Polaroid FLM-2061 User Manual
26” LCD Television
FLM-2601
Operating Manual
20050323
Table of Contents
Important Information..........................................................................................................................................................1
Important Safety Precautions .............................................................................................................................................2
Preparations .......................................................................................................................................................................5
Using the Remote Control........................................................................................................................................5
Batteries for the Remote Control .............................................................................................................................5
Power Connection....................................................................................................................................................5
Antenna Connection ................................................................................................................................................6
Identification of Controls.....................................................................................................................................................7
Main Unit..................................................................................................................................................................7
Remote Control........................................................................................................................................................9
Connections......................................................................................................................................................................11
Cautions Before Connecting ..................................................................................................................................11
Connect a VCR ......................................................................................................................................................11
Connect a Camcorder ............................................................................................................................................12
Connect a DVD player or Set-Top Box...................................................................................................................13
Connect a DTV receiver.........................................................................................................................................14
Connect a PC.........................................................................................................................................................15
Connect a VCR for Recording...............................................................................................................................16
Turning the Unit On and Off..............................................................................................................................................17
Turning the Unit On and Off ...................................................................................................................................17
Viewing the Menus and Displays ...........................................................................................................................17
Memorizing the Channels.................................................................................................................................................18
Selecting the Signal Source ...................................................................................................................................18
Storing Channels in Memory Automatically............................................................................................................18
Adding and Erasing Channels................................................................................................................................19
Basic Operations ..............................................................................................................................................................20
Changing Channels................................................................................................................................................20
Adjusting the Volume..............................................................................................................................................20
Selecting Input Source Signal ................................................................................................................................21
Selecting a Menu Language...................................................................................................................................21
Setting Picture ..................................................................................................................................................................22
Customizing the Picture .........................................................................................................................................22
Using the Preset Picture Mode...............................................................................................................................22
Setting System .................................................................................................................................................................23
Setting System In TV Mode .................................................................................................................................23
Adjusting Screen Aspect ........................................................................................................................................23
Reducing Picture Noise..........................................................................................................................................23
VCR mode..............................................................................................................................................................23
Loading Default Values ..........................................................................................................................................23
Setting System In VGA Mode..............................................................................................................................24
Changing the Position of Image .............................................................................................................................24
Adjusting Clock and Phase ....................................................................................................................................24
Adjusting the Picture Automatically........................................................................................................................24
Adjusting Screen Aspect ........................................................................................................................................25
Displaying Resolution Information..........................................................................................................................25
Loading Default Values ..........................................................................................................................................25
Table of Contents (continued)
Setting System In YPbPr Mode...........................................................................................................................26
Adjusting Phase .....................................................................................................................................................26
Adjusting Screen Aspect ........................................................................................................................................26
Reducing Picture Noise..........................................................................................................................................26
Loading Default Values ..........................................................................................................................................26
Setting System In DVI Mode ..................................................................................................................................27
Adjusting Screen Aspect ........................................................................................................................................27
Displaying Resolution Information..........................................................................................................................27
Setting Sound ...................................................................................................................................................................28
Customizing the Sound ..........................................................................................................................................28
Using the Preset Sound Mode ...............................................................................................................................28
Setting SRS effect..................................................................................................................................................28
Adjusting On-Screen Display............................................................................................................................................29
Adjusting OSD Position..........................................................................................................................................29
Adjusting OSD Transparence.................................................................................................................................29
Zooming OSD Menu...............................................................................................................................................29
Setting OSD Off Time.............................................................................................................................................29
Loading default values ...........................................................................................................................................29
TVPC Operations .............................................................................................................................................................30
Viewing the TVPC ..................................................................................................................................................30
Selecting the Signal Source for the TVPC Frame..................................................................................................30
Changing Channels for the TVPC Frame...............................................................................................................30
Changing the Position of the TVPC Frame ............................................................................................................31
Adjusting the Size of TVPC Frame.........................................................................................................................31
Viewing Picture-by-Picture .....................................................................................................................................31
Using Hotkeys ..................................................................................................................................................................32
Setting Sleep Timer................................................................................................................................................32
Setting Audio Mode................................................................................................................................................32
To pause Picture.....................................................................................................................................................32
Viewing Closed Captions..................................................................................................................................................33
Turning Closed Caption On or Off..........................................................................................................................33
Setting Closed Caption...........................................................................................................................................33
Setting CC When Mute...........................................................................................................................................33
Adjusting Child Lock Settings ...........................................................................................................................................34
Child Lock...............................................................................................................................................................34
Turning Child Lock On or Off..................................................................................................................................36
Changing the Password .........................................................................................................................................36
Adjusting the Movie Rating.....................................................................................................................................36
Adjusting the TV Rating..........................................................................................................................................36
Adjusting Canadian English Rating........................................................................................................................37
Adjusting Canadian French Rating.........................................................................................................................37
Troubleshooting................................................................................................................................................................38
Care and Maintenance
Specification .....................................................................................................................................................................40
.....................................................................................................................................................39
Important Information
WARNING:
CAUTION-To reduce the risk of electric shock, do not perform any
"Note to CATV system installer: This reminder is provided to call the CATV system installer's attention to Article 820-40 of the National Electrical
Code that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system
of the building, as close to the point of cable entry as practical.”
