High Definition
Digital Video Camera
User’s Manual
Read This Before Using the Camera
SAFETY INSTRUCTIONS
Do not drop, puncture or disassemble the camera. •
Use the camera with care. Rough handling may damage the internal components.•
Do not expose the camera to high temperature. Avoid contact with water.•
Please notice that the camera body may become warm when operating it for an extended period.•
Test for proper operation before using the camera.•
Only use accessories supplied by the manufacturer.•
Use only the type of battery that came with your camera.•
Remove the battery if the camera is not going to be used for long periods.•
Product Information
Designs and specifications of the camera are subject to change without notice. This includes primary •
product specifications, software, and this user’s manual.
This User’s Manual is a general reference guide for the camera.•
The illustrations in this manual may not be the same as the actual design of your camera and those •
you see on the LCD screen.
2
EN
Contents
Read This Before Using the Camera ................................................... 2
Section 1 Getting to Know Your Camera ........................................... 4
Section 2 Getting Started .................................................................... 7
Section 3 Enjoying the Record Mode .............................................. 10
Section 4 Enjoying the Playback Mode ........................................... 23
Section 5 Setting Your Camera ....................................................... 28
Section 6 WiFi to Cloud-Ustream ..................................................... 32
Section 7 WiFi to PC-WiVideo Program .......................................... 36
Section 8 Viewing Photos and Videos on TV .................................. 41
Section 9 Viewing Video & Photo on PC ......................................... 42
Section 10 ..................... 43
Section 11 Troubleshooting ................................................................ 45
Section 12 Techinal Support
Section 12 Warranty Card
................................................................
................................................................
47
48
Section 1
Getting to Know Your Camera
Overview
This camera with a 5 Mega Pixel sensor can take H.264 format videos. The H.264 technology allows
for extended video recording with less memory. High quality images up to 16 mega-pixels can also
be delivered smoothly. With a color LCD monitor, you can view and examine the video and photo
easily.
The 3” LCD touch panel is an ideal platform for you to operate your camera. The menu options are
accessible with your fingertip. With the touch panel, you can select the options directly and quickly.
The camera also features video recording at an HD resolution of 1920x1080. You can also connect
it to an HDTV via an HDMI cable, and easily playback the recorded high-definition videos on the
wide screen HDTV.
Moreover, the camera is equipped with WiFi module and the exclusive application. You can broadcast
live streaming of the camera on Ustream website via WiFi. Your family and friends can watch the live
video streaming of the camera on their smart phones, tablets, or computers.
The camera can also connect with your computer via WiFi. It can be a wireless webcam for your
on-line video chatting. Through WiFi connecting, you can transfer the videos and photos on your
computer, and monitor live video from your camera.
ISO sensitivity and color balance can either be adjusted automatically or changed manually. A 16x
digital zoom helps you to control over the video and photo you take. The varied effect options, such
as Time Lapse and Slow Motion, make recording more fun.
The built-in memory allows you to take photos and to record videos without a memory card. The
memory card slot allows users to increase the storage capacity.
Note
Partial memory of the built-in memory is used for the camera’s Firmware code• and software.
Install the bundled ArcSoft MediaImpression application for viewing the videos correctly on the •
computer.
For the WiFi connectivity working correctly, make sure the bundled• WiVideo program (for
Windows
activated.
®
based systems only) is installed and the wireless LAN module of your computer is
Standard Accessories
Unpack the package and make sure all standard accessories listed are included:
USB Cable•
HDMI Cable•
Adaptor•
Lithium-ion Rechargeable Battery•
Quick Guide•
CD-ROM (Software, User’s Manual)•
Pouch•
Strap•
4
EN
Front View
Speaker
Lens
Light
Microphone
Bottom View
Tripod Socket
Strap Hook
EN
5
Side/Rear View
Photo Mode LED Indicator
LCD Touch Panel
Video Mode LED Indicator
Record Button
In Video Mode, press
to take video. To stop
recording, press it again.
In Photo Mode, press to
take photo.
Tele/Wide Button
Zoom In/Out
Power Button
Power On/Off
WiFi Button
WiFi On/Off.
HDMI Port
Mini USB 2.0 Port
6
EN
Loading the Battery
Before using the camera, you must load the supplied Lithium-ion
rechargeable battery.
Slide the battery cover down and remove.1.
Insert the battery according to the correct polarity marks ( + or -).2.
Close the battery cover firmly.3.
Section 2
Getting Started
Note
Different battery types and surrounding temperatures may affect the battery performance.•
Never expose the battery to a heating equipment (e.g., microwave oven) and attempt to dispose •
of a battery by burning or by throwing it into a fire. Heat can cause the battery to explode and/
or release caustic liquid, both which may possibly cause serious injury.
Turn the power off and stop using the battery if you observe the condition of excessive heat on •
the battery.
7
EN
Charge your battery
You must use the supplied power charger and the USB cable.
A blinking light will indicate active charging.
In adapter charging mode, the full charging time for a depleted battery is about 4- 5 hours and the light
will turn off automatically after the charging is completed.
In PC USB charging mode, a longer charging time is
required.
or
Note
Never charge the battery by a method other •
than as instructed. Doing so may cause a fire or
explosion possibly resulting in serious injury.
Use the supplied AC adapter only with the •
indicated power supply voltage.
Use with any other power supply voltage might •
cause electric shock.
Be sure that the power outlet you plug the adapter into is easily accessible. When you need •
to disconnect power from the camera, be sure to unplug the power cord from the electrical
outlet.
Inserting and Removing a Micro SD Card (Optional)
The camera comes with an internal memory which allows you to
store photos and videos. You can expand the memory capacity by
using an optional micro SD memory card.
Remove the battery cover and the battery.1.
Insert the memory card into the slot until it locks properly. 2.
To remove an installed micro SD card, press the card inwards 3.
to release it.
