10.0 Megapixel Digital Camera
i1037
User’s Manual
Questions?
Need Some Help?
This manual should help you
understand your new product.
or visit
www.polaroid.com/support.
If you still have questions, call
our help line found on the
insert with this icon:
DIGITAL QUALITY, POLAROID SIMPLICITY™
2
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
3
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
Product Overview
1. Shutter button
2. Flash
3. Self-timer LED
4. Stabilizer
5. Power button
6. Speaker
7. USB/AV port
8. LensMicrophone
9. Microphone
10. Zoom out / Thumbnail button
11. Playback mode button
12. Power / Auto Focus LED
13. Macro / VLeft button
14. Stop / Down button
15. Menu button
16. Zoom in button
17. Wrist strap holder
18. Play / Pause / Up button
19. Flash / Right button
20. Set / Display button
21. Mode / Scene button
22. SD card door
23. Tripod mount
24. Battery
22
23
24
1
1
2
2
3
3
10
1 1
12
13
14
15
menu
scene
Table of Contents
4
4
5
5
6
6
7
7
8
9
16
17
18
19
20
21
Product Overview ......................................................................................... 2
Table of Contents ......................................................................................... 3
1 Getting Started ........................................................................................ 6
• Camera Package Contents ...................................................................... 7
• Attaching the Wrist Strap ....................................................................... 8
• Installing the Batteries ............................................................................ 8
• Using Your Batteries ............................................................................... 9
• Checking the Battery Level .................................................................... 10
• Turning the Camera On and Off ............................................................. 10
2 Camera Settings ...................................................................................... 11
• Checking Camera Status ...................................................................... 11
• Capture Modes .................................................................................... 11
• Playback Mode .................................................................................... 15
• Camera Modes .................................................................................... 16
• Capture Modes .................................................................................... 17
• How to Navigate Menus ....................................................................... 18
• Setup Menu ....................................................................................... 19
• Adjusting the Sounds ........................................................................... 20
• Selecting Auto Review Period ................................................................ 21
• Power Saving Settings ......................................................................... 22
• Setting the Date and Time ................................................................... 23
• Setting the Display Language ............................................................... 24
• File No. Reset Setting ........................................................................... 25
• Choosing a Startup Image .................................................................... 26
• Formatting the Internal Memory ............................................................ 28
• Selecting the Battery Type .................................................................... 29
• Resetting to Default Settings ................................................................ 30
• Turning the Information Display On/Off ................................................... 31
3 Taking Pictures ....................................................................................... 33
• Taking Pictures in Normal Mode ............................................................. 33
• Taking Pictures in Macro Mode .............................................................. 35
• Taking Pictures in Different Scene Shooting Modes .................................. 36
• Using the Q Mode ................................................................................ 38
• Setting Flash Mode ............................................................................. 39
• Setting ASM Mode .............................................................................. 41
• Setting Self-timer ................................................................................. 43
• Taking Continuous Pictures ................................................................... 44
• Zoom Feature ..................................................................................... 44
4
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
5
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Setting the Image Size and Quality ......................................................... 46
• Setting Light Metering ......................................................................... 47
• Setting White Balance .......................................................................... 48
• Setting the ISO ................................................................................... 49
• Setting Exposure Compensation ............................................................. 50
• Setting the AEB .................................................................................. 51
• Setting the Highlight ........................................................................... 51
• Setting the Sharpness ......................................................................... 52
• Setting the Photo Effect. ...................................................................... 53
• Setting Date/Time, Display On/Off ......................................................... 54
• Setting Camera Shake Warning h Feature ............................................... 55
• Setting Face Tracking ........................................................................... 56
• Setting Smile Capture ........................................................................... 57
• Setting Photo Frame ............................................................................. 58
• Setting AF Lamp .................................................................................. 60
4 Recording Movie Clips .............................................................................. 61
• Recording Movie Clips ......................................................................... 61
• Setting the Movie Size .......................................................................... 61
• Setting the You Tube Mode ................................................................... 62
5 Recording Audio Clips .............................................................................. 63
• Voice REC Clip ................................................................................... 63
• Recording a Voice Memo for the Desired Image ....................................... 63
6 Managing Pictures and Video Clips ............................................................ 65
• Reviewing Pictures .............................................................................. 65
• Magnifying & Trimming the Displayed Picture .......................................... 65
• Rotating the Displayed Picture .............................................................. 66
• Changing the Image Effect .................................................................... 67
• Changing the Image Size ...................................................................... 68
• Reviewing Pictures and Video Clip Files in Thumbnail .............................. 69
• Running a Slide Show on the LCD screen ................................................ 69
• Playing a Video Clip on LCD Screen........................................................ 71
• Playing Audio Clips .............................................................................. 71
• Playing a Voice Memo .......................................................................... 72
• Protecting/Unprotecting Pictures, Movie and Audio Clips .......................... 73
• Deleting Pictures, Video and Audio Clips ................................................ 74
• Viewing Pictures and Video Clips on a TV .............................................. 75
7 Print Settings .......................................................................................... 77
• About PictBridge .................................................................................. 77
• Resetting to Default Settings ................................................................ 83
• About DPOF ....................................................................................... 84
8 Using the SD (Secure Digital) Card ............................................................ 86
• Using the SD Card ............................................................................... 86
• Formatting a SD card .......................................................................... 89
• Copying Pictures, Video and Audio Clips to Memory Card ........................ 90
9 Installing the Software onto a Computer..................................................... 91
• Installing the Software .......................................................................... 91
• Software Included with Your Camera ..................................................... 93
• Computer System Requirements ............................................................ 94
• Fast and Easy YouTube™ Upload ............................................................ 95
10 Transferring Pictures and Video Clips to a Computer .................................. 96
• Before Transferring Files ....................................................................... 96
• Connecting to Your Computer ............................................................... 96
• Transferring Pictures and Video Clips to a Computer ................................ 97
11 Troubleshooting Problems ....................................................................... 99
12 Getting Help ....................................................................................... 102
• Polaroid Online Services ...................................................................... 102
• Software Help ................................................................................... 102
13 Appendix ............................................................................................ 103
• Technical specifications ...................................................................... 103
• Uninstalling Polaroid i1037 Driver (PC only) ........................................... 105
• Camera Default Settings ..................................................................... 106
• Tips, Your Safety & Maintenance ......................................................... 108
• Regulatory Information ....................................................................... 108
6
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
7
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
1 Getting Started
Thank you for selecting the new Polaroid i1037 digital camera for
your imaging needs. The i1037 comes equipped with a powerful 10.0
Megapixels CCD sensor, 2.7-inch bright color TFT LCD, high quality optics
and many manual settings and options.
Outstanding features that your i1037 digital camera has:
• A high quality glass lens system for exposures from 6.3 inches to
infinity including 3 times optical and 4 times digital zoom modes.
• Built-in flash with five modes (Auto, Red-eye, Always On, Slow Sync
and Flash Off).
• Free to edit your images and print your pictures by DPOF.
• Large 2.7 inch LCD screen for easier image preview and review.
• Camera Package Contents
Quick Start Guide
Guide de Démarrage rapide
Schnellanleitung
Guida Rapida
Guía Rápida de Inicio
Guia de Início Rápido
i1037
Quick Start Guide
The CD-ROM includes
Polaroid i1037 Camera Driver (PC)
ArcSoft MediaImpression™: (PC/Mac)
ArcSoft Print Creations® (PC/Mac)
Adobe® Acrobat® Reader™ (PC/Mac)
User Guide (in PDF format)
• Convenient multiple shooting modes for more accurate reproduction
of pictures.
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
Wrist Strap
2 x AA Batteries
USB Cable
8
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
9
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Attaching the Wrist Strap
1
2
• Installing the Batteries
Two AA-size batteries are supplied with the product. For a detailed guideline
on battery usage, please see “Using Your Batteries” on page 9.
1. Open the camera’s battery/SD card door by pushing it outwards as
illustrated.
2. Insert the batteries as shown, ensuring you follow the +/- signs
correctly.
3. Close the battery/SD card door by pressing it downwards and then
sliding it towards the camera to lock.
1
2
3
• Using Your Batteries
There are four types of batteries that are suitable for your camera:
Alkaline, NiMH, Lithium and Oxyride. Please select the type of
batteries you are using in the set up menu. For more details,
please refer to “Selecting the Battery Type” on page 29.
IMPORTANT NOTE:
• For best performance and prolonged battery life, we recommend using a
brand name high capacity battery.
• To ensure the camera displays the battery level correctly, please set the
type to match the batteries being used.
Here are some helpful hints to extend battery life considerably by limiting
the following activities:
• Reviewing the pictures on the LCD screen.
• Use the optical viewfinder (if applicable) to frame the subject when
taking pictures.
• Reduce the excessive use of the flash.
• Remove batteries from your camera when not in use for long periods
of time.
WARNING!
• Do not short the supply terminals.
• Do not dispose the batteries in fire.
• Do not touch or push the lens back when the camera hangs due to low
battery. Please replace the batteries and power on the camera.
These instructions should be retained for future reference.
10
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
11
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Checking the Battery Level
Check the battery power level before taking pictures.
1. Turn on the camera.
2. Check the battery power level that appears on the LCD screen.
Battery power is full.
10 M
Battery power is adequate.
Battery power is exhausted. Please
replace the battery.
+0.7EV
• Turning the Camera On and Off
1. Press and hold the (POWER) button
until the LCD screen is activated.
2. Press the (POWER) button again to
turn the power off.
9999
2 Camera Settings
• Checking Camera Status
Turn on the camera, view the camera’s LCD screen to check which
camera settings are active. Those particular features whose icons are not
displayed are not activated.
