Psion Teklogix 7530 G2 User Manual

7530 G2 Hand-Held

Computer

User Manual

June 21, 2006 Part No. 8000081.A

ISO 9001 Certified

Quality Management System

© Copyright 2006 by Psion Teklogix Inc., Mississauga, Ontario

This document and the information it contains is the property of Psion Teklogix Inc.,
is issued in strict confidence, and is not to be reproduced or copied, in whole or in
part, except for the sole purpose of promoting the sale of Teklogix manufactured
goods and services. Furthermore, this document is not to be used as a basis for
design, manufacture, or sub-contract, or in any manner detrimental to the interests
of Psion Teklogix Inc.

All trademarks are the property of their respective holders.

Return-To-Factory Warranty

Psion Teklogix Inc. provides a return to factory warranty on this product for a period
of twelve (12) months in accordance with the Statement of Limited Warranty and
Limitation of Liability provided at www.psionteklogix.com/warranty. (If you are not
already a member of Teknet and you attempt to view this warranty, you will be asked
to register. As a member of Teknet, you will have access to helpful information about
your Psion Teklogix products at no charge to you.) In some regions, this warranty
may exceed this period. Please contact your local Psion Teklogix office for details.
For a list of offices, see Appendix A: “Support Services And Worldwide Offices”.
The warranty on Psion Teklogix manufactured equipment does not extend to any
product that has been tampered with, altered, or repaired by any person other than an
employee of an authorized Psion Teklogix service organization. See Psion Teklogix
terms and conditions of sale for full details.

Important:Psion Teklogix warranties take effect on the date of shipment.

Service

Psion Teklogix provides a complete range of product support services to its custom­ers. For detailed information, please refer to Appendix A: “Support Services And
Worldwide Offices”. This section also provides information about accessing support
services through the Psion Teklogix web site.

Waste Electrical and Electronic Equipment (WEEE) Directive

2002/96/EC

This Product, and its accessories, comply with the requirements of the Waste Electri­cal and Electronic Equipment (WEEE) Directive 2002/96/EC. If your end-of-life
Psion Teklogix product or accessory carries a label as shown here, please contact
your local country representative for details on how to arrange recycling.

For a list of international subsidiaries, please go to:

www.psionteklogix.com/public.aspx?s=us&p=Contacts.

Restriction On Hazardous Substances (RoHS) Directive 2002/95/EC

What is RoHS?

The European Union has mandated that high environmental standards be met in the
design and manufacture of electronic and electrical products sold in Europe, to reduce
hazardous substances from entering the environment. The “Restriction on Hazardous

Substances Directive (RoHS)” prescribes the maximum trace levels of lead, cad­mium, mercury, hexavalent chromium, and flame retardants PBB and PBDE that
may be contained in a product. Only products meeting these high environmental
standards may be “placed on the market” in EU member states after July 1, 2006.

RoHS Logo

Although there is no legal requirement to mark RoHS-compliant products, Psion
Teklogix Inc. indicates its compliance with the directive as follows:

The RoHS logo located either on the back of the product or underneath the battery in
the battery compartment (or on a related accessory such as the charger or docking
station) signifies that the product is RoHS-compliant as per the EU directive. Other
than as noted below, a Psion Teklogix product that does not have an accompanying
RoHS logo signifies that it was placed on the EU market prior to July 1, 2006, and is
thereby exempt from the directive.

Note: Not all accessories or peripherals will have a RoHS logo due to physical

space limitations or as a result of their exempt status.

Disclaimer

Every effort has been made to make this material complete, accurate, and up-to­date. In addition, changes are periodically added to the information herein; these
changes will be incorporated into new editions of the publication.

Psion Teklogix Inc. reserves the right to make improvements and/or changes in the
product(s) and/or the program(s) described in this document without notice, and
shall not be responsible for any damages, including but not limited to consequential
damages, caused by reliance on the material presented, including but not limited to
typographical errors.

TABLE OF CONTENTS

Program License Agreements ............................I

Approval And Safety Summary .........................VII

Chapter 1: Introduction

1.1 About This Manual ............................3

1.2 Text Conventions............................. 4

1.3 7530 G2 Features.............................4

1.4 About The 7530 G2 Hand-Held Computer ................7

1.4.1 The 7530 G2 Hand-Held Computer................8

1.4.2 Regulatory Labels......................... 9

Chapter 2: Basic Checkout

2.1 Preparing The 7530 G2 For Operation . . ................13

2.1.1 Equipment You Need To Get Started...............13

2.1.2 Charging The Battery.......................13

2.1.3 Installing The Battery.......................14

2.1.4 Switching On The Hand-Held...................14

2.1.5 Attaching Carrying Accessories..................15

2.2 Calibrating The Touchscreen.......................16

2.3 Configuring An IEEE 802.11 Radio In The Unit . . . ..........17

2.3.1 Assigning An IP Address.....................23

2.3.2 Name Servers Tab.........................24

2.3.3 Advanced Features.........................25

2.4 Checking The Scanner ..........................26

2.5 Using Microsoft ActiveSync.......................26

2.6 Resetting The Hand-Held.........................27

Psion Teklogix 7530 G2 Hand-Held Computer User Manual i

Contents

Chapter 3: Getting To Know Your 7530 G2

3.1 Features Of The 7530 G2 ........................31

3.2 The Battery................................ 32

3.2.1 Battery Safety ..........................32

3.2.2 Removing And Installing The Battery Pack........... 32

3.2.3 Battery Chargers.........................32

3.3 The Keyboard ..............................33

3.3.1 Modifier Keys .......................... 34

3.3.2 The Keys.............................34

3.3.3 Function And Macro Keys....................36

3.3.4 Alphanumeric Keyboard – 63-Key................ 38

3.3.5 Numeric Keyboard – 37-Key .................. 38

3.3.6 The Keypad Backlight......................40

3.4 The Display ............................... 41

3.4.1 Adjusting The Display Backlight ................41

3.4.2 Adjusting The Contrast......................41

3.4.3 Calibrating The Touchscreen...................41

3.5 7530 G2 Indicators............................43

3.5.1 LEDs...............................43

3.5.2 Onscreen Indicators ....................... 45

3.5.3 Audio Indicators.........................47

3.6 Internal Scanners............................. 48

3.6.1 Scanning Techniques.......................49

3.6.2 Scan LED Indicators.......................50

3.6.3 Troubleshooting ......................... 50

3.6.4 Operating One Dimensional (1D) Internal Laser Scanners . . . 50

3.6.5 Operating Internal PDF Laser Scanners............. 51

3.6.6 Operating Internal Two Dimensional (2D) Imager Scanners . . 51

3.7 Connecting & Disconnecting Tethered Peripherals ........... 52

3.8 Monitoring The Battery And Maximizing Run Time.......... 53

3.8.1 Storing Batteries.........................54

3.9 Monitoring The Network Connection .................. 55

3.10 Uploading Data In A Docking Station.................. 55

3.11 General Maintenance ..........................56

3.11.1Caring For The Touchscreen................... 56

ii Psion Teklogix 7530 G2 Hand-Held Computer User Manual

3.11.2 Cleaning The 7530 G2.......................56

Chapter 4: Working With Windows CE

4.1 Navigating In Windows CE And Applications ..............59

4.1.1 Navigating Using A Touchscreen And Stylus...........59

4.1.2 Navigating Using The Keyboard . ................59

4.2 Working With Files, Folders And Programs...............60

4.3 The Startup Desktop............................61

4.3.1 The Desktop Icons.........................62

4.3.2 The Taskbar............................62

4.4 The Start Menu..............................65

4.4.1 The Desktop............................66

4.4.2 Security Settings..........................66

4.4.3 Programs..............................68

4.4.4 Shortcuts..............................69

4.4.5 Settings...............................71

4.4.6 Run.................................72

4.4.7 Shutdown .............................72

4.5 Using A Dialog Box............................73

Contents

Chapter 5: Configuration

5.1 Remote Desktop Connection .......................81

5.2 The TekTerm Application.........................81

5.3 Pocket PC Compatibility.........................81

5.4 The Control Panel.............................82

5.5 Control Panel Icons............................83

5.6 Basic Setup................................87

5.6.1 Display Properties.........................87

5.6.2 Keyboard Properties . .......................90

5.6.3 Volume And Sound Properties . . ...............100

5.6.4 Power Management Properties.................102

5.6.5 Stylus Properties.........................107

5.6.6 Manage Triggers.........................109

5.6.7 Certificate Assignment .....................113

5.7 Bluetooth Setup.............................114

5.7.1 The Devices Tab.........................115

Psion Teklogix 7530 G2 Hand-Held Computer User Manual iii

Contents

5.7.2 The Servers Tab .........................118

5.7.3 Outgoing Tab...........................118

5.7.4 Active Conn. Tab.........................119

5.7.5 The Properties Tab........................120

5.7.6 Bluetooth GPRS Connection...................121

5.8 Total Recall ...............................126

5.8.1 Creating A Backup Profile....................126

5.8.2 Restoring A Profile........................130

5.9 IPv6 Support ...............................131

5.10 Narrow Band Radio Setup........................132

5.10.1Info Tab..............................132

5.10.2Channel Tab...........................135

5.10.3Protocol Tab...........................138

5.10.4Power Tab............................141

5.10.5Radio Tab.............................142

5.11 Scanner Settings.............................143

5.11.1Bar Codes.............................144

5.11.2Non-Decoded Scanners .....................145

5.11.3Decoded (Internal) Scanners...................156

5.11.4Decoded (Intermec ISCP)....................173

5.11.5Imager ..............................187

5.11.6Options Tab ...........................196

5.11.7Translations............................198

5.11.8Ports ...............................199

5.12 SNMP (Simple Network Management Protocol) Setup.........204

5.12.1Contact Tab............................205

5.12.2Communities Tab.........................206

5.12.3Trap Destination Tab.......................208

5.12.4Permitted Hosts Tab.......................210

Chapter 6: Peripheral Devices & Accessories

6.1 External Bar Code Readers.......................215

6.1.1 PowerScan™ Standard, LR and XLR Bar Code Scanners . . . 215

6.1.2 Entering Data With The Bar Code Reader............215

6.2 RD7950 Integrated UHF RFID Reader .................215

6.3 Batteries.................................215

iv Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Contents

6.4 Battery Charging ............................216

6.5 Gang Charger..............................216

6.5.1 Installation............................216

6.5.2 Operator Controls........................217

6.5.3 Charge Indicators........................217

6.5.4 Charging Batteries........................217

6.5.5 Troubleshooting . . . ......................218

6.6 Combo Charger.............................219

6.6.1 Installation............................219

6.6.2 Operator Controls........................220

6.6.3 Using the Combo Charger With The 7530 G2.........220

6.6.4 Charging The Spare Battery...................220

6.6.5 Charge Indicators........................221

6.6.6 Troubleshooting . . . ......................221

6.7 Combo Dock ..............................222

6.7.1 Installation............................222

6.7.2 Using The Combo Dock.....................222

6.7.3 Network Access.........................222

6.7.4 Troubleshooting . . . ......................222

6.8 Quad Dock ...............................223

6.8.1 Installation............................223

6.8.2 Indicators And Controls.....................223

6.8.3 Using The Quad Dock......................224

6.8.4 Network Access.........................224

6.8.5 Battery Charging.........................224

6.8.6 Troubleshooting . . . ......................224

6.9 Portable Docking Module (PDM)....................225

6.10 Bluetooth Peripherals..........................228

6.11 The 7530 G2 Picker Cradle . ......................228

6.11.1Picker Cradle Mounting Recommendations...........229

6.11.2Wiring Guidelines........................230

6.11.3Using The Picker Cradle.....................230

6.11.4Maintaining The Picker Cradle.................230

6.11.5 Powered Cradle Installation In High Voltage Vehicles . . . . . 231

6.11.6Powered Cradle Installation...................231

6.11.7The Port Replicator .......................233

Psion Teklogix 7530 G2 Hand-Held Computer User Manual v

Contents

6.12 Tether Adaptor Cables..........................234

Chapter 7: Specifications

7.1 7530 G2 Hand-Held Computer Specifications .............237

7.2 Radio Specifications...........................239

7.3 Internal Scanner Port...........................240

7.4 RFID Applications............................240

7.5 External Scanners............................240

7.6 Internal Scanner Specifications.....................240

7.6.1 SE 1200 High Performance & Long Range Specs. . ......241

7.6.2 SE 1200 Advanced Long Range & SE 2223PDF Specs.....241

7.6.3 SE 1224HP Scanner Specifications . . . ............243

7.6.4 SE 1524ER – Extended Range Scanner Specifications .....244

7.6.5 EV15 Imager Specifications...................245

7.6.6 SX5303 Imager Specifications..................247

7.7 1900 mAh Lithium-Ion Battery Pack..................247

7.8 2400 mAh Lithium-Ion Battery Pack..................248

Appendix A: Support Services And Worldwide Offices

A.1 Technical Support . . . .........................A-1

A.2 Product Repairs .............................A-1

A.3 Worldwide Offices............................A-2

Appendix B: Port Pinouts

B.1 Tether Port Pinout . . . .........................B-1

B.2 Docking Station Connector .......................B-1

B.3 Battery Contacts.............................B-2

B.4 JB5 To USB Type B Cable - PN CA1020 ................B-3

B.5 JB5 To RS-232 Serial Cable - PN CA1010 . . . ............B-3

Appendix C: USB Setup Application

C.1 USB Setup................................C-1

C.1.1 Launching The Application...................C-2

C.1.2 Installation Complete Dialog Box................C-3

vi Psion Teklogix 7530 G2 Hand-Held Computer User Manual

PROGRAM LICENSE AGREEMENTS

Microsoft's End User License Agreement

You have acquired a device (“DEVICE”) that includes software licensed by Psion Teklogix
Inc. from Microsoft Licensing Inc. or its affiliates (‘MS”). Those installed software products
of MS origin, as well as associated media, printed materials, and “online” or electronic doc­umentation (“SOFTWARE”) are protected by international intellectual property laws and
treaties. The SOFTWARE is licensed, not sold. All rights reserved.

IF YOU DO NOT AGREE TO THIS END USER LICENSE AGREEMENT (“EULA”),
DO NOT USE THE DEVICE OR COPY THE SOFTWARE. INSTEAD, PROMPTLY
CONTACT PSION TEKLOGIX INC. FOR INSTRUCTIONS ON RETURN OF THE
UNUSED DEVICE(S) FOR A REFUND. ANY USE OF THE SOFTWARE, INCLUD-

ING BUT NOT LIMITED TO USE ON THE DEVICE, WILL CONSTITUTE YOUR
AGREEMENT TO THIS EULA (OR RATIFICATION OF ANY PREVIOUS CON­SENT).