When the card pops out, gently remove it from its slot.4.
Recommended memory capacity: 1GB or above.5.
8
EN
Turning the Camera On
To turn on the camera: •
Flip out the LCD panel; the camera will turn on automatically.1.
Or press the [Power Button2. ] for one second to turn it on.
Configuring the Initial Date and Time Setup
The time setting screen appears to allow you to setup date and time:•
Operation Display Screen
Touch Year, Month, Day, Hour, Minute, and AM/PM to set.1.
Adjust the numeric value by touching 2. /
Touch the OK icon ( 3. ) to validate the setting.
Touch the Exit icon 4. (
) to exit.
Getting Started
To record video: Touch • (on-screen icon) on the screen to switch to the Video mode. (The Video
Mode LED Indicator lights up.) Press the [Record Button ] to record video. To stop recording,
press it again.
To take a • photo: Touch
Mode LED Indicator
To view stored videos and photos: Touch •
(on-screen icon) on the screen to switch to the Photo mode. (The Photo
lights up.) Press the [Record Button ] to take photo.
on the screen to switch to the Playback mode.
Turning the Camera Off
To turn off the camera: You can either press the [Power Button] for one second, or you can place the •
LCD panel back to its original position.
9
EN
Button Function
Section 3
Enjoying the Record Mode
Record Button:
In the Video Mode, press to take video. To stop recording, press it 1.
again.
In the Photo Mode, press to take photo.2.
Tele Button:
Zoom In.1.
Wide Button
Zoom out.1.
Power Button:
Press down for one second to turn on or turn off the camera.1.
WiFi Button:
WiFi On/Off.1.
10
EN
LCD Monitor Information
The indicators shown below may display on LCD:
Video Resolution
(1)
Photo Resolution
00:06:30
(2)
(3)
1000
Full HD (1080p 30 fps)
HD+ (720p 60 fps)
HD (720p 30 fps)
VGA (640X480)
Slow Motion (Record video at QVGA resolution.)
16MP
5MP
3MP
Recording time of the video that can still be taken at current
resolution
Number of images that can still be taken at current resolution
Micro SD Card Inserted
(4)
(5)
Date Printing On (Photo Only)
Face Tracking On (Photo Only)
EN
11
Scene
Skin
Night
(6)
(7)
(8)
(9)
(10)
(11)
Backlight
Black/White
Classic
Negative
White Balance
Daylight
Fluorescent
Tungsten
Time Lapse (Video Recording Only)
Stabilization (Video Recording Only)
Digital Light On
Light On
WiFi signal strength
WiFi to PC On
(12)
(13)
Battery: full power
Battery: high power
Battery: medium power
Battery: low power
Battery: no power
DC power mode
Zoom meter:
1X~16X (16X Digital zoom)
Motion Detection (Video Recording Only)
EN
12
(14) Self-timer enabled
On-screen touchable function icon
(15)
(16)
(17)
Playback Mode On
Menu On
Toggle [Video Mode] and [Photo Mode]
Note
Tap on the screen to display the icons. Tap again to hide the icons.•
Stabilization and Slow Motion functions cannot be used simultaneously.•
Motion Detect, Slow Motion, and Time Lapse functions can not be used simultaneously.•
Motion Detect, Sl• ow Motion, and Zooming functions cannot be used simultaneously.
The WiFi •
and your camera. Some access points do not allow you to connect to the network. Some
network require the authentication from the network service provider (NSP) Please follow the
instruction on the screen or contact with the network service provider.
signal strength indicates the connection strength between the access point
13
EN
Video Recording
Touch • (on-screen icon) on the screen to switch to the Video mode. (The Video Mode LED Indicator
lights up.) Press the [Record Button ] to start recording. When a video is being recorded, a
time indicator will display on the LCD monitor (
Touch •
Four resolution settings are available: •
on the screen to view the recorded video.
Video Quality
Full HD (1080p 30 fps)
HD (720p 60 fps)
HD (720p 30 fps)
VGA (640X480)
Note
When Slow Motion function is activated, the video resolution is QVGA.• The view angle becomes
smaller when the Slow Motion is activated.
00:06:30
). To stop recording, press it again.
Photo Capturing
Touch • (on-screen icon) on the screen to switch to the Photo mode. (The Photo Mode LED Indicator
lights up.) Press the [Record Button ] to take photo.
Touch •
Three resolution settings are available: •
on the screen to view the photo.
Image Quality
16 Mega Pixels
5 Mega Pixels
3 Mega Pixels
Using Zoom Function
The zoom magnifies images when recording video or taking photo.•
To zoom in/out, press the Tele/Wide Button.1.
It can be set from 1X~16X (16X Digital zoom)2.
14
EN
Options for Record Menu
Menu Flow
Touch 1.
Swipe or touch 2.
on the screen to open the Menu.
on the menu screen to change the pages.
Video Photo Setting*
Resolution•
Light•
Scene•
White Balance•
Stabilization•
Motion Detect•
Slow Motion•
Time Lapse•
* Please refer to Section 5 for the detailed information about [Setting].
* Please refer to Section 6 for the detailed information about [Ustream].
Resolution•
Face Tracking•
Date Printing•
ISO•
Self-Timer•
Ustream•
WiFi ID•
Menu Sound•
TV•
Language•
Time Setting•
Format•
Default Setting•
15
EN
Video Menu
Operation Display Screen
Touch 1.
will show on the screen.
The first page contains 8 options-- Video Resolution, 2.
Light, Scene, White Balance, Video Stabilization, Motion
Detect, Slow Motion, and Time Lapse --for you to adjust
the camera settings.
Touch the Exit icon 3. (
on the screen to open the Menu. The menu
) to exit.
Video Resolution
Four resolution settings are available.
Full HD (1080p 30)• (Full HD (1080p30)):Record videos at 1920x1080p 30 fps resolution.
