Polaroid XSA-01010B User Manual

Digital Photo Picture Frame

User’s Manual

Questions? Need some help?

This manual should help you understand your new product. If you have
questions, please call our toll-free number found on the insert with this icon:

Or visit www.polaroid.com.

Important Safety Instructions

CAUTION: These servicing instructions are for use by qualied service personnel only. To

reduce the risk of electric shock, do not perform any servicing other than that contained in the
operating instructions unless you are qualied to do so.

Note: Do not touch the color TFT LCD screen by hand directly.

Proper Handling of the Digital Photo Picture Frame

Always handle the Digital Photo Picture Frame carefully. Avoid touching the LCD screen as
natural skin oils are very difcult to remove.

Always position the Digital Photo Picture Frame on a stable and level surface. Unstable
surfaces can cause the Digital Photo Picture Frame to topple and fall, resulting in possible
damage or injury.

Avoid exposing the Digital Photo Picture Frame to direct sunlight or high temperatures, which
can damage or shorten its life. Do not place the unit near heat sources such as radiators, heat
registers, or other appliances that generate heat. Orient the Digital Photo Picture Frame away
from direct sunlight to reduce glare.

Avoid exposing the Digital Photo Picture Frame to rain, water, moisture or high humidity. Do not
place it in a bathroom or kitchen near a sink or where it may come in contact with water.

Never place heavy or sharp objects on the LCD panel, frame, or power cord.

Overloading Outlets

Do not overload electrical power sources when using the Digital Photo Picture Frame.
Overloading wall outlets, circuits, or extension cords can result in overheating, re, or electric
shock. Use only grounded or polarized outlets.

Power Cord Protection

To minimize wear on the power supply cord, the power supply cord should be routed away
from foot trafc and contact with other objects. Do not route the power cord under rugs or
carpeting. The cord should never be severely bent, pinched, or twisted. Periodically inspect
the power cord and each end of the cord for wear or damage. Unplug and replace the cord if
it is damaged.

Ventilation

Slots and openings on the Digital Photo Picture Frame are provided for ventilation purposes.
To ensure proper ventilation and reliable operation of the product do not place Digital Photo
Picture Frame on a bed, sofa, rug or similar surface. Do not place it in an enclosed space such
as a bookcase, unless proper ventilation is provided.

1

Controls and Basic Instructions

CONGRATULATIONS on your purchase of your Polaroid Digital Photo Picture Frame. Please

read carefully and follow all instructions in the manual and those marked on the product before
rst use. Failing to follow these warnings could result in personal injury or damage to the
device. Remember to keep this User’s Manual in a convenient location for future reference.

Important: Save the original box and all packing material for future shipping needs.

Controls

Secure Digital™,
Multi Media Card™,
Memory Stick™,
Memory Stick Duo™

USB Host Port
for USB Flash Drives

Menu

OK

Up

Down

Play

Forward

Macrophone

AC Power Input

2

Backward

Lock

Adjustable Base

Power

Remote Control

Remote Control

Card Select

Setup MP3 Select

Rotate

Slide Show

Exit

Display Type

Mark

Up Arrow

Right ArrowLeft Arrow

Down Arrow

3

Quick Start

Quick Start Instructions

1. Plug the AC adapter into the Digital Photo Picture Frame and plug it into a wall outlet.

2. Insert a memory card into the slot or insert peripheral USB equipment into USB host:

Memory Card Slot: Secure Digital™, MultiMedia Card™, Memory Stick™, Memory Stick

Duo™

3. Press POWER button to power on the device.

4. Once the Digital Photo Picture Frame has been turned on, the unit will enter the “Select

Card” page automatically.

5. Press the

button to enter “Select Mode” page.

6. Press the

7. When selecting Photo mode, following step 6, press the

and press the Play ▶II button to view it in full screen. Press the ▶I button to go to the next

picture or press the

8. When selecting Music mode, following step 6, press the

le and press the Play ▶II button to play the selected music. Press the ▶II button to pause

when playing , press it again to resume.

9. When viewing a picture, press the Play ▶II button again to enlarge the current picture. In the

zoom state, press the

10. Press and hold the MENU button for one second to access the On Screen Display (OSD).

Press the or button to choose an item and press the Play ▶II button to enter. Press

the or button to choose an option and press the Play OK button to conrm your

choice.

▶I

▶I

▶I

or

button to select one type of memory cards and press the Play ▶II

▶I

or

button to select a mode and press the Play ▶II button to enter.

▶I

or

▶I

▶I

button to go back to the previous picture.

UP

▶I

,

▶I

, or button to move the picture accordingly.

button to select a picture

or DOWN button to select a mp3

4

Controls and Basic Instructions

Buttons on the Remote Control

SETUP BUTTON Press to select the menu for changing

settings.

CARD SELECTION BUTTON Press to choose a different
memory card.

EXIT BUTTON hold down for one second to enter the On
Screen Display menu, press again to exit.