GRANT OF SOFTWARE LICENSE. This EULA grants you the following license:

• You may use the SOFTWARE only on the DEVICE.

• NOT FAULT TOLERANT. THE SOFTWARE IS NOT FAULT TOLERANT.
PSION TEKLOGIX INC. HAS INDEPENDENTLY DETERMINED HOW TO
USE THE SOFTWARE IN THE DEVICE, AND MS HAS RELIED UPON
PSION TEKLOGIX INC. TO CONDUCT SUFFICIENT TESTING TO DETER­MINE THAT THE SOFTWARE IS SUITABLE FOR SUCH USE.

• NO WARRANTIES FOR THE SOFTWARE. THE SOFTWARE is provided

“AS IS” and with all faults. THE ENTIRE RISK AS TO SATISFACTORY
QUALITY, PERFORMANCE, ACCURACY, AND EFFORT (INCLUDING
LACK OF NEGLIGENCE) IS WITH YOU. ALSO, THERE IS NO WAR­RANTY AGAINST INTERFERENCE WITH YOUR ENJOYMENT OF
THE SOFTWARE OR AGAINST INFRINGEMENT. IF YOU HAVE

RECEIVED ANY WARRANTIES REGARDING THE DEVICE OR THE SOFT­WARE, THOSE WARRANTIES DO NOT ORIGINATE FROM, AND ARE NOT
BINDING ON, MS.

• Note on Java Support. The SOFTWARE may contain support for programs
written in Java. Java technology is not fault tolerant and is not designed, manufac­tured, or intended for use or resale as online control equipment in hazardous envi­ronments requiring fail-safe performance, such as in the operation of nuclear

Psion Teklogix 7530 G2 Hand-Held Computer User Manual I

License Agreement

facilities, aircraft navigation or communication systems, air traffic control, direct
life support machines, or weapons systems, in which the failure of Java technology
could lead directly to death, personal injury, or severe physical or environmental
damage. Sun Microsystems, Inc. has contractually obligated MS to make this dis­claimer.

• No Liability for Certain Damages. EXCEPT AS PROHIBITED BY LAW, MS

SHALL HAVE NO LIABILITY FOR ANY INDIRECT, SPECIAL, CONSE­QUENTIAL OR INCIDENTAL DAMAGES ARISING FROM OR IN CON­NECTION WITH THE USE OR PERFORMANCE OF THE SOFTWARE.
THIS LIMITATION SHALL APPLY EVEN IF ANY REMEDY FAILS OF
ITS ESSENTIAL PURPOSE. IN NO EVENT SHALL MS BE LIABLE FOR
ANY AMOUNT IN EXCESS OF U.S. TWO HUNDRED FIFTY DOLLARS
(U.S.$250.OO).

• Limitations on Reverse Engineering, Decompilation, and Disassembly. Yo u
may not reverse engineer, decompile, or disassemble the SOFTWARE, except and
only to the extent that such activity is expressly permitted by applicable law not­withstanding this limitation.

• SOFTWARE TRANSFER ALLOWED BUT WITH RESTRICTIONS. Yo u
may permanently transfer rights under this EULA only as part of a permanent sale
or transfer of the Device, and only if the recipient agrees to this EULA. If the
SOFTWARE is an upgrade, any transfer must also include all prior versions of the
SOFTWARE.

• EXPORT RESTRICTIONS. You acknowledge that SOFTWARE is subject to
U.S. export jurisdiction. You agree to comply with all applicable international and
national laws that apply to the SOFTWARE, including the U.S. Export Administra­tion Regulations, as well as end-user, end-use and destination restrictions issued by
U.S. and other governments. For additional information see
http://www.microsoft.com/exporting/.

Psion Teklogix Inc. End User License Agreement

IMPORTANT – READ CAREFULLY:

This License Agreement (“Agreement”) is a legal agreement between you and Psion Tek­logix (“we”), the licensor of this software package (“Software”), for your use of the Soft­ware only as authorized in this Agreement.

By clicking on the “Accept” or other appropriate assent button and/or installing the Soft­ware, you agree to be and are hereby bound by the terms and conditions of this Agreement.
If you do not agree with this Agreement, we do not grant you a license to the Software, and
you may not install or use the Software or any accompanying documentation.

II Psion Teklogix 7530 G2 Hand-Held Computer User Manual

License Agreement

The Software is the property of Psion Teklogix Inc. or its licensors and is protected by copy­right laws and international copyright treaties, as well as other intellectual property laws and
treaties. The Software is licensed, not sold. Psion Teklogix Inc. provides the Software and
licenses its use worldwide. You assume responsibility for the selection of the Software to
achieve your intended results, and for the use and results obtained from it.

1. GRANT OF LICENSE

We hereby grant you and you hereby accept a non-exclusive, non-transferable, limited
license to install and use the Software in object code form only, subject to the terms and
restrictions set forth in this Agreement. Except as explicitly set forth below, (i) you are not
permitted to copy, sell, lease or rent, distribute or sublicense the Software or to use the Soft­ware in a time-sharing arrangement or in any other unauthorized manner; (ii) no license is
granted to you in the human readable code of the Software (source code); and (iii) this
Agreement does not grant you any rights to patents, copyrights, trade secrets, trademarks,
intellectual property or any other ownership rights with respect to the Software.

2. DESCRIPTION OF REQUIREMENTS, RESTRICTIONS, RIGHTS AND
LIMITATIONS

a. Copy. The right and license granted to you shall be limited to installation and use

of the Software up to but not exceeding the number of copies you have licensed.
However, you may make a copy of the Software for backup or archival purposes.
You shall not remove any copyright notice or proprietary notices, labels or marks
in or on the Software.

b. Evaluation. As part of evaluation, you may install and use the Software only

during the specified evaluation period. Unless you register the license as
described below, the evaluation license shall expire upon the expiration of the
evaluation period.

c. License Registration. You will be required to provide a license ID, unique to

each device, for registering your Software license. As part of your software
license registration, we will provide you a corresponding license key for each
device.

d. No Modifications. You may not modify or create any derivative work of the

Software or any copy or portion thereof nor may you remove any Software iden­tification, copyright or other notices.

e. No Distribution. You may not distribute the Software, in whole or in part, to any

other third party.

f. Virus Program. You may not develop or knowingly incorporate any virus pro-

gram that may be harmful to a computer or a network in conjunction with the
Software, or use the Software for any other purpose as which may be harmful to
a third party.

g. Assignment. You may not assign or transfer the Software to a third party or

allow a third party to use the same.

h. Reverse Engineering. Modification, reverse engineering, reverse compiling,

Psion Teklogix 7530 G2 Hand-Held Computer User Manual III

License Agreement

disassembly, unbundling or extraction of the Software is expressly prohibited.

i. Export Restrictions. You agree to comply with all applicable laws and regula-

tions and that you will not export or re-export the Software, or any part or copies
thereof, or any products utilizing the Software in violation of applicable laws or
regulations of the United States or the country in which you obtained them.

3. HIGH RISK ACTIVITIES

The Software is not fault-tolerant and is not designed, manufactured or intended for use or
resale as on-line control equipment in hazardous environments requiring fail-safe perfor­mance, such as in the operation of nuclear facilities, aircraft navigation or communication
systems, air traffic control, direct life support machines, or weapons systems, in which the
failure of the Software could lead to death, personal injury, or severe physical or environ­mental damage (“High Risk Activities”). We specifically disclaim any express or implied
warranty of fitness for High Risk Activities.

4. DISCLAIMER OF WARRANTY

We do not warrant uninterrupted or error free operation of the Software nor do we warrant
that the Software will meet your requirements. THE SOFTWARE IS PROVIDED “AS-IS”
WITHOUT ANY WARRANTY WHATSOEVER AND WITHOUT ANY TECHNICAL
SUPPORT OF ANY KIND. WE DISCLAIM ANY AND ALL REPRESENTATIONS,
WARRANTIES AND CONDITIONS, WHETHER EXPRESS OR IMPLIED, INCLUD­ING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABLE QUALITY OR FITNESS FOR A PARTICULAR PURPOSE. WE DO
NOT WARRANT OR MAKE ANY REPRESENTATIONS REGARDING THE USE OR
THE RESULTS OF THE USE OF THE SOFTWARE IN TERMS OF ITS CORRECT­NESS, ACCURACY, RELIABILITY, USE WITH FUTURE PSION TEKLOGIX
DEVICES INTRODUCED, OR OTHERWISE. YOU EXPRESSLY ACKNOWLEDGE
AND AGREE THAT USE OF THE SOFTWARE IS AT YOUR SOLE RISK AND YOU
ARE RESPONSIBLE FOR INSTALLATION OF THE SOFTWARE ON YOUR COM­PUTER.

5. LIMITATION OF LIABILITY

We are liable for no more than the value of the license fee that you paid for the Software.
This limitation is cumulative and our responsibility for multiple claims will not exceed in
aggregate this limit.

Under no circumstances are we or our third party suppliers liable for damages of third parties
claimed against you, or for harm to your records or data, or special, incidental, indirect, or
consequential damages, including but not limited to lost profits, lost business revenue or fail­ure to realize expected savings, loss of data, loss of use of the Software or any associated
equipment, downtime and user’s time, even if you informed us of their possibility, or for
breach of any express or implied warranty, breach of contract, negligence, strict liability or
any other legal theory related to the Software. This limitation applies whether you are enti­tled to claim damages from us or our third party suppliers as a matter of contract or tort.

IV Psion Teklogix 7530 G2 Hand-Held Computer User Manual

License Agreement

6. COPYRIGHTS, OWNERSHIP AND PROPRIETARY RIGHTS

All title and copyrights in and to the Software, and any copies thereof, are owned by Psion
Teklogix Inc. or its suppliers. The Software also contains copyrighted material licensed from
our suppliers or obtained from open source and all rights to such copyrighted material rests
with such suppliers. Additional third party license terms and conditions may apply. We
retain title to the Software and any copies made from it. Any copies of the Software you
made are subject to the restrictions of this Agreement.

WE DISCLAIM ALL WARRANTIES AND INDEMNITIES, EXPRESS, IMPLIED OR
STATUTORY, FOR PATENT OR COPYRIGHT INFRINGEMENT.

7. CONFIDENTIALITY

You agree not to use or disclose any proprietary information provided by us, except for the
purposes of this Agreement. You agree not to reproduce any of the copyrighted materials
unless expressly permitted by this Agreement.

8. ENDING THIS AGREEMENT

We may terminate this Agreement and your license immediately without notice if (a) you
fail to comply with any term of this Agreement, or (b) your rights are assigned by you, by
operation of law or otherwise. In such event, you must return or destroy all copies and com­ponent parts of the Software and documentation, as well as any other Psion Teklogix propri­etary information in your possession, within fourteen (14) days of the date of termination.
Any rights and obligations under this Agreement that by their nature continue after it ends
will remain in effect until they are completed.

9. GENERAL

The laws of the Province of Ontario and the federal laws applicable therein, excluding the
conflict of laws provisions, govern this Agreement. If any provision of this Agreement is
deemed invalid or unenforceable by any country, that particular provision will be deemed
modified to the extent necessary to make the provision valid and enforceable, and the
remaining provisions will remain in full force and effect. Failure by us to insist on strict per­formance or to exercise a right when entitled, does not prevent us from doing so at a later
time, either in relation to that default or any subsequent one.

No modifications of this Agreement shall be effective unless in writing and approved by us.

You acknowledge that you have read this Agreement, understand it, and that it is the com­plete agreement between you and Psion Teklogix with respect to the subject matter hereof
and supersedes all prior agreements, oral or written.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual V

APPROVAL AND SAFETY SUMMARY

FCC DECLARATION OF CONFORMITY (DoC)

Applicant’s Name & Address: PSION TEKLOGIX

2100 Meadowvale Blvd.
Mississauga, Ontario
Canada L5N 7J9
Contact Person: Iain Roy
Telephone No.: [phone]

US Representative’s Name & Address: 1810 Airport Exchange Blvd., Suite 500

Equipment Type/Environment: Computing Devices

Trade Name / Model No.: 7530 G2 Hand-Held Micro-computer with

Year of Manufacture: 2006

Standard(s) to which Conformity is Declared:

The 7530 G2 Hand Held Micro-computer with Portable Docking Module, supplied by
Psion Teklogix, has been tested and found to comply with FCC PART 15, SUBPART B -

UNINTENTIONAL RADIATORS, CLASS B COMPUTING DEVICES FOR
HOME & OFFICE USE.

I, the undersigned, hereby declare that the equipment as tested is representative within
manufacturing tolerance to units.

Applicant

Signature Signature

Mike Doyle Kyle Day

Full Name Full Name

Vice President, Engineering

Position Position

Mississauga, Ontario, Canada

Place Place

June 2006

Date Date

Erlanger, KY, 41018, USA
Contact Person: Kyle Day
Telephone No.: [phone]

Portable Docking Module

Legal Representative in U.S.

Vice President, Channel Sales

Erlanger, KY 41018, USA

June 2006

Psion Teklogix 7530 G2 Hand-Held Computer User Manual VII

Approvals And Safety Summary

CE Marking

When used in a residential, commercial or light industrial environment the product
and its approved UK and European peripherals fulfil all requirements for CE marking.

R&TTE Directive 1999/5/EC

This equipment complies with the essential requirements of EU Directive
1999/5/EC (Declaration available: www.psionteklogix.com).

Cet équipement est conforme aux principales caractéristiques définies dans la
Directive européenne RTTE 1999/5/CE. (Déclaration disponible sur le site:
www.psionteklogix.com).

Die Geräte erfüllen die grundlegenden Anforderungen der RTTE-Richtlinie
(1999/5/EG). (Den Wortlaut der Richtlinie finden Sie unter:
www.psionteklogix.com).

Questa apparecchiatura è conforme ai requisiti essenziali della Direttiva Europea
R&TTE 1999/5/CE. (Dichiarazione disponibile sul sito: www.psionteklogix.com).

Este equipo cumple los requisitos principales de la Directiva 1995/5/CE de la UE,
“Equipos de Terminales de Radio y Telecomu-nicaciones”. (Declaración disponible
en: www.psionteklogix.com).

Este equipamento cumpre os requisitos essenciais da Directiva 1999/5/CE do
Parlamento Europeu e do Conselho (Directiva RTT). (Declaração disponível no
endereço: www.psionteklogix.com).

Ο εξοπλισμός αυτός πληροί τις βασικές απαιτήσεις της κοινοτικής οδηγίας EU
R&TTE 1999/5/EΚ. (Η δήλωση συμμόρφωσης διατίθεται στη διεύθυνση:
www.psionteklogix.com)

Deze apparatuur voldoet aan de noodzakelijke vereisten van EU-richtlijn
betreffende radioapparatuur en telecommunicatie-eindappa-ratuur 199/5/EG.
(verklaring beschikbaar: www.psionteklogix.com).