HD+ (720p 60):• Record videos at 1280x720p 60 fps resolution.
HD (720p 30):• Record videos at 1280x720p 30 fps resolution.
VGA (640X480): • Record videos at 640x480p 30 fps resolution.
Operation Display Screen
In the Video menu, touch the [Video Resolution] icon on 1.
the screen.
Touch to select the desired option.2.
Touch the OK icon ( 3.
Touch the Return icon 4. (
) to validate the setting.
) to return.
16
EN
Light
Three light settings are available.
Light OFF• : The light is turned off.
Light ON• : The light will be turned on and keep providing light.
Digital Light• : To extend the dynamic range for backlight and high contrast sense so that the objects
will be brighter and clearer.
Operation Display Screen
In the Video menu,1. touch the [Light] icon on the screen.
Touch to select the desired option.2.
Touch the OK icon ( 3.
Touch the Return icon 4. (
) to validate the setting.
) to return.
Without Digital Light Digital Light ON
Scene
You can select the mode according to the scene condition.
Auto:• Shoot without any special effect on the image.
Skin: • Shoot with an effect that makes skin tones more natural.
Night: • Use Night Mode for night scenes or low light conditions.
Backlight:• You can take shots when the bright light is behind the subject.
Black/White: • The image is converted to black-and-white.
Classic: • The image is converted to a sepia look.
Negative: • The image is converted as the negative of the normal.
Operation Display Screen
In the Video menu, touch the [Scene] icon on the 1.
screen.
Touch to select the desired option.2.
Touch the OK icon ( 3.
Touch the Return icon 4. (
) to validate the setting.
) to return.
Note
To avoid blurry image, place the camera on a flat, steady surface, or use a tripod in the Night •
Mode.
17
EN
White Balance
The camera adjusts the color balance of images automatically. Three manual white balance settings are
available:
Auto: • The camera automatically adjusts white balance.
Daylight: • Under outdoor condition.
Fluorescent: • Under fluorescent light condition.
Tungsten: • Under tungsten light condition.
Operation Display Screen
In the Video menu, touch the [White Balance] icon on 1.
the screen.
Touch to select the desired option.2.
Touch the OK icon ( 3.
Touch the Return icon 4. (
) to validate the setting.
) to return.
Video Stabilization
Record with an effect of reducing camera shake to result in more stable video.
Operation Display Screen
In the Video menu, touch the [Video Stabilization] icon on 1.
the screen.
Touch to select [2. On] (
Touch the Return icon 3. (
Without Stabilization Stabilization ON
)or [Off] ( ).
) to return.
18
EN
Motion Detection
Record videos automatically when the camera detects a movement.
Operation Display Screen
In the Video menu, touch the [1. Motion Detect] icon on the
screen.
Touch to select [2. On] (
Touch the Return icon 3. (
The camera will start to record video automatically if it 4.
detects a movement. It will stop recording if it does not
detect a movement.
)or [Off] ( ).
) to return.
Slow Motion
Record videos with slow motion effect. When playing the video, the playback time will be longer than
the actual recording time. Some occasions you can use this effect are the skill demonstration of athletic
activities of all kinds, or a key moment in an athletic game.
Operation Display Screen
In the Video menu, touch the [Slow Motion] icon on the 1.
screen.
Touch to select [2. On] (
Touch the Return icon 3. (
)or [Off] ( ).
) to return.
Note
While Slow Motion function is activated, audio is not recorded and zoom is disabled.•
The view angle may become smaller when the Slow Motion is activated.•
When Slow Motion function is activated, the video resolution is QVGA.•
Time Lapse
Record still images at specific intervals you can set and play them as one video file. This effect is good
for recording cloudscapes, seed germinating and flowers opening.
Off:• Disable Time Lapse.
1 Second.: • Record one frame per second.
3 Seconds: • Record one frame every 3 seconds.
5 Seconds: • Record one frame every 5 seconds.
Operation Display Screen
In the Video menu, touch the [Time Lapse] icon on the 1.
screen.
Touch to select the desired option.2.
Touch the OK icon ( 3.
Touch the Return icon 4. (
) to validate the setting.
) to return.
19
EN
Photo Menu
Operation Display Screen
Touch 1.
will show on the screen.
Swipe on the menu screen to change the page.2.
The second page contains 5 options-- Photo Resolution, 3.
Face Tracking, Date Printing, ISO, and Self-Timer --for
you to adjust the camera settings.
Touch the Exit icon 4. (
on the screen to open the Menu. The menu
) to exit.
Photo Resolution
Three resolution settings are available.
16MP•
:Shoot photo at 4608 x 3456, 16MP quality.
5MP• :Shoot photo at 2592 x 1944, 5MP quality.
3MP• :Shoot photo at 2048 x 1536, 3MP quality.
Operation Display Screen
In the Photo menu, touch the [Photo Resolution] icon on 1.
the screen.
Touch to select the desired option.2.
Touch the OK icon ( 3.
Touch the Return icon 4. (
) to validate the setting.
) to return.
Face Tracking
The camera can detect human face(s) and focus on the face(s) automatically. This function can works
with photo capturing. It is wonderful for capturing beautiful portraits in backlight situation.
Operation Display Screen
In the Photo menu, touch the [Face Tracking] icon on 1.
the screen.
Touch to select [2. On] (
Touch the Return icon 3. (
)or [Off] ( ).
) to return.
Note
When Face Tracking is activated, aim the camera at the human face(s). The focus frame(s) will •
show on the LCD before the [Record Button] is pressed.
20
EN
Date Printing
Imprint the date and time on the photo.
Operation Display Screen
In the Photo menu, touch the [Date Printing] 1. icon on the
screen.
Touch to select [2. On] (
Touch the Return icon 3. (
As the function is activated, the date will appear on the 4.
corner of the photo.
)or [Off] ( ).
) to return.
