SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 1

OWNER’S MANUAL

Wet/Dry Vacuum

ProGuard®4 Portable

SKU: 107128 Model: 1071280

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 2

TABLE OF CONTENTS

ProGuard®4 Portable,

4 Gallon Wet/Dry Vacuum

Vacuum Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Carton Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Preparation for Operation . . . . . . . . . . . . . . . . . . . . . 6

Filter Assembly/Replacement . . . . . . . . . . . . . . . . . . . 7

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Cord Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Filter Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . 13

Preventive Maintenance

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

ProGuard ProGuard

Servicing Double Insulated Wet/Dry Vacuums . . . . . . . . 17

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Spanish

French . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Go to www

4 Portable Assembly . . . . . . . . . . . . . . . . . . 16

4 Portable Parts List . . . . . . . . . . . . . . . . . . 17

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

.pro-team.com to register your new Vacuum.

INSPECTION

Carefully unpack and inspect your new ProTeam Vacuum for shipping damage. Each unit is tested and thoroughly inspected before shipping. All returns must have a Return Authorization Number (RAN). To request an RAN or to ask questions regarding any shipping damage, contact ProTeam at 866.888.2168 or customerservice.proteam@emerson.com

This Owner’s Manual has important information for the use and safe operation of this machine. R machine. K to read this manual. If instructions are not followed, an injury may occur or equipment, furniture or buildings may become damaged.

For new manuals please contact ProTeam, Inc. at: customerservice.proteam@emerson.com P.O. Box 7385, Boise, ID 83707

866.888.2168 or visit www.pro-team.com for a downloadable version.

The contents of this manual are based on the latest product information available at the time of publication. ProTeam reserves the right to make changes or improvements to its machines without notice.

eep this manual available at all times and instruct all owners

. . . . . . . . . . . . . . . . . . . . . . 15

ead this manual carefully before starting the

E N G

S H

P A

N O

R A N Ç A

2 ProTeam

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 3

IMPORTANT SAFETY INSTRUCTIONS

Safety is a combination of common sense, staying alert, and knowing how your Wet/Dry Vacuum cleaner (“Vacuum”) works.

Safety Signal Words

DANGER:

death or serious injury.

WARNING: Indicates a hazardous situation which, if not avoided, could result in

death or serious injury.

CAUTION: Indicates a hazardous situation which, if not avoided, could result in

minor or moderate injury. When using your Vacuum, always follow basic safety precautions including the following:

WARNING: To reduce the risk of fire, electric shock, or injury.

1. Read and understand this manual and all labels on the Wet/Dry Vacuum before operating.

2. Use only as described in this manual.

3. Do not leave Vacuum running while unattended - you may fail to notice important signs indicating abnormal operation such as loss of suction, debris/liquid exiting the exhaust, or abnormal motor noises. Immediately stop using Vacuum if you notice these signs.

4. Do not leave Vacuum when plugged in. Unplug from outlet when not in use and before servicing.

5. Sparks inside the motor can ignite flammable vapors or dust. To reduce the risk of fire or explosion, do not use near combustible liquids, gases, or dusts, such as gasoline or other fuels, lighter fluid, cleaners, oil-based paints, natural gas, coal dust, magnesium dust, grain dust, aluminum dust, or gun powder.

6. Do not vacuum anything that is burning or smoking, such as cigarettes, matches, or hot ashes.

7. To reduce the risk of inhaling toxic vapors, do not vacuum or use near toxic or hazardous materials.

8. To reduce the risk of electric shock, do not expose to rain or allow liquid to enter motor compartment. Store indoors.

9. Do not allow to be used as a toy. Close attention is necessary when used by or near children.

10. Do not use with a torn filter or without the filter installed except when vacuuming liquids as described in this manual. Dry debris ingested by the impeller may damage the motor or be exhausted back into the air.

11. Turn off Vacuum before unplugging.

12. To reduce the risk of injury from accidental starting, unplug power cord before changing or cleaning filter.

13. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

14. Do not use with damaged cord, plug, or other parts. If your Vacuum is not working as it should, has missing parts, has been dropped, damaged, left outdoors, or dropped into water, call customer service.

15. Do not pull or carry by cord, use cord as handle, close a door on cord, or pull cord around sharp edges or corners. Keep cord away from heated surfaces.