Dette udstyr opfylder de Væsentlige krav i EU's direktiv 1999/5/EC om Radio- og
teleterminaludstyr. (Erklæring findes på: www.psionteklogix.com).

Dette utstyret er i overensstemmelse med hovedkravene i R&TTE-direktivet
(1999/5/EC) fra EU. (Erklæring finnes på: www.psionteklogix.com).

Utrustningen uppfyller kraven för EU-direktivet 1999/5/EC om ansluten
teleutrustning och ömsesidigt erkännande av utrustningens överensstämmelse
(R&TTE). (Förklaringen finns att läsa på: www.psionteklogix.com).

VIII Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Approvals And Safety Summary

Tämä laite vastaa EU:n radio- ja telepäätelaitedirektiivin (EU R&TTE Directive
1999/5/EC) vaatimuksia. (Julkilausuma nähtävillä osoitteessa:
www.psionteklogix.com).

Psion Teklogix tímto prohlašuje, že 7530 G2 je ve shodě se základními požadavky a
dalšími příslušnými ustanoveními směrnice 1995/5/ES (NV č. 426/2000 Sb.) a
Prohlášení o shodě je k dispozici na www.psionteklogix.com. Toto zarízení lze
provozovat v České republice na základě generální licence č. GL-12/R/2000.

Psion Teklogix týmto vyhlasuje, že 7530 G2 spĺňa základné požiadavky a všetky
príslušné ustanovenia Smernice 1995/5/ES (NV č. 443/2001 Z.z.) a Vyhlásenie o
zhode je k dispozícii na www.psionteklogix.com. Toto zariadenie je možné
prevádzkovat’ v Slovenskej republike na základe Všeobecného povolenia č. VPR­01/2001.

L

Use of the 802.11g 7530 G2 Hand-Held in France:
Owing to French Government restrictions, the 802.11g 7530 G2 Hand-Held
Computer is limited to indoor use. It may be used outdoors, on private property,
only with prior authorization from the French Ministry of Defense.

FCC Information To Users

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual IX

Approvals And Safety Summary

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interfer­ence that may cause undesired operation.

FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment under 47 CFR 2.1093 paragraph (d)(2), for use in a PDA.
End users must follow the specific operating instructions for satisfying RF
exposure compliance.

This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.

Some equipment in hospitals and aircraft are not shielded from radio frequency
energy. Do not use the 7530 G2 hand-held onboard aircraft, or in hospitals, without
first obtaining permission.

Do not use near pacemakers. The product may affect the operation of some
medically implanted devices such as pacemakers, causing them to malfunction.
Avoid placing your product next to such devices. Keep a minimum distance of 20
cm between the device and the product to reduce the risk of interference. If you have
any reason to suspect that interference is taking place, turn off the 7530 G2 hand­held and contact your cardiologist for assistance.

Note: To maintain compliance with the FCC RF exposure guidelines, if

you wear the 7530 G2 on your body, use the Psion Teklogix approved
carrying case.

Use of non-approved accessories may violate FCC RF exposure guidelines.

X Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Approvals And Safety Summary

Emissions Information For Canada

This Class B digital apparatus meets all requirements of the Canadian Interference­Causing Equipment Regulations. When using the 802.11 radio option, to prevent
radio interference, this device is intended to be operated indoors and away from
windows to provide maximum shielding. Equipment (or its transmit antenna) that is
installed outdoors is subject to licensing.

Cet appareil numérique de la classe B respecte toutes les exigences du Règlement
sur le matériel brouilleur du Canada. En cas d’utilisation du module radio 802.11,
afin d'éviter toute interférence radio avec le service autorisé, l'appareil doit être
utilisé à l'intérieur, tout en tant éloigné de toute fenêtre afin de garantir le maximum
de protection. Si cet équipement (ou son antenne émettrice) est installé à l'extérieur,
il est alors soumis à licence.

Warning to Users

This product is a Class I/Class II laser product according to CDRH 21 CFR 1040.10
and 1040.11 and Class1/Class 2 laser product according to IEC 60825­1:1993+A1:1997+A2:2001.

LASER WARNINGS

For your own safety, it is critical that you comply with the following warnings:

CAUTION

Do not look into the laser beam or point the beam at people or animals.

CAUTION

Using controls or adjustments, or performing procedures other than those
specified herein may result in hazardous radiation exposure.

CAUTION

The use of optical instruments (magnification devices) with this product
will increase eye hazard.

DO NOT OPERATE IN AN EXPLOSIVE ATMOSPHERE

Operating Psion Teklogix equipment where explosive gas is present may
result in an explosion.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual XI

Approvals And Safety Summary

DO NOT REMOVE COVERS OR OPEN ENCLOSURES

To avoid injury, the equipment covers and enclosures should only be
removed by qualified service personnel. Do not operate the equipment
without the covers and enclosures properly installed.

CAUTION!

Danger of explosion if a 7530 G2 battery is incorrectly handled, charged,
disposed of or replaced. Replace only with the same or equivalent type
recommended by the manufacturer. Dispose of used batteries according to
the instructions described in “Lithium-Ion Battery Safety Precautions” on
page XII. Carefully review all battery safety issues.

VORSICHT!

Explosiongefahr bei unsachgemäßem Austausch der Batterie Ersatz nur
durch denselben oder einen vom Hersteller empfohlenen gleichwertigen
Typ. Entsorgung gebrauchter Batterien nach Angaben des Herstellers.

LITHIUM-ION BATTERY SAFETY PRECAUTIONS

Important: Before charging or using the battery pack, it is critical that the

safety information in this section is reviewed and that all warn­ings are strictly followed.

Warning: BATTERIES ARE CONSIDERED HAZARDOUS WASTE and

must be returned to Psion Teklogix for proper disposal. Forward all
used batteries to one of the following offices:

Psion Teklogix Inc. Psion Teklogix Corp.
2100 Meadowvale Blvd. 1810 Airport Exchange Blvd.
Mississauga, Ontario Suite 500
Canada Erlanger, Kentucky
L5N 7J9 USA 41018

Psion Teklogix S.A.
La Duranne, 135 Rue Rene Descartes
BP 421000, 13591 Aix-En-Provence
Cedex 3; France

XII Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Approvals And Safety Summary

Warning: TO PREVENT the battery from leaking acid, generating heat or

exploding, adhere to precautions listed below.

• The battery incorporates built-in safety devices. To ensure
their proper function, do not disassemble or alter any parts
of the battery.

• Do not short-circuit the battery by directly connecting any of the
exposed terminals with metal objects such as wire. Do not trans­port or store the battery together with metal objects such as neck­laces, hair pins, etc.

• Do not dispose of batteries in fire.

• Do not use or leave the battery near a heat source such as a fire
or heater.

• Do not immerse the battery in water.

• When charging, use the battery charger specifically designed for
the battery.

• Do not pierce, strike, throw or step on the battery.

• Do not directly solder the battery.

• Do not connect the battery to an electrical outlet, vehicle
cigarette lighter, etc.

• Do not put battery into a microwave oven or pressurized con­tainer.

• Do not use the battery in combination with primary batteries (such
as dry-cell batteries) or batteries of different capacities or brands.

• Immediately remove the battery from the device or battery
charger and stop use if the battery gives off an odor, generates
heat, becomes discoloured or deformed, or in any way appears
abnormal during use.

• Do not continue charging the battery if it does not recharge within
the specified charge time.

• The battery may burst or ignite if the battery leaks. Always ensure
that it is away from any exposed flames.

• If leaking electrolyte sprays into your eyes, rinse them with clean
running water, and immediately seek medical attention.

• Do not store the battery in extremely high temperatures (e.g., a
vehicle, strong direct sunlight, etc.). This may cause the battery to
overheat or ignite, and it may also reduce the performance and
service life of the battery.

• Do not use in areas where static electricity is greater than what the
manufacturer guarantees.

• Keep batteries out of reach of children.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual XIII

Approvals And Safety Summary

• Always switch the unit off before changing the battery. While the
battery is being replaced, the 7530 G2 will save its current data for
at least 10 minutes.

IMPORTANT CHARGER AND AC/DC ADAPTOR SAFETY INSTRUCTIONS

• SAVE THESE INSTRUCTIONS – This manual contains important safety
and operating instructions for battery chargers and AC/DC adaptors.

• Before using the battery charger or AC/DC adaptor, read all instructions and
cautionary markings on the (1) AC/DC adaptor, (2) battery charger, (3) bat­tery, and (4) product using the battery.

• The mains power cord shall comply with national safety regulations of the
country where the equipment is to be sold.

• Use of an attachment not recommended or sold by the battery charger or
AC/DC adaptor manufacturer may result in fire, electric shock, or
personal injury.

• To reduce risk of damage to the electric plug and cord when unplugging the
charger or AC/DC adaptor, pull the plug rather than the cord.

• Make sure the cord is positioned so that it is not stepped on, tripped over,
or otherwise subjected to damage or stress.

• Do not operate the charger or AC/DC adaptor with a damaged cord or plug.
Replace immediately.

• Do not operate the charger or AC/DC adaptor if it has received a sharp blow,
been dropped, or otherwise damaged in any way; it should be inspected by
qualified service personnel.

• Do not disassemble the charger or AC/DC adaptor; it should be repaired by
qualified service personnel. Incorrect reassembly may result in electric shock
or fire.

• To reduce risk of electric shock, unplug the charger or AC/DC adaptor from
the outlet before attempting any maintenance or cleaning.

• An extension cord should not be used unless absolutely necessary. Use of an
improper extension cord could result in fire or electric shock.

• If an extension cord must be used, make sure:

• The plug pins on the extension cord are the same number, size,
and shape as those on the charger or AC/DC adaptor.

• The extension cord is properly wired and in good electrical
condition and that the wire size is larger than 16 AWG.

• Do not expose the charger or AC/DC adaptor to rain or snow.

XIV Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Approvals And Safety Summary

• Do not use the charger if, after an overnight charge, any of the batteries feel
warmer than the charger housing. The charger should be inspected by
qualified service personnel.

• Do not use the charger if any of the batteries or the charger get more than
lukewarm. Do not use the AC/DC adaptor if it gets more than lukewarm. The
equipment should be inspected by qualified personnel.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual XV

INTRODUCTION 1

1.1 About This Manual..............................3

1.2 Text Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

1.3 7530 G2 Features...............................4

1.4 About The 7530 G2 Hand-Held Computer..................7

1.4.1 The 7530 G2 Hand-Held Computer . . . . . . . . . . . . . . . . . . 8

1.4.2 Regulatory Labels ...........................9

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 1

Chapter 1: Introduction

About This Manual

1.1 About This Manual

This manual describes how to configure, operate and maintain the Psion Teklogix
7530 G2 hand-held computer.

Chapter 1: Introduction

provides a basic overview of the 7530 G2 hand-held.

Chapter 2: Basic Checkout

describes the steps required to get the 7530 G2 ready for operation.

Chapter 3: Getting To Know Your 7530 G2

describes the 7530 G2 features and outlines how to charge and maintain the bat­tery. This chapter also provides a description of the keyboard, how to navigate
in Microsoft Windows CE, how to use the internal scanner, and so on.

Chapter 4: Working With Windows CE

describes the Microsoft Windows CE desktop and how to use it. This chapter
also outlines the basics of moving around a Windows CE window, selecting and
opening icons, files, folders and working with a Windows dialog box.

Chapter 5: Configuration

provides a description of the Windows CE Control Panel and how to use it to
configure the 7530 G2, along with the scanners attached to the hand-held,
and so on.

Chapter 6: Peripheral Devices & Accessories

describes the peripherals and accessories available for your 7530 G2 hand-held.

Chapter 7: Specifications

details radio, hand-held computer and battery specifications.

Appendix A: Support Services And Worldwide Offices

provides helpdesk phone numbers and provides web-based information to help
you search for worldwide office addresses and phone numbers.

Appendix B: Port Pinouts

includes 7530 G2 pinouts.

Appendix C: USB Setup Application

provides detailed instructions on USB application setup.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 3

Chapter 1: Introduction

Text Conventions

1.2 Text Conventions

Note: Notes highlight additional helpful information.

Important: These statements provide particularly important instructions

Warning: These statements provide critical information that may prevent

1.3 7530 G2 Features

• Rugged design:

• IP67 rating protects against dust and temporary water immersion.

• drop rating up to 2 meters (6.5 feet) onto concrete.

• Processor and memory:

• 520 MHz XScale PXA 270 processor

• On-board RAM: 128MB SDRAM

• On-board ROM: 64MB FLASH

• Operating System:

• Windows CE 5.0

or additional information that is critical to the operation of
the equipment.

physical injury, equipment damage or data loss.

• Programming environment:

• HTML, XML

• Mobile Devices SDK

• CE.NET SDK

• Java, Visual C++

• Standard protocol APIs - Windows sockets (WinCE)

• Wireless communications:

• IEEE 802.11g 54Mbps 2.4 GHz Compact Flash radio

• Narrow Band 403-512 MHz PC Card radio

• On-board Bluetooth radio 2.4 GHz (10m range)

4 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

• Application software:

• Internet Explorer 6 for CE

•Wordpad

• Active Sync

• Optimized for use with Open TekTerm V2.0

• ANSI

• TESS terminal emulations

• IBM 3270, IBM 5250, HP 2392

• User Interface:

•Display:

- 320 x 240 (1/4 VGA) graphic colour TFT

- 3.5" diagonal portrait mode

- 64K displayable colours

- Contrast control and automatic backlight

- Sunlight readable (for outdoor use)

• Keyboards:

- 2 formats available

- 37-key large button (10 F-keys)

- 63-key alpha (10 F-keys)

- Illuminated with EL backlight

- Ergonomic design with ambidextrous one-hand operation with
dual [ENTER] keys

- Dedicated function keys

- Hard-capped keys

• Touchscreen options:

- Passive stylus or finger operation

- Signature capture

- Integral stylus holder

- Ultra-rugged 5-wire technology

• Sound:

- Voice Features - speaker and mic

Chapter 1: Introduction

7530 G2 Features

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 5

Chapter 1: Introduction

7530 G2 Features

• Indicators and controls:

• Internal speaker & beeper with volume control, internal mic

• Multicolour LEDs for radio transmit/receive, scanning, battery status,
user applications

• Internal Bar Code Scanners:

• 1D & 2D scan engines:

•Standard

• Long Range

• Advanced Long Range

• Enhanced Standard Range (Fuzzy Logic)

• PDF417 Raster Laser

• 1D Auto-Ranging

• 1D Standard Imager

• 2D Standard Imager

• RFID Applications (future release):

• Tethered reader/writer

• Multi-protocol support @ 900MHz/ 868 MHz (future)

• Internal expansion slots:

• One SD I/O (MultiMediaCard) slot

• One Type II Compact Flash slot

• One Type III Extended PC Card slot

• External ports:

• Tether port with:

-RS232 serial

- decoded/undecoded scanner, printer

-USB host

• Docking Station Port with:

-RS232 serial

- USB device support

- USB host support

- Power in/out

6 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

About The 7530 G2 Hand-Held Computer

• Freezer option:

• Heated scan window to reduce fogging

• Internal heat control optimizes low temperature performance and
battery life

• Power management:

• Up to 12 hr usage Li-Ion standard battery (reduced in
freezer applications)

• Optional High capacity battery (up to 17 hrs) (reduced in
freezer applications)

• Quick swap packs

• Advanced Smart Battery with gas gauge

• Built-in fast charger (2hrs)

• System backup during battery swap (15 min)

• 1 week real-time clock backup

• Network Management And Security:

• SNMP MIB 2 support

• Remote software download

• Remote WLAN management

• Enhanced security for 802.11

Chapter 1: Introduction

1.4 About The 7530 G2 Hand-Held Computer

The 7530 G2 is a rugged, Windows CE based hand-held computer. It is designed to
withstand the harshest mobile environments including cold environments like
freezers, ports and yards. It supports wide area mobile applications and is built using
industry standards-based software and hardware components, making it easy to
integrate existing or future site infrastructures.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 7

Chapter 1: Introduction

The 7530 G2 Hand-Held Computer

1.4.1 The 7530 G2 Hand-Held Computer

Figure 1.1 7530 G2 With 63-Key Keyboard

8 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Figure 1.2 7530 G2 Ports

1.4.2 Regulatory Labels

MODEL No: 7530 G2 Handheld

Tether Port

LASER RADIATION

DO NOT STARE INTO BEAM

CLASS 2 LASER PRODUCT (IEC)

CLASS II LASER PRODUCT (CDRH)

610-680nm LASER (LED)DIODE

Max.Output:1.4mW (SCAN ) <1mW(AIM)

IEC 60825-1:1993+A1:1997+A2:2001

Chapter 1: Introduction

Regulatory Labels

Docking Port

This label is affixed below the scanner window.