MUSIC SELECT BUTTON Press to enter Music mode

SLIDE SHOW BUTTON Press to start/stop a photo slideshow

ROTATE BUTTON Press to rotate photos 90 degrees

clockwise on screen

DISPLAY BUTTON Press to toggle from 4:3 to 16:9 aspect

ratio

MARK BUTTON Press to mark your favorite pictures for a
slide show

ZOOM BUTTON Press to increase zoom up to 4x

ENTER BUTTON Press to conrm your slection and play still

images

BUTTON Press to move up when selecting les on your

screen.

BUTTON Press to move left when selecting les on your

screen.

BUTTON Press to move right when selecting les on your

screen.

BUTTON Press to move down when selecting les on your

screen.

5

Controls and Basic Instructions

Control Button Functions

All function settings for your Digital Photo Picture Frame can be controlled via the buttons
located on the top of the frame. You will be able to access the On Screen Display (OSD) at
any time, except when in the Slide Show Mode, by simply holding down the “EXIT” button for
one second.

OSD Menus Sub-Menus Description

Full Screen On Pictures display in full screen or not

Off

Slide Show Effect Off Select style of transition

Fade

Shutter

Cross Comb

Mask

Brick

Dissolve

Bar

Random

Slide Show Speed Fast Speed of slide show

Normal

Slow

Slide Show Shufe On

Off

Rotate -- Rotate the selected picture by 90 degrees

Language English

Italian
German
French
Spanish
Portuguese
Dutch

Auto Slide Set Off

30 Seconds
60 Seconds
5 Minutes
15 Minutes

Music Repeat One

All
Off

Picture display order is random in slide
show mode

clockwise.

Multiple languages

The slide show will run automatically after
the time is selected.

The times for the selected music repeat

6

Controls and Basic Instructions

Control Button Functions - continued

OSD Functions

Note: To enter the OSD, hold the MENU button down for one second.
To exit, press the MENU button again.

Button Command

Up

Down

▶II Select
▶I Forward

▶I

Backward

Viewing Pictures Individually

Button Command

▶I

Previous Picture

▶II Zoom in the Select Picture
▶I Next Picture

Select Mode Page / Select Card Page

Button Command

▶I
Left

▶II Select
▶I Right

Playing musics Individually

Button Command

Previous Music

▶II Play or pause

Next Music

Demo Slide Show

▶I

pictures can be viewed without inserting any memory cards. Power on the Digital Photo Picture
Frame, wait for a while, the demo slide show will run automatically.

▶I

or

Some demo pictures have been loaded into the Digital Photo Picture Frame. These

Connecting a USB Device to the Digital Photo Frame

Your Digital Photo Picture Frame has a built-in USB port. Using a USB cable (not included)
and your digital camera or a USB ash drive, you have the ability to view images directly from
the USB source.

1. Connect the AC adapter to the Digital Photo Picture Frame and slide the power switch to
the “on” position.

2. Connect one end of a USB cord to a USB device such as a digital camera or USB ash drive,
and the other end to the Digital Photo Picture Frame.

3. Once the Digital Photo Picture Frame has recognized the USB source, you will be able
to view all the pictures on the camera’s internal memory, its memory card, or a USB ash
drive.

7

Frequently Asked Questions

Frequently Asked Questions(FAQ)

Q : What other media formats can the Digital Photo Picture Frame support? Why will it not play

all images?

A : The Digital Photo Picture Frame will support JPEGs taken from a digital camera. The

Digital Photo Picture Frame may not read all images.

Q : I have a memory card in the Digital Photo Picture Frame, but it’s not reading the card. What

should I do?

A : First, make sure that you are using a memory card that is supported by the Digital Photo

Picture Frame. Second, ensure that the memory card is inserted all the way into the correct
slot. Third, press the EXIT button until you reach the “Select Card” page. If the memory
card is properly inserted into the slot, that memory card icon will be highlighted.

Note: Some digital cameras save images into non-standard formats. Please refer to your
camera’s operating manual for specics.

Q : Why do some pictures load faster than others?
A : Higher resolution pictures load slower. Using a lower resolution when taking pictures

speeds loading time.

8

Technical Specications and Recycling

Technical Specications

Product: 10.2” LCD Screen Digital Photo Picture Frame
Resolution: 800 x 600 pixels
Input Formats: Secure Digital™, Multi Media Card™, Memory Stick™,
Memory Stick Duo™

Questions? Need some help?

This manual should help you understand your new product. If you have
questions, please call our toll-free number found on the insert with this icon:

Or visit www.polaroid.com.

WEEE:

This product contains electrical or electronic materials.
The presence of these materials may, if not disposed of
properly, have potential adverse effects on the environment
and human health. Presence of this label on the product
means it should not be disposed of as unsorted waste
and must be collected separately. As a consumer, you
are responsible for ensuring that this product is disposed
of properly. To nd out how to properly dispose of this
product, please go to www.polaroid.com and click on
“Company“ or call the customer service number for your
country listed in the instruction manual.

“Polaroid” and “Polaroid and Pixel” are trademarks of Polaroid Corporation.
For service, support and warranty information, visit www.polaroid.com.

RoH S

9

Part No.:OM6077US001

Printed in China