16. Do not handle plug, switch, or the Vacuum with wet hands.

Indicates a hazardous situation which, if not avoided, will result in

ProTeam 3

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 4

VACUUM SAFETY (Continued)

17. Use only extension cords that are rated for outdoor use. Extension cords in poor condition or too small in wire size can pose fire and shock hazards. To reduce the risk of these hazards, be sure the cord is in good condition and that liquid does not contact the connection. Do not use an extension cord with conductors smaller than 16 gauge (AWG) in size. To reduce power loss, use a 14 gauge extension cord if 25 to 50 ft long and 12 gauge for 50 ft or longer.

18. This Wet/Dry Vacuum is double-insulated, eliminating the need for a separate grounding system. Use only identical replacement parts. Read the instructions for Servicing Double-Insulated Wet/Dry Vacuums before servicing.

19. Do not put any object into ventilation openings. Do not vacuum with any ventilation openings blocked; keep free of dust, lint, hair, or anything that may reduce air flow.

20. Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.

21. To reduce the risk of falls, use extra care when cleaning on stairs.

22. To reduce the risk of personal injury or damage to Vacuum, use only ProTeam recommended accessories.

23. When using as a blower:

- Direct air discharge only at work area.

- Do not set down in liquid; electric shock could occur.

- Do not direct air at bystanders.

- Keep children away when blowing.

- Do not use blower for any job except blowing dirt and debris.

- Do not use as a sprayer.

- Wear safety eyewear.

24. To reduce the risk of eye injury, wear safety eyewear. The operation of any utility Vacuum or blower can result in foreign objects being blown into the eyes, which can result in severe eye damage.

CAUTION:

To reduce the risk of hearing damage, wear ear protectors when using for extended

time or in a noisy area.

- For dusty operations, wear dust mask, such as an N95 or P100 mask.

- Static shocks are common when the relative humidity of the air is low. Vacuuming

fine debris with your Vacuum can deposit static charge on the hose or Vacuum. To reduce the frequency of static shocks when using this Vacuum, add moisture to the air with a humidifier.

Observe the following warnings that appear on the motor housing of your V

WARNING - For your own safety, read and understand Owner’s Manual. Do not run unattended. Do not pick up hot ashes, coals, toxic, flammable or other hazardous materials. Do not use around explosive liquids or vapors.

ARNING - To reduce the risk of electric shock - do not expose to rain - store

indoors.

DOUBLE INSULATED - GROUNDING NOT REQUIRED. WHEN SERVICING USE ONLY IDENTICAL PROTEAM REPLACEMENT PARTS.

acuum:

SAVE THESE INSTRUCTIONS

4 ProTeam

(1)

(5)

(6)

(7)

(8)

(9)

(10)

(11)

(15)

(12)

(13)

(14)

(3)

(4)

(2)

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 5

ELECTRICAL CORD CARE

When vacuuming is complete, unplug the cord and wrap it around the motor cover. If the power cord is damaged, it must be replaced by the manufacturer or their service agent or by similarly qualified personnel to reduce the risk of accident.

NEVER stretch the cord tightly between the Vacuum and the outlet. A cord that is stretched or pulled will not function properly and creates a danger.

After vacuuming, unplug the cord and wind it up as described on page 12. DO NOT wind up the cord wrapping it around your hand and elbow.

Use only the designated ProTeam replacement cord. Reference Important Safety Instructions item number 17. Cord jacket type should be SJTW or better.

CARTON CONTENTS

OVERVIEW

• 4 Gallon Wet/Dry Vacuum (1)

• 4 Casters (2)

• Qwik Lock™ Fine Dust Cartridge

Filter (3)

• Master Floor Tool (4)

• Floor Brush Insert (5)

• Squeegee Insert (6)

• Carpet Insert (7)

• Crevice Tool (8)

• Dust Brush (9)

• Claw Nozzle (10)

• Diffuser (11)

• Straight Wand (12)

• Curved Wand (13)

• Hose Assembly (14)

• Owner’s Manual (15)

ProTeam 5

Power Head

Tank Latch

Tank

Hose

Vacuum Port Inlet

Switch

Handle

Power Cord

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 6

PREPARATION FOR OPERATION

GETTING STARTED

This Wet/Dry Vacuum is intended for commercial use. It may be used for light vacuuming of wet or dry media and may be used as a blower. The lightweight design allows usage for most small vacuuming chores. Familiarize yourself with the following product and features and read the entire manual for specific usage of your new Wet/Dry Vacuum.

Familiarize yourself with the controls and features of your Wet/Dry Vacuum before operating

(Figure A).

