Polar CS400 User Manual
Polar CS400
User Manual
Polar CS400 User Manual 2
Contents
1. INTRODUCTION ............................................................................................................ 4
2. CYCLING COMPUTER COMPONENTS ................................................................................... 4
3. GETTING STARTED........................................................................................................ 5
Measuring Wheel Size................................................................................................... 5
Basic Settings............................................................................................................. 5
Menu Structure ........................................................................................................... 7
4. PREPARE FOR TRAINING................................................................................................. 7
Plan your training ........................................................................................................ 7
Exercise Types ......................................................................................................... 7
Create New Exercises With Your Cycling Computer........................................................... 8
Create New Exercises with Polar ProTrainer 5 ............................................................... 10
5. TRAINING..................................................................................................................10
Wear the Transmitter....................................................................................................10
Start Training.............................................................................................................10
Information on the Display .............................................................................................11
Graph view ............................................................................................................ 12
Symbols on the Display.................................................................................................13
Button Functions During Exercise.....................................................................................14
Take a Lap ............................................................................................................ 14
Lock a Zone........................................................................................................... 14
Zoom the Display ................................................................................................... 15
Illuminate the Display (Night mode on) ....................................................................... 15
View Settings Menu................................................................................................. 15
Pause Exercise....................................................................................................... 15
Stop Exercise ............................................................................................................16
6. AFTER TRAINING ........................................................................................................16
Analyze Exercise Results...............................................................................................16
Exercise Log .......................................................................................................... 16
Weekly Summary ................................................................................................... 22
Totals................................................................................................................... 23
Delete Files .......................................................................................................... 23
7. SETTINGS .................................................................................................................23
Exercise types............................................................................................................23
Feature Settings .........................................................................................................23
Altitude ................................................................................................................ 23
Recording Rate ...................................................................................................... 24
Automatic Lap Recording ......................................................................................... 25
Using the HeartTouch Function CS400 ...................................................................... 25
Heart Rate View ..................................................................................................... 25
Sport Zones .......................................................................................................... 25
Bike Settings .............................................................................................................25
Wheel Size ........................................................................................................... 26
Autostart: On / Off .................................................................................................. 26
Arrival time ........................................................................................................... 26
Speed: On / Off ..................................................................................................... 26
Cadence*: On / Off.................................................................................................. 26
User Settings .............................................................................................................27
Heart Rate: HRmax, HRsit........................................................................................ 27
Maximal Oxygen Intake: VO2max................................................................................ 27
General Settings ........................................................................................................27
Sound ................................................................................................................. 28
Volume................................................................................................................. 28
Polar CS400 User Manual 3
TZ Alarm (Target Zone Alarm).................................................................................... 28
Keylock ............................................................................................................... 28
Units.................................................................................................................... 28
Language ............................................................................................................. 28
Sleep .................................................................................................................. 28
Watch Settings...........................................................................................................28
Reminder ............................................................................................................. 28
Event ................................................................................................................... 29
Alarm .................................................................................................................. 29
Time .................................................................................................................... 29
Time zone ............................................................................................................. 30
Date .................................................................................................................... 30
Personalize the Cycling Computer Display ..........................................................................30
Shortcut Button (Quick Menu) .........................................................................................30
8. TRAINING PROGRAM ....................................................................................................30
View Program ...........................................................................................................30
Perform Programmed Exercise ........................................................................................32
Start Exercising...................................................................................................... 32
Exercise with Phases ............................................................................................... 32
Views during the exercise ......................................................................................... 32
Functions During Exercise ........................................................................................ 33
Lap Menu ............................................................................................................. 33
9. TESTS......................................................................................................................33
Polar Fitness Test™.....................................................................................................33
Before the Test ...................................................................................................... 34
Performing the Test................................................................................................. 34
After the Test ........................................................................................................ 35
10.BACKGROUND INFORMATION ..........................................................................................36
Polar Sport Zones .......................................................................................................36
OwnZone Training .......................................................................................................37
Maximum Heart Rate ...................................................................................................38
Heart Rate Value in a Sitting Position ...............................................................................38
Heart Rate Reserve .....................................................................................................38
Heart Rate Variability...................................................................................................39
Polar Article Library.....................................................................................................39
11.CUSTOMER SERVICE INFORMATION ..................................................................................39
Care and Maintenance..................................................................................................39
Caring of Your Product............................................................................................. 39
Service ................................................................................................................. 40
Changing Batteries.................................................................................................. 40
Changing Cycling Computer Battery ............................................................................ 40
Precautions...............................................................................................................41
Interference During Exercise .................................................................................... 41
Minimizing Risks When Exercising.............................................................................. 42
Technical Specifications...............................................................................................42
Frequently Asked Questions............................................................................................44
Limited Polar International Guarantee ...............................................................................45
Polar Disclaimer .........................................................................................................46
INDEX ......................................................................................................................47
Polar CS400 User Manual 4
1. INTRODUCTION
Congratulations! You have purchased a complete training system to tailor-fit your training needs. This
user manual includes complete instructions, helping you get the most out of your cycling computer.
