Note: StorNext file system API names are preceded with “CvApi”

because they were inherited from CVFS.

StorNext API Guide 88

Allocation and Space Management APIs

These APIs allow you to control how data is written to StorNext, resulting in faster writes and more efficient allocation of capacity.

Chapter 3 StorNext File System APIs

CvApi_AllocSpace 3

This API allocates extent space in a file. (This API is scheduled for deprecation and will not be supported in future StorNext releases.)

Handle

Target file.

Notes

This call attempts to allocate disk space of the requested size, starting at the requested file-relative offset. Commonly, this results in a single extent being allocated. However, if the file system free space is fragmented, up to 24 extents may be allocated. In addition, if the entire requested space cannot be allocated by adding 24 new extents, the API performs only a partial allocation and still returns a successful status. Therefore, to reliably determine the actual amount of space allocated by

CvApi_AllocSpace, applications must track the number of file blocks using the UNIX fstat(2) system call or through the CvApi_CvFstat API.

If the caller specifies an offset to begin allocation, the call allocates space at the offset, rounded up to a file system block size. If any allocation exists

that maps even a portion of <offset + size>, the call returns EXISTS. If no

offset is specified, the call allocates the requested size beginning at the next file system block boundary beyond the current end of file. The number of bytes is rounded up to a file system block size. In both cases, the file size is updated if the allocation causes an increase in the current end of file.

If the affinity is specified, this sets the affinity for this and all future allocations. In this way, setting the affinity is “sticky.” If the affinity is already set in the file, setting the affinity in this call has no affect. To get/

set the affinity, see the CvApi_GetAffinity / CvApi_SetAffinity calls. The

StorNext API Guide 89

Chapter 3 StorNext File System APIs

Allocation and Space Management APIs

allocation will be made exclusively only from stripe groups that have the matching affinity.

The caller can also specify that the extent information be loaded into the client extent mapping tables. This eliminates a subsequent trip to the FSM to retrieve extent information for the range mapped by this call.

All byte sizes and offsets are rounded up to the nearest file system block size. The call returns the actual allocated size and offset.

CvApi_AllocSpace is scheduled for deprecation in a future release. You should use the new function CvApi_VerifyAlloc instead.

Structure

typedef struct _AllocSpaceReq {

uint64_taq_size; uint64_taq_offset; uint64_taq_affinitykey;

uint32_taq_flags;

#define ALLOC_OFFSETzx01 #define ALLOC_LOAD_EXT0x02 #define ALLOC_STRIPE_ALIGN0x04 #define ALLOC_AFFINITY0x08 #define ALLOC_KEEPSIZE0x10 #define ALLOC_PERFECTFIT0x20 #define ALLOC_SETSIZE0x40

uint32_taq_pad1;

} AllocSpaceReq_t;

typedef struct _AllocSpaceReply {

uint64_tar_size; uint64_tar_offset;

} AllocSpaceReply_t;

StorNext API Guide 90

Chapter 3 StorNext File System APIs

Allocation and Space Management APIs

UNIX ioctl structure: 3

typedef union _allocspacereqreply {

AllocSpaceReq_treq; AllocSpaceReply_treply

} AllocSpaceReqReply_t;

reQuest Fields

aq_size Size in bytes to allocate. Must not be zero. If not a

multiple of the file system block size, it is rounded up to the nearest file system block size.

aq_offset If ALLOC_OFFSET is set, the aq_size bytes (rounded up

to the nearest file system block size) is allocated starting at file byte offset aq_offset (rounded up to the nearest file system block size).

If ALLOC_OFFSET is clear, the offset is ignored when

allocating space. The space is allocated at the end of the file.

aq_affinitykey 64 bit affinity “key” identifying the affinity for the

allocation. Valid only if ALLOC_AFFINITY is set. This

forces the space to be allocated exclusively from stripe groups with a matching affinity key.

aq_flags Control Flags:

ALLOC_OFFSET aq_offset is valid. ALLOC_LOAD_EXT Load the extent struct mapping on

the client and add it to the client file system. Note: in case where multiple extents are allocated, only the first extent is loaded.

ALLOC_STRIPE_ALIGN Allocate space starting at a stripe

boundary.

ALLOC_AFFINITY aq_affinitykey is valid. ALLOC_KEEPSIZE Do not update the size of the file,

even if extending it.

ALLOC_PERFECTFITFollow the ‘perfect fit’ rules for

allocation.

ALLOC_SETSIZE Update the file size, and broadcast

the size change to other clients.

StorNext API Guide 91

Chapter 3 StorNext File System APIs

Allocation and Space Management APIs

The default is to only broadcast the new number of blocks and the fact the extent list has changed (which causes clients to flush their extent lists).

CvApi_GetPerfectFitStatu

Reply Fields

ar_size Actual size of the allocation that was attempted. ar_offset File relative offset of allocated space.

Error Returns

VOP_ENOSPC Insufficient space in the file system to satisfy the

request.

VOP_EINVAL Invalid affinity key. VOP_EXISTS An allocation already exists that maps some or all of

the specified offset and length.

This API determines whether a file has been marked for PerfectFit allocations.

Handle

Handle for the file being queried.

Notes

This API is used by the snfsdefrag application to ensure that files with PerfectFit allocations continue to have PerfectFit allocations after the files are defragmented.

Structure

typedef struct _GetPerfectFitStatusReply {

StorNext API Guide 92

uint32_t pr_status; uint32_t pr_pad1;

} GetPerfectFitStatusReply_t;

Chapter 3 StorNext File System APIs

Allocation and Space Management APIs

CvApi_PunchHole 3

UNIX ioctl structure:

None. Use GetPerfectFitStatusReply_t directly.