Figure A

6 ProTeam

Pull Out And Lift Up

Power Head

Tank

Latch

Tank

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 7

FILTER ASSEMBLY/REPLACEMENT

WARNING: For your own safety, never connect plug to power source outlet until

all assembly steps are complete and you have read and understood the safety and operation instructions. Do not operate Vacuum with any parts damaged or missing.

To Remove Power Head:

1. Grasp the tank latches on both the right and left side of the power head.

Slowly pull the tank latches away from the tank. Lift the power head off the tank. Place the power head of the Vacuum upside down

(Figure B).

Figure B

ProTeam 7

Rubber Gasket at Bottom of Filter

(cutaway view)

Filter Cage

Filter Tabs (2)

Integrated Filter Plate with Center Hole

USH

DOWN

PULL

Qwik Lock™ Stud

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 8

FILTER ASSEMBLY/REPLACEMENT (cont.)

WARNING: Do not operate without filter cage and float, as they prevent liquid

from entering the impeller and damaging the motor. IMPORTANT: To avoid damage to the blower wheel, always reinstall the filter

before using the Vacuum for dry material pick-up.

Removal and Installation of Qwik Lock™ Fine Dust Cartridge Filter

Filter Removal:

1. Hold the filter tabs of the Qwik Lock

filter in each hand

2. With one thumb on the Qwik Lock

stud, which protrudes through the integrated filter plate, lift up on the filter tabs while pushing down on the stud.

3. This action will cause the filter to

release from the filter cage. Slide filter off cage.

(Figure C).

Filter Installation:

1. Carefully slide the Qwik Lock filter

2. Align the small center hole in the top of the filter over the Qwik Lock™ stud on

NOTE: Failure to properly seat the bottom gasket could result in debris bypassing the filter.

over the filter cage and press down on the outside edge of the filter until the rubber gasket on the bottom of the filter seats securely around the base of the filter cage and against the lid.

Figure C

the filter cage. Press firmly on top of the filter near the stud to allow the filter to snap over the ball on the end of the stud. The filter is now attached.

8 ProTeam

"ON"

"OFF"

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 9

OPERATION

WARNING - To reduce the risk of fire, explosion, or damage to Vacuum:

• Do not leave Vacuum running while unattended - you may fail to notice important

signs indicating abnormal operation such as loss of suction, debris/liquid exiting the exhaust, or abnormal motor noises. Immediately stop using Vacuum if you notice these signs.

• Do not leave Vacuum plugged in when not in use.

• Do not continue running when float has cut off suction.

• Do not operate Vacuum in areas with flammable gases, vapors or explosive dust in

the air. Sparks inside the motor can ignite airborne flammables. Flammable gases and vapors include: lighter fluid, solvent-type cleaners, oil-based paints, gasoline, alcohol, and aerosol sprays. Flammable dusts include: coal, magnesium, aluminum, grain, and gun powder.

• Do not vacuum up explosive dusts, flammable liquids, or hot ashes.

• Do not use Vacuum as a sprayer.

WARNING - To reduce the risk of electric shock or injury:

• Do not expose to rain or allow liquid to enter motor compartment. Store indoors.

• Do not handle plug, switch, or Vacuum with wet hands.

• Do not service Vacuum while it is plugged in. If your Vacuum is not working as it

should, has missing parts, has been dropped, damaged, left outdoors, or dropped into water, return it to an authorized service center or call customer service.

• When using an extension cord, use only outdoor-rated cords that are in good

condition. Do not allow the connection to come into contact with liquid.

• Do not vacuum toxic materials to reduce the risk of inhaling the vapors or dust.

To reduce the risk of electric shock, this Vacuum has a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way.

After you plug the power cord into the outlet, turn the unit on by pushing the switch from position "O" to position "l". The symbols used on the switch actuator are international "On & Off" symbols (Figure D).

OOFFF

OON

Figure D

ProTeam 9

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 10

OPERATION (Continued)

Vacuuming Dry Materials

1. The filter must be in correct position at all times to avoid leaks and possible

damage to Vacuum.

2. When using your Vacuum to pick up very fine dust, it will be necessary for you to

empty the tank and clean the filter at more frequent intervals to maintain peak Vacuum performance.

NOTE: A dry filter is necessary to pick up dry material. If you use your Vacuum to pick up dust when the filter is wet, the filter will clog quickly and will be very difficult to clean.

WARNING: Do not operate without filter cage and float, as they prevent liquid

from entering the impeller and damaging the motor. For dry material pick-up, do not operate without the filter in place to reduce the risk of damage to the motor.

