1. Safety recommendations
1.1 Symbols |
||
! |
WARNING |
|
This may cause injury. |
||
|
i |
INFORMATION |
|
Important or useful information. |
||
|
ELECTRICAL HAZARD DANGER
This may cause injury.
Q10 is a fully automatic grinder which grinds coffee beans in programmed instant, pre-grind or manual instant mode. Simply insert the filter holder in the corresponding guide to obtain one or two freshly ground doses of coffee. The grinder's versatility also allows for independently adjusting the amount of coffees we require for serving one or two coffee, accessing the corresponding menu using the touch screen.
1.2Safety recommendations
Installation
Location
Electric connection
Handling
This machine should only be installed by authorised technical personnel. The manufacturer declines all responsibility for any damage caused due to inadequate installation.
We recommend the machine is installed in a spacious area, free from airstreams and on a solid base. Avoid installing it on a damp or hot surface.
Check that the voltage, frequency and power characteristics of the electric connection coincide with those described on the machine's characteristics plate. The characteristics plate can be found below the hopper.
The machine must be installed according to the country's current electric regulation. You must ensure the electric installation has a reliable earthed connection, according to the aforementioned standards. The company declines all responsibility for any possible damage caused by a faulty installation or earth connection.
Do not use extension cables or multiple adaptors of any type to connect the machine to the power supply. The power supply cable should never be wound up, it should be as straight as possible in order to avoid it from overheating.
All internal handling of the machine, except for operations specifically described in this manual related to cleaning processes, must be carried out by authorised technical personnel.
Preventive cleaning and maintenance tasks must be performed within the intervals indicated by the machine or the technical service.
The manufacturer declines all responsibility for any possible damage caused to the machine due to a failure to comply with these obligations, as well as those due to incorrect or inappropriate use.
All of the machine's components, including the connection cable, must be replaced with original spare parts, which can be supplied by the authorised technical service or the manufacturer.
Before performing any maintenance operation, ensure the machine is disconnected from the electric power supply by using the installation's general switch or disconnecting the power supply cable.
GB |
17
Important advice
Install the grinder on a solid base
The machine shall only be used by adults. Children do not acknowledge the hazards involved in machine, due to which they should not be in contact with them and should
!not be allowed to use them. People with reduced physical, sensory or mental capacities, or inexperienced people, should not use this machine without supervision person qualified for this purpose.
Do not use this machine outdoors, unless it is protected from external elements (air, rain, fog, etc.)
!The machine should not be exposed to water sprays or steam.
Do not touch the machine with wet, damp or bare feet, or with wet or damp hands.
The machine should not be used for grinding products other than those described in this manual.
18
2.General view
2.1View
i |
|
i |
|
Removable hopper |
|
|
|
|
Closed hopper
Coffee type identification label
Touch Screen
Coffee press
Double-dose pushbutton
USB plug
Filter holder guide
i General switch
- General on/off switch. Located under |
|
the coffee grounds tray. |
General switch |
|
Open hopper
Hopper security micro (optional)
-Upon removing the hopper, the security micro disconnects the grinder.
Grinding adjustment knob
Single-dose pushbutton
Coffee grounds tray
Features:
Height: 610 mm.
Width: 193 mm.
Depth: 391 mm.
Weight: 16 Kg.
Hoper capacity: 1.5 Kg.
Power supply: 230 V, 50 Hz.
Nominal Power: 525 W
2.2 Touch screen
The grinder is fitted with a resistant touch screen with which we can access the different menus, which allow for functions such as:
|
|
- |
Check the number of doses used for one and two coffees. |
|
COUNTERS |
|
- |
Check the number of remaining doses until change of blades. |
|
|
|
- |
Check the number of doses remaining before brush cleaning. |
|
CONFIGURATION |
CLEANING |
- |
Configure operating mode, “Pre-grind” o “Instant” o “Manual Grind”. |
|
- |
Adjust the coffee dosage |
|||
|
|
|||
|
|
- |
Other functions. |
|
|
|
|
|
Note: Refer to Section 8 – programming, for a description on all the menus and functions of the screen.
