Rev. 1, June 10, 2002
CONTENTS
The Polaroid PhotoMAX FUN! 620 Creative Kit . . . . . . . . . . . . . . . . . . . 1
Camera front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Camera rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Turning the Camera On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Inserting Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Taking Photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Using the Self-timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Erasing photos From the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installing Your PhotoMAX Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Transferring Photos to Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connecting the camera to your computer . . . . . . . . . . . . . . . . . . . . 10
Transferring photos to your computer . . . . . . . . . . . . . . . . . . . . . . . 12
For information about PhotoMAX tools . . . . . . . . . . . . . . . . . . . . . 17
Camera Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Contacting Polaroid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Questio ns? Contact Polaroid Corporation at www.PolaroidD igital.co m
The Polaroid PhotoMAX FUN! 620 Creative Kit
Your Polaroid PhotoMAX FUN! 620 Digital Camera Creative Kit
contains everything you need to take digital photos, save them to your
computer, and manipulate them.
Caution:Before you connect the camera to your computer, install the
PhotoMAX Image Maker software that comes with the camera
(page 9). Restart your computer after installing the software.
Your kit contains the following:
• Polaroid PhotoMAX FUN! 620 Digital
Camera with wrist strap
• Four AAA batteries
• Camera-to-computer cable (with
both RS-232C Serial and USB plugs)
• Polaroid PhotoMAX Image Maker Software CD-ROM and User
Manual
Note: To connect to your digital camera, your computer needs an
RS-232C Serial port or a high-speed USB port (only on Windows
98, Me, or 2000 computers).
Polaroid PhotoMAX FUN! 620 Digital Camera User’s Manual 1
2 Questio ns? Contact Polaroid Corporation at www.PolaroidD igital.co m
Camera front
a Viewfinder
b Lens
c Serial/USB cable
connector port
d Tr i po d m ou n t
e Battery compartment
Camera rear
f LCD status display
g Power/status
indicator
h Low-battery
indicator
i Viewfinder
j Power button
k Photo erase button
l Self-timer button
m Shutter button
n Wris t str ap sl o t
o Battery compartment
a
b
c
de
i
j
klm
n
h
g
f
o
Polaroid PhotoMAX FUN! 620 Digital Camera User’s Manual 3
Note: For more information about the camera’s features and functions
than we can provide in this manual, see the Tips, Tricks, Terms,
and Techniques section of the PhotoMAX Online User’s Guide
(the software online Help). For a detailed list of camera
specifications, see the PhotoMAX FUN! 620 Digital Camera
Specifications section of the PhotoMAX Online User’s Guide.
Turning the Camera On and Off
Tur n t he ca me r a o n ( a). The camera
emits a click, the LCD status display
(e) turns on, and the green power/
status indicator (b) is lit.
If the green power/status indicator is
not lit, make sure the batteries are
loaded properly and do not need
replacing.
Note: To turn the camera off, press and hold the power button (a) until
the green power/status indicator (b) turns off.
abc
d
e
4 Questio ns? Contact Polaroid Corporation at www.PolaroidD igital.co m
Note: To conserve battery life, the camera beeps and automatically
shuts off after about 90 seconds of inactivity. To turn it back on,
press the power button (a). The LCD status display (e) turns on
and the power/status indicator (b) is lit. To take a photo, look
through the viewfinder (c) and press the shutter button ( d).
Inserting Batteries
Your kit includes four AAA batteries.
1 Turn the camera off.
2 Open the battery door by sliding
the cover out to the side as far as
it will go and lifting it.
3 Insert four AAA batteries. Make
sure that the battery terminals
(
+ and -) are properly
positioned.
4 Close the battery door securely.
Slide it out to the side as far as it will go, press it against the camera
base, and slide it back into the base to lock it closed. If you feel
resistance, do not force the door.
Polaroid PhotoMAX FUN! 620 Digital Camera User’s Manual 5
Note: Replace all four batteries when the low-battery indicator turns
on, the LCD displays the low-battery message (bL), or the LCD
status display does not turn on.
Do not mix old and new batteries, batteries of different types, or
batteries from different manufacturers. High-capacity superalkaline batteries provide longer battery life in digital cameras.
Taking Photos
1 Tur n t he ca me r a o n ( a). The
green power/status indicator (b)
is lit.
2 Stand at least 3 feet (1 m) from
your subject.
Note: For best results, take
photos outdoors or
indoors in a brightly lit
room.