Vacuuming Liquids

1. When picking up small amounts of liquid, the filter may be left in place.

2. When picking up large amounts of liquid, we recommend that the filter be

removed. If the filter is not removed, it will become saturated and misting may appear in the exhaust.

3. When the liquid in the tank reaches a predetermined level, the float mechanism

will rise automatically to cut off airflow. You will know that the float has risen because Vacuum airflow ceases and the motor noise will become higher in pitch, due to increased motor speed. When this happens, turn off the Vacuum and empty the tank.

4. After using the Vacuum to pick up liquids, the filter must be dried to avoid

possible mildew and damage to the filter.

IMPORTANT: To avoid damage to the Vacuum, do not run motor with float in raised position.

10 ProTeam

Power Head

Tank Latch

Tank

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 11

OPERATION (Continued)

Emptying the Tank

1. To remove the lid to empty contents of the tank, simply lift the two tank latches on the side of the Vacuum and lift the power head up and off the tank and set to the side

(Figure E).

2. Lay the power head on a clean dry area while emptying the tank or changing the filter.

3. Dump the tank contents into the proper waste disposal container

(Figure F).

Figure E

Blowing Feature

Your Wet/Dry Vacuum has the capability to be used as a blower for yard work, patio cleanup and workshop applications to blow sawdust and other debris.

NOTE: The blowing port is located opposite the Vacuum port.

WARNING - Always wear safety

eyewear complying with ANSI Z87.1 (or in Canada, CSA Z94.3) before using as a blower.

Figure F

CAUTION - W

dust which might be inhaled.

CAUTION - To reduce the risk of hearing damage, wear ear protectors when using

the Vacuum/Blower for extended time or in a noisy area.

ear a dust mask, such as an N95 or P100 mask, if blowing creates

WARNING - To reduce the risk of injury to bystanders, keep them clear of blowing debris.

ProTeam 11

Handle

Power Cord

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 12

CORD STORAGE

1. Your Vacuum has a convenient area to store your power cord.

2. Wrap the power cord around the top of the handle on the Vacuum and attach the end of the plug to the cord

3. The hose included with this product will not store around handle. Store hose separately in a safe place, close to Wet/Dry Vacuum.

Cord Maintenance

When vacuuming is complete, unplug the cord and wrap it around the motor cover. If the power cord is damaged, it must be replaced by qualified personnel to reduce the risk of accident.

Storage

Before storing your Vacuum, the tank should be emptied and cleaned. The cord should be wrapped around the unit. Accessories should be kept in the same area as the Vacuum so they can be readily available. The Vacuum should be stored indoors.

(Figure G).

Figure G

12 ProTeam

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 13

MAINTENANCE

Cleaning Vacuum Filter

Note: The filter is made of high quality paper designed to stop very small particles of

dust. The filter can be used for dry pick-up or to pick up small amounts of liquid. Handle the filter carefully when removing or installing. Creases in the filter pleats may occur from installation but will not affect the performance of the filter.

Filter Removal

Refer to page 8 "Filter Assembly/Replacement" Section of this manual.

IMPORTANT: To avoid damage to the blower wheel and motor, always reinstall the filter before using the Vacuum for dry material pick up.

Cleaning A Dry Filter

NOTE: Clean the filter in an open area. Cleaning SHOULD be done outdoors.

1. Light cleaning of some dry debris from the filter can be accomplished without removing the filter from the Vacuum. Simply slap your hand on top of the handle while the Vacuum is turned off.

2. Remove filter from Vacuum. Gently tap the filter against the inside wall of your tank and the debris will loosen and fall.

3. For thorough cleaning of a dry filter with fine dust (no debris) you may run water through it as described under “Cleaning A Wet Filter” Section.

Cleaning A Wet Filter

After filter is removed, run water from a hose or spigot through the filter. Take care that water pressure from the hose is not strong enough to damage filter. Allow the filter to air dry before reinstalling and storing the Vacuum.

IMPORTANT: After cleaning, check the filter for tears or small holes. Do not use a filter with holes or tears in it. Even a small hole can cause a lot of dust to come out of your Vacuum. If your filter is damaged or worn,

ProTeam 13

replace it immediately

Dampened Cloth

Vacuum Assembly

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 14

MAINTENANCE (Continued)

Cleaning and Disinfecting the Wet/Dry Vacuum

To keep your Wet/Dry Vacuum looking its best, clean the outside with a cloth dampened with warm water and mild

(Figure H).

soap

To clean the tank:

1. Dump out debris.

2. Wash tank thoroughly with warm water and mild soap.

3. Wipe out with dry cloth.

Before prolonged storage or as needed (e.g., waste water pick up), the tank should be disinfected.