2. CYCLING COMPUTER COMPONENTS
1. Polar CS400 Cycling Computer: Cycling and exercise data are recorded and displayed during
exercise.
2. Polar WearLink®31 Coded Transmitter: The transmitter sends the heart rate signal to the cycling
computer. The transmitter consists of a connector and a strap.
3. Polar Bike Mount™: Secure the bike mount to your bike and attach the cycling computer to it.
4. Polar Speed Sensor™: A wireless speed sensor measuring speed and distance during cycling.
5. Optional Cadence Sensor™: A wireless cadence sensor measuring the speed at which you turn the
cranks of your bicycle, expressed in revolutions per minute (rpm).
6. CD-ROM: Including Polar ProTrainer 5™ software and a complete User Manual to help you make
the most out of your cycling computer.
Polar CS400 User Manual 5
3. GETTING STARTED
Before activating your cycling computer, measure the wheel size of your bicycle.
Measuring Wheel Size
Wheel size settings are a prerequisite for correct cycling information. There are two ways of
determining the wheel size of your bike:
Method 1
Look for the diameter in inches or in ETRTO printed on the wheel. Match it to the wheel size in
millimeters in the right column of the chart.
ETRTO
25-559
23-571
35-559
37-622
47-559
20-622
52-559
23-622
25-622
28-622
32-622
42-622
47-622
Wheel size diameter (inches) Wheel size setting (mm)
26 x 1.0 1884
650 x 23C 1909
26 x 1.50 1947
700 x 35C 1958
26 x 1.95 2022
700 x 20C 2051
26 x 2.0 2054
700 x 23C 2070
700 x 25C 2080
700 x 28 2101
700 x 32C 2126
700 x 40C 2189
700 x 47C 2220
Wheel sizes on the chart are advisory as wheel size depends on the wheel type and air pressure.
Method 2
Measure the wheel manually for the most accurate result.
Use the valve to mark the point where the wheel touches the ground. Draw a line on the ground to
mark that point. Move your bike forward on a flat surface for one complete rotation. The tire should be
perpendicular to the ground. Draw another line on the ground at the valve to mark a full rotation.
Measure the distance between the two lines.
Subtract 4 mm to account for your weight on the bike to get your wheel circumference. Enter this
value in the cycling computer.
Basic Settings
Before using your cycling computer for the first time, customize the basic settings. Enter as accurate
data as possible to ensure correct feedback based on your performance.
Polar CS400 User Manual 6
To adjust the data, use UP, DOWN and accept with OK. The values scroll faster if you press and hold
UP or DOWN.
1. To activate your cycling computer, press OK twice. Once activated, it cannot be switched off!
2. Welcome to Polar Cycling World! is displayed. Press OK.
3. Language: Select English, Deutsch, Español, Français or Italiano. Press OK
4. Start with bike settings is displayed. Press OK.
5. Number of bikes: Select 1 or 2 depending on how many bicycles you will be using. If you only use
one bicycle, settings for bike 2 can be entered later. For further information, see Bike Settings.
6. Wheel: Enter the wheel size (mm) for each of your bicycles. For further information, see Measuring
Wheel Size.
