Q-Logic 59047-09 C User Manual

SANbox
Simple Network Management Protocol
Reference Guide
Firmware Version 7.4/7.8/7.10
59047-09 C
SANbox Simple Network Management Protocol Reference Guide
Information furnished in this guide is believed to be accurate and reliable. However, QLogic Corporation assumes no responsibility for its use, nor for any infringements of patents or other rights of third parties which may result from its use. QLogic Corporation reserves the right to change product specifications at any time without notice. Applications described in this document for any of these products are for illustrative purposes only. QLogic Corporation makes no representation nor warranty that such applications are suitable for the specified use without further testing or modification. QLogic Corporation assumes no responsibility for any errors that may appear in this document.
All other brand and product names are trademarks or registered trademarks of their respective owners.
S
Document Revision History
Release, Revision A, April 2008 Update, Revision B, August 2008 Update, Revision C, October 2008
Changes Sections Affected
Updated title page to include 7.10 firmware
Page ii 59047-09 C

Table of Contents

1 Introduction
Intended Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Related Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Technical Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Availability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Training . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Contact Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2 SNMP Overview
SNMP Interface Objectives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Manager and Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Traps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Management Information Base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
User Datagram Protocol. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Numbering System Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
3 Configuring a Switch
System Specifications and Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Configuring a Switch Using the Command Line Interface . . . . . . . . . . . . . . 3-2
Configuring a Switch Using Enterprise Fabric Suite 2007 . . . . . . . . . . . . . . 3-6
4 MIB-II Objects
Groups in MIB-II. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
System Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
sysDescr (1.3.6.1.2.1.1.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
sysObjectID (1.3.6.1.2.1.1.2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
sysUpTime (1.3.6.1.2.1.1.3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
sysContact (1.3.6.1.2.1.1.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
sysName (1.3.6.1.2.1.1.5). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
sysLocation (1.3.6.1.2.1.1.6). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
sysServices (1.3.6.1.2.1.1.7). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
The Interfaces Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
ifNumber (1.3.6.1.2.1.2.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
The Interfaces Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
59047-09 C Page iii
SANbox Simple Network Management Protocol Reference Guide
ifIndex (1.3.6.1.2.1.2.2.1.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
ifDescr (1.3.6.1.2.1.2.2.1.2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
ifType (1.3.6.1.2.1.2.2.1.3). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
ifMtu (1.3.6.1.2.1.2.2.1.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
ifSpeed (1.3.6.1.2.1.2.2.1.5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
ifPhysAddress (1.3.6.1.2.1.2.2.1.6). . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
ifAdminStatus (1.3.6.1.2.1.2.2.1.7) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7
ifOperStatus (1.3.6.1.2.1.2.2.1.8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
ifLastChange (1.3.6.1.2.1.2.2.1.9). . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
ifInOctets (1.3.6.1.2.1.2.2.1.10). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
ifInUcastPkts (1.3.6.1.2.1.2.2.1.11) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
ifInNUcastPkts (1.3.6.1.2.1.2.2.1.12). . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
ifInDiscards (1.3.6.1.2.1.2.2.1.13). . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
ifInErrors (1.3.6.1.2.1.2.2.1.14) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
ifInUnknownProtos (1.3.6.1.2.1.2.2.1.15) . . . . . . . . . . . . . . . . . . . . . . 4-10
ifOutOctets (1.3.6.1.2.1.2.2.1.16) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
ifOutUcastPkts (1.3.6.1.2.1.2.2.1.17) . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
ifOutNUcastPkts (1.3.6.1.2.1.2.2.1.18) . . . . . . . . . . . . . . . . . . . . . . . . 4-11
ifOutDiscards (1.3.6.1.2.1.2.2.1.19). . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
ifOutErrors (1.3.6.1.2.1.2.2.1.20). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
ifOutQLen (1.3.6.1.2.1.2.2.1.21) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
ifSpecific (1.3.6.1.2.1.2.2.1.22) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
The Address Translation Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
atIfIndex (1.3.6.1.2.1.3.1.1.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
atPhysAddress (1.3.6.1.2.1.3.1.1.2) . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
atNetAddress (1.3.6.1.2.1.3.1.1.3) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
The IP Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14
ipForwarding (1.3.6.1.2.1.4.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14
ipDefaultTTL (1.3.6.1.2.1.4.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14
ipInReceives (1.3.6.1.2.1.4.3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
ipInHdrErrors (1.3.6.1.2.1.4.4). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
ipInAddrErrors (1.3.6.1.2.1.4.5). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
ipForwDatagrams (1.3.6.1.2.1.4.6) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
ipInUnknownProtos (1.3.6.1.2.1.4.7). . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
ipInDiscards (1.3.6.1.2.1.4.8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
ipInDelivers (1.3.6.1.2.1.4.9) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
ipOutRequests (1.3.6.1.2.1.4.10) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
ipOutDiscards (1.3.6.1.2.1.4.11) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
ipOutNoRoutes (1.3.6.1.2.1.4.12) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
S
Page iv 59047-09 C
A
SANbox Simple Network Management Protocol
ipReasmTimeout (1.3.6.1.2.1.4.13). . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
ipReasmReqds (1.3.6.1.2.1.4.14) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
ipReasmOKs (1.3.6.1.2.1.4.15). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
ipReasmFails (1.3.6.1.2.1.4.16) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
ipFragOKs (1.3.6.1.2.1.4.17). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
ipFragFails (1.3.6.1.2.1.4.18) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
ipFragCreates (1.3.6.1.2.1.4.19). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
The IP Address Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
ipAdEntAddr (1.3.6.1.2.1.4.20.1.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
ipAdEntIfIndex (1.3.6.1.2.1.4.20.1.2). . . . . . . . . . . . . . . . . . . . . . . . . . 4-21
ipAdEntNetMask (1.3.6.1.2.1.4.20.1.3). . . . . . . . . . . . . . . . . . . . . . . . 4-21
ipAdEntBcastAddr (1.3.6.1.2.1.4.20.1.4). . . . . . . . . . . . . . . . . . . . . . . 4-21
ipAdEntReasmMaxSize (1.3.6.1.2.1.4.20.1.5) . . . . . . . . . . . . . . . . . . 4-22
The IP Routing Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22
ipRouteDest (1.3.6.1.2.1.4.21.1.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-22
ipRouteIfIndex (1.3.6.1.2.1.4.21.1.2). . . . . . . . . . . . . . . . . . . . . . . . . . 4-22
ipRouteMetric1 (1.3.6.1.2.1.4.21.1.3) . . . . . . . . . . . . . . . . . . . . . . . . . 4-23
ipRouteMetric2 (1.3.6.1.2.1.4.21.1.4) . . . . . . . . . . . . . . . . . . . . . . . . . 4-23
ipRouteMetric3 (1.3.6.1.2.1.4.21.1.5) . . . . . . . . . . . . . . . . . . . . . . . . . 4-24
ipRouteMetric4 (1.3.6.1.2.1.4.21.1.6) . . . . . . . . . . . . . . . . . . . . . . . . . 4-24
ipRouteNextHop (1.3.6.1.2.1.4.21.1.7) . . . . . . . . . . . . . . . . . . . . . . . . 4-24
ipRouteType (1.3.6.1.2.1.4.21.1.8) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-25
ipRouteProto (1.3.6.1.2.1.4.21.1.9). . . . . . . . . . . . . . . . . . . . . . . . . . . 4-25
ipRouteAge (1.3.6.1.2.1.4.21.1.10). . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26
ipRouteMask (1.3.6.1.2.1.4.21.1.11) . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26
ipRouteMetric5 (1.3.6.1.2.1.4.21.1.12) . . . . . . . . . . . . . . . . . . . . . . . . 4-26
ipRouteInfo (1.3.6.1.2.1.4.21.1.13) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
The IP Address Translation Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
ipNetToMediaIfIndex (1.3.6.1.2.1.4.22.1.1) . . . . . . . . . . . . . . . . . . . . . 4-27
ipNetToMediaPhysAddress (1.3.6.1.2.1.4.22.1.2). . . . . . . . . . . . . . . . 4-28
ipNetToMediaNetAddress (1.3.6.1.2.1.4.22.1.3) . . . . . . . . . . . . . . . . . 4-28
ipNetToMediaType (1.3.6.1.2.1.4.22.1.4) . . . . . . . . . . . . . . . . . . . . . . 4-29
Additional IP Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29
ipRoutingDiscards (1.3.6.1.2.1.4.23). . . . . . . . . . . . . . . . . . . . . . . . . . 4-29
The ICMP Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30
icmpInMsgs (1.3.6.1.2.1.5.1). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30
icmpInErrors (1.3.6.1.2.1.5.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-30
icmpInDestUnreachs (1.3.6.1.2.1.5.3). . . . . . . . . . . . . . . . . . . . . . . . . 4-30
icmpInTimeExcds (1.3.6.1.2.1.5.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31
59047-09 C Page v
SANbox Simple Network Management Protocol Reference Guide
icmpInParmProbs (1.3.6.1.2.1.5.5) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31
icmpInSrcQuenchs (1.3.6.1.2.1.5.6) . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31
icmpInRedirects (1.3.6.1.2.1.5.7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-31
icmpInEchos (1.3.6.1.2.1.5.8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
icmpInEchoReps (1.3.6.1.2.1.5.9). . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
icmpInTimestamps (1.3.6.1.2.1.5.10) . . . . . . . . . . . . . . . . . . . . . . . . . 4-32
icmpInTimestampReps (1.3.6.1.2.1.5.11) . . . . . . . . . . . . . . . . . . . . . . 4-33
icmpInAddrMasks (1.3.6.1.2.1.5.12) . . . . . . . . . . . . . . . . . . . . . . . . . . 4-33
icmpInAddrMaskReps (1.3.6.1.2.1.5.13). . . . . . . . . . . . . . . . . . . . . . . 4-33
icmpOutMsgs (1.3.6.1.2.1.5.14) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-33
icmpOutErrors (1.3.6.1.2.1.5.15). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34
icmpOutDestUnreachs (1.3.6.1.2.1.5.16) . . . . . . . . . . . . . . . . . . . . . . 4-34
icmpOutTimeExcds (1.3.6.1.2.1.5.17). . . . . . . . . . . . . . . . . . . . . . . . . 4-34
icmpOutParmProbs (1.3.6.1.2.1.5.18). . . . . . . . . . . . . . . . . . . . . . . . . 4-35
icmpOutSrcQuenchs (1.3.6.1.2.1.5.19). . . . . . . . . . . . . . . . . . . . . . . . 4-35
icmpOutRedirects (1.3.6.1.2.1.5.20) . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35
icmpOutEchos (1.3.6.1.2.1.5.21). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35
icmpOutEchoReps (1.3.6.1.2.1.5.22) . . . . . . . . . . . . . . . . . . . . . . . . . 4-36
icmpOutTimestamps (1.3.6.1.2.1.5.23) . . . . . . . . . . . . . . . . . . . . . . . . 4-36
icmpOutTimestampReps (1.3.6.1.2.1.5.24). . . . . . . . . . . . . . . . . . . . . 4-36
icmpOutAddrMasks (1.3.6.1.2.1.5.25). . . . . . . . . . . . . . . . . . . . . . . . . 4-37
icmpOutAddrMaskReps (1.3.6.1.2.1.5.26) . . . . . . . . . . . . . . . . . . . . . 4-37
The TCP Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-37
tcpRtoAlgorithm (1.3.6.1.2.1.6.1). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-37
tcpRtoMin (1.3.6.1.2.1.6.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-38
tcpRtoMax (1.3.6.1.2.1.6.3). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-38
tcpMaxConn (1.3.6.1.2.1.6.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-38
tcpActiveOpens (1.3.6.1.2.1.6.5). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-39
tcpPassiveOpens (1.3.6.1.2.1.6.6) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-39
tcpAttemptFails (1.3.6.1.2.1.6.7) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-39
tcpEstabResets (1.3.6.1.2.1.6.8). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-40
tcpCurrEstab (1.3.6.1.2.1.6.9). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-40
tcpInSegs (1.3.6.1.2.1.6.10) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-40
tcpOutSegs (1.3.6.1.2.1.6.11) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-41
tcpRetransSegs (1.3.6.1.2.1.6.12). . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-41
The TCP Connection Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-41
tcpConnState (1.3.6.1.2.1.6.13.1.1). . . . . . . . . . . . . . . . . . . . . . . . . . . 4-41
tcpConnLocalAddress (1.3.6.1.2.1.6.13.1.2). . . . . . . . . . . . . . . . . . . . 4-42
tcpConnLocalPort (1.3.6.1.2.1.6.13.1.3) . . . . . . . . . . . . . . . . . . . . . . . 4-42
S
Page vi 59047-09 C
A
SANbox Simple Network Management Protocol
tcpConnRemAddress (1.3.6.1.2.1.6.13.1.4) . . . . . . . . . . . . . . . . . . . . 4-42
tcpConnRemPort (1.3.6.1.2.1.6.13.1.5). . . . . . . . . . . . . . . . . . . . . . . . 4-43
Additional TCP Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-43
tcpInErrs (1.3.6.1.2.1.6.14) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-43
tcpOutRsts (1.3.6.1.2.1.6.15) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-43
The UDP Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-44
udpInDatagrams (1.3.6.1.2.1.7.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-44
udpNoPorts (1.3.6.1.2.1.7.2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-44
udpInErrors (1.3.6.1.2.1.7.3). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-44
udpOutDatagrams (1.3.6.1.2.1.7.4). . . . . . . . . . . . . . . . . . . . . . . . . . . 4-45
The UDP Listener Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-45
udpLocalAddress (1.3.6.1.2.1.7.5.1.1) . . . . . . . . . . . . . . . . . . . . . . . . 4-45
udpLocalPort (1.3.6.1.2.1.7.5.1.2). . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-45
The EGP Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-46
egpInMsgs (1.3.6.1.2.1.8.1). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-46
egpInErrors (1.3.6.1.2.1.8.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-46
egpOutMsgs (1.3.6.1.2.1.8.3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-46
egpOutErrors (1.3.6.1.2.1.8.4). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-47
The EGP Neighbor Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-47
egpNeighState (1.3.6.1.2.1.8.5.1.1). . . . . . . . . . . . . . . . . . . . . . . . . . . 4-47
egpNeighAddr (1.3.6.1.2.1.8.5.1.2). . . . . . . . . . . . . . . . . . . . . . . . . . . 4-47
egpNeighAs (1.3.6.1.2.1.8.5.1.3). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-48
egpNeighInMsgs (1.3.6.1.2.1.8.5.1.4). . . . . . . . . . . . . . . . . . . . . . . . . 4-48
egpNeighInErrs (1.3.6.1.2.1.8.5.1.5). . . . . . . . . . . . . . . . . . . . . . . . . . 4-48
egpNeighOutMsgs (1.3.6.1.2.1.8.5.1.6) . . . . . . . . . . . . . . . . . . . . . . . 4-48
egpNeighOutErrs (1.3.6.1.2.1.8.5.1.7) . . . . . . . . . . . . . . . . . . . . . . . . 4-49
egpNeighInErrMsgs (1.3.6.1.2.1.8.5.1.8) . . . . . . . . . . . . . . . . . . . . . . 4-49
egpNeighOutErrMsgs (1.3.6.1.2.1.8.5.1.9) . . . . . . . . . . . . . . . . . . . . . 4-49
egpNeighStateUps (1.3.6.1.2.1.8.5.1.10) . . . . . . . . . . . . . . . . . . . . . . 4-50
egpNeighStateDowns (1.3.6.1.2.1.8.5.1.11) . . . . . . . . . . . . . . . . . . . . 4-50
egpNeighIntervalHello (1.3.6.1.2.1.8.5.1.12). . . . . . . . . . . . . . . . . . . . 4-50
egpNeighIntervalPoll (1.3.6.1.2.1.8.5.1.13). . . . . . . . . . . . . . . . . . . . . 4-50
egpNeighMode (1.3.6.1.2.1.8.5.1.14) . . . . . . . . . . . . . . . . . . . . . . . . . 4-51
egpNeighEventTrigger (1.3.6.1.2.1.8.5.1.15) . . . . . . . . . . . . . . . . . . . 4-51
egpAs (1.3.6.1.2.1.8.6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-52
The Transmission Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-52
The SNMP Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-52
snmpInPkts (1.3.6.1.2.1.11.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-52
snmpOutPkts (1.3.6.1.2.1.11.2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-53
59047-09 C Page vii
SANbox Simple Network Management Protocol Reference Guide
snmpInBadVersions (1.3.6.1.2.1.11.3) . . . . . . . . . . . . . . . . . . . . . . . . 4-53
snmpInBadCommunityNames (1.3.6.1.2.1.11.4). . . . . . . . . . . . . . . . . 4-53
snmpInBadCommunityUses (1.3.6.1.2.1.11.5) . . . . . . . . . . . . . . . . . . 4-54
