Campmate-2

Introduction

CampMate-2 is an all in one kit for all camping enthusiasts. A rugged wireless speaker with
a powerful 10000mAh backup battery and LED light. Countless features in one compact
and lightweight product. CampMate-2 is one indispensable companion for your overnight
camping trips. The super bright LED lights are powerful enough to use in the darkest
environments. CampMate-2, a one-stop solution for all your adventures.

Packaging Contents

• CampMate-2

• Charging Cable

• User Guide

Specications

• Bluetooth Version: v4.2

• Bluetooth Chipset: AC6905C_QSOP24

• Bluetooth Frequency:2402-2480MHz

• Bluetooth Proles: A2DP, AVRCP

• Battery Type: Li-ion

• Battery Capacity: 10000mAh

• Power Input: DC5V, 2.3A MAX

• Power Output: DC 5V,2.3A MAX

• Speaker Output: 5W

• Impedance: 4Ω

• Operating Distance: 10m

• Music Playback Time: 60 hours

• Charging Time: 6-7 hours

• LED Brightness: 4W/200lm

Features

• Compact Design: CampMate-2 will not clutter your desk or home, CampMate-2 is compact

enough to toss in a bag should you care to take great sound with you.

• Big On Sound:

The powerful 5-watt integrated wireless speaker ensures you have the

best quality music playback no matter where you are.

• Charge on the go:

The built-in 10000mAh battery can also charge your smartphone so

that you never run out of power on the go

• LED Lights: The super bright LED light is powerful enough to use in the darkest environ
ments or use it as a powerful torch or a ashing SOS alert device.

• Universal Compatibility: CampMate-2is compatible with all Bluetooth enabled devices

• Music On The Go: CampMate-2 can be put in to the water bottle cage of bike perfectly,

make your riding journey full of Music.

Precautions

Please read all safety instructions and warnings thoroughly before using this product. Improper
use of this product may result in damage to this or attached products.

1. Do not disassemble the product or attempt to x it.

2. Kindly use an original charging cable provided.

3. Do not attempt to replace any part of this product or battery inside.

4. Do not crush, puncture, dispose of in re, short the contacts or expose the product to
water or other liquids.

5. Do not store or use the product in a high-temperature environment, including intense sunlight or heat.

6. Avoid drops, bumps, abrasions and impacts.

7. If there is any reason to believe that there is damage to the product, discontinue use immediately.

8. If you nd that the product is too hot, is emitting an odor, or is deformed, punctured or
exhibits any suspicious or abnormal behavior, discontinue use immediately and contact our
customer service.

1. Speaker Power Button

2. USB Charging Port

3. Volume + Button

4. LED Light Power Button

5. Charge-in Port

6. Bluetooth LED Indicator

7. Volume - Button

8. Battery LED Indicator

9. Speaker

10. Handle

11. LED Light

Appearance & Interface Description

1 4

5
6

7

8

9

10

11

2

3

Operation Instructions

1. Charging CampMate-2

• Use the provided cable to charge CampMate-2.

• Connect one end of the USB Cable provided to CampMate-2 and the other end of the
powercord to any 5V/2A USB Power Socket.

2. Checking the remaining power left in CampMate-2

• In order to view the remaining power left, press the LED Light Power Buttononce and view
the LED Battery Level Indicator

No of LED’s Active 1 2 3 4

% of power remaining <=25% <=50% <=75% <=100%

3. Charging USB chargeable devices using CampMate-2

• Plug the USB cable into the USB output port on CampMate-2 and the other end into the device.

4. Turning the LED Light On/O:

• Press and Hold the LED Light Power Button to turn on the LED Light

• Short press the LED Light Power Button to scroll through the LED light modes

• Press and Hold the LED Light Power Button to turn o the LED Light

5. Playing Music via Via Bluetooth

• Press and hold the “Speaker Power Button” until the LED Indicator starts ashing rapidly

• Turn on the Bluetooth function on your smartphone/tablet and search for “CampMate-2” in the
available device list.

• Pair the device to your smartphone/tablet

• Once connected the Bluetooth Indicator will stop ashing

• Press the Volume + button once to skip to the previous track

• Press the Volume - button once to skip to the next track

• Press and Hold the Volume + button to increase the volume

• Press and Hold the Volume - button to decrease the volume

Troubleshooting

1. CampMate-2 does not pair with a Bluetooth device:

• Check if the Bluetooth hardware on your device supports A2DP prole which is necessary for sound
transmission over Bluetooth.

