Powerware 3110 User Manual

POWERWARE 3110
250 VA600 VA
User's Guide
www.powerware.com
Class B EMC Statements
FCC Part 15
NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
ICES-003
This Class B Interference Causing Equipment meets all requirements of the Canadian Interference Causing Equipment Regulations ICES003.
Cet appareil numérique de la classe B respecte toutes les exigences du Reglement sur le matériel brouilleur du Canada.
Requesting a Declaration of Conformity
Units that are labeled with a CE mark comply with the following harmonized standards and EU directives:
Harmonized Standards: EN 50091-1-1 and EN 50091-2
EU Directives: 73/23/EEC, Council Directive on equipment designed for use within certain voltage limits
The EC Declaration of Conformity is available upon request for products with a CE mark. For copies of the EC Declaration of Conformity, contact:
Powerware Corporation Koskelontie 13 FIN-02920 Espoo Finland Phone: +358-9-452 661 Fax: +358-9-452 665 68
93/68/EEC, Amending Directive 73/23/EEC 89/336/EEC, Council Directive relating to electromagnetic compatibility 92/31/EEC, Amending Directive 89/336/EEC relating to EMC
Powerware is a registered trademark of Powerware Corporation Patriot is a registered trademark and Best Dock is a trademark of Best Power. Windows is a registered trademark of Microsoft Corporation.
Copyright 19992001 Powerware Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Powerware Corporation.
TABLE OF CONTENTS
1 Installation 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inspecting the Equipment 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Precautions 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Quick Startup 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
UPS Top and Side Panels 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Features 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Communication Port 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pinouts 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery Start Feature 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Network Transient Protector 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 UPS Maintenance 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
UPS and Battery Care 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storing the UPS 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing Batteries 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recycling the Used Battery 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Specifications 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Troubleshooting 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service and Support 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
i
Table of Contents
ii
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
C H A P T E R 1
INSTALLATION
This section explains:
Equipment inspection
Safety precautions
UPS installation
UPS top and side panels
Inspecting the Equipment
If any equipment has been damaged during shipment, keep the shipping cartons and packing materials for the carrier or place of purchase and file a claim for shipping damage. If you discover damage after acceptance, file a claim for concealed damage.
To file a claim for shipping damage or concealed damage: 1) File with the carrier within 15 days of receipt of the equipment; 2) Send a copy of the damage claim within 15 days to your service representative.
Safety Precautions
Read the following precautions before you install the UPS.
I M P O R T A N T S A F E T Y I N S T R U C T I O N S
SAVE THESE INSTRUCTIONS. This manual contains important instructions that you should follow during installation and maintenance of the UPS and batteries. Please read all instructions before operating the equipment and save this manual for future reference.
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
1
Installation
W A R N I N G
This UPS contains its own energy source (batteries). The output receptacles may
carry live voltage even when the UPS is not connected to an AC supply.
Do not remove or unplug the input cord when the UPS is turned on. This removes
the safety ground from the UPS and the equipment connected to the UPS.
To reduce the risk of fire or electric shock, install this UPS in a temperature and
humidity controlled, indoor environment, free of conductive contaminants. Ambient
temperature must not exceed 40°C (104°F). Do not operate near water or
excessive humidity (95% max).
With the exception of the user-replaceable battery, all servicing of this equipment
must be performed by qualified service personnel.
Before maintenance or repair, all connections must be removed. Before
maintenance, repair, or shipment, the unit must be completely switched off and unplugged or disconnected.
C A U T I O N
Important Notice: The UPS ground (earth) conductor carries leakage current from
the loads in addition to any leakage current generated by the UPS. This UPS generates no more than 0.5 mA of current (120V Model), or 1 mA of current (230V Model).
To limit the total leakage current to 3.5 mA, the load leakage must be limited to
3 mA on the 120V Model and 2.5 mA on the 230V Model.
If you do not know the load leakage current, replace the UPS power cord
(230V Model only) with a power cord that uses a locking plug with a minimum rating of 10A (such as IEC 309).
If you do not have a matching receptacle, consult an electrician to install the
proper receptacle.
The three-wire receptacle that you plug the UPS into must have a good
(low-impedance) ground (protective earth) connection to provide a safe path for leakage current.
2
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
Quick Startup
Installation
The Powerware 3110 provides protection against many power problems, including power outages. It also provides spike suppression and line noise filtering to protect your equipment.