IN
• Capture Modes
123
Still Image Mode
AUTO
No. Description Icon Ref. Page
1 Macro Mode tt 35
2 Flash Mode
3 Shooting Mode
4 Image Resolution
5 Quality
6 Sharpness
10 M
4
5
6
7
8
9
+0.7EV
10 1 1 12
, , , ,
10 M
, ,
2526
2
F2.8 1/30
813 1 4
16:9
,8M,5M,3M,
x4.0
24
AUTO
IN
VG A
23
22
21
20
19
18
17
16
39
36
46
46
52
9999
15
12
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
13
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
No. Description Icon Ref. Page
7 AEB
8 Date Stamp
9 Exposure Compensation Value
10 Shake Warning
11 Face Tracking
2EV
51
54
50
---
56
12 Aperture Value F2.8 ~ F5.2 ---
13 Focus Mark
---
14 Shutter Speed 1/2000 sec ~ 8 sec ---
15 White balance
, , , , , , AUTO
48
16 Histogram ---
17 Highlight
18 ISO Sensitivity
19 Light Metering
20 Stabilizer
Internal Memory
21
SD Card
22 Battery Power Level
23 Number of Remaining Pictures
OFF,
50, 100, 200, 400, 800
, ,
IN
, ,
9999
,
1600
, AUTO
51
49
47
55
---
---
10
---
24 Digital Zoom Factor X 1.0 ............ X 4.0 44
25 Optical & Digital Zoom Bar
Self-timer
26
Continuous Pictures
2, 10
,
44
43
43
Movie Mode
1
2
10
00:01:30
3 5
4
9
8
7
IN
6
No. Description Icon Ref. Page
1 Movie Mode
2 Movie Size
3 Focus Mark
4
White Balance
5
Light Metering
6
Internal Memory
, ,
AUTO,
,
, ,
IN
Share
, , , ,
SD Card
7 Battery Power Level
, ,
8 Remaining Recording Time 00:01:30 ---
9 Optical & Digital Zoom Bar
10 Macro Mode
58
59
----
48
47
---
---
10
44
35
14
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
15
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
Audio Mode
1
00:09:12
No. Description Icon Ref. Page
1 Audio mode
2
Internal Memory
IN
SD Card
Battery Power Level
3
, ,
4 Remaining Recording Time 00:09:12 ---
4
3
2
IN
60
---
---
10
• Playback Mode
v
10M
1
2
+2.0EV
F2.8
1/30
2008/01/01 18:59
3
5/150
5
320
IN
4
:Play
6/150
7
IN
6
2008/01/01 18:59 2008/01/01 18:59
No. Description Icon Ref. Page
1 Resolution
1 0 M
2 DPOF
3 Recording info ---
4 Date & Time ---
5 Playback mode ---
Internal Memory
6
SD Card
Battery Power Level
7
IN
, ,
8 Protect
9 File Number / Total Number 7/160 ---
:Play
8
9
7/150
IN
---
---
---
---
10
69
16
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
17
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Camera Modes
The camera has two working modes, Capture mode
and Playback mode. Pressing the PLAYBACK button
switches between the Capture mode and Playback
mode.
• Capture Modes
The camera has three modes for recording: still images, video clips and
audio clips.
Selecting these three modes as follows:
menu
scene
1. Press the button to set the camera to
capture mode.
PROGRAM
Capture Mode
In this mode, you can record still images, video and audio clips. This
mode allows you to select the image and video settings according to the
shooting environment. For more details, refer to “Taking Pictures” on page
33, “Recording Movie Clips” on page 61 and “Recording Audio Clips” on
page 63.
Playback Mode
This mode allows the review, rotation, protection or deletion of pictures
and video clips from the camera. You can add a voice memo to a picture.
For more details, please refer to “Managing Pictures and Video Clips” on
page 65.
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
2. Press the t button to access the scene
mode palette.
3. Press button to select the desired
setting.
4. Press the button to confirm your
choice.
No. Description Icon
1 Still Image Mode
2 Video Mode
3 Audio Mode
SELECT
OK
18
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
19
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• How to Navigate Menus
Menus are used to select capture and play
settings, as well as other camera settings like the
Date/Time and Auto Power Off.
• Setup Menu
You can change the basic settings of the camera in Capture mode and
Playback mode.
1. Press the
2. Press the or button to choose (Setup).
menu
button.
1. Press the
menu
button to enter a menu bar and
press it again to exit.
2. Press the and buttons to scroll left and
right through the menu bar.
3. Press the and buttons to scroll up and
down through menu options.
4. Press the button to enter a submenu or
confirm your choice.
menu
scene
Menu button
7M1 0 M
10M
3:2
16:9
8M
5M
Resolution
ISO
WB
3. Press the button to enter the setup menu.
4. Press the
menu
button to exit the setup menu.
SETUP MENU 1/3
Enter
Setup
Sounds
Auto Review 3 Sec.
Power Save 3 Min.
Date & Time
Language English
Select
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
Exit
menu
scene
Menu button
20
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
21
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Adjusting the Sounds
You can set the start-up, shutter and beep sounds in the Setup mode.
Setup Menu 1/3
2. (Sounds) is the current selection.
3. Press the or button.
4. “Shutter” is the current selection.
5. Press the or to select the desired item.
6. Press the or button to select the desired
setting.
7. Press the button.
Sounds
Auto Review 3 sec
Power Save 1 min
Date & Time
Language English
Select
Sounds
Shutter On
START-UP 1
Beep On
Volume
Select
• Selecting Auto Review Period
When the auto review feature is activated, the picture just taken will be
shown on the LCD screen for a certain period.
1. Access the setup menu.
2. Press the or button to select ( Auto Review
).
Exit
3. Press the or button.
4. Press the or button to select the desired
setting.
OK
5. Press button.
OFF The auto review feature is not activated.
Setup Menu 1/3
Sounds
Auto Review 3 sec.
Power Save 1 min
Date & Time
Language English
Select
Setup Menu 1/3
Sounds
Auto Review
Power Save
Date & Time
Language
Select
Exit
Off
1 Sec.
3 Sec.
5 Sec.
OK
Shutter You can turn the shutter sound on or off in the Setup mode. When the
Start-up You can set the start-up sound in the Setup mode. When the start-
Beep You can turn the beep sound on or off in the Setup mode. When the
Volume Adjusting the volume of the shutter sound, start-up sound, beep and
shutter sound is turned on, the camera will beep when you press the
shutter button.
up sound is turned on, the camera will beep when you power on the
camera.
beep sound is turned on, the camera will beep when you press the
buttons.
playback sound.
1/3/5 Seconds The picture just taken will be shown on the LCD
screen for a certain period.
NOTE:
This setting is also available in
(Video) mode.
22
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
23
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Power Saving Settings
The camera performs the following power save operation to conserve
battery power.
1. Access the setup menu.
2. Press the or button to select (Power
Save).
3. Press the or button.
4. Press or to select the desired setting.
5. Press the button.
1/3/5 MIN The camera is designed to switch off automatically to save
battery life after the specified period of inactivity.
NOTE:
This setting is not active in the following situation:
• Recording movie clips or audio les
• Playing movie clips or audio les
• Playing slideshow
• Connecting the camera to a computer or printer with the USB cable
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
Setup Menu 1/3
Sounds
Auto Review 3 sec.
Power Save 1 min
Date & Time
Language English
Select
Setup Menu 1/3
Sounds
Auto Review
Power Save
Date & Time
Language
Select
Exit
1 Min.
3 Min.
5 Min.
OK
• Setting the Date and Time
1. Access the setup menu.
2. Press or button to select (Date & time).
Setup Menu 1/3
3. Press the or button.
4. Press the or button to select a field, such
year, month, day, hour, minute, and date
format.
5. Press or button to adjust the value in the
field and select the date format.
6. Press the button.
NOTE:
• If the batteries are removed for about two days, the time setting will be
lost.•
This setting is also available in
(Video) and (Playback) modes.
Sounds
Auto Review 3 sec
Power Save 1 min
Date & Time
Language English
Select
Date & Time
2009 / 01 / 01 18:59
YY/MM/DD
Select
Exit
OK
24
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
25
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Setting the Display Language
Under this setting, you can select the language you prefer for the LCD
screen.
1. Access the setup menu.
2. Press the or button to select
(Language).
3. Press the or button.
4. Press the or button to select the desired
setting.
5. Press button.
Setup Menu 1/3
Sounds
Auto Review 3 sec.
Power Save 1 min.
Date & Time
Language English
Select
Setup Menu 1/3
Sounds
Auto Review
Power Save
Date & Time
Language
Select
Exit
English
Español
Deutsch
Français
Italiano
OK
• File No. Reset Setting
Setting the file numbers in series for all pictures taken on the internal
memory or a memory card avoids file name duplication when images are
downloaded to a computer.
1. Access the setup menu.
2. Press the or to select ICON (File No.).
3. Press the or button.
4. Press the or button to select the desired setting.
Setup Menu 2/3
File No. Series
TV Out NTSC
USB Computer
Start-up Image
Format No
Select
Exit
Setup Menu 2/3
File No.
TV Out
USB
Start-up Image
Format
Select
Series
Reset
OK
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
SERIES The le number of a newly-captured picture will continue from
the last number used.
RESET The picture le number starts from 0001
5. Press the button.
26
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
27
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Choosing a Startup Image
A start-up animation image appears on the LCD screen for a few seconds
when the camera is turned on.
You can choose a recorded image in your camera as your own startup
image:
1. Press the button to set the camera to
Playback mode.
2. Press the or button to select a desired
image.
3. Press the
menu
button.
4. Press the or button to select (Start-up
Image).
5. Press the button. A hint window will
appear on the left bottom corner of the LCD.
6. Press the or button to confirm or give up
your choice.
7. Press the button to apply the choice.
8. Press the button to set the camera to
Capture mode.
9. Press the
menu
button.
10M
Start-up Image
Select
10M
Set this?
Yes
+2.0EV
F2.8
1/30
2008/01/ 01
+2.0EV
F2.8
1/30
2008/01/ 01
5/150
IN
18:59
OK
5/150
IN
18:59
10. Access the setup menu.
11. Press the
or button to select (Start-up
Image).
12. Press the or button.
Setup Menu 2/3
File No. Series
TV Out NTSC
USB Computer
Start-up Image
Format No
Select
13. Press the or button to select the desired
picture.
14. Press button.
Start-up Image
The image that you choose will stored in
directory as a startup image.
15. Press the
NOTE:
The startup image will not be deleted even if the original image is deleted or
memory is formatted.
menu
button to exit the menu.
Off
System
My image
Select
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
Exit
OK
28
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
29
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Formatting the Internal Memory
Formatting the internal memory deletes all data stored in it.
1. Access the setup menu.
2. Press or to select (Format).
3. Press the or button.
4. Press the or button to select the desired
setting.
5. Press the button.
NOTE:
• Data deleted by a format operation is not recoverable. Make sure you do not
have any useful data currently stored in the internal memory before you format
it.
• Formatting the internal memory destroys all the pictures, even those are
protected.
• With a memory card inserted, the above operation would format the inserted
memory card only. The internal memory will not be formatted.
• This setting is also available in
(Video) and (Playback) modes.
Setup Menu 2/3
File No. Series
TV Out NTSC
USB Computer
Start-up Image
Format No
Select
Setup Menu 2/3
File No. Yes
TV Out No
USB
Start-up Image
Format
Select
• Selecting the Battery Type
NOTE:
It is VERY important that the correct battery type be selected.
To ensure the camera displays the battery level correctly, set the type to
match the batteries used.
