1730 LCR Meter
USES:
• Production Testing of LCR Components
• Component Screening
• Material Testing
• Quality Assurance Testing
• Component Design and Evaluation
FEATURES:
• 12 Measurement Parameters
• 0.1% Basic Measurement Accuracy
• 7 Test Frequencies: 100Hz-100kHz
• Programmable Test Voltage: 10mV-1V
• Measurement Speeds up to 62/second
• Monitor DUT Voltage and Current
• Large High Resolution Graphic Display
• IEEE and Handler Interfaces, Standard
• Automatic Open/Short Zeroing
• Pass/Fail Binning (8)
• Storage/Recall of 50 Setups
• Measurement Averaging (1-256)
• Measurement Delay (0-10 seconds)
• Programmable Source Impedance
• DC Bias Voltage (0-5V)
• Keypad Lockout
• Easy Operation
• Cable Correction 0-4M
Introduction
The QuadTech 1730 LCR Digibridge is an easily programmable, microprocessor-based high performance passive component tester with excellent
low impedance measurement and fast measurement speeds even at
100/120Hz. It measures 12 different parameters with a basic accuracy of
0.1%. Programmable test frequency, speed, mode and voltage permits great
versatility in component and materials testing. Standard IEEE-488 and
Handler interfaces provide data transfer and component automation applications for faster production line testing.
Description
12 Measurement Parameters: Measure and display two of 12 impedance
parameters simultaneously with a basic accuracy of 0.1%. Test results can also
be shown as Deviation or %Deviation from nominal value.
7 Test Frequencies: User selectable: 100Hz, 120Hz, 1kHz, 10kHz, 20kHz,
50kHz and 100kHz.
LCD Display: Large, high resolution graphic display for clear, concise results
and user friendly menu interface for easy programming.
Setup Store/Recall: Store/Recall up to 50 test setups from instrument memory . Lock out front panel to ensur e procedur es ar e run the same way every time.
Programmable Source Impedance: Program tester impedance to 100Ω,
100/25Ω, 25Ω or 10Ω constant current when comparing results with measurements made on other testers. Measurement results can vary significantly
based solely on the source impedance of the tester being used.
Voltage/Current Monitoring: Use the test signal monitoring function to display the actual voltage level across and current through the DUT.
DC Bias: External and internal DC Bias voltage from 0-5V, permits capacitors
to be tested under real DC bias conditions.
Open/Short Zeroing: Reduce the effects of error sources (stray
admittance/residual impedance) between the DUT and the calibrated connection to the measuring instrument.
Fast Testing: Select from one of three measurement speeds: slow, medium or
fast for varying degrees of accuracy and speed up to 62 measurements/second.
Interfaces Standard:The 1730 unit includes IEEE-488 and Handler interfaces
for adaption into production environments or remote control applications.
1-800-253-1230
Fax 1-978-461-4295
Intl. 1-978-461-2100
For more information about special
purchase, rent & lease options, call
For more detailed
specifications, visit
www.quadtech.com
HIPOT • LCR METERS • MEGOHMMETERS • MILLIOHMMETERS
Digibridge
Digibridge
1730 LCR Digibridge
Includes:
QuadTech P/N
Item
4200-0300 AC Power Cord
150683 Instruction Manual
520026/520138 Power Line Fuses (1.0A 250V/0.5A 250V)
Calibration Certificate Traceable to NIST
Optional Accessories:
B/A Calibration Data
1700-01 Axial/Radial Component Test Fixture
1700-02 Axial/Radial Remote Test Fixture
1700-03 Lead Set: 4 BNC Connectors to 2 Kelvin Clips
7000-01 BNC to BNC Cable Lead Set (1m)
7000-02 BNC to BNC Cable Lead Set (2m)
7000-05 Lead Set: 4 BNC Connectors to Chip Component Tweezers
7000-07 Low Voltage Chip Component Test Fixture
Or
dering Information
Product Specifications
For more detailed specifications, visit www.quadtech.com
For more information about special purchase, rent & lease options, call
1-800-253-1230 • Fax 1-978-461-4295 • Intl. 1-978-461-2100
5 Clock Tower Place, 210 East, Maynard MA 01754
Parameter Measurement Range
Ls, Lp 0.001uH - 99.999kH
Cs, Cp 0.001pF - 9.9999F
Rs, Rp 0.01mΩ - 99.99MΩ
D 0.0001 - 9999
Q 0.0001 - 9999
ESR 0.01mΩ - 99.99MΩ
lZl 0.01mΩ - 99.99MΩ
Xs 0.01mΩ - 99.99MΩ
Phase -180.00
° - +180.00°
Accuracy: Basic LCR ±0.1%.
Basic DQ ±0.001
Test Frequencies: 100Hz, 120Hz, lkHz, 10kHz, 20kHz,
50kHz and 100kHz
Accuracy ±(0.01% ± 0.01Hz)
Measurement Speed: Fast: 62 measurements/second
Medium: 19 measurements/isecond
Slow: 3 measurements/second
Ranging: Automatic or User Selectable
Trigger: Internal
External (IEEE or Handler)
Manual
Source Impedance: 100/25Ω, 100Ω,25Ω or 10Ωc.c. (constant
current)
AC Test Signal: Voltage: 10mV - 1V, 10mV steps
DC Bias Voltage: External: 0-5V
Internal: 0-5V with R
BIAS
external resistor
DC Bias Current: Internal: 0-200mA using R
BIAS
external
resistor
Display: 240 by 64 LCD display
Results Format: Value
Deviation
% Deviation
Bin Number
GO/NO GO
Measurement Delay: Programmable from 0-10s in 1ms steps
Averaging: Programmable from 1-256
Binning: Eight pass bins for LCR
One fail bin, LCR and DQ
Interfaces: IEEE-488 and Handler Standard
Equivalent Circuit: Series or Parallel
Zeroing: Open and short circuit compensation.
Buzzer: Programmable: HI LO or OFF for Pass or
Fail Result
Comparator: Set Upper/ Lower Limit as absolute value
or % value for primary and secondary
parameters
Test Signal: Monitor voltage across and current
through device under test.
Test Terminals: Front: 4 BNC & 1 GND
Rear: EXT BIAS: 1 BNC, 2-terminal strip
Setup Storage: Store/Recall 50 test setups
Lock: Keypad Lockout
Dimensions: (w x h x d): 12.5 x 4.0 x 13.5in
(312.5 x 100.0 x 337.5mm)
Weight: 12.4 lbs. (5.7kg) net, 17 lbs. (7.8 kg) ship
Enviromental: Specifications: +15°C to +35°C, 75% RH
Operating: 0°C to +50°C
Storage: -40°C to +75°C
Humidity: <85%
Power: • 90 - 125V AC
• 190 - 250V AC
• 50 or 60 Hz
• 65W max
P/N 030116/A1