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE.
The lightning flash with arrowhead symbol,
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
servicing other than that contained in the operating
instructions unless you are qualified to do so.
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dan g e rou s volt a g e wi t h in th e prod u c t's
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
p r es e nc e of i mp or t a nt o pe ra t i ng a nd
maintenance (servicing) instructions in the
literature accompanying the appliance.
This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury. Disposal of these materials may be regulated due
to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance:
www.eia.org
FCC STATEMENT
FCC Notice
LCD TV: A CLASS B digital device
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his own expense.
FCC CAUTION:
Pursuant to 47CFR, Part 15.21 of the FCC rules, any changes or modifications to this monitor not expressly approved by the
manufacturer could cause harmful interference and would void the user's authority to operate this device.
WARNING: This is a CLASS B product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures to counter interference.
1
Important Safety Precautions
Electrical energy can perform many useful functions, but it can also cause personal injuries and property damage if improperly handled.
This product has been engineered and manufactured with the highest priority on safety. But IMPROPER USE CAN RESULT IN
POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order to prevent potential danger, please observe the following instructions
when installing, operating and cleaning the product. To ensure your safety and prolong the service life of your LCD TV product, please read
the following precautions carefully before using the product.
1. Read these instructions---All operating instructions must be read and understood before the product is operated.
2. Keep these instructions---These safety and operating instructions must be kept in a safe place for future reference.
3. Heed all warnings---All warnings on the product and in the instructions must be observed closely.
4. Follow all instructions---All operating instructions must be followed.
5. Do not use this apparatus near water---for example, near a bathtub, washbowl,
kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.
Do not use immediately after moving from a low temperature to high temperature
environment, as this causes condensation, which may result in fire, electric shock, or
other hazards.
6. Clean only with dry cloth---Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
7. Ventilation---Do not block any ventilation openings. Install in accordance with the
manufacturer instructions. The vents and other openings in the cabinet are designed for
ventilation. Do not cover or block these vents and openings since insufficient ventilation
can cause overheating and/or shorten the life of the product. Do not place the product on
a bed, sofa, rug or other similar surface, since they can block ventilation openings. This
product is not designed for built-in installation; do not place the product in an enclosed
place such as a bookcase or rack, unless proper ventilation is provided or the
manufacturer’s instructions are followed.
8.Heat sources---Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9.Grounding or Polarization---Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10.Power cord protection---Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
11.Attachments---Only use attachments/accessories specified by the manufacturer. Do not use attachments not recommended by the
manufacturer. Use of improper attachments can result in accidents.
2
Important Safety Precautions (continued)
12. Stand---Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. Do not place the product on an unstable trolley, stand, tripod or table.
Placing the product on an unstable base can cause the product to fall, resulting inserious personal
injuries as well as damage to the product. When mounting the product on a wall, be sure to follow
the manufacturer’s instructions. Use only the mounting hardware recommended by the
manufacturer.
13. Move Carefully---When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over. Sudden stops, excessive force and uneven floor surfaces
can cause the product to fall from the trolley.
14. Lightning---Unplug this apparatus during lightning storms or when unused for long periods of
time.
For added protection for this television equipment during a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the
antenna. This will prevent damage to the equipment due to lightning and power-line surges.
15. Servicing---Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
16. Replacement parts---In case the product needs replacement parts, make sure that the service person uses
replacement parts specified by the manufacturer, or those with the same characteristics and performance as the
original parts. Use of unauthorized parts can result in fire, electric shock and/or other danger.
17.Ove r l oadin g - --Do n o t overl o a d wal l outle t s , exte n s ion c o r ds, or c onven i e n ce re c e ptacle s on ot h e r
equipment as this can result in a risk of fire or electric shock.