snmpInASNParseErrs (1.3.6.1.2.1.11.6). . . . . . . . . . . . . . . . . . . . . . . 4-54
snmpInTooBigs (1.3.6.1.2.1.11.8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-54
snmpInNoSuchNames (1.3.6.1.2.1.11.9) . . . . . . . . . . . . . . . . . . . . . . 4-55
snmpInBadValues (1.3.6.1.2.1.11.10) . . . . . . . . . . . . . . . . . . . . . . . . . 4-55
snmpInReadOnlys (1.3.6.1.2.1.11.11). . . . . . . . . . . . . . . . . . . . . . . . . 4-55
snmpInGenErrs (1.3.6.1.2.1.11.12) . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-56
snmpInTotalReqVars (1.3.6.1.2.1.11.13) . . . . . . . . . . . . . . . . . . . . . . . 4-56
snmpInTotalSetVars (1.3.6.1.2.1.11.14). . . . . . . . . . . . . . . . . . . . . . . . 4-56
snmpInGetRequests (1.3.6.1.2.1.11.15) . . . . . . . . . . . . . . . . . . . . . . . 4-56
snmpInGetNexts (1.3.6.1.2.1.11.16) . . . . . . . . . . . . . . . . . . . . . . . . . . 4-57
snmpInSetRequests (1.3.6.1.2.1.11.17) . . . . . . . . . . . . . . . . . . . . . . . 4-57
snmpInGetResponses (1.3.6.1.2.1.11.18). . . . . . . . . . . . . . . . . . . . . . 4-57
snmpInTraps (1.3.6.1.2.1.11.19) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-58
snmpOutTooBigs (1.3.6.1.2.1.11.20). . . . . . . . . . . . . . . . . . . . . . . . . . 4-58
snmpOutNoSuchNames (1.3.6.1.2.1.11.21) . . . . . . . . . . . . . . . . . . . . 4-58
snmpOutBadValues (1.3.6.1.2.1.11.22). . . . . . . . . . . . . . . . . . . . . . . . 4-59
snmpOutGenErrs (1.3.6.1.2.1.11.24) . . . . . . . . . . . . . . . . . . . . . . . . . 4-59
snmpOutGetRequests (1.3.6.1.2.1.11.25). . . . . . . . . . . . . . . . . . . . . . 4-59
snmpOutGetNexts (1.3.6.1.2.1.11.26). . . . . . . . . . . . . . . . . . . . . . . . . 4-60
snmpOutSetRequests (1.3.6.1.2.1.11.27) . . . . . . . . . . . . . . . . . . . . . . 4-60
snmpOutGetResponses (1.3.6.1.2.1.11.28) . . . . . . . . . . . . . . . . . . . . 4-60
snmpOutTraps (1.3.6.1.2.1.11.29). . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-60
snmpEnableAuthenTraps (1.3.6.1.2.1.11.30) . . . . . . . . . . . . . . . . . . . 4-61
S
5 Fibre Alliance MIB Objects
FA MIB Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
revisionNumber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Connectivity Unit Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
uNumber (1.3.6.1.3.94.1.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
systemURL (1.3.6.1.3.94.1.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
statusChangeTime (1.3.6.1.3.94.1.3) . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
configurationChangeTime (1.3.6.1.3.94.1.4). . . . . . . . . . . . . . . . . . . . 5-4
connUnitTableChangeTime (1.3.6.1.3.94.1.5). . . . . . . . . . . . . . . . . . . 5-5
Connectivity Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
connUnitId (1.3.6.1.3.94.1.6.1.1). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
connUnitGlobalId (1.3.6.1.3.94.1.6.1.2). . . . . . . . . . . . . . . . . . . . . . . . 5-6
connUnitType (1.3.6.1.3.94.1.6.1.3) . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Page viii 59047-09 C
A
SANbox Simple Network Management Protocol
connUnitNumports (1.3.6.1.3.94.1.6.1.4) . . . . . . . . . . . . . . . . . . . . . . 5-6
connUnitState (1.3.6.1.3.94.1.6.1.5) . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
connUnitStatus (1.3.6.1.3.94.1.6.1.6) . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
connUnitProduct (1.3.6.1.3.94.1.6.1.7) . . . . . . . . . . . . . . . . . . . . . . . . 5-9
connUnitSn (1.3.6.1.3.94.1.6.1.8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
connUnitUpTime (1.3.6.1.3.94.1.6.1.9) . . . . . . . . . . . . . . . . . . . . . . . . 5-9
connUnitUrl (1.3.6.1.3.94.1.6.1.10) . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
connUnitDomainId (1.3.6.1.3.94.1.6.1.11 . . . . . . . . . . . . . . . . . . . . . . 5-10
connUnitProxyMaster (1.3.6.1.3.94.1.6.1.12) . . . . . . . . . . . . . . . . . . . 5-11
connUnitPrincipal (1.3.6.1.3.94.1.6.1.13) . . . . . . . . . . . . . . . . . . . . . . 5-12
connUnitNumSensors (1.3.6.1.3.94.1.6.1.14). . . . . . . . . . . . . . . . . . . 5-12
connUnitStatusChangeTime (1.3.6.1.3.94.1.6.1.15) . . . . . . . . . . . . . . 5-13
connUnitConfigurationChangeTime (1.3.6.1.3.94.1.6.1.16) . . . . . . . . 5-13
connUnitNumRevs (1.3.6.1.3.94.1.6.1.17) . . . . . . . . . . . . . . . . . . . . . 5-14
connUnitNumZones (1.3.6.1.3.94.1.6.1.18) . . . . . . . . . . . . . . . . . . . . 5-14
connUnitModuleId (1.3.6.1.3.94.1.6.1.19). . . . . . . . . . . . . . . . . . . . . . 5-15
connUnitName (1.3.6.1.3.94.1.6.1.20) . . . . . . . . . . . . . . . . . . . . . . . . 5-15
connUnitInfo (1.3.6.1.3.94.1.6.1.21) . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
connUnitControl (1.3.6.1.3.94.1.6.1.22) . . . . . . . . . . . . . . . . . . . . . . . 5-16
connUnitContact (1.3.6.1.3.94.1.6.1.23) . . . . . . . . . . . . . . . . . . . . . . . 5-17
connUnitLocation (1.3.6.1.3.94.1.6.1.24) . . . . . . . . . . . . . . . . . . . . . . 5-18
connUnitEventFilter (1.3.6.1.3.94.1.6.1.25). . . . . . . . . . . . . . . . . . . . . 5-18
connUnitNumEvents (1.3.6.1.3.94.1.6.1.26). . . . . . . . . . . . . . . . . . . . 5-19
connUnitMaxEvents (1.3.6.1.3.94.1.6.1.27) . . . . . . . . . . . . . . . . . . . . 5-20
connUnitEventCurrID (1.3.6.1.3.94.1.6.1.28) . . . . . . . . . . . . . . . . . . . 5-20
connUnitFabricID (1.3.6.1.3.94.1.6.1.29) . . . . . . . . . . . . . . . . . . . . . . 5-20
connUnitNumLinks (1.3.6.1.3.94.1.6.1.30) . . . . . . . . . . . . . . . . . . . . . 5-21
connUnitVendorId (1.3.6.1.3.94.1.6.1.31) . . . . . . . . . . . . . . . . . . . . . . 5-21
Revision Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21
connUnitRevsUnitId (1.3.6.1.3.94.1.7.1.1) . . . . . . . . . . . . . . . . . . . . . 5-22
connUnitRevsIndex (1.3.6.1.3.94.1.7.1.2). . . . . . . . . . . . . . . . . . . . . . 5-22
connUnitRevsRevId (1.3.6.1.3.94.1.7.1.3) . . . . . . . . . . . . . . . . . . . . . 5-22
connUnitRevsDescription (1.3.6.1.3.94.1.7.1.4) . . . . . . . . . . . . . . . . . 5-23
Sensor Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-24
connUnitSensorUnitId (1.3.6.1.3.94.1.8.1.1). . . . . . . . . . . . . . . . . . . . 5-24
connUnitSensorIndex (1.3.6.1.3.94.1.8.1.2) . . . . . . . . . . . . . . . . . . . . 5-24
connUnitSensorName (1.3.6.1.3.94.1.8.1.3). . . . . . . . . . . . . . . . . . . . 5-25
connUnitSensorStatus (1.3.6.1.3.94.1.8.1.4). . . . . . . . . . . . . . . . . . . . 5-26
connUnitSensorInfo (1.3.6.1.3.94.1.8.1.5). . . . . . . . . . . . . . . . . . . . . . 5-27
59047-09 C Page ix
SANbox Simple Network Management Protocol Reference Guide
connUnitSensorMessage (1.3.6.1.3.94.1.8.1.6) . . . . . . . . . . . . . . . . . 5-28
connUnitSensorType (1.3.6.1.3.94.1.8.1.7). . . . . . . . . . . . . . . . . . . . . 5-29
connUnitSensorCharacteristic (1.3.6.1.3.94.1.8.1.8). . . . . . . . . . . . . . 5-30
Port Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-31
connUnitPortUnitId (1.3.6.1.3.94.1.10.1.1) . . . . . . . . . . . . . . . . . . . . . 5-31
connUnitPortIndex (1.3.6.1.3.94.1.10.1.2). . . . . . . . . . . . . . . . . . . . . . 5-31
connUnitPortType (1.3.6.1.3.94.1.10.1.3) . . . . . . . . . . . . . . . . . . . . . . 5-32
connUnitPortFCClassCap (1.3.6.1.3.94.1.10.1.4). . . . . . . . . . . . . . . . 5-33
connUnitPortFCClassOp (1.3.6.1.3.94.1.10.1.5). . . . . . . . . . . . . . . . . 5-34
connUnitPortState (1.3.6.1.3.94.1.10.1.6). . . . . . . . . . . . . . . . . . . . . . 5-34
connUnitPortStatus (1.3.6.1.3.94.1.10.1.7) . . . . . . . . . . . . . . . . . . . . . 5-35
connUnitPortTransmitterType (1.3.6.1.3.94.1.10.1.8) . . . . . . . . . . . . . 5-35
connUnitPortModuleType (1.3.6.1.3.94.1.10.1.9) . . . . . . . . . . . . . . . . 5-36
connUnitPortWwn (1.3.6.1.3.94.1.10.1.10). . . . . . . . . . . . . . . . . . . . . 5-37
connUnitPortFCId (1.3.6.1.3.94.1.10.1.11) . . . . . . . . . . . . . . . . . . . . . 5-38
connUnitPortSn (1.3.6.1.3.94.1.10.1.12). . . . . . . . . . . . . . . . . . . . . . . 5-38
connUnitPortRevision (1.3.6.1.3.94.1.10.1.13) . . . . . . . . . . . . . . . . . . 5-38
connUnitPortVendor (1.3.6.1.3.94.1.10.1.14) . . . . . . . . . . . . . . . . . . . 5-39
connUnitPortSpeed (1.3.6.1.3.94.1.10.1.15). . . . . . . . . . . . . . . . . . . . 5-39
connUnitPortControl (1.3.6.1.3.94.1.10.1.16) . . . . . . . . . . . . . . . . . . . 5-40
connUnitPortName (1.3.6.1.3.94.1.10.1.17) . . . . . . . . . . . . . . . . . . . . 5-41
connUnitPortPhysicalNumber (1.3.6.1.3.94.1.10.1.18). . . . . . . . . . . . 5-42
connUnitPortStatObject (1.3.6.1.3.94.1.10.1.19). . . . . . . . . . . . . . . . . 5-42
connUnitPortProtocolCap (1.3.6.1.3.94.1.10.1.20) . . . . . . . . . . . . . . . 5-43
connUnitPortProtocolOp (1.3.6.1.3.94.1.10.1.21). . . . . . . . . . . . . . . . 5-43
connUnitPortNodeWwn (1.3.6.1.3.94.1.10.1.22). . . . . . . . . . . . . . . . . 5-44
connUnitPortHWState (1.3.6.1.3.94.1.10.1.23). . . . . . . . . . . . . . . . . . 5-44
Event Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-45
connUnitEventUnitId (1.3.6.1.3.94.1.11.1.1) . . . . . . . . . . . . . . . . . . . . 5-45
connUnitEventIndex (1.3.6.1.3.94.1.11.1.2) . . . . . . . . . . . . . . . . . . . . 5-46
connUnitEventId (1.3.6.1.3.94.1.11.1.3) . . . . . . . . . . . . . . . . . . . . . . . 5-47
connUnitREventTime (1.3.6.1.3.94.1.11.1.4). . . . . . . . . . . . . . . . . . . . 5-47
connUnitSEventTime (1.3.6.1.3.94.1.11.1.5). . . . . . . . . . . . . . . . . . . . 5-48
connUnitEventSeverity (1.3.6.1.3.94.1.11.1.6) . . . . . . . . . . . . . . . . . . 5-48
connUnitEventType (1.3.6.1.3.94.1.11.1.7). . . . . . . . . . . . . . . . . . . . . 5-48
connUnitEventObject (1.3.6.1.3.94.1.11.1.8). . . . . . . . . . . . . . . . . . . . 5-49
connUnitEventDescr (1.3.6.1.3.94.1.11.1.9) . . . . . . . . . . . . . . . . . . . . 5-49
Link Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-50
connUnitLinkUnitId (1.3.6.1.3.94.1.12.1.1) . . . . . . . . . . . . . . . . . . . . . 5-50
S
Page x 59047-09 C
A
SANbox Simple Network Management Protocol
connUnitLinkIndex (1.3.6.1.3.94.1.12.1.2). . . . . . . . . . . . . . . . . . . . . . 5-51
connUnitLinkNodeIdX (1.3.6.1.3.94.1.12.1.3). . . . . . . . . . . . . . . . . . . 5-51
connUnitLinkPortNumberX (1.3.6.1.3.94.1.12.1.4) . . . . . . . . . . . . . . . 5-51
connUnitLinkPortWwnX (1.3.6.1.3.94.1.12.1.5) . . . . . . . . . . . . . . . . . 5-52
connUnitLinkNodeIdY (1.3.6.1.3.94.1.12.1.6). . . . . . . . . . . . . . . . . . . 5-52
connUnitLinkPortNumberY (1.3.6.1.3.94.1.12.1.7) . . . . . . . . . . . . . . . 5-53
connUnitLinkPortWwnY (1.3.6.1.3.94.1.12.1.8) . . . . . . . . . . . . . . . . . 5-53
connUnitLinkAgentAddressY (1.3.6.1.3.94.1.12.1.9) . . . . . . . . . . . . . 5-53
connUnitLinkAgentAddressTypeY (1.3.6.1.3.94.1.12.1.10). . . . . . . . . 5-54
connUnitLinkAgentPortY (1.3.6.1.3.94.1.12.1.11). . . . . . . . . . . . . . . . 5-54
connUnitLinkUnitTypeY (1.3.6.1.3.94.1.12.1.12). . . . . . . . . . . . . . . . . 5-55
connUnitLinkConnIdY (1.3.6.1.3.94.1.12.1.13. . . . . . . . . . . . . . . . . . . 5-55
connUnitLinkCurrIndex (1.3.6.1.3.94.1.12.1.14) . . . . . . . . . . . . . . . . . 5-55
Zone Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-56
connUnitZoneIndex (1.3.6.1.3.94.1.13.1.1). . . . . . . . . . . . . . . . . . . . . 5-56
connUnitZoneMemberIndex (1.3.6.1.3.94.1.13.1.2) . . . . . . . . . . . . . . 5-56
connUnitZoneSetName (1.3.6.1.3.94.1.13.1.3). . . . . . . . . . . . . . . . . . 5-57
connUnitZoneSetNumZones (1.3.6.1.3.94.1.13.1.4). . . . . . . . . . . . . . 5-57
connUnitZoneName (1.3.6.1.3.94.1.13.1.5) . . . . . . . . . . . . . . . . . . . . 5-57
connUnitZoneCapabilities (1.3.6.1.3.94.1.13.1.6). . . . . . . . . . . . . . . . 5-58
connUnitZoneEnforcementState (1.3.6.1.3.94.1.13.1.7). . . . . . . . . . . 5-58
connUnitZoneAttributeBlock (1.3.6.1.3.94.1.13.1.8) . . . . . . . . . . . . . . 5-59
connUnitZoneNumMembers (1.3.6.1.3.94.1.13.1.9). . . . . . . . . . . . . . 5-59
connUnitZoneMemberIdType (1.3.6.1.3.94.1.13.1.10) . . . . . . . . . . . . 5-60
connUnitZoneMemberID (1.3.6.1.3.94.1.13.1.11). . . . . . . . . . . . . . . . 5-60
Zoning Alias Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-61
connUnitZoningAliasIndex (1.3.6.1.3.94.1.14.1.1) . . . . . . . . . . . . . . . 5-61
connUnitZoningAliasMemberIndex (1.3.6.1.3.94.1.14.1.2). . . . . . . . . 5-61
connUnitZoningAliasNumAliases (1.3.6.1.3.94.1.14.1.3) . . . . . . . . . . 5-62
connUnitZoningAliasName (1.3.6.1.3.94.1.14.1.4) . . . . . . . . . . . . . . . 5-62
connUnitZoningAliasNumMembers (1.3.6.1.3.94.1.14.1.5). . . . . . . . . 5-62
connUnitZoningAliasMemberIdType (1.3.6.1.3.94.1.14.1.6). . . . . . . . 5-63
connUnitZoningAliasMemberID (1.3.6.1.3.94.1.14.1.7) . . . . . . . . . . . 5-63
Port Statistics Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-64
connUnitPortStatUnitId (1.3.6.1.3.94.4.5.1.1) . . . . . . . . . . . . . . . . . . . 5-64
connUnitPortStatIndex (1.3.6.1.3.94.4.5.1.2) . . . . . . . . . . . . . . . . . . . 5-65
connUnitPortStatCountError (1.3.6.1.3.94.4.5.1.3) . . . . . . . . . . . . . . . 5-65
connUnitPortStatCountTxObjects (1.3.6.1.3.94.4.5.1.4) . . . . . . . . . . . 5-65
connUnitPortStatCountRxObjects (1.3.6.1.3.94.4.5.1.5). . . . . . . . . . . 5-66
59047-09 C Page xi
SANbox Simple Network Management Protocol Reference Guide
connUnitPortStatCountTxElements (1.3.6.1.3.94.4.5.1.6). . . . . . . . . . 5-66
connUnitPortStatCountRxElements (1.3.6.1.3.94.4.5.1.7) . . . . . . . . . 5-67
connUnitPortStatCountBBCreditZero (1.3.6.1.3.94.4.5.1.8) . . . . . . . . 5-67
connUnitPortStatCountInputBuffersFull (1.3.6.1.3.94.4.5.1.9) . . . . . . 5-67
connUnitPortStatCountFBSYFrames (1.3.6.1.3.94.4.5.1.10) . . . . . . . 5-68
connUnitPortStatCountPBSYFrames (1.3.6.1.3.94.4.5.1.11) . . . . . . . 5-68
connUnitPortStatCountFRJTFrames (1.3.6.1.3.94.4.5.1.12). . . . . . . . 5-69
connUnitPortStatCountPRJTFrames (1.3.6.1.3.94.4.5.1.13) . . . . . . . 5-69
connUnitPortStatCountClass1RxFrames (1.3.6.1.3.94.4.5.1.14) . . . . 5-70
connUnitPortStatCountClass1TxFrames (1.3.6.1.3.94.4.5.1.15). . . . . 5-70
connUnitPortStatCountClass1FBSYFrames (1.3.6.1.3.94.4.5.1.16 . . 5-70
connUnitPortStatCountClass1PBSYFrames (1.3.6.1.3.94.4.5.1.17). . 5-71
connUnitPortStatCountClass1FRJTFrames (1.3.6.1.3.94.4.5.1.18. . . 5-71
connUnitPortStatCountClass1PRJTFrames (1.3.6.1.3.94.4.5.1.19) . . 5-72
connUnitPortStatCountClass2RxFrames (1.3.6.1.3.94.4.5.1.20) . . . . 5-72
connUnitPortStatCountClass2TxFrames (1.3.6.1.3.94.4.5.1.21) . . . . 5-72
connUnitPortStatCountClass2FBSYFrames (1.3.6.1.3.94.4.5.1.22). . 5-73
connUnitPortStatCountClass2PBSYFrames (1.3.6.1.3.94.4.5.1.23). . 5-73
connUnitPortStatCountClass2FRJTFrames (1.3.6.1.3.94.4.5.1.24) . . 5-74
connUnitPortStatCountClass2PRJTFrames (1.3.6.1.3.94.4.5.1.25) . . 5-74
connUnitPortStatCountClass3RxFrames (1.3.6.1.3.94.4.5.1.26) . . . . 5-74
connUnitPortStatCountClass3TxFrames (1.3.6.1.3.94.4.5.1.27) . . . . 5-75
connUnitPortStatCountClass3Discards (1.3.6.1.3.94.4.5.1.28). . . . . . 5-75
connUnitPortStatCountRxMulticastObjects (1.3.6.1.3.94.4.5.1.29). . . 5-76
connUnitPortStatCountTxMulticastObjects (1.3.6.1.3.94.4.5.1.30). . . 5-76
connUnitPortStatCountRxBroadcastObjects (1.3.6.1.3.94.4.5.1.31). . 5-76
connUnitPortStatCountTxBroadcastObjects (1.3.6.1.3.94.4.5.1.32). . 5-77
connUnitPortStatCountRxLinkResets (1.3.6.1.3.94.4.5.1.33) . . . . . . . 5-77
connUnitPortStatCountTxLinkResets (1.3.6.1.3.94.4.5.1.34) . . . . . . . 5-77
connUnitPortStatCountNumberLinkResets (1.3.6.1.3.94.4.5.1.35). . . 5-78
connUnitPortStatCountRxOfflineSequences (1.3.6.1.3.94.4.5.1.36). . 5-78
connUnitPortStatCountTxOfflineSequences (1.3.6.1.3.94.4.5.1.37). . 5-79
connUnitPortStatCountNumberOfflineSequences (1.3.6.1.3.94.4.5.1.38)
5-79
connUnitPortStatCountLinkFailures (1.3.6.1.3.94.4.5.1.39) . . . . . . . . 5-79
connUnitPortStatCountInvalidCRC (1.3.6.1.3.94.4.5.1.40) . . . . . . . . . 5-80
connUnitPortStatCountInvalidTxWords (1.3.6.1.3.94.4.5.1.41). . . . . . 5-80
connUnitPortStatCountPrimitiveSequenceProtocolErrors
(1.3.6.1.3.94.4.5.1.42) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-81
connUnitPortStatCountLossofSignal (1.3.6.1.3.94.4.5.1.43). . . . . . . . 5-81
S
Page xii 59047-09 C
A
SANbox Simple Network Management Protocol
connUnitPortStatCountLossofSynchronization (1.3.6.1.3.94.4.5.1.44) 5-81
connUnitPortStatCountInvalidOrderedSets (1.3.6.1.3.94.4.5.1.45). . . 5-82
connUnitPortStatCountFramesTooLong (1.3.6.1.3.94.4.5.1.46) . . . . . 5-82
connUnitPortStatCountFramesTruncated (1.3.6.1.3.94.4.5.1.47). . . . 5-83
connUnitPortStatCountAddressErrors (1.3.6.1.3.94.4.5.1.48). . . . . . . 5-83
connUnitPortStatCountDelimiterErrors (1.3.6.1.3.94.4.5.1.49) . . . . . . 5-83
connUnitPortStatCountEncodingDisparityErrors (1.3.6.1.3.94.4.5.1.50) 5-84
Simple Name Server Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-84
connUnitSnsMaxEntry (1.3.6.1.3.94.5.1.1) . . . . . . . . . . . . . . . . . . . . . 5-85
connUnitSnsId (1.3.6.1.3.94.5.2.1.1.1) . . . . . . . . . . . . . . . . . . . . . . . . 5-85
connUnitSnsPortIndex (1.3.6.1.3.94.5.2.1.1.2). . . . . . . . . . . . . . . . . . 5-85
connUnitSnsPortIdentifier (1.3.6.1.3.94.5.2.1.1.3) . . . . . . . . . . . . . . . 5-86
connUnitSnsPortName (1.3.6.1.3.94.5.2.1.1.4). . . . . . . . . . . . . . . . . . 5-86
connUnitSnsNodeName (1.3.6.1.3.94.5.2.1.1.5). . . . . . . . . . . . . . . . . 5-86
connUnitSnsClassOfSvc (1.3.6.1.3.94.5.2.1.1.6) . . . . . . . . . . . . . . . . 5-87
connUnitSnsNodeIPAddress (1.3.6.1.3.94.5.2.1.1.7) . . . . . . . . . . . . . 5-87