7. Start with basic settings is displayed. Press OK and adjust the following data:
8. Time: Select 12h or 24h. With 12h, select AM or PM. Enter the local time.
9. Date: Enter current date; dd = day, mm = month, yy = year. If you use imperial units, set the date;
mm = month, dd = day, yy = year.
10. Units: Select metric (kg/cm/km) or imperial (lb/ft/mi) units.
11. Weight: Enter your weight. To change units, press and hold the LIGHT.
12. Height: Enter your height. In LB/FT format, first enter feet then inches.
13. Birthday: Enter your date of birth; dd=day, mm=month, yy=year.
14. Sex: Select Male or Female.
15. Settings OK? is displayed. Select Yes or No. Select Yes to accept and save settings. The cycling
computer will display time of day. Select No if settings are incorrect and need to be changed.
Press STOP to return to the data you want to change.
Use the Polar ProTrainer 5 software to enter all basic settings.
Polar CS400 User Manual 7
Menu Structure
4. PREPARE FOR TRAINING
Installation of the sensors
Polar Bike Mount and CS400 Cycling Computer
For instructions on how to install the Polar Bike Mount and the Polar CS400 Cycling Computer,
consult Speed Sensor user manual.
Polar Speed and Cadence Sensors
For instructions on how to install the sensors, consult the separate Speed or Cadence user manuals.
Plan your training
Exercise Types
You can utilize the installed ready-made exercises or create new ones on your cycling computer. Plan
and create more versatile exercises and transfer them to your cycling computer by using the Polar
ProTrainer 5 training software. For more information on how to transfer the exercises, see 8. Training
Program.
Select Settings > Exercise
The Exercises menu shows a list of exercises.
Polar CS400 User Manual 8
Navigate through the options with UP or DOWN
• Free: Free exercise with no settings.
• Basic: Training with moderate intensity. Duration around 45 min.
• OwnZone: OwnZone-based exercise with moderate intensity. The cycling computer is able to
automatically determine your individual aerobic (cardiovascular) heart rate zone during warm-up.
This is called OwnZone. Suggested duration 45 minutes. For further information, see ???. For
additional background information, see OwnZone Training
• Interval: Interval training starts with a 15-minute warm-up, followed by a 5 km interval (work phase)
and a 5-minute recovery period, repeated 3 times. The session ends with a 15-minute cool-down.
• Add new: Create and save your own exercise. Store a total of 10 exercises + 1 Free exercise in your
cycling computer.
Select the desired exercise (Free, Basic, OwnZone, Interval or Add new), and press OK, the following
options are displayed:
• Select the exercise as a default exercise.
The next time you train, your cycling computer will offer this exercise as default.
• View the exercise settings. Scroll UP or DOWN to view:
1. Basic exercise with 1-3 exercise zones: target heart rate or cadence* limits for each zone,
timer/distance for the zone, or
2. Exercise with phases: name, description, target exercise time. (Press and hold LIGHT to view the
exercise phases and chosen sport profile.)
• Edit Basic or OwnZone exercise to fit your needs. You can also edit exercise created with the cycling
computer. For further information, see Create New Exercises With Your Cycling Computer. If you
created exercise with the Polar ProTrainer 5 software that includes phases, you cannot edit them
with the cycling computer.
• Rename Basic, Interval or other exercise created with the cycling computer.
• Default Return to default settings of Basic, Interval or OwnZone exercise.
• Delete exercise you created using the cycling computer or the Polar ProTrainer 5 software.
* Optional sensor required.
Create New Exercises With Your Cycling Computer
Create a New Exercise with Zones
Create your own exercise with the cycling computer.
Select Settings > Exercise > Add new
1. Set the number of zones for the exercise (0-3) and press OK. Also see Creating a New Exercise
Without Zones.
2. Choose zone type:
Polar CS400 User Manual 9
A. Heart rate
B. Cadence*
Press OK.
A. For heart rate, select Sport zone, or Manual to set heart rate zone manually. Press OK.
• Sport zone: Select one of the sport zones (e.g. Z1: 50-59%HR
continue to step 3.
) for your exercise. Press OK to
max
Polar sport zones are heart rate intensity areas expressed in percentages of your maximum heart rate.