18.Entering of objects and liquids---Never insert an object into the product through vents or openings. High voltage flows in the product,
and inserting an object can cause electric shock and/or short internal parts. For the same reason, do not spill water or liquid on the product.
19.Damage requiring service---If any of the following conditions occurs, unplug the power cord from the AC outlet, and request a qualified
service person to perform repairs.
a. When the power cord or plug is damaged.
b. When a liquid is spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d. When the product does not operate properly as described in the operating instructions. Do not touch the controls other than those
described in the operating instructions. Improper adjustment of controls not described in the instructions can cause damage, which often
requires extensive adjustment work by a qualified technician.
e. If the product has been dropped or the cabinet has been damaged in any way.
f. When the product displays an abnormal condition or exhibits a distinct change in performance. Any noticeable abnormality in the product
indicates that the product needs servicing.
20.Safety checks---Upon completion of service or repair work, request the service technician to perform safety
checks to ensure that the product is in proper operating condition.
21.Wall or ceiling mounting---When mounting the product on a wall or ceiling, be sure to install the product according to the method
recommended by the manufacturer. This is a safety precaution.
3
Important Safety Precautions (continued)
22. Power source---This product is intended to be supplied by a listed power supply indicated on the marking label. If you are not sure of the
type of power supply to your home, consult your product dealer or local power company. For added protection for this product during a
lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the cable
system. This will prevent damage to the product due to lightning and power line surges. When the unit has to be used with another power
supply voltage, the power cable must be changed. Consult your product dealer. The socket outlet should be installed near the equipment
and easily accessible. Use only the power cord designated by our dealer to ensure safety and EMC. When connecting other products such
as VCRs and personal computers, you should turn off the power of the unit for protection against electric shock.
23.Panel protection---The LCD panel used in this product is made of glass. Therefore, it can break
when the product is dropped or impacted upon by other objects. Be careful not to be injured by
broken glass pieces in case the LCD panel breaks.
24.Pixel defect---The LCD panel is a very high technology product, giving you finely detailed pictures. Occasionally, a few non-active
pixels may appear on the screen as a fixed point of blue, green or red. Please note that this does not affect the performance of your product.
<If an outside antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide some protection
against voltage surges and built-up static charges. Section 810 of the National Electrical Code provides information with respect to
proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL
ELECTRICAL CODE
NEC—NATIONAL ELECTRICAL CODE
<An outside antenna system should not be located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can collide with such power lines or circuits. When
installing an outside antenna system, extreme care should be taken to keep from touching such
power lines or circuits, as contact with them might be fatal.
4
Preparations
Using the Remote Control
<Use the remote control by pointing it towards the remote sensor window of the set. Objects between
the remote control and sensor window may prevent proper operation.
Note: This illustration is for reference only. The remote sensor may be in different locations on
different models.
3
03
0
Cautions regarding use of remote control
<Do not expose the remote control to shock. In addition, do not expose the remote control to liquids,
and do not place in an area with high humidity.
<Do not install or place the remote control under direct sunlight. The heat may cause deformation of the unit.
<The remote control may not work properly if the remote sensor window of the main unit is under direct sunlight or strong lighting. In such a
case, change the angle of the lighting or LCD TV set, or operate the remote control closer to the remote sensor window.
Batteries for the Remote Control
If the remote control fails to operate the LCD TV functions, replace the batteries in the remote control.
Open the battery cover.
1
Insert two size-AA batteries.
2
<(Place the batteries with their terminals
corresponding to the (+) and (–) indications in
the battery compartment.)
Replace the cover.
3
5m
+
-
+
-
Precaution on battery use
Improper use of batteries can result in a leakage of chemicals and/or explosion. Be sure to follow the instructions below.
<Place batteries with their terminals corresponding to the (+) and (–) indications.
<Different types of batteries have different characteristics. Do not mix batteries of different types.
<Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries and/or cause old batteries to leak
chemicals.
<Remove batteries as soon as they are non-operable. Chemicals that leak from batteries can cause skin irritation. If chemical leakage is
found, wipe with a cloth.
<The batteries supplied with the product may have a shorter life expectancy due to storage conditions.
<If the remote control is not used for an extended period of time, remove the batteries from the remote control.
Power Connection
Household
power outlet
bottom view
AC INPUT
AC cord
1. Connecting the female plug to the AC socket on the unit.
2. Connecting the male plug to the wall outlet as illustrated.
Note:
<This illustration is for reference only. The AC plug may be different on different models.