2. Reseting the CampMate-2:

• Press the Volume + and Volume – buttons simultaneously to reset the CampMate-2

1 4

5
6

7

8

9

10

11

2

3

Descripción del Aspecto y la Interfaz

1. Botón de Encendido del Altavoz

2. Puerto de Carga USB

3. Botón para + volumen

4. Botón de Encendido de la Luz LED

5. Puerto de Carga

6. Indicador LED del Bluetooth

7. Botón para - volumen

8. Indicador LED de la Batería

9. Altavoz

10. Asa

11. Luz LED

Instrucciones de Operación

1. Cómo cargar el CampMate-2

• Use el cable proporcionado para cargar el CampMate-2.

• Conecte un extremo del Cable USB proporcionado a CampMate-2 y el otro extremo del
cable de corriente a cualquier tomacorriente USB de 5V/2A.

2. Cómo vericar la energía remanente que queda en CampMate-2

• Para ver la energía remanente que queda, oprima el Botón de Encendido de la Luz LED
una vez y vea el Indicador LED del Nivel de Batería

No. de LEDs activos 1 2 3 4

% de energía remanente <=25% <=50% <=75% <=100%

3. Cómo cargar dispositivos que se cargan por USB usando CampMate-2

• Enchufe el cable USB al puerto de salida USB en el CampMate-2 y el otro extremo al dispositivo.

4. Cómo encender/apagar la Luz LED:

• Oprima y retenga el Botón de Encendido de la Luz LED para encender la Luz LED

• Oprima brevemente el Botón de Encendido de la Luz LED para desplazarse a través de
los modos de luz LED

• Oprima y retenga el Botón de Encendido de la Luz LED para apagar la Luz LED

5. Cómo reproducir música mediante Bluetooth

• Oprima y retenga el “Botón de Encendido del Altavoz” hasta que el indicador de LED
empiece a parpadear rápidamente

• Encienda la función Bluetooth en su teléfono inteligente/tableta y busque “CampMate-2”
en la lista de dispositivos disponible.

• Conecte el dispositivo a su teléfono inteligente/tableta

• Una vez conectado, el Indicador de Bluetooth dejará de parpadear

• Oprima el botón + Volumen una vez para saltar a la pista anterior

• Oprima el botón - Volumen una vez para saltar a la pista siguiente

• Oprima y retenga el botón + Volumen para subir el volumen

• Oprima y retenga el botón - Volumen para bajar el volumen

Solución de problemas

1. CampMate-2 no se conecta con un dispositivo Bluetooth:

• Revise si el equipo Bluetooth en su dispositivo respalda perl A2DP que es necesario
para transmisión de sonido por Bluetooth.

2. Cómo reiniciar el CampMate-2:

• Oprima los botones + Volumen y - Volumen a la vez para reiniciar el CampMate-2

1 4

5
6

7

8

9

10

11

2

3

Aspect & Description Interface

1. Bouton Mise en Marche de l’Enceinte

2. Port de Charge USB

3. Bouton Volume +

4. Bouton Mise en Marche Lumière LED

5. Port de Charge Entrée

6. Voyant LED Bluetooth

7. Bouton Volume -

8. Voyant LED de Batterie

9. Enceinte

10. Poignée

11. Lumière LED

Mode d’Emploi

1. Chargement de la CampMate-2

• Utilisez le câble fourni pour charger la CampMate-2.

• Branchez une des extrémités du Câble USB qui est fourni sur la CampMate-2 et l'autre
extrémité du cordon d'alimentation à n'importe quelle Prise de Courant USB 5V/2A.

2. Vérication de l’énergie restante dans la CampMate-2

• Pour vérier l’énergie restante, appuyez une fois sur le Bouton LED de Mise en Marche
et visualisez l’indicateur du Niveau de la Batterie.

N° de Voyants LED Actifs 1 2 3 4

% de batterie restante <=25% <=50% <=75% <=100%

3. Chargement des dispositifs rechargeables USB à travers la CampMate-2

• Branchez le câble USB sur le port de sortie USB de la CampMate-2 et l'autre extrémité
sur l'appareil.