Figure 1.3 Laser Warning Label

MODEL No: 7530 G2 Handheld

This product contains an imager

that uses an LED light source

to illuminate barcodes

LED RADIATION

CLASS 1 LED PRODUCT (IEC)

CLASS I LED PRODUCT (CDRH)

IEC 60825-1:1993+A1:1997+A2:2001

Figure 1.4 LED Radiation Notice Label

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 9

1080259E

1080258A

BASIC CHECKOUT 2

2.1 Preparing The 7530 G2 For Operation...................13

2.1.1 Equipment You Need To Get Started.................13

2.1.2 Charging The Battery.........................13

2.1.3 Installing The Battery.........................14

2.1.4 Switching On The Hand-Held ....................14

2.1.5 Attaching Carrying Accessories...................15

2.1.5.1 Attaching The Handstrap ..................15

2.1.5.2 Attaching The Pistol Grip..................16

2.2 Calibrating The Touchscreen........................16

2.3 Configuring An IEEE 802.11 Radio In The Unit . . . . . . . . . . . . . . 17

2.3.1 Assigning An IP Address.......................23

2.3.2 Name Servers Tab ..........................24

2.3.3 Advanced Features..........................25

2.3.3.1 Rearranging Preferred Networks . . . . . . . . . . . . . . 25

2.3.3.2 Deleting A Preferred Network . . . . . . . . . . . . . . . . 25

2.3.3.3 Changing Network Properties . . . . . . . . . . . . . . . . 26

2.4 Checking The Scanner...........................26

2.5 Using Microsoft ActiveSync........................26

2.6 Resetting The Hand-Held..........................27

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 11

Chapter 2: Basic Checkout

Preparing The 7530 G2 For Operation

2.1 Preparing The 7530 G2 For Operation

Typically, 7530 G2 hand-helds are configured at the factory and arrive ready for use.
Although these hand-helds are equipped with an internal Compact Flash and SD I/O
slot, these slots are not intended for user modification. If a device needs to be
changed or added in these slots, contact qualified Psion Teklogix personnel. Refer to
Appendix A: Support Services And Worldwide Offices for service information.

2.1.1 Equipment You Need To Get Started

You’ll need:

• A compatible battery charger, docking station or portable docking module
(PDM) with power supply.

• An operating wireless network (if you are not operating the equipment in
batch mode).

• A #2 Phillips head screwdriver (if you need to attach a carrying strap or
pistol grip handle).

2.1.2 Charging The Battery

Important: The 7530 G2 uses a high capacity Lithium-Ion battery. It is criti-

cal that you review the battery safety guidelines in “Lithium-Ion
Battery Safety Precautions” on page XII before charging
the battery.

Batteries shipped from the factory are not charged. They must be fully charged prior
to use. Full capacity may not be reached until at least 5 full charge/discharge cycles
have been performed.

Batteries can be charged using a gang charger or the unit’s internal charger. When
using the internal charger, a suitable power source is required. All chargers and
docking stations are described in Chapter 6: Peripheral Devices & Accessories
beginning on page 213.

Note: The 7530 G2 Battery Properties dialog box may indicate an incorrect bat-

tery capacity until the new battery has been fully charged.

It may take several charge/discharge cycles for the battery capacity
gauge to register capacity with the full 95% accuracy.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 13

Chapter 2: Basic Checkout

Installing The Battery

2.1.3 Installing The Battery

• Slide the charged battery with the contoured plastic facing you into the unit.
Click the battery into place.

Keep in mind that if you are using a docking station, you can insert an uncharged
battery in the hand-held, dock the unit and switch it on. If you are using a PDM, you
can configure your unit without a battery, with a charged battery or with an
uncharged battery.

Important: Accidental removal and insertion of the battery during operation

may result in the 7530 G2 not booting up normally. Should this
occur, remove the battery and allow the internal backup power
supply to deplete – approximately 15 minutes. Unsaved data may
be lost.

2.1.4 Switching On The Hand-Held

To switch the unit on:

• Press and hold down the [ENTER/ON] key for at least one second.

• When all four LEDs flash yellow, release the [ENTER/ON] button.

A splash screen of the Psion Teklogix logo and the Windows CE logo appears.
When Windows CE has successfully loaded, the startup desktop is displayed.

Note: The screen may go blank for a few seconds after the splash screen loading

bar reaches the end. This is part of the normal Windows CE cold boot
process. The desktop is displayed after a few moments.

14 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 2: Basic Checkout

Attaching Carrying Accessories

2.1.5 Attaching Carrying Accessories

Psion Teklogix recommends that a carrying accessory – a handstrap, pistol grip or
shoulder strap – be installed on the 7530 G2 before use. If your hand-held is not
fitted with a handstrap or pistol grip, you can install either using the carrying
accessory kit supplied. You’ll need:

• A Phillips head screwdriver.

Important: Do not use adhesives such as Loctite to secure screws on carrying

accessories. These chemicals may damage the plastic casing.

2.1.5.1 Attaching The Handstrap

Two Phillips head screws are provided with the handstrap.

• Attach the strap to the two threaded inserts located at the back of the
7530 G2 near the top of the unit.

• Stretch the handstrap toward the base of the 7530 G2, and hook the bottom
of the handstrap into the slot near the base of the battery pack.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 15

Chapter 2: Basic Checkout

Attaching The Pistol Grip

2.1.5.2 Attaching The Pistol Grip

Note: A Phillips head screwdriver is required.

The pistol grip is attached to the back of the 7530 G2 using the four threaded inserts
in the upper part of the 7530 G2 casing. Four black #4-40 Phillips head screws are
provided with this accessory.

Note: Prior to installation, make sure the trigger mechanism is securely

snapped into the pistol grip body and that the trigger operates properly.

• Position the pistol grip so that it fits snugly over the back of the unit and
the inserts on the back of the hand-held are aligned with the holes in the
pistol grip.

• Using a Phillips screwdriver, securely fasten the pistol grip to the back of
the 7530 G2.

2.2 Calibrating The Touchscreen

Your 7530 G2 touchscreen will need to be calibrated. Refer to “Calibrating The
Touchscreen” on page 41 for details.

16 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 2: Basic Checkout

Configuring An IEEE 802.11 Radio In The Unit

2.3 Configuring An IEEE 802.11 Radio In The Unit

The most common 802.11 settings are configured as defaults. However, there are
some fields that must be completed, including the SSID of your access point and the
security methods implemented in the network (including access keys).

Important: If the 7530 G2 is equipped with a radio that has never been con-

figured, the radio settings dialog box opens automatically when
the unit is powered on. In this case, skip to Step 4 on page 19.

Note: In most situations, the configuration of your 802.11 radio will require

parameter setting and access keys from a network administrator.
Network administrators should review the detailed security information in

this section in order to effectively configure the 802.11 wireless network.

To configure the 802.11 radio:

1. Press on [BLUE][0] to display the Start Menu.

Tap on Settings>Network and Dial-up Connections.

If you’re using the keyboard, press [BLUE] [0] to display the Start
Menu. Use the [DOWN] arrow key to highlight Settings. Press the
[RIGHT] arrow key to display the sub-menu. Highlight Network, and
press [ENTER].

Figure 2.1 Network And Dial-Up Connections

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 17

Chapter 2: Basic Checkout

Configuring An IEEE 802.11 Radio In The Unit

2. Choose the radio icon to open the 802.11 Wireless LAN Settings
window – in the sample screen, this is labelled PTXCF8385P N1.

Figure 2.2 802.11 Wireless LAN Settings Window

3. Wireless Statistics Tab
When you choose the Wireless LAN icon, an 802.11 Wireless LAN Set-
tings window (PTXCF8385P N1 in the sample below) is displayed.

Figure 2.3 Wireless Statistics

This tab lists your radio statistics. Choosing the Zero button resets the
statistics of the last four items – Packets IN, Packets OUT, IN errors and
OUT errors.

• Display the next tab in this window – Wireless Information.

18 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 2: Basic Checkout

Configuring An IEEE 802.11 Radio In The Unit

4. Wireless Information Tab

The options under this tab display existing networks to which you can
connect, and it allows you to add a new network or modify the settings
for an existing network.

Note: Configure button – To change the settings in an existing network, high-

light the network you want to modify, and tap on the Configure button to
display the Wireless Properties dialog box.

Connect button – To force connection to a specific, existing network,
highlight the network to which you want your 7530 G2 to connect, and
tap on the Connect button.

Figure 2.4 Wireless Information Tab

This tab lists available networks – any access points that are broadcasting
an SSID, and it lists preferred networks – networks that you have config­ured. Since access points are generally secure, they will most likely not
be listed here. By default, 7530 G2 attempts to connect to preferred net­works. This behaviour can be changed by enabling Automatically connect
to non-preferred networks in the Advanced dialog box (page 25).

• To add a new configuration, tap on the Add New button. A blank Wire-
less Properties dialog box is displayed.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 19

Chapter 2: Basic Checkout

Configuring An IEEE 802.11 Radio In The Unit

5. Wireless Properties

Figure 2.5 Wireless Properties Dialog Box

Network name (SSID):

• Type the appropriate SSID (Service Set Identifier) in the Network name
(SSID) text box at the top of this dialog box.

The Network name field can contain a maximum of 32 characters. The
name assigned here is listed as a preferred network.

Important: Keep in mind that the 7530 G2 will only communicate with access

points that are configured with the same SSID.

Ad Hoc And Infrastructure:

If you are using an Infrastructure network – one in which 7530 G2s must
pass data through an access point – leave the checkbox next to This is an
ad hoc network blank.

If you are using an Ad Hoc network – a network in which 7530 G2s pass
data directly to other 7530 G2s without an access point – add a checkmark
in the checkbox next to This is an ad hoc network to enable Ad Hoc.

Encryption
WEP (Wired-Equivalent Privacy) encryption prevents others from acciden­tally accessing your network. If you are not using encryption, you can
choose Disabled from the dropdown encryption menu. Otherwise, leave
this field as is.

20 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 2: Basic Checkout

Configuring An IEEE 802.11 Radio In The Unit

Note: WEP cannot be disabled if you are using WPA or WPA-PSK authentication.

TKIP (Temporal Key Integrity Protocol) is an encryption protocol included

as part of the IEEE 802.11 standard for wireless LANs. Designed to
enhance WEP, TKIP uses the original WEP encryption but ‘wraps’ addi­tional code at the beginning and end to encapsulate and modify it, encrypt­ing each data packet with a unique encryption key.

Authentication

802.11 supports four subtypes of network authentication services: Open,
Shared, WPA, and WPA-PSK. Under Open authentication, any wireless

station can request authentication. The station that needs to authenticate
with another wireless station sends an authentication management frame
that contains the identity of the sending station. The receiving station then
sends back a frame that indicates whether it recognizes the identity of the
sending station.

Under Shared authentication, each wireless station is assumed to have
received a secret shared key over a secure channel that is independent from
the 802.11 wireless network communications channel.

Under WPA and WPA-PSK authentication, the use of 802.1x authentication
is required. For wireless networks without a Remote Authentication Dial-In
User Service (RADIUS) infrastructure, WPA supports the use of a pre­shared key. For wireless networks with a RADIUS infrastructure, Extensi­ble Authentication Protocol (EAP) and RADIUS is supported.

Network Key:

This text box is used to specify a 5 or 13 ASCII character sequence or an
equivalent 10 or 26 Hexadecimal digit sequence that matches the active
WEP key on the access point.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 21

Chapter 2: Basic Checkout

Configuring An IEEE 802.11 Radio In The Unit

• To assign a Network key, highlight The key is provided automatically,
and uncheck the checkbox to disable this option.

Disable this option to
access

Network Key &

Key Index fields.

Figure 2.6 Accessing Network Key And Key Index

Key Index:

This field is used to identify the WEP key.

• Enter a value from 1 to 4.

Enable 802.1x authentication:

802.1X is the IEEE standard that offers additional security for local area
networks. It provides authentication for user devices attached to an Ethernet
network, whether wired or wireless. A security protocol packet such as TLS
or MD5 encapsulated in an EAP is used in conjunction with the 802.1X
standard to authenticate users at the MAC layer. Available EAPs are listed
in the dropdown menu next to the EAP option.

• To activate 802.1X, highlight 802.1x authentication, and check

the checkbox.

EAP Type (Extensible Authentication Protocol):

This dropdown menu lists the EAP types available on your system. The
items in this dropdown menu will vary depending on your network setup.
Keep in mind also that some authentication protocols require that you select
a Certificate. By selecting the Properties button, you will be able to select a
Certificate. “Certificate Assignment” on page 113 provides a website that
outlines how to create certificates for your network.