3 Before you look through the viewfinder, point the camera toward
your subject. If you see a low-light warning message (
LL) on the
LCD status display (e), add light (or move to a brighter location).
abc
d
e
6 Questio ns? Contact Polaroid Corporation at www.PolaroidD igital.co m
If you still want to take a low-light photo without adding light or
moving to a brighter location, hold the camera very steady or attach
it to a tripod (using the tripod mount), due to the increased
exposure time required. Under low light conditions, photo quality
may be reduced.
4 Frame your subject within the yellow lines that are visible in the
viewfinder (
c).
5 Hold the camera steady and press and hold the shutter button (d)
until the camera beeps. (Moving the camera before you hear the
beeps may blur the photo.)
The power/status indicator blinks while the photo is processed, and
the picture counter in the LCD status display (e) increases by one.
Note: When the camera’s 1 MB of internal memory is full (after about
15 photos), the LCD status display shows the memory-full
message (FL) and the camera issues three quick warning beeps. If
you press the shutter button, the camera again issues three quick
beeps, but takes no more photos.
Note: The camera does not have removable memory. When memory is
full, transfer photos into your computer (page 10) and then erase
them from the camera’s memory (pages 8 and 16).
Polaroid PhotoMAX FUN! 620 Digital Camera User’s Manual 7
Using the Self-timer
The self-timer is useful for giving you time to also get into the photo.
1 Tur n th e cam er a on (
a).
2 Set the camera into position to take a photo.
Note: Using a tripod is recommended. A tripod mount is on the
bottom of the camera. Or place the camera on a flat surface.
3 Look through the viewfinder (b) to
compose the photo.
4 Press the self-timer button (
c). The
camera beeps for 15 seconds, the
beep speeds up and then stops just
before the camera takes the photo.
Note: You do not need to press the
shutter button to take a selftimed photo.
Note: To cancel the self-timer, press the power button to turn the
camera off.
abc
8 Questio ns? Contact Polaroid Corporation at www.PolaroidD igital.co m
Erasing photos From the Camera
1 Press and hold the photo erase
button (a) for 3 seconds to erase
the last photo taken.
The camera beeps to confirm
that the photo is erased, and the
photo count on the LCD status
display (b) decreases by one.
2 Repeat step 1 to erase additional
photos.
Note: You can also erase one or more photos from the camera using the
Polaroid PhotoMAX Image Maker Software (page 16).
Warning: Once you erase a photo, it is gone forever!
a
b
Polaroid PhotoMAX FUN! 620 Digital Camera User’s Manual 9
Installing Your PhotoMAX Software
To install the PhotoMAX Image Maker Software:
1 Turn your computer on.
2 Check that your computer meets the following requirements:
• 200 MHz Pentium processor or equivalent
• Compatible with Microsoft Windows 95, 98, Me, or 2000
• 32 MB RAM
• 195 MB available hard disk space
• Available USB port (Windows 98, Me, or 2000) or RS-232
Serial port
• High-color display with 800 x 600 DPI resolution or higher
• 2x or faster CD-ROM drive
• Mouse
3 Insert the software CD in your PC’s CD-ROM drive.
If the installation program does not start automatically:
a Select Run from the Windows Start menu.
b Click Browse and select your CD-ROM drive.
c Select Setup.exe from the CD-ROM.
d Click Open.
e Click OK. The installation program begins.
10 Qu estions? Contact Polaroid Corporation at www.PolaroidD igital.com
4 Follow the instructions on your computer screen.
5 In the final prompt, select Yes, I want to restart my computer
now. and click Finish. Your computer restarts.
Caution:You must restart your computer after installing the PhotoMAX
Image Maker Software.
Caution:Turn your computer off before connecting the camera to it using
the Serial cable (as described in the next section).
Transferring Photos to Your Computer
To transfer photos from your camera to your computer:
1 Connect the FUN! 620 Digital Camera to your computer (below).
2 Transfer photos from camera to computer using the PhotoMAX
Image Maker Software (page 12).
Connecting the camera to your computer
1 Turn the camera off.
2 Turn off the computer and any peripheral devices.
Polaroid PhotoMAX FUN! 620 Digital Camera User’s Manual 11
Note: You do not need to turn off a Windows 98, Me, or 2000 computer
to connect the camera to its USB port.
Caution:Be sure to turn your computer off before connecting the camera
to it using the Serial cable.
3 Locate the connector cable from your kit.
The large head of this cable (on the left in
this illustration) has a Serial plug at one
end and a USB plug at the other.
Note: If your computer is equipped with a USB port, it transfers
photos much faster than a Serial port.
4 Connect the Serial plug (a) to the
Serial port on your computer, or
connect the USB plug (b) to the
USB port on your Windows 98,
Me, or 2000 computer.
