Router Lift Accessories for PM2000B Table Saw
6827041B – Wood Extension Table with Router Cutout
737014 – Router Fence
737013 – Power Switch with Mounting Bracket
The Wood Extension Table with Router Cutout, Router Fence, and Power Switch, are designed for use with the
#737000 Model JRL-912 Router Lift (not included). See your dealer to order.
Refer to Accu-Fence manual M-2195079B that accompanied your PM2000B table saw for instructions on
mounting the wood table to your table saw. Manuals may also be found on our website, www.powermatic.com
Once the Wood Extension Table is installed, use the following exploded views to help assemble the Router
Fence.
Before assembling or operating these accessories, know and follow all instructions
and safety warnings that accompanied your table saw, router lift, rip fence system, and router. Failure
to comply may cause serious injury!
WARNING: This product can expose you to chemicals including lead which is known to the State of
California to cause cancer and birth defects or other reproductive harm. For more information go to
http://www.p65warnings.ca.gov.
WARNING: Drilling, sawing, sanding or machining wood products generates wood dust and other
substances known to the State of California to cause cancer. Avoid inhaling dust generated from wood
products or use a dust mask or other safeguards for personal protection.
Wood products emit chemicals known to the State of California to cause birth defects or other reproductive
harm. For more information go to http://www.p65warnings.ca.gov/wood.
Powermatic
427 New Sanford Road
LaVergne, Tennessee 37086 Part No. M-6827041B
Ph.: 800-274-6848 Edition 2 05/2019
www.powermatic.com Copyright © 2017 Powermatic
Replacement Parts
To order parts or reach our service department, call 1-800-274-6848 Monday through Friday, 8:00 a.m. to 5:00
p.m. CST. Having the Model Number and Serial Number of your machine available when you call will allow us
to serve you quickly and accurately. Non-proprietary parts, such as fasteners, can be found at local hardware
stores, or may be ordered from Powermatic. Some parts are shown for reference only, and may not be
available individually.
6827041B Router Table Assembly
5
5
5
5
5
5
3
5
5
3
10
78
7
6
2
5
5
4
1
11
5
5
7
5
5
9
8
7
6
Index No Part No Description Size Qty
.................. 6827041B .................. Wood Ext. Table 30.5 x 33 w/Router Cutout (#1 thru 10) .................................
1 ................ .................................. Wood Ext. Table (RE: 6827041B) ........................... ...................................... 1
2 ................ F001225 .................... Phillips Flat Hd Mach Screw .................................... M6-1.0 x 13 ................... 2
3 ................ F010966 .................... Socket Hd Flat Screw BO ........................................ M6-1.0 x 30 ................... 2
4 ................ JRLS-602 .................. Phillips Flat Hd Wood Screw ................................... M7 x 40 ....................... 10
5 ................ F011316 .................... Phillips Flat Hd Tap Screw ...................................... #10 x 5/8” .................... 20
6 ................ PRL-106 .................... Scale Plate .............................................................. ...................................... 2
7 ................ F011821 .................... Phillips Pan Hd Tap Screw ...................................... M3 x 10 ......................... 4
8 ................ PRL-108 .................... Scale ........................................................................ ...................................... 2
9 ................ PRL-109 .................... T-Track .................................................................... ...................................... 2
10 .............. PRL-110 .................... T-Slot Guide Rail ..................................................... ...................................... 1
11 .............. F011317 .................... Phillips Pan Hd Tap Screw ...................................... #10 x 5/8” ...................... 6
737014 Router Fence Assembly
737013 Power Switch with Mounting Bracket
2
3
5
8
9
7
4
21
22
21
5
23
24
25
6
5
6
6
5
12
4
4
11
10
6
5
6
5
4
9
2
5
1
7
8
Index No Part No Description Size Qty
.................. 737014 ...................... Router Fence Assembly for PM2000B (#1 thru 12) . ........................................
1 ................ PRL-201 .................... Router Table Fence ................................................. 780mm (30-3/4”) ........... 1
2 ................ JRL912-401 ............... Lock Handle ............................................................. M8 ................................. 2
3 ................ PRL-203 .................... Scale ........................................................................ 780mm (30-3/4”) ........... 1
4 ................ JRL912-403 ............... T-Bolt ....................................................................... ...................................... 8
5 ................ TS-1550061 .............. Flat Washer ............................................................. M8 ............................... 10
6 ................ JRL912-406 ............... Lock Knob ................................................................ M8 ................................. 8
7 ................ JRL912-407 ............... Lock Nut .................................................................. M8 ................................. 2
9 ................ PRL-209 .................... Sub-Fence ............................................................... 390 mm (15-11/32”) .... 2
10 .............. JRL912-410 ............... Router Bit Guard ...................................................... ...................................... 1
11 .............. JRL912-411 ............... Fence Spacer .......................................................... ...................................... 2
12 .............. JRL912-432 ............... Dust Port .................................................................. ...................................... 1
Index No Part No Description Size Qty
.................. 737013 ...................... Power Switch with Table Saw Mounting Bracket (#21 thru 25) ........................