Five different sport zones are set in the cycling computer as a default: very light (50-59% HR
(60-69% HR
Default HRmax value is age-based, but if you know your exact aerobic and anaerobic thresholds, have
had your maximum heart rate (HR
heart rate yourself or in a lab, then you can define sport zones will better suit your training needs.
), moderate (70-79% HR
max
), hard (80-89% HR
max
-p) predicted in a Polar Fitness Test™, tested your maximum
max
), and maximum (90-99% HR
max
max
), light
max
).
• Manual: Set the high and low zone HR limits as beats per minute (bpm) or HR% and press OK to
continue to step 3.
B. If you selected cadence* zones, set the high and low zone limits. Press OK to continue to step 3.
• If you choose cadence as a zone type, the zones will be expressed in rounds per minute (rpm).
3. Set Zone guide to change zones after a specified time or distance. During your workout, the cycling
computer will alert you when changing zones.
• Timers: Set a timer for the zone (minutes and seconds) and press OK.
• Distances: Set distance for the zone and press OK.
• Off: Deactivate timers and distances and press OK.
Once you have defined the first zone, Zone 1 OK is displayed. For more than one exercise zone, repeat
steps 2 and 3 until all zones are defined.
When the exercise is ready, New exercise added is displayed. The new exercise (NewExe) is stored in the
Exercises menu, where you can select it for your next workout. Rename the exercise by selecting
Rename from the list.
Create a New Exercise Without Zones
To create a new exercise without zones, you can use timers or distances to guide your training.
Select Settings > Exercise > Add new
1. Number of zones: Set the number of zones to 0.
2. Guide type: Choose to sound a timer during workout (reminding you to drink, for example), or set a
distance (for following lap times without recording them).
Timers
• Number of timers: Choose the number of timers (1-3) for the session. Press OK.
• Timer 1: Define minutes and seconds for the timer and press OK.
Distances
• Number of distances: Choose the number of distances (1-3) for the session. Press OK.
• Distance 1: Enter the distance(s) and press OK.
Repeat step 2 until you have defined timers or distances. When the exercise is ready, New exercise
added is displayed. The new exercise (NewExe) is stored in the Exercises menu, where you can select it
for your next exercise. Rename the exercise by selecting Rename from the list.
* Optional sensor required.
Polar CS400 User Manual 10
Create New Exercises with Polar ProTrainer 5
Create more diversified exercises by using Polar ProTrainer 5. For further information, consult Polar
ProTrainer 5 help.
5. TRAINING
Wear the Transmitter
Wear the transmitter to measure heart rate.
1. Moisten the electrode areas of the strap under running water and make sure that they are well
moistened.
2. Attach the connector to the strap. Position the connector's letter L to the word LEFT on the strap
and snap the fastener. Adjust the strap length to fit snugly and comfortably. Secure the strap
around your chest, just below the chest muscles, and snap the second fastener.
3. Check that the wet electrode areas are firmly against your skin and that the Polar logo of the
connector is in a central, upright position.
4. To detach the connector from the strap, apply pressure with your thumb and forefinger and turn
your hand as indicated in the picture.
The Polar WearLink transmitter can be used with specific apparel that has built-in soft textile
electrodes. Wet the electrode areas of the apparel. Clip the connector of the transmitter straight onto
the apparel without the strap so that connector’s Polar logo is in an upright position.
Start Training
Wear the transmitter and attach the cycling computer to the bike mount.
1. Start heart rate measurement by pressing the OK button. The cycling computer goes into pause
mode.
2. Select the bike you are going to exercise with. Bike 1 is set as a default. Select Settings > Bike >
Bike 1 > OK. Select Other if you only want to record heart rate.
Only the bikes that are switched ON are shown on this selection list. For further information see Bike
Settings.
The number on the bottom, right hand corner indicates the bike that is going to be used. By pressing
Polar CS400 User Manual 11
and holding the DOWN button, you can switch the bike quickly or switch to heart rate recording only.
By pressing and holding the UP button you can switch the exercise quickly.