connUnitSnsProcAssoc (1.3.6.1.3.94.5.2.1.1.8) . . . . . . . . . . . . . . . . . 5-88
connUnitSnsFC4Type (1.3.6.1.3.94.5.2.1.1.9) . . . . . . . . . . . . . . . . . . 5-88
connUnitSnsPortType (1.3.6.1.3.94.5.2.1.1.10) . . . . . . . . . . . . . . . . . 5-88
connUnitSnsPortIPAddress (1.3.6.1.3.94.5.2.1.1.11) . . . . . . . . . . . . . 5-89
connUnitSnsFabricPortName (1.3.6.1.3.94.5.2.1.1.12). . . . . . . . . . . . 5-89
connUnitSnsHardAddress (1.3.6.1.3.94.5.2.1.1.13) . . . . . . . . . . . . . . 5-90
connUnitSnsSymbolicPortName (1.3.6.1.3.94.5.2.1.1.14) . . . . . . . . . 5-90
connUnitSnsSymbolicNodeName (1.3.6.1.3.94.5.2.1.1.15) . . . . . . . . 5-91
Platform Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-91
connUnitPlatformMaxEntry (1.3.6.1.3.94.5.1.2) . . . . . . . . . . . . . . . . . 5-91
connUnitPlatformIndex (1.3.6.1.3.94.5.2.2.1.1). . . . . . . . . . . . . . . . . . 5-92
connUnitPlatformNodeIndex (1.3.6.1.3.94.5.2.2.1.2) . . . . . . . . . . . . . 5-92
connUnitPlatformUnitID (1.3.6.1.3.94.5.2.2.1.3) . . . . . . . . . . . . . . . . . 5-92
connUnitPlatformName (1.3.6.1.3.94.5.2.2.1.4) . . . . . . . . . . . . . . . . . 5-93
connUnitPlatformType (1.3.6.1.3.94.5.2.2.1.6) . . . . . . . . . . . . . . . . . . 5-93
connUnitPlatformLabel (1.3.6.1.3.94.5.2.2.1.7). . . . . . . . . . . . . . . . . . 5-93
connUnitPlatformDescription (1.3.6.1.3.94.5.2.2.1.8) . . . . . . . . . . . . . 5-94
connUnitPlatformLocation (1.3.6.1.3.94.5.2.2.1.9) . . . . . . . . . . . . . . . 5-94
connUnitPlatformManagementUrl (1.3.6.1.3.94.5.2.2.1.10) . . . . . . . . 5-95
connUnitPlatformNumNodes (1.3.6.1.3.94.5.2.2.1.11) . . . . . . . . . . . . 5-95
connUnitPlatformNodeName (1.3.6.1.3.94.5.2.2.1.12). . . . . . . . . . . . 5-95
Trap Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-96
trapMaxClients (1.3.6.1.3.94.2.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-96
59047-09 C Page xiii
SANbox Simple Network Management Protocol Reference Guide
trapClientCount (1.3.6.1.3.94.2.2). . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-97
trapRegIpAddress (1.3.6.1.3.94.2.3.1.1). . . . . . . . . . . . . . . . . . . . . . . 5-97
trapRegPort (1.3.6.1.3.94.2.3.1.2). . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-98
trapRegFilter (1.3.6.1.3.94.2.3.1.3). . . . . . . . . . . . . . . . . . . . . . . . . . . 5-98
trapRegRowState (1.3.6.1.3.94.2.3.1.4) . . . . . . . . . . . . . . . . . . . . . . . 5-98
Related Traps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-100
connUnitStatusChange (1.3.6.1.3.94.0.1) . . . . . . . . . . . . . . . . . . . . . . 5-100
connUnitDeletedTrap (1.3.6.1.3.94.0.3) . . . . . . . . . . . . . . . . . . . . . . . 5-100
connUnitEventTrap (1.3.6.1.3.94.0.4) . . . . . . . . . . . . . . . . . . . . . . . . . 5-100
connUnitSensorStatusChange (1.3.6.1.3.94.0.5) . . . . . . . . . . . . . . . . 5-102
connUnitPortStatusChange (1.3.6.1.3.94.0.6). . . . . . . . . . . . . . . . . . . 5-102
coldStart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-103
authenticationFailure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-103
6 Fabric Element MIB Objects
Fibre Channel FE MIB Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Configuration Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
fcFeFabricName (1.3.6.1.2.1.75.1.1.1) . . . . . . . . . . . . . . . . . . . . . . . . 6-3
fcFeElementName (1.3.6.1.2.1.75.1.1.2) . . . . . . . . . . . . . . . . . . . . . . 6-3
fcFeModuleCapacity (1.3.6.1.2.1.75.1.1.3). . . . . . . . . . . . . . . . . . . . . 6-3
Module Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
fcFeModuleDescr (1.3.6.1.2.1.75.1.1.4.1.2) . . . . . . . . . . . . . . . . . . . . 6-4
fcFeModuleObjectID (1.3.6.1.2.1.75.1.1.4.1.3). . . . . . . . . . . . . . . . . . 6-4
fcFeModuleOperStatus (1.3.6.1.2.1.75.1.1.4.1.4) . . . . . . . . . . . . . . . . 6-5
fcFeModuleLastChange (1.3.6.1.2.1.75.1.1.4.1.5) . . . . . . . . . . . . . . . 6-6
fcFeModuleFxPortCapacity (1.3.6.1.2.1.75.1.1.4.1.6). . . . . . . . . . . . . 6-6
fcFeModuleName (1.3.6.1.2.1.75.1.1.4.1.7) . . . . . . . . . . . . . . . . . . . . 6-6
FxPort Configuration Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
fcFxPortName (1.3.6.1.2.1.75.1.1.5.1.2). . . . . . . . . . . . . . . . . . . . . . . 6-7
fcFxPortFcphVersionHigh (1.3.6.1.2.1.75.1.1.5.1.3) . . . . . . . . . . . . . . 6-7
fcFxPortFcphVersionLow (1.3.6.1.2.1.75.1.1.5.1.4) . . . . . . . . . . . . . . 6-8
fcFxPortBbCredit (1.3.6.1.2.1.75.1.1.5.1.5). . . . . . . . . . . . . . . . . . . . . 6-8
fcFxPortRxBufSize (1.3.6.1.2.1.75.1.1.5.1.6) . . . . . . . . . . . . . . . . . . . 6-9
fcFxPortRatov (1.3.6.1.2.1.75.1.1.5.1.7). . . . . . . . . . . . . . . . . . . . . . . 6-9
fcFxPortEdtov (1.3.6.1.2.1.75.1.1.5.1.8) . . . . . . . . . . . . . . . . . . . . . . . 6-9
fcFxPortCosSupported (1.3.6.1.2.1.75.1.1.5.1.9) . . . . . . . . . . . . . . . . 6-10
fcFxPortIntermixSupported (1.3.6.1.2.1.75.1.1.5.1.10). . . . . . . . . . . . 6-10
fcFxPortStackedConnMode (1.3.6.1.2.1.75.1.1.5.1.11). . . . . . . . . . . . 6-10
fcFxPortClass2SeqDeliv (1.3.6.1.2.1.75.1.1.5.1.12) . . . . . . . . . . . . . . 6-11
fcFxPortClass3SeqDeliv (1.3.6.1.2.1.75.1.1.5.1.13) . . . . . . . . . . . . . . 6-11
S
Page xiv 59047-09 C
A
SANbox Simple Network Management Protocol
fcFxPortHoldTime (1.3.6.1.2.1.75.1.1.5.1.14) . . . . . . . . . . . . . . . . . . . 6-12
The Status Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
fcFxPortID (1.3.6.1.2.1.75.1.2.1.1.1). . . . . . . . . . . . . . . . . . . . . . . . . . 6-12
fcFxPortBbCreditAvailable (1.3.6.1.2.1.75.1.2.1.1.2) . . . . . . . . . . . . . 6-13
fcFxPortOperMode (1.3.6.1.2.1.75.1.2.1.1.3) . . . . . . . . . . . . . . . . . . . 6-13
fcFxPortAdminMode (1.3.6.1.2.1.75.1.2.1.1.4) . . . . . . . . . . . . . . . . . . 6-14
FxPort Physical Level Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
fcFxPortPhysAdminStatus (1.3.6.1.2.1.75.1.2.2.1.1). . . . . . . . . . . . . . 6-14
fcFxPortPhysOperStatus (1.3.6.1.2.1.75.1.2.2.1.2). . . . . . . . . . . . . . . 6-15
fcFxPortPhysLastChange (1.3.6.1.2.1.75.1.2.2.1.3). . . . . . . . . . . . . . 6-16
fcFxPortPhysRttov (1.3.6.1.2.1.75.1.2.2.1.4) . . . . . . . . . . . . . . . . . . . 6-16
Fx Port Fabric Login Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-17
fcFxPortFcphVersionAgreed (1.3.6.1.2.1.75.1.2.3.1.2). . . . . . . . . . . . 6-17
fcFxPortNxPortBbCredit (1.3.6.1.2.1.75.1.2.3.1.3) . . . . . . . . . . . . . . . 6-17
fcFxPortNxPortRxDataFieldSize (1.3.6.1.2.1.75.1.2.3.1.4). . . . . . . . . 6-18
fcFxPortCosSuppAgreed (1.3.6.1.2.1.75.1.2.3.1.5) . . . . . . . . . . . . . . 6-18
fcFxPortIntermixSuppAgreed (1.3.6.1.2.1.75.1.2.3.1.6) . . . . . . . . . . . 6-19
fcFxPortStackedConnModeAgreed (1.3.6.1.2.1.75.1.2.3.1.7). . . . . . . 6-19
fcFxPortClass2SeqDelivAgreed (1.3.6.1.2.1.75.1.2.3.1.8) . . . . . . . . . 6-20
fcFxPortClass3SeqDelivAgreed (1.3.6.1.2.1.75.1.2.3.1.9) . . . . . . . . . 6-20
fcFxPortNxPortName (1.3.6.1.2.1.75.1.2.3.1.10) . . . . . . . . . . . . . . . . 6-21
fcFxPortConnectedNxPort (1.3.6.1.2.1.75.1.2.3.1.11). . . . . . . . . . . . . 6-21
fcFxPortBbCreditModel (1.3.6.1.2.1.75.1.2.3.1.12). . . . . . . . . . . . . . . 6-21
The Error Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-22
fcFxPortLinkFailures (1.3.6.1.2.1.75.1.3.1.1.1). . . . . . . . . . . . . . . . . . 6-22
fcFxPortSyncLosses (1.3.6.1.2.1.75.1.3.1.1.2). . . . . . . . . . . . . . . . . . 6-22
fcFxPortSigLosses (1.3.6.1.2.1.75.1.3.1.1.3) . . . . . . . . . . . . . . . . . . . 6-23
fcFxPortPrimSeqProtoErrors (1.3.6.1.2.1.75.1.3.1.1.4). . . . . . . . . . . . 6-23
fcFxPortInvalidTxWords (1.3.6.1.2.1.75.1.3.1.1.5) . . . . . . . . . . . . . . . 6-23
fcFxPortInvalidCrcs (1.3.6.1.2.1.75.1.3.1.1.6). . . . . . . . . . . . . . . . . . . 6-24
fcFxPortDelimiterErrors (1.3.6.1.2.1.75.1.3.1.1.7). . . . . . . . . . . . . . . . 6-24
fcFxPortAddressIdErrors (1.3.6.1.2.1.75.1.3.1.1.8). . . . . . . . . . . . . . . 6-24
fcFxPortLinkResetIns (1.3.6.1.2.1.75.1.3.1.1.9) . . . . . . . . . . . . . . . . . 6-25
fcFxPortLinkResetOuts (1.3.6.1.2.1.75.1.3.1.1.10). . . . . . . . . . . . . . . 6-25
fcFxPortOlsIns (1.3.6.1.2.1.75.1.3.1.1.11). . . . . . . . . . . . . . . . . . . . . . 6-25
fcFxPortOlsOuts (1.3.6.1.2.1.75.1.3.1.1.12) . . . . . . . . . . . . . . . . . . . . 6-26
Accounting Groups. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-26
Class 1 Accounting Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-26
fcFxPortC1InFrames (1.3.6.1.2.1.75.1.4.1.1.1). . . . . . . . . . . . . . . . . . 6-26
59047-09 C Page xv
SANbox Simple Network Management Protocol Reference Guide
fcFxPortC1OutFrames (1.3.6.1.2.1.75.1.4.1.1.2) . . . . . . . . . . . . . . . . 6-27
fcFxPortC1InOctets (1.3.6.1.2.1.75.1.4.1.1.3). . . . . . . . . . . . . . . . . . . 6-27
fcFxPortC1OutOctets (1.3.6.1.2.1.75.1.4.1.1.4) . . . . . . . . . . . . . . . . . 6-27
fcFxPortC1Discards (1.3.6.1.2.1.75.1.4.1.1.5) . . . . . . . . . . . . . . . . . . 6-28
fcFxPortC1FbsyFrames (1.3.6.1.2.1.75.1.4.1.1.6) . . . . . . . . . . . . . . . 6-28
fcFxPortC1FrjtFrames (1.3.6.1.2.1.75.1.4.1.1.7). . . . . . . . . . . . . . . . . 6-28
fcFxPortC1InConnections (1.3.6.1.2.1.75.1.4.1.1.8). . . . . . . . . . . . . . 6-29
fcFxPortC1OutConnections (1.3.6.1.2.1.75.1.4.1.1.9) . . . . . . . . . . . . 6-29
fcFxPortC1ConnTime (1.3.6.1.2.1.75.1.4.1.1.10) . . . . . . . . . . . . . . . . 6-30
Class 2 Accounting Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-30
fcFxPortC2InFrames (1.3.6.1.2.1.75.1.4.2.1.1). . . . . . . . . . . . . . . . . . 6-30
fcFxPortC2OutFrames (1.3.6.1.2.1.75.1.4.2.1.2) . . . . . . . . . . . . . . . . 6-30
fcFxPortC2InOctets (1.3.6.1.2.1.75.1.4.2.1.3). . . . . . . . . . . . . . . . . . . 6-31
fcFxPortC2OutOctets (1.3.6.1.2.1.75.1.4.2.1.4) . . . . . . . . . . . . . . . . . 6-31
fcFxPortC2Discards (1.3.6.1.2.1.75.1.4.2.1.5) . . . . . . . . . . . . . . . . . . 6-32
fcFxPortC2FbsyFrames (1.3.6.1.2.1.75.1.4.2.1.6) . . . . . . . . . . . . . . . 6-32
fcFxPortC2FrjtFrames (1.3.6.1.2.1.75.1.4.2.1.7). . . . . . . . . . . . . . . . . 6-32
Class 3 Accounting Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-33
fcFxPortC3InFrames (1.3.6.1.2.1.75.1.4.3.1.1). . . . . . . . . . . . . . . . . . 6-33
fcFxPortC3OutFrames (1.3.6.1.2.1.75.1.4.3.1.2) . . . . . . . . . . . . . . . . 6-33
fcFxPortC3InOctets (1.3.6.1.2.1.75.1.4.3.1.3). . . . . . . . . . . . . . . . . . . 6-34
fcFxPortC3OutOctets (1.3.6.1.2.1.75.1.4.3.1.4) . . . . . . . . . . . . . . . . . 6-34
fcFxPortC3Discards (1.3.6.1.2.1.75.1.4.3.1.5) . . . . . . . . . . . . . . . . . . 6-34
Capability Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-35
fcFxPortCapFcphVersionHigh (1.3.6.1.2.1.75.1.5.1.1.1). . . . . . . . . . . 6-35
fcFxPortCapFcphVersionLow (1.3.6.1.2.1.75.1.5.1.1.2) . . . . . . . . . . . 6-35
fcFxPortCapBbCreditMax (1.3.6.1.2.1.75.1.5.1.1.3). . . . . . . . . . . . . . 6-36
fcFxPortCapBbCreditMin (1.3.6.1.2.1.75.1.5.1.1.4) . . . . . . . . . . . . . . 6-36
fcFxPortCapRxDataFieldSizeMax (1.3.6.1.2.1.75.1.5.1.1.5). . . . . . . . 6-36
fcFxPortCapRxDataFieldSizeMin (1.3.6.1.2.1.75.1.5.1.1.6) . . . . . . . . 6-37
fcFxPortCapCos (1.3.6.1.2.1.75.1.5.1.1.7) . . . . . . . . . . . . . . . . . . . . . 6-37
fcFxPortCapIntermix (1.3.6.1.2.1.75.1.5.1.1.8). . . . . . . . . . . . . . . . . . 6-37
fcFxPortCapStackedConnMode (1.3.6.1.2.1.75.1.5.1.1.9) . . . . . . . . . 6-38
fcFxPortCapClass2SeqDeliv (1.3.6.1.2.1.75.1.5.1.1.10). . . . . . . . . . . 6-38
fcFxPortCapClass3SeqDeliv (1.3.6.1.2.1.75.1.5.1.1.11). . . . . . . . . . . 6-38
fcFxPortCapHoldTimeMaxv (1.3.6.1.2.1.75.1.5.1.1.12) . . . . . . . . . . . 6-39
fcFxPortCapHoldTimeMin (1.3.6.1.2.1.75.1.5.1.1.13). . . . . . . . . . . . . 6-39
S
7 QLOGIC MIB Objects
QLOGIC MIB Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Page xvi 59047-09 C
A
fcQxPortPhysAdminStatus (1.3.6.1.4.1.1663.1.3.10.1.1.3). . . . . . . . . 7-1
fcQxPortPhysOperStatus (1.3.6.1.4.1.1663.1.3.10.1.1.4). . . . . . . . . . 7-2
Related Traps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
qlSB2PortLinkDown (qLogicExperimental 0 10) . . . . . . . . . . . . . . . . . 7-3
qlSB2PortLinkUp (qLogicExperimental 0 11) . . . . . . . . . . . . . . . . . . . 7-3
qlconnUnitAddedTrap (qLogicExperimental 0 12). . . . . . . . . . . . . . . . 7-3
8 Firmware Download MIB Objects
Firmware Download MIB Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
qlgcChFwOpResult (1.3.6.1.4.1.3873.3.1.1.2.1). . . . . . . . . . . . . . . . . 8-1
qlgcChFwOpRequest (1.3.6.1.4.1.3873.3.1.1.2.2) . . . . . . . . . . . . . . . 8-2
qlgcChFwDwldHostAddrType (1.3.6.1.4.1.3873.3.1.1.2.3). . . . . . . . . 8-2
qlgcChFwDwldHostAddr (1.3.6.1.4.1.3873.3.1.1.2.4). . . . . . . . . . . . . 8-3
qlgcChFwDwldHostPort (1.3.6.1.4.1.3873.3.1.1.2.5) . . . . . . . . . . . . . 8-3
qlgcChFwDwldPathName (1.3.6.1.4.1.3873.3.1.1.2.6). . . . . . . . . . . . 8-3
qlgcChFwDwldFileName (1.3.6.1.4.1.3873.3.1.1.2.7). . . . . . . . . . . . . 8-3
qlgcChFwResetMethod (1.3.6.1.4.1.3873.3.1.1.2.8). . . . . . . . . . . . . . 8-4
SANbox Simple Network Management Protocol
9 Maintenance Panel Health Check MIB Objects
Maintenance Panel MIB Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
qlgcMPStatus (1.3.6.1.4.1.3873.3.2.1.1.1) . . . . . . . . . . . . . . . . . . . . . 9-1
Related Traps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
qlgcMPStatusChange (1.3.6.1.4.1.3873.3.2.0.1). . . . . . . . . . . . . . . . . 9-2
Glossary Index
List of Figures
Figure Page
2-1 SNMP Interface Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
5-1 connUnitEventDescr Variable Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-100
List of Tables
Table Page
2-1 Trap Severity Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
4-1 MIB-II Groups. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
5-1 FA-MIB Textual Substitutions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
5-2 Switch Operational States . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
5-3 SANbox 5000 Series Connectivity Unit Return Values . . . . . . . . . . . . . . . . . . . . . . 5-8
5-4 SANbox 9000 Series Connectivity Unit Return Values . . . . . . . . . . . . . . . . . . . . . . 5-8
5-5 connUnitContol Read Return Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17
59047-09 C Page xvii
SANbox Simple Network Management Protocol Reference Guide
5-6 connUnitContol Write Control Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17
5-7 connUnitEventFilter Read Return Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
5-8 connUnitEventFilter Control Write Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
5-9 SANbox 5000/9000 Series ConnUnitRevsRevId Return Values . . . . . . . . . . . . . . . 5-23
5-10 SANbox 5200/5600 Series ConnUnitRevsDescription Return Values. . . . . . . . . . . 5-23
5-11 SANbox 5200/5600 ConnUnitSensorName Return Va lues . . . . . . . . . . . . . . . . . . . 5-25
5-12 SANbox 5202/5602 ConnUnitSensorName Return Values . . . . . . . . . . . . . . . . . . . 5-26
5-13 SANbox 9000 ConnUnitSensorName Return Values . . . . . . . . . . . . . . . . . . . . . . . 5-26
5-14 ConnUnitSensorStatus Return Values for Board Temperature . . . . . . . . . . . . . . . . 5-27
5-15 ConnUnitSensorStatus Return Values for Fan Status . . . . . . . . . . . . . . . . . . . . . . . 5-27
5-16 ConnUnitSensorStatus Return Values for Voltage Status . . . . . . . . . . . . . . . . . . . . 5-27
5-17 ConnUnitSensorMessage Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-28
5-18 ConnUnitSensorType Return Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-29
5-19 ConnUnitSensorCharacteristic Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-30
5-20 ConnUnitPortType Return Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-32
5-21 ConnUnitPortState Return Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-35
5-22 ConnUnitPortTransmitterType Return Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-36
5-23 ConnUnitPortModuleType Return Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-37
5-24 ConnUnitPortControl Read Return Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-41
5-25 ConnUnitPortControl Write Command Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-41
5-26 ConnUnitPortHWState Port State Return Values. . . . . . . . . . . . . . . . . . . . . . . . . . . 5-45
5-27 ConnUnitPortType State Return Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-89
5-28 Trap Severity Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-96
5-29 connUnitEventDescr Variable Field Descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . 5-101
5-30 Filter Trap Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-101
6-1 FA-MIB Textual Substitutions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6-2 Module Operational Status Return Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
6-3 Port Operational Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-13
6-4 fcFxPortPhysAdminStatus Read Return Values . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
6-5 fcFxPortPhysAdminStatus Write Values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
6-6 fcFxPortPHysOperStatus Return Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16
7-1 fcQxPortPhysAdminStatus Read Return Values . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
7-2 fcQxPortPhysAdminStatus Write Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
7-3 fcFxPortPHysOperStatus Return Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
S
Page xviii 59047-09 C