Exit
1. Access the setup menu.
2. Press or to select (Battery Type).
3. Press the or button.
4. Press or to select the type you want.
OK
t
5. Press the button.
Setup Menu 3/3
Battery Type Alkaline
Reset All No
Select
Setup Menu 3/3
Battery Type
Reset All
Select
Alkaline
NiMH
Lithium
Oxyride
Exit
OK
30
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
31
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Resetting to Default Settings
You can easily change all the settings you made back to the camera
default setting by the following steps.
Please refer to “Camera Default Settings” on page 106 for more details.
1. Access the setup menu.
2. Press or to select (Reset All).
Setup Menu 3/3
Battery Type Alkaline
Reset All No
• Turning the Information Display On/Off
Press the button each time switches
the LCD screen to the next display mode in
the following mode.
menu
scene
3. Press the or button.
4. Press or to select “YES”.
5. Press the button.
NOTE:
The following settings do not change with this procedure:
• Date & Time setting
• Language setting
• TV out setting
• Battery Type
Select
Setup Menu 3/3
Battery Type
Reset All
Select
Exit
Yes
No
OK
1 0 M
+0.7EV
Still Image Mode
1
2
1 0 M
IN
Press
+0.7EV
1
1
2
IN
Press
AUT O
Press
2
Press
+0.7EV
2
+0.7EV
About Crossing Lines
The crossing lines on the LCD helps check and lock the location of your
subject when you frame it on the LCD screen.
32
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
33
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
Video Mode
3 Taking Pictures
00:01:30
IN
Press
Playback Mode
2008/0 1/01
5/150
IN
18:59
10M
Press
10M
NOTE:
• You can not change the LCD status in the following situation:
• Recording video clips or audio les
• Playing video clips or audio les
• Playing the slideshow
• Viewing in thumbnail
• Trimming a still image
5/150
Press
IN
+2.0E V
F2.8
1/30
2008/01/01
18:59
Press
Before you take pictures, please read this note rst:
NOTE:
Never remove the batteries while a picture is being saved. Doing so will prevent
the current picture from being saved and may corrupt other pictures already
stored on the camera’s internal memory or a memory card.
• Taking Pictures in Normal Mode
You can take pictures at approximately 2.6 feet to infinity (80 cm to
infinity).
NOTE:
Most settings are saved by the camera when the power is turned off so that the
same setting is automatically available when the power is turned on again. Make
sure you verify your settings when turning the camera on again.
1. Set the camera to the Still Image mode.
2. Frame your subject using the LCD screen.
3. Press the Shutter button halfway to set the exposure and focus. The
camera automatically detects the subject. The camera highlights the
focus mark in green and the Auto Focus LED remains continuously
on, indicating the camera’s focus is locked on the subject. (When the
camera’s focus mark is red and the green Auto Focus LED blinks, the
subject is not in focus.) Release the shutter button, recompose the
scene and press the Shutter button halfway to reset the focus.
34
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
35
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Taking Pictures in Macro Mode
1
IN
Focus mark
AUTO
Shutter speed
menu
scene
Auto Focus LED
1 0 M
F2.8 1/30
+0.7EV
Aperture value
NOTE:
(Still Image) mode is the capture mode by default.
•
P
• The LCD screen will show you the aperture value and shutter speed at which
you take the picture.
• If the shutter speed is slow your image may become blurred, the shake
warning icon
may appear on the LCD screen. Should you see the shake
warning, the use of a tripod is recommended, enable the camera stabilizer
feature or change the flash mode to “Always On”.. Refer to page 55.
4. Hold the camera steady and slowly press the shutter button down to
take your image.
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
Use this mode to capture subjects close to the lens:
Wide Angle: 0.5 ~ 3.3 ft (10 cm ~ 1.0 m)
Telephoto: 1.3 ~ 3.3 ft (40 cm ~ 1.0 m)
1. Set the camera to Still Image mode.
2. Press the button and the icon appears
on the LCD screen.
3. Capture procedures are the same as for
taking a picture in the normal capture mode.
See page 33.
1 0 M
+0.7EV
Macro
1
IN
AUTO
36
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
37
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Taking Pictures in Different Scene Shooting Modes
Select a mode that is suitable to your shooting conditions:
1. Set the camera to Still Image mode.
2. Press the
shooting mode screen.
3. Press the
desired setting.
4. Press the button.
5. Capture procedures are the same as for
taking a picture in the normal capture
mode. See page 33.
Call our customer service help number. Look for the insert with this icon:
scene
button to show the scene
or , trrt button to select the
Need help with your digital camera?
Or visit www.polaroid.com.
SELECT
PROGRAM
Display Option Description
Program All settings can be changed in this mode
Movie For recording movie clips
Audio REC For recording audio
Q Mode Allows beginners to take pictures easily.
Portrait Blurring the background to focus on the subject
OK
Landscape Used for the wide scenic views
Sunset Enhance the red hue for recording sunset images
Backlight Shooting the image of backlight object by changing metering
Smile Capture Used for locating smiles in your pictures (see page 57)
Children Take a still image to capture moving children
Night Scene Shooting the subject while keeping the background night scenery
Fireworks Slow shutter speed to take reworks exploding.
Snow Used for the beach or snow scenes.
Sports Used to take still pictures in high speed motions.
Party Used for the wedding or indoor parties.
Candlelight To capture the warmth effects of candle light.
Night Portrait Use to take portrait pictures when the background is darker.
Soft Skin Enhance the tone of skin so that the facial skin appears smooth.
Soft Flowing
Water
Food Increased color level makes food more appetizing
Can take pictures with effects as smooth as silk.
38
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
39
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
Display Option Description
Building Enhance the edges of the subject
Text Enhance the black & white contrast
Auction Records small-size images that are perfect for auction notices.
Aperture
Priority
Shutter Priority
Manual
Exposure
Photo Stitch Used for taking panoramic pictures
Blink Detection Used for detecting whether the subjects’ eyes are open
The camera automatically adjusts an aperture value to match
the brightness.
The camera automatically adjusts the shutter speed to match
the brightness.
This feature allows the user to adjust shutter speed and
aperture value to correctly expose your images
• Using the Q Mode
The Q mode provides a simplified camera interface. Larger icons and
fewer controls make it easier to take pictures anytime, especially for the
beginners and first time digital camera users.
1 0 M
You can only use the following basic settings in the Q mode.
Flash: Auto / Red eye / Always on / Slow sync / Off
Button
Menu
NOTE:
• When you rst power on the camera after you purchased it, the camera
will be in Q mode. Follow the operation guides on page 17 or 36 to set the
camera to other capture modes.
• When you power on the camera after resetting to default settings, the camera
will be in Q mode. Follow the operation guides on page 30 to reset to default
settings.
Macro: Off / On
SET/ DISP: OSD On / Guide Line / OSD Off
Resolution: 10M / 3:2 / 16:9 / 8M / 5M / 3M / VGA
Drive Mode: Off / 2 sec. / 10 sec. / Double / Burst
Face Tracking: Off / On
Photo Frame: Off
Beep: Off / On
Auto Review: Off / 1sec. / 3 sec. / 5 sec.
9999
40
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
41
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Setting Flash Mode
A
Flash Range:
For Normal mode:
Wide Angle: 2.6 ft ~ 8.0 ft ( 40 cm ~ 2.5 m )
Telephoto: 2.6 ft ~ 5.0 ft ( 40 cm ~ 1.2 m )
For Macro mode:
Wide Angle: 0.5 ft~ 3.3 ft (0.15 m ~ 1.0 m)
Telephoto: 1.3 ft ~ 3.3 ft (0.4 m ~ 1.0 m)
1. Set the camera to Still Image mode.
2. Press the button to cycle through the flash settings and select the
one you need. The icon (according to the flash setting you selected)
will appear on the LCD screen.
1 0 M
1
IN
Display Option Description
Auto
Red-eye
Reduction
Always On
Slow Sync
S
Off
The ash res automatically as needed. Use this
setting to take most pictures.
The ash res a few times before taking your picture
to reduce the red-eye phenomenon.
The ash res for every picture. Use this setting in
high-contrast situations to provide ll-light. Use it
indoors in low light or you see the shake warning.
The ash res regardless of the surrounding
brightness. In low light conditions, slow shutter
speed provides better lighting of the background that
is out of range of the ash.
The ash does not re. Use this setting for outdoor
pictures or where ash is prohibited or may be
distracting. Also use when shooting toward a
reective surface, such as a window or mirror. If you
do not have enough light when using this setting,
your pictures will be too dark.
AUTO
+0.7EV
Flash
The camera has five flash modes (default setting is Auto Flash). Use
the flash when you take pictures at night, indoors, or outdoors in heavy
shadows or you see the shake warning.
NOTE:
• Flash modes are only used in still image shooting.
• Never touch or block the ash with your ngers.
• The ash charging time may increase when the battery is low.
42
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
43
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
Using the Aperture Priority
Using the aperture-priority mode, you select an aperture and the camera
chooses an appropriate shutter speed to match the brightness. The main
purpose of using aperture-priority mode is to control the Depth of Field.
A higher aperture value brings the background in focus. Selecting a lower
aperture value allows you to soften the background.
Using the Shutter Priority
Using the shutter-priority mode, you select a shutter speed and the
camera chooses an appropriate aperture value to match the brightness.
The main purpose of using the shutter-priority mode is to have a faster
shutter speed to freeze the action of fast-moving subjects or to have a
slower shutter speed to blur moving subjects in order to create a sense
of motion. Faster shutter speeds allow you to take a sharp picture of a
moving subject while slower speeds create a trail effect and allow you to
shoot without a flash in dark areas.
Using the Manual Exposure
Using the manual exposure mode, you can set both aperture and shutter
speed, and, therefore, you have complete control over the exposure
system, including exposure compensation.
Press the shutter button halfway, the difference between the standard
exposure and the selected exposure appears in red.
• Setting Self-timer
Your camera is designed with a self timer
function which will allow you to take pictures
with a countdown of 2 or 10 seconds.
1. Press the button to set the camera to
Still Image mode.
2. Press the
menu
button to enter menu bar.
3. Press the or button to choose (Drive
Mode).
4. Press the or buttons to scroll up and
down through menu options.
5. Press the button.
Display Option Description
Off Single shot Record a single image
2-SEC Take a picture after a count down of 2 seconds
2
10
10-SEC Take a picture after a count down of 10 seconds
Double
Burst
Take two pictures in a shot after a count down of 10
seconds
Press and hold the shutter button to take pictures in quick
succession
6. Capture procedures are the same as for taking a picture in the normal
capture mode. See page 33.
NOTE:
• This feature is only available in Still Image mode.
• Place the camera on a at surface or use a tripod when using the self-timer
function.
Off
2 sec
10 sec
Double
Burst
Drive Mode
menu
scene
44
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
45
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Taking Continuous Pictures
Continuous pictures mode allows you to take pictures continuously until
release the shutter button.