22 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 2: Basic Checkout

Assigning An IP Address

6. Saving and exiting the radio setup.
Once you’ve completed the configuration, press [ENTER], or tap
on OK.

The connection you created will be listed in the Wireless Information tab as a
preferred network. The radio will search for the SSID and will compare the WEP
and authentication information you specified. If there is a match between your hand­held settings and the access point settings, the hand-held will communicate on the
network through the access point.

2.3.1 Assigning An IP Address

If your network is not using a DHCP server, you will need to assign an IP address.

•In the PTXCF8385P N1 Settings window, display the IP Information tab.

Figure 2.7 IP Information

Note: Tapping the Renew button forces the 7530 G2 to renew or find a new

IP address. This is useful if, for example, you are out of communication
range for a longer period of time and your 7530 G2 is dropped from
the network.

To define a static IP address:

• Tap on the Configure button.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 23

Chapter 2: Basic Checkout

Name Servers Tab

• Tap the stylus on the radio button next to Specify an IP address to select it.

• Type an IP, Subnet Mask and Default Gateway address in the appropriate
fields. Press [ENTER] to save your information.

2.3.2 Name Servers Tab

Note: If DHCP is enabled, name server addresses are assigned automatically.

Figure 2.8 Defining An IP Address

•In the PTXCF8385P N1 Settings window, display the IP Information tab.

•In the IP Information tab, tap on the Configure button.

• Tap on the Name Servers tab to display it.

Figure 2.9 Name Servers Tab

The DNS and WINS fields in the Name Servers tab allow you to specify additional
WINS and DNS resolvers. The format for these fields is ###.###.###.###.

24 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 2: Basic Checkout

2.3.3 Advanced Features

To display the Advanced Wireless Settings dialog box:

• Tap on the Advanced button in the Wireless Information tab. (see
Figure 2.4 on page 19).

This window lists the available preferred networks.

Figure 2.10 Advanced Settings

Advanced Features

2.3.3.1 Rearranging Preferred Networks

The 7530 G2 attempts to connect with the networks listed in this dialog box in
sequence, beginning at the top of the list. If you need to rearrange this list of
networks – move networks up and down in the list:

• Tap in the Networks List, and highlight the network that you want to move
up or down in the list.

• To move the highlighted item in the list upward or downward, tap on the Up
or Down button.

2.3.3.2 Deleting A Preferred Network

To delete a network from this list:

•In the networks list, highlight the network that you want to remove.

• Tap on the Delete button.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 25

Chapter 2: Basic Checkout

Changing Network Properties

2.3.3.3 Changing Network Properties

To change the properties of an existing preferred network:

• Highlight the network that you want to modify.

• Tap on the Properties button.

• Make any necessary changes in the Wireless Properties dialog box, and
press [ENTER] to save the changes.

2.4 Checking The Scanner

Note: Details about operating and troubleshooting scanners, Imagers and

RFID readers are provided under the heading “Internal Scanners” on
page 48.

If your 7530 G2 is equipped with an internal scanner, you can test it to ensure that it is
operating properly. Point the scanner window at a bar code that your scanner was
designed to decode—for example, a 1D UPC bar code or 2D bar code. Press the
SCAN button or pistol trigger, and check for a valid decode on the hand-held’s screen.

Performance is improved if you disable all unneeded bar codes in the Bar Codes
screen. Review “Scanner Settings” on page 143 for details about
bar codes.

2.5 Using Microsoft ActiveSync

ActiveSync – Microsoft PC connectivity software – can be used to connect the
hand-held to PCs running this software.

Note: Keep in mind that you’ll need to run the USB Setup program to

configure your workstation before connecting the 7530 G2 via USB.
For information about the USB application, refer to Appendix C: USB
Setup Application.

By connecting the 7530 G2 to a PC with a cable and running ActiveSync on the PC,
you can:

• View 7530 G2 files from Windows Explorer.

• Drag and drop files between the 7530 G2 and the PC in the same way that
you would between PC drives.

• Back up 7530 G2 files to the PC, then restore them from the PC to the hand­held again, if needed, and so on.

To install ActiveSync, follow the step-by-step instructions provided with the
program’s setup wizard. Refer to the following website for details:

http://www.microsoft.com/windowsmobile/resources/downloads/pocketpc/activesync35.mspx

26 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 2: Basic Checkout

Resetting The Hand-Held

2.6 Resetting The Hand-Held

Warm Reset

To execute a warm reset:

• Press and hold down the [BLUE] key and the [ENTER/ON] key simulta­neously for a minimum of six seconds.

A warm reset closes open applications; any unsaved data are lost. Installed
programs and saved data are preserved.

Note: You do not need to reset your 7530 G2 after configuring the radio.

Cold Reset

There are two options when executing a cold reset: reset to BootLoader or reset
directly to Windows CE operating system.

To execute a cold reset and access the BooSt menu:

• Press and hold down the left [BLUE] key, the [ENTER] key and the
[SCAN] key simultaneously for a minimum of six seconds.

After a cold reset, the BooSt menu appears.

• If you want to load the Windows CE operating system, type 1.

• If you want a clean start, press ! (that is, the [SHIFT] key and 1). All data
and settings are lost. Files and data stored in flash are preserved.

Once the OS loads, any executables and cab files in the startup folders are run. The
cab files are deleted by the cab file installer unless they are marked read-only.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 27

GETTING TO KNOW YOUR 7530 G23

3.1 Features Of The 7530 G2..........................31

3.2 The Battery.................................32

3.2.1 Battery Safety.............................32

3.2.2 Removing And Installing The Battery Pack . . . . . . . . . . . . . 32

3.2.3 Battery Chargers...........................32

3.3 The Keyboard................................33

3.3.1 Modifier Keys ............................34

3.3.1.1 Activating Modifier Keys . . . . . . . . . . . . . . . . . . 34

3.3.1.2 Locking Modifier Keys...................34

3.3.2 The Keys...............................34

3.3.3 Function And Macro Keys......................36

3.3.3.1 Function Keys........................36

3.3.3.2 Macro Keys.........................37

3.3.4 Alphanumeric Keyboard – 63-Key . . . . . . . . . . . . . . . . . . 38

3.3.5 Numeric Keyboard – 37-Key.....................38

3.3.6 The Keypad Backlight........................40

3.4 The Display.................................41

3.4.1 Adjusting The Display Backlight...................41

3.4.2 Adjusting The Contrast........................41

3.4.3 Calibrating The Touchscreen.....................41

3.5 7530 G2 Indicators.............................43

3.5.1 LEDs.................................43

3.5.1.1 Charge LED.........................43

3.5.1.2 Radio Traffic LED......................44

3.5.1.3 Scan LED ..........................44

3.5.1.4 User Application LED....................44

3.5.2 Onscreen Indicators..........................45

3.5.3 Audio Indicators...........................47

3.5.3.1 Adjusting The Beeper Volume................48

3.6 Internal Scanners..............................48

3.6.1 Scanning Techniques.........................49

3.6.2 Scan LED Indicators.........................50

3.6.3 Troubleshooting............................50

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 29

Chapter 3: Getting To Know Your 7530 G2

3.6.4 Operating One Dimensional (1D) Internal Laser Scanners . . . . . . 50

3.6.5 Operating Internal PDF Laser Scanners ...............51

3.6.6 Operating Internal Two Dimensional (2D) Imager Scanners . . . . . 51

3.7 Connecting & Disconnecting Tethered Peripherals . . . . . . . . . . . . . 52

3.8 Monitoring The Battery And Maximizing Run Time . . . . . . . . . . . . 53

3.8.1 Storing Batteries............................54

3.9 Monitoring The Network Connection....................55

3.10 Uploading Data In A Docking Station...................55

3.11 General Maintenance............................56

3.11.1 Caring For The Touchscreen.....................56

3.11.2 Cleaning The 7530 G2........................56

30 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

3.1 Features Of The 7530 G2

Stylus

(Pointing Tool)

7530 G2 Screen

Ambient Light

Sensor

Beeper Port

Chapter 3: Getting To Know Your 7530 G2

Features Of The 7530 G2

Sound Port

Microphone

Figure 3.1 Front Of 7530 G2

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 31

Chapter 3: Getting To Know Your 7530 G2

The Battery

3.2 The Battery

The hand-held operates with a Lithium-Ion battery pack. Preparing the unit for
operation requires that a battery pack be charged and installed in the 7530 G2.

3.2.1 Battery Safety

Important: Before attempting to install, use or charge the battery pack, it is

critical
in the section entitled “Lithium-Ion Battery Safety Precautions”
on page XII.

3.2.2 Removing And Installing The Battery Pack

Note: TURN OFF THE HAND-HELD BEFORE REMOVING THE BATTERY

PACK. If you do not turn the hand-held off before removing the battery, it
may be necessary to reboot the unit. Any active sessions may be lost.

Removing The Battery Pack

• If your unit is equipped with a handstrap, unhook it from the base of
the battery.

• Press down the release tab at the top of the battery, and slide the battery out.

that you review and follow the important safety guidelines

Installing The Battery Pack

To install the battery pack:

• Slide the battery pack with the contoured plastic facing you into the
7530 G2. Click the battery into place.

• If your computer is equipped with a handstrap, insert the hook at the end of
the handstrap into the slot at the base of the battery.

3.2.3 Battery Chargers

Important: FOR DETAILED INFORMATION about chargers and docking

stations, refer to Chapter 6: Peripheral Devices & Accessories
beginning on page 213. For battery safety, refer to “Lithium-Ion
Battery Safety Precautions” on page XII.

All batteries must be charged before use. The battery can be charged with a variety
of chargers. These include:

32 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 3: Getting To Know Your 7530 G2

The Keyboard

• 6-Unit Gang Charger (Model #HU3006) – charges up to six Lithium-Ion
batteries at one time.

• Portable Docking Module (Model #HU4001 or HU1005 and HU3220) –
charges the 7530 G2 battery (with the battery installed in the unit).

• Combo Charger (Model #HU3002) – a desktop charger that charges the
internal battery along with a spare battery pack.

• Combo Docking Station (Model #HU4002) – operates as both a charger
and a docking station. Operating as a charger, both the battery installed in
the computer and a spare battery can be charged simultaneously.

• Quad Docking Station (Model #HU4004) – can charge the battery of up to
four hand-helds inserted in the docking station while transferring data
through an Ethernet connection.

• Powered Cradle (Model # CV1010 and CV1030) – can charge the 7530 G2
with the battery installed in the hand-held.

It can take from 1.5 to 4 hours to charge a battery. The unit’s intelligent charging
system protects the battery from over-charging by terminating the charge process
when the battery is at maximum capacity.

Note: Refer to “Monitoring The Battery And Maximizing Run Time” on page 53

for additional information about the battery.

Important: To avoid damaging the battery, chargers will not begin the charge

process until the battery temperature is between 0° C (32° F) and
39° C (102° F). If the battery is too hot or cold, the battery status
LED flashes yellow and the charge is suspended. Refer to
Table 3.1, “Charge LEDs” on page 44 for details.

3.3 The Keyboard

The 7530 G2 offers two types of keyboard layouts – a 63-key and a 37-key
keyboard. Most of the keys on these keyboards operate much like a desktop
computer. Where a key or key function is not consistent with the PC keyboard, the
differences are noted.

The [BLUE] and [ORANGE] modifier keys provide access to additional keys and
system functions. These functions are colour coded in orange and blue print above
the keyboard keys.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 33

Chapter 3: Getting To Know Your 7530 G2

Modifier Keys

3.3.1 Modifier Keys

The [SHIFT], [CTRL], [ALT], [BLUE] and [ORANGE] keys are modifier keys.
Pressing a modifier key changes the function of the next key pressed. For example,
on a 63-key keyboard, a square bracket is printed in orange print above the [4] key.
Pressing the [ORANGE] key followed by the [4] key displays a square bracket
rather than the number 4.

The [SHIFT], [CTRL] and [ALT] keys operate much like a desktop keyboard except
that they are not chorded (two keys held down simultaneously). The modifier key
must be pressed first followed by the key whose function you want modified.

3.3.1.1 Activating Modifier Keys

When a modifier key is not locked ‘on’, it is displayed in lowercase letters in the
taskbar at the bottom of the hand-held screen. For example, if the [CTRL] key is
pressed,
When the next key is pressed, the modifier key becomes inactive and is cleared from
the taskbar.

3.3.1.2 Locking Modifier Keys

Note: The locking function of the modifier keys can be set up so that pressing

When a modifier key is ‘locked’ on, it is displayed in uppercase letters in the
taskbar. For example, if the [BLUE] key is locked on – it is displayed as BLUE KEY in
the taskbar at the bottom of the screen.

The locked modifier key will remain active until it is pressed again to unlock or turn
it off. Once a modifier key is unlocked, the uppercase representation in the taskbar
is cleared.

ctrl key is displayed at the bottom of the unit screen in lowercase letters.

one of these keys once will lock the key ‘on’. They can also be set up so
that they must be pressed twice to be locked ‘on’. Refer to “Keyboard One
Shot Modes” on page 93 for details.

3.3.2 The Keys

The [SHIFT] Key

The [SHIFT] key is used to display uppercase alpha characters and provide access to
the symbols above the numeric keys.

34 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 3: Getting To Know Your 7530 G2

The Keys

The Arrow Keys

The Arrow keys move the cursor around the screen in the direction of the arrow –
up, down, left and right. The cursor is the flashing box or underline character that
indicates where the next character you type will appear.

The [BKSP/DEL] Key

The [BKSP] key (sometimes referred to as destructive backspace) moves the cursor
one character to the left, erasing the incorrectly entered key stroke.

The [DEL] key ([BLUE] [BKSP]) erases the character at the cursor position.

The [CTRL] And [ALT] Key

The [CTRL] and [ALT] keys modify the function of the next key pressed and are
application dependent.

The [TAB] Key

Typically, the [TAB] key moves the cursor to the next field to the right or
downward.

The [ESC] Key

Generally, this key is used as a keyboard shortcut to close the current menu, dialog
box or activity and return to the previous one.

The [SPACE] Key

Pressing this key inserts a blank space between characters. In a Windows dialog
box, pressing the [SPACE] key enables or disables a checkbox.

The [SCAN] Key

Pressing the [SCAN] key – the yellow key with the star-burst scan symbol on it –
activates the scanner beam while pressed. For units that do not have internal
scanners, this key can be remapped for another use.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 35

Chapter 3: Getting To Know Your 7530 G2

Function And Macro Keys

3.3.3 Function And Macro Keys

In addition to the standard keyboard functions (see “The Keyboard” on page 33), the
7530 G2 supports function keys and macro keys.

3.3.3.1 Function Keys

63-Key Keyboard Function Keys

The 63-key keyboard is equipped with thirty function keys. Function keys [F1] to
[F10] are located in the top two rows of the keyboard and are directly accessible – a
key combination is not required. Function keys [F11] to [F30] are colour coded in
blue print above the alpha keys and are accessed using a key combination – [BLUE]
followed by the appropriate alpha key.