1 Introduction

This guide describes the support for Simple Network Management Protocol (SNMP) used with SANbox switch products. This Simple Network Management Protocol Reference Guide describes how to use SNMP to manage and monitor the SANbox switch products.
This guide is organized as follows:
Section 2 provides an overview of SNMP objectives, managers and agents,
traps, Management Information Bases (MIB), and User Datagram Protocol.
Section 3 describes how to configure a SANbox switch using Telnet and the
Enterprise Fabric Suite 2007 graphical user interface.
Section 4 describes the Management Information Bases (MIB-II). Section 5 describes the Fibre Alliance - Management Information Bases
(FA-MIB version 4.0).
Section 6 describes the Fabric Element - Management Information Bases
(FE-MIB).
Section 7 describes the QLOGIC Management Information Bases
(QLOGIC-MIB).
Section 8 describes the Firmware Download Management Information
Bases (FD-MIB).

Intended Audience

This guide is intended for users responsible for the support of SNMP and SANbox switch configurations.
59047-09 C 1-1
1 – Introduction Related Materials

Related Materials

Refer to the following publications for switch hardware and installation information:
SANbox 5600 Series Enterprise Fabric Suite 2007 User Guide, publication
number 59097-06. SANbox 5802V Enterprise Fabric Suite 2007 User Guide, publication
number 59266-00 A.
SANbox 5802V Fibre Channel Switch Installation Guide, publication number
59265-01.
SANbox 5600 Series Fibre Channel Switch Installation Guide, publication
number 59096-06.
SANbox 5802V Fibre Channel Switch Command Line Interface Guide,
publication number 59263-01.
SANbox 5600 Series Fibre Channel Switch Command Line Interface Guide,
publication number 59183-03.
S

Technical Support

Customers should contact their authorized maintenance provider for technical support of their QLogic switch products. QLogic-direct customers may contact QLogic Technical Support; others will be redirected to their authorized maintenance provider.
Visit the QLogic switch support Web site listed in “Contact Information” on
page 1-3 for the latest firmware and software updates.

Availability

QLogic Technical Support is available from 7:00 AM to 7:00 PM Central Standard Time, Monday through Friday, excluding QLogic-observed holidays.

Training

QLogic offers certification training for the technical professional for both the SANblade HBAs and the SANbox switches. From the training link at www.qlogic.com, you may choose Electronic-Based Training or schedule an intensive "hands-on" Certification course.
1-2 59047-09 C
A

Contact Information

Please feel free to contact your QLogic approved reseller or QLogic Technical Support at any phase of integration for assistance. QLogic Technical Support can be reached by the following methods:
Web http://support.qlogic.com North America Contact Information
Email support@qlogic.com Phone (952) 932-4040
Support contact information for other regions of the world is available at the QLogic website: http://support.qlogic.com
The QLogic knowledge database contains troubleshooting information for the QLogic HBAs. Access the data base from the QLogic web site, www.qlogic.com Click the Support tab, Use the search engine at the top of the page to look for specific troubleshooting information.
1 – Introduction
Technical Support
.
59047-09 C 1-3
1 – Introduction Technical Support
S
Notes
1-4 59047-09 C

2 SNMP Overview

Simple Network Management Protocol is the protocol governing network management and monitoring of network devices. This Simple Network Management Protocol Reference Guide describes how to use SNMP to manage and monitor the SANbox switch products. Specifically, this guide describes the SNMP agent that resides on the switch.
The following topics are covered in this section:
SNMP interface objectives Manager and agent Traps Management information bases (MIBs) User datagram protocol (UDP) Numbering system conventions

SNMP Interface Objectives

The objectives of the SNMP Interface are as follows: Connect to the SNMP agent that resides on the switch using a management
workstation. Support of Fabric Element Management Information Bases (FE-MIB)
(rfc2837) and Fibre Alliance Management Information Bases (FA-MIB) draft.
Support of version 1 and 2 traps. The SNMP agent supports SNMPv1and SNMPv2c.

Manager and Agent

The two primary elements of SNMP are:
Manager — the application that runs on the management workstation. Agent — the daemon application that runs on the switch.
59047-09 C 2-1
2 – SNMP Overview Traps
The Manager is the application through which the network administrator performs network management functions. The SNMP agent is the direct interface on the switch for any SNMP manager connecting to the switch using the SNMP protocol, as shown in Figure 2-1. The agent will be started by the script file(s) responsible for switch initialization when the switch powers up or when the switch is reset.
When an SNMP request arrives at the agent, the agent will compose a message and pass it on to Switch Management to process the message and provide a response to the agent. The agent then provides a response to the originator of the SNMP request. The SNMP agent does not have direct access to the internal database of the switch.
S
Workstation with SNMP
Manager Application

Traps

Ethernet Connection
Switch with Agent and
Common User Interface API
Figure 2-1 SNMP Interface Architecture
Traps are notification messages sent from the switch to a registered manager when a change of state occurs within the switch. A change of state can be an alarm condition or simply a configuration change.
The Fibre Alliance MIB defines a trap table configurable through SNMP. A trap table may have up to 5 entries, and can be configured using the SNMP Manager or Enterprise Fabric Suite 2007 graphical user interface. The same trap table information is available to both SNMP Manager and Enterprise Fabric Suite 2007.
A trap event is reported when the incoming error has a severity level less than or equal to the configured severity level. The trap event types and trap severity levels are listed in Table 2-1. Refer to Table 5-1 for information on specific traps.
2-2 59047-09 C
A
2 – SNMP Overview

Management Information Base

Table 2-1. Trap Severity Levels
Event Type Severity Level
Unknown 1 Emergency 2 Alert 3 Critical 4 Error 5 Warning 6 Notify 7 Info 8 Debug 9 Mark 10
Management Information Base
Management information bases (MIBs) define the properties of the managed object within the device to be managed. Every managed de vice keeps a database of values for each definition written in the MIB. It is not the actual database itself; it is implementation dependant. Definition of the MIB conforms to the Structure of Management Information (SMI) given in Request For Comment (RFC) 1155. The latest Internet MIB is given in RFC 1213, and is sometimes called MIB-II.

