Pro-Lite DIGI-Q User Manual

User Manual

What’s in the box
Ticket Dispenser Installation
Ticket Roll Installation
LED Queuing Unit Installation
Operation / Troubleshooting
Contact Us

What’s in the box?

1. LED queuing unit

2. Power adaptor

3. Wireless transmitter

4. Ticket number dispenser

5. Ticket dispenser hardware

o “L” bracket
o Swivel with mounting screws (4 pcs)

6. Ticket roll holder

7. Ticket number roll

Note: Some accessory items are stored in the actual product.

Ticket Dispenser Installation

1

2

3

1) Mount the “L” bracket on a flat sturdy surface.

Note: “L” bracket surface mounting screws are not included.

2) Using the included mounting screws, install the Swivel onto the “L” bracket.

3) Snap the swivel onto the Ticket Dispenser.