Note
Date Printing function can not be used in Video Record Mode.•
ISO
The camera adjusts the ISO sensitivity of its images automatically. Two manual ISO sensitivity settings
are available. (800/1600). The larger the number, the higher the ISO sensitivity. Select the lower setting
to shoot a smoother image. Select the higher setting to shoot a photo in a dark poorly lit location, or to
shoot a subject moving at a high rate of speed.
Operation Display Screen
In the Photo menu, touch the [ISO] icon on the screen.1.
Touch to select the desired option.2.
Touch the OK icon ( 3.
Touch the Return icon 4. (
) to validate the setting.
) to return.
Note
The image may become noisy when the ISO number is large.•
21
EN
Self-Timer
The self-timer allows you to take photos with a ten-second time delay. The LED light on the front of the
camera will also blink. The speed of blinking will increase just before the photo is taken.
Operation Display Screen
In the Photo menu, touch the [Self-Timer] icon on the 1.
screen.
Touch to select [2. On] (
Touch the Return icon 3. (
)or [Off] ( ).
) to return.
22
EN
Enjoying the Playback Mode
Button Function
The Buttons have the following functions in Playback Mode.
Record Button:
Press to go the Record Mode1.
Tele Button:
Volume increase. 1.
Zoom in the photo2.
Wide Button
Volume decrease. 1.
Zoom out the photo2.
Section 4
Power Button:
Press down for one second to turn on or turn off the camera.1.
WiFi Button:
WiFi On/Off.1.
23
EN
LCD Monitor Information
Indicators on the LCD screen while in Playback Mode:
Video Playback Mode Photo Playback Mode
Video Resolution
Full HD (1080p 30 fps)
HD+ (720p 60 fps)
HD (720p 30 fps)
(1)
Photo Resolution
00:06:30
VGA (640×480)
Slow Motion (QVGA)
16MP
5MP
3MP
Video playback time counter.
0088/0093
(2)
0050
Current number/ Total number of photo/video.
0055
(3) Volume
(4)
(5)
Return
Video stop
Previous video/photo
EN
24
(6)
(7)
Video fast rewind
Video play
Video pause
(8)
(9)
(10)
(11)
(12)
Video fast forward
Next video/photo
Delete
Slideshow
Slideshow stop
Magnification Indicator
Operations for Playback Mode
The Playback Mode is for viewing and managing videos and photos on the built-in memory or on an SD
Card.
Operation Display Screen
T1. ouch
mode.
Touch 2. to go to the Video Playback Mode.
Touch 3.
Touch 4.
on the screen to switch to the Playback
to go to the Photo Playback Mode )
to back to Record Mode.
25
EN
Video Playback
Operation Display Screen
In the Video Playback mode, touch 1.
pause the video.
Swipe to the right or touch 2.
video; swipe to the left or touch
video.
While playing video, touch 3.
forward.
Touch 4.
Touch 5.
to adjust the volume
to exit.
Note
When the LCD is idle for a few seconds, the playback function icons will disappear •
automatically. Tap again to show the bar.
Delete Videos
Operation Display Screen
T1. ouch
to go to the Delete option screen.
/ to play or
to go to the previous
to go to the next
/ to fast rewind/
Touch [Yes] to delete the current video or [No] to cancel 2.
the operation and to exit; touch [All (Delete All)] to delete
all videos.
Before all videos are about to be deleted, a confirmation 3.
screen will appear; touch [Yes] to execute the operation
and [No] to cancel the operation.
Note
If a memory card has been inserted, you can only delete those videos stored on the card. •
26
EN
Photo Playback
Operation Display Screen
In the Photo Playback mode,1. swipe to the right or touch
to go to the previous photo; swipe to the left or touch
to go to the next photo.
While the photo is selected, press [Tele Button] to magnify. 2.
(The magnification Indicator
screen)
To navigate the magnified photo, press on the screen and 3.
move as well.
Press [Wide Button] to zoom out or exit the magnification 4.
mode.
Touch 5.
Touch 6.
/ to start or to stop the slide show.
to exit.
Note
When the LCD is idle for a few seconds, the playback function icons will disappear •
automatically.
Tap again to show the bar.
Delete Photo
appears on the
Operation Display Screen
Touch1.
Touch [Yes] to delete the current photo or [No] to cancel 2.
the operation and to exit; touch [All (Delete All)] to delete
all photos.
Before all photos are deleted, a confirmation screen will 3.
appear; touch [Yes] to execute the operation and [No] to
cancel the operation.
to go to the Delete option screen.
Note
If a memory card has been inserted, you can only delete those photos stored on the card. •
27
EN
Setting Menu
Section 5
Setting Your Camera
Operation Display Screen
Touch 1.
will show on the screen.
Swipe on the menu screen to change the page.2.
The fourth page contains 8 options 3. for configuring your
cam
era setup. They are Ustream, WiFi ID, Menu Sound
(operation sound), TV, Language, Time Setting, Format,
and Default Setting.
Touch the Exit icon 4. (
on the screen to open the Menu. The menu
) to exit.
WiFi ID
Edit the WiFi ID & Password for [WiFi to PC]. (Refer to section 7)
Operation Display Screen
In the Setting menu, touch the [WiFi ID] 1. icon on the
screen.
Go to the WiFi ID & Password screen.2.
Touch on the column to go to the 3. keypad screen and
you can edit the WiFi ID & Password.
28
EN
Sound
Enable or disable the keypad tone and the operation sound.
Operation Display Screen
In the Setting menu, touch the [Sound] 1. icon on the
screen.
Touch to select [2. On] (
Touch the Return icon 3. (
)or [Off] ( ).
) to return.
TV
Ensure that the appropriate TV standard of your area is selected – either NTSC or PAL. Wrong TV
system setting may cause image flickers.
NTSC• (60Hz):USA, Canada, Japan, South Korea and Taiwan, etc.