1. Follow the selection steps 1~4 on page 43.
2. Select and press the button.
3. Capture procedures are the same as for taking a picture in the normal
capture mode. See page 33.
NOTE:
• The flash is automatically disabled in the
(Continuous) mode.
9999
10 M
+2.0EV
IN
AUTO
• Zoom Feature
There are two types of zoom in this camera: optical zoom and digital
zoom. Optical zoom alters the focal distance, and its factor range is 1X to
3X. Digital zoom is activated after you reach the maximum optical zoom
(3X). It enlarges the part of the image at the centre of the image screen.
Digital zoom factor range is 1X to 4X. These zoom features let you zoom
in the central area of an image and photograph only the enlarged portion
of the picture.
NOTE:
• Using the digital zoom may cause a decrease in image quality.
Turn Digital Zoom On/Off
1. Set the camera to Still Image mode.
2. Press the
3. Press or button to select ICON
menu
button.
Off
On
Digital Zoom
(Digital Zoom).
4. Press or button to select the desired setting.
5. Press the button.
To Zoom In and Out
1. Set the camera to Still Image mode.
2. Press the to zoom in the subject, or press the button to return
to original zoom status. While you press the or buttons, a red
square will show on the zoom status bar as illustrated. The white
square in the bar indicates the zoom status. “T” stands for “Tele”
and “W” stands for “Wide”. Keep the button pressed, and the
camera switches from optical zoom to digital zoom when it reaches
the maximum optical zoom.
3. Now you can takes pictures and review them under the zoom setting
you just made. The zoom setting will remain after pictures are taken.
If you want to take a normal size picture, please use the button.
x3.0
Digital Zoom
Red Square
1
IN
AUTO
Digital zoom
status
Zoom Button
(Thumbnail)
Zoom
Button
(Digital zoom)
Optical Zoom
1 0 M
+0.7EV
46
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
47
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Setting the Image Size and Quality
Picture resolution refers to the number of pixels in a digital picture. Picture
quality depends on the JPEG file compression that the camera applies
when the picture is taken. Higher resolution and less compression make
better quality which occupies more memory space. Smaller size pictures
with normal quality are easier to email while larger size with fine quality
are better for printing.
Resolution setting
1. Set the camera to Still Image mode.
1 0 M
7M
2. Press the
menu
button.
3. Press the or button to select
(Resolution).
4. Press the and button to select the desired
setting.
5. Press the button.
Quality setting
1. Set the camera to Still Image mode.
2. Press the
menu
button.
3. Press the or button to select (Quality).
4. Press the and button to select the desired
setting.
5. Press the button.
10M
3:2
16:9
8M
5M
Resolution
ISO
WB
Super Fine
Fine
Normal
Quality
ISO
WB
• Setting Light Metering
Use the light metering setting to ensure that the proper amount of light
enters into the camera lens.
1. Set the camera to Still Image mode.
2. Press the
menu
button.
3. Press the or button to select
(Metering).
4. Press the and button to select the
desired setting.
5. Press the button.
Option Description
Light is measured from the entire shooting screen, but gives more importance
to the values near the center.
Selects an exposure based on readings from multiple points in the subject area.
Selects an exposure based on a single reading taken from the center of your
picture.
NOTE:
This setting is also available in
(Video) mode.
Center
Multi
Spot
Metering
ISO
WB
48
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
49
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Setting White Balance
Selecting the right type of white balance can help to make the color of a
subject appear more natural under the type of lighting that is available.
1. Set the camera to Still Image mode.
2. Press the
3. Press the or button to select WB (White
Balance).
4. Press the and button to select the
desired setting.
5. Press the button.
Option Description
AUTO
button.
menu
Automatic adjustment. Use this for most picture taking scenes.
Outdoor daylight
Cloudy
Indoors, illuminated by incandescent light bulbs
Adjusts for uorescent lighting. Corrects the green hue of uorescent
lighting. Ideal for indoor photos under uorescent lighting without a ash
For more accurate adjustment or when the light source cannot be
specied
Auto
Daylight
Cloudy
Tungsten
Fluor_H
White Balance
WB
ISO
• Setting the ISO
This function enables you to change the camera’s sensitivity to light by
selecting the different ISO values. ISO is a measure of how quickly your
camera reacts to light. The higher the ISO value, the less light the camera
needs to make an exposure, allowing the same exposure to be achieved
with higher shutter speeds or smaller apertures. In a digital camera, higher
ISO value allows higher shutter speed, at the expense of mottled or grain
appearing in the final picture.
Auto
1. Set the camera to Still Image mode.
2. Press the
menu
button.
125
200
400
800
3. Press the or button to select “ISO”.
4. Press the and button to select the desired setting.
5. Press the button.
AUTO The camera’s sensitivity is automatically changed by
different lighting value or subject brightness.
125/200/400/800 In the same lighting condition, the higher the ISO
/1600/3200 value is, the faster the shutter speed will be.
NOTE:
• Higher ISO speeds increase the image noise. To get better images, use as low
as an ISO speed as possible.
AUTO
ISO
ISO
WB
NOTE:
This setting is also available in
(Movie) mode.
50
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
51
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Setting Exposure Compensation
You can adjust the exposure compensation value (EV) within the range
of -2EV to +2EV in order to compensate for current lighting conditions.
This setting can be used to obtain better result when shooting with
backlighting, indirect indoor lighting, a dark background, and so on.
1. Set the camera to Still Image mode.
2. Press the
3. Press the or button to select
“Exposure”.
4. Press the and button to select the desired
setting.
5. Press the button.
NOTE:
• A higher EV value is better used for light-colored and backlit subjects. A lower
EV value is better for dark-colored and shooting outdoors on a clear day.
• When shooting under very dark or very bright conditions, you may not be able
to obtain satisfactory results even if performing exposure compensation.
Call our customer service help number. Look for the insert with this icon:
menu
button.
Need help with your digital camera?
Or visit www.polaroid.com.
0EV
Exposure
ISO
WB
• Setting the AEB
Use the auto exposure bracketing (AEB) to shoot 3 continuous images,
each with a different exposure setting: correctly exposed, underexposed
and overexposed.
1. Set the camera to Still Image mode.
2. Press the
menu
button.
3. Press the or button to select (AEB).
Off
On
AEB
4. Press the and button to select the desired
setting.
5. Press the button.
• Setting the Highlight
This function makes the background slightly out of focus and makes the
subject standout from the surroundings.
1. Set the camera to Still Image mode.
2. Press the
menu
button.
3. Press the or button to select
(Highlight).
4. Press the and button to select the desired
setting.
5. Press the button.
Off
Highlight
52
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
53
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Setting the Sharpness
Use the sharpness setting to highlight or blend the edges of subjects in
pictures.
1. Set the camera to Still Image mode.
2. Press the
3. Press the or button to select
(Sharpness).
4. Press the and button to select the desired
setting.
5. Press the button.
menu
button.
Option Description
Increases contrast on the edge of the picture. But noise may
occur in the recording image.
The edges of the image are sharp. This is suitable for printing.
Soften the edge of the picture, creating a “soft focus” effect.
Hard
Normal
Soft
Sharpness
• Setting the Photo Effect
This setting allows control over the color tones and moods of a picture.
1. Set the camera to Still Image mode.
2. Press the
menu
button.
3. Press the or button to select (Effect).
4. Press the and button to select the desired setting.
(You can see the effect you want on the LCD display).
5. Press the button.
Option Description
Off No effect is added to the image
Red eye removal. (Playback only)
B&W Convert image to black & white
Sepia Recorded image will be stored in a sepia tone
Negative Opposite what was in the original image (Playback only)
Mosaic Add mosaic tiles to the images (Playback only)
Red The images becomes reddish
Green The images becomes greenish
Blue The images becomes bluish
NOTE:
• This setting is available in Still Image and Playback modes.
• The mosaic effect only can be set in Playback mode.
Off
B&W
Sepia
Red
Green
Effect
54
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
55
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Setting the Date Stamp On/Off
Date and time can be displayed on the picture by the following steps:
1. Set the camera to Still Image mode.
2. Press the
3. Press or button to select (Date
Stamp).
4. Press and button to select the desired
setting.
Call our customer service help number. Look for the insert with this icon:
menu
button.
Option Description
Off Do not add the recorded date & time to printed images
Date Only add the recorded date to printed images
Date & Time Add the recorded date & time to printed images
Need help with your digital camera?
Or visit www.polaroid.com.
Off
Date
Date & Time
Date Stamp
• Setting the Camera Stabilizer Feature
With more sensitivity and faster shutter speeds to brighten up the pictures,
using this feature will prevent blurred images caused by camera shake and
subject motion.
To activate Stabilizer
Press the Stabilizer button on top of
your camera to enable/disable stabilizer.
If Stabilizer is enabled, the stabilizer icon
is displayed on the LCD monitor.
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
56
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
57
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Setting Face Tracking
When this feature is on, the camera uses auto digital zoom technology to
retract and extract the zoom lens to lock the main subject in the picture
and follow their movements.
1. Set the camera to Still Image mode.
2. Press the
3. Press or button to select (Face
Tracking).
4. Press and button to select the desired
setting.
NOTE:
• The camera uses the single AF window to automatically set the focus. When
the shutter button is pressed halfway, the camera starts focusing until it
“locks” onto your subject. When in focus, the focus frame will turn green. If
your subject is not in focus, the focus frame will turn red. Release the shutter
button and press the shutter button halfway down again until it turns green.
Press the shutter button all the way down to take you picture.
• Face tracking is powered by Arcsoft.
• In some photographic scenes, the face tracking function may not be
available.
menu
button.
Off
On
Face Tracking
• Setting Smile Capture
This Feature is based on “Face Tracking”. When you use smile capture,
the face tracking feature will automatically turn on.
1. Set the camera to Still Image mode.
2. Press the
shooting mode screen.
3. Press the and , or button to
select (Smile Capture).
4. Press the button.
5. Frame your subject using the LCD
screen.
6. The Camera auto detects faces that are
close to the center of the screen and
displays the AF frames (up to 5 frames).
7. Fully press the shutter button to start the
smile capture feature.
8. The camera will search for smiles on
faces and main AF frames will turn green
when detected.
9. When all detected faces smile, the
camera will take the pictures without
you having to press the shutter button
again.
scene
button to show the scene
SELECT
Smile Capture
OK
58
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
59
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
NOTE:
• There is a 15 second time-out to detect the smiles. If a smile is not detected
after 15 seconds, the camera will not take photos. Should this happen, you
must press the shutter button to disable the featureand press it again to
capture smiles in your image.
• In Smile Capture mode, it will take 6 continuous shots.