3. Within 15 seconds, your heart rate appears on the display. The frame around the heart symbol
indicates that transmission is coded. The cyclist symbol on the bottom, left hand corner indicates
that bike 1 or 2 is in use.
If you want to change or view different exercise settings before you start training select Settings >
Exercise. Select an exercise type or view exercise settings.
Exercise: Select Free, Basic, OwnZone or Interval, and press OK. (If you created new exercises, these
will be listed, as well.)
Select: Set a default exercise to be performed the next time you train.
View: View exercise settings.
• Altitude: Calibrate altitude.
• Rec.rate: Set the recording rate.
• TZ Alarm: Switch target zone alarm sounds on or off.
• HR view: Choose to view heart rate in beats per minute (bpm),or as a percentage of maximum heart
rate (HR%).
• HeartTouch: Set the HeartTouch function.
• Bike: Select bike 1 or 2.
• A.Lap (Automatic Lap): Switch the automatic lap function On/Off.
• Arr. time: Set the arrival time function On/Off and set the distance of your ride.
• Display: Modify the display. For further information, see Personalize the Cycling Computer Display.
Here are some shortcuts you can use, when in Exercise pause menu:
• Press and hold UP to quickly change training session type. The default training session type is Free
exercise.
• Press and hold DOWN to quickly change the bikes.
• Press BACK to enter to Time mode.
• Press and hold LIGHT to view the Settings menu
If you activate the AutoStart function, the cycling computer will automatically start and stop exercise
recording when you start and stop cycling. For further information on AutoStart, see Autostart: On / Off .
The cycling computer automatically chooses the bike you have used during the previous exercise.
4. Start exercising by pressing OK. The exercise type is displayed in the upper left-hand corner.
If the following message is displayed: (Exercise name) requires Speed/ Cadence* sensor. Turn Speed/
Cadence sensor on, your exercise requires this sensor to display speed/ cadence* data (e.g. you have
defined speed or cadence zones for the exercise). Select Yes to turn the sensor function on. If Exercise
displays updated is displayed, speed/ cadence* data will be shown during exercise.
* Optional sensor required.
Information on the Display
Your cycling computer offers you a simultaneous view of three different lines of exercise information.
By pressing UP or DOWN, you can view different displays. The name of the display appears for a few
seconds. The name indicates the lower row information. The display varies depending on the sensors
you have installed, which features are set ON and what kind of exercise you are performing.
Customize the cycling computer display easily with Polar ProTrainer 5 software.
Polar CS400 User Manual 12
Default Views on Your Display When Using Speed Sensor
Speed
Heart rate
Trip distance
Speed in km/h
Heart Rate
Burned calories/ hour
Trip distance
Current heart rate
Stopwatch
Average heart rate
Average speed
Stopwatch
Altitude
Time of day
Incline
Altitude in meters
Graph
Heart rate graph
Altitude in graph
Stopwatch (Total duration of the exercise so far)
Zonelock
Countdown timer
Zone pointer
Current heart rate
Customize the cycling computer display to show information you want to see. See Personalize the
Cycling Computer Display.
If a cadence sensor is installed, you have a variety of ways to display data.
Graph view
The graph view enables comparison in graphs of two values during exercise. For example, choose a
graphical overview of your heart rate and speed.
The graph view can be customized. For the upper and middle rows, you can choose to view Speed,
Altitude or Heart rate in graphs.
Polar CS400 User Manual 13
Symbols on the Display
Text on the display
Time of day
Cycling symbol
Bike number
Key lock on
Rec -symbol
Interval icon
Countd. Timer
Lap number and time
Lap distance*
Symbol Explanation
Time of day
Recording mode: indicates that
bike 1 or 2 on and bike date is
recorded.
The number on right, bottom
corner indicates which bike is in
use during this exercise.
Indicates that the key lock is on.
Displayed in the exercise mode
when stopwatch time is running
and the recordings are on. The
symbol is blinking when memory
is low.
Indicates that Interval exercise is
chosen.
Countdown timer
Lap number and lap time
This will show the distance of the
current lap.
Stopwatch
Heart rate
Heart rate
Calories
Distance
Trip
If you record a lap time by
pressing OK, it will also reset
the Trip distance. This will be
done automatically if the
Autolap function is ON.