User Datagram Protocol

SANbox switches support the following User Datagram Protocol (UDP) settings:
Agents “listen” on UDP port 161. Responses are sent back to the originating Network Management Station
(NMS) port from a dynamic port, although many agents use p ort 161 also for
this target. The maximum SNMP message size is 65507 octets (maximum UDP
message size). The minimum receive packet size for SNMP implementations is 484 octets
in length. Agent and Network Monitoring Systems are responsible for determining
error recovery.
59047-09 C 2-3
2 – SNMP Overview Numbering System Conventions

Numbering System Conventions

The conventions for numbering systems in this guide are as follows:
Decimal = 101 Hexadecimal = 0x101 Binary = 101b
S
2-4 59047-09 C

3 Configuring a Switch

This section describes how to configure a SANbox switch to support SNMP. The following topics are covered:
System specifications and requirements Configuring a switch using the Telnet command line interface Configuring a switch using the Enterprise Fabric Suite 2007 application

System Specifications and Requirements

SANbox switches support SNMPv1 and SNMPv2c. Version 1 and 2 traps are supported. Hardware — one out-of-band Ethernet connection is required. Software — one switch management software application allows you to:
Monitor and control the switch.
Read, write, and receive trap information, if supported. Ports on the switch reserved for SNMP:
Port 161 is not configurable, and is used for the standard SNMP
commands.
Port 162 is configurable and is the default port used for traps. One or more in-band switches can be managed by an out-of-band SANbox
switch acting as a proxy switch.
SANbox can only act as a proxy for other SANbox switches. SANbox proxy capability can be disabled.
59047-09 C 3-1
3 – Configuring a Switch Configuring a Switch Using the Command Line Interface
S

Configuring a Switch Using the Command Line Interface

The Telnet command line interface offers a convenient way to change SNMP parameters. SNMP parameter defaults are preset during manufacturing. For security purposes, these default values should be changed. For specific information about SNMP parameters, refer to the SNMP Configuration section in the corresponding SANbox Switch Management User Guide. To configure a switch using the command line interface, do the following.
3-2 59047-09 C
A
3 – Configuring a Switch
Configuring a Switch Using the Command Line Interface
Press the Enter key to accept the default value for each parameter.
SB5600.116.50 (admin) #> set setup snmp A list of attributes with formatting and current values will follow. Enter a new value or simply press the ENTER key to accept the current value. If you wish to terminate this process before reaching the end of the attributes for the category being processed, press 'q' or 'Q' and the ENTER key to do so. If you wish to terminate the configuration process completely, press 'qq' or 'QQ' and the ENTER key to do so.
SNMP System Configuration - may optionally use 'set setup snmp common' command.
Current Values: SnmpEnabled True Contact <sysContact undefined> Location <sysLocation undefined> ReadCommunity public WriteCommunity private AuthFailureTrap False ProxyEnabled True SNMPv3Enabled False
New Value (press ENTER to not specify value, 'q' to quit): SnmpEnabled (True / False) : Contact (string, max=64 chars) : Location (string, max=64 chars) : ReadCommunity (string, max=32 chars) : WriteCommunity (string, max=32 chars) : AuthFailureTrap (True / False) : ProxyEnabled (True / False) : SNMPv3Enabled (True / False) :
SNMP Trap 1 Configuration - may optionally use 'set setup snmp trap 1' command.
Current Values: Trap1Enabled False Trap1Address 10.0.0.254 Trap1Port 5001 Trap1Severity info Trap1Version 2 Trap1Community public
New Value (press ENTER to not specify value, 'q' to quit): Trap1Enabled (True / False) : Trap1Address (hostname, IPv4, or IPv6 Address) : Trap1Port (decimal value, 1-65535) : Trap1Severity (select a severity level) 1=unknown 6=warning
59047-09 C 3-3
3 – Configuring a Switch Configuring a Switch Using the Command Line Interface
2=emergency 7=notify 3=alert 8=info 4=critical 9=debug 5=error 10=mark : Trap1Version (1 / 2) : Trap1Community (string, max=32 chars) :
SNMP Trap 2 Configuration - may optionally use 'set setup snmp trap 2' command.
Current Values: Trap2Enabled False Trap2Address 10.20.43.231 Trap2Port 162 Trap2Severity info Trap2Version 2 Trap2Community public
New Value (press ENTER to not specify value, 'q' to quit): Trap2Enabled (True / False) : Trap2Address (hostname, IPv4, or IPv6 Address) : Trap2Port (decimal value, 1-65535) : Trap2Severity (select a severity level) 1=unknown 6=warning 2=emergency 7=notify 3=alert 8=info 4=critical 9=debug 5=error 10=mark : Trap2Version (1 / 2) : Trap2Community (string, max=32 chars) :
S
SNMP Trap 3 Configuration - may optionally use 'set setup snmp trap 3' command.
Current Values: Trap3Enabled False Trap3Address 10.20.33.231 Trap3Port 162 Trap3Severity warning Trap3Version 2 Trap3Community public
New Value (press ENTER to not specify value, 'q' to quit): Trap3Enabled (True / False) : Trap3Address (hostname, IPv4, or IPv6 Address) : Trap3Port (decimal value, 1-65535) : Trap3Severity (select a severity level) 1=unknown 6=warning 2=emergency 7=notify
3-4 59047-09 C
A
3 – Configuring a Switch
Configuring a Switch Using the Command Line Interface
3=alert 8=info 4=critical 9=debug 5=error 10=mark : Trap3Version (1 / 2) : Trap3Community (string, max=32 chars) :
SNMP Trap 4 Configuration - may optionally use 'set setup snmp trap 4' command.
Current Values: Trap4Enabled False Trap4Address 0.0.0.0 Trap4Port 162 Trap4Severity warning Trap4Version 2 Trap4Community public
New Value (press ENTER to not specify value, 'q' to quit): Trap4Enabled (True / False) : Trap4Address (hostname, IPv4, or IPv6 Address) : Trap4Port (decimal value, 1-65535) : Trap4Severity (select a severity level) 1=unknown 6=warning 2=emergency 7=notify 3=alert 8=info 4=critical 9=debug 5=error 10=mark : Trap4Version (1 / 2) : Trap4Community (string, max=32 chars) :
SNMP Trap 5 Configuration - may optionally use 'set setup snmp trap 5' command.
Current Values: Trap5Enabled False Trap5Address 0.0.0.0 Trap5Port 162 Trap5Severity warning Trap5Version 2 Trap5Community public
New Value (press ENTER to not specify value, 'q' to quit): Trap5Enabled (True / False) : Trap5Address (hostname, IPv4, or IPv6 Address) : Trap5Port (decimal value, 1-65535) : Trap5Severity (select a severity level) 1=unknown 6=warning 2=emergency 7=notify 3=alert 8=info
59047-09 C 3-5
3 – Configuring a Switch Configuring a Switch Using Enterprise Fabric Suite 2007
4=critical 9=debug 5=error 10=mark : Trap5Version (1 / 2) : Trap5Community (string, max=32 chars) :
Do you want to save and activate this snmp setup? (y/n): [n]
SNMP setup NEITHER saved NOR activated.
SB5600.116.50 (admin) #>
S

Configuring a Switch Using Enterprise Fabric Suite 2007

To configure a SANbox switch using Enterprise Fabric Suite 2007, use the SNMP Properties, Switch Properties, and Network Properties dialogs. For specific information, refer to the corresponding Switch Management User’s Guide.
3-6 59047-09 C

4 MIB-II Objects

This section covers the implementation details for the MIB-II on the SANbox switch. A MIB defines the properties of the managed object within the device to be managed. Every managed device keeps a database of values for each definition written in the MIB. It is not the actual database itself; it is implementation dependant. Definition of the MIB conforms to the SMI given in RFC 1155. The latest Internet MIB is given in RFC 1213, and is sometimes called MIB-II.

Groups in MIB-II

Refer the Table 4-1 for the syntax for MIB-II Groups.
Table 4-1. MIB-II Groups
Group Syntax
system OBJECT IDENTIFIER ::= { mib-2 1 } interfaces OBJECT IDENTIFIER ::= { mib-2 2 } at OBJECT IDENTIFIER ::= { mib-2 3 } ip OBJECT IDENTIFIER ::= { mib-2 4 } icmp OBJECT IDENTIFIER ::= { mib-2 5 } tcp OBJECT IDENTIFIER ::= { mib-2 6 } udp OBJECT IDENTIFIER ::= { mib-2 7 } snmp OBJECT IDENTIFIER ::= { mib-2 11 }

System Group

Implementation of the System group is mandatory for all systems. If an agent is not configured to have a value for any of these variables, a string of length 0 is returned.
59047-09 C 4-1
4 – MIB-II Objects System Group
sysDescr (1.3.6.1.2.1.1.1)
A textual description of the entity. This value should include the full name and version identification of the system's hardware type, operating-system, and networking software. It is mandatory that this only contain printable American Standard Code for Information Interchange (ASCII) characters.
Syntax
DisplayString (SIZE (0..255))
Access
read-only
Status
Mandatory
Return Value
The default values are: SANbox 5200 = SANbox 5200 FC Switch, SANbox
5202 = SANbox 5202 FC Switch, SANbox 5600 = SANbox 5600 FC Switch,
SANbox 5602 = SANbox 5602 FC Switch
S
sysObjectID (1.3.6.1.2.1.1.2)
The vendor's authoritative identification of the network management subsystem contained in the entity. This value is allocated within the SMI enterprise subtree (1.3.6.1.4.1) and provides an easy and unambiguous means for determining `what kind of box' is being managed. For example, if vendor `Flintstones, Inc.' was assigned the subtree 1.3.6.1.4.1.4242, it could assign the identifier
1.3.6.1.4.1.4242.1.1 to its `Fred Router'.
Syntax
OBJECT IDENTIFIER
Access
read-only
Status
mandatory
Return Value
The values are: SANbox 5200 = 1.3.6.1.4.1.1663.1.1.1.1.17, SANbox 5202
= 1.3.6.1.4.1.1663.1.1.1.1.30, SANbox 5600 = 1.3.6.1.4.1.1663.1.1.1.1.23,
and SANbox 5602 = 1.3.6.1.4.1.1663.1.1.1.1.24
4-2 59047-09 C
A
sysUpTime (1.3.6.1.2.1.1.3)
The time, in hundredths of a second, since the network management portion of the system was last re-initialized.
Syntax
TimeTicks
Access
read-only
Status
mandatory
Return Value
The time since the switch was powered on, or last reset (reset, hardreset, or
hotreset) was executed. For example, 3 days 21 hours, 5 minutes, and
26.84 seconds. The value will roll over after approximately 497 days of
continuous up time.
4 – MIB-II Objects
System Group
sysContact (1.3.6.1.2.1.1.4)
The textual identification of the contact person for this managed Node, together with information on how to contact this person.
Syntax
DisplayString (SIZE (0..255))
Access
read-write
Status
mandatory
Return Value
The default is: <sysContact undefined>. The string size is limited to a
maximum of 64.
sysName (1.3.6.1.2.1.1.5)
An administratively-assigned name for this managed Node. By convention, this is the Node's fully-qualified domain name.
Syntax
DisplayString (SIZE (0..255))
59047-09 C 4-3
4 – MIB-II Objects System Group
Access
read-write
Status
mandatory
Return Value
The defaults are: SANbox 5200 Series = SANbox, SANbox 5600 Series =
SANbox
sysLocation (1.3.6.1.2.1.1.6)
The physical location of this Node, such as telephone closet and 3rd floor.
Syntax
DisplayString (SIZE (0..255))
Access
S
read-write
Status
mandatory
Return Value
The default is: <sysLocation undefined>. The string size is limited to a
maximum of 64.
sysServices (1.3.6.1.2.1.1.7)
A value that indicates the set of services that this entity primarily offers.The value is a sum. This sum initially takes the value zero. Then, for each layer L in the range 1 through 7 that this Node performs transactions for, 2 raised to (L - 1) is added to the sum. For example, a Node that performs primarily routing functions would have a value of 4 (2^(3-1)). In contrast, a Node that is a host offering application services would have a value of 72 (2^(4-1) + 2^(7-1)).
Syntax
INTEGER (0..127)
Access
read-only
Status
mandatory
4-4 59047-09 C
A
Return Value
The default is: 2

The Interfaces Group

Implementation of the Interfaces group is mandatory for all systems.
ifNumber (1.3.6.1.2.1.2.1)
The number of network interfaces (regardless of their current state) present on this system.
Syntax
INTEGER
Access
read-only
Status
4 – MIB-II Objects
The Interfaces Group
mandatory
Return Value
The default is: 2

The Interfaces Table

The Interfaces table contains information on the entity's interfaces. Each interface is thought of as being attached to a `subnetwork'. This term should not be confused with `subnet' which refers to an addressing partitioning scheme used in the Internet suite of protocols.
ifIndex (1.3.6.1.2.1.2.2.1.1)
A unique value for each interface. Its value ranges between 1 and the value of ifNumber. The value for each interface must remain constant at least from one re-initialization of the entity's network management system to the next re-initialization.
Syntax
INTEGER
Access
read-only
Status
mandatory
59047-09 C 4-5
4 – MIB-II Objects The Interfaces Table
ifDescr (1.3.6.1.2.1.2.2.1.2)
A textual string containing information about the interface. This string should include the name of the manufacturer, the product name, and the version of the hardware interface.
Syntax
DisplayString (SIZE (0..255))
Access
read-only
Status
mandatory
ifT ype (1.3.6.1.2.1.2.2.1.3)
The type of interface distinguished according to the physical/link protocol(s) immediately `below' the network layer in the protocol stack.
S
Syntax
INTEGER
Access
read-only
Status
mandatory
ifMtu (1.3.6.1.2.1.2.2.1.4)
The size of the largest datagram which can be sent/received on the interface, specified in octets. For interfaces that are used for transmitting network datagrams, this is the size of the largest network datagram that can be sent on the interface.
Syntax
INTEGER
Access
read-only
Status
mandatory
4-6 59047-09 C
A
ifSpeed (1.3.6.1.2.1.2.2.1.5)
An estimate of the interface's current bandwidth in bits per second. For interfaces that do not vary in bandwidth or for those where no accurate estimation can be made, this object should contain the nominal bandwidth.
Syntax
Gauge
Access
read-only
Status
mandatory
ifPhysAddress (1.3.6.1.2.1.2.2.1.6)
The interface's address at the protocol layer immediately “below” the network layer in the protocol stack. For interfaces that do not have such an address, such as a serial line, this object should contain an octet string of zero length.
4 – MIB-II Objects
The Interfaces Table
Syntax
PhysAddress
Access
read-only
Status
mandatory
ifAdminStatus (1.3.6.1.2.1.2.2.1.7)
The desired state of the interface. The testing(3) state indicates that no operational packets can be passed.
Syntax
INTEGER
Access
read-write
Status
mandatory
Return Value
Writes not supported.
59047-09 C 4-7
4 – MIB-II Objects The Interfaces Table
ifOperSt atus (1.3.6.1.2.1.2.2.1.8)
The current operational state of the interface. The testing(3) state indicates that no operational packets can be passed.
Syntax
INTEGER
Access
read-only
Status
mandatory
ifLastChange (1.3.6.1.2.1.2.2.1.9)
The value of sysUpTime at the time the interface entered its current operational state. If the current state was entered prior to the last re-initialization of the local network management subsystem, then this object contains a zero value.
S
Syntax
TimeTicks
Access
read-only
Status
mandatory
ifInOctets (1.3.6.1.2.1.2.2.1.10)
The total number of octets received on the interface, including framing chara cters.
Syntax
Counter
Access
read-only
Status
mandatory
ifInUcastPkts (1.3.6.1.2.1.2.2.1.11)
The number of subnetwork-unicast packets delivered to a higher-layer protocol.
4-8 59047-09 C
A
Syntax
Counter
Access
read-only
Status
mandatory
ifInNUcastPkts (1.3.6.1.2.1.2.2.1.12)
The number of non-unicast (that is, subnetwork- broadcast or subnetwork-multicast) packets delivered to a higher-layer protocol.
Syntax
Counter
Access
4 – MIB-II Objects
The Interfaces Table
read-only
Status
mandatory
ifInDiscards (1.3.6.1.2.1.2.2.1.13)
The number of inbound packets that were chosen to be discarded even though no errors had been detected to prevent their being deliverable to a higher-layer protocol. One possible reason for discarding such a packet could be to free up buffer space.
Syntax
Counter
Access
read-only
Status
mandatory
ifInErrors (1.3.6.1.2.1.2.2.1.14)
The number of inbound packets that cont a ined errors pr eventing them from being deliverable to a higher-layer protocol.
Syntax
Counter
59047-09 C 4-9
4 – MIB-II Objects The Interfaces Table
Access
read-only
Status
mandatory
ifInUnknownProtos (1.3.6.1.2.1.2.2.1.15)
The number of packets received from the interface that were discarded because of an unknown or unsupported protocol.
Syntax
Counter
Access
read-only
Status
S
mandatory
ifOutOctets (1.3.6.1.2.1.2.2.1.16)
The total number of octets transmitted out of the interface, including framing characters.
Syntax
Counter
Access
read-only
Status
mandatory
ifOutUcastPkts (1.3.6.1.2.1.2.2.1.17)
The total number of packets that higher level protocols requested be transmitted to a subnetwork unicast address, including those that were discarded or not sent.
Syntax
Counter
Access
read-only
4-10 59047-09 C
A
Status
mandatory
ifOutNUcastPkts (1.3.6.1.2.1.2.2.1.18)
The total number of packets that higher level protocols requested be transmitted to a non-unicast (subnetwork broadcast or subnetwork multicast) address, including those that were discarded or not sent.
Syntax
Counter
Access
read-only
Status
mandatory
4 – MIB-II Objects
The Interfaces Table
ifOutDiscards (1.3.6.1.2.1.2.2.1.19)
The number of outbound packets that were chosen to be discarded even though no errors had been detected to prevent their being transmitted. One possible reason for discarding such a packet could be to free up buffer space.
Syntax
Counter
Access
read-only
Status
mandatory
ifOutErrors (1.3.6.1.2.1.2.2.1.20)
The number of outbound packets that could not be transmitted because of errors.
Syntax
Counter
Access
read-only
Status
mandatory
59047-09 C 4-11
4 – MIB-II Objects The Address Translation Group
ifOutQLen (1.3.6.1.2.1.2.2.1.21)
The length (in packets) of the output packet queue.
Syntax
Gauge
Access
read-only
Status
mandatory
ifSpecific (1.3.6.1.2.1.2.2.1.22)
A reference to MIB definitions specific to the particular media being used to realize the interface. For example, if the interface is realized by an Ethernet, then the value of this object refers to a document that defines objects specific to Ethernet. If this information is not present, its value should be set to the OBJECT IDENTIFIER { 0 0 }, which is a syntactically valid object identifier, and any conformant implementation of ASN.1 (Abstract Syntax Notation) and BER must be able to generate and recognize this value.
S
Syntax
OBJECT IDENTIFIER
Access
read-only
Status
mandatory