• The following functions are not available in Smile Capture mode:
• Drive Mode
• Photo Effect: Negative, Blue, Green
• Highlight
• Photo frame
• Setting Photo Frame
You can add 10 kinds of frames to still images, making them more
interesting.
1. Set the camera to Still Image mode.
2. Press the
3. Press or button to select (Photo
Frame).
4. Press and button to select the desired
setting.
menu
button.
Off
Photo Frame
Option Description
Off Taking pictures without Photo Frame
Frame 1 Little Animals Frame.
Frame 2 Pirate Frame.
Frame 3 Little Flower Frame
Frame 4 Cartoon Frame
Frame 5 Christmas Frame
Frame 6 OSCAR Frame
Frame 7 Benthal Castle Frame
Frame 8 Calendar Frame
Frame 9 Surfride Frame
Frame 10 Sleeping Baby Frame
NOTE:
• This feature only available with still images (except 3:2 and 16:9).
• The Highlight and Face Tracking cannot be used as using the Photo Frame.
60
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
61
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Setting AF Lamp
The AF Lamp function allows you record images in low light conditions.
4 Recording Movie Clips
1. Set the camera to Still Image mode.
2. Press the
menu
button.
3. Press or button to select (Photo
Frame).
4. Press and button to select the desired
setting.
Option Description
Off Disable the AF lamp while recording images.
Auto The AF lamp turns on automatically by half pressing the shutter
button under low light conditions.
Off
Photo Frame
• Recording Movie Clips
Use the Movie mode to record video clips with audio. The Power / Auto
Focus LED button blinks and the remaining time that can be recorded will
decrease in seconds while recording.
1. Set the camera to Movie mode . (See page 17)
NOTE:
icon will appear on the LCD screen,
The
indicating the Movie mode is activated.
00:01:30
IN
2. Frame your subject using the LCD screen.
3. Press the Shutter button to start recording.
4. Press the Shutter button again to stop
recording, or recording stops when the
current memory is full.
5. Press the or button to zoom in or out
the subject.
NOTE:
Digital zoom feature is not available in (Movie) mode.
•
Sound cannot be recorded while pressing the zoom button.
•
• Setting the Movie Size
1. Set the camera to (Movie mode).
2. Press the
3. Press the or button to select
menu
button.
62
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
63
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
(MOVIE SIZE).
4. Press the button.
5. Press the and button to
select the desired setting.
6. Press the button.
Movie Size and Frame Rate
Icon Resolution Imagel Quality
640 x 480 High Quality
320 x 240 Normal
640 x 480 For YouTube
640
320
Share
Movie Size
Movie Size
5 Voice REC Clips
WB
• Recording a Audio Clip
1. Set the camera to (Voice REC mode). (See page 17)
2. Press the Shutter button completely down to start recording.
3. Press the Shutter button again to stop recording or recording stops
when the current memory is full.
00:09:12
IN
REC
00:02:20
• Setting the You Tube Mode
The YouTube Mode allows you to record movies with predened video
settings for easy upload to the YouTube website.
1.YouTube supports two le upload standards:
• Single File Uploader. The maximum movie le size is up to 100 MB.
• YouTube Uploader. The maximum movie le size is up to 1 GB.
Most uploaded movie length ranges within 5 minutes, although you can upload a
maximum movie length of 10 minutes.
2.Therefore when you record using the YouTube mode, the following
standards are followed:
• Recorded movies are set to YouTube standard resolution of 640 X 480.
• Recording automatically stops when the le reaches 100 MB.
NOTE:
• Using VLC software to play videos of the MAC may lead to display issues.
We recommend using the QT player for video playback.
• To record a YouTube movie, select from the Movie Size function.
NOTE:
• The voices are recorded from the microphone of the camera. Be careful to
avoid touching the microphone while recording.
• The camera will stop recording automatically when the memory capacity has
been reached.
• Recording a Voice Memo for the Desired Image
1. Set the camera to the Playback mode.
2. Press the or button to select the desired
image where you want to add a voice memo.
3. Press the
menu
button.
4. Press the or button to select “Voice
10M
+2.0EV
F2.8
1/30
2008/01/ 01
5/150
IN
18:59
64
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
65
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
Memo”.
5. Press button.
6. Press the button to start recording.
7. Press the button again to stop recording.
Voice Memo
Select
OK
5/150
IN
2008/01/ 01
18:59
10M
REC voice?
Start
+2.0EV
F2.8
1/30
5/150
IN
2008/01/ 01
18:59
10M
REC voice?
Stop
00:00
+2.0EV
F2.8
1/30
NOTE:
• The voice memo cannot be added to a video clip
or a protected image.
• You can only delete the voice memo by deleting
the image.
• A voice memo may not exceed 30 seconds.
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
6 Managing Pictures and Video Clips
NOTE:
The camera automatically saves the image as a new le after rotating, resizing
and adding a voice memo to it. Make sure there is suf cient memory before
editing an image.
• Reviewing Pictures
IN
5/150
10M
2008/01/01
18:59
+2.0EV
F2.8
1/30
1. Set the camera to Playback mode.
2. Use the
or buttons to view the pictures
taken.
• Magnifying & Trimming the Displayed Picture
5.0x
SET:
1. Set the camera to Playback mode.
2. Use the
or buttons to select a picture.
3. Press
to magnify the select picture.
4. Press the
or , or button to move
around the magnified picture.
5. Press the
button to view the picture in the
original size.
6. Press the button to set the image
trimming.
7. Press the button again to trim the
selected image and save it as a new one.
66
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
67
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Rotating the Displayed Picture
The currently displayed picture can be rotated for a better review angle
on the LCD screen.
1. Set the camera to PLAYBACK mode.
2. Press the
3. Press the or button to select (ROTATE).
4. Press the button.
5. Press the or button to select “Rotate” to rotate the image and
select “Save” to save the rotated image.
6. Select “ ” to return without rotating.
NOTE:
• The rotated image will be saved and the original le will be deleted.
menu
Select
button.
Rotate
Rotate
Rotate
Save
OK
Select
OK
• Setting the Photo Edit
1. Set the camera to PLAYBACK mode.
2. Press the
menu
button.
3. Press the or button to select
(Photo Edit).
4. Press the button.
5. Press the or button to select the
desired setting.
6. Press the button.
Option Description
Red Eye Removal Remove subject’s red eyes from the images
B&W Convert image to black & white
Sepia Recorded image will be stored in a sepia tone
Negative Opposite what was in the original image
Mosaic Add mosaic tiles to the images
Red The images becomes reddish
Green The images becomes greenish
Blue The images becomes bluish
NOTE:
• The edited image will be saved as a new le and the original le will be
replaced by the new one.
Select
B&W
Sepia
Nagative
Mosaic
Select
Photo Edit
Photo Edit
OK
OK
68
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
69
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Changing the Image Size
Resizing a large size image to a smaller one helps to share with families
and friends.
• Reviewing Pictures and Video Clip Files in Thumbnail
You can view up to 9 picture and video clip files at a time on the LCD
screen by using the thumbnail function.
1. Set the camera to PLAYBACK mode.
2. Press the
menu
button.
3. Press the or button to select
(RESIZE).
4. Press the button.
5. Press the or button to select the
desired setting.
6. Press the button.
NOTE:
• The resized image will be saved as a new le name.
• Only a large size image can be resized to a smaller one.
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
Resize
Select
6M
4M
2M
VGA
Select
OK
Resize
OK
1. Set the camera to the Playback mode.
2. Press the button and up to 9 thumbnail
files appear on the LCD screen.
3. Press the or , or button to select a
Full screen
thumbnail file.
4. Press the or button to view the file in
full screen.
• Running a Slide Show on the LCD screen
The slide show function lets you view all the pictures and video clip files
stored in the current memory in sequence on the LCD screen.
Select
Select
Start
Slide Show
OK
Slide Show
3 sec
Yes
OK
1. Set the camera to the
2. Press the
menu
button.
Playback mode.
3. Press the or button to select “SLIDE
SHOW”.
4. Press the button.
Setting Slide Show Interval Time
5. ICON is the current selection.
70
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
71
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
6. Press the or button to select the interval
period for each file to display.
Setting Slide Show Effect
7. Press the
button to select ICON.
8. Press the or to select the animation effect for each file to
display.
Setting Repeat On/Off
9. Press the button to select ICON.
10. Press the or to select the desired setting.
• Playing a Video Clip on LCD Screen
1. Set the camera to Playback mode.
2. Press the or buttons to select the desired video clip.
3. Press the button to start playing the video clip.
4. Press the button again to pause.
5. Press the
menu
or button to stop the video clip.
00:01:30
PLAY
IN
00:01:30
Running a Slide Show
11. Press the button to start a slide show.
12. Pressing the button pauses the slide show.
13. Pressing the
menu
stops the slide show.
The slide show will keep running as long as there is power supply.
NOTE:
This function is not available for the video clips and voice recording.
:Play
2008/01/01 18:59
WT
• Playing Audio Clips
1. Set the camera to the Playback mode.
2. Press the or buttons to select the desired audio clip.
3. Press the button to start playing the audio clip.
4. Press the button again to pause.
5. Press the
menu
or button to stop playing.
72
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
73
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
PLAY
00:00:13
WT
:Play
7/150
IN
2008/01/01 18:59
• Playing a Voice Memo
1. Set the camera to the Playback mode.
2. Press the or buttons to select the desired image that has the voice
memo recorded.
3. Press the button to start playing the voice memo.
4. Press the button again to pause.
5. Press the
menu
or button to stop the video clip.
• Protecting/Unprotecting Pictures, Movie and Audio Clips
1. Set the camera to the Playback mode.
2. Press
menu
button.
3. Press the or button to select “PROTECT”.
4. Press the button.
5. Press the or button to select the desired setting.
6. Press the button.
SINGLE Protect the selected picture, video or audio clip.
LOCK ALL Protect all of the pictures, video and audio clips in the
current memory.
UNLOCK ALL Remove protection from all protected pictures, video and
audio clips in the current memory.
Single
Lock all
Unlock all
Select
Protect
OK
10M
:Play
5/150
+2.0EV
F2.8
1/30
2008/01/01 18:59
IN
PLAY
00:00:13
WT
Protect Single Picture, Movie or Audio Clip
5. Press the or button to select the picture,
video or audio clip you want to protect.
6. Press the button.
7. Press the or button to select another one
and protect it .
2008/01/ 01
5/150
IN
18:59
10M
Protect?
Lock
74
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
75
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
Protect All pictures, Movie and Audio Clips
5. Press the button.
6. Press the button.
10M
Yes
Lock all?
5/150
IN
2008/01/ 0118:59
Remove Protection from All Pictures, Movie and Audio Clips
5. Press the button.
6. Press the button.
10M
Unlock all?