To access function keys [F11] to [F30]:

• Press the [BLUE] key followed by the alpha key to which the
function key you want to use is mapped. For example:
To access function key [F11], press [BLUE] [C].
To access function key [F12], press [BLUE] [D], and so on.

37-Key Keyboard Function Keys

The 37-key keyboard is equipped with twenty function keys. Function keys [F1] to
[F4] are located across the top of the keyboard and function keys [F5] to [F10] are
located at the bottom of the keyboard.

Additional function keys – [F11] to [F20] – are colour coded in orange print above
function keys [F1] to [F10].

To access function keys [F11] to [F20]:

• Press the [ORANGE] key followed by the appropriate function key.
For example:
To access function key [F11], press the [ORANGE] key followed
by [F1].
To access function key [F12], press [ORANGE] followed by [F2],
and so on.

36 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 3: Getting To Know Your 7530 G2

Macro Keys

3.3.3.2 Macro Keys

Important: Refer to “Keyboard Macro Keys” on page 94 for details about

creating macros.

7530 G2 hand-helds are equipped with a series of macro keys that can be
programmed to replace frequently used keystrokes, along with the function of
executable keys like the [ENTER] key, the [BKSP] key, any function key and arrow
key, and so on.

63-Key Keyboard Macro Keys

63-key (alphanumeric) keyboards have twelve macro keys – [M1] to [M12]. These
keys are colour coded in orange print above alpha keys [O] to [Z].

To access a macro key:

• Press the [ORANGE] key followed by the appropriate alpha key from
O to Z. For example:
To access macro key [M1], press [ORANGE] [O].
To access macro key [M2], press [ORANGE] [P], and so on.

37-Key Keyboard Macro Keys

37- key (numeric) keyboards are equipped with six macro keys – [M1] to [M6].
Macro keys [M1] to [M2] are directly accessible in the bottom row of the keyboard
– a key combination is not required.

Macro keys [M3] and [M4] are colour coded in orange print above macro keys [M1]
and [M2].

• To access [M3], press the [ORANGE] key followed by [M1]

• To access [M4], press [ORANGE] [M2].

Macro keys [M5] to [M6] are colour coded in blue print above macro keys [M1]
and [M2].

• To access [M5], press the [BLUE] key followed by [M1].

• To access [M6], press [BLUE] [M2].

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 37

Chapter 3: Getting To Know Your 7530 G2

Alphanumeric Keyboard – 63-Key

3.3.4 Alphanumeric Keyboard – 63-Key

On 63-key, alphanumeric keyboards, all alphabetic and numeric keys are directly
accessible from the keyboard; a key combination is not required.

Function keys [F1] through [F24] can be used with the CE operating system or
another application. The additional function keys, [F25] through [F30] along with
the macro keys, are not used as part of the Windows CE operating system.

All function keys and macro keys can be custom defined for each application. The
TekTerm application utilizes these keys (for detailed information, see the Tek Ter m
Software User Manual, PN 8000073). Refer to “Function And Macro Keys” on
page 36 for details about accessing function keys [F25] to [F30].

3.3.5 Numeric Keyboard – 37-Key

On 37-key 7530 G2s, all alpha characters are printed on the unit plastic in orange
typeface above the numeric keys. To access an alpha character, you must first press
the [ORANGE] key and then press the numeric key above which the alpha character
you want to type is printed.

Because the alpha keys on these keyboards are laid out much like the letters on a
telephone – generally in groups of three letters per numeric key – you need to take a
few extra steps to access the alphabetic characters. The examples in this section help
illustrate how to access alpha characters.

Choosing A Single Alpha Character

Note: As you press alpha keys, each is displayed in the left-hand corner of the

taskbar to make it easier to determine which letter is currently active.

Alpha key

representation.

38 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 3: Getting To Know Your 7530 G2

Numeric Keyboard – 37-Key

The examples below illustrate how to access A, B and C, all of which are printed in
orange characters above the numeric key, [2].

To choose the letter ‘a’:

• Press the [ORANGE] key, and press the numeric key [2].

To choose the letter ‘b’:

• Lock the [ORANGE] key on, and press [2] twice.

• Press the [ORANGE] key again to unlock it.

To choose the letter ‘c’:

• Lock the [ORANGE] key on.

• Press [2] three times.

• Press the [ORANGE] key again to unlock it.

Creating Uppercase Letters

To display a capital letter:

• Press the [ORANGE] key and then the [SHIFT] key before typing the
alpha character.

Choosing More Than One Alpha Character From The Same Key

If you need to choose more than one alpha character from a single key, you’ll need
to press the ‘Accept’ key between alpha selections. The ‘Accept’ key is presented as
an arrow [⇒] symbol above the [0] (zero) key. Pressing this key signals the 7530 G2
to display the alpha character you’ve chosen and await the next selection from the
same key.

Note: Remember that as you choose alpha keys, each is displayed in the

left-hand corner of the taskbar to make it easier to determine which letter
is currently chosen.

For example, suppose you want to type the letters ‘a’, ‘b’ and ‘c’. These letters are
all accessible from the numeric key, [2].

To type the letter ‘a’:

• Lock the [ORANGE] key ‘on’, and then press the numeric key, [2].

• Press the ‘Accept’ key [⇒] (zero key) to indicate that the letter ‘a’ should
be accepted and that another letter from the same key will be chosen.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 39

Chapter 3: Getting To Know Your 7530 G2

The Keypad Backlight

To type the letter ‘b’:

• Press the [2] key twice.

•Press [⇒] to accept the letter ‘b’.

To type the letter ‘c’:

• Press the [2] key three times.

When you have completed your alpha selections from this key, you can do one of the
following:

• If you want to choose additional alpha characters from another key(s),
leave the [ORANGE] key locked ‘on’, and press the next numeric key that
supports the alpha character you require, or

• If you do not want to choose any additional alpha characters, unlock the
[ORANGE] key, and end alpha selection.

Choosing Multiple Alpha Characters From A Range Of Keys

If you plan on choosing alpha characters from a number of different keys, you are
not required to press the ‘Accept’ [⇒] key after each alpha selection. The [⇒] key
is only required when you are choosing more than one alpha character from the
same key – e.g., ‘a’, ‘b’ and ‘c’ from the [2] key.

Suppose you want to type the letters ‘a’, ‘d’ and ‘g’. These alpha characters are
accessed from the numeric keys [2], [3] and [4].

• With the [ORANGE] key locked ‘on’, press [2] to type the letter ‘a’.

• Press [3] to type ‘d’, and press [4] to type the letter ‘g’.

• To end alpha selection, unlock the [ORANGE] key.

3.3.6 The Keypad Backlight

Note: This option may be restricted to supervisory use only.

The intensity of the keypad backlight and the conditions under which this
backlight is activated can be tailored in the Keyboard Properties dialog box in
the Control Panel.

Note: Refer to “Keyboard Backlight” on page 92 for details about this option.

40 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 3: Getting To Know Your 7530 G2

The Display

3.4 The Display

7530 G2s are equipped with display backlighting to improve character visibility in
low light conditions. The backlight switches on when a key is pressed and the
ambient light is below the set threshold. A light sensor on the front of the hand-held
determines the ambient light level. On some displays, the contrast can also be
adjusted to further improve character visibility.

3.4.1 Adjusting The Display Backlight

The behaviour of the display backlight can be specified in the Display Properties
dialog box in the Control Panel.

Note: Refer to “Display Backlight” on page 88 for details about the Display

Properties dialog box.

3.4.2 Adjusting The Contrast

Note: In addition to the manual adjustments described in this section, the dis-

play contrast can also be adjusted using the Control Panel. Refer to “Dis-

play Contrast” on page 87 for details about this dialog box.

The display contrast can be adjusted from the unit keyboard using the [BLUE] key
and function keys [F1] and [F2]. Pressing [F1] darkens the display, and
pressing [F2] lightens the display. Keep in mind that adjusting the contrast on a
colour display is much less pronounced than on a monochrome display.

To adjust the display contrast:

• Lock the [BLUE] key on, and then press [F1] to darken the display or [F2]
to lighten the display.

• Once you’ve successfully adjusted the display contrast, remember to press
the [BLUE] key again to unlock or turn it ‘off’.

Note: Contrast settings are optimized for the maximum readability. However, if

the display jitters or flickers, consider adjusting the contrast at power up.

3.4.3 Calibrating The Touchscreen

If your 7530 G2 touchscreen has never been calibrated, or if you find that the stylus
pointer is not accurate when you tap on an item, use the Stylus Properties dialog
box in the Control Panel to recalibrate the screen.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 41

Chapter 3: Getting To Know Your 7530 G2

Calibrating The Touchscreen

•In the Control Panel, tap on the Stylus icon to display the Stylus
Properties window.

• Select the Calibration tab, and then choose the Recalibrate button.

Figure 3.2 Stylus Icon

• Follow the directions on the calibration screen to calibrate the screen.

42 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 3: Getting To Know Your 7530 G2

7530 G2 Indicators

3.5 7530 G2 Indicators

7530 G2s use LEDs (Light Emitting Diode), onscreen messages and audio tones as
indicators.

3.5.1 LEDs

Hand-helds are equipped with four tri-coloured LEDs. This section outlines what
these LEDs indicate.

Important: If an LED is illuminated in red, the operator should be cautious

as this generally indicates an abnormal operating condition or
active laser emission.

Radio Traffic LED

Scanner LED

User Application LED

Charge LED

Figure 3.3 Keyboard LEDs

3.5.1.1 Charge LED

The lower-right LED is reserved for internal charger/power status. This indicator is
active even when the hand-held is inserted in a docking station (and in suspend
mode) so that the charge status of the battery can be detected easily.

Function Charge LED Behaviour

External power not available. LED off.
Fully charged to within 95% of charge

capacity.
Quick charge successfully completed to

within 75% of charge capacity.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 43

LED displays solid green colour.

LED flashes slow green.

Chapter 3: Getting To Know Your 7530 G2

Radio Traffic LED

Function Charge LED Behaviour

Charge in progress. LED displays solid yellow colour.
Cell temperature out of range for charge. LED flashes yellow.
Unable to charge battery. LED displays solid red colour.
Charge circuit failure.* LED flashes fast red.*

* If the charge fails, refer to the charger troubleshooting sections in ‘Chapter 6:

Peripheral Devices & Accessories’ beginning on page 213 for helpful details.

3.5.1.2 Radio Traffic LED

The upper-left LED on your unit flashes either yellow or green to indicate when the
radio transmits and receives data.

Note: Keep in mind that while the standard 802.11 radio supports the trans-

mit/receive LED, not all radios support this function.

Function Radio Traffic LED Behaviour

Radio Transmit LED flashes yellow.
Radio Receive LED flashes green.

Table 3.1 Charge LEDs

Table 3.2 Transmit and Receive LEDs

3.5.1.3 Scan LED

Successful scans are indicated in two ways – with a scan LED and with an
audio tone.

Function Scan LED Behaviour

Scan in progress LED displays solid red during scan.

Successful scan

Unsuccessful scan LED flashes red.

LED displays solid green after decode.
Off when scan ended.

Table 3.3 Scan LED

3.5.1.4 User Application LED

This indicator is available for user-loaded custom Windows CE applications. Your
supervisor can describe how this LED behaves with your application. Neither
Windows CE nor Open Tekterm V2.0 use this LED.

44 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 3: Getting To Know Your 7530 G2

Onscreen Indicators

3.5.2 Onscreen Indicators

The taskbar at the bottom of the screen displays a variety of system status indicators.

Figure 3.4 Taskbar

The taskbar changes dynamically, and only those icons that are applicable are
displayed. For example, if a radio is not installed in your 7530 G2, the radio signal
icon is not displayed in the taskbar.

Windows® Start Button

If you have a touchscreen, you can display the Start Menu by tapping on the Windows
Start button in the taskbar.

Modifier Key Indicators

[SHIFT], [CTRL], [ALT], [BLUE] and [ORANGE] are modifier keys that when
pressed, are displayed in the taskbar to indicate that they are active. If a modifier key
is locked ‘on’, it is displayed in uppercase characters. For example, if the [BLUE]
key is locked on, it is displayed as
remains active until it is pressed again to unlock or turn it off.

If a modifier key has been pressed but is not locked on, it is displayed in the taskbar
in lowercase characters – for example,
key is pressed at which point, the modifier key is turned off.

Note: The locking function of the modifier keys can be set up so that pressing

one of these keys once will lock the key ‘on’. They can also be set up so
that they must be pressed twice to be locked ‘on’. Refer to “Keyboard One
Shot Modes” on page 93 for details.

BLUE KEY in the taskbar. A locked modifier key

blue key. It will remain active only until the next

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 45

Chapter 3: Getting To Know Your 7530 G2

Onscreen Indicators

Battery Gauge

The battery shaped icon displayed in the taskbar provides a visual indication of the
remaining battery power. The icon acts as a meter that is either full, at three-quarter
level, half, quarter level or empty.

When the battery level is low – approximately 15 minutes from empty – a warning
window pops up. When the battery power is completely depleted, a final warning
window indicates that the 7530 G2 will be powered down.

If the 7530 G2 is using external AC power, an AC icon is displayed in the taskbar.

75%

50% 25% Empty

AC ConnectionFull

Battery Charge

The battery charge icon is displayed in the taskbar when the hand-held battery is
being charged.

802.11 Radio Signal Quality

Increasing radio signal quality is represented by longer, filled bars within this icon.

Good No Radio

Reception

Weak

Reception Link

Narrow Band Radio Signal Quality

Increasing radio signal quality is represented by vertical bars within this icon.

Good No Radio

Reception

Weak

Reception Link

46 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 3: Getting To Know Your 7530 G2

Audio Indicators

Tethered Devices

When a peripheral is attached to the tether port and activated, an associated icon
appears in the taskbar.

Scanner RFID Serial DeviceUSB Device

Docking Device

When a hand-held is inserted in a docking station, charger or cradle, an associated
icon appears in the taskbar.

Gang Charger, Combo Charger &

Combo Docking Station

Quad Docking Station Power Cradle Portable Docking

Module (PDM)

Bluetooth Radio

This icon represents the Bluetooth radio installed in your unit.

Security Level

Security levels can be set to limit user access. In addition, applications can be
restricted to prevent inadvertent changes.

3.5.3 Audio Indicators

The beeper provides a variety of sounds and can be configured to emit a sound when
a key is pressed, a keyboard character is rejected, scan input is accepted or rejected,
an operator’s entry does not match in a match field or the battery is low. The volume
function keys are located in the top row of the keyboard. The increase volume key is
labelled with a plus symbol and the decrease volume function key is labelled
with a minus symbol .