The Address Translation Group

Implementation of the Address Translation group is mandatory for all systems. However, this group is dep recated by MIB-II. That is, it is being inclu ded solely for compatibility with MIB-I Nodes, and will most likely be excluded from MIB-III Nodes. From MIB-II and onwards, each network protocol group contains its own address translation tables.
The Address Translation group contains one table which is the union across all interfaces of the translation tables for converting a NetworkAddress (for example , an IP address) into a subnetwork-specific address. For lack of a better term, this document refers to such a subnetwork-specific address as a `physical' address.
4-12 59047-09 C
A
Examples of such translation tables are for: broadcast media where ARP is in use, the translation table is equivalent to the ARP cache, or on an X.25 network where non-algorithmic translation to X.121 addresses is required. The translation table contains the NetworkAddress to X.121 address equivalences.
atIfIndex (1.3.6.1.2.1.3.1.1.1)
The interface on which this entry's equivalence is effective. The interface identified by a particular value of this index is the same interface as identified by the same value of ifIndex.
Syntax
INTEGER
Access
read-write
Status
deprecated
4 – MIB-II Objects
The Address Translation Group
atPhysAddress (1.3.6.1.2.1.3.1.1.2)
The media-dependent “physical” address. Setting this object to a null string (one of zero length) has the effect of invalidating the corresponding entry in the atTable object. That is, it effectively disassociates the interface identified with the entry from the mapping identified with the entry. It is an implementation-specific matter as to whether the agent removes an invalidated entry from the table. Accordingly, management workstations must be prepared to receive tabular information from agents that corresponds to entries not currently in use. Proper interpretation of such entries requires examination of the relevant atPhysAddress object.
Syntax
PhysAddress
Access
read-write
Status
deprecated
atNetAddress (1.3.6.1.2.1.3.1.1.3)
The NetworkAddress corresponding to the media-dependent `physical' address.
Syntax
NetworkAddress
59047-09 C 4-13
4 – MIB-II Objects The IP Group
Access
read-write
Status
deprecated

The IP Group

Implementation of the IP group is mandatory for all systems.
ipForwarding (1.3.6.1.2.1.4.1)
The indication of whether this entity is acting as an IP Gateway with respect to the forwarding of datagrams received by, but not addressed to, this entity. IP Gateways forward datagrams; IP hosts do not (except those source-routed from the host).
For some managed Nodes, this object may take on only a subset of the values possible. Accordingly, it is appropriate for an agent to return a “badValue” response if a management station attempts to change this object to an inappropriate value.
S
Syntax
INTEGER
Access
read-write
Status
mandatory
Return Value
Returns forwarding (1). Writes not supported.
ipDefaultTTL (1.3.6.1.2.1.4.2)
The default value inserted into the Time-To-Live field of the IP header of datagrams originated at this entity whenever a TTL value is not supplied by the transport layer protocol.
Syntax
INTEGER
Access
read-write
4-14 59047-09 C
A
Status
mandatory
Return Value
Returns 64 (0x40). Writes not supported.
ipInReceives (1.3.6.1.2.1.4.3)
The total number of input datagrams received from interfaces, including those received in error.
Syntax
Counter
Access
read-only
Status
4 – MIB-II Objects
The IP Group
mandatory
ipInHdrErrors (1.3.6.1.2.1.4.4)
The number of input datagrams discarded due to errors in their IP headers. These include bad checksums, version number mismatch, other format errors, time-to-live exceeded, and errors discovered in processing their IP options.
Syntax
Counter
Access
read-only
Status
mandatory
ipInAddrErrors (1.3.6.1.2.1.4.5)
The number of input datagrams discarded because the IP address in their IP header's destination field was not a valid address to b e received at this entity. This count includes invalid addresses (for example, 0.0.0.0) and addresses of unsupported Classes (for example, Class E). For entities which are not IP Gateways and therefore do not forward datagrams, this counter includes datagrams discarded because the destination address was not a local address.
Syntax
Counter
59047-09 C 4-15
4 – MIB-II Objects The IP Group
Access
read-only
Status
mandatory
ipForwDatagrams (1.3.6.1.2.1.4.6)
The number of input datagrams for which this entity was not their final IP destination. As a result, an attempt was made to find a route to forward them to that final destination. In entities that do not act as IP Gateways, this counter will include only those packets that were Source Routed from this entity, and the Source Route option processing was successful.
Syntax
Counter
Access
S
read-only
Status
mandatory
ipInUnknownProtos (1.3.6.1.2.1.4.7)
The number of locally-addressed datagrams received successfully but discarded because of an unknown or unsupported protocol.
Syntax
Counter
Access
read-only
Status
mandatory
ipInDiscards (1.3.6.1.2.1.4.8)
The number of input IP datagrams for which no problems were encountered to prevent their continued processing, but which were discarded (for example, for lack of buffer space). This counter does not include any datagrams discarded while awaiting reassembly.
Syntax
Counter
4-16 59047-09 C
A
Access
read-only
Status
mandatory
ipInDelivers (1.3.6.1.2.1.4.9)
The total number of input datagrams successfully delivered to IP user protocols (including ICMP).
Syntax
Counter
Access
read-only
Status
4 – MIB-II Objects
The IP Group
mandatory
ipOutRequests (1.3.6.1.2.1.4.10)
The total number of IP datagrams that local IP user protocols (including ICMP) supplied to IP in requests for transmission. This counter does not include any datagrams counted in ipForwDatagrams.
Syntax
Counter
Access
read-only
Status
mandatory
ipOutDiscards (1.3.6.1.2.1.4.11)
The number of output IP datagrams for which no problem was encountered to prevent their transmission to their destination, but which were discarded (for example, for lack of buffer space). This co unter would include dat agrams counted in ipForwDatagrams if any such packets met this (discretionary) discard criterion.
Syntax
Counter
59047-09 C 4-17
4 – MIB-II Objects The IP Group
Access
read-only
Status
mandatory
ipOutNoRoutes (1.3.6.1.2.1.4.12)
The number of IP datagrams discarded because no route could be found to transmit them to their destination. This counter includes any packets counted in ipForwDatagrams which meet this “no-route” criterion. This includes any datagrams that a host cannot route because all of its default gateways are down.
Syntax
Counter
Access
read-only
S
Status
mandatory
ipReasmTimeout (1.3.6.1.2.1.4.13)
The maximum number of seconds which received fragments are held while they are awaiting reassembly at this entity.
Syntax
INTEGER
Access
read-only
Status
mandatory
ipReasmReqds (1.3.6.1.2.1.4.14)
The number of IP fragments received tha t needed to be reassembled at this entity.
Syntax
Counter
Access
read-only
4-18 59047-09 C
A
Status
mandatory
ipReasmOKs (1.3.6.1.2.1.4.15)
The number of IP datagrams successfully reassembled.
Syntax
Counter
Access
read-only
Status
mandatory
ipReasmFails (1.3.6.1.2.1.4.16)
The number of failures detected by the IP reassembly algorithm for example, timed out, errors). This is not necessarily a count of discarded IP fragments, since some algorithms (notably the algorithm in RFC 815) can lose track of the number of fragments by combining them as they are received.
4 – MIB-II Objects
The IP Group
Syntax
Counter
Access
read-only
Status
mandatory
ipFragOKs (1.3.6.1.2.1.4.17)
The number of IP datagrams that have been successfully fragmented at this entity.
Syntax
Counter
Access
read-only
Status
mandatory
59047-09 C 4-19
4 – MIB-II Objects The IP Address Table
ipFragFails (1.3.6.1.2.1.4.18)
The number of IP datagrams that have been discarded because they needed to be fragmented at this entity, but could not because their Don't Fragment flag was set.
Syntax
Counter
Access
read-only
Status
mandatory
ipFragCreates (1.3.6.1.2.1.4.19)
The number of IP datagram fragments that have been generated as a result of fragmentation at this entity.
S
Syntax
Counter
Access
read-only
Status
mandatory

The IP Address Table

The IP address table contains this entity's IP addressing information.
ipAdEntAddr (1.3.6.1.2.1.4.20.1.1)
The IP address to which this entry's addressing information pertains.
Syntax
IpAddress
Access
read-only
Status
mandatory
4-20 59047-09 C
A
ipAdEntIfIndex (1.3.6.1.2.1.4.20.1.2)
The index value which uniquely identifies the interface to which this entry is applicable. The interface identified by a particular value of this index is the same interface as identified by the same value of ifIndex.
Syntax
INTEGER
Access
read-only
Status
mandatory
ipAdEntNetMask (1.3.6.1.2.1.4.20.1.3)
The subnet mask associated with the IP address of this entry. The value of the mask is an IP address with all the network bits set to 1 and all the hosts bit s set to
0.
4 – MIB-II Objects
The IP Address Table
Syntax
IpAddress
Access
read-only
Status
mandatory
ipAdEntBcastAddr (1.3.6.1.2.1.4.20.1.4)
The value of the least-significant bit in the IP broadcast address used for sending datagrams on the (logical) interface associated with the IP address of this entry. For example, when the Internet standard all-ones broadcast address is used, the value will be 1. This value applies to both the subnet and network broadcasts addresses used by the entity on this (logical) interface.
Syntax
INTEGER
Access
read-only
Status
mandatory
59047-09 C 4-21
4 – MIB-II Objects The IP Routing Table
ipAdEntReasmMaxSize (1.3.6.1.2.1.4.20.1.5)
The size of the largest IP datagram which this entity can reassemble from incoming IP fragmented datagrams received on this interface.
Syntax
INTEGER (0..65535)
Access
read-only
Status
mandatory

The IP Routing Table

The IP routing table contains an entry for each route presently known to this entity.
ipRouteDest (1.3.6.1.2.1.4.21.1.1)
The destination IP address of this route. An entry with a value of 0.0.0.0 is considered a default route. Multiple routes to a single destination can appear in the table, but access to such multiple entries is dependent on the table-access mechanisms defined by the network management protocol in use.
S
Syntax
IpAddress
Access
read-write
Status
mandatory
Return Value
Writes not supported.
ipRouteIfIndex (1.3.6.1.2.1.4.21.1.2)
The index value which uniquely identifies the local interface through which the next hop of this route should be reached. The interface identified by a particular value of this index is the same interface as identified by the same value of ifIndex.
Syntax
INTEGER
4-22 59047-09 C
A
Access
read-write
Status
mandatory
Return Value
Writes not supported.
ipRouteMetric1 (1.3.6.1.2.1.4.21.1.3)
The primary routing metric for this route. The semantics of this metric are determined by the routing protocol specified in the route's ipRouteProto value. If this metric is not used, its value should be set to -1.
Syntax
INTEGER
4 – MIB-II Objects
The IP Routing Table
Access
read-write
Status
mandatory
Return Value
Writes not supported.
ipRouteMetric2 (1.3.6.1.2.1.4.21.1.4)
An alternate routing metric for this route. The semantics of this metric are determined by the routing protocol specified in the route's ipRouteProto value. If this metric is not used, its value should be set to -1.
Syntax
INTEGER
Access
read-write
Status
mandatory
Return Value
Writes not supported.
59047-09 C 4-23
4 – MIB-II Objects The IP Routing Table
ipRouteMetric3 (1.3.6.1.2.1.4.21.1.5)
An alternate routing metric for this route. The semantics of this metric are determined by the routing protocol specified in the route's ipRouteProto value. If this metric is not used, its value should be set to -1.
Syntax
INTEGER
Access
read-write
Status
mandatory
Return Value
Writes not supported.
S
ipRouteMetric4 (1.3.6.1.2.1.4.21.1.6)
An alternate routing metric for this route. The semantics of this metric are determined by the routing protocol specified in the route's ipRouteProto value. If this metric is not used, its value should be set to -1.
Syntax
INTEGER
Access
read-write
Status
mandatory
Return Value
Writes not supported.
ipRouteNextHop (1.3.6.1.2.1.4.21.1.7)
The IP address of the next hop of this route. In the case of a route bound to an interface which is realized from a broadcast media, the value of this field is the agent's IP address on that interface.
Syntax
IpAddress
4-24 59047-09 C
A
Access
read-write
Status
mandatory
Return Value
Writes not supported.
ipRouteT ype (1.3.6.1.2.1.4.21.1.8)
The type of route. The values direct(3) and indirect(4) refer to the notion of direct and indirect routing in the IP architecture. Setting this object to the value invalid(2) has the effect of invalidating the corresponding entry in the ipRouteTable object. That is, it effectively disassociates the destinatio n identified with the entry from the route identified with the entry . It is an imp lementation-specific matter as to whether the agent removes an invalidated entry from the table. Accordingly, management stations must be prepared to receive tabular information from agents that corresponds to entries not currently in use. Proper interpretation of such entries requires examination of the relevant ipRouteType object.
4 – MIB-II Objects
The IP Routing Table
Syntax
INTEGER
Access
read-write
Status
mandatory
Return Value
Writes not supported.
ipRouteProto (1.3.6.1.2.1.4.21.1.9)
The routing mechanism through which this route was learned. Inclusion of values for gateway routing protocols is not intended to imply that hosts should support those protocols.
Syntax
INTEGER
Access
read-only
59047-09 C 4-25
4 – MIB-II Objects The IP Routing Table
Status
mandatory
ipRouteAge (1.3.6.1.2.1.4.21.1.10)
The number of seconds since this route was last updated or otherwise determined to be correct. No semantics of `too old' can be implied except through knowledge of the routing protocol by which the route was learned.
Syntax
INTEGER
Access
read-write
Status
mandatory
S
Return Value
Writes not supported.
ipRouteMask (1.3.6.1.2.1.4.21.1.1 1)
Indicate the mask to be logical-ANDed with the destination address before being compared to the value in the ipRouteDest field.
Syntax
IpAddress
Access
read-write
Status
mandatory
Return Value
Writes not supported.
ipRouteMetric5 (1.3.6.1.2.1.4.21.1.12)
An alternate routing metric for this route. The semantics of this metric are determined by the routing-protocol specified in the route's ipRouteProto value. If this metric is not used, its value should be set to -1.
Syntax
INTEGER
4-26 59047-09 C
A
Access
read-write
Status
mandatory
Return Value
Writes not supported.
ipRouteInfo (1.3.6.1.2.1.4.21.1.13)
A reference to MIB definitions specific to the particular routing protocol which is responsible for this route, as determined by the value specified in the route's ipRouteProto value. If this information is not present, its value should be set to the OBJECT IDENTIFIER { 0 0 }, which is a syntactically valid object identifier. Any conformant implementation of ASN.1 and BER must be able to generate and recognize this value.
Syntax
4 – MIB-II Objects