PAL• (50Hz):UK, Europe, China, Australia, Singapore and Hong Kong, etc.
Operation Display Screen
In the Setting menu, touch the [TV] icon on the screen.1.
Touch to select [PAL] or [NTSC].2.
Touch the OK icon ( 3.
Touch the Return icon 4. (
) to validate the setting.
) to return.
Language
Use this option to select the language of the user interface.
Operation Display Screen
In the Setting menu, touch the [Language] icon on the 1.
screen.
Touch to select the desired option.2.
Touch the OK icon ( 3.
Touch the Return icon 4. (
) to validate the setting.
) to return.
29
EN
Time Setting
Operation Display Screen
In the Setting menu, touch the [Time Setting] icon on the 1.
screen to enter the time setting screen.
Touch Year, Month, Day, Hour, Minute, and AM/PM to set.2.
Adjust the numeric value by touching 3.
Touch the [OK] icon to validate the setting.4.
Touch the Return icon 5. (
) to return.
/
Format
Yes: • Format the built-in memory (When no memory card is installed ) / Memory Card (When a memory
card is installed).
No: • Do not format the built-in memory (When no memory card is installed ) / Memory Card (When
a memory card is installed).
Operation Display Screen
In the Setting menu, touch the [Format] icon on the 1.
screen.
Touch to select [Yes] or [No] 2. (
to enter the confirmation screen.)
). (Touch [Yes]
Touch the [Yes3. ] icon to execute the operation and
the [No ] icon to cancel the operation.
Note
All the data will be erased if the memory card is formatted. Make sure all the data are copied to •
your PC before formatting the memory card.
30
EN
Default Setting
To restore the default factory setting, select this option.
Operation Display Screen
In the Setting menu, touch the [Default Setting] icon on 1.
the screen.
Touch to select [Yes] or [No] 2. (
(Touch [Yes] to enter the confirmation screen.)
Touch the [Yes3. ] icon to execute the operation and
the [No ] icon to cancel the operation.
).
Note
The WiFi setting, such as profile of access points and Ustream account information will be •
erased.
The following table indicates the camera’s default settings
Setting Default Factory Setting
Resolution FHD (1080p 30) for Video
5MP for Photo
Video Stabilization Off
Light Off
Scene Auto
White Balance Auto
Motion Detection Off
Slow Motion Off
Time Lapse Off
Self-Timer Off
Face Tracking Off
Date Printing Off
ISO Auto
Password of WiFi ID 0000
Sound On
TV Depends on shipping area
Language Depends on shipping area
Volume Level 3
31
EN
Section 6
WiFi to Cloud-Ustream
Start to use Ustream
Ustream enables you to free broadcast the live video of your camera. People can watch your broadcasting
on their iPhone, iPad, iPod touch, Android phones/tablets, or PC on Ustream website/ APP anytime,
anywhere.
First, you need to pre-register an account at Ustream website (www.ustream.com).
(If you already have an account, please skip.)
Operation Screen
Go to1. http://www.ustream.com/.
Click on [Login/Sign Up ], and follow the instruction 2.
step by step to create your username and password.
The website will create a default channel for you to 3.
start broadcasting.
More you can do:
Create a channel
Click on [Create a Channel]. Follow the instruction to 1.
create your channel.
Or go to [Dashboard], and select [Manage My 2.
Channel].
Manage your channel
Edit or check your channel information in [Manage 1.
My Channel] section. (Default is a public channel)
Select the category.2.
Change the channel name.3.
Or you can make your channel to be private in 4.
[Advanced Settings].
32
EN
Prepare to broadcast on Ustream
Ensure you have a working AP(Access Point) device to get ready to start broadcasting.
Broadcast live streaming on Ustream
Select Ustream on [Setting] page.1.
Log in your Ustream account.2.
(1) Tap on the blank and the keypad screen shows up.
(2) When you complete, touch the [Enter] icon to save it.
Note
When execute [Default Setting], the account •
information of the websites will be erased.
Make sure you create the channel on Ustream •
website for your broadcast. For detailed setup
procedure, please refer to Ustream website.
33
EN
The camera lists available Access Points. Please 3.
select one for WiFi connection.
Icon Description
Currently connecting AP
Secured network: Requires the password
to access the AP.
Signal strength
Up Down cursor: Change the pages.
AP Profile information: Check the status or
you can remove its profile.
Select the desired AP4. (Network) to connect to.
If the selected AP requires the password 5. authentication,
you will enter the keypad screen.
Enter the password and touch the [Enter] icon to 6.
Toggle between letters
and numbers/symbols
Confirm
Capital Lock
confirm it.
Or touch the [Return] icon7. to exit.
When the connection is 8. established, the signal strength
will show on the top of the screen.
Once the 9. connection to the network has been
established, the camera automatically connects to
Ustream server and starts streaming.
To cancel streaming, touch the [10. Return] icon to
terminate streaming.
The video streaming will be broadcasted on the 11.
Ustream website.
Ustream
People who has your account / channel name, they can 12.
visit Ustream website and watch the live video streaming
from you camera through their various devices, such
as computers, tablets, or smart phones.
(Free download Ustream App on App Store/ Andriod
Market. Go to Ustream website/App. Enter the username
in search bar.)
Exit
Back
34
EN
The screen shown the icon [Connecting Failed] (13. )
indicates the camera does not connect to the network
correctly.
Note
The possible reasons for “Connecting Failed” could be (1) wrong password ; (2) you are not •
in the wireless network area of the AP. (3) the camera does not support the type of encryption
used on the AP. This model only supports WEP/WPA/WPA2 personal type of encryption, but
not up to enterprise level (4)your network requires PPPoE account/password information.
This camera only supports the AP(SSID) named in English/number/symbols (ASCII •
characters).