1. On 230V Models, plug the UPS power cord into the input connector on the UPS side panel.
2. Plug the equipment to be protected into the UPS output receptacles.
DO NOT protect laser printers with the UPS because of the exceptionally high power requirements of the heating elements.
3. Start the UPS by pressing the
switch as shown in Figure 3 or Figure 4 on page 5. The Power indicator illuminates indicating that power is available from the UPS output receptacles.
The units beeps and the front panel LEDs illuminate several times. The green indicator remains on, indicating normal operation.
If the unit continues to beep, or if the green indicator is off even though input power is available from the wall outlet, see Troubleshooting" on page 15.
NOTE Let the unit charge the battery for at least 3 hours. You may use the unit while the battery charges, but the battery backup runtime will be reduced until the battery is fully charged. This will take up to 8 hours after a full discharge while the UPS is fully loaded.
4. Please fill out and return the warranty registration card. If you are in the USA or Canada and would like to activate the Transient Voltage Surge Suppression warranty, return the card within 10 days of installation.
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
3
Installation
UPS Top and Side Panels
Figure 1 and Figure 3 identify features of the 120V Model (USA) units, with attached input line cord. Figure 2 and Figure 4 identify features of the 230V Model (European) units, which have a connector for the input line cord as well as different output receptacles.
Fault Indicator
Output Receptacles
(Battery and Surge Protection)
Figure 1. 120V Model Top Panel
Fault Indicator
Power Indicator
Output Receptacles
(Surge Protection Only)
Power Indicator
(Battery and Surge Protection)
Output Receptacles
Output Receptacles
(Surge Protection Only)
Figure 2. 230V Model Top Panel
4
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
Installation
Network Transient Protector
Circuit Breaker Power Cord
Figure 3. 120V Model Side Panel (600 VA Shown)
Network Transient Protector
Circuit Breaker Input Connector
Figure 4. 230V Model Side Panel (600 VA Shown)
Communication Port
On/Standby Switch
Communication Port
On/Standby Switch
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
5
Installation
6
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
C H A P T E R 2
FEATURES
This section covers:
Using the communication port
Starting the UPS on battery
Communication Port
Powerware Corporation offers an accessory interface kit that allows you to connect many types of computer systems to the UPS communication port. For specific information on Powerware Corporation interface kits, call your service representative.
Pinouts
Contacts consist of open collector circuits capable of switching up to +30 Vdc, 6 mA resistive load.
Table 1. Communication Port Pin Assignment
Pin Signal Type Function
1 RS-232 Level Shutdown +12 Vdc signal held for 5 seconds on this pin shuts the UPS
down 120 seconds later. The UPS restarts after 15 seconds when utility power returns.
2 Not Used Not Used
3 Normally Open On-Battery Contact A normally open contact that closes 15 seconds (pulls to
Common) after the UPS switches to battery power.
4 Common The signal ground for all signal pins.
5 Normally Open Low-Battery-Alarm Contact A normally open contact that closes (pulls to Common)
during a Low Battery Alarm.
6 Normally Closed Low-Battery-Alarm Contact A normally closed contact that opens (releases from
Common) during a Low Battery Alarm. This tells some shutdown software when to start a computer shutdown.
7 Not Used Not Used
8 Normally Closed On-Battery Contact A normally closed contact that opens 15 seconds (releases
from Common) after the UPS switches to battery power.
9 Not Used Not Used
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
7
Features
Battery Start Feature
The Battery Start feature allows you to turn on the UPS when utility power is not available. The battery-start range is up to about 40% of nominal input; otherwise, the UPS displays an input voltage fault and the alarm beeps.
Network Transient Protector
The Network Transient Protector is located on the side panel and has jacks labeled IN and OUT. This feature accommodates a RJ11 telephone connector that provides protection for modems, fax machines, or other telecommunications equipment. As with most modem equipment, it is not advisable to use this jack in digital PBX (Private Branch Exchange) environments.
Low voltage models can also accommodate a single RJ45 (10BaseT) network connector.
Connect the input connector of the equipment you are protecting to the jack labeled IN. Connect the output connector to the jack labeled OUT.
8
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
C H A P T E R 3
UPS MAINTENANCE
This section explains how to:
Care for the UPS and batteries
Replace the batteries
Recycle used batteries
UPS and Battery Care
For the best preventive maintenance, keep the area around the UPS clean and dustfree. If the atmosphere is very dusty, clean the outside of the system with a vacuum cleaner.
For full battery life, keep the UPS at an ambient temperature of 25°C (77°F).
Storing the UPS
If you store the UPS for a long period, recharge the battery every 6 months by plugging the UPS into a power outlet.