The IP Address Translation Table

OBJECT IDENTIFIER
Access
read-only
Status
mandatory
The IP Address Tr anslation Table
The IP address translation table contain the IpAddress to`physical' address equivalences. Some interfaces do not use translation tables for determining address equivalences (for example, DDN-X.25 has an algorithmic method). If all interfaces are of this type, then the Address Translation t able is empty, that is, has zero entries.
ipNetT oMediaIfIndex (1.3.6.1.2.1.4.22.1.1)
The interface on which this entry's equivalence is effective. The interface identified by a particular value of this index is the same interface as identified by the same value of ifIndex.
Syntax
INTEGER
Access
read-write
59047-09 C 4-27
4 – MIB-II Objects The IP Address Translation Table
Status
mandatory
Return Value
Writes not supported.
ipNetT oMediaPhysAddress (1.3.6.1.2.1.4.22.1.2)
The media-dependent `physical' address.
Syntax
PhysAddress
Access
read-write
Status
mandatory
S
Return Value
Writes not supported.
ipNetToMediaNetAddress (1.3.6.1.2.1.4.22.1.3)
The IpAddress corresponding to the media-dependent `physical' address.
Syntax
IpAddress
Access
read-write
Status
mandatory
Return Value
Writes not supported.
4-28 59047-09 C
A
ipNetT oMediaT ype (1.3.6.1.2.1.4.22.1.4)
The type of mapping. Setting this object to the value invalid(2) has the effect of invalidating the corresponding entry in the ipNetToMediaTable. That is, it effectively disassociates the interface identified with the entry from the mapping identified with the entry. It is an implementation-specific matter as to whether the agent removes an invalidated entry from the table. Accordingly, management stations must be prepared to receive tabular information from agents that corresponds to entries not currently in use. Proper interpretation of such entries requires examination of the relevant ipNetToMediaType object.
Syntax
INTEGER
Access
read-write
Status
4 – MIB-II Objects

Additional IP Objects

mandatory
Return Value
Writes not supported.
Additional IP Objects
Following are the additional IP objects.
ipRoutingDiscards (1.3.6.1.2.1.4.23)
The number of routing entries which were chosen to be discarded even though they are valid. One possible reason for discarding such an entry could be to free-up buffer space for other routing entries.
Syntax
Counter
Access
read-only
Status
mandatory
59047-09 C 4-29
4 – MIB-II Objects The ICMP Group

The ICMP Group

Implementation of the ICMP group is mandatory for all systems.
icmpInMsgs (1.3.6.1.2.1.5.1)
The total number of ICMP messages received by the entity. This counter includes all those counted by icmpInErrors.
Syntax
Counter
Access
read-only
Status
mandatory
icmpInErrors (1.3.6.1.2.1.5.2)
The number of ICMP messages received by the entity but were determined as having ICMP-specific errors (such as, bad ICMP checksums, bad length).
S
Syntax
Counter
Access
read-only
Status
mandatory
icmpInDestUnreachs (1.3.6.1.2.1.5.3)
The number of ICMP Destination Unreachable messages received.
Syntax
Counter
Access
read-only
Status
mandatory
4-30 59047-09 C
A
icmpInTimeExcds (1.3.6.1.2.1.5.4)
The number of ICMP Time Exceeded messages received.
Syntax
Counter
Access
read-only
Status
mandatory
icmpInParmProbs (1.3.6.1.2.1.5.5)
The number of ICMP Parameter Problem messages received.
Syntax
Counter
4 – MIB-II Objects
The ICMP Group
Access
read-only
Status
mandatory
icmpInSrcQuenchs (1.3.6.1.2.1.5.6)
The number of ICMP Source Quench messages received.
Syntax
Counter
Access
read-only
Status
mandatory
icmpInRedirects (1.3.6.1.2.1.5.7)
The number of ICMP Redirect messages received.
Syntax
Counter
59047-09 C 4-31
4 – MIB-II Objects The ICMP Group
Access
read-only
Status
mandatory
icmpInEchos (1.3.6.1.2.1.5.8)
The number of ICMP Echo (request) messages received.
Syntax
Counter
Access
read-only
Status
mandatory
S
icmpInEchoReps (1.3.6.1.2.1.5.9)
The number of ICMP Echo Reply messages received.
Syntax
Counter
Access
read-only
Status
mandatory
icmpInTimestamp s (1.3.6.1.2.1.5.10)
The number of ICMP Timestamp (request) messages received.
Syntax
Counter
Access
read-only
Status
mandatory
4-32 59047-09 C
A
icmpInTimestampReps (1.3.6.1.2.1.5.11)
The number of ICMP Timestamp Reply messages received.
Syntax
Counter
Access
read-only
Status
mandatory
icmpInAddrMasks (1.3.6.1.2.1.5.12)
The number of ICMP Address Mask Request messages received.
Syntax
Counter
4 – MIB-II Objects
The ICMP Group
Access
read-only
Status
mandatory
icmpInAddrMaskReps (1.3.6.1.2.1.5.13)
The number of ICMP Address Mask Reply messages received.
Syntax
Counter
Access
read-only
Status
mandatory
icmpOutMsgs (1.3.6.1.2.1.5.14)
The total number of ICMP messages which this entity attempted to send. This counter includes all those counted by icmpOutErrors.
Syntax
Counter
59047-09 C 4-33
4 – MIB-II Objects The ICMP Group
Access
read-only
Status
mandatory
icmpOutErrors (1.3.6.1.2.1.5.15)
The number of ICMP messages which this entity did not send due to problems discovered within ICMP, such as a lack of buffers. This value should not include errors discovered outside the ICMP layer such as the inability of IP to route the resultant datagram. In some implementations, there may be no types of errors which contribute to this counter's value.
Syntax
Counter
Access
S
read-only
Status
mandatory
icmpOutDestUnreachs (1.3.6.1.2.1.5.16)
The number of ICMP Destination Unreachable messages sent.
Syntax
Counter
Access
read-only
Status
mandatory
icmpOutTimeExcds (1.3.6.1.2.1.5.17)
The number of ICMP Time Exceeded messages sent.
Syntax
Counter
Access
read-only
4-34 59047-09 C
A
Status
mandatory
icmpOutParmProbs (1.3.6.1.2.1.5.18)
The number of ICMP Parameter Problem messages sent.
Syntax
Counter
Access
read-only
Status
mandatory
icmpOutSrcQuenchs (1.3.6.1.2.1.5.19)
The number of ICMP Source Quench messages sent.
4 – MIB-II Objects
The ICMP Group
Syntax
Counter
Access
read-only
Status
mandatory
icmpOutRedirects (1.3.6.1.2.1.5.20)
The number of ICMP Redirect messages sent. For a host, this object will always be zero, since hosts do not send redirects.
Syntax
Counter
Access
read-only
Status
mandatory
icmpOutEchos (1.3.6.1.2.1.5.21)
The number of ICMP Echo (request) messages sent.
59047-09 C 4-35
4 – MIB-II Objects The ICMP Group
Syntax
Counter
Access
read-only
Status
mandatory
icmpOutEchoReps (1.3.6.1.2.1.5.22)
The number of ICMP Echo Reply messages sent.
Syntax
Counter
Access
read-only
S
Status
mandatory
icmpOutTimestamps (1.3.6.1.2.1.5.23)
The number of ICMP Timestamp (request) messages sent.
Syntax
Counter
Access
read-only
Status
mandatory
icmpOutTimestampReps (1.3.6.1.2.1.5.24)
The number of ICMP Timestamp Reply messages sent.
Syntax
Counter
Access
read-only
4-36 59047-09 C
A
Status
mandatory
icmpOutAddrMasks (1.3.6.1.2.1.5.25)
The number of ICMP Address Mask Request messages sent.
Syntax
Counter
Access
read-only
Status
mandatory
icmpOutAddrMaskReps (1.3.6.1.2.1.5.26)
The number of ICMP Address Mask Reply messages sent.
4 – MIB-II Objects

The TCP Group

Syntax
Counter
Access
read-only
Status
mandatory
The TCP Group
Implementation of the TCP group is mandatory for all systems that implement the TCP. Instances of object types that represent information about a particular TCP connection are transient; they persist only as long as the connection in question.
tcpRtoAlgorithm (1.3.6.1.2.1.6.1)
The algorithm used to determine the timeout value used for retransmitting unacknowledged octets.
Syntax
INTEGER
Access
read-only
59047-09 C 4-37
4 – MIB-II Objects The TCP Group
Status
mandatory
tcpRtoMin (1.3.6.1.2.1.6.2)
The minimum value permitted by a TCP implementation for the retransmission timeout, measured in milliseconds. More refined semantics for object s of this type depend upon the algorithm used to determine the retransmission timeout. In particular, when the timeout algorithm is rsre(3), an object of this type has the semantics of the LBOUND quantity described in RFC 793.
Syntax
INTEGER
Access
read-only
Status
S
mandatory
tcpRtoMax (1.3.6.1.2.1.6.3)
The maximum value permitted by a TCP implementation for the retransmission timeout, measured in milliseconds. More refined semantics for object s of this type depend upon the algorithm used to determine the retransmission timeout. In particular, when the timeout algorithm is rsre(3), an object of this type has the semantics of the UBOUND quantity described in RFC 793.
Syntax
INTEGER
Access
read-only
Status
mandatory
tcpMaxConn (1.3.6.1.2.1.6.4)
The limit on the total number of TCP connections the entity can support. In entities where the maximum number of connections is dynamic, this object should cont ain the value -1.
Syntax
INTEGER
4-38 59047-09 C
A
Access
read-only
Status
mandatory
tcpActiveOpens (1.3.6.1.2.1.6.5)
The number of times TCP connections have made a direct transition to the SYN-SENT state from the CLOSED state.
Syntax
Counter
Access
read-only
Status
4 – MIB-II Objects
The TCP Group
mandatory
tcpPassiveOpens (1.3.6.1.2.1.6.6)
The number of times TCP connections have made a direct transition to the SYN-RCVD state from the LISTEN state.
Syntax
Counter
Access
read-only
Status
mandatory
tcpAttemptFails (1.3.6.1.2.1.6.7)
The number of times TCP connections have made a direct transition to the CLOSED state from either the SYN-SENT st ate or th e SYN-RCVD state, plus the number of times TCP connections have made a direct transition to the LISTEN state from the SYN-RCVD state.
Syntax
Counter
Access
read-only
59047-09 C 4-39
4 – MIB-II Objects The TCP Group
Status
mandatory
tcpEstabReset s (1.3.6.1.2.1.6.8)
The number of times TCP connections have made a direct transition to the CLOSED state from either the ESTABLISHED state or the CLOSE-WAIT state.
Syntax
Counter
Access
read-only
Status
mandatory
tcpCurrEstab (1.3.6.1.2.1.6.9)
The number of TCP connections for which the current state is either ESTABLISHED or CLOSE-WAIT.
S
Syntax
Gauge
Access
read-only
Status
mandatory
tcpInSegs (1.3.6.1.2.1.6.10)
The total number of segments received, including those received in error. This count includes segments received on currently established connections.
Syntax
Counter
Access
read-only
Status
mandatory
4-40 59047-09 C
A
tcpOutSegs (1.3.6.1.2.1.6.11)
The total number of segments sent including those on current connections, but excluding those containing only retransmitted octets.
Syntax
Counter
Access
read-only
Status
mandatory
tcpRetransSegs (1.3.6.1.2.1.6.12)
The total number of segments retransmitted. That is, the number of TCP segments transmitted containing one or more previously transmitted octets.
Syntax
4 – MIB-II Objects

The TCP Connection Table

Counter
Access
read-only
Status
mandatory
The TCP Connection Table
The TCP connection table contains information about this entity's existing TCP connections.
tcpConnState (1.3.6.1.2.1.6.13.1.1)
The state of this TCP connection. The only value which may be set by a management station is deleteTCB(12). Accordingly, it is appropriate for an agent to return a “badValue” response if a management station attempts to set this object to any other value.
If a management station sets this object to the value deleteTCB(12), then this has the effect of deleting the TCB (as defined in RFC 793) of the corresponding connection on the managed Node. The result is an immediate termination of the connection.
Syntax
INTEGER
59047-09 C 4-41
4 – MIB-II Objects The TCP Connection Table
Access
read-write
Status
mandatory
Return Value
Writes not supported.
tcpConnLocalAddress (1.3.6.1.2.1.6.13.1.2)
The local IP address for this TCP connection. In the case of a connection in the listen state which is willing to accept connections for any IP interface associated with the Node, the value 0.0.0.0 is used.
Syntax
IpAddress
S
Access
read-only
Status
mandatory
tcpConnLocalPort (1.3.6.1.2.1.6.13.1.3)
The local port number for this TCP connection.
Syntax
INTEGER (0..65535)
Access
read-only
Status
mandatory
tcpConnRemAddress (1.3.6.1.2.1.6.13.1.4)
The remote IP address for this TCP connection.
Syntax
IpAddress
Access
read-only
4-42 59047-09 C
A
Status
mandatory
tcpConnRemPort (1.3.6.1.2.1.6.13.1.5)
The remote port number for this TCP connection.
Syntax
INTEGER (0..65535)
Access
read-only
Status
mandatory

Additional TCP Objects

4 – MIB-II Objects
Additional TCP Objects
Following are the additional TCP objects.
tcpInErrs (1.3.6.1.2.1.6.14)
The total number of segments received in error (for example, bad TCP checksums).
Syntax
Counter
Access
read-only
Status
mandatory
tcpOutRsts (1.3.6.1.2.1.6.15)
The number of TCP segments sent containing the RST flag.
Syntax
Counter
Access
read-only
Status
mandatory
59047-09 C 4-43
4 – MIB-II Objects The UDP Group

The UDP Group

Implementation of the UDP group is mandatory for all systems which implement the UDP.
udpInDat agrams (1.3.6.1.2.1.7.1)
The total number of UDP datagrams delivered to UDP users.
Syntax
Counter
Access
read-only
Status
mandatory
udpNoPort s (1.3.6.1.2.1.7.2)
The total number of received UDP datagrams for which there was no application at the destination port.
S
Syntax
Counter
Access
read-only
Status
mandatory
udpInErrors (1.3.6.1.2.1.7.3)
The number of received UDP datagrams that could not be delivered for reasons other than the lack of an application at the destination port.
Syntax
Counter
Access
read-only
Status
mandatory
4-44 59047-09 C
A
udpOutDat agrams (1.3.6.1.2.1.7.4)
The total number of UDP datagrams sent from this entity.
Syntax
Counter
Access
read-only
Status
mandatory

The UDP Listener Table

The UDP listener table contains information about this entity's UDP end-point s on which a local application is currently accepting datagrams.
udpLocalAddress (1.3.6.1.2.1.7.5.1.1)
The local IP address for this UDP listener. In the case of a UDP listener which is willing to accept datagrams for any IP interface associated with the Node, the value 0.0.0.0 is used.
4 – MIB-II Objects
The UDP Listener Table
Syntax
IpAddress
Access
read-only
Status
mandatory
udpLocalPort (1.3.6.1.2.1.7.5.1.2)
The local port number for this UDP listener.
Syntax
INTEGER (0..65535)
Access
read-only
Status
mandatory
59047-09 C 4-45
4 – MIB-II Objects The EGP Group

The EGP Group

Implementation of the EGP group is mandatory for all systems which implement the EGP.
egpInMsgs (1.3.6.1.2.1.8.1)
The number of EGP messages received without error.
Syntax
Counter
Access
read-only
Status
mandatory
egpInErrors (1.3.6.1.2.1.8.2)
The number of EGP messages received that proved to be in error.
S
Syntax
Counter
Access
read-only
Status
mandatory
egpOutMsgs (1.3.6.1.2.1.8.3)
The total number of locally generated EGP messages.
Syntax
Counter
Access
read-only
Status
mandatory
4-46 59047-09 C
A
egpOutErrors (1.3.6.1.2.1.8.4)
The number of locally generated EGP messages not sent due to resource limitations within an EGP entity.
Syntax
Counter
Access
read-only
Status
mandatory