Total duration of the exercise so
far
Current heart rate
Average heart rate
Expended calories in kcal or Cal
Distance cycled
Distance between points A and
B. This distance is reset every
time OK button is pressed.
Pressing OK will also reset the
Lap distance. This will be done
automatically if the Autolap
function is ON.
Polar CS400 User Manual 14
Text on the display
Arrival time
Ascent
Inclinometer
Altitude
Cadence*
Speed
Max speed
Avg speed
Zone pointer (heart rate)
Zone pointer*(cadence)
Time in zone
Symbol Explanation
Estimated time of arrival
Ascended meters/ feet
Uphill/downhill steepness in
percentages and grades.
Estimates in numerical form how
steep uphill or downhill you are
cycling and helps you to adjust
cycling effort accordingly.
Current altitude
Measures the speed at which you
turn the cranks of your bicycle
(i.e. cadence), in revolutions per
minute (rpm).
Speed you are currently cycling
on
The maximum speed during you
training
The average speed you are
cycling on
If the heart symbol is not visible
and/or an alarm sounds, your
heart rate is outside the target
zone.
If the cadence symbol is not
visible and/or an alarm sounds,
you are outside the target
cadence zone limits.
Time spent on the zone
Button Functions During Exercise
Take a Lap
Press OK to record a lap. The display will show:
Lap number
Average heart rate of the lap
Lap time
Lap number
Lap distance
Average speed
Lock a Zone
When training without preset target zones (FREE exercise), you can lock your heart rate into a sport
Polar CS400 User Manual 15
zone. For more information see Polar Sport Zones. This way, if you haven’t had time to define preset
target zones prior to exercise, you can set a target zone on the go during a session.
Press and hold LAP (OK) to Lock /Unlock zone.
If, for example, you are cycling with a heart rate of 130 bpm which is 75% of your maximum heart
rate, and matches sport zone 3, you can press and hold LAP to lock your heart rate into this zone. Sport
zone3 Locked 70-79 is displayed. An alarm sounds if you are below or above the sport zone (if the target
zone alarm function is on). Unlock the sport zone by pressing and holding OK again: Sport zone3
Unlocked is displayed.
Zoom the Display
Press and hold UP to zoom into the upper row, and DOWN to zoom into the middle row. Return to the
normal display by pressing and holding the button again.
Illuminate the Display (Night mode on)
To illuminate your display, press LIGHT during the exercise. Night mode is turned on, and the display
illuminates automatically when any button is pressed or exercise phase is changed.
View Settings Menu
Press and hold LIGHT > Settings
The Settings menu is displayed when pressing and holding LIGHT. In the settings menu you can change
certain settings without pausing the exercise recording. The contents of this menu vary according to
the exercise type. For further information, see 7. Settings.
• Prev. phase: View summary information of the previous phase or repetition (displayed when you have
created an exercise with phases with the Polar ProTrainer 5 software).
• Keylock: Lock/unlock buttons to prevent accidental button presses.
• Autoscr.: Select the Auto scroll On/ Off and displays will scroll during the exercise.
• TZ Alarm: Turn target zone alarm sound on/off.
• Change zone: Switch target zones (displayed when you have defined multiple target zones, except
when an exercise with phases is created with the Polar ProTrainer 5 software).
• HR view: Select how to view your heart rate.
• HeartTouch: Select HeartTouch to view data during exercise without pressing buttons, by bringing
the cycling computer near the Polar logo on the transmitter.
• A.Lap: Switch the automatic lap function on or off.
• Arr. time: Set the arrival time On/Off.
Once modify the settings, the cycling computer will return to exercise mode.
Pause Exercise
Pause exercise recording by pressing STOP.
In pause mode you can:
• Continue: Continue exercise recording.
• Exit: Stop exercise recording.
• Summary: View a summary of functions that were activated during exercise.
• Settings: Change all the same settings as during exercise. Additionally, you can also change display
personalization, which cannot be done during exercise.
• Reset: Delete recorded exercise information. Confirm with OK and press OK again to restart
Loading...