You can only enter text in English, regardless of the OSD language.•
Some AP routers do not allow you to connect to the network (e.g. firewall).•
You may be charged by the network service provider. •
Please stay away from any electronic equipment since the radio frequency signals may •
interfere connecting.
When streaming on Ustream, the record/ zoom functions are disabled.•
The camera cannot connect to the network while it is connected to an HDTV via the cable, or •
vice versa.
It may take time to scan and connect to the AP/network or to upload. The stream speed is •
affected by the Internet connection speed or other factors.
Please be sure the battery is fully charged before connecting to the network. It may take time •
to upload.
If you do not have an account, please sign up on the website first.•
The social website update is the subject to change without notice. (e.g. password validation, •
create a channel) Please visit the website first to update your account setting.
Ustream may not be allowed to access in certain regions or networks.•
Please avoid transferring the confidential files and setting your personal account information on •
the open networks or in public areas . The data transferred via WiFi could be leaked.
35
EN
Section 7
WiFi to PC-WiVideo Program
Advanced Operation on Your Computer - WiVideo
The camera can connect to your computer via WiFi or USB. Once you launch the [WiVideo] application
(for Windows® based systems only) on your computer, it will search for your camera and connect to it.
Then, you can operate more functions on your computer. There are several functions as below:
Transfer the files from the camera. ( WiFi/USB connection)•
Watch live streaming video from the camera on your computer. • ( WiFi connection)
Use the camera as a wireless webcam for online video chatting. • ( WiFi connection)
Install [WiVideo] on your computer
To connect to the camera and launch [WiVideo] application via WiFi correctly, you have to install this
program firstly. It is a perfect platform for you to watch live streaming video from your camera and use
the camera as a webcam for your online video chatting.
Follow the steps below to install the [WiVideo] on the computer.
Connect the camera to your computer by using the supplied USB cable.1.
36
EN
After making a USB connection, the program installs automatically, or the AutoPlay window 2.
appears. (It may be different based on OS recognition. If the AutoPlay window does not appear.
Please click [My Computer]-->[WiVideo] to execute the installation of this program.
Windows XP Win7
(Install automatically)
(AutoPlay window)
Follow the on-screen instructions to complete the installation.3.
The shortcut of WiVideo (4.
Program].)
The main screen appears automatically on the desktop.5.
Note
(Path to WiVideo.exe) (Path to WiVideo.exe)
) shows on the desktop. (Or you can find the application at [Start]-->[All
If ArcSoft MediaImpression is not installed, WiVideo program will install the H.264 Codec •
(ffdshow-a free software under GPL license) for viewing the videos correctly.
To install correctly, you have to log out /quit from the Instant Message (IM) application before •
the installation.
WiVideo is for Windows•
®
based systems only.
37
EN
When the installation is completed, you can unplug the USB cable. 6.
Using WiVideo via WiFi Connection
Operation Screen
On your camera:
Press WiFi Button 1.
password.
(The default password is 0000. WiFi ID and password can
be edited on camera Setting menu.)
to show the WiFi ID and
On your computer:
Double click on the [WiVideo] shortcut 2.
desktop. (make sure the [WiVideo] application is installed
in your computer.)
Click [Detect WiFi Camera] button to search for your 3.
camera.
*One task window may pop out to ask you to select
your camera when there are two or more WiFi
cameras in the same
Select the WiFi ID and input the Password shown on 4.
your camera for the WiVideo task window. Then, click
[OK].
Once the connection is 5. established, the signal of WiFi
to PC
will show on the top of the screen.
wireless network range.
on the
38
EN
The WiVideo application serves 3 options while connecting via WiFi:
Function Description
TRANSFER You can remote access the videos and photos stored in your camera.
You can transfer or delete the files on your computer.
LIVE VIDEO Watch live streaming from your camera on your computer.
The video resolution can be selected.
VIDEO CHAT Use your camera as a wireless webcam for online video chatting
(You have to select this device as your webcam on the camera/audio setting
first.)*
*You have to select [WiVideo Camera] as your webcam/microphone for
the online video chatting.
Note
For the WiFi connectivity working correctly, make sure the bundled WiVideo (for Windows•
based systems only) is installed and the wireless LAN module of your computer is activated.
Make sure your computer connects with your access point (AP) correctly and your camera is •
in the same range of the WLAN.
For the much more stable video streaming when using LIVE VIDEO or VIDEO CHAT, please •
make sure the WiFi signal strength shows 2 bars (
To boost the WiFi signal strength, you can move the camera closer to your computer.•
If the camera is far from your computer or the AP device, it may take longer to connect to the •
network. ( The signal and the radio frequency may be interfered.)
To prevent the camera from turning off accidentally, please be sure the battery is fully •
charged.
) or above on the camera.
®
39
EN
Using WiVideo via USB Connection
Connect the camera to your computer by using the supplied USB cable.1.
After making a USB connection, the main screen will appear. Or please click [WiVideo] shortcut 2.
on the desktop to execute the application. Or you can find it at [Start]-->[All Program].
The WiVideo application serves 1 option while connecting via USB:
Function Description
TRANSFER
You can access the videos and photos stored in your camera and upload files to the
social websites.
Upload
Select the videos/photos on the thumbnail screen. 1.
Click on [Upload].2.
The website options appears.3.
Select the website and check the 4.
social website in the fields.
Click on [OK] to upload.5.
Username/Email and password of the specific
Note
LIVE VIDEO and VIDEO CHAT are not available during USB connecting.•
Some • social websites may not be allowed to access in certain regions or networks.
Your computer must have internet access to upload files to the website.•
If you do not have a account, please sign up on the website first.•
The social website update is the subject to change without notice. (e.g. password validation, •
create a channel) Please visit the website first to update your account setting.
40
EN
Viewing Photos and Videos on TV
Connecting to a High-Definition 16:9(Wide) TV
Connect the HDMI cable to your camera’s HDMI Out port.1.
Connect the other end of the cable to a television.2.