<This product should be operated only from the type of power source indicated on the marking label.
<Always unplug the AC cord from power outlet when not using for a long period of time.
Plug into AC outlet.
5
Preparation (continued)
Antenna Connection
CABLE TV (CATV) CONNECTION
A 75-ohm coaxial cable connector is built into the set for easy hookup. When connecting the 75- ohm coaxial cable to the set, screw the 75ohm cable to the ANT. Terminal.
Some cable TV companies offer “premium pay channels”. Since the signals of these premium pay channels are scrambled, a cable TV
converter/descrambler is generally provided to the subscriber by the cable TV company.
This converter/descrambler is necessary for normal viewing of the scrambled channels. For more specific instructions on installing cable
TV, consult your cable TV company. One possible method of utilizing the converter/descrambler provided by your cable TV company is
explained below. Please note: An RF switch provided with two inputs (A and B) is required (not supplied).
RF switch (not supplied)
OUT
Cable TV converter/
descrambler
(not supplied)
IN
Two-set
signal
splitter
(not
supplied)
Cable TV Line
“A” position on the RF switch (not supplied) : You can view all unscrambled channels by using the TV’s channel keys.
“B” position on the RF switch (not supplied) : You can view the scrambled channels via the converter/descrambler by using the converter’s
channel keys.
Note:
Consult your Dealer or Service Center for the type of splitter, RF switch or combiner that might be required.
ANTENNAS
The antenna requirements for good color television reception are more important than those for black & white television reception. For this
reason, a good quality outdoor antenna is strongly recommended.
The following is a brief explanation of the type of connections that are provided with the various antenna systems.
1. A 75-ohm system is generally a round cable with F-type connector that can
easily be attached to a terminal without tools (not supplied).
2. A 300-ohm system is a flat “twin-lead” cable that can be attached to a 75-ohm
terminal through a 300-75-ohm adapter (not supplied).
F-type connector
75-ohm coaxial cable (round)
300-ohm twin-lead cable (flat)
OUTDOOR ANTENNA CONNECTION
Use one of the following two diagrams if you connect an outdoor antenna.
A: Using a VHF/UHF combination outdoor antenna.
B: Using separate VHF and/or UHF outdoor antennas.
Connect the outdoor antenna cable lead-in to the ANT. terminal on the rear of the
TV set.
Antenna cable
VHF/UHF
antenna
A. Combination VHF/UHF Antenna
300/75-ohm
adapter
(not supplied)
or
300-ohm
twin-lead
75-ohm
coaxial cable
B. Separ ate VHF And/or
UHF Antennas
UHF
antenna
300-ohm
twin-lead
Combiner
(not supplied)
OUT IN
300-ohm
twin-lead
75-ohm
coaxial cable
VHF/UHF
antenna
VHF
antenna
or
6
Identification of Controls
Main Unit
AC INPUT
Power Indicator
Remote Sensor
A blue indicator lights when the power is on and a red
indicator lights when in the standby mode.
CH+
CH–
VOL+
VOL–
INPUT
MENU
Channel Up/Down
Volume Up/Down
Select Input Signal
Menu
Power On/Standby
1. POWER
Press this button to turn the unit ON from STANDBY mode. Press it again to turn the set back to STANDBY.
2. MENU
Press this button to access the Menu main page.
3. INPUT
To access signal source select menu.
4. VOL+/-
Press the vol+ or vol- button to directly increase or decrease the sound volume level;
In OSD Menu, press these buttons to adjust the value or setting of each item.
5. CH+/-
Press these two buttons to directly change the TV channel;
In OSD Menu, press these buttons to choose the OSD items.
Note:
Functions of VOL+/-, CH+/-, MENU, INPUT and POWER are also provided to the remote control. This operation manual provides a
description based on operating functions with the remote control.
7
Main Unit
Identification of Controls (continued)
ANTENNA INPUT
HEADPHONE
-
AVI IN PUT/
S-V IDEO IN
AV2 INPUT
AV OUT
S-VIDEO
AUDIO R
AUDIO L/MONO
VIDEO
AUDIO R
AUDIO L/MONO
VIDEO
AUDIO R
AUDIO L
VID EO
S VIDE O
R
AUDIO
L/MONO
VIDEO
AV1 IN/ S-V IDEO IN
VGA
AUDIO
DVI-D
-D I D IN
V
AUDIO
HDT V IN
AUDIO
DVI-D
AUDIO
Y
Pb
Pr
AUDIO R
AUD IO L
VGA IN
DVI-D IN
Component inputs
1. Antenna input
Allows you to connect cable or outdoor antenna.
