Powersolve TMH User Manual

www.powersolve.co.uk

Powersolve Electronics Ltd. 8A, Arnhem Road, Newbury, RG14 5RU. England

Tel :[phone] Fax: [phone] Email: [e-mail]

DC/DC Converters

Bottom view

12 546

1.25

2.54

0.5

2.3 2.54

19.5 (0.77)

5.08 2.54

0.5 (0.02)

10.2 (0.4)

(0.02)

(0.1) (0.1)(0.1)

(0.09)

(0.2)

7.5 (0.30)

(0.05)

0.5 (0.02)

3.2
(0.13)

0.25 (0.01)

() = Inches

TMH Series, 2 Watt

= Single-in-Line (SIL) Package

= Single and Dual Output Models

= I/O Isolation 1000 VDC

= High Efficiency

= Operating Temperature Range –40°C to +85°C

= Industry Standard Pinout

100% Burn-in

=

Line regulation: non regulated

Load regulation: ±10% max.

Ripple & Noise: – 5 Vin models: < 75 mVpk-pk (20 MHz BW)

– 12/24 Vin models: <150 mVpk-pk (20 MHz BW)

Short circuit protection:

Efficiency: 81% typ. 5 VDC output models: 78% typ.

Operating temperature range: –40°C … +85°C

I/O isolation voltage: 1000 VDC

Case: plastic (UL 94V-0 rating)

limited 1 sec.

above 70°C derating 3%/°C

Models

Order Code Input voltage Output voltage Output current

TMH 0505S 5 VDC 400 mA

TMH 0512S 12 VDC 165 mA

TMH 0515S 5 VDC ± 10 % 15 VDC 130 mA

TMH 0505D ±5 VDC ±200 mA

TMH 0512D ±12 VDC ±80 mA

TMH 0515D ±15 VDC ±65 mA

TMH 1205S

TMH 1212S 12 VDC 165 mA

TMH 1215S

TMH 1205D ±5 VDC ±200 mA

TMH 1212D ±12 VDC ±80 mA

TMH 1215D ±15 VDC ±65 mA

TMH 2405S 5 VDC 400 mA

TMH 2412S 12 VDC 165 mA

TMH 2415S 24 VDC ± 10% 15 VDC 130 mA

TMH 2405D

TMH 2412D

TMH 2415D ±15 VDC ±65 mA

max.

mA

VDC

5

12 VDC ± 10% 15 VDC 130 mA

VDC ±200 mA

5

±

±12 VDC ±80 mA

400

Pin-Out

Pin Single output Dual output

1 + Vin (Vcc) + Vin (Vcc)

2 – Vin (GND) – Vin (GND)

4 – Vout – Vout

5 No pin Common

6 + Vout + Vout