Yes
NOTE:
• The icon
appears on the LCD screen when you review the protected les.
• Protected les cannot be deleted. Remove protection before deleting.
• Formatting the internal memory or a SD card deletes all les, including the
protected les.
5/150
IN
2008/01/ 0118:59
Deleting a Single Picture, Movie or Audio Clip
6. Press the
or button to select the picture,
video or audio clip you want to delete.
7. Press the button.
Single
Delete
All
Select
NOTE:
You can also press the
button to delete a single le.
10M
Deleting All Pictures, Video and Audio Clips
6. Press the button.
Delete?
Yes
SINGLE Delete a selected unprotected option.
ALL Delete all the unprotected files in the current memory.
NOTE:
• Protected les cannot be deleted. Remove protection before deleting.
• All deleted pictures and video clips cannot be recovered.
OK
5/150
IN
2008/01/ 0118:59
• Deleting Pictures, Movie and Audio Clips
1. Set the camera to the Playback mode.
2. Press the
3. Press the or button to select (DELETE).
4. Press the or button to select the desired
setting.
5. Press the button.
menu
button.
Delete
Select
OK
• Viewing Pictures and Movie Clips on a TV
To set the video output system:
The video output signal (NTSC or PAL) can be switched to accommodate
different signal systems. For example, NTSC for U.S.A., Canada, Taiwan,
Japan, etc. and PAL for Europe, Asia (excluding Taiwan), etc.
You can change the video output system according to the following
steps:
76
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
77
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
1. Access the setup menu.
2. Press the or button to select (TV
Out).
3. Press the or button.
4. Press the or button to select the desired
setting.
5. Press the button.
6. Press the
menu
button to exit the menu.
Setup Menu 2/3
File No. Series
TV Out NTSC
USB Computer
Start-up Image
Format No
Select
Setup Menu 2/3
File No.
TV Out
USB
Start-up Image
Format
Select
NTSC
PAL
EXIT
OK
7 Print Settings
Printing Procedures
1. Preparing the camera and the printer.
Camera Be sure battery level is full before printing.
Printer Refer to the user guide that comes with your
printer and make preparations (paper, ink cassette,
cartridge, etc.) as required.
Turn on the camera and the printer.
2. Connecting the camera to the printer
Refer to "Camera / Printer Connection" on page 78 for details.
3. Select print settings
Use the camera's function and navigation buttons to select the print
settings. Refer to page 79 for details.
4. Printing
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
Press the
button to start printing.
78
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
79
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
Cancelling Printing
Press the
print job. The printer will stop printing and
menu
button to cancel printing the
CANCELLING?
eject the paper.
Printing Errors
If for some reason an error occurs during or
before printing, press
reconfigure printing settings.
NOTE:
• Please refer to the printer’s user guide for the solutions. Printing may resume
once the problem is solved.
menu
button to exit and
OPERATING ERROR
1. Plug the labelled end of the USB cable into the socket marked
on your printer. Location of USB socket will vary from printer to
printer.
2. Plug the other end of the USB cable into the USB port on your
camera.
3. Press the or to select “Printer”.
Pictbridge Menu 1/2
Print Standard
USB
Computer
Printer
CONNECTING......
NOTE:
• “CONNECTING” displays on the LCD screen, indicating a proper connection to
the printer.
Image Single
Quality Auto
Layout Auto
Paper Size Auto
Select
SELECT
Camera / Printer Connection
Connecting with the USB Cable.
USB port
To Printer
Selecting Print images
1. Access the PictBridge menu.
Setup Menu 1/2
2. Press the or button to
select the desired setting.
3. Press the button.
The following options are available.
SINGLE Print the selected image in the camera’s internal
memory or a memory card according to specified
settings.
ALL Print all images in the camera’s internal memory
or a memory card according to the specified
settings.
Print
Quality
Layout
Paper Size
Select
SINGLE
ALL
OK
80
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
81
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
NOTE:
• Print settings are congured for images only. Make sure there are no video clips
or other le besides images in the memory before printing,
• Not all printers will support all these print options. Please refer to the printer
user guide for options available.
hIf you choose single image, press the or button to select a desired
image, and press the or button to set the number of copies.
30
Select
PictBridge Menu
OK
5/150
Press
10M
PictBridge Menu
Setup
5/150
IN
2008/01/ 01 18 :59
10M
PictBridge Menu
Setup
5/150
2008/01/ 01 18 :59
IN
Press
NOTE:
The value for number of copies is : 1 to 30.
Selecting Print Quality
1. Access the PictBridge menu.
2. Press the or button to select the
desired setting.
3. Press the button.
The following quality settings are available:
Pictbridge Menu 1/2
Print
Quality
Layout
Paper Size
Select
Auto
Fine
Normal
Draft
OK
AUTO, FINE, NORMAL, DRAFT
AUTO Print settings differ according to the printer model.
Selecting Print Layout
1. Access the PictBridge menu.
2. Press the
desired setting.
3. Press the button.
The following layout settings are available:
AUTO, 1,2,3,4...250, FULL
or button to select the
Pictbridge Menu 1/2
Print
Quality
Layout
Paper Size
Select
AUTO Print settings differ according to the printer model.
Full Print a full-size picture on the selected paper.
1,2...250 Specify the number of printed images on a page.
Selecting Paper Size
1. Access the PictBridge menu.
2. Press the or button to select the desired setting.
3. Press the button.
The following paper size are available:
AUTO, Postcard, L, 2L, Card Size, 100X150mm,
4”X6”, 8”X10”, Letter, 11”X17”, A0~A9, B0~B9,
Roll(L), Roll(2L), Roll (4”), Roll (A4)
Pictbridge Menu 1/2
Print
Quality
Layout
Paper Size
Select
AUTO Print settings differ according to the printer model.
Auto
Full
1
2
4
OK
Auto
Postcard
L
2L
4” x 6”
OK
82
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
83
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
Selecting Paper Type
1. Access the PictBridge menu.
2. Press the or button to select the
desired setting.
3. Press the button.
Pictbridge Menu 2/2
Paper Type Auto
Date Plain
File No Photo
Reset Fast Photo
Select
The following paper type are available:
AUTO, PHOTO, PLAIN, F PHOTO
AUTO Print settings differ according to the printer model.
Setting the Date Stamp On / Off
1. Access the PictBridge menu.
2. Press the or button to select the
desired setting.
3. Press the button.
Pictbridge Menu 2/2
Paper Type Auto
Date Off
File No On
Reset
Select
AUTO Print settings differ according to the printer model.
ON Add the date stamp to the printed image.
OFF Print without the date stamp.
Pictbridge Menu 2/2
Setting the File Name On / Off
1. Access the PictBridge menu.
2. Press the
or button to select the
desired setting.
3 Press the button.
OK
AUTO Print settings differ according to the printer model.
Paper Type Auto
Date Off
File No On
Reset
Select
OK
ON Add the file name to the printed image.
OFF Print without the file name.
• Resetting to Default Settings
NOTE:
Choosing the “RESET” setting in PictBridge menu returns all print settings to the
default value. More details, refer to “Resetting to Default Setting” on page 30.
Selecting Print format
1. Access the PictBridge menu.
OK
2. Press the or button to select the
desired setting.
3. Press the button.
STANDARD Print settings differ according to the printer model.
INDEX Print pictures as a thumbnail image.
DPOF Print settings by DPOF format.
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
Pictbridge Menu 1/2
Print
Quality
Layout
Paper Size
Select
Standard
Index
Dpof
OK
84
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
85
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• About DPOF
DPOF stands for “Digital Print Order Format”, which is a format for
recording on a memory card or other medium which digital camera images
should be printed and how many copies of the image should be printed.
Then you can print on a DPOF-compatible printer or at a professional
print service from the memory card in accordance with the file name and
number of copies settings recorded on the card.
With this camera, you should always select images by viewing them on
the LCD screen. Do not specify images by file name without viewing the
file contents.
IMPORTANT!
DPOF print settings can be congured for images on a memory card only, not for
images in the camera’s built-in memory.
Setting the DPOF:
1. Insert an SD card into the camera.
2. Turn on the camera.
3. Set the camera to the Playback mode.
4. Press the
5. Press the or button to select DPOF.
6. Press the or button to select the desired
menu
button.
setting.
SINGLE The selected picture in a memory card
DPOF
will be printed out up to 30 copies.
ALL All pictures in a memory card will be
printed out up to 30 copies for
each picture.
Select
RESET Returns to the normal playback mode.
7. Press the
8. Press the or button to select the picture you
want to print out.
button.
Single
All
Reset
Select
OK
DPOF
OK
9. Press the or button to select the
number of print copies.
10. Press the
11. Press the
scene
button to set the Date Stamp on/off.
menu
button to complete the setting.
10M
5/150
12. Power off the camera.
13. Remove the memory card from the camera and
insert it into the printer’s card slot (as illustrated).
01
SCN
Date stamp on
Location of thecard slot may vary from printer to printer model.
NOTE:
Make sure you turn off the camera before inserting or removing a memory card.
14. Press the Print button on the printer to start printing.
86
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
87
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
8 Using the SD (Secure Digital) Card
• Using the SD Card
Your camera comes with built-in flash memory for storing pictures and
video clips. You can expand the memory using a Polaroid SD card (not
included - up to 8GB). The camera senses whether a memory card is
inserted, and automatically saves pictures and video clips accordingly.
Note that you cannot save pictures or video clips to the built-in flash
memory while a memory card is installed in the camera.
Memory card precautions:
1. Use only a SD memory card with this camera.
2. Electrostatic charge, electrical noise, and other phenomena can cause
data corruption or even loss. Always make sure that you always back
up important data on other media (MO disc, computer hard drive,
etc.).
3. If a memory card starts to behave abnormally, you can restore normal
operation by formatting it. However, we recommend that you always
take along with more than one memory card whenever using the
camera far away from your home or office.
4. We recommend that you format a memory card when using it for the
first time, or whenever the card you are using seems to be the cause
of abnormal pictures. Remember to format a memory card if it was
used in another digital camera or other devices.
IMPORTANT!
• Make sure you turn off the camera before inserting or removing a memory
card.
• Be sure to orient the card correctly when inserting it. Never try to force a
memory card into the slot when you feel resistance.
• SD memory cards have a write protection switch that you can use to protect
les from accidental deletion. However, you must remove the write protection
whenever you want to record new les onto it, format it, or delete its les.
• Files contained in the SD card recorded by other cameras may conict with the
i1037 camera, and valuable data in your existing SD card may be distorted or
lost when the card is inserted in the i1037 camera. We strongly recommend
the user to use a NEW or formatted Polaroid SD card (not included) for the
i1037 camera. The manufacturer is not liable for losing or corrupting any
valuable data or les in your SD card due to improper operation.