Caution:If the connection between the
USB head and the computer’s
USB port is not tight, the USB head may eventually pull out of
the port. Check that the USB head is fully plugged in every time
you transfer photos.
c
b
a
12 Qu estions? Contact Polaroid Corporation at www.PolaroidD igital.com
Note: For help finding the Serial or USB port on your computer,
read the instruction manual that came with your computer
or contact the computer manufacturer.
5 Insert the other end of the cable (the round connector) straight into
the camera (
c) without twisting. The side of the connector with the
arrow on it should face toward the front of the camera. If you feel
resistance, do not force the connector; reposition it and try again.
6 Turn the computer on, if you turned it off to connect the Serial
cable.
Note: The computer can remain on when you plug the Serial/USB
connector cable into the computer’s USB port.
Transferring photos to your computer
1 Open the PhotoMAX Image Maker
Software by double-clicking the
PhotoMAX software icon on your
desktop. The
Get Photo button is
selected.
Get
Polaroid PhotoMAX FUN! 620 Digital Camera User’s Manual 13
The Get Photo button lets you acquire photos from several
sources:
Selection: Used To:
Album
Open a pho to that is in a Photo MAX album
From File
Open a recently used photo or any pho to stored
on your com puter
Camera/Scanner
Transfer a photo from your camera, scanner, or
other TWAIN-co m patible device
Create New
Create a new image file
Screen Capture
Grab an entire computer screen or active window
*Get From Web
This feature no lo nger suppo rted.
14 Qu estions? Contact Polaroid Corporation at www.PolaroidD igital.com
2 Click Camera/Scanner.
3 Select
Polaroid FUN! 620
in the Select Source list.
4 Choose a location on your
computer for storing your
photos. There are two
ways to choose a location:
• The fastest way to
save, display, and
manipulate your
photos is to select
an album in the
Select Album list.
Note:To create a new album, select [New] and use the album
NewAlbum1 or type a different album name.
Your photos appear in the active photo album and the photo
files are stored in
c:\My Documents\My Pictures. The files
are named using the date you downloaded them. For example:
• If you want to customize where and how your photos are
stored, click the Acquire Options button.
Select Source list
Camera/Scanner button
Acquire button
Select Album list
Acquire Options button
Polaroid PhotoMAX FUN! 620 Digital Camera User’s Manual 15
A TWAIN Options window opens,
which lets you specify the file format
for the photos, the folder where the
photos will be stored, and how the
photos will be named. After making
your selections, click
OK.
5 Tur n t he ca me r a o n.
6 Click the Acquire button.
The digital camera TWAIN
software window opens. TWAIN
software is used to transfer and
delete photos from your camera.
Note: If you see a failed connection message or warning window,
turn the camera off and on again, check the connections
between the camera and computer, and click Acquire.
7 Click Refresh Thumbnails if your photos do not appear
automatically in the TWAIN window.
16 Qu estions? Contact Polaroid Corporation at www.PolaroidD igital.com
8 Select photos for transfer to your computer:
• To select a single photo, click on the photo thumbnail. A red
border appears around the photo.
• To select more that one photo, press Control (Ctrl) on your
keyboard while you click on each thumbnail photo. Red
borders appear around all selected thumbnails.
• To select all photos, click Select All. Red borders appear
around all thumbnails in the camera.
9 Click Get Photos.
Caution:To avoid losing your photos, copy them to removable storage,
such as a floppy disk, Zip disk, or writable CD.
10 To open a photo stored using the
Select Album list (step 4),
double-click the photo thumbnail that is displayed on-screen in the
album. The photo appears in the image tray.
To open a photo stored using the TWAIN Options window
(step 4), use the PhotoMAX Get Photos, From File, and
Browse buttons to find the photo and display it in the image tray.
You can now manipulate the image using the PhotoMAX software tools.
Note: To erase all photos from the camera, click Delete All Photos.
Once you delete the photos, they are gone forever!
Polaroid PhotoMAX FUN! 620 Digital Camera User’s Manual 17
For information about PhotoMAX tools
• Select the ? button to open the PhotoMAX
Online User’s Guide. This provides an index and
step-by-step procedures for using your Polaroid
PhotoMAX Image Maker Software to
manipulate and enhance your photos.
• You can also get help with any button or feature
in the software by moving your mouse cursor over it and clicking
the right mouse button. This brings up context-sensitive help that
explains the software button or feature.