Set the video input source of your TV to “ HDMI.”3.
The steps for viewing stored videos and photos on an HDTV are exactly the same as for viewing them 4.
on the LCD monitor.
(16:9)
Section 8
Note
Some icons on the LCD screen do not display when the camera is connected to an HDTV.•
Some functions may not be accessible while the camera is connected to an HDTV.•
41
EN
Section 9
Viewing Video & Photo on PC
Installing Bundled Software
The CD-ROM supplied with this camera contains 2 pieces of software.
ArcSoft MediaImpression • is a user-friendly application that helps you managing your media, burning
your video into DVD, and uploading your files to the web sites easily.
Adobe Reader• is a popular program that you need to have installed to read the User’s Manual. Many
computer users will find they already have this software installed on their computer.
To install the bundled software:
Insert the CD-ROM into your computer’s CD-ROM drive. The autorun screen appears.1.
Follow the on-screen instructions to complete the installation.2.
Note
Detailed information can be found in the online help of all the bundled software.•
Install the bundled software application, ArcSoft MediaImpression, for viewing the video •
correctly on a computer.
Transferring Photos or Videos to a Computer
You can transfer photos or videos stored on your camera to a computer and send them in e-mails to
friends or post them on the web sites.
To do this you should:
Connect the computer and camera with the supplied mini USB 2.0 cable.1.
To access photos and videos on your memory card: Videos and photos can be found on your 2.
computer at My Computer\ SD\DCIM\100MEDIA (path will vary depending on the name of the
memory card).
To access photos and videos in the camera’s internal memory: Videos and photos can be found 3.
on your computer at My Computer\DV\DCIM\100MEDIA
Under this folder, you can view, delete, move, or copy any video/photo you want.4.
42
EN
Section 10
Specifications and System Requirements
Specification
Image sensor 5 Mega pixel CMOS sensor
Operation modes Video record, Photo record, Live streaming via WiFi, Wireless webcam
Lens Fixed Focus (F 2.8)
Focus range HD+(720p 60) & HD(720p 30): 60 cm ~ infinity
Photo & Full HD (1080p 30):110 cm ~ infinity
Zoom 1X~16X (16X Digital zoom)
Shutter Electronic
LCD monitor 3” touch LCD
Storage media Built-in 128MB memory (partial memory is used for firmware code and
software)
Micro SD/SDHC/SDXC card slot support (up to 64GB)
Image resolution 16MP: 4608 x 3456 (16M pixels) (Interpolated)
5MP: 2592x1944 (5M pixels)
3MP: 2048x1536 (3M pixels)
Video resolution Full HD (1080p 30): 1920X1080(30fps)
HD+ (720p 60): 1280X720(60fps)
HD (720p 30): 1280X720(30fps)
VGA (640X480): 640X480(30fps)
White balance Auto/Manual (Daylight, Fluorescent, Tungsten)
ISO Auto/800/1600
Self-timer 10 seconds delay
Light Light On/ Digital Light / Light Off
File format Photo: JPG
Video: AVI (H.264)
Image play Single image/Slideshow
PC interface Mini USB 2.0 port
TV out HDMI
WiFi Compatible with WiFi 802.11 a/b/g/n
Battery Lithium-ion rechargeable battery
Dimension 58mm (L) × 112mm (H) × 17mm (W)
Weight 105 g ( without battery)
43
EN
System requirements
Microsoft Windows XP(SP3 or above)/Vista/7•
Intel /AMD Dual-Core CPU or above•
1GB• System memory and free
2GB System hard disk space•
Available USB 1.1/2.0 port or above•
WiFi a/b/g/n capability•
Note
The LCD screen is manufactured using extremely high-precision technology, so over 99.99% •
of the pixels are operational for effective use. However, some tiny black and/or bright dots
(white, red, blue or green) may appear on the LCD screen. These dots are a normal result of
the manufacturing process, and do not affect the recording.
44
EN
Section 11
Troubleshooting
Troubleshooting
If the camera fails to function as expected, check the list of the common problems below.
Problem/Situation Remediation/Solution
Cannot turn on the camera. The
power turns off suddenly.
Camera cannot be turned on
after plugging power adapter.
WiFi icon does not appear after
pressing WiFi button.
The files on the memory card do
not display smoothly when the
LCD shows the “!” marking.
Cannot take video/photo. Memory is full. Delete some unnecessary videos/photos or •
The camera is frozen. Please remove the battery/unplug the adapter. Then, insert •
The date imprinted on the photo
is incorrect
Why do some of my indoor
photos look blurry and dark?
The color of the video/photo is
not natural.
When the camera is connected
to the PC via USB cable, many
Autoplay windows may pop out.
They indicate the disks of the
camera.
Power is off. Press the [Power Button] to turn on.•
Battery pack is weak or depleted. Recharge the battery pack.•
Please make sure that you use the supplied power adapter •
and connect it to the power outlet correctly.
Battery pack is low. Recharge the battery pack.•
“!” means the micro SD card is low speed or contains •
corrupted files. To solve this, format the microSD card using
the camera instead of a computer. (Please refer to the detailed
Format instruction in Section 5).
The card has some problems and can not be recognized. •
Change the card with another one.
Or please change the micro SD card to a high speed one.•
insert a new micro SD card.
Power is off. Press the [Power Button] to turn on.•
the battery/plug the adapter and turn on the camera again.
Set the date and time in the [Setting] menu.•
Poor lighting. Take photo in better lighting.•
The camera extends photo exposure time under low light/ •
indoor condition. Keep the camera (and the target subject)
steady for several seconds when taking photos.
Place the camera on a flat and steady surface, or use a •
tripod when take photo.
Select the proper white balance option to match the light •
source.
“DV” indicates the internal memory of the camera.•
“Removable Disk” indicates the external memory (memory •
card installed in the camera).
