Prokit's Industries MT-4012 User Manual

NOTE: This manual is for three models, which

CONTENTS

are distinguished by model A, B and C

hereinafter.

A B C

Emissivity

adjustable

Temperature

Alarming

1. Safety Information………….………….

2. Precautions……………………….……

3. Feature Locations……………………..

4. LCD Illustration………….……..………

5. Measurement Principle….……………

6. Measurement Method…………………

7. Distance to Spot Ratio……..…………

8. Emissivity………………………………

9. Temperature alarming function………

10. Specifications………………...………

11. Changing the Battery……….……….

12. Accessories…………………………..

1

1

2

4

7

7

9

9

13

13

14

15

1. Safety Information

● Avoid operating near strong electromagnetic

● Please read the following information carefully

before using the meter.

● Safety symbols:-

Danger/Important Information prompt.

Comply with CE safety standards.

This instrument is compatible with the following

standards:

EN61326-1

EN61010-1

EN60825-1

Warning!
Do not point laser directly at eye or
indirectly off reflective surfaces.

fields such as arc welders, induction furnaces,

etc.

● Do not expose thermometer to excessive

ambient temperatures.

● Keep the thermometer clean and avoid getting

dust into the detector’s optics.

● Do not use solvents to clean the meter.

3. Feature Locations

2. Precautions

● After abrupt ambient temperature changes,

allow instrument temperature to stabilize for 30

minutes before using for measurement.

1

2

1. Sighting Groove

4. LCD illustration

2. Laser orifice

3. Detector orifice

4. Tripod nut

5. Trigger

6. Battery cover

7. LCD

8. Laser button

9. Emissivity reduction button (Model B)

Model A:

1. Laser-On Indicator

2. Holding indicator

3. The first temperature display

4. Low power indicator

5. Average value indicator

Temperature reduction button (Model C)

10. Mode button

11. Emissivity addition button (Model B)

Temperature addition button (Model C)

12. Backlight button

13. °C/°F button

3

6. MAX/MIN indicator

7. The second temperature display

8. °F temperature unit

9. °C temperature unit

10. Emissivity display

11. Measurement indicator

4