Replacing Batteries
The Powerware 3110's battery is user-replaceable. Before replacing the battery, make sure that you read the safety information below.
Batteries can present a risk of electrical shock or burn from high short circuit
current. The following precautions should be observed: 1) Remove watches, rings, or other metal objects; 2) Use tools with insulated handles; 3) Do not lay tools or metal parts on top of batteries.
ELECTRIC ENERGY HAZARD. Do not attempt to alter any battery wiring or
connectors. Attempting to alter wiring can cause injury.
Replace batteries with the same number and type of batteries as originally
installed in the UPS.
DO NOT DISCONNECT the batteries while the UPS is in Battery mode.
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
W A R N I N G
9
UPS Maintenance
C A U T I O N
The 230V Models require replacement by qualified service personnel.
1. Contact your service representative to order a replacement battery. It must be the same type and rating as the original battery (see Table 3 on page 14).
2. Switch off and unplug the protected equipment from the UPS.
3. Turn off the UPS and disconnect the power cord.
4. Turn the UPS upside down.
Battery
Battery Cover
10
Figure 5. Removing the Battery Cover and Battery
5. Remove the battery cover:
Models 425 and 600: Use a screwdriver to remove the four screws
securing the battery cover and lift the battery cover off.
Model 250: Press down on the battery cover tabs and slide the
battery cover off of the end of the case.
6. Lift the battery up and out of the case.
7. Disconnect the red and black cables from the used battery.
8. Replace the battery. See Recycling the Used Battery" for proper
disposal.
9. Reconnect the cables to the new battery; red to positive ( black to negative (
), and slide the battery back into the case.
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
+),
10. Replace the battery cover by pushing the cover until it snaps
into place securely. Replace any battery cover screws that were removed to access the battery.
11. Turn the UPS right side up. Reconnect the UPS power cord and turn the unit on.
12. Reconnect the equipment. Switch on the protected equipment one piece at a time.
Recycling the Used Battery
Contact your local recycling or hazardous waste center for information on proper disposal of the used battery.
Do not dispose of the battery or batteries in a fire. Batteries may explode. Proper
disposal of batteries is required. Refer to your local codes for disposal requirements.
Do not open or mutilate the battery or batteries. Released electrolyte is harmful to
the skin and eyes. It may be toxic.
UPS Maintenance
W A R N I N G
Do not discard the UPS or the UPS batteries in the trash. This product contains sealed, leadacid batteries and must be disposed of properly. For more information, contact your local recycling or hazardous waste center.
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
C A U T I O N
11
UPS Maintenance
12
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
C H A P T E R 4
SPECIFICATIONS
Powerware Corporation reserves the right to change specifications without prior notice.
Table 2. Electrical
120V Model 230V Model
Nominal Voltage 120V 230V
Power Factor 0.67
Voltage Range Online: 100V142V
On Battery: 0V100V and 142V160V
Nominal Frequency 50/60 Hz auto-sensing
57-63 Hz (60 Hz) 47-53 Hz (50 Hz)
Efficiency (Normal mode)
Noise Filtering Full-time EMI/RFI filtering
Overcurrent Protection Resettable circuit breaker
Connections Attached 5-15P power cord IEC 320-C14 input connector
Power Levels (rated at nominal inputs)
Total Output Current 10A maximum
Load Compatibility Switch-mode power supply or resistive load Output Frequency
(Battery mode)
Connections (4) 5-15 receptacles with UPS
PW3110 250: 250 VA, 168W PW3110 425: 425 VA, 425W PW3110 600: 600 VA, 400W
50/60 Hz ±1 Hz of nominal frequency
and surge protection
(2) 5-15 receptacles with surge
protection only
On Battery: 0V192V and 278V290V
> 95%
(2) IEC 320-C14 receptacles with surge
Online: 192V278V
Input fault current: 15A maximum
PW3110 250i: 250 VA, 1680 PW3110 425i: 425 VA, 425W PW3110 600i: 600 VA, 400W
(4) IEC 320-C14 receptacles with UPS
and surge protection
protection only
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
13
Specifications
Table 3. Battery
Configuration 250 VA: (1) 12V or (2) 6V, 4.2 Ah internal battery(s)
425 VA: (1) 12V, 7 Ah internal battery
600 VA: (1) 12V, 9 Ah internal battery
Voltage 12 Vdc
Type Sealed, maintenancefree, valveregulated, leadacid
Charging 8 hours to 95% capacity with output fully loaded
Monitoring Advanced monitoring for earlier failure detection and warning
Backup Time 250-425 VA: 3 minutes at full load; 5 minutes typical load
600 VA: 2.5 minutes at full load; 5 minutes typical load
Transfer Time 4 ms typical
Table 4. Weights and Dimensions
UPS Dimensions (HxWxD)
UPS Weight 250 VA: 3.0 kg (6.6 lb)
250 VA: 15.0 x 5.9 x 39.3 cm (5.9" x 2.3" x 15.5")
425-600 VA: 17.2 x 7.9 x 37.6 cm (6.8" x 3.1" x 14.8")
425 VA: 4.2 kg (9.2 lb)
600 VA: 4.3 kg (9.4 lb)
Table 5. Environmental and Safety
120V Model 230V Model
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -15°C to 50°C (-5°F to 122°F)
If the UPS is stored, the batteries should be recharged every 6 months. If stored above 25°C
(77°F), battery life is reduced and should be recharged more often.