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 47

Chapter 3: Getting To Know Your 7530 G2

Adjusting The Beeper Volume

3.5.3.1 Adjusting The Beeper Volume

On 63-key keyboards, the volume function keys are accessed by pressing [BLUE]
[F5] and [F6].

On 37-key keyboards, the volume function keys are accessed by pressing [BLUE]
[F3] and [F4].

To adjust the beeper volume:

• Lock the [BLUE] key ‘on’ and then, press the increase volume function key

or the decrease volume function key until the volume meets

your requirements.

• Remember to unlock the [BLUE] key when you’ve completed the volume
adjustment.

3.6 Internal Scanners

Important: For detailed scanner specifications and decode zone tables, refer

to “Internal Scanner Specifications” beginning on page 240.

7530 G2s support a wide range of scanner options to address a variety of user applica­tion requirements. The scanner installed in your unit can be configured using the

Scanner Settings dialog box in the Control Panel (see page 143) and the Manage
Triggers application (see page page 109). External, non-decoded scanners are also

configured through the Control Panel.

However, external decoded scanners must be configured by scanning special configura­tion bar codes. In these cases, the scanner manufacturer provides programming
manuals for configuration purposes.

• For Symbol decoded scanners, refer to the LS3408 programming guide.

• For PowerScan (PSC) decoded scanners, refer to the Powerscan Programing
Guide (PSC).

Scanner types include:

• Advanced Long Range: reads very large 1D bar codes (60 mil+) at very
long distances (up to 14m).

• Long Range: reads large 1D bar codes (55 mil) at long distances (up to 3m).

• High Performance: reads1D linear bar codes (5 - 55 mil) at medium dis­tances (up to 1m).

• Extended Range: reads regular 1D bar codes (5 - 55mil) at short to medium
distances (1m), as well as large 1D bar codes (e.g. 55 mil) at long distances.

48 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 3: Getting To Know Your 7530 G2

Scanning Techniques

• RFID: The RD7950 UHF RFID Reader is an EPC-compliant RFID reader
which can be integrated with laser bar code scanning or imaging (for
future release).

• Fuzzy Logic: reads damaged or low contrast regular 1D bar codes
(5 - 55mil) at medium distances (up to 1m).

• PDF Raster Laser: reads 2D PDF bar codes or regular 1D bar codes at short
to medium distances.

• 2D Imager: reads regular 1D and all 2D bar codes at short to medium distances.

• 1D Imager: reads regular 1D and PDF417 bar codes at short to
medium distances.

It is critical that you review the warnings listed under “Warning to Users” beginning
on page XI (at the beginning of this manual) before using any of the scanners
described in this chapter. “Scanning Techniques” outlines the mechanics of a
successful scan. In addition, review “Scan LED Indicators” on page 50 to better
understand how to interpret whether or not a bar code has been successfully scanned.
Finally, “Troubleshooting” on page 50 provides some helpful suggestions should the
scan fail.

3.6.1 Scanning Techniques

Note: The scanning techniques described here apply to internal and

external scanners.

• Hold the scanner at an angle. Do not hold it perpendicular to the bar code.

•Do not hold the scanner directly over the bar code. In this position, light
can reflect back into the scanner’s exit window and prevent a successful
decode.

• Scan the entire bar code. If you are using a 1D or 2D scanner, make certain
that the scan beam crosses every bar and space on the bar code, including
the margins on either end of the symbol.

• If you are using a 2D imaging scanner, make certain the red, oval-shaped
framing mark is centered within the bar code you want to scan.

• When using imaging scanners, do not move the scanner while decoding the
bar code. Movement blurs the image.

• Hold the scanner farther away for larger bar codes.

• Hold the scanner closer for bar codes with bars that are close together.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 49

Chapter 3: Getting To Know Your 7530 G2

Scan LED Indicators

3.6.2 Scan LED Indicators

The scanner LED (the lower-left LED) indicates whether or not your scan is
successful. The LED behaves as follows:

• Scan In Progress: scan LED displays solid red colour.

• Successful Scan: scan LED displays solid green colour and turns off when
the scan is ended.

• Unsuccessful scan: scan LED flashes red.

A bar code icon appears on the screen during a scan. While the scanner beam
is active, the onscreen message states – SCANNING. If the scan is successful,
the bar code data is displayed on the screen until the scan button (or pistol trigger)
is released.

3.6.3 Troubleshooting

If the scanner is not working, investigate the following:

• Is the unit on?

• Check that the bar code symbology being scanned is enabled for the
hand-held you are using. Check any other parameters that affect the scan­ning procedure or the bar code.

• Check the bar code to make sure it is not damaged. Try scanning a different
bar code to verify that the problem is not with the bar code.

• Check that the bar code is within the proper range.

• Does the hand-held display the warning without scanning? This suggests a
hardware problem in the hand-held.

• Is the laser beam scanning across the bar code?

• Once the scan beam has stopped, check the scanner window for
dirt or fogging.

3.6.4 Operating One Dimensional (1D) Internal Laser Scanners

• Turn the hand-held on. Wait until the unit has booted up completely.

Important: If an aiming dot is available on the installed scanner, the dot will

be enabled for a configurable time period (including off), after
which normal scanning begins. Refer to “Dot Time (msec)” on
page 146 for details.

50 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 3: Getting To Know Your 7530 G2

Operating Internal PDF Laser Scanners

Double-clicking the trigger will override the aiming delay and
initiate an immediate scan. Note that the aiming dot is standard
on long-range and high visibility internal scanners.

• Aim at the bar code and press the scan key or the trigger. A scan beam and a
warning indicator appear until a successful decode is achieved or six
seconds have elapsed.

3.6.5 Operating Internal PDF Laser Scanners

This scanner decodes PDF417 two-dimensional bar codes.

• Turn the hand-held on. Wait until the unit has booted up completely.

• Aim at the bar code and press the scan key or the trigger. The beam expands
into a rectangle covering the bar code to properly scan it. The scan beam
and a warning indicator are visible until a successful decode is achieved or
three seconds have elapsed.

3.6.6 Operating Internal Two Dimensional (2D) Imager Scanners

An imager scanner takes a snap shot of a single bar code or multiple bar codes (at
one time). It can find a bar code regardless of its orientation – that is, even a bar
code printed at a 45 degree angle to the hand-held will be decoded successfully.

Note: When scanning multiple bar codes, ensure that all of the desired bar

codes are within the field of view of the scanner. It is possible that even
when all bar codes are within the field of view, not all of them will be
decoded. Only successfully decoded bar codes are passed to the applica­tion program. The application program then issues a warning, asking that
you scan the missing bar codes.

When scanning a single bar code, ensure that only the desired bar code is
within the field of view of the scanner.

Because imager scanners generally have a shorter depth of field than laser scanners,
some practise may be required to find the optimal distance from the types of bar
codes being scanned. Although the imager includes illumination LEDs, ambient
light will help the imager decode the bar codes, especially if the bar code is far from
the hand-held.

Important: Keep in mind that the imager scanner is a camera, and the LED

illumination is a flash. Glare can be an issue on reflective media
such as plastic coated bar codes, just as glare is an issue for pho-

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 51

Chapter 3: Getting To Know Your 7530 G2

Connecting & Disconnecting Tethered Peripherals

tographers. When pointing at a shiny surface, either shift the bar
code to the side or top, or angle the bar code so that the glare
reflects away from the imager scanner.

Most imagers take several ‘snap shots’ of the bar code in order to
decode it. It is normal for the LEDs to flash two or three times. Hold
the unit steady between flashes to improve decode performance.

• Turn the hand-held computer on. Wait until the unit has booted
up completely.

• Aim at the bar code and press the scan key or the trigger.

• When the scan button or trigger is pressed, a red, oval shaped light (the
framing marker) is displayed. Centre the framing marker in the field –
either in the centre of the bar code you want to scan or in the centre of the
area in which multiple bar codes are to be scanned. Hold the scan trigger or
button until a successful or failed scan result is obtained.

Illumination LEDs flashes (typically several times) and a picture of the bar code(s)
is taken.

3.7 Connecting & Disconnecting Tethered Peripherals

Tethered peripherals such as scanners and printers connect to the hand-held
computer with a quick release, circular connector. When a peripheral is connected to
the hand-held, the unit detects the peripheral and loads the necessary drivers for it.
An icon in the taskbar at the bottom of the screen provides a visual representation of
the peripheral and indicates that it is ready for operation.

To attach the peripheral to the round, tether port on the side of the unit:

• Insert the barrel of the plug into the tether port and rotate slowly until
it clicks into place. The red dot on the port and on the connector should
be aligned.

52 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 3: Getting To Know Your 7530 G2

Monitoring The Battery And Maximizing Run Time

Tether Shell

To remove the peripheral:

•Grasp the shell of the plug, and pull it back gently to unlock and release the
connector.

Important: Never attempt to disconnect a peripheral by pulling the cable by

the wire. The connector is locked into place and can only be
unlocked and removed by pulling back the plug

shell.

3.8 Monitoring The Battery And Maximizing Run Time

Under normal operating conditions, fully charged batteries last for 9 hours. As
Lithium-Ion batteries age, their capacity decreases gradually, and they are generally
considered depleted after approximately 2 years of use (less than 60% of original
capacity remaining). Keep in mind however that heavy usage or operating the 7530
G2 at temperature extremes will shorten the battery life.

Lithium-Ion batteries do not require conditioning cycles and the 7530 G2 battery system
(including chargers) requires no user interaction to maintain peak performance.

To maximize the run time of your batteries, consider the following:

• The display backlight is the largest drain on the battery. Try to keep its
brightness as low as possible.

• Depending on the ambient light at your site, consider turning off the
keypad backlight.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 53

Chapter 3: Getting To Know Your 7530 G2

Storing Batteries

• The hand-held is ‘event’ driven – that is, when the unit is not in use, it
reverts to sleep mode (even when it appears to be running), saving battery
power. Events include a key press, touchscreen taps and scan triggers.
Power consumption is reduced if you avoid unnecessary events, and allow
the unit to sleep as much as possible.

• The hand-held battery is a ‘smart battery’ with built-in intelligence. The
taskbar battery icon is a linear gauge used to estimate the remaining run
time of the battery. It is important to note that the battery capacity icon dis­plays quarter percentages of nominal capacity (the capacity of a new bat­tery). An aged battery, even when fully charged, shows somewhat less
capacity than nominal.
Double-tapping on the battery icon displays a dialog box that provides
detailed information about the battery status and performance. If the
remaining capacity indication seems inaccurate, the battery may need recal­ibration. Recalibration requires that the battery be fully charged, discharged
and then charged again before use. If the battery is fully discharged and
charged on a regular basis, recalibration should not be necessary.

• When the hand-held is switched off, it goes into a low-power, suspend state
but continues to draw a small amount of power from the battery. This
should not be an issue unless the unit is left in suspend state for more than a
week – in this case, the battery should be removed.

• Batteries left unused for durations of more than one or two months should
be fully charged, discharged (operated in the hand held until the low battery
warning appears), and then charged again before use. This recalibrates the
gas gauge and allows the internal electronics to determine the actual capac­ity of the battery.

3.8.1 Storing Batteries

Long term battery storage is not recommended. If storage is necessary:

• Always try to use a ‘first-in first-out’ approach to minimize storage time.

• Lithium-Ion batteries age much faster at elevated temperatures. Store bat­teries at temperatures between 0° C and 20°C.

• Always charge batteries to 40 to 60% before storing them. Batteries can be
damaged by an over-discharge phenomenon that occurs when an empty
battery is stored for a long period of time such that the cell voltage drops
below a lower limit.

54 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 3: Getting To Know Your 7530 G2

Monitoring The Network Connection

• To minimize storage degradation, recharge stored batteries to 40 to 60%
every 4 or 6 months to prevent over-discharge damage.

• A ‘never used’ Li-Ion battery that has been stored for 3 years may have
limited or no useful life remaining once put into service. Think of batteries
as perishable goods.

3.9 Monitoring The Network Connection

If your hand-held is equipped with a wireless LAN radio, it will typically associate
with the nearest access point. The radio signal quality meter in the taskbar indicates
the relative strength of the communication link.

• Tap on the Radio icon in the taskbar to display the Wireless Statistics
dialog box.

To access the radio signal icon using the keyboard:

• Press [BLUE] [0] to display the Start Menu.

• Highlight Shortcuts and then choose System Tray from the sub-menu.

• Use the [LEFT] and [RIGHT] arrow keys to highlight the radio signal icon
in the taskbar.

• Press [ENTER] to display the Wireless Statistics dialog box.

Note: Moving in and out of the radio coverage area can have varying effects on

a network session. At times, you may need to renew your connection by
logging in again.

3.10 Uploading Data In A Docking Station

The Combo Docking and Quad Docking peripherals allow your hand-held to link to
an Ethernet network. They are typically used to upload transaction data to a server
computer when a radio link is not available. When a 7530 G2 is properly inserted in
a docking station, a dock icon is displayed in the taskbar at the bottom of the unit
screen. The hand-held also detects the presence of the Ethernet network. Review the
documentation provided with the user application installed in your 7530 G2 before
preforming data uploads.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 55

Chapter 3: Getting To Know Your 7530 G2

General Maintenance

3.11 General Maintenance

3.11.1 Caring For The Touchscreen

The touchscreen is covered with a thin, flexible polyester plastic sheet with a
conductive coating on the inside. The polyester can be permanently damaged
by harsh chemicals and is susceptible to abrasions and scratches. Using sharp
objects on the touchscreen can scratch or cut the plastic, or crack the internal
conductive coating.

The chemicals listed below must not come into contact with the touchscreen:

• mustard, ketchup

• sodium hydroxide,

• concentrated caustic solutions,

• benzyl alcohol, and

• concentrated acids.

If the touchscreen is used in harsh environments, consider applying a disposable
screen protector (PN HU6110). These covers reduce the clarity of the display
slightly but will dramatically extend the useful life of the touchscreen. When they
become scratched and abraded, they are easily removed and replaced.

3.11.2 Cleaning The 7530 G2

Important: Do not immerse the unit in water. Dampen a soft cloth with mild

detergent to wipe the unit clean.

•Use only mild detergent or soapy water to clean the hand-held unit.

• Avoid abrasive cleaners, solvents or strong chemicals for cleaning. The
7530 G2 has a plastic case that is susceptible to harsh chemicals. The plastic
is partially soluble in oils, mineral spirits and gasoline. The plastic slowly
decomposes in strong alkaline solutions.

• To clean ink marks from the keypad and touchscreen, use isopropyl alcohol.

