Duecanali DSP+D Series
2-Channel High-Performance Amplifier Platform with DSP and Dante™
Excellent sound quality and
ample output power result from
Powersoft’s unique approach to
Class D amplication, making
the Duecanali DSP+D Series
ideal for the main system in any
venue where performance is
priority.
Providing access to all relevant
amplier parameter yet easily
set up, the Duecanali DSP+D
Series is versatile in use,
providing status feedback via
its front panel LED display or a
connected PC running Armonía
Pro Audio Suite™ software.
Powersoft’s legendary
efciency saves valuable
energy, keeping both
operational cost and carbon
footprint at a minimum: the
Duecanali DSP+D Series
shines with outstandingly low
power consumption and heat
dissipation, with direct positive
effects on investment – not to
mention the benets for the
environment and a more ecofriendly planet.
A fully integrated state-of-theart DSP yields extensive system
management functionality.
In addition to sound shaping
and limiter functions in unique
Powersoft style, the DSP
hardware and Armonía Pro
Audio Suite™ software enable
compliance with IEC 60849
for the crucial requirements of
sound systems for emergency
purposes.
The Duecanali DSP+D is
designed to work with lo-Z
(from 2 �) and with 70V/100V
distributed lines: any mixed
conguration of low and high
impedance output loads
can be realized, making the
Duecanali DSP+D suitable for
all application in installed sound
reinforcement systems.
DSP+D versions of the
Duecanali series extends
system performance with the
support of Dante™ digital audio
networking architecture and
the on board high-end signal
processing.
Small to Medium-scale venues
Main systems, central or
distributed, subwoofers, hi-Z/lo-Z
Emergency systems (IEC 60849)
Stadiums, arenas
Theaters, concert halls
Houses of worship
Convention centers
Amusement parks, themed
entertainment
Cruise ships
Data are subject to change without notice
© 2018 Powersoft | All right reserved
DO000218.03_DS_Duecanali_DSP+D
Duecanali DSP+D Series
2-Channel High-Performance Amplifier Platform with DSP and Dante™
Specifications
Channel Handling
Number of output channels
Number of input channels
Analog 2 Phoenix MC 1,5/6-ST-3,81
Dante™* 2 1 x RJ45
2 Hi-Z or Lo-Z
(bridgeable per ch. pair)
Phoenix PC 5/4-STF1-7,62
Audio
Gain
Input sensitivity @ 8 Ω 26 dB 2.84 4.08 5.03 Vrms
Input sensitivity @ 8 Ω 29 dB 2.01 2.89 3.56 Vrms
Input sensitivity @ 8 Ω 32 dB 1.42 2.04 2.52 Vrms
Input sensitivity @ 8 Ω 35 dB 1.01 1.45 1.79 Vrms
S/N (20 Hz - 20 kHz @ 8 Ω) >106 >109 >111 dB(A)
Max input level 20 dBu
Frequency Response 20 Hz - 20 kHz ±0.5 dB, 1 W @ 8 Ω
Crosstalk (1 kHz) typical -70 dB
Input impedance 20 kΩ balanced
THD+N (from 0.1 W to Full Power) < 0.1% (typical < 0.05%)
DIM (from 0.1 W to Full Power) < 0.05%
Slew Rate > 50 V/µs @ 8 Ω, input lter bypassed
Damping Factor > 1000 @ 8 Ω, 20 Hz - 100 Hz
804 1604 4804
DSP
AD converters
DA converters
Sample rate converter
Internal precision 32 bit oating point
Latency 2.5 ms xed latency architecture
Memory/Presets 128 MB (RAM) plus 512 MB ash for presets
Delay 2 s (input) + 100 ms (output) for time alignment
Equalizer
Crossover
Limiters TruePower™, RMS voltage, RMS current, Peak limiter
Damping control
Linkwitz-Riley, Bessel: 6 dB/oct to 48 dB/oct (IIR)
24 Bit Tandem™ @ 48 kHz
125 dB-A Dynamic Range - 0.005 % THD+N
24 Bit Tandem™ @ 48 kHz
117 dB-A Dynamic Range - 0.003 % THD+N
24 Bit @ 44.1 kHz to 192 kHz
140 dB Dynamic Range - 0.0001 % THD+N
Raised-cosine, custom FIR, parametric IIR:
peaking, hi/lo-shelving, all-pass,
band-pass, band-stop, hi/lo-pass
linear phase (FIR), Butterworth,
Active DampingControl™ and
LiveImpedance™ measurement
Output Stage 804 1604 4804
Maximum output power per channel @ 8 Ω 400 W 800 W 1250 W
Maximum output power per channel @ 4 Ω 400 W 800 W 2400 W
Maximum output power per channel @ 2 Ω 500 W 1000 W 3000 W
Maximum output power @ 4 Ω Bridged 1000 W 2000 W 6000 W
Maximum output power @ 8 Ω Bridged 800 W 1600 W 4800 W
Maximum output power @ Hi-Z distributed line 100 V 400 W 800 W 2400 W
Maximum output power @ Hi-Z distributed line 70 V 400 W 800 W 2400 W
Maximum unclipped output voltage @ 8 Ω 80 V
Maximum output current 39 A
The power gure is calculated by driving and loading symmetrically all the channels:
uneven loads allow to achieve higher performances.
Power & Thermal
Power 23.0 23.0 32.5 W
Idle
@ 115 V
1/8
Power
@ 4Ω
Idle
@ 230 V
1/8
Power
@ 4Ω
Nominal voltage (±10%) 100-240 V @ 50-60Hz
AC Mains connector
Current Draw 0.34 0.34 0.31 A
Thermal Loss 78 78 111 BTU/h
Power 148 267 780 W
Current Draw 1.4 2.5 7.0 A
Thermal Loss 162 229 613 BTU/h
Power 22.5 23.3 32.8 W
Current Draw 0. 21 0.21 0.30 A
Thermal Loss 77 79 112 BTU/h
Power 147 274 755 W
Current Draw 0.9 1.5 3.9 A
Thermal Loss 161 251 528 BTU/h
Power supply Universal regulated switch mode with PFC, SRM
Operating Voltage 60-264 V (with reduced power below 90 V)
804 1604 4804
IEC C20 inlet (20 A max)
region-specic power cord provided
peak
peak
115 V
45 A
peak
peak
142 V
80 A
peak
rms
rms
rms
rms
Networking
Standards compliance auto-sensing Fast Ethernet (IEEE 802.3u, 100 Mbit/s)
Supported topologies Star
Remote interface Armonía Pro Audio Suite™
Construction
Dimensions
Weight 7 Kg (15 lb)
483 x 44.5 x 358 mm
19.0 x 1.75 x 14.1 in
peak
Powersoft S.p.A.
Via Enrico Conti, 5 - 50018 Scandicci (FI) Italy
Tel: +39 055 735 0230 - Fax: +39 055 735 6235
www.powersoft-audio.com