Reply Fields:

pr_status If 1, the file has the PerfectFit bit set. If 0, the file does

not.

Error Returns

VOP_ENOENT The file doesn't exist. VOP_EINVAL The file is not a “regular” file.

Other Communications failure with the FSM.

This API punches a hole in the file.

Handle

Target file.

Notes

This call punches a hole in the file, adjusting the allocation map of the file to indicate that no data blocks are allocated for the indicated range. The granularity of access is the file system block size. The byte offsets are rounded down to the beginning of the block containing the specified byte offset. The actual offsets used are returned; the starting offset will always be file system block aligned.

If zero is specified as the ending offset, a hole is punched to the end of the file.

StorNext API Guide 93

Chapter 3 StorNext File System APIs

Allocation and Space Management APIs

Structure 3

typedef struct _PunchHoleReq {

uint64_tpq_start; uint64_tpq_end; /* Inclusive */

} PunchHoleReq_t;

typedef struct _PunchHoleReply {

uint64_tpr_start; uint64_tpr_end; uint64_tpr_nblocks; uint64_tpr_blksfreed;

} PunchHoleReply_t;

UNIX ioctl structure:

typedef union _punchholereqrep {

PunchHoleReq_treq; PunchHoleReply_treply;

} PunchHoleReqReply_t;

reQuest fields

pq_start Starting byte offset of hole. pq_end Inclusive ending byte offset. A value of zero means punch

to EOF.

Reply Fields

pr_start Starting byte offset where hole was created. pr_end Inclusive ending byte offset where hole was created. pr_nblocks Number of blocks currently allocated to the file. pr_blksfreed Number of blocks freed.

CvApi_SetFileSize 3

StorNext API Guide 94

This API sets the size of a file without zeroing pre-allocated data.

Chapter 3 StorNext File System APIs

Allocation and Space Management APIs

Handle 3

Target file.

Notes

The effect of this call is very similar to making the ftruncate(2) system call,

except that when the file size is being extended, any existing blocks between the old EOF and the new EOF are not zeroed regardless of whether the SNFS “sparse” mount option is enabled or not.

CvApi_SetFileSize is not currently supported on the Apple Xsan clients.

Structure

typedef struct _setfilesizereq {

uint64_t sq_size;

} SetFileSizeReq_t;

No reply structure

UNIX ioctl structure.

None. Use SetFileSizeReq_t directly.

reQuest Fields

sq_size New file size.

Error Returns

VOP_EFAULT Bad buffer offset. VOP_EPERM File is not writable by the caller. VOP_EPERM The user is not superuser and the “protect alloc” mount

option is enabled.

Other Communications failure with the FSM.

StorNext API Guide 95

Chapter 3 StorNext File System APIs

Allocation and Space Management APIs

CvAPI_VerifyAlloc 3

This API allocates blocks within a file at the given offset.

Handle

The target file.

Notes

This call allocates all extents needed to fill the given range within a file. If any portion of the given range is already allocated, that portion is skipped. All additional space needed to form a completely allocated range is then filled in and a successful return status is set. If the given range is completely allocated, no allocations will be done and a successful status will be returned.

In order to ensure that only the requested allocation and no more is

provided, use the ALLOC_NOMORETHAN flag. If this flag is not used the

allocation might be rounded to optimize allocations.

In the case of an allocation failure, no space will be allocated and an error will be returned.

CvAPI_VerifyAlloc does not modify the file's size.

Structure

typedef struct _VerifyAllocReq {

uint64_tvq_size;

uint64_tvq_offset;

uint32_tvq_flags;

#define ALLOC_STRIPE_ALIGN0x04 #define ALLOC_NOMORETHAN0x20

uint32_tvq_pad1;

} VerifyAllocReq_t;

StorNext API Guide 96

Quantum STORNEXT SNAPI 2.0.1 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

About This Guide

1Introduction

Product Compatibility

SNAPI/StorNext Compatibility Matrix 1

Installing StorNext APIs

Running APIs Remotely

Explanation of Warnings, Cautions and Notes

Related Documents You Might Need

Quantum Technical Assistance Center

Getting More Information or Help 1

Introduction

2StorNext Storage Manager APIs

Installing the APIs on the Storage Manager Host

Installing the APIs on a Remote Client

Configuring SNAPI

Snapi.cfg Example 2

SNAPI Logs and Health Checks

HA Failover Support 2

Use Cases

• Using a C or C++ Library

Using a C or C++ Library with XML Wrapper 2

Using the SNAPI XML Command Line Interface (snclix) 2

API Descriptions and Arguments

Backup 2

CheckoutMedia 2

CleanMedia 2

CopyMedia 2

EjectMedia 2

EnterMedia 2

FileRetrieve 2

GetArchiveCapacity 2

GetArchiveList 2

GetBackupStatus 2

GetDriveList 2

GetFileAttribute 2

GetFileTapeLocationI 2

GetMediaList 2

GetMediaStatus 2

GetPolicy 2

GetPortList 2

GetSchedule 2

GetSystemStatus 2

MoveMedia 2

This API executes the specified command line argument. The PassThru

RmDiskCopy 2

SetArchiveState 2

SetDirAttributes 2

SetDriveState 2

SetFileAttributes 2

SetMediaState 2

SetPolicy 2

SetSchedule 2

3StorNext File System APIs

Allocation and Space Management APIs

CvApi_AllocSpace 3

CvApi_PunchHole 3

CvApi_SetFileSize 3

CvAPI_VerifyAlloc does not modify the file's size.