2. Headphone jack
3. AV1 inputs (Video, Audio L/mono, R) / S-Video input
Receive video/audio signals from external sources such as VCR or DVD player.
Receive a S-Video signal from external source such as VCR or DVD player.
4. AV2 inputs (Video, Audio L/mono, R)
Receive video/audio signals from external sources such as VCR or DVD player.
5. AV outputs (Video, Audio L/mono, R)
Connect to the VCR input jacks to record programs.
6. VGA input /Audio in
Connect to the VGA/audio outputs on your PC.
7. DVI input /Audio in
Connect to the DVI/audio outputs on your DTV receiver.
8. Component inputs (Y, Pb/Cb, Pr/Cr, Audio L, R)
Connect to the audio and component output jacks of a DVD player or Set-Top Box.
Note:
The AV output terminals output audio/video signal inputted from Antenna input or AV inputs.
8
Identification of Controls (continued)
Remote Control
1
2
4
5
7
3
6
1. POWER
Turn the unit on or off
2. 0~9 number buttons
Direct channel select
3. ENTER button
Channel enter button
4. INPUT
To access source select menu
5. LAST
To quickly jump between current channel and last selected
channel.
6. VOL+/-
Used to adjust volume.
10
11
8
9
7. CH+/-
Used to switch channels.
8. MUTE
Sound mute
9. MENU
To access the Menu main page or exit menu operation
10. Menu navigation button: 5634
In Menu operation, use 5/6 to select menu item;
Use 3/4to adjust selected item;
OK button
To confirm, enter submenu or toggle between the settings of the
selected menu item.
11. EXIT
Used to exit the current menu and return to upper level menu.
Note:
In menu operation, CH+/- and VOL+/- button also can be used to navigate
in menus.
9
Remote Control
Identification of Controls (continued)
12. ASPECT
To select screen aspect ratio
13. DISPLAY
To display channel status or signal information
14. STEREO
To select STEREO, SAP or MONO
15. SRS
To turn on or off the SRS sound effect *
16. PIP
To activate picture-by-picture
17. SIZE
To adjust TVPC frame size
12
13
14
15
16
17
18
19
20
21
22
23
18. CAPTION
To select CCD on/off and CCD channel
19. SLEEP
To set Sleep timer
20. PICTURE MODE
Picture mode select
21. SOUND MODE
Sound mode select
22. PIP INPUT
To select signal source for TVPC frame
23. TV/PC
To activate TVPC function
Note:
The TVPC function means you may view a TV program from a mini window
while the main window is displaying a PC screen.
The SRS symbol is trademark of SRS Labs,Inc.
*
SRS technology is incorporated under license from SRS Labs, Inc.
10
Connections
Cautions Before Connecting
Carefully check the terminals for position and type before making any connections.
The illustration of the external equipment may be different depending on your model.
Loose connectors can result in image or color problems. Make sure that all connectors are securely inserted into their terminals.
Refer to the operating manual of the external device as well.
When connecting an external device, turn the power off on the panel to avoid any issues.
Connect a VCR
ANTENNA
INPUT
HEADPHONE
AVI IN PUT
S VIDE O
R
AUDIO
L/MONO
VIDEO
-
RR
AV1 IN/ S-V IDEO IN
WW
S-video
cable
or
AV2 INPUT
AV OUT
Video
YY
cable
VCR
YY
Yellow (VIDEO)
WW
White (AUDIO L)
RR
Red (AUDIO R )
How to connect:
Connect the Audio/Video cables between the Audio (L/R)/Video jacks on the unit and VCR.
Note:
For better video, you can use the S-video terminal if your source supports it.
To play VCR
1. Turn on your LCD TV , press INPUT button on the remote control.
2. Press 5or6 to select Video1(AV1 IN) or SVideo and press OK to confirm.
3. Turn on your VCR , insert a videotape and press the Play button.
Audio
cable
AV OUT
AV IN
WW
AUDIO
AUDIO
RLVIDE O
RLVIDE O
YY
Rear of the VCR
Source Select
YPbPr1
YPbPr2
RR
-
S V IDEO
VGA
DVI
RF
Vide o1
Vide o2
SVid eo
ANT INANT OUT
11
Loading...