To disinfect the tank:

1. Pour 1 gallon of water and 1 teaspoon of chlorine bleach into the tank.

2. Let solution stand for 20 minutes, carefully swishing every few minutes, making sure to wet all inside surfaces of the tank.

3. Empty tank after 20 minutes. Rinse with water until bleach smell is gone. Allow tank to dry completely before sealing the motor on the tank.

WARNING - To assure product SAFETY and RELIABILITY, repairs and adjustments should be performed by an Authorized Service Centers, always using ProTeam replacement parts.

Figure H

14 ProTeam

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 15

PREVENTIVE MAINTENANCE

WARNING:

The following information is for use by qualified service personnel only and provides guidance for troubleshooting and maintenance.

• Unplug

• DO NOT lubricate the motor.

• DO NOT tie extension cord and power cord together. Doing so will result in

damage to both cords and will not be covered under warranty.

CARING FOR YOUR VACUUM

1. The ensure a valid Vacuum warranty, optimal performance and improved indoor

2. Check all filters before each use. Empty or replace the filters as necessary.

3. Wipe the inside and outside of the Vacuum with a cleaning agent after each use.

PROPER STORAGE

When the Vacuum is not in use, the Vacuum should be stored indoors and in a dry location. Before storing your Vacuum, the tank should be emptied and cleaned. The cord should be wrapped around the unit and the hose and accessories should be stored as described in this manual. Accessories should be kept in the same area as the Vacuum so they can be readily available.

the Vacuum when working on the motor or any electrical part.

air quality, be sure to use genuine ProTeam Filters.

TROUBLESHOOTING

1. If the Vacuum will not operate, check the following:

a. The power supply cord at the wall outlet b. The power supply cord at the Vacuum c. That the switch is in the “on” position and functioning properly d. Confirm the wall outlet being used has power. Check the circuit breaker in

the building. If that is not the problem contact a ProTeam Authorized Warranty Station.

2. If the cord is getting too warm, check to see that the cord does not exceed a length

of 50 feet at 14 gauge or 100 feet at 12 gauge.

3. If loss of suction occurs, check the following:

a. Check that debris is not plugging the hose and/or accessories. b. Check and/or clean the pleated filter. c. Check that the hose cuffs are fitting tightly on the hose and are not cracked. d. Check that the power head is properly attached to the Vacuum tank.

ProTeam 15

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 16

PROGUARD®4 PORTABLE ASSEMBLY

16 ProTeam

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 17

PROGUARD®4 PORTABLE REPAIR PARTS

Repair Parts Assembly

All items sold as each's unless otherwise identified

OORRDDEERR QQTTYY..

1 510123 Switch and Switch Cover (Set) 1 2 510107 Motor Cover and Top Handle 1 3 829719-4 Cord Assembly 1 4 830519 Exhaust Duct 1 5 509776-19 Motor Assembly (Includes: # 8) 1 6 830520-2 Lid 1 7 826387 Tank Latch 2 8 510124 Spacer, Blower Wheel, Washer, Nut 1 9 832656-1 Plate Collector 1 10 820563-4 Screw, Type AB #10 x 3/4” 7 11 510108 Filter Cage and Float Assembly 1 12 107178 Qwik Lock™ Fine Dust Cartridge Filter 1 13 510106 Tank (With Inlet) 1 14 510109 Caster (Set of 4) 1 15 831337-6 Premium Hose Assembly 1 16 107184 Accessory Kit (Includes: 17 - 26) 1 17 107189 Master Floor Tool 1 18 107191 Carpet Insert 1 19 107192 Floor Brush Insert 1 20 107193 Squeegee Insert 1 21 107194 Crevice Tool 1 22 107195 Dust Brush 1 23 107196 Claw Nozzle 1 24 830098 Diffuser 1 25 107190 Straight Wand 1 26 107188 Curved Wand 1 27 107182 Intercept Micro® Filter Bag - 3/pk (Optional) 1 28 SP6768 Owner’s Manual 1

## PPRROODDUUCCTT NNAAMMEE NNEEEEDDEEDD

ProGuard®4 Portable

WARNING

SERVICING OF DOUBLE-INSULATED WET/DRY VACUUM

In a double-insulated Wet/Dry Vacuum, two systems of insulation are provided instead of grounding. No means of grounding is provided on a double-insulated appliance, nor should a means for grounding be added. Servicing a doubleinsulated Wet/Dry Vacuum requires extreme care and knowledge of the system, and should be done only by qualified service personnel. Replacement parts for a double-insulated Wet/Dry Vacuum must be identical to the parts they replace. Your double-insulated Wet/Dry Vacuum is marked with the words "DOUBLE INSULATED" and the symbol (square within a square) may also be marked on the appliance.