Inserting a SD card
1. Turn off the camera.
2. Open the SD card door by pushing it outwards as illustrated.
3. Insert the SD card and ensure the card is inserted the correct position
as illustrated.
4. Close the SD card door by pressing it downwards and then slide it
back to lock.
1
The icon will appear on the LCD screen when a SD card is inserted into
the camera.
2
MB
3
88
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
89
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
Removing the SD card
To remove the SD card, turn off your camera and open the Battery/SD
card door. Gently push the SD card inwards and then release it. The SD
card will eject out of the SD card slot.
1
IMPORTANT!
• Never insert any other object into the camera’s SD card slot. Doing so creates
the risk of damage to the camera and card.
• Should water or any foreign objects ever get into the card slot, immediately
turn off the camera, remove the battery or disconnect the AC adapter, and
contact your dealer or the nearest service provider.
• Never remove a card from the camera while the camera is powered on. Doing
so can cause the picture or video recording operation to fail, and even damage
the memory card.
2
MB
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
• Formatting the SD card
Formatting a memory card erases all data stored on it, including the
protected ones. Removing the SD card during formatting may damage
the card.
1. Insert an SD card into the camera.
2. Turn on the camera.
3. Access the setup menu.
4. Press the or button to select (Format).
5. Press the button.
6. Press the or button to select the desired
option.
7. Press the button.
IMPORTANT!
• SD cards formatted in another camera, computer or other devices may
not work properly. It is recommended to format SD cards with your i1037
camera.
• Note that data deleted by formatting operation cannot be recovered. Make
sure you do not have any useful data currently stored on a memory card before
you format it.
Setup Menu 2/3
File No. Series
TV Out NTSC
USB Computer
Start-up Image
Format No
Select
Setup Menu 2/3
File No. Yes
TV Out No
USB
Start-up Image
Format
Select
Exit
OK
90
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
91
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Copying Pictures, Video and Audio Clips to Memory Card
This setting allows you to copy pictures, video and audio clips stored in
the internal memory to a memory card.
1. Insert an SD card into the camera.
2. Turn on the camera.
3. Set the camera to the Playback mode.
4. Press the
menu
button.
5. Press the or button to select ICON
(Copy To Card).
6. Press the or button to select the desired
setting.
7. Press the button.
SINGLE Copy a selected image or video clip.
ALL Copy all the files in the current memory.
Copy Single File
8. Press the or button to select a picture, video
or audio file.
9. Press the button.
Copy All Files
8. Press the button.
NOTE:
With a memory card inserted into the camera, the card memory has a higher
priority over the internal memory. The selected picture or video clip can be only
copied from internal memory to the memory card.
Copy to Card
Select
Copy to Card
Single
All
Select
10M
Copy?
Yes
2008/01/ 0118:59
OK
OK
5/150
IN
9 Installing the Software onto a Computer
• Installing the Software
For Windows® Users:
IMPORTANT!
• Please backup all the necessary data before any driver and software
installation.
• The CD-ROM is tested and recommended to use under English Windows OS.
• Please restart the computer after installing the software.
• If you don’t know how to perform the software installation, please read the
“ReadMe” le in the CD rst.
IMPORTANT! (For Windows® 98SE)
Windows® 98SE needs to install your digital camera Driver for Mass Storage
function. After the installation, please restart the Windows before connecting
the camera to the PC.
IMPORTANT! (For Windows® Me, 2000, XP & Vista)
Directly plug-in the camera to transfer and play the pictures and video clips.
No need to install the driver.
IMPORTANT!
To experience higher performance in graphics and sound when you’re watching
video clips on your PC, it is recommended to install the DirectX ver. 9.0 or above.
It can be downloaded from It can be downloaded from http://www.microsoft.
com
1. Before you begin, close all other
software applications open on
your computer.
2. Insert the CD supplied into the
computer CD-ROM Drive.
PC
92
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
93
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
3. The CD User Interface Screen
will automatically launch.
4. With the mouse, click on each
software interface button in
turn and follow the on screen
instructions.
NOTE:
If the setup screen does not appear
after loading the CD, then you can
manually start it by double clicking
the “My Computer” icon on your
desktop, then double clicking the
icon for the CD-ROM drive. When the
CD-ROM window opens, double click
the “INSTALL-E.EXE” icon.
For Macintosh Users:
Mac
1. Before you begin, close all other software applications open on your
computer.
2. Insert the CD supplied into the computer CD-ROM Drive.
3. Double click the CD-ROM icon “Polaroid”.
4. Install the software included.
• Software Included with Your Camera
The i1037 software CD contains the following software:
Polaroid Digital Camera Driver
Driver is for Windows 98se Users only, Windows 98se needs to install this
digital camera Driver for camera’s mass storage function
ArcSoft MediaImpression™:
Manages your media for you, and gives you tons of fun and exciting ways to
create and share projects featuring your photo, video, and music files. Edit,
enhance and add creative effects to your photos. Create your own movies
or photo slide shows, complete with soundtrack. Upload your files easily to
YouTube™! Or share them through simple email attachments or popular photo
printing.
ArcSoft Print Creations®:
A family of fun and easy print-project software that brings out the creativity
in you. Print Creations brings together ArcSoft’s latest printing applications
into one great user experience. Starting from the Print Creations Launch
Pad, you can access any of ArcSoft’s great new printing applications
including: Greeting Card, Photo Calendar, Album Page and more. Projects
can be printed at home or saved as image files for sharing with family and
friends by email or the web. Each unique print-project software comes
packed with a full set of professionally designed templates and layouts for
all occasions and in all kinds of styles. You can personalize the designs
with your own digital pictures and text.
NOTE:
• Please access http://www.arcsoft.com/ to learn more about ArcSoft software.
• ArcSoft MediaImpression™ & Print Creations
Adobe® Acrobat® Reader™ .PDF File Reading Software
Adobe® Acrobat® Reader™ lets you view and print Adobe Portable
Document format (PDF) files on all major computer platforms, as well as
fill in and submit Adobe PDF forms online.
® don’t support Windows 98se/Me.
94
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
95
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Computer System Requirements
For acceptable picture transferring and editing performance, we recommend
the following minimum requirements;
For Windows® Users:
• Compatible with Microsoft® Windows® 98SE/2000/XP/ME/Vista
• Pentium® III 1GHz or equivalent processor
• USB Port
• 256MB RAM (512MB recommended)
• DirectX 9.0 or higher
• 500MB or above free disk space HDD space:
• Color monitor with high color (16-bit) graphic capability or higher
• CD-ROM drive
• Standard mouse and keyboard
• Stereo speakers
For Macintosh Users:
• Mac® OS Version 10.3 - 10.5
• PowerMac G3 or higher
• USB Port
• 256MB or above RAM
• 500MB Free disk space
• Color monitor with high color (16-bit) graphic capability or higher
• CD-ROM drive
• Standard mouse and keyboard
• Stereo speakers
PC
Mac
• Fast and Easy YouTube™ Upload:
1. Install ArcSoft software on included CD-ROM.
2. Download movie files from your digital camera to your computer.
3. Open ArcSoft software and select “Video”.
4. Select the movie file you want to upload and click. Upload to
YouTube” icon.
5. Enter your YouTube account information. If you do not have a
YouTube account, visit www.youtube.com to register for a free
account.
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
96
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
97
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
10 Transferring Pictures and Video Clips to a Computer
• Before Transferring Files
IMPORTANT! - FOR PC USERS
BEFORE YOU CONNECT YOUR DIGITAL CAMERA TO THE COMPUTER, MAKE
SURE THAT YOU HAVE INSTALLED THE SOFTWARE FROM THE ENCLOSED
CD. PLEASE REFER TO “9 Installing the Software Onto a Computer”.
If your OS is Windows 98se, You must install the i1037 camera driver from the
supplied CD rst.
• Connecting to Your Computer
Connect the camera directly to your computer
1. Turn on the camera.
2. Plug the labelled end of the USB cable into the marked
socket on your computer.
3. Plug the other end of the USB cable into the port on your camera.
4. Press the or to select “Computer”.
5. An interface “New Hardware Found” will show on the computer
desktop.
6. A removable disk drive will be installed onto your computer
automatically.
• Transferring Pictures and Movie Clips to a Computer
NOTE:
The Mass Storage mode is the default setting when the docking is connected
with a TV set or a computer.
For Windows® Users
NOTE:
You can transfer pictures and Movie clips in any mode.
1. Turn on the camera.
2. Connect the camera to a computer via the USB cable.
3. Double click on “My Computer” on your PC desktop and you will see
a “Removable Disk” drive.
4. Double click “Removable Disk” -> double click “DCIM”-> double click
any directory folder under “DCIM”.
5. All the pictures, video and audio clips are in the directory folder.
Highlight the pictures, video and audio clips and drag them to a folder
of your choice. You can also create sub folders to group them or use
the Arcsoft software to edit and manage the pictures, video or audio
clips.
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
PC
98
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
99
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
For Macintosh Users
Mac
NOTE:
For Mac user, directly plug-in the camera, no need to install the driver.
1. Turn on the camera.
2. Set the camera to Playback mode.
3. Connect the camera to Mac via the USB cable, the systems will
automatically recognize the MASS STORAGE drive. (System will
automatically create a Mass Storage named “DIGITALCAM”).
NOTE:
This Drive name will vary from different version of Mac OS system.
4. Double click the folder “DIGITALCAM” to enter sub-folder “DCIM”.
5. Double click the folder “DCIM” and then any subfolder inside.
6. You can copy the pictures and video clips from this directory folder
and paste to the hard disk.
11 Troubleshooting Problems
The troubleshooting guide is designed to help you. If problems continue,
please contact customer support. Details are provided under “Getting
Help”.
I receive an error message when I
am installing “Polaroid i1037 Camera
Driver”.
I cannot upload images to my
computer.
I cannot run the “Polaroid i1037
Camera Driver”.
My CD Installation wizard does
not work.
Symptom Problem Solution
“Polaroid i1037
Camera Driver” does
not load.
Connection failure. Check all cable connections are secured.
Camera Driver is not
installed.
Conict with another
camera driver or
capture device.
The auto installation
le is switched off
or The CD-ROM is
disconnected.
Shut down all other applications and attempt to
reinstall the driver.
Check to see if the USB in your BIOS is activated.
Please refer to Polaroid web site to activate the
USB in the BIOS.
You need to install the camera driver for
Windows 98SE systems.
If you have another camera installed on your
computer, remove it and it’s driver completely
from your system to avoid conicting with it.
