SS-969 SMD Rework Station
User’s Manual
1st Edition, 2013
©2013 Copyright by Prokit’s Industries Co., Ltd.
SAFETY INSTRUCTIONS
WARNING
Warnings and cautions are placed at critical points in this manual to direct the operator’s attention to significant items. They are defined as follows:
WARNING: Failure to comply with a WARNING may result in serious injury or death.
CAUTION: Failure to comply with a CAUTION may result in injury to the operator, or damage to the items involved. Two examples are given below.
NOTE: A NOTE indicates a procedure or point that is important to the process being described.
EXAMPLE: AN EXAMPLE is given to demonstrate a particular procedure, point or process.
Be sure to comply with following WARNINGS and CAUTIONS for your safety.
WARNING
Do not change or disassemble any components related to this product, it may cause product damaged.
When you need to replace the fuse, be sure turn off the power before operating.
During working period, do not turn off the power suddenly, the heat gun should be placed on the heat gun holder until cool off after power turn off, otherwise it will damage the product
CAUTION
When the power is ON, the temperature of the hot air and the nozzle ranges from 100 to 450 (212 to 842 ). To avoid injury to personnel or damage to items in the work area, observe the following:
**Do not direct the hot air toward personnel or touch the metal parts near the nozzle.
**Do not use the product near combustible gases or flammable materials.
**Advise those in the work area that the unit can reach very high temperatures and should be considered potentially dangerous.
**Turn the power OFF when no longer using the Pro’sKit SS-969 or when leaving it unattended.
**Before replacing parts or storing the unit, allow the unit to cool and then turn the power OFF.
To prevent accidents and failures, be sure to take the following precautions:
1
**Do not strike the handpiece against hard surfaces or otherwise subject it to physical shock.
**Be sure the unit is grounded. Always connect power to a grounded receptacle.
**Do not disassemble the machine.
**Do not modify the unit.
**Use Pro’sKit provides replacement parts.
**Do not wet the unit or use the unit with wet hands.
**Remove power cord by holding the plug – not the wires.
**Make sure the work area is well ventilated.
**The Pro’sKit SS-969 is not intended for use by children or infirm persons without supervision.
**Children should be supervised to ensure that they do not play with the SS-969.
Packing list and name of parts
Name of Parts
|
|
|
|
Heat gun holder |
|
Temperature |
|
|
|||
Display |
|
|
|
|
Heat gun |
|
|
|
|||
Airflow |
|
||||
|
|
||||
adjustment |
|
|
|
|
|
|
|
|
|||
knob |
|
Temperature |
|||
|
|
|
|
|
|
Power |
|
adjustment button |
|||
|
|
||||
Switch |
|
|
|||
Packing List
SS-969 SMD Rework Station (include holder) x1
Heat Gun x1
Air nozzle x 3
Power cord x1
User’s manual x1
2
Features:
1.Microprocessor-controlled, closed circuit sensor design, high power and quick warm-up times
2.Adjustable air flow, air volume and temperature, suitable for a variety of applications.
3.Handle with sensor design switching work & sleep mode for real-time operation convenience.
4.Auto Cool-Off Process to prolong the life of heating element
5.Plastic shell, compact body, beautiful, small footprint.
6.Comes with brushless motor provides long service life, quiet in operation
7.Safe solder temperature-sensitive components, and won’t deform other plastic components. Also for heating shrink, viscidity removal, lacquer removal, preheating and more
Specification:
Model No. |
SS-969E |
|
SS-969E7 |
SS-969B |
SS-969H |
|
|
|
|
|
|
Power Input |
110V |
|
127V |
220V |
220V |
|
|
|
|
|
|
Power Consumption |
|
|
700W |
|
|
|
|
|
|
|
|
Temperature Range |
|
|
100-450 |
|
|
|
|
|
|
|
|
Air Volume |
|
|
120L/min Max |
|
|
|
|
|
|
|
|
Heating Element |
|
|
Metal Heating core |
|
|
|
|
|
|
|
|
Equipment noise |
|
|
<45dB |
|
|
|
|
|
|
|
|
Temperature Display |
|
|
LED |
|
|
|
|
|
|
|
|
Weight |
|
|
1.43kgs |
|
|
|
|
|
|
|
|
Plug Type |
E |
|
E |
B |
H |
|
|
||||
|
|
|
|
|
|
Machine Size(mm) |
|
170x170x140 (include holder) |
|||
|
|
|
|
|
|
Overall package(mm) |
|
280x182x170 |
|
|
|
|
|
|
|
|
|
Fuse Type |
250V/10A |
|
250V/10A |
250V/5A |
250V/5A |
|
|
|
|
|
|
3
Optional replacement
Replacement Nozzle
IC Package |
Model No. |
ID (mm) |
|
9SS-969-A1 |
Ø4.5 |
|
|
|
|
9SS-969-A2 |
Ø7.5 |
|
9SS-969-A3 |
Ø11.2 |
|
|
|
Replacement Heat Gun
|
Model No. |
Description |
Dimension |
|
5SS-969E-HG |
Heat Gun for |
225x60x40mm |
|
|
SS-969E (110V) |
(wire length |
|
|
|
115cm) |
|
5SS-969B-HG |
Heat Gun for |
|
|
|
SS-969B/H (220V) |
|
|
|
|
|
|
5SS-969E7-HG |
Heat Gun for |
|
|
|
SS-969E7 (127V) |
|
|
|
|
|
Application
1.Suitable for desoldering multiple components.
2.Ideal for heating shrink, viscidity removal, lacquer removal, preheating and more
Operation Instruction
1.Put the rework station ready and place handle on the holder.
2.Connect the power cord to the power receptacle on the back panel of the station.
3.Set the blast nozzle (large caliber nozzle preferred).
4.Switch the power on, the screen displays “- - -“, it represents standby mode. (Available in microcomputer with digital LED)
5.Press “▲”or “▼”button as to set up the temperature. 6.Adjust the airflow knob to set up the required air volume.