• Visit our Help site on the Web for more information.
www.polaroid.com
? button
18 Qu estions? Contact Polaroid Corporation at www.PolaroidD igital.com
Camera Precautions
• This camera is battery operated. Supervise children when the
camera is operated by them or used in their presence. To avoid
electrical shock, do not expose the camera to, or immerse it in, any
fluids. Do not disassemble or operate the camera if dropped or
damaged. Contact a Polaroid Service Center for repair information.
• Do not open the camera case or attempt your own repairs. High-
voltage internal components create the risk of electrical shock when
exposed. Return your camera to authorized Polaroid service
providers for all maintenance and repairs.
• Keep the camera away from all fluids. Moisture creates the danger of
fire and electrical shock. Do not use the camera in the rain, at the
seashore, or any location where there is the possibility of exposure
to fluids.
• Turn the camera off and remove the batteries immediately if the
camera is exposed to water or any other fluid.
• Do not open the battery compartment while the camera is on. If the
camera loses power while processing a new photo, the photo cannot
be stored and may cause corruption of other stored photos.
Polaroid PhotoMAX FUN! 620 Digital Camera User’s Manual 19
FCC Notice
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) This device must accept any interference received, including interference
that may cause undesired operation.
Warning: Changes or modifications to this equipment not expressly
approved by the party responsible for compliance could void the
user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
20 Qu estions? Contact Polaroid Corporation at www.PolaroidD igital.com
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Use the USB or RS232 Serial cable shipped with this unit, which must be
used to ensure compliance with the Class B FCC limits.
• Consult the dealer or an experienced radio/TV technician for help.
Warranties
One Year Limited Warranty
Polaroid Ph otoMAX FUN! 620 Digital Camera
Polaroid will, at our option, repair or replace any unit found defective in
manufacture within the warranty period. The warranty period is determined by
the date of purchase. Keep the receipt as proof of purchase. Otherwise, the
warranty period is determined by the date of manufacture.
This warranty does not apply to damage caused by accident, misuse o r
tampering, and excludes all consequenti al damages except in jurisdictio ns no t
allowin g such exclusion s or limitations.
Polaroid PhotoMAX FUN! 620 Digital Camera User’s Manual 21
Ninety Day Limited Warranty
Polaroid Ph otoMAX Image Maker Software
Polaroid warrants that the software media will be free of defects in materials and
workmanship for a period of 90 days from the date of purchase. Polaroid's entire
liability and your exclusive remedy shall be to repair or replace the software that
does not meet Polaroid's Limited Warranty and is returned to Polaroid with a
copy of your sales receipt. This Limited Warranty is void if failure of the software
has resulted from accident, abuse, or misapplication. Any replacement software
will be warranted for the remainder of the original warranty period or 30 days,
whichever is longer.
Polaroid makes no oth er warranties with respect to the software, either express
or implied, including but no t limited to implied warranties o f merchantability
and fitness for a particular purpose.
22 Qu estions? Contact Polaroid Corporation at www.PolaroidD igital.com
Contacting Polaroid
Polaroid Corporation provides technical support for digital cameras at
www.PolaroidDigital.com, and within the United States by calling
800-897-0356 from 8 A.M. to 8 P.M. EST, 7 days a week. Please note that phonesupport and repair services are regional and may not be available for a particular
product outside the country where it was purchased. To obtain parts for cameras
purchased in the United States, call 800-343-4846 (9 a.m. to 5 p.m. EST, Mon. Fri. Note: No technical support is available at this number). A list of Polaroid
International sales and customer support offices is available at
www.polaroid.com/service/phone.html.
© 2001 Polaroid Corporation, Cambridge, MA 02139, U.S.A., owner of
the trademarks “Polaroid and Pixel Design,” “Polaroid PhotoMAX”, and
Max the Bird (and Design) © 1998-2001. All other product names may
be the property of their respective owners. All rights reserved, Printed in
the U.S.A.
PU-21787M-0 04/ 01
Fun! 620
Technical Support Information
(This information replaces that found on Page 24)
Polaroid Corporation provides technical support for digital cameras at
http://www.polaroid.com/, and within the United States by calling
800-897-0356 from 10 A.M. to 7 P.M. EST, (Mon - Fri) and 10 A.M.
to 4 P.M. EST (Sat). Please note that phone support and repair services are
regional and may not be available for a particular product outside the
country where it was purchased. To obtain parts for cameras purchased in
the United States, call 800-343-4846 from 9 a.m. to 5 p.m. EST, Mon. - Fri.
(Note: No technical support is available at this number.) A list of Polaroid
international sales and customer support offices is available at
http://www.polaroid.com/service/phone.html
.
Loading...