The EGP Neighbor Table

The EGP neighbor table contains information about this entity's EGP neighbors.
egpNeighState (1.3.6.1.2.1.8.5.1.1)
The EGP state of the local system with respect to th is entry's EGP neighbor. Each EGP state is represented by a value that is one greater than the numerical value associated with the state in RFC 904.
4 – MIB-II Objects
The EGP Neighbor Table
Syntax
INTEGER
Access
read-only
Status
mandatory
egpNeighAddr (1.3.6.1.2.1.8.5.1.2)
The IP address of this entry's EGP neighbor.
Syntax
IpAddress
Access
read-only
Status
mandatory
59047-09 C 4-47
4 – MIB-II Objects The EGP Neighbor Table
egpNeighAs (1.3.6.1.2.1.8.5.1.3)
The autonomous system of this EGP peer. Zero should be specified if the autonomous system number of the neighbor is not yet known.
Syntax
INTEGER
Access
read-only
Status
mandatory
egpNeighInMsgs (1.3.6.1.2.1.8.5.1.4)
The number of EGP messages received without error from this EGP peer.
Syntax
S
Counter
Access
read-only
Status
mandatory
egpNeighInErrs (1.3.6.1.2.1.8.5.1.5)
The number of EGP messages received from this EGP peer that proved to be in error (for example, bad EGP checksum).
Syntax
Counter
Access
read-only
Status
mandatory
egpNeighOutMsgs (1.3.6.1.2.1.8.5.1.6)
The number of locally generated EGP messages to this EGP peer.
Syntax
Counter
4-48 59047-09 C
A
Access
read-only
Status
mandatory
egpNeighOutErrs (1.3.6.1.2.1.8.5.1.7)
The number of locally generated EGP messages not sent to this EGP peer due to resource limitations within an EGP entity.
Syntax
Counter
Access
read-only
Status
4 – MIB-II Objects
The EGP Neighbor Table
mandatory
egpNeighInErrMsgs (1.3.6.1.2.1.8.5.1.8)
The number of EGP-defined error messages received from this EGP peer.
Syntax
Counter
Access
read-only
Status
mandatory
egpNeighOutErrMsgs (1.3.6.1.2.1.8.5.1.9)
The number of EGP-defined error messages sent to this EGP peer.
Syntax
Counter
Access
read-only
Status
mandatory
59047-09 C 4-49
4 – MIB-II Objects The EGP Neighbor Table
egpNeighStateUp s (1.3.6.1.2.1.8.5.1.10)
The number of EGP state transitions to the UP state with this EGP peer.
Syntax
Counter
Access
read-only
Status
mandatory
egpNeighStateDowns (1 .3.6.1.2.1.8.5.1.11)
The number of EGP state transitions from the UP state to any other state with this EGP peer.
Syntax
S
Counter
Access
read-only
Status
mandatory
egpNeighIntervalHello (1.3.6.1.2.1.8.5.1.12)
The interval between EGP Hello command retransmissions, in hundredths of a second. This represents the t1 timer as defined in RFC 904.
Syntax
INTEGER
Access
read-only
Status
mandatory
egpNeighIntervalPoll (1.3.6.1.2.1.8.5.1.13)
The interval between EGP poll command retransmissions, in hundredths of a second. This represents the t3 timer as defined in RFC 904.
4-50 59047-09 C
A
Syntax
INTEGER
Access
read-only
Status
mandatory
egpNeighMode (1.3.6.1.2.1.8.5.1.14)
The polling mode of this EGP entity, either passive or active.
Syntax
INTEGER { active(1), passive(2) }
Access
read-only
4 – MIB-II Objects
The EGP Neighbor Table
Status
mandatory
egpNeighEventTrigger (1.3.6.1.2.1.8.5.1.15)
A control variable used to trigger operator-initiated Start and Stop events. When read, this variable always returns the most recent value that egpNeighEventTrigger was set to. If it has not bee n set since th e last initialization of the network management subsystem on the Node, it returns a value of “stop”.
When set, this variable causes a S tart or Stop event on the specified neighbor, as specified on pages 8-10 of RFC 904. Briefly, a Start event causes an Idle peer to begin neighbor acquisition and a non-Idle peer to re-initiate neighbor acquisition. A stop event causes a non-Idle peer to return to the Idle state until a Start event occurs, either by egpNeighEventTrigger or otherwise.
Syntax
INTEGER { start(1), stop(2) }
Access
read-write
Status
mandatory
59047-09 C 4-51
4 – MIB-II Objects The Transmission Group
egpAs (1.3.6.1.2.1.8.6)
The autonomous system number of this EGP entity.
Syntax
INTEGER
Access
read-only
Status
mandatory

The Transmission Group

Based on the transmission media underlying each interface on a system, the corresponding portion of the Transmission group is mandatory for that system.
When Internet-standard definitions for managing transmission media are defined, the transmission group is used to provide a prefix for the names of those objects.
S
Typically, such definitions reside in the experimental portion of the MIB until they are "proven", then as a part of the Internet standardization process, the definitions are accordingly elevated and a new object identifier , under the transmission group is defined. By convention, the name assigned is:
type OBJECT IDENTIFIER ::= { transmission number }. Where "type" is the symbolic value used for the media in the ifType column of the
ifTable object, and "number" is the actual integer value corresponding to the symbol.

The SNMP Group

Implementation of the SNMP group is mandatory for all systems which support an SNMP protocol entity. Some of the objects defined below will be zero-valued in those SNMP implementations that are optimized to support only those functions specific to either a management agent or a management station. In particular, it should be observed that the objects below refer to an SNMP entity, and there may be several SNMP entities residing on a managed Node.
snmpInPkts (1.3.6.1.2.1.1 1.1)
The total number of messages delivered to the SNMP entity from the transport service.
Syntax
Counter
4-52 59047-09 C
A
Access
read-only
Status
mandatory
snmpOutPkts (1.3.6.1.2.1.1 1.2)
The total number of SNMP messages passed from the SNMP protocol entity to the transport service.
Syntax
Counter
Access
read-only
Status
4 – MIB-II Objects The SNMP Group
mandatory
snmpInBadV ersions (1.3.6.1.2.1.11.3)
The total number of SNMP messages delivered to the SNMP protocol entity and were for an unsupported SNMP version.
Syntax
Counter
Access
read-only
Status
mandatory
snmpInBadCommunityNames (1.3.6.1.2.1.1 1.4)
The total number of SNMP messages delivered to the SNMP protocol entity wh ich used a SNMP community name not known to the entity.
Syntax
Counter
Access
read-only
59047-09 C 4-53
4 – MIB-II Objects The SNMP Group
Status
mandatory
snmpInBadCommunityUses (1.3.6.1.2.1.1 1.5)
The total number of SNMP messages delivered to the SNMP protocol entity which represented an SNMP operation which was not allowed by the SNMP community named in the message.
Syntax
Counter
Access
read-only
Status
mandatory
S
snmpInASNParseErrs (1.3.6.1.2.1.11.6)
The total number of ASN.1 or BER errors encountered by the SNMP protocol entity when decoding received SNMP messages.
Syntax
Counter
Access
read-only
Status
mandatory
snmpInT ooBigs (1.3.6.1.2.1.11.8)
The total number of SNMP PDUs delivered to the SNMP protocol entity and for which the value of the error-status field is “tooBig”.
Syntax
Counter
Access
read-only
Status
mandatory
4-54 59047-09 C
A
snmpInNoSuchNames (1.3.6.1.2.1.11.9)
The total number of SNMP PDUs delivered to the SNMP protocol entity and for which the value of the error-status field is "NoSuchName".
Syntax
Counter
Access
read-only
Status
mandatory
snmpInBadV alues (1.3.6.1.2.1.11.10)
The total number of SNMP PDUs delivered to the SNMP protocol entity and for which the value of the error-status field is “badValue”.
Syntax
4 – MIB-II Objects The SNMP Group
Counter
Access
read-only
Status
mandatory
snmpInReadOnlys (1.3.6.1.2.1.1 1.11)
The total number valid SNMP PDUs delivered to the SNMP protocol entity and for which the value of the error-status field is “readOnly”. It should be noted that it is a protocol error to generate an SNMP PDU which contains the value ”readOnly” in the error-status field, as such, this object is provided as a means of detecting incorrect implementations of the SNMP.
Syntax
Counter
Access
read-only
Status
mandatory
59047-09 C 4-55
4 – MIB-II Objects The SNMP Group
snmpInGenErrs (1.3.6.1.2.1.1 1.12)
The total number of SNMP PDUs delivered to the SNMP protocol entity and for which the value of the error-status field is “genErr”.
Syntax
Counter
Access
read-only
Status
mandatory
snmpInT otalReqV ars (1.3.6.1.2.1.11.13)
The total number of MIB objects retrieved successfully by the SNMP protocol entity as the result of receiving valid SNMP Get-Request and Get-Next PDUs.
Syntax
S
Counter
Access
read-only
Status
mandatory
snmpInT otalSetV ars (1.3.6.1.2.1.11.14)
The total number of MIB objects altered successfully by the SNMP protocol entity as the result of receiving valid SNMP Set-Request PDUs.
Syntax
Counter
Access
read-only
Status
mandatory
snmpInGetRequests (1.3.6.1.2.1.1 1.15)
The total number of SNMP Get-Request PDUs accepted and processed by the SNMP protocol entity.
4-56 59047-09 C
A
Syntax
Counter
Access
read-only
Status
mandatory
snmpInGetNexts (1.3.6.1.2.1.1 1.16)
The total number of SNMP Get-Next PDUs accepted and processed by th e SNMP protocol entity.
Syntax
Counter
Access
4 – MIB-II Objects The SNMP Group
read-only
Status
mandatory
snmpInSetRequests (1.3.6.1.2.1.1 1.17)
The total number of SNMP Set-Request PDUs accepted and processed by the SNMP protocol entity.
Syntax
Counter
Access
read-only
Status
mandatory
snmpInGetResponses (1.3.6.1.2.1.1 1.18)
The total number of SNMP Get-Response PDUs accepted and processed by the SNMP protocol entity.
Syntax
Counter
59047-09 C 4-57
4 – MIB-II Objects The SNMP Group
Access
read-only
Status
mandatory
snmpInT raps (1.3.6.1.2.1.1 1.19)
The total number of SNMP Trap PDUs accepted and processed by the SNMP protocol entity.
Syntax
Counter
Access
read-only
Status
S
mandatory
snmpOutT ooBigs (1.3.6.1.2.1.11.20)
The total number of SNMP PDUs generated by the SNMP protocol entity and for which the value of the error-status field is “tooBig”'
Syntax
Counter
Access
read-only
Status
mandatory
snmpOutNoSuchNames (1.3.6.1.2.1.11.21)
The total number of SNMP PDUs generated by the SNMP protocol entity and for which the value of the error-status is "NoSuchName".
Syntax
Counter
Access
read-only
4-58 59047-09 C
A
Status
mandatory
snmpOutBadValues (1.3.6.1.2.1.1 1.22)
The total number of SNMP PDUs generated by the SNMP protocol entity and for which the value of the error-status field is “badValue”.
Syntax
Counter
Access
read-only
Status
mandatory
snmpOutGenErrs (1.3.6.1.2.1.1 1.24)
The total number of SNMP PDUs generated by the SNMP protocol entity and for which the value of the error-status field is “genErr”.
4 – MIB-II Objects The SNMP Group
Syntax
Counter
Access
read-only
Status
mandatory
snmpOutGetRequests (1.3.6.1.2.1.1 1.25)
The total number of SNMP Get-Request PDUs generated by the SNMP protocol entity.
Syntax
Counter
Access
read-only
Status
mandatory
59047-09 C 4-59
4 – MIB-II Objects The SNMP Group
snmpOutGetNexts (1.3.6.1.2.1.1 1.26)
The total number of SNMP Get-Next PDUs generated by the SNMP protocol entity.
Syntax
Counter
Access
read-only
Status
mandatory
snmpOutSetRequests (1.3.6.1.2.1.1 1.27)
The total number of SNMP Set-Request PDUs generated by the SNMP protocol entity.
Syntax
S
Counter
Access
read-only
Status
mandatory
snmpOutGetResponses (1.3.6.1.2.1.11.28)
The total number of SNMP Get-Response PDUs generated by the SNMP protocol entity.
Syntax
Counter
Access
read-only
Status
mandatory
snmpOutTrap s (1.3.6.1.2.1.11.29)
The total number of SNMP Trap PDUs generated by the SNMP protocol entity.
4-60 59047-09 C
A
Syntax
Counter
Access
read-only
Status
mandatory
snmpEnableAuthenTrap s (1.3.6.1.2.1.11.30)
Indicates whether the SNMP agent process is permitted to generate authentication-failure traps. The value of this object overrides any configuration information; as such, it provides a means whereby all authentication-failure traps may be disabled.
It is strongly recommended that this object be stored in non-volatile memory so that it remains constant between re-initializations of the network management system.
4 – MIB-II Objects The SNMP Group
Syntax
INTEGER { enabled(1), disabled(2) }
Access
read-write
Status
mandatory
Return Value
Read returns enabled (1) if AuthFailureTrap = True, otherwise disabled (2).
Writes not supported.
59047-09 C 4-61
4 – MIB-II Objects The SNMP Group
S
Notes
4-62 59047-09 C

5 Fibre Alliance MIB Objects

This section covers the implementation details for the Fibre Alliance Management Information Bases (FA-MIB) version 6.0 on the SANbox switch.

FA MIB Definitions

The FA-MIB version 4.0 is a collection of structured objects that resides on the workstation with the manager application. These objects define the syntax for information exchanged between the manager and the agent. The textual substitutions in Table 5-1 are specific to the FA-MIB and can be used in place of primitive data types.
Table 5-1. FA-MIB Textual Substitutions
Description Syntax
FcNameId OCTET STRING (SIZE(8)) FcGlobalId OCTET STRING (SIZE(16)) FcAddressId OCTET STRING (SIZE(3)) FcEventSeverity INTEGER
unknown (1), emergency (2), alert (3), critical (4), error (5), warning (6), notify (7), info (8), debug (9), mark (10) - All messages logged }
59047-09 C 5-1
{
5 – Fibre Alliance MIB Objects FA MIB Definitions
Description Syntax
FcUnitType INTEGER {
S
Table 5-1. FA -MIB Textual Substitutions (Continued)
unknown(1) other(2) - none of the following hub(3) - passive connectivity unit supporting loop protocol. switch(4) - active connectivity unit supporting multiple protocols. gateway(5) - unit that converts not only the interface but also
encapsulates the frame into another protocol. The assumption is that there is always two gateways connected together. For exam­ple, FC <-> ATM.
converter(6) - unit that converts from one interface to another. For example, FC <-> SCSI.
hba(7) - host bus adapter proxy-agent(8) - software proxy-agent storage-device(9) - disk, cd, tape, etc. host(10) - host computer storage-subsystem(11) - raid, library, etc. module(12) - subcomponent of a system swdriver(13) - software driver storage-access-device(14) - Provides storage management and
access for heterogeneous hosts and heterogeneous devices wdm(15) - waveform division multiplexer ups(16) - uninterruptable power supply }
revisionNumber
The revision number for this MIB. The format of the revision value is as follows:
(0) = high order major revision number (1) = low order major revision number (2) = high order minor revision number (3) = low order minor revision number
The value will be stored as an ASCII value. The following is the current value of
04.00 for this object.
(0) = '0' (1) = '4'
5-2 59047-09 C
A
(2) = '0' (3) = '0'
Syntax
DisplayString (SIZE (4))
Access
read-only
Status
mandatory
Return Value
A four digit ASCII value (for example, 0400 for MIB revision 4.0).

Connectivity Unit Group

5 – Fibre Alliance MIB Objects
Connectivity Unit Group
The objects described in this section are not in a table format. An example of how to access one of these objects is:
"snmpget localhost public fcmgmt.connSet.uNumber.0".
uNumber (1.3.6.1.3.94.1.1)
The number of connectivity units present on this system (represented by this agent). May be a count of the boards in a chassis or the number of full boxes in a rack.
Syntax
INTEGER
Access
read-only
Status
mandatory
Return Value
The number of switches in fabric.
systemURL (1.3.6.1.3.94.1.2)
The top-level URL of the system. If it does not exist, the value is an empty string. The URL format is implementation dependant and can have keywords embedded that are preceded by a percent sign (for example, %USER).
59047-09 C 5-3
5 – Fibre Alliance MIB Objects Connectivity Unit Group
Syntax
DisplayString
Access
read-write
Status
mandatory
Return Value
The switch IP address. For example, http://10.0.0.1. Writes not supported,
returns 'NoSuchName".
statusChangeTime (1.3.6.1.3.94.1.3)
The sysUpTime timestamp at which the last status change occurred for any members of the set, in centiseconds.
S
Syntax
TimeTicks
Access
read only
Status
obsolete
Return Value
The sysUpTime timestamp at which the last status change occurred.
configurationChangeTime (1.3.6.1.3.94.1.4)
The sysUpTime timestamp at which the last configuration change occurred for any members of the set, in centiseconds. This represents a union of change information for connUnitConfigurationChangeTime.
Syntax
TimeTicks
Access
read only
Status
obsolete
5-4 59047-09 C
A
Return Value
The sysUpTime timestamp at which the last configuration change occurred.
connUnitTableChangeTime (1.3.6.1.3.94.1.5)
The sysUpTime timestamp a t which the connUnitTable was updated (an entry was either added or deleted), in centiseconds.
Syntax
TimeTicks
Access
read only
Status
obsolete
Return Value
5 – Fibre Alliance MIB Objects

Connectivity Table

The sysUpTime timestamp at which the connUnitTable was updated.
Connectivity Table
The objects described in this section are in a table format indexed by switch World Wide Name. An example of how to access one of these objects given a WWN of 100000c0dd0090a7 is:
"snmpget localhost public fcmgmt.connSet.connUnitTable.connUnitEntry.connUnitId..16.0.0.192.
221.0.144.167.0.0.0.0.0.0.0.0".
connUnitId (1.3.6.1.3.94.1.6.1.1)
The unique identification for this connectivity unit among those within this proxy domain. The value must be unique within the proxy domain because it is the index variable for connUnitTable. The value assigned to a given connectivity unit should be persistent across agent and unit resets. It should be the same as connUnitGlobalId if connUnitGlobalId is known and stable.
Syntax
FcGlobalId
Access
read-only
59047-09 C 5-5
5 – Fibre Alliance MIB Objects Connectivity Table
Status
mandatory
Return Value
The World Wide Name of the switch followed by 8 bytes of zeros. For
example: 10 00 00 C0 DD 00 71 C9 00 00 00 00 00 00 00 00.
connUnitGlobalId (1.3.6.1.3.94.1.6.1.2)
An optional global-scope identifier for this connectivity unit. It must be a WWN for this connectivity unit or 16 octets of value zero.
Syntax
connUnitGlobalId
Access
read-only
S
Status
mandatory
Return Value
The World Wide Name of the switch followed by 8 bytes of zeros. For
example: 10 00 00 C0 DD 00 71 C9 00 00 00 00 00 00 00 00.
connUnitT ype (1.3.6.1.3.94.1.6.1.3)
The type of this connectivity unit.
Syntax
FcUnitType
Access
read-only
Status
mandatory
Return Value
switch (4)
connUnitNumports (1.3.6.1.3.94.1.6.1.4)
Number of physical ports in the connectivity unit (internal/embedded, external).
5-6 59047-09 C