Ventilation Air around the unit must be free of dust, chemicals, or other materials
that corrode or contaminate.
Relative Humidity 595% RH noncondensing
Audible Noise Less than 40 dBA typical at one meter
Surge Energy Rating 450 joules
Surge Suppression ANSI C62.41 Category A (formerly IEEE 587) IEC 61000-4-5, Level 3
Safety Conformance UL 1778; UL 497A;
CAN/CSA C22.2, No. 107.1
Safety Markings UL, cUL TUV/GS, CE
EMC (Class B) FCC Part 15, ICES-003 EN 50091-2
14
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
EN 50091-1-1 and IEC 60950
C H A P T E R 5
TROUBLESHOOTING
The front panel LEDs and an audible beep indicate the UPS status (see Table 6). The UPS beeps whenever the unit is on battery power or an alarm is present.
Table 6. Troubleshooting
Alarm or Condition Possible Cause What to Do
Normal operation. None. The UPS is operating in Normal mode.
Line loss due to:
1 beep every 5 seconds.
2 beeps every 5 seconds.
Utility power outage.Loose plug connection.Tripped circuit breaker.Power cord failure.
Low battery alarm; shutdown is imminent.
The battery needs charging or service.
Wait for utility power to return.Check the power cord connections.Reset the circuit breaker.Contact your service representative for a new power
cord.
Prepare for a UPS shutdown. Save your work and turn off your equipment.
The unit automatically restarts when acceptable power returns.
Turn the UPS off and plug the UPS into a power outlet for 24 hours to charge the battery. Turn the UPS on to test the battery. If the alarm still beeps, see Replacing the Battery" on page 9 to replace the battery.
3 beeps every 5 seconds.
The battery is discharged and battery power is not available.
3 beeps every 5 minutes.
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
The UPS automatically recharges the battery. The alarm clears when the battery is recharged.
NOTE: If the UPS has not recharged the battery after
24 hours, the alarm changes to 3 beeps every 5 seconds and the battery must be replaced. See Replacing the Battery" on page 9 to replace the battery.
15
Troubleshooting
What to DoPossible CauseAlarm or Condition
Power requirements exceed the UPS capacity.
1 beep every half second.
Output short circuit. Turn off or unplug the equipment connected to the UPS.
Input voltage is out of range when the UPS is turned on.
Continuous beep.
UPS fault. Contact your service representative.
Service and Support
If you have any questions or problems with the UPS, call your Local
Distributor
and ask for a UPS technical representative.
In the United States 1-800-365-4892 In Canada 1-800-461-9166 All other countries 1-919-870-3149
Please have the following information ready when you call the Help Desk:
Model numberSerial numberVersion number (if available)Date of failure or problemSymptoms of failure or problemCustomer return address and contact information
If repair is required, you will be given a Returned Material Authorization (RMA) Number. This number must appear on the outside of the package and on the Bill Of Lading (if applicable). Use the original packaging or request packaging from the Help Desk or distributor. Units damaged in shipment as a result of improper packaging are not covered under warranty. A replacement or repair unit will be shipped, freight prepaid for all warrantied units.
Remove some of the equipment from the UPS. You may need to obtain a larger capacity UPS.
Turn off the UPS until acceptable input voltage restored.
or the Help Desk at one of the following telephone numbers
16
NOTE For critical applications, immediate replacement may be available. Call the
Help Desk for the dealer or distributor nearest you.
Powerware® 3110 User's Guide LTM-XXXX A Draft 03/01/2001
Loading...