“WiVideo” indicates the bundled program. If you want •
to install this program, please double-click on it to start
installation automatically.
45
EN
The LCD shows [Connecting
Failed] after pressing WiFi
Button.
The WiVideo program cannot be
installed.
The password configuration does not match to the AP you •
want to connect.
The AP router or the computer is not turned on. Turn the AP •
router or your computer on.
The camera is not in the wireless network service area or •
weak network signal. Please make sure the AP router is able
to access the Internet.
The camera does not support the type of encryption used on •
the AP. This model only supports WEP/WPA/WPA2 personal
type of encryption, but not up to enterprise level.
Your network requires PPPoE account/password information.•
Some AP routers do not allow you to connect to the network •
(e.g. firewall).
The social websites update their websites without notice. •
Please visit the website first to update your account setting or
upgrade the firmware and WiVideo program.
Check the computer system compatibility.•
46
EN
Technical Support
Technical Support
For technical support issues please visit our website at
www.polaroid.com
technical support department toll free at 877-408-0033, or for e-mail
support, please contact us at polaroid@sakar.com
© 2012 All Rights Reserved
. For further assistance, you can also call our
.
Section 12
47
EN
Warranty Card
This warranty covers the original consumer purchaser only and is
not transferable.
This warranty covers products that fail to function properly
UNDER NORMAL USAGE, due to defects in material or
workmanship. Your product will be repaired or replaced at no
charge for parts or labor for a period of one year.
What Is Not Covered by Warranty
Damages or malfunctions not resulting from defects in material
or workmanship and damages or malfunctions from other than
normal use, including but limited to, repair by unauthorized
parties, tampering, modification or accident.
To obtain Warranty Service and Troubleshooting
information:
Call 877-408-0033 or Visit our website at
www.polaroid.com
.
To receive Warranty service along with the name and address of an
authorized product service center, the original consumer purchaser
must contact us for problem determination and service procedures.
Proof of purchase in the form of a bill of sale or receipted invoice,
evidencing that the Product is within the applicable Warranty
period(s), MUST be presented in order to obtain the requested
service. It is your responsibility to properly package and send any
defective products along with a dated copy of proof of purchase, a
written explanation of the problem, and a valid return address to the
authorized service center at your expense. Do not include any
other items or accessories with the defective product. Any products
received by the authorized service center that are not covered by
warranty will be returned unrepaired.
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, OTHER THAN THOSE
EXPRESSLY DESCRIBED ABOVE SHALL APPLY. DISTRIBUTOR
FURTHER DISCLAIMS ALL WARRANTIES AFTER THE EXPRESS
WARRANTY PERIOD STATED ABOVE. NO OTHER EXPRESS
WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR ENTITY
WITH RESPECT TO THE PRODUCT SHALL BE BINDING ON
DISTRIBUTOR. REPAIR, REPLACEMENT, OR REFUND OF THE
ORIGINAL PURCHASE PRICE - AT DISTRIBUTOR’S SOLE DISCRETION ARE THE EXCLUSIVE REMEDIES OF THE CONSUMER. IN NO EVENT
WILL DISTRIBUTOR, ITS MANUFACTURERS, OR PLR IP HOLDINGS,
LLC BE LIABLE FOR ANY INCIDENTAL, DIRECT, INDIRECT, SPE
PUNITIVE OR CONSEQUENTIAL DAMAGES (SUCH AS, BUT NOT
LIMITED TO, DAMAGES FOR LOSS OF PROFITS, BUSINESS, SAVINGS,
DATA OR RECORDS) CAUSED BY THE USE, MISUSE OR INABILITY TO
USE THE PRODUCT. EXCEPT AS STATED HEREIN, NO OTHER
WARRANTIES SHALL APPLY. NOTWITHSTANDING THE FOREGOING,
CONSUMER’S RECOVERY AGAINST DISTRIBUTOR SHALL NOT
CIAL,
48
EN
EXCEED THE PURCHASE PRICE OF THE PRODUCT SOLD BY
DISTRIBUTOR. THIS WARRANTY SHALL NOT EXTEND TO ANYONE
OTHER THAN THE ORIGINAL CONSUMER WHO PURCHASED THE
PRODUCT AND IS NOT TRANSFERABLE.
Some countries, states or provinces do not allow the exclusion or
limitation of incidental or consequential damages or allow limitations on
warranties, so limitation or exclusions may not apply to you. This
warranty gives you specific legal rights, and you may have other rights
that vary from state to state or province to province. Contact your
authorized retailer to determine if another warranty applies.
This product is manufactured, distributed and sold by SAKAR
International, Inc. Polaroid, Polaroid & Pixel, Made in Polaroid and
Polaroid Classic Border Logo are trademarks of PLR IP Holdings, LLC,
used under license. All other trademarks are the property of the
respective owner, who has not sponsored, endorsed or approved this
product. PLR IP Holdings, LLC does not manufacture this product or
provide any Manufacturer's Warranty or support.
E-Waste - PLR IP Holdings, LLC, its licensees, affiliates, and Sakar
International, Inc. fully supports all electronic waste initiatives. As
responsible stewards of the environment, and to avoid violating
established laws, you should properly dispose of this product in
compliance with all
governances in the area where you reside. Please check with local
authorities or the retailer where you purchased this product to
determine a location where you can appropriately dispose of the
product.
applicable regulations, directives or other
You may also go to www.polaroid.com
Responsibility to learn more about the specific laws in your area and to
locate a collection facility near your home.
If your electronic device has internal memory on which personal or
other confidential data may be stored, you may want to perform a data
sanitization process before you dispose of your device to assure
another party cannot access your personal data. Data sanitization
varies by the type of product and its software, and you may want to
research the best sanitization process for your device before disposal.
You may also check with your local recycling facility to determine their
data sanitization procedures during the recycling process.
and reference Social
49
EN
50
EN
Loading...