* For Win98se/Me user:
Go to the computer desktop. Right click on “My
Computer”. Click “Properties”. Select “Device
Manager”. Double click on “CD_ROM”, double
click on “CD-R (normally the manufacturer’s
name. Click on “Settings”. Ensure both “Auto
insert notication” and the “disconnect” are
ticked. If you change the settings the computer
will ask you to restart your PC. Click “Yes”.
* For WinXP user:
Go to the computer desktop. Double click on
“My Computer”. Right click “CD Driver” and
select “Properties”. Click “Autoplay”. Ensure
“Prompt me each time to choose an action“ is
ticked. Click “OK” to exit.
* For Win Vista user:
Go to “Control Panel / Hardware and Sound /
AutoPlay”, then set “Software and games” to
“Install or run grogram” or “Ask me every time”.
Click “Save” button to exit.
100
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
101
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
Symptom Problem Solution
Images are not shown
on TV.
The video clip (AVI) le
cannot be played.
The camera is detected by
the Windows and works
properly, but a driver letter
of the Removable disk is
not created.
I cannot activate my
Digital Camera by pressing
the Power switch.
Camera does not turn on. Batteries are not oriented
Camera suddenly powers
off.
Image is not recorded
when the shutter button
is pressed.
Camera powers off during
self-timer countdown.
LCD screen image is out
of focus.
Recorded pictures are not
saved in memory.
Video cable is not connected
correctly.
DirectX version is lower than
9.0
The removable disk crashes
with the network drives.
Insufcient battery power or
battery is missing.
correctly.
Batteries are dead.
Auto Power Off function is
activated.
Batteries are dead.
Camera is turned off.
Flash unit is charging.
Memory is full.
Batteries are dead. Replace or recharge your batteries.
Macro mode is being used for
far subjects.
Still image mode is being
used for near subjects.
Removing the memory card
before the save operation is
complete.
Or
Or
Or
Or
Or
Make sure the video cable is connected to the
TV “Video In” socket.
Install DirectX 9.0 or above. Visit http://www.
microsoft.com for more details.
Disconnect the crashed network drive and reserve
this drive letter for the camera.
Recharge the batteries or install the batteries.
Orient the batteries correctly.
Replace or recharge the batteries.
Turn the camera on.
Replace or recharge your batteries.
Turn the camera on.
Wait until ash unit charging nishes.
Delete images you no longer need, or use another
memory card.
Set the camera to Still Image mode.
Set the camera to Macro mode for subjects this
close to the lens:
Wide Angle: 0.32 ft~ 3.3 ft (0.1 m ~ 1.0 m)
Telephoto: 1.3 ft ~ 3.3 ft (0.4 m ~ 1.0 m)
Do not remove the memory card before the save
operation is complete.
Symptom Problem Solution
Colour of the playback pictures is
different from the picture on the
LCD screen during recording.
Pictures are not displayed. A memory card with non-DCF
I cannot erase pictures. All the pictures in memory are
There is no response from the
camera while pressing any
buttons.
Or
Sunlight or light from another
source is shining directly into the
lens during recording.
pictures recorded with another
camera is loaded in the camera.
protected.
The LCD screen is frozen or the
camera is hanged.
Position the camera so sunlight
does not shine directly onto
the lens.
This camera cannot display nonDCF pictures recorded onto a
memory card used by another
digital camera.
Unprotect the pictures you want
to delete.
Remove and re-install the battery
or batteries to reset the camera.
Your valuable data stored in the
camera will not be lost.
TV out
Or
Or
Or
Or
Please also refer to the help les & User Guides that accompany the
Symptom Problem Solution
LCD screen does not appear
on the screen of the connected
television
Images do not display in color
on TV.
There is a problem with the
camera-TV connection
TV setup is wrong
Video system is incompatible.
Wrong system selection. Change to NTSC or PAL.
Or
Or
Use the optional video cable to
connect the camera to the TV
Consult the documentation of the
TV and put it in its video mode
Select the proper video output
system.
Or
Or
enclosed applications.
For further information and support, please visit our website:
http://www.polaroid.com
102
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
103
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
12 Getting Help
• Polaroid Online Services
Website: http://www.polaroid.com
• ArcSoft Software Help
For United States For Latin America
ArcSoft HQ Support Center E-mail:latinsupport@arcsoftsupport.com
(Fremont, CA 94538)
Tel.: 1-510-979-5599
Fax: 1-510-440-7978
E-mail: support@arcsoftsupport.com
Web: http://www.arcsoft.com/en/support/
For Europe For China
ArcSoft Europe Support Center ArcSoft China Support Center
(Ireland) (Hangzhou)
Tel.: +353-(0) 61-702087 Tel.: +86-571-88210575
Fax: +353-(0) 61-702001 E-mail: support@arcsoft.com.cn
E-mail: eurosupport@arcsoft.com Web: http://www.arcsoft.com.cn/new/support
For Japan For Taiwan
ArcSoft Japan Support Center (Tokyo) ArcSoft Taiwan Support Center (Taiwan)
Tel.: +81-3-5795-1392 Tel.: +886-(0) 2-2506-9355
Fax: +81-3-5795-1397 Fax: +886-(0) 2-2506-8922
E-mail: support@arcsoft.jp E-mail: support@arcsoft.com.tw
Web: http://www.arcsoft.jp Web: www.arcsoft.com.tw
Visit http:// www.arcsoft.com for technical support and frequently asked questions (FAQ’s).
®2009 by All rights reserved
“Polaroid” and “Polaroid and Pixel” are trademarks of Polaroid Corporation, USA.
13 Appendix
• Technical specications
Sensor
Lens
LCD Screen 2.7” TFT-LCD panel
Built-in Flash
Exposure Control -/+2.0 EV in 0.3 increments
ISO Speed Auto,125,200,400,800,1600,3200
• Sensor:
- Size : 1/2.3 inch
- 10.0 Megapixels CCD
• Aperture: F 3.1 ~ 5.6
• Focal Length: 6.3 ~ 18.9 mm
• Focal Distance
- Normal Focus: 40 cm to ∞
(The focusing range is the distance from the lens
surface to the subject.)
- Macro Focus:
Wide Angle: 10 cm ~ 1.0 m
Telephoto: 40 cm ~ 1.0 m
• Modes
- Auto/Red Eye Reduction/Always On/Slow Sync/OFF
• Range
Flash Range for Normal mode:
Wide Angle: 40 cm ~ 2 m
Telephoto: 40 cm ~ 1.2 m
Flash Range for Macro mode:
Wide Angle: 0.33 ft~ 3.3 ft (0.1 m ~ 1.0 m)
Telephoto: 1.3 ft ~ 3.3 ft (0.4 m ~ 1.0 m)
104
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
105
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
Shutter
Speed
White
Balance
Storage 32 MB internal memory / SD Card
Self-timer Off / 2 sec/ 10 sec/ Double / Burst
File Format • Still Image
Power Supply AA alkaline battery X2
Scene Mode Program / Movie / Voice REC / Q. Mode / Portrait /
Metering Center-weighted / Multi / Spot
Drive mode 2 sec. / 10 sec. / Double / Burst
Photo Edit Red eye removal / Black & White / Sepia / Negative /
Ambient
temperature
Connectivity With computer via USB cable (included)
Dimension • Size:
Mechanical shutter speed 1/1000 sec
CCD variable electronic shutter 1/2000 sec ~ 8 sec
Auto, Day light, Cloudy, Tungsten, Fluorescent-H,
Fluorescent-L, Custom
- EXIF 2.2 compatible format (JPEG compression) DCF
compatible, Support DPOF ( PictBridge available
• Video Clip: AVI
• Audio: WAV
Landscape / Sunset / Backlight / Smile Capture / Kids
/ Night scene / Fireworks / Snow /Sports / Party /
Candlelight / Night Portrait / Soft Skin / Soft Flowing
Water / Food / Building / Text / Auction / Aperture
Priority / Shutter Priority / Manual Exposure
Mosaic / Red / Green / Blue
Operating: 0° C to 40° C
Storage: -20 to 60° C
Camera Body ( W x H x T ) : 92 x 60.5 x 24.3 m
• Weight:
Camera Body w/o battery : Approx. 120 (g)
• Uninstalling Polaroid i1037 Driver (PC only)
For Windows® 98SE Users
NOTE:
The following driver uninstall procedure is for Windows 98SE user only because
only Windows 98SE needs to install the i1037 driver.
1. Open Add/Remove Program Properties in Control Panel and select
“Polaroid Digital Camera” program, then click “Add/Remove”.
2. The following dialogue box appears, please click “Yes” to confirm
removing the camera driver.
3. The un-installation program runs automatically, please restart your
computer when it is finished.
PC
106
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
107
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Camera Default Settings
Camera Mode Description Default
Still Image Mode Image Resolution
Quality Fine
Metering Multi
White Balance for Pictures Auto
ISO Auto
Exposure 0
Drive Mode Off
AEB Off
Highlight Off
Sharpness Normal
Effect Off
Date Stamp Off
Stabilizer Off
Face Tracking Off
Photo Frame Off
Digital Zoom On
Movie Mode Movie Resolution 640 x 480
Metering Multi
White Balance for Video Clips Auto
Setup Mode Capture mode Still Image
Auto Review 3 sec.
Power Save 1 min
Date & Time YY/MM/DD
Language English
File No. Series
TV Out NTSC
USB Computer
Start-up Image ---
Format No
Battery Type Alkaline
Reset All No
Playback Mode Protect Off
Slide Show 3 Sec
NOTE:
The default language for the LCD screen may vary with the different shipment
destinations.
Need help with your digital camera?
Call our customer service help number. Look for the insert with this icon:
Or visit www.polaroid.com.
108
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
109
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
• Tips, Your Safety & Maintenance
Your Camera should only be operated within the following environment.
• 32 - 104º Fahrenheit; 0 - 40º Celsius
• 20% - 85% relative humidity, non condensing
The battery life or image quality may be affected when the camera is oper-
ated outside these conditions.
Camera Cautions
• NEVER immerse any part of the camera or its accessories into any
fluid or liquid.
• ALWAYS disconnect the camera from your PC or TV before cleaning
it.
• ALWAYS remove dust or stains on the camera with a soft cloth
dampened with water or neutral detergent.
• NEVER place hot items on the surface of the camera.
• NEVER attempt to open or disassemble the camera as this will affect
any warranty claim.
• Regulatory Information
FCC Notice
This device complies with Part 15 of FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved
by the party responsible for compliance could void the user’s authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply with the
limits for Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is needed.
• Consult the dealer or an experienced radio/TV technician for help.
Shielded cable must be used with this unit to ensure compliance with the
Class B FCC limits.
Under the environment with electrostatic discharge, the product may
malfunction and require user to reset the product.
110
Part No.: OMi1037US001
US 0215
Polaroid i1037 Digital Camera User Guide
www.polaroid.com
Loading...