To reduce the risk of injury from electrical shock, unplug power cord before servicing the electrical parts of the Wet/Dry Vacuum.

ProTeam 17

SP6768-1 PROTEAM 4 GALLON 12/28/11 11:17 AM Page 18

PROGUARD®4 PORTABLE WARRANTY

This limited warranty applies to the following ProTeam, Inc. commercial ProGuard®Wet/Dry Vacuums (collectively, the “ProGuard Products”): ProGuard 4.

If you have any questions or need assistance regarding the warranty of your product, please call ProTeam Customer Service department at (866) 888-2168 7:30 a.m. - 5:00 p.m. Mountain Time.

ProGuard®- Limited Warranty

ProTeam, Inc., located at 12438 W. Bridger Street, Boise, Idaho 83713 (“ProTeam”) warrants to the original purchaser only (“you”) subject to the exclusions described below, that the ProGuard Product component parts and motors listed below will be free from defects in material and workmanship beginning on the original date of purchase and continuing for the period set forth below (each a “Warranty Period”). This limited warranty terminates if the original purchaser transfers the ProGuard Product to any other person or entity.

Parts Warranties - All ProGuard Products

• Molded body parts on all ProGuard Products - Expected lifetime of the ProGuard Product.

• All other component parts (excluding the motor) on all ProGuard Products - 3 years.

Motor Warranties - Specific to each ProGuard Product

• ProGuard 4 - Vacuum motor - 1 year.

What is Not Covered - Warranty Exclusions

This limited warranty does not extend to and expressly excludes:

• Normal wear and tear and/or replacement attachments or accessories, including, without

limitation, extension cords, hoses, filters, switches, carbon motor brushes and other

attachments to the ProGuard Product.

• Damage or burnout of the ProGuard Product motor resulting from failure to clear a blockage

occurring during the normal course of use.

• Loss or damage to the ProGuard Product resulting from conditions beyond ProTeam's control

including without limitation, misuse, accident, abuse, neglect, negligence (other than

ProTeam's), overuse beyond intended capacity, or unauthorized modification or alteration.

• Loss or damage to the ProGuard Product resulting from failure to follow the required

maintenance schedule, or failure to use the ProGuard Product in accordance with ProTeam's

written instructions, guidelines or the terms of its Owner's Manual.

What We Will Do to Correct Problems

If a claim made during the Warranty Period is covered under this limited warranty, ProTeam or your local ProTeam authorized dealer will, at ProTeam's sole option, (a) repair the defective portion of the ProGuard Product or (b) replace the entire ProGuard Product. THE SOLE AND EXCLUSIVE REMEDY FOR BREACH OF THIS LIMITED WARRANTY SHALL BE LIMITED TO REPAIR OR REPLACEMENT OF THE PROGUARD PRODUCT.

No Other Express W

THE LIMITED W PROVIDED BY PROTEAM T

ARRANTIES, WRITTEN OR ORAL, EXPRESS OR IMPLIED, WHETHER ARISING BY OPERA

W LAW OR OTHERWISE, INCLUDING, WITHOUT LIMIT FITNESS FOR A PAR AND WHETHER OR NOT THE PROGUARD PRODUCT HAS BEEN SPECIFICALL MANUFACTURED FOR YOUR USE OR PURPOSE. No employee, agent, dealer authorized to alter this limited warranty or make any other warranty on behalf of P The terms of this limited warranty shall not be modified by P their respective successors or assigns.

ARRANTIES PROVIDED ABOVE ARE THE SOLE AND EXCLUSIVE W

O THE ORIGINAL PURCHASER, AND ARE IN LIEU OF ALL OTHER

TICULAR PURPOSE, WHETHER OR NOT THE PURPOSE HAS BEEN DISCLOSED

arranty Applies

ARRANTIES OF MERCHANTABILITY OR

TION, W

roT

ARRANTIES

TION OF

Y DESIGNED OR

, or other person is

roT

eam, the original owner

eam.

, or

18 ProTeam

+ 42 hidden pages

ProTeam ProGuard 4 Portable User Manual [en, es, fr]

Specifications and Main Features

Frequently Asked Questions

User Manual