56 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

WORKING WITH WINDOWS CE 4

4.1 Navigating In Windows CE And Applications . . . . . . . . . . . . . . . 59

4.1.1 Navigating Using A Touchscreen And Stylus . . . . . . . . . . . . 59

4.1.2 Navigating Using The Keyboard...................59

4.2 Working With Files, Folders And Programs................60

4.3 The Startup Desktop ............................61

4.3.1 The Desktop Icons..........................62

4.3.2 The Taskbar..............................62

4.3.2.1 Using The Taskbar......................63

4.3.2.2 Customizing The Taskbar..................63

4.4 The Start Menu...............................65

4.4.1 The Desktop .............................66

4.4.2 Security Settings...........................66

4.4.2.1 Assigning The Supervisor Security Level. . . . . . . . . . 66

4.4.2.2 Changing A Password....................67

4.4.2.3 Configuring Security.....................67

4.4.3 Programs...............................68

4.4.4 Shortcuts...............................69

4.4.5 Settings................................71

4.4.6 Run..................................72

4.4.7 Shutdown...............................72

4.5 Using A Dialog Box ............................73

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 57

Chapter 4: Working With Windows CE

Navigating In Windows CE And Applications

4.1 Navigating In Windows CE And Applications

Graphic user interfaces like Windows CE for portable devices and desktop
Windows (2000, XP, etc.) utilize ‘point and click’ navigation. An equivalent
keyboard shortcut is also available for every ‘point and click’ action.

Windows CE supports the same ‘point and click’ user interface and keyboard
shortcuts as desktop Windows with one difference – the ‘point and click’ action is
accomplished using a touchscreen rather than a mouse. Actions can be performed
using any combination of keyboard shortcuts or touchscreen tapping.

Note: The security level must be set to ‘Supervisor’ in order to access many of

the items discussed in this section.

4.1.1 Navigating Using A Touchscreen And Stylus

Note: If the touchscreen is not registering your screen taps accurately, the

touchscreen may need recalibration. Refer to “Calibrating The Touch­screen” on page 41.

A touchscreen is standard for all 7530 G2s. Each unit is equipped with a stylus – a
pointing tool that looks like a pen – stored in a slot at the top of the unit. The stylus
is used to select objects on the touchscreen.

Note: To prevent damage to the touchscreen, use only the stylus (pen)

supplied with your 7530 G2.

To choose an icon, open a file, launch an applet or open a folder:

• Double-tap the stylus on the appropriate icon.

4.1.2 Navigating Using The Keyboard

If the touchscreen on your is disabled, you’ll need to use the keyboard to choose
icons and navigate dialog boxes, display the desktop, and so on.

Note: Keep in mind that if your 7530 G2 has already been fully configured and

your application is automatically launched at startup, you will have little
need for keyboard navigation.

Operation Key or Key Combination

Switch between active applications [ALT] [TAB]

Open task manager [ALT] [ESC]

Move the cursor Arrow keys

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 59

Chapter 4: Working With Windows CE

Working With Files, Folders And Programs

Open file, folder or icon [ENTER]

Exit & Save [ENTER]

Close/Exit & Do Not Save [ESC]

Navigate Dialog Boxes

Select Radio Button/Press Button [SPACE]

Go to Start Menu [BLUE][0]

Table 4.1 Keyboard Navigation

Unlike a desktop computer, the 7530 G2 does not support key chording (pressing
two keys at the same time). You must press one key followed by the next in
sequence.

Refer to “Working With Files, Folders And Programs” for additional details about
keyboard navigation.

4.2 Working With Files, Folders And Programs

[TAB]
To move cursor up [SHIFT] [TAB]
To display the contents of the next ‘tab’ in
a dialog box [CTRL] [TAB]

Folder File

Program

• Double-tap on the appropriate icon – either a folder icon, a program icon or
a file icon – to open or launch your selection.

On a keyboard:

• Use the arrow keys to highlight the icon you want to open or launch.

• Press [ENTER].

60 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 4: Working With Windows CE

The Startup Desktop

4.3 The Startup Desktop

When the 7530 G2 boots up, the startup desktop (shell) is displayed. Any
applications stored in the Startup folder start up immediately.

Note: The startup folder is located in \Windows\StartUp and

\Flash Disk\StartUp.

• Double-tap on the icon to open a window or, in the case of an application
icon, launch an application.

On the keyboard:

• Use the arrow keys to highlight the icon, and press [ENTER] to launch the
highlighted icon.

Note: If the arrow keys do not highlight the desktop icons, the desktop may not

be selected. Press [BLUE] 0 (zero) to display the Start Menu, and select
Desktop. Now the desktop will be “in focus” and the arrow keys will high­light the icons.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 61

Chapter 4: Working With Windows CE

The Desktop Icons

4.3.1 The Desktop Icons

The icons displayed in the startup desktop operate in much the same way as those
displayed on any standard PC desktop that is running Windows.

My Device

Choosing this icon displays the contents of your 7530 G2 computer. If you’re not
sure how to work with the files, folders and programs displayed, refer to “Working
With Files, Folders And Programs” on page 60.

Recycle Bin

The Recycle Bin temporarily stores items that were deleted, allowing you to either
permanently delete or restore these items.

Internet Explorer

Choosing this icon launches Internet Explorer – a standard Windows CE version.
Keep in mind that your supervisor will need to set up access using the Internet
Options and the Network and Dial-up Connections icons in the Control Panel.

Remote Desktop Connection

This option allows your 7530 G2 to communicate with a remote desktop PC. “Remote
Desktop Connection” on page 81 provides a website with step-by-step instructions.

4.3.2 The Taskbar

The 7530 G2 is equipped with a taskbar at the bottom of the screen. It displays icons
through which you can view the status of various elements of your unit such as

62 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 4: Working With Windows CE

Using The Taskbar

battery capacity and radio signal quality. If the hand-held is attached to a charger,
cradle, docking station or PDM, an associated icon is displayed. In addition, the
taskbar displays the application(s) currently running on your unit and the security
level assigned to your 7530 G2.

The taskbar also displays active modifier keys – [SHIFT], [ALT], [CTRL], [BLUE]
and [ORANGE]. Keys that have been locked “on” are displayed in uppercase
letters. For example, if you lock the [CTRL] key “on”, it is displayed as CTRL KEY in
the taskbar.

4.3.2.1 Using The Taskbar

Using the icons in the taskbar, you can either display the Control Panel dialog box
associated with an icon, or you can view a tooltip. A tooltip provides the status of
each icon.

• Tap and hold the stylus on an icon to display the icon’s tooltip. Double-tap
on the icon to open the Control Panel dialog box associated with the icon.

On the keyboard:

• Press [BLUE] [0] to display the Start Menu.

• Choose Shortcuts from the Start Menu, and then press the [RIGHT] arrow
key to display the sub-menu.

• Choose System Tray in the sub-menu.

• Use the arrow keys to highlight the icon in the taskbar about which you’d
like more information. As each icon is highlighted, a tooltip is displayed.

• To display the associated Control Panel dialog box, press [ENTER].

4.3.2.2 Customizing The Taskbar

To customize the taskbar so that it displays only those icons you require:

•In the Start Menu, tap on Settings>Taskbar.

If you’re using the keyboard:

• Press [BLUE] [0] to display the Start Menu.

• Highlight the Settings option, highlight Taskbar in the sub-menu, and
press [ENTER].

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 63

Chapter 4: Working With Windows CE

Customizing The Taskbar

The Taskbar and Start Menu dialog box is displayed.

Figure 4.1 Taskbar And Start Menu Settings

Taskbar General Tab

• Tap on the items you want to display in the taskbar. The checkmark indi­cates items that will be displayed.

If you’re using the keyboard:

• Highlight the options you want to activate, and press the [SPACE] key to
select them.

Taskbar Advanced Tab

• Tap on the Clear button to empty the Documents folder.

• To display Control Panel applets in menu form rather than in a window, tap
in the checkbox next to Expand Control Panel.

64 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 4: Working With Windows CE

The Start Menu

Taskbar Security Tab

If you check Disable hot keys, the Application from Start menu field becomes
enabled. Use this field to enter the name of the application you want to run when the
user presses the Menu hot key – [BLUE] [0].

If you have disabled hot keys, hidden the Start Menu and have no application
configured, the Menu hot key brings up the Security dialog box.

4.4 The Start Menu

Note: Some of the Start Menu items may be disabled based on the 7530 G2’s

current security settings.

The Start Menu lists the operations you can access and work with. It is available
from the startup desktop or from within any application.

To display the menu:

• Press [BLUE] [0] (zero).

• Tap on the item in the menu with which you want to work.

If you’re using a keyboard:

• Use the arrow keys to highlight a menu item, and press [ENTER], or

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 65

Chapter 4: Working With Windows CE

The Desktop

• If the menu item has an underlined character, type the underlined alpha
character – for example, to display the Security dialog box, type the letter s.

4.4.1 The Desktop

Choosing the Desktop option from the Start Menu displays the 7530 G2 desktop.

4.4.2 Security Settings

Choosing the Security option from the Start Menu displays a dialog box in which
you can define the access level for the 7530 G2 – Supervisor or User.

Figure 4.2 Security Levels

4.4.2.1 Assigning The Supervisor Security Level

The security level is represented by an icon in the shape of a lock in the taskbar. The
security levels define the options accessible to the operator in the Start Menu and
the taskbar. By default, the security level is set to User, restricting access to only the
most basic Start Menu items.

To allow access to all the Start Menu and taskbar options:

•In the Security Level dialog box, tap on the radio button next to Supervisor.

•In the Password field, type the Supervisor level password.

• Tap on OK – you can now access all menu items in the Start Menu along
with the icons in the taskbar.

66 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 4: Working With Windows CE

Changing A Password

4.4.2.2 Changing A Password

Note: Keep in mind that this is the same password as that assigned through the

Password control panel applet.

• To assign a password, choose a security level, and enter the existing pass-
word in the Password field.

• Tap on the Set Password button.

A dialog box labelled Password Properties is displayed.

• Type the new password in the Password: text box

•In the Confirm Password: text box, retype the new password.

4.4.2.3 Configuring Security

In the Security Level dialog box (see Figure 4.2 on page 66):

• Tap on the Configure button.

This dialog box also allows you to determine which security levels will have an
associated icon displayed in the taskbar. By default, a security icon is not displayed
for user-level security.

Note: It is recommended that you enable ‘Allow Teklogix Security Level’ so that

authorized Psion Teklogix service personnel can access your unit should
it require maintenance.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 67

Chapter 4: Working With Windows CE

Programs

4.4.3 Programs

• Tap on Programs to display a sub-menu of options.

This sub-menu allows you to choose ActiveSync and Command Prompt, and you
can access the Internet Explorer, installed applications (e.g., Open Tekterm V2.0),
Remote Desktop Connection or Windows Explorer.

Figure 4.3 Program Sub-Menu

ActiveSync®

ActiveSync is used to connect your PC to another device.

Demo

This folder contains the Demo Imager, Demo Scanner, Demo Signature and Demo
Sound applications. Demo Imager is used for simple image-capturing purposes and

for displaying bar code data and bar code statistics on the same screen with image
data and information. Demo Scanner can be used to test how the hand-held reads
and writes RFID tags. Demo Signature allows you to capture a signature written
on the screen with your stylus and save it to a file. Demo Sound allows you to
record sound.

Command Prompt

Command Prompt is used to access the DOS command prompt. At the prompt, you
can type DOS commands such as dir to display all the directories in the drive.

68 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 4: Working With Windows CE

Shortcuts

Internet Explorer

The 7530 G2 is equipped with Microsoft Internet Explorer for Windows CE. You
can access the Internet Options icon through the Start Menu under
Settings>Control Panel or by double-tapping on the desktop icon My Device and
then, double-tapping on the Control Panel icon.

Windows Explorer

The Windows Explorer installed on your 7530 G2 is consistent with all Windows
CE devices. You can access this option from the Start Menu under Programs,
Windows Explorer.

Remote Desktop Connection

Remote Desktop Connection is a 7530 G2 application used to connect to a Windows
Terminal Server so that you can run a “session” on the Server machine using the
7530 G2 (Windows CE device). “Remote Desktop Connection” on page 81
provides a website with details about this option.

4.4.4 Shortcuts

Figure 4.4 Shortcuts Sub-Menu

The System Tray

If your touchscreen is disabled, you can use the System Tray option to access the
icons in the taskbar at the bottom of the screen. The taskbar displays indicators such
as a radio signal icon and the security level. These indicators are attached to dialog
boxes that provide additional information.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 69

Chapter 4: Working With Windows CE

Shortcuts

• Press [BLUE] [0] to display the Start Menu.

• Using the arrow keys, highlight Shortcut>System Tray.

When System Tray is chosen, the taskbar icons become accessible.

• Use the arrow keys to highlight an icon. As each icon is highlighted, a
tooltip – a description of the status of the icon – is displayed.

• Press [ENTER] to display the Control Panel dialog box associated with
the icon.

Cycle Tasks

When Cycle Tasks is selected (and the Task Manager is not open), you can cycle
through active applications.

To cycle through your active applications:

• Tap on Shortcuts>Cycle Tasks, or

Press [ALT] [TAB].

The Task Manager

The Task Manager allows you to switch to another task or to end an active task. To
display the task manager window:

• Tap on Shortcut>Task Manager, or
Press [ALT] [ESC].

70 Psion Teklogix 7530 G2 Hand-Held Computer User Manual

Chapter 4: Working With Windows CE

4.4.5 Settings

The Settings sub-menu includes the following settings: Control Panel, Network
and Dial-up Connections and Taskbar and Start Menu.

Figure 4.5 Settings Sub-Menu

Settings

Control Panel

The Control Panel contains applets used to configure hardware, the operating
system and the shell. If your 7530 G2 is running with the Psion Teklogix Tekterm
application or another application, additional configuration applets may appear in
the Control Panel.

Network And Dial-Up Connections

The Network and Dial-up Connections window allows you to configure the 7530
G2 radio or execute an existing configuration. Refer to “Configuring An IEEE

802.11 Radio In The Unit” on page 17 for radio setup details.

Taskbar And Start Menu

The Taskbar and Start Menu option displays a dialog box in which you can
customize the taskbar, choosing which options will be displayed. Refer to
“Customizing The Taskbar” on page 63 for additional details about this option.

Psion Teklogix 7530 G2 Hand-Held Computer User Manual 71

Chapter 4: Working With Windows CE

Run

4.4.6 Run

Choosing the Run option from the Start Menu displays a dialog box in which you
can enter the name of the program, folder or document you want to open or launch.

4.4.7 Shutdown

Figure 4.6 Run Option

The Shutdown menu includes the following options: Suspend, Warm Reset and
Cold Reset.

Figure 4.7 Shutdown Sub-Menu

Note: This menu varies slightly depending on the security level chosen. When

the 7530 G2 is set to User level, the Shutdown option is replaced by Sus-
pend. A sub-menu is not available.

72 Psion Teklogix 7530 G2 Hand-Held Computer User Manual