21 .............. F001226 .................... Phillips Pan Hd Machine Screw BO ........................ M5-0.8×33 ..................... 2
22 .............. PRL-300 .................... Mounting Bracket ..................................................... ...................................... 1
23 .............. 5AD-D04A ................. Phillips Pan Hd Machine Screw ............................... M5-0.8×8 ....................... 4
24 .............. 737006 ...................... On/Off Switch (includes #5) ..................................... 15A 125V ...................... 1
25 .............. JRL912-224 ............... Power Cord .............................................................. 15 mm²×3C ................... 1
Additional Accessories:
8 ................ PRL-208 .................... Shims for Sub-Fence (set of 2) ................................ 338mm ...........................
.................. 737010 ...................... Vertical Feather Board Assembly (set of 2) ............. ........................................
.................. 737011 ...................... Horizontal Feather Board Assembly (set of 2) ......... ........................................
.................. 737008 ...................... Flip Stop Assembly .................................................. ........................................
Warranty and Service
Powermatic® warrants every product it sells against manufacturers’ defects. If one of our tools needs service or
repair, please contact Technical Service by calling 1-800-274-6846, 8AM to 5PM CST, Monday through Friday.
Warranty Period
The general warranty lasts for the time period specified in the literature included with your product or on the official
Powermatic branded website.
Powermatic products carry a limited warranty which varies in duration based upon the product. (See chart
below)
Accessories carry a limited warranty of one year from the date of receipt.
Consumable items are defined as expendable parts or accessories expected to become inoperable within a
reasonable amount of use and are covered by a 90 day limited warranty against manufacturer’s defects.
Who is Covered
This warranty covers only the initial purchaser of the product from the date of delivery.
What is Covered
This warranty covers any defects in workmanship or materials subject to the limitations stated below. This warranty
does not cover failures due directly or indirectly to misuse, abuse, negligence or accidents, normal wear-and-tear,
improper repair, alterations or lack of maintenance. Powermatic woodworking machinery is designed to be used with
Wood. Use of these machines in the processing of metal, plastics, or other materials outside recommended
guidelines may void the warranty. The exceptions are acrylics and other natural items that are made specifically for
wood turning.
Warranty Limitations
Woodworking products with a Five Year Warranty that are used for commercial or industrial purposes default to a
Two Year Warranty. Please contact Technical Service at 1-800-274-6846 for further clarification.
How to Get Technical Support
Please contact Technical Service by calling 1-800-274-6846. Please note that you will be asked to provide proof
of initial purchase when calling. If a product requires further inspection, the Technical Service representative will
explain and assist with any additional action needed. Powermatic has Authorized Service Centers located throughout
the United States. For the name of an Authorized Service Center in your area call 1-800-274-6846 or use the Service
Center Locator on the Powermatic website.
More Information
Powermatic is constantly adding new products. For complete, up-to-date product information, check with your local
distributor or visit the Powermatic website.
How State Law Applies
This warranty gives you specific legal rights, subject to applicable state law.
Limitations on This Warranty
POWERMATIC LIMITS ALL IMPLIED WARRANTIES TO THE PERIOD OF THE LIMITED WARRANTY FOR EACH
PRODUCT. EXCEPT AS STATED HEREIN, ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE ARE EXCLUDED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW
LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
POWERMATIC SHALL IN NO EVENT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY, OR
FOR INCIDENTAL, CONTINGENT, SPECIAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF
OUR PRODUCTS. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
Powermatic sells through distributors only. The specifications listed in Powermatic printed materials and on the official
Powermatic website are given as general information and are not binding. Powermatic reserves the right to effect at
any time, without prior notice, those alterations to parts, fittings, and accessory equipment which they may deem
necessary for any reason whatsoever.
Product Listing with Warranty Period
90 Days – Parts; Consumable items
1 Year – Motors, Machine Accessories
2 Year – Woodworking Machinery used for industrial or commercial purposes
5 Year – Woodworking Machinery
NOTE: Powermatic is a division of JPW Industries, Inc. References in this document to Powermatic also apply to
JPW Industries, Inc., or any of its successors in interest to the Powermatic brand.
